Samsung MC17J8100CS/AC - 1.7 cu.ft Over the Range Microwave

User Manual - Transcript

• Page 1 - English - : QUESTIONS OR COMMENTS COUNTRY CALL OR VISIT US ONLINE AT USA Consumer Electronics 1800SAMSUNG 7267864 wwwsamsungcomussupport CANADA 1800SAMSUNG 7267864 wwwsamsungcomcasupport English wwwsamsungcomcafrsupport French Please be advised that the Samsung warranty does NOT cover service calls to explain product operation correct improper installation or perform normal cleaning or maintenance Scan the QR code or visit wwwsamsungcomspsn to view our helpful Howto Videos and Live Shows Requires reader to be installed on your smartphone DE6804224B02 MC17J8100CSACDE6804224B01ENCFRindb 80 11282017 41857 PM
• Page 2: Microwave Oven User manual MC17J8100CS MC17J8100CSACDE6804224B01ENCFRindb 1 11282017 41857 PM
• Page 3 - English - : English Contents Important safety instructions 4 Setting up your new microwave oven 15 Checking the parts 15 Setting up your microwave oven 16 Checking the control panel 17 Setting the time 18 Using my setting feature 18 Using your microwave oven 20 Using the stopclear button 20 Using the child lock 20 Using the kitchen timer 20 Using the microwave 30 sec feature 21 Using the moreless feature 21 Using the eco mode 21 Using the steam clean feature 22 Turntable onoff feature 23 Turning on the light 23 Turning on the vent 23 Using the warm hold feature 24 Using the defrost button 24 Accessory usage Use accessories in the combinations shown below 26 Using the slim fry button 26 Using the t choice button 28 Using the steam cook button 35 Using the speed cook button 38 Using the auto cook button 45 Using the express menu feature 52 Using the microwave setting cooking times amp power levels 54 Power levels 54 Onestage cooking 54 Multistage cooking maximum of 2 stages 55 Brown 56 Convection bakeroast 56 Speed bakeroast 58 Cookware for cooking with speed bakeroast 59 Food suitable for speed bakeroast 59 Speed bakeroast cooking guide 59 Contents MC17J8100CSACDE6804224B01ENCFRindb 2 11282017 41857 PM
• Page 4 - English - : English Contents Cookware guide 61 Recommended cooking utensils 61 Limited use items 61 Not recommended 61 Testing utensils 62 Cooking guide 63 Cooking techniques 63 Recommended cooking utensils 64 Guide for cooking eggs in your microwave 64 Guide for cooking vegetables in your microwave 64 Cleaning and maintaining your microwave oven 65 Cleaning the exterior 65 Cleaning under your microwave oven 65 Cleaning the control panel 65 Cleaning the door and door seals 65 Cleaning the interior 65 Cleaning the turntable and roller rings 65 Storing and repairing your microwave oven 66 Replacing the cooktopnight light 66 Replacing the oven light 67 Cleaning the grease lter 68 Replacing the charcoal lter 69 Troubleshooting 70 Check points 70 Information codes 75 Appendix 76 Specications 76 Warranty 77 Samsung overtherange otr microwave oven 77 MC17J8100CSACDE6804224B01ENCFRindb 3 11282017 41857 PM
• Page 5 - English - : English SAVE THESE INSTRUCTIONS Important safety instructions Congratulations on your new Samsung microwave oven This manual contains important information on the installation use and care of your appliance Please take time to read this manual to take full advantage of your microwave ovens many benets and features WHAT YOU NEED TO KNOW ABOUT SAFETY INSTRUCTIONS Warnings and Important Safety Instructions in this manual do not cover all possible conditions and situations that may occur It is your responsibility to use common sense caution and care when installing maintaining and operating your microwave oven PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY A Do not attempt to operate this oven with the door open since opendoor operation can result in harmful exposure to microwave energy It is important not to defeat or tamper with the safety interlocks B Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on the sealing surface C Do not operate the oven if it is damaged It is particularly important that the oven door close properly and that there is no damage to the 1 Door bent 2 Hinges and latches broken or loosened 3 Door seals and sealing surface D Only properly qualied service personnel should adjust or repair the oven Do not attempt to adjust or repair the oven yourself Important safety instructions MC17J8100CSACDE6804224B01ENCFRindb 4 11282017 41857 PM
• Page 6 - English - : English SAVE THESE INSTRUCTIONS Important safety instructions IMPORTANT SAFETY SYMBOLS AND PRECAUTIONS What the icons and signs in this user manual mean WARNING Hazards or unsafe practices that may result in severe personal injury or death CAUTION Hazards or unsafe practices that may result in minor personal injury or property damage CAUTION To reduce the risk of re explosion electric shock or personal injury when using your microwave oven follow these basic safety precautions Do NOT attempt Unplug the power plug from the wall socket Do NOT disassemble Make sure the machine is grounded to prevent electric shock Do NOT touch Call the service center for help Follow directions explicitly Note These warning signs are here to prevent injury to you and others Please follow them explicitly After reading this section keep it in a safe place for future reference MC17J8100CSACDE6804224B01ENCFRindb 5 11282017 41857 PM
• Page 7 - English - : English Important safety instructions SAVE THESE INSTRUCTIONS Important safety instructions When using any electrical appliance basic safety precautions should be followed including the following WARNING To reduce risk of burns electric shock re personal injury or exposure to excessive microwave energy 1 Read all safety instructions before using the appliance 2 Read and follow the specic Precautions to avoid possible exposure to excessive microwave energy on page 4 3 This appliance must be grounded Connect only to properly grounded outlets See Important Grounding instructions on page 8 of this manual 4 Install or locate this appliance only in accordance with the provided installation instructions 5 Some products such as whole eggs and sealed containers for example closed glass jars can explode if heated rapidly Never heat them in a microwave oven 6 Use this appliance only for its intended use as described in the manual Do not put corrosive chemicals or vapors in or on this appliance This type of oven is specically designed to heat cook or dry food It is not designed for industrial or laboratory use 7 As with any appliance close supervision is necessary when it is used by children Keep children away from the door when opening or closing it as they may bump themselves on the door or catch their ngers in the door 8 Do not operate this appliance if it has a damaged cord or plug if it is not working properly or if it has been damaged or dropped 9 This appliance should be repaired or serviced only by qualied service personnel Contact the nearest authorized service facility for examination repair or adjustment 10 Do not cover or block any openings on the appliance 11 Do not tamper with or make any adjustments or repairs to the door 12 Do not store this appliance outdoors Do not use this product near water for example near a kitchen sink in a wet basement near a swimming pool or similar locations 13 Do not immerse the cord or plug in water 14 Keep the cord away from heated surfaces including the back of the oven 15 Do not let the cord hang over edge of table or counter MC17J8100CSACDE6804224B01ENCFRindb 6 11282017 41857 PM
• Page 8 - English - : English SAVE THESE INSTRUCTIONS Important safety instructions 16 When cleaning surfaces of the door and oven that come together when the door closes use only mild nonabrasive soaps or detergents applied with a sponge or soft cloth Unplug the plug before cleaning 17 To reduce the risk of re in the oven cavity a Do not overcook food Carefully attend appliance when paper plastic or other combustible materials are placed inside the oven to facilitate cooking b Remove wire twistties from paper or plastic bags before placing the bags in the oven c If materials inside the oven ignite keep the oven door closed turn the oven off and disconnect the power cord or shut off the power at the fuse or circuit breaker panel If the door is opened the re may spread d Do not use the cavity for storage purposes Do not leave paper products cooking utensils or food in the cavity when not in use 18 Liquids such as water milk coffee or tea can be overheated beyond the boiling point without appearing to be boiling Visible bubbling or boiling when the container is removed from the microwave oven is not always present THIS COULD RESULT IN VERY HOT LIQUIDS SUDDENLY BOILING OVER WHEN THE CONTAINER IS DISTURBED OR A SPOON OR OTHER UTENSIL IS INSERTED INTO THE LIQUID To reduce the risk of injury a Do not overheat liquid b Stir liquid both before and halfway through heating it c Do not use straightsided containers with narrow necks d After heating allow the container to stand in the microwave oven for a short time before removing the container e Use extreme care when inserting a spoon or other utensil into the container 19 Oversized foods or oversized metal utensils should not inserted in microwave toaster oven as they may create a re of electric shock 20 Do not clean with metal scouring pads Piece can burn off the pad and touch electrical parts involving a risk of electric shock 21 Do not use paper products when appliance is operated in the toaster mode 22 Do not store any materials other than manufacturers recommended accessories in this oven when not in use 23 Do not cover racks or any other part of the oven with metal foil This will cause overheating of the oven MC17J8100CSACDE6804224B01ENCFRindb 7 11282017 41857 PM
