PHOTOELECTRIC SENSOR
myQ REMOTE LED LIGHT
BATTERY BACKUP CAPABILITY
LIGHT CURTAIN
MECHANICAL LIMIT SWITCH
OPTIONAL ACCESSORIES:
8355W
LIGHT-DUTY DOCK DOOR OPERATOR
Ideal for applications that require full vertical lift
with light-duty cycle requirements.
myQ BUSINESS FACILITY LETS YOU ANALYZE AND OPTIMIZE
PRODUCTIVITY WITH INTUITIVE CONTROL AND MONITORING
CAPABILITIES. ANNUAL SUBSCRIPTION, FIRST YEAR INCLUDED.
LMi5 MONITORS UP TO 5 EXTERNAL SENSORS, ENABLING THE DOCK
DOOR SESSION FEATURE IN myQ BUSINESS FACILITY AND VISUALIZATION
OF PRODUCTIVITY AT THE DOCK.
BUILT-IN WI-FI
®
FOR SIMPLE OPERATOR INTERNET CONNECTION.
RELIABLE
SMART
3-BUTTON STATION INCLUDED STANDARD FOR FLOOR-LEVEL ACCESS.
DOOR LOCK CAPABILITY LETS YOU ADD UP TO (2) DOOR LOCKS TO
YOUR SYSTEM FOR ADDED SECURITY.
BATTERY BACKUP CAPABILITY ENSURES ACCESS EVEN WHEN THE
POWER IS OUT.
SMOOTH SMART/STOP REDUCES WEAR OF YOUR DOOR SYSTEM FOR
LASTING PERFORMANCE.
TIMER-TO-CLOSE CAN BE PROGRAMMED TO CLOSE THE DOOR
AFTER 1, 5 OR 10 MINUTES.
SECURITY+ 2.0
®
SAFEGUARDS FACILITY ACCESS WITH ROLLING CODE
TECHNOLOGY, OPENING FOR REGISTERED DEVICES ONLY.
SAFE
AND
SECURE
WARRANTY: 2 YEARS.
BEYOND INDUSTRY STANDARDS: LIFTMASTER
®
IS COMMITTED TO QUALITY
PRODUCTS, INNOVATIVE DESIGN AND COMPREHENSIVE SERVICES.
PRODUCT GUIDE DDO8900W
LIGHT-DUTY DOCK DOOR OPERATOR
Monitors whether a dock leveler
is deployed or a truck restraint is
engaged; does not require power.
Identifies when a truck has
arrived or left a dock.*
TRAILER PRESENCE SENSOR
Monitors whether a dock
leveler is deployed or a truck
restraint is engaged.*
Programs directly to the
operator and acts as a work light
when the door moves or photo
beams are interrupted.
485LM
LC-36A
WS-SENSOR
PRE-SENSOR
WS-SENSOR-E
827LM841LM
LMS24W/LMS24R
JACKSHAFT (DDO8900W)
WALL MOUNT
for Full Vertical Lift, Lighter
Weight Sectional Doors
DOOR STATUS MONITORING
with myQ
®
Business
™
Facility
and up to 5 External Sensors
Around the Door
AUTOMATIC DOOR LOCK
STROBE
Deadbolts the door automatically
every time it closes; add up to (2)
locks to your system.
Provides visual notification
to deliver an alert when
the door is in motion.*
Powers up the operator when
the power is out.
Provides 36" of increased zone
coverage for additional protection;
indoor use; max. range: 33'.*
POWERFUL ADD-ONS:
Ideal for applications requiring
a large number of remotes
for a common entrance.
REMOTE CONTROLS
813LM
D
O
C
K
D
O
O
R
A
P
P
L
I
C
A
T
I
O
N
S
*External power source required (100MAPS)
KPW250/KPW5
NEMA 4X (water protection
requirements) sealed electronics
for reliable outdoor use.
WIRELESS KEYPAD
LiftMaster offers accessory solutions for any commercial application.
View the full product lineup at LiftMaster.com
STANDARD SPECS.
© 2019 The Chamberlain Group, Inc. All Rights Reserved. LiftMaster, the LiftMaster logo,
myQ and the myQ logo are registered trademarks of The Chamberlain Group, Inc.
300 Windsor Drive, Oak Brook, IL 60523
LiftMaster.com
UL
®
and the UL logo are trademarks of UL LLC © 2019 All Rights Reserved.
Wi-Fi
®
is a registered trademark of Wi-Fi Alliance
LMCDENPGDDO 7/19
- Steel Chassis and Rigid Plastic Cover
- Internal Chain and Sprocket Drive Mechanism
(63:1 Gear Reduction)
- Auto-Force Adjustment for Changing Weather
and Environmental Conditions
- Electronic Limits for Easy Setup
- Expanded Terminal Block on DC Wi-Fi
®
Logic Board
Has Integrated Flasher Circuit and Door Interlock
to Accommodate Commercial Accessories (for
Replacement Logic Boards, Order Part 050DCDDOWF)
COMMERCIAL-GRADE DESIGN
DDO8900W
LIGHT-DUTY JACKSHAFT
DOCK DOOR OPERATOR
LIGHT-DUTY APPLICATIONS.
The DDO Is Designed for Applications Using Full Vertical, Sectional
Commercial Doors Requiring 25 Cycles or Fewer per Day.
This Operator Is Ideal for:
- Warehouses with Full Vertical Lift Dock Doors
- Businesses with Smaller Sectional Vertical Lift Doors
- Distribution Centers
- Third-Party Logistics Facilities (3PL)
- Energy-Conscious Warehouses
- Office/Commercial Facilities with Loading Docks
SECURITY+ 2.0
®
RADIO CONTROLS
Commercial Door Operator
- Frequency Agile on 310, 315 and 390 MHz
Optional 3-Button Remote Control with Open/Close/Stop (813LM)
- Program Using Optional 881LM Control Panel
Optional 1-Button Remote Control (811LM)
6.25"
21.5"
3.2"
7.5"
2.2"
7.9"
MAXIMUM DOOR AREA (SQ. FT.)
MAX. HEIGHT MAX. WIDTH MAX. SQ. FT.
SECTIONAL
HEADROOM CLEARANCE REQUIRED: 3 IN. FROM CENTER OF THE TORSION BAR
MAX DOOR WEIGHT: 300 LBS.
14 FT. OR 16 FT. 180 FT. TOTAL
SPEED
8"
12"
per
second
for door
to move
downward
per
second
for door
to move
upward
Operating Range:
~200'
30.6
CARTONS (1)
CARTON 1: 27.88" x 11.61" x 9.79"
- Commercial Door Opener (DDO8900W)
- Accessory Interface (LMi5)
- (1) Cable Tension Monitor (041A6104);
Additional Monitor Can Be Added
- 3-Button Control Station (02-103)
- The Protector System
®
Safety
Reversing Sensors
SHIPPING.
SHIPPING WEIGHT
(in lbs.)
LMi5
DDO8900W
MASTERFUL ENGINEERING.
- 12V DC
- Automatic Thermal Protection
- Permanent Lubrication
- Duty Cycle: Maximum 10 Cycles
per Hour; Fewer than 25 Cycles
per Day
MOTOR
- 120V AC
- 60 Hz Voltage
- 2.0A Current Rating
- UL
®
Listed
- 6' Power Cord (3-Prong)
POWER
