LMHNTG
FC: 24 ID: 00025
Remove permit while vehicle is in motion.
07/18
07/18
FC: 24 ID: 000025
FC: 24 ID: 000025
LMUNTG Windshield/Headlamp Tag
LiftMaster Vehicle RFID Tags
LMHNTG Hang Tag and LMUNTG LiftMaster Dual-
Purpose Vehicle RFID Tag (Windshield/Headlamp)
UHF RFID Tag Mounting Instructions
LiftMaster Proprietary RFID Tags must be used with LiftMaster RFID Long
Range Reader (LMSC1000). The tags are high performance radio frequency
identifi cation devices. They have been designed to be installed on the
interior (LMHNTG/SPLMHNTG LiftMaster RFID Hang Tag and LMUNTG/
SPLMUNTG LiftMaster Dual-Purpose RFID Tag [Windshield/Headlamp])
or exterior of the vehicle (LMUNTG/SPLMUNTG LiftMaster Dual-Purpose
RFID Tag [Windshield/Headlamp]). LMUNTG Tag can be installed on
surfaces that are made of glass, plastic or fi berglass. When mounted on
the windshield, these tags are designed to not interfere with the vision of
the driver. Installation of the LMUNTG is critical, as when installed properly
the tags are designed to not interfere or obstruct the headlamp’s beam
per United States DOT specifi cations. Additionally, the LMUNTG offers
an unmatched level of security as their design does not allow them to be
removed or transferred once mounted to the vehicle.
All LiftMaster tags have been tested to withstand a variety of environmental
conditions such as UV exposure, vibration, temperature and humidity
cycles. Tags have been engineered for the rigors of automotive use, but
handle carefully during installation process.
NOTE: Please consult your local and state vehicle ordinances to determine
the allowable mounting locations for this type of tag. Due to the wide
variance in windshield design, this document is intended as a general guide
and not inclusive of all vehicle makes and models. This document serves to
supply only general guidelines for the correct handling and installation of
tags.
NOTE: If the facility code is not visible on the tag it will be “000”.
*If specifi c Facility Code and Start
ID are required, use special part #s
SPLMHNTG, SPLMUNTG.
Choosing a Proper Tag Mounting Location
For optimum performance, the LMUNTG/SPLMUNTG LiftMaster Dual-Purpose RFID Tag (Windshield/Headlamp) must be installed on a windshield location
or other suitable mounting point that is facing the RFID reader during normal driving. Hang Tags (LMHNTG) should be attached to your rear view mirror for
best results.
LMHNTG/SPLMHNTG*
LiftMaster RFID Hang Tag
LMUNTG/SPLMUNTG
LiftMaster Dual-Purpose RFID
Tag (Windshield/Headlamp)
WARNING: This product can expose you to chemicals including
lead, which are known to the State of California to cause cancer or
birth defects or other reproductive harm. For more information go
to www.P65Warnings.ca.gov
NOTE: Use LMHNTG for rear view mirror tag location and LMUNTG for all other tag locations.
Reader
Tag not
read
Tag Read
Zone
Tag not
read
Preferred Tag
Locations
Preferred Tag
Locations
Preferred Tag
Locations
Reader
Reader
Tag Read
Zone
Tag Read
Zone
Correct Driver Side
Reader Placement
Correct Overhead
Reader Placement
Correct Passenger Side
Reader Placement