• Page 9 - English - : English Important safety instructions SAVE THESE INSTRUCTIONS Important safety instructions CAUTION 1 Clean Ventilating Hoods Frequently Grease should not be allowed to accumulate on the hood of the lter 2 When aming foods under the hood turn the fan on 3 Use care when cleaning the venthood lter Corrosive cleaning agents such as lyebased oven cleaner may damage the lter GROUNDING INSTRUCTIONS This appliance must be grounded In the event of an electrical short circuit grounding reduces the risk of electric shock by providing an escape wire for the electrical current This appliance is equipped with a cord that includes a grounding wire and a grounding plug The plug must be plugged into an outlet that is properly installed and grounded WARNING Improper use of the grounding plug can result in a risk of electric shock Plug into a grounded 3 pronged outlet Do not remove the third grounding prong Do not use an adaptor or otherwise thwart the safety function of the grounding plug Consult a qualied electrician or service person if you do not understand the grounding instructions or if you are not sure if the appliance is properly grounded We do not recommend using an extension cord with this appliance If the powersupply cord is too short have a qualied electrician or serviceman install an outlet near the appliance However if it is necessary to use an extension cord read and follow the Use of Extension Cords section on the next page MC17J8100CSACDE6804224B01ENCFRindb 8 11282017 41857 PM
• Page 10 - English - : English SAVE THESE INSTRUCTIONS Important safety instructions USE OF EXTENSION CORDS A short powersupply cord is provided to reduce the risk of your becoming entangled in or tripping over a longer cord Longer cord sets or extension cords are available and you can use them if you exercise care If you use a long cord or extension cord 1 The marked electrical rating of the cord set or extension cord should be at least as great as the electrical rating of the appliance 2 The extension cord must be a groundingtype 3wire cord and it must be plugged into a 3slot outlet 3 The longer cord should be arranged so that it will not drape over the counter top or tabletop where it can be pulled on by children or tripped over accidentally If you use an extension cord the interior light may icker and the speed of the blower may vary when the microwave oven is on Cooking times may be longer too CRITICAL INSTALLATION WARNINGS This appliance must be installed by a qualied technician or service company Failing to have a qualied technician install the oven may result in electric shock re an explosion problems with the product or injury Unpack the oven remove all packaging material and examine the oven for any damage such as dents on the interior or exterior of the oven broken door latches cracks in the door or a door that is not lined up correctly If there is any damage do not operate the oven and notify your dealer immediately Make sure to install your oven in a location with adequate space Remove all foreign substances such as dust or water from the power plug terminals and contact points using a dry cloth on a regular basis Unplug the power plug and clean it with a dry cloth Failing to do so may result in electric shock or re Plug the power cord into a properly grounded 3 pronged outlet Your oven should be the only appliance connected to this circuit Sharing a wall socket with other appliances using a power strip or extending the power cord may result in electric shock or re Do not use an electric transformer It may result in electric shock or re Ensure that the voltage frequency and current provided match the products specications Failing to do so may result in electric shock or re Keep all packaging materials out of the reach of children Children may use them for play MC17J8100CSACDE6804224B01ENCFRindb 9 11282017 41857 PM
• Page 11 - English - : English Important safety instructions SAVE THESE INSTRUCTIONS Important safety instructions This appliance must be properly grounded Read and follow the specic Grounding instructions found in the beginning of this section Do not ground the appliance to a gas pipe plastic water pipe or telephone line This may result in electric shock re an explosion or problems with the product Never plug the power cord into a socket that is not grounded correctly and make sure that it is grounded in accordance with local and national codes Do not cut or remove the third ground prong from the power cord under any circumstances The microwave requires a separate branch circuit single grounded outlet of at least 15A and max of 20A Do not install this appliance in a humid oily or dusty location or in a location exposed to direct sunlight or water rain drops This may result in electric shock or re Plug the power plug into the wall socket rmly Do not use a damaged power plug damaged power cord or loose wall socket This may result in electric shock or re Do not mount over a sink Do not pull or excessively bend the power cord Do not twist or tie the power cord Do not hook the power cord over a metal object place a heavy object on the power cord insert the power cord between objects or push the power cord into the space behind the appliance This may result in electric shock or re Do not pull the power cord when you unplug the oven Unplug the oven by pulling the plug only Failing to do so may result in electric shock or re When the power plug or power cord is damaged contact your nearest service center for a replacement or repair MC17J8100CSACDE6804224B01ENCFRindb 10 11282017 41858 PM
• Page 12 - English - : English SAVE THESE INSTRUCTIONS Important safety instructions INSTALLATION CAUTIONS Position the oven so that the plug is easily accessible Failing to do so may result in electric shock or re due to electric leakage Unplug the oven when it is not being used for long periods of time or during a thunderlightning storm Failing to do so may result in electric shock or re CRITICAL USAGE WARNINGS If the microwave appliance is ooded please contact your nearest service center Failing to do so may result in electric shock or re Read and follow the specic Precautions to Avoid Possible Exposure to Excessive Mic rowave Energy found in the beginning of this Safety Information Section If the microwave generates a strange noise a burning smell or smoke unplug it immediately and contact your nearest service center Failing to do so may result in electric shock or re In the event of a gas leak propane gas LP gas etc ventilate the room immediately Do not touch the microwave power cord or plug Do not use a ventilating fan A spark may result in an explosion or re Take care that the door or any of the other parts do not come into contact with your body while cooking or just after cooking Failing to do so may result in burns In the event of a grease re on the surface units below the oven smother the aming pan on the surface unit by covering the pan completely with a lid a cookie sheet or a at tray Never leave surface units beneath your oven unattended at high heat settings Boil overs cause smoking and greasy spillovers that may ignite and spread if the vent fan is operating To minimize automatic fan operation use adequate sized cookware and use high heat on surface units only when necessary If materials inside the oven should ignite keep the oven door closed turn the oven off and disconnect the power cord or shut off power at the fuse or circuit breaker panel If the door is opened the re may spread Always observe safety precautions when using your oven Never try to repair the oven on your own There is dangerous voltage inside If the oven needs to be repaired contact an authorized service center near you MC17J8100CSACDE6804224B01ENCFRindb 11 11282017 41858 PM
• Page 13 - English - : English Important safety instructions SAVE THESE INSTRUCTIONS Important safety instructions Do not attempt to repair disassemble or modify the appliance yourself Because a high voltage current enters the product chassis during operation opening the chassis can result in electric shock or re You may be exposed to electromagnetic waves When the oven requires repair contact your nearest service center If any foreign substance such as water enters the microwave unplug it and then contact your nearest service center Failing to do so may result in electric shock or re Do not touch the power plug with wet hands This may result in electric shock Do not turn the appliance off by unplugging the power plug while the appliance is in operation Plugging the power plug into the wall socket again may cause a spark and result in electric shock or re Keep all packaging materials well out of the reach of children Packaging materials can be dangerous to children If a child places a bag over its head the child can suffocate Do not let children or any person with reduced physical sensory or mental capabilities use this appliance unsupervised Make sure that the appliance is out of the reach of children Failing to do so may result in electric shock burns or injury Do not touch the inside of the appliance immediately after cooking The inside of the appliance will be hot The heat on the inside of the oven can cause burns Do not put aluminum foil except as specically directed in this manual metal objects such as containers forks etc or containers with golden or silver rims into the microwave These objects can cause sparks or a re Do not use or place ammable sprays or objects near the oven Heat from the microwave can cause ammable sprays to explode or burn Failing to do so may result in electric shock or injury Do not tamper with or make any adjustments or repairs to the door Under no circumstances should you remove the outer cabinet Do not store or use the oven outdoors MC17J8100CSACDE6804224B01ENCFRindb 12 11282017 41858 PM
• Page 14 - English - : English SAVE THESE INSTRUCTIONS Important safety instructions USAGE CAUTIONS If the surface of the microwave is cracked turn it off Failing to do so may result in electric shock Dishes and containers can become hot Handle with care Hot foods and steam can cause burns Carefully remove container coverings directing steam away from your hands and face Remove lids from baby food before heating After heating baby food stir well to distribute the heat evenly Always test the temperature by tasting before feeding the baby The glass jar or surface of the food may appear to be cooler than the food in the interior which can be so hot that it will burn the infants mouth Make sure all cookware used in the oven is suitable for microwaving Use microwavable cookware in strict compliance with such manufacturers recommendations Do not stand on top of the microwave or place objects such as laundry oven covers lighted candles lighted cigarettes dishes chemicals metal objects etc on the appliance Items such as a cloth may get caught in the door This may result in electric shock re problems with the product or injury Do not operate the appliance with wet hands This may result in electric shock Do not spray volatile material such as insecticide onto the surface of the appliance As well as being harmful to humans it may also result in electric shock re or problems with the product Do not place the appliance over a fragile object such as a sink or glass object This may result in damage to the sink or glass object Do not put your face or body close to the appliance while cooking or when opening the door just after cooking Take care that children do not come too close to the appliance Failing to do so may result in children burning themselves Do not place food or heavy objects over the door when opening the door The food or object may fall and this may result in burns or injury Do not abruptly cool the door the inside of the appliance or the dish by pouring water over it during or just after cooking This may result in damage to the appliance The steam or water spray may result in burns or injury Do not cook without the glass tray in place on the oven oor Food will not cook properly without the tray MC17J8100CSACDE6804224B01ENCFRindb 13 11282017 41858 PM
• Page 15 - English - : English Important safety instructions SAVE THESE INSTRUCTIONS Important safety instructions Do not defrost frozen beverages in narrownecked bottles The containers can break Do not scratch the glass of the oven door with a sharp object This may result in the glass being damaged or broken Do not store anything directly on top of the appliance when it is in operation Do not use sealed containers Remove seals and lids before use Sealed containers can explode due to buildup of pressure even after the oven has been turned off CRITICAL CLEANING INSTRUCTIONS Do not clean the appliance by spraying water directly onto it Do not use benzene thinner or alcohol to clean the appliance This may result in discoloration deformation damage electric shock or re Before cleaning or performing maintenance unplug the appliance from the wall socket and remove food waste from the door and cooking compartment Failing to do so may result in electric shock or re Take care not to hurt yourself when cleaning the appliance externalinternal You may hurt yourself on the sharp edges of the appliance Do not clean the appliance with a steam cleaner This may result in corrosion Keep the inside of the oven clean Food particles or spattered oils stuck to the oven walls or oor can cause paint damage and reduce the efciency of the oven MC17J8100CSACDE6804224B01ENCFRindb 14 11282017 41858 PM
• Page 16 - English - : English Setting up your new microwave oven Setting up your new microwave oven Be sure to follow these instructions closely so that your new microwave oven works properly Checking the parts Carefully unpack your microwave oven and make sure youve received all the parts shown below If your microwave oven was damaged during shipping or if you do not have all the parts contact the Samsung Call Center Refer to the WARRANTY AND SERVICE INFORMATION on page 77 Microwave oven Ceramic Enamel Tray Glass Tray Roller Guide Ring Grease Filters 2ea Charcoal lter Exhaust adaptor Hardware kit Screws amp Brackets Manuals User amp Installation Templates Top amp Wall Cooking Guide Manual Low Rack High Rack NOTE If you need an accessory marked with an asterisk please contact the Samsung Call Center using the phone number listed on the last page of this manual or visit our online parts web site at wwwsamsungpartscom Glass Steamer MC17J8100CSACDE6804224B01ENCFRindb 15 11282017 41859 PM
• Page 17 - English - : English Setting up your new microwave oven Setting up your new microwave oven Setting up your microwave oven 1 Open the door by pulling the handle on the right side of the door 2 Wipe the inside of the oven with a damp cloth 3 Install the preassembled ring into the indentation at the center of the microwave oven 4 Place the glass tray securely in the center of the preassembled roller ring damp cloth preassembled roller ring indentation glass tray MC17J8100CSACDE6804224B01ENCFRindb 16 11282017 41859 PM
• Page 18 - English - : English Setting up your new microwave oven Checking the control panel 01 Turntable OnOff Button 02 Light Button HiLowOff 03 Vent Button 3 Speed amp OnOff 04 Slim Fry Button 05 Fit Choice Button 06 Steam Cook Button 07 Speed Cook Button 08 Express Menu Button 09 Auto Cook Button 10 Convection BakeRoast Button 11 Speed BakeRoast Button 12 Brown Button 13 Warm Hold Button 14 Microwave Button 15 Defrost Button 16 Up amp Down Buttons 17 Numeric Buttons 18 OK Button 19 Kitchen Timer Button 20 Steam Clean Button 21 My Settings Button 22 Eco Mode Button 23 30sec Button 24 StopClear Button 25 Start Button 02 03 05 07 09 13 15 19 21 23 25 04 06 08 10 12 14 18 20 22 2416 MC17J8100CSACDE6804224B01ENCFRindb 17 11282017 41859 PM
• Page 19 - English - : English Setting up your new microwave oven Setting up your new microwave oven 1 Press the My Settings button 2 Press the 9 button 3 Press the OK button 4 Use the numeric buttons to enter the current time You need to press at least three numbers to set the clock For example if the current time is 500 press 5 0 0 The display will show 5 00 5 Press the OK button 1 Press the My Settings button 2 Press one of the numeric buttons to select a function you want to customize 3 Press the OK button 4 Press one of the numeric buttons to select a function you want to customize 5 Press the OK button Setting the time Your microwave oven is equipped with a builtin clock Set the clock when rst installing your microwave oven and after a power failure The time is displayed whenever the microwave oven is not being used Using my setting feature You can customize your new microwave oven to suit your preferences To customize MC17J8100CSACDE6804224B01ENCFRindb 18 11282017 41900 PM
• Page 20 - English - : English Setting up your new microwave oven The functions options and corresponding numeric buttons are listed in the table below No Function Description Options 1 Display Weight Weight options are pounds and kilograms 1 Lb 2 Kg 2 12 HR24 HR The clock can display in either the 12 HR or 24 HR time mode 1 12 HR 2 24 HR 3 Sound Sound can be turned On and Off 1 Sound ON 2 Sound OFF 4 Remind End Signal The Remind End Signal can be turned On and Off 1 ON 2 OFF 5 Daylight Savings Time Adjustment The time can be advanced one hour for DST without resetting the clock 1 ON to advance one hour 2 OFF to go back one hour 6 Demo Mode The Demo Mode can be turned On and Off 1 ON 2 OFF 7 Filter Remind The Filter Remind function can be turned On and Off 1 ON 2 OFF 8 Word Scroll Speed There are three speeds Slow Normal and Fast The default is Normal speed 1 Slow speed 2 Normal speed 3 Fast speed 9 Clock The clock can be adjusted Press the numeric buttons to enter the current time First 2 digits are for hours last 2 digits are for minutes NOTE If you change your mind while adjusting a setting press the STOPCLEAR button to cancel and then adjust the setting again NOTE If there is a power interruption you will need to reset these options NOTE If the clock is set for standard time the Daylight Savings Time Adjustment function allows you to change the time easily without needing to reset the clock Daylight Saving Time begins for most of the United States at 2 am on the rst Sunday of April and reverts to Standard time at 2 am on the last Sunday of October Filter Reminder If the Filter Remind function is ON the microwave will remind you to clean or replace the grease lter every four months When it is time to clean or replace the grease lter the microwave displays the Filter message to remind you to clean or replace the grease lter To remove the message press the number 0 when the microwave is in standby mode If you dont want to receive this message set the Filter Remind function off in My settings MC17J8100CSACDE6804224B01ENCFRindb 19 11282017 41900 PM
• Page 21 - English - : English Using your microwave oven Using the stopclear button The STOPCLEAR button allows you to clear instructions you have entered It also allows you to pause the ovens cooking cycle so that you can check the food To pause the oven during cooking press the STOPCLEAR button once To restart press the START button To stop cooking erase instructions and return the oven display to the time of day press the STOPCLEAR button twice To clear instructions you have just entered press the STOPCLEAR button once and then reenter the instructions To cancel a timer setting press the STOP CLEAR button once Using the child lock The Child Lock function allows you to lock all buttons except Eco Mode so that the microwave oven cannot be operated by children accidentally The oven can be locked at any time Activating Deactivating If you want to activate or deactivate the child lock function press the STOPCLEAR button for 3 seconds The display will show CHILD LOCK ON or CHILD LOCK OFF when the oven is locked or unlocked and then redisplay the time Using the kitchen timer Your microwave has a builtin timer function the Kitchen Timer Use the Kitchen Timer for timing up to 99 minutes 99 seconds 1 Press the Kitchen Timer button 2 Use the numeric buttons to set the time you want the timer to run Max time 99 minutes 99 seconds 3 Press the OK button 4 The display counts down and beeps when the time has elapsed 5 To cancel the timer setting Press the STOPCLEAR button once Using your microwave oven MC17J8100CSACDE6804224B01ENCFRindb 20 11282017 41900 PM
• Page 22 - English - : English Using your microwave oven Using the microwave 30 sec feature This feature offers a convenient way to heat food in set time increments at the High power level 100 power 1 Press the 30 sec button for each additional 30seconds you want the food to be cooked for For example press the button twice to cook for one minute 2 Press the START button NOTE When the oven is operating if you press the 30 sec button the cooking time will be increased by 30 seconds Using the moreless feature The More or Less feature allows you to adjust the preset cooking time It works with 1 and 2stage cooking MW Bake Roast Brown Speed BakeRoast and Warm Hold buttons Using the eco mode Use the More or Less feature only after cooking has begun 1 To ADD more time to a cooking procedure press the More button Each time you press the More button the cooking time will be increased by 10 seconds 2 To REDUCE the time of a cooking procedure press the Less button Each time you press the Less button the cooking time will be decreased by 10seconds Eco Mode reduces standby power usage When you press the Eco Mode button once the display will go out and the microwave shifts to a mode which minimizes power usage To cancel the Eco Mode press the Eco Mode button once again or press any other button MC17J8100CSACDE6804224B01ENCFRindb 21 11282017 41900 PM
• Page 23 - English - : English Using your microwave oven Using your microwave oven Using the steam clean feature The steam provided by the steam clean system will soak the cavity surface After using the steam clean function you can easily clean the cavity of the oven 1 Open the door 2 Carefully pour about 2oz of water into a wide plate 3 Place the plate on the tray of the microwave oven 4 Close the door 5 Press the Steam Clean button 6 Press the START button Steam clean will operate for 6 minutes and 30 seconds The length of time cannot be modied 7 When the cleaning time is over the oven will beep Open the door 8 Clean the cavity of the oven with a dry dishtowel Remove the turntable and wipe under the rack with a piece of paper towel NOTE Use this function only after the oven has completely cooled NOTE Use normal tap water only Do not use distilled water CAUTION The water in the oven will be very hot due to the steam cleaning function Wipe up carefully MC17J8100CSACDE6804224B01ENCFRindb 22 11282017 41901 PM
• Page 24 - English - : English Using your microwave oven Turntable onoff feature For best cooking results leave the turntable on However for large dishes it can be turned off Press the Turntable OnOff button to turn the turntable on or off CAUTION The turntable may become too hot to touch Use pot holders to handle the turntable during and after cooking Press the Light button to turn the cooktop lamp on or off Press the button once for high twice for low and three times to turn the cooktop lamp off Press the Vent button once for high fan speed twice for medium fan speed and three times for low fan speed Press the Vent button four times to turn the fan off Turning on the light Turning on the vent The vent fan removes steam and other vapors that result from cooking on the rangetop below NOTE The exhaust fans speed will decrease when the ovens cooking function is activated NOTE The Vent Fan protects the microwave from excess heat rising from the cooktop below it It automatically turns on if it senses too much heat If you have turned the fan on you may nd that you cannot turn it off The fan will automatically turn off when the internal parts are cool It may stay on for 30 minutes or more after the cooktop and microwave controls are turned off MC17J8100CSACDE6804224B01ENCFRindb 23 11282017 41901 PM
• Page 25 - English - : English Using your microwave oven Using your microwave oven Using the warm hold feature You can keep cooked food warm in your microwave oven for up to 99 minutes and 99 seconds 1 Press the Warm Hold button 2 Enter the warm hold time by pressing the numeric buttons If you dont set the time your oven will maintain the Warm Hold function for 99 minutes 3 Press the START button NOTE Warm Hold operates for up to 99 minutes and 99 seconds NOTE Food that is cooked covered should also be covered during Warm Hold NOTE Pastry items pies turnovers etc should be uncovered during Warm Hold NOTE Complete meals kept warm on a dinner plate can be covered during Warm Hold Below are the amounts of food we recommend you apply the Warm Hold function to by Food Type Food Type Recommended Quantity Liquid 12 cups Dry 510 oz Using the defrost button Remove all packaging material before defrosting Place meat poultry sh bread etc on a ceramic plate General defrosting instructions 1 Place the food on the turntable glass tray 2 Press the Defrost button MC17J8100CSACDE6804224B01ENCFRindb 24 11282017 41902 PM
• Page 26 - English - : English Using your microwave oven For specic instructions for different kinds of food see the table below Cook No Food Amount Standing time Remark 1 Meat 0160 lbs 510 min Shield the edges with aluminium foil Turn the meat over when the oven beeps This program is suitable for lamb pork steaks chops and ground meat For ground meat place the meat directly on the turntable tray on wax paper Do not use an extra tray Let stand covered with foil for 510 minutes 2 Poultry 0160 lbs 3060 min Shield the leg and wing tips with aluminium foil Turn the poultry over when the oven beeps This program is suitable for whole chicken as well as for chicken portions 3 Fish 0160 lbs 2060 min Shield the tail of a whole sh with aluminium foil Turn the sh over when the oven beeps This program is suitable for whole sh as well as for sh llets 4 Bread 0120 lbs 520 min Put bread on a piece of paper towel Turn over as soon as the oven beeps Place cake on a ceramic plate and if possible turn over as soon as the oven beeps The oven keeps operating and stops only when you open the door This program is suitable for all kinds of bread sliced or whole as well as for bread rolls and baguettes Arrange bread rolls in a circle 3 To select the number that corresponds to the food you want to defrost press the UpampDown key or one of the numeric buttons Refer to the below table 4 Press the OK button 5 Enter the weight of the food by pressing the numeric buttons Refer to the table below to see the weights you can enter 6 Press the START button The microwave oven will automatically operate for the preprogrammed time NOTE Check food when the oven signals After the nal stage small sections may still be icy Let them stand to continue thawing Food is not fully defrosted until all ice crystals have thawed Shielding roasts and steaks with small pieces of foil prevents the edges from cooking before the center of the food has defrosted Use narrow at smooth strips of aluminum foil to cover the edges and thinner sections of the food 3 45 MC17J8100CSACDE6804224B01ENCFRindb 25 11282017 41902 PM
• Page 27 - English - : English Using your microwave oven Using your microwave oven Accessory usage Use accessories in the combinations shown below Using the slim fry button The Slim Fry menu contains preset cooking programs for 9 different items You do not need to set the cooking times or the power level 1 Place the food on the tray or the rack See Accessory Usage on page 26 2 Press the Slim Fry button 3 To select the number that corresponds to the food press the UpampDown key or one of the numeric buttons Refer to the table on the next page 4 Press the OK button 5 Enter the amount of food by pressing the UpampDown key or one of the numeric buttons Refer to the table on the next page 6 Press the START button The microwave oven will automatically operate for the preprogrammed time 3 45 Ceramic Enamel Tray High Rack Ceramic Enamel Tray Ceramic Enamel Tray Glass Tray Glass Tray Glass Tray Glass Tray Glass Tray Glass Tray Guide Roller Guide Roller Guide Roller Guide Roller Guide Roller Guide Roller Low Rack Ceramic Enamel Tray High Rack Low Rack Glass Steamer A D C F B E Coupler Coupler Coupler Coupler Coupler Coupler MC17J8100CSACDE6804224B01ENCFRindb 26 11282017 41902 PM
• Page 28 - English - : English Using your microwave oven Cook No Food Amount Directions Accessory Type 1 Frozen Oven Chips 2 servings 8 oz 227 g 4 servings 16 oz 454 g Place frozen french fries on greased ceramic enamel tray Place the tray on high rack C 2 Frozen Prawns Breaded 2 servings 8 oz 227 g 4 servings 16 oz 454 g Place frozen prawns in ceramic enamel tray Place the tray on high rack When the oven beeps turn prawns over and then restart the oven C 3 Frozen Chicken Nuggets 1 serving 5 ea 2 servings 10 ea 5 ea per serving Place chicken nuggets on the ceramic enamel tray Place the tray on high rack C 4 Frozen Mini Spring Rolls 1 serving 6 oz 170 g 2 servings 24 oz 680 g Place frozen spring rolls on ceramic enamel tray Place the tray on high rack C 5 Homemade French Fries 2 servings 8 oz 227 g 4 servings 12 oz 340 g Peel potatoes and cut into sticks with a thickness of 04 x 04 inches 10 x 10mm Soak in cold water for 30 mins Dry with a towel and then brush with ¼ oz 5 g oil Place on greased ceramic enamel tray Place the tray on high rack C 6 Frozen Potato Wedges 2 servings 8 oz 227 g 4 servings 16 oz 454 g Place frozen potato wedges on greased ceramic enamel tray Place the tray on high rack C 7 Frozen Potato Croquettes 2 servings 8 oz 227 g 4 servings 16 oz 454 g Place frozen potato croquettes on greased ceramic enamel tray Place the tray on high rack When the oven beeps turn croquettes over and then restart the oven C 8 Drumsticks 1 serving 12 oz 340 g 2 servings 24 oz 680 g 4 pcs per serving Rinse drumsticks and place them directly on high rack Place the high rack on the ceramic enamel tray D 9 Sliced Courgettes 2 servings 8 oz 227 g 4 servings 16 oz 454 g Cut courgettes and brush with 14 oz 5 g oil Place sliced courgettes on greased ceramic enamel tray Place the tray on the high rack When the oven beeps turn the pieces over and then restart the oven C MC17J8100CSACDE6804224B01ENCFRindb 27 11282017 41903 PM
• Page 29 - English - : English Using your microwave oven Using your microwave oven Using the t choice button The Fit Choice menu contains preset cooking programs for 30 different items You do not need to set the cooking times or the power level 1 Place the food on the tray or the rack See Accessory Usage on page 26 2 Press the Fit Choice button 3 To select the number that corresponds to the category press the UpampDown key or one of the numeric buttons Refer to the table beginning on the next page 4 Press the OK button 5 To select the number that corresponds to the food press the UpampDown key or one of the numeric buttons Refer to the table beginning on the next page After selecting the food if you do not need to set the amount press the START button If you need to set the amount go to Step 6 6 Press the OK button 7 Enter the amount of food by pressing the UpampDown key or one of the numeric buttons Refer to the table beginning on the next page 8 Press the START button The microwave oven will automatically operate for the preprogrammed time 63 45 7 MC17J8100CSACDE6804224B01ENCFRindb 28 11282017 41903 PM
• Page 30 - English - : English Using your microwave oven Category Cook No Food Amount Directions Accessory Type Fresh Vegetables 1 Broccoli 1 serving 2 servings 3 servings 4 servings 1 serving ½cup or 5orets Wash and clean broccoli and prepare orets Put into a microwavesafe ceramic or glass bowl and add ½ to 2oz 1560 ml of water ½ oz or 15 ml per serving Put bowl in the center of glass tray Cook covered Stir after cooking F 2 Carrots 1 serving 2 servings 3 servings 4 servings 1 serving ½cup Wash and clean carrots and cut into round slices evenly Put into a microwavesafe ceramic or glass bowl and add ½ to 2 oz 1560ml of water ½ oz or 15 ml per serving Put bowl in the center of glass tray Cook covered Stir after cooking F 3 Green Beans 1 serving 2 servings 3 servings 4 servings 1 serving ½cup Wash and clean green beans Put into a microwavesafe ceramic or glass bowl and add ½ to 2 oz 1560ml of water ½ oz or 15ml per serving Put bowl in the center of glass tray Cook covered Stir after cooking F 4 Spinach 1 serving 2 servings 3 servings 4 servings 1 serving 1cup Wash and clean spinach Put into a microwavesafe ceramic or glass bowl and add ½ to 2 oz 1560ml of water ½ oz or 15 ml per serving Put bowl in the center of glass tray Cook covered Stir after cooking F 5 Squash 12 lbs 0509 kg 23 lbs 0914 kg Slice squash in half Put into a microwavesafe ceramic or glass dish cut side down and add ¼ cup 240ml water Put dish in the center of glass tray F MC17J8100CSACDE6804224B01ENCFRindb 29 11282017 41903 PM
• Page 31 - English - : English Using your microwave oven Using your microwave oven Category Cook No Food Amount Directions Accessory Type Frozen Vegetables 1 Broccoli 1 serving 2 servings 3 servings 4 servings 1 serving ½cup or 5orets Wash and clean frozen broccoli orets Put into a microwavesafe ceramic or glass bowl and add ½ to 2oz 1560 ml of water ½ oz or 15 ml per serving Put bowl in the center of glass tray Cook covered Stir after cooking F 2 Carrots 1 serving 2 servings 3 servings 4 servings 1 serving ½cup Wash and clean frozen sliced carrots Put into a microwavesafe ceramic or glass bowl and add ½ to 2oz 1560 ml of water ½oz or 15 ml per serving Put bowl in the center of glass tray Cook covered Stir after cooking F 3 Corn 1 serving 2 servings 3 servings 4 servings 1 serving ½cup Wash and clean frozen corn Put into a microwavesafe ceramic or glass bowl and add ½ to 2 oz 1560ml of water ½ oz or 15 ml per serving Put bowl in the center of glass tray Cook covered Stir after cooking F 4 Green Beans 1 serving 2 servings 3 servings 4 servings 1 serving ½cup Wash and clean frozen green beans Put into a microwave safe ceramic or glass bowl and add ½ to 2oz 1560 ml of water ½oz or 15 ml per serving Put bowl in the center of glass tray Cook covered Stir after cooking F 5 Peas 1 serving 2 servings 3 servings 4 servings 1 serving ½cup Wash and clean frozen peas Put into a microwavesafe ceramic or glass bowl and add ½ to 2 oz 1560ml of water ½ oz or 15 ml per serving Put bowl in the center of glass tray Cook covered Stir after cooking F MC17J8100CSACDE6804224B01ENCFRindb 30 11282017 41903 PM
• Page 32 - English - : English Using your microwave oven Category Cook No Food Amount Directions Accessory Type Canned Vegetables 1 Carrots 1 serving 2 servings 3 servings 4 servings 1 serving ½cup Put into a microwavesafe ceramic or glass bowl Put bowl in the center of glass tray Cook covered Stir after cooking F 2 Corn 1 serving 2 servings 3 servings 4 servings 1 serving ½cup Put into a microwavesafe ceramic or glass bowl Put bowl in the center of glass tray Cook covered Stir after cooking F 3 Green Beans 1 serving 2 servings 3 servings 4 servings 1 serving ½cup Put into a microwavesafe ceramic or glass bowl Put bowl in the center of glass tray Cook covered Stir after cooking F 4 Peas 1 serving 2 servings 3 servings 4 servings 1 serving ½cup Put into a microwavesafe ceramic or glass bowl Put bowl in the center of glass tray Cook covered Stir after cooking F 5 Spinach 1 serving 2 servings 3 servings 4 servings 1 serving 1cup Put into a microwavesafe ceramic or glass bowl Put bowl in the center of glass tray Cook covered Stir after cooking F 6 Beans 1 serving 2 servings 3 servings 4 servings 1 serving ½cup or 5orets Put into a microwavesafe ceramic or glass bowl Put bowl in the center of glass tray Cook covered Stir after cooking F MC17J8100CSACDE6804224B01ENCFRindb 31 11282017 41903 PM
• Page 33 - English - : English Using your microwave oven Using your microwave oven Category Cook No Food Amount Directions Accessory Type Grain 1 Oatmeal 1 pack 2 packs Follow package directions for amount of water Stir well before and after standing time Let stand 35 minutes F 2 Brown Rice 2 servings 4 servings 1 serving ½cup Follow package directions for amount of water Stir well before and after standing time Let stand 35 minutes F 3 Bulgur 2 servings 4 servings 1 serving ½cup Follow package directions for amount of water Stir well before and after standing time Let stand 35 minutes F 4 Whole Wheat Macaroni 2 servings 4 servings 1 serving ½cup Follow package directions for amount of water Remove from the oven and let stand for 5 minutes Drain hot water carefully F 5 Quinoa 2 servings 4 servings 1 serving ½cup Follow package directions for amount of water Stir well as soon as oven beeps and push start button to continue process F 6 Whole Wheat Couscous 2 servings 4 servings 1 serving ½cup Follow package directions for amount of water First pour water into a microwavesafe ceramic or glass bowl and put bowl in the center of glass tray When the oven beeps add couscous and restart the oven Remove from the oven and let stand for 5minutes F MC17J8100CSACDE6804224B01ENCFRindb 32 11282017 41903 PM
• Page 34 - English - : English Using your microwave oven Category Cook No Food Amount Directions Accessory Type Poultry 1 Chicken Breast 2 pieces 4 pieces 6 oz 170 g each Place chicken breasts on high rack Place the high rack on ceramic enamel tray When the oven beeps turn over chicken breasts and re start the oven D 2 Bonein Chicken Pieces 2 servings 18 oz 510 g 4 servings 36 oz 1020 g Brush chilled chicken pieces with oil and spices Put skin side up on high rack Place the high rack on ceramic enamel tray D 3 Turkey Breast 4 pieces 12 oz 340 g each 3 oz 85 g Place turkey breasts on high rack Place the high rack on ceramic enamel tray When the oven beeps turn over turkey breasts and restart the oven D 4 Ground Turkey 4 Servings 1 lb 454 g Place ground turkey in microwave safe 2 quart casserole glass dish then place on glass tray When the oven beeps stir and restart the oven F Seafood 1 White Fish Fillet 1 serving 2 pieces 4 oz 113 g 2 servings 4 pieces 8 oz 227 g 1 serving 2pcs each piece 2 oz 57 g Spray high rack with non stick spray Place white llets cod pollack etc on the high rack Place the high rack on ceramic enamel tray D 2 Salmon Fillet 1 serving 1 piece 4 oz 113 g 2 servings 2 pieces 8 oz 227 g 1 serving 1pc each piece 4 oz 113 g Spray high rack with non stick spray Place salmon llets on the high rack Place the high rack on ceramic enamel tray D MC17J8100CSACDE6804224B01ENCFRindb 33 11282017 41903 PM
• Page 35 - English - : English Using your microwave oven Using your microwave oven Category Cook No Food Amount Directions Accessory Type Seafood 3 Tilapia Fillet 1 serving 2 pieces 4 oz 113 g 2 servings 4 pieces 8 oz 227 g 1 serving 2pcs each piece 2 oz 57 g Spray high rack with non stick sprayPlace tilapia llets on the high rack Place the high rack on ceramic enamel tray D 4 Tuna Steak 1 serving 1 piece 4 oz 113 g 2 servings 2 pieces 8 oz 227 g 1 serving 1pc each piece 4 oz 113 g Spray high rack with non stick spray Place tuna steaks on high rack Place the high rack on ceramic enamel tray When the oven beeps turn over tuna steaks and restart the oven D MC17J8100CSACDE6804224B01ENCFRindb 34 11282017 41903 PM
• Page 36 - English - : English Using your microwave oven Using the steam cook button The Steam Cook menu contains preset cooking programs for 9 different items You do not need to set the cooking times or the power level 1 Add ½ cup 100 ml of water to the Glass Steamer Put food on the insert tray of the Glass Steamer and then place the tray into the Steamer See Accessory Usage on page 26 2 Press the Steam Cook button 3 To select the number that corresponds to the food press the UpampDown key or one of the numeric buttons Refer to the table beginning on the next page After selecting the food if you do not need to set the amount press the START button If you need to select the amount go to Step 4 Press the OK button 5 Enter the amount of food by pressing the UpampDown key or one of the numeric buttons Refer to the table beginning on the next page 6 Press the START button The microwave will automatically operate for the pre programmed time 3 45 MC17J8100CSACDE6804224B01ENCFRindb 35 11282017 41903 PM
• Page 37 - English - : English Using your microwave oven Using your microwave oven Cook No Food Amount Directions Accessory Type 1 Frozen Vegetable 2 servings 9 oz 255 g 4 servings 18 oz 510 g Add ½ cup 100ml water to the glass steamer Put the frozen vegetable on the insert tray and place in the glass steamer Cover with lid After cooking let stand for 23 minutes E 2 Broccoli Florets 2 servings 9 oz 255 g 4 servings 18 oz 510 g Rinse and clean fresh broccoli and prepare orets Add ½ cup 100ml water to the glass steamer Put the broccoli on the insert tray and place in the glass steamer Cover with lid After cooking let stand for 23 minutes E 3 Sliced Carrots 2 servings 9 oz 255 g 4 servings 18 oz 510 g Rinse and clean fresh carrots Add ½ cup 100ml water to the glass steamer Put the carrots on the insert tray and place in the glass steamer Cover with lid After cooking let stand for 23 minutes E 4 Cauliower Florets 2 servings 9 oz 255 g 4 servings 18 oz 510 g Rinse and clean fresh cauliower and prepare orets Add ½ cup 100ml water to the glass steamer Put the cauliower on the insert tray and place in the glass steamer Cover with lid After cooking let stand for 23 minutes E 5 Peeled Potatoes 2 servings 9 oz 255 g 4 servings 18 oz 510 g Rinse and peel the potatoes and cut into a similar size pieces Add ½ cup 100ml water to the glass steamer Put the potato pieces on the insert tray and place in the glass steamer Cover with lid After cooking let stand for 23 minutes E 6 Cubed Pumpkin 2 servings 9 oz 255 g 4 servings 18 oz 510 g Wash the pumpkin and then cut into similar size pieces Add ½ cup 100ml water to the glass steamer Put the pumpkin pieces on the insert tray and then place in the glass steamer Cover with lid After cooking let stand for 23minutes E MC17J8100CSACDE6804224B01ENCFRindb 36 11282017 41903 PM
• Page 38 - English - : English Using your microwave oven Cook No Food Amount Directions Accessory Type 7 Chicken Breasts 2 servings 11 oz 312 g 4 servings 22 oz 624 g Rinse pieces and pierce the surface of the skin in a number of places Add ½ cup 100ml water to the glass steamer Put the chicken breasts on the insert tray and place in the glass steamer Cover with lid After cooking let stand for 23 minutes E 8 Salmon Fillets 2 servings 11 oz 312 g 4 servings 22 oz 624 g Rinse sh and add 1 tablespoon lemon juice Add ½ cup 100ml water to the glass steamer Put the salmon llets on the insert tray and place in the glass steamer Cover with lid After cooking let stand for 23 minutes E 9 Steamed Prawns 2 servings 11 oz 312 g Add ½ cup 100ml water to the glass steamer Rinse the fresh prawns Put them on the insert tray and place in the glass steamer Cover with lid After cooking let stand for 23 minutes E MC17J8100CSACDE6804224B01ENCFRindb 37 11282017 41903 PM
• Page 39 - English - : English Using your microwave oven Using your microwave oven Using the speed cook button The Speed Cook menu contains preset cooking programs for 41 different items You do not need to set the cooking times or the power level 1 Place the food on the tray or the rack See Accessory Usage on page 26 2 Press the Speed Cook button 3 To select the number that corresponds to the category press the UpampDown key or one of the numeric buttons Refer to the table beginning on the next page 4 Press the OK button 5 To select the number that corresponds to the food press the UpampDown key or one of the numeric buttons Refer to the table beginning on the next page After selecting the food if you do not need to set the amount press the START button If you need to set the amount go to Step 6 6 Press the OK button 7 Enter the amount of food by pressing the UpampDown key or one of the numeric buttons Refer to the table beginning on the next page 8 Press the START button The microwave will automatically operate for the pre programmed time 63 45 7 MC17J8100CSACDE6804224B01ENCFRindb 38 11282017 41903 PM
• Page 40 - English - : English Using your microwave oven Category Cook No Food Amount Directions Accessory type Breakfast 1 French Toast Frozen 2 servings 4 servings 1 serving 1 toast Place toast on high rack Place the high rack on ceramic enamel tray Turn over when the oven beeps and restart the oven D 2 French Toast Sticks 1 serving 2 servings 1 serving 5sticks Place sticks on the high rack Place the high rack on ceramic enamel tray Turn over when the oven beeps and restart the oven D 3 Sausage Links Fresh 2 servings 4 servings 1 serving 3 links Place links on ceramic enamel tray Place the tray on the high rack When the oven beeps turn over sausages and restart the oven C 4 Sausage Links Frozen 2 servings 4 servings 1 serving 3 links Place links on ceramic enamel tray Place the tray on the high rack C 5 Sausage Patties Frozen 2 servings 4 patties 4 servings 8 patties 1 serving 2patties Place patties on ceramic enamel tray Place the tray on the high rack C 6 Sausage Patties Fresh 2 servings 2 patties 4 servings 4 patties 1 serving 1 pattie Place patties on ceramic enamel tray Place the tray on the high rack When the oven beeps turn over sausages and restart the oven C 7 Toaster Items 2 servings 4 servings 1 serving 1 toast Place toaster item on high rack Place the high rack on ceramic enamel tray Turn over when the oven beeps and restart the oven D 8 Wafes Frozen 2 servings 3 servings 1 serving 2wafes Place wafes on low rack Place the low rack on ceramic enamel tray Turn over when the oven beeps and restart the oven B MC17J8100CSACDE6804224B01ENCFRindb 39 11282017 41903 PM
• Page 41 - English - : English Using your microwave oven Using your microwave oven Category Cook No Food Amount Directions Accessory type Poultry 1 Chicken Breast 2 pieces 4 pieces 6 oz 170 g each Place chicken on high rack Place the high rack on ceramic enamel tray When the oven beeps turn over chicken and restart the oven D 2 Bonein Chicken Pieces 2 servings 18 oz 510 g 4 servings 36 oz 1020 g Place chicken on high rack Place the high rack on ceramic enamel tray D 3 Whole Chicken 34 lbs 1418 kg Fold chicken wings under the chicken Place chicken on low rack Place the low rack on ceramic enamel tray Brush chicken with melted butter B 4 Turkey Breast 4 pieces 12 oz 340 g each 3 oz 85 g Place turkey breasts on high rack Place the high rack on ceramic enamel tray When the oven beeps turn over turkey breasts and restart the oven D Seafood 1 White Fish Fillet 1 serving 2 pieces 4 oz 113g 2 servings 4 pieces 8 oz 227g 1 serving 2 pcs each piece 2 oz 57 g Spray high rack with non stick spray Place white llets cod pollack etc on the high rack Place the high rack on ceramic enamel tray D 2 Salmon Fillet 1 serving 1 piece 4 oz 113g 2 servings 2 pieces 8 oz 227g 1 serving 1 pc each piece 4 oz 113 g Spray high rack with non stick spray Place salmon llets on the high rack Place the high rack on ceramic enamel tray D MC17J8100CSACDE6804224B01ENCFRindb 40 11282017 41903 PM
• Page 42 - English - : English Using your microwave oven Category Cook No Food Amount Directions Accessory type Seafood 3 Shrimp Fresh 2 servings 8 oz 227 g 4 servings 16 oz 454 g Place shrimp on ceramic tray Place the tray on the high rack When the oven beeps turn over shrimp and restart the oven C 4 Tuna Steak 1 serving 1 piece 4 oz 113 g 2 servings 2 pieces 8 oz 227 g 1 serving 1 pc each piece 4 oz 113 g Spray high rack with non stick spray Place tuna steaks on high rack Place the high rack on ceramic enamel tray When the oven beeps turn over tuna steak and restart the oven D Beef 1 Beef Roast 2 lbs 091 kg 3 lbs 136 kg Place beef on low rack Place the low rack on ceramic enamel tray When the oven beeps turn over beef and restart the oven B 2 Top Loin Steak Medium 1 inch 05 lb 227 g Place steak on high rack Place the high rack containing the steak on the ceramic enamel tray When the oven beeps turn over steak and restart the oven Let steak stand for 5minutes before slicing D 3 Top Loin Steak Well Done 1 inch 05 lb 227 g Place steak on high rack Place the high rack containing the steak on the ceramic enamel tray When the oven beeps turn over steak and restart the oven Let steak stand for 5minutes before slicing D 4 Top Round Steak Medium ¾ Inch 1 lb 454 g Place steak on high rack Place the high rack containing the steak on the ceramic enamel tray When the oven beeps turn over steak and restart the oven Let steak stand for 5minutes before slicing D MC17J8100CSACDE6804224B01ENCFRindb 41 11282017 41903 PM
• Page 43 - English - : English Using your microwave oven Using your microwave oven Category Cook No Food Amount Directions Accessory type Beef 5 Top Round Steak Well Done ¾ Inch 1 lb 454 g Place steak on high rack Place the high rack containing the steak on the ceramic enamel tray When the oven beeps turn over steak and restart the ovenLet steak stand for 5minutes before slicing D 6 Sirloin Steak Medium 1 Inch 1 lb 454 g Place steak on high rack Place the high rack containing the steak on the ceramic enamel tray When the oven beeps turn over steak and restart the oven Let steak stand for 5minutes before slicing D 7 Sirloin Steak Well Done 1 Inch 1 lb 454 g Place steak on high rack Place the high rack containing the steak on the ceramic enamel tray When the oven beeps turn over steak and restart the oven Let steak stand for 5minutes before slicing D 8 Ground Beef 2 servings 05 lb 227 g 4 servings 1 lb 454 g Place beef in microwave safe 2 quart casserole glass dish then place casserole dish on glass tray When the oven beeps stir and restart the oven F 9 Hamburgers 2 each 4 oz 113 geach 4 each 4 oz 113 geach Place hamburgers on ceramic enamel tray Place the tray on the high rack When the oven beeps turn over hamburgers and re start the oven C MC17J8100CSACDE6804224B01ENCFRindb 42 11282017 41904 PM
• Page 44 - English - : English Using your microwave oven Category Cook No Food Amount Directions Accessory type Pork 1 BoneIn Pork Chops 1 serving 2 servings 1 serving 68 oz 170227 g each Place pork chops on high rack Place the high rack on ceramic enamel tray When the oven beeps turn over pork chops and re start the oven D 2 Boneless Pork Chops 2 servings 2 ea 4 servings 4 ea 1 serving 45 oz 113142 g each Place pork chops on high rack Place the high rack on ceramic enamel tray When the oven beeps turn over pork chops and re start the oven D 3 Pork Tenderloin Small 1 piece 051 lb 227454g Large 1 piece 152 lbs 680907 g Place pork on low rack Place the low rack containing the pork on the ceramic enamel tray When the oven beeps turn over pork and restart the oven B Pizza 1 Frozen Pizza Individual 6Inch 6 inch Place pizza on low rack Place the low rack on ceramic enamel tray B 2 Frozen Pizza Regular 12Inch 12 inch Place pizza on low rack Place the low rack on ceramic enamel tray B 3 Frozen Individual Deep Dish Pizza 6 inch Place pizza on low rack Place the low rack on ceramic enamel tray B 4 Frozen Rising Crust Pizza 12 inch Place pizza on low rack Place the low rack on ceramic enamel tray B MC17J8100CSACDE6804224B01ENCFRindb 43 11282017 41904 PM
• Page 45 - English - : English Using your microwave oven Using your microwave oven Category Cook No Food Amount Directions Accessory type Potato 1 Baked Potato 2 ea 4 ea 810 oz 227283 geach Pierce each potato several times with a fork Place on the turntable in a spoke like fashion After cooking let the potatoes stand for 35 minutes F 2 Sweet Potato 2 ea 4 ea 810 oz 227283 geach Pierce each sweet potato several times with a fork Place on the turntable in a spokelike fashion After cooking let the potatoes stand for 35 minutes F Snacks Frozen 1 Chicken Nuggets 1 serving 5 ea 2 servings 10 ea 5 ea per serving Place chicken nuggets on the ceramic enamel tray Place the tray on the high rack C 2 Chicken Tenders 1 serving 5 ea 2 servings 10 ea 5 ea per serving Place chicken tenders on the ceramic enamel tray Place the tray on the high rack C 3 Chicken Wings 2 servings 10 ea 4 servings 20 ea 5 wings per serving Place chicken wings on low rack Place the low rack on ceramic enamel tray B 4 Fried Chicken 2 servings 4 servings 1 piece per serving Place chicken on ceramic enamel tray Place the tray on the low rack A 5 Cheese Sticks 2 servings 4 servings 2 sticks per serving Place cheese sticks on ceramic enamel tray Place the tray on the high rack C 6 Onion Rings 2 servings 6 ea 4 servings 12 ea 3 rings per serving Place onion rings on ceramic enamel tray Place the tray on the high rack When the oven beeps stir and restart the oven C 7 French Fries 2 servings 6 oz 170 g 4 servings 12 oz 340 g 3 oz 85 g per serving Place fries on ceramic enamel tray Place the tray on the high rack When the oven beeps stir and restart the oven C MC17J8100CSACDE6804224B01ENCFRindb 44 11282017 41904 PM
• Page 46 - English - : English Using your microwave oven Using the auto cook button The Auto Cook menu contains preset cooking programs for 45 different items You do not need to set the cooking times or the power level 1 Place the food on the tray or the rack See Accessory Usage on page 26 2 Press the Auto Cook button 3 To select the number that corresponds to the category press the UpampDown key or one of the numeric buttons Refer to the table that begins on the next page 4 Press the OK button 5 To select the number that corresponds to the food press the UpampDown key or one of the numeric buttons Refer to the table that begins on the next page After selecting the food if you do not need to set the amount press the START button If you need to set the amount go to Step 6 6 Press the OK button 7 Enter the amount of food by pressing the UpampDown key or one of the numeric buttons Refer to the table that begins on the next page 8 Press the START button The microwave will automatically operate for the pre programmed time 63 45 7 MC17J8100CSACDE6804224B01ENCFRindb 45 11282017 41904 PM
• Page 47 - English - : English Using your microwave oven Using your microwave oven Category Cook No Food Amount Directions Accessory type Reheat 1 Soup Broth 1 to 4 servings 8 oz 227 g serving Use only refrigerated food Pour into a deep ceramic plate or bowl Cover with lid or vented plastic wrap Stir well before serving F 2 Soup Cream 1 to 4 servings 8 oz 227 g serving Use only refrigerated food Pour into a deep ceramic plate or bowl Cover with lid or vented plastic wrap Stir well before serving F 3 Pasta 1 to 4 servings 8 oz 227 g serving Use only refrigerated food Pour into a deep ceramic plate or bowl Cover with lid or vented plastic wrap Stir well before serving F 4 Casserole 1 to 4 servings 8 oz 227 g serving Use only refrigerated food Pour into a deep ceramic plate or bowl Cover with lid or vented plastic wrap Stir well before serving F 5 Dinner Plate 1 serving Use only precooked refrigerated food Put meal on a ceramic plate Cover plate with vented plastic wrap or wax paper F 6 Beverage ½ cup 1 cup 2 cups Use measuring cup do not cover Place the beverage in the oven After heating stir well F 7 Roll 1 to 4 rolls Put dinner rolls on a microwavesafe ceramic plate Before serving let stand 12 minutes F 8 Pizza Reheat 2 slices 4 slices 34 oz 85113geach Put the pizza on a microwavesafe plate with wide end of slices towards the outside edge of the plate Do not let slices overlap Do not cover Before serving let stand 12 minutes F MC17J8100CSACDE6804224B01ENCFRindb 46 11282017 41904 PM
• Page 48 - English - : English Using your microwave oven Category Cook No Food Amount Directions Accessory type Cook 1 Frozen Dinner 810 oz 227283 g 1114 oz 312397 g 1518 oz 425510 g Remove package from outerwrapping and follow package instructions for covering and standing After cooking let stand 13minutes F 2 Frozen Breakfast 46 oz 113170 g 78 oz 198227 g Remove package from outer wrapping and follow package instructions for covering and standing After cooking let stand 13minutes When the oven beeps stir and restart the oven F 3 Mashed Potatoes Instant 2 servings 4 servings 1 serving ⅓cup akes Follow package preparation directions F 4 Bacon Uncooked 2 slices 4 slices 6 slices Place 2 paper towels on plate and arrange bacon on towels Do not overlap Cover with additional paper towel Remove paper towel immediately after cooking F 5 Bacon Pre Cooked 2 slices 4 slices 6 slices Place 2 paper towels on plate and arrange bacon on towels Do not overlap F MC17J8100CSACDE6804224B01ENCFRindb 47 11282017 41904 PM
• Page 49 - English - : English Using your microwave oven Using your microwave oven Category Cook No Food Amount Directions Accessory type Kids Menu 1 Chicken Nuggets 1 serving 2 servings 1 serving 5 ea Place a paper towel on a plate and arrange the nuggets in a spokelike fashion on the paper towel Do not cover Let stand for 1minute after heating F 2 Hot Dogs 2 each 4 each Pierce hot dogs place on plate When the oven beeps add buns and restart the oven F 3 Canned Pasta 1 serving 75 oz 213 g 2 servings 15 oz 425 g Use only canned pasta at room temperature Pour into a deep ceramic plate or bowl Cover with lid or vented plastic wrap Stir well before serving F 4 Burrito 1 each 2 each Follow package preparation directions Let stand for 12minutes after heating F 5 Snack Pocket 1 serving 1 ea 2 servings 2 ea Follow package preparation directions Let stand for 12minutes after heating F Pasta 1 Spaghetti 1 serving 2 oz 57 g 2 servings 4 oz 113 g Placed 4 for 1 serving or 8for 2 servings cups water in large microwave safe bowl When the oven beeps add spaghetti and restart the oven Remove from the oven and let stand for 5minutes Drain hot water carefully F 2 Macaroni and Cheese 1 serving 1 ea 2 servings 2 ea Follow package preparation directions F 3 Instant Noodles 1 serving 1 ea 2 servings 2 ea Put noodles in microwave safe bowl and pour 2for 1 serving or 4 for 2servings cups water After cooking drain water carefully and add seasoning F MC17J8100CSACDE6804224B01ENCFRindb 48 11282017 41904 PM
• Page 50 - English - : English Using your microwave oven Category Cook No Food Amount Directions Accessory type Bread 1 Biscuits Refrigerated 10 ea Preheat oven to 375 F Place biscuits on greased ceramic enamel tray Place the tray on the low rack A 2 Bread Sticks 12 ea Preheat oven to 375F Place breadsticks on greased ceramic enamel tray Place the tray on the low rack A 3 Crescent Rolls Refrigerated Small 8 ea Preheat oven to 375 F Place rolls on greased ceramic enamel tray Place the tray on the low rack A 4 Crescent Rolls Refrigerated Large 8 ea Preheat oven to 375 F Place rolls on greased ceramic enamel tray Place the tray on the low rack A Baked Goods 1 Box Cake Mix ½ package Preheat oven to 350 F Pour batter into an 8 inch round cake pan In the oven place the lled pan with batter on the low rack A Except ceramic enamel tray 2 Cinnamon Rolls 8 ea Preheat oven to 375 F Place buns on greased ceramic enamel tray Place the tray on the low rack A 3 Brownie Mix 1 package Preheat oven to 350 F Poured batter into an 8 x 8 inch pan and then place the pan on the low rack A 4 Cookie Dough Sliced 8 ea ½ inch sliced Preheat oven to 350 F Place 8 cookies on greased ceramic enamel tray Place the tray on the high rack C 5 Cookie Dough Pre Formed 10 ea Preheat oven to 350 F Place 10 cookies on greased ceramic enamel tray Place the tray on the high rack C MC17J8100CSACDE6804224B01ENCFRindb 49 11282017 41904 PM
