Register your product and get support at
www.philips.com/support
User Manual
BDP7303
4K Ultra HD
Blu-ray™ Player
For further assistance, call the customer
support service in your country.
• To obtain assistance, contact Philips Customer
Care Center;
In the U.S.A., Canada, Puerto Rico, or the U.S.
Virgin Islands; 1-866-202-5960
2
CONTENTS
INTRODUCTION ................................................. 3
Safety instruction ........................................................... 3
Included accessories .................................................... 6
FEATURES ........................................................... 7
Features .............................................................................7
Version information ...................................................... 9
Symbols used in this owner’s manual ..................... 9
FUNCTIONAL OVERVIEW .............................. 10
Top / front panel ...........................................................10
Rear panel ......................................................................10
Remote control ...............................................................11
Guide to on-screen display ....................................... 13
CONNECTIONS ..................................................14
HDMI video /audio connection................................ 14
HDMI audio output ......................................................18
Connection to the network........................................19
BEFORE YOU START ........................................21
Initial setup ..................................................................... 21
INFORMATION ON PLAYBACK ..................... 23
Information on playback ........................................... 23
Guide to file list ............................................................ 26
How to insert a disc .....................................................27
BASIC PLAYBACK ............................................28
Playing back a disc ..................................................... 28
4K or 4K HDR playback ............................................. 30
Playing back an Ultra HD Blu-ray™ disc ............... 31
Playing back a Blu-ray 3D™ disc ............................ 32
Playing back content from a USB memory stick ... 33
Using the title / disc / pop menu ............................ 34
SPECIAL PLAYBACK ........................................ 35
Fast forward / fast reverse ....................................... 35
Slow forward playback .............................................. 35
Frame by frame playback ......................................... 35
Repeat playback .......................................................... 36
Shuffle / random playback ......................................36
Slide show ......................................................................36
PiP (BONUSVIEW™) setting ......................................37
Enjoying BD-Live™ discs using Internet ................37
Title / chapter search ................................................. 38
Track / file search ........................................................ 38
Time search ................................................................... 39
Number select search ................................................ 39
Switching subtitles ......................................................40
Switching audio soundtrack ...................................... 41
Switching camera angles .......................................... 42
Noise reduction ............................................................ 42
Closed caption ............................................................. 42
NETWORK SERVICES .....................................43
Before using network services ................................ 43
Information on network services ............................ 43
Deactivate the network services ............................ 43
LIST OF SETTINGS ........................................... 44
SETUPS ..............................................................48
Network connection ................................................... 48
EasyLink (HDMI CEC) ................................................. 53
HDMI video resolution ............................................... 54
Parental controls ......................................................... 55
Software update .......................................................... 56
Voice guide .....................................................................57
Restore default settings ............................................ 58
TROUBLESHOOTING ......................................59
SPECIFICATIONS ..............................................63
NETWORK SERVICE DISCLAIMER ............... 64
MAINTENANCE ................................................65
TRADEMARK INFORMATION....................... 66
GLOSSARY .........................................................68
IMPORTANT HEALTH AND SAFETY
INFORMATION FOR 3D TELEVISIONS ........70
LIMITED WARRANTY ....................................... 71
EN 3
1. INTRODUCTION
1.1. Safety instruction
For fastest support visit us online at www.philips.com/support
for chat and self service solutions.
The lightning ash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sucient
magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
Know these
safety symbols
CAUTION AVIS
CAUTION:
TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK). NO
USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
* Additional Benets
Registering your product guarantees that you’ll
receive all of the privileges to which you’re
entitled, including special money-saving oers.
*
Product Safety Notication
By registering your product, you’ll receive
notication - directly from the manufacturer - in
the rare case of a product recall or safety defect.
Registering your model with Philips makes you eligible for all of the valuable benefits
listed below, so don’t miss out. Register online at www.philips.com/support to ensure:
Register online at www.philips.com/support
today to get the most benets from your purchase.
The symbol for CLASS ll (Double Insulation)
WARNING
:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS
TO RAIN OR MOISTURE. APPARATUS SHALL NOT BE EXPOSED TO DRIPPING OR SPLASHING AND NO
OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES, SHALL BE PLACED ON THE APPARATUS.
CAUTION: To prevent electric shock, match wide blade of plug to wide slot, fully insert.
ATTENTION:
Pour éviter les chocs électriques, introduire la lame la plus large de la che dans la borne
correspondante de la prise et pousser jusqu’au fond.
The important note and rating are located on the rear or bottom of the cabinet.
For Customer Use
Model No. ___________________________________________________________
Serial No. ___________________________________________________________
Please write the model and serial number of your
unit (located on the cabinet) in the space below for
future reference.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
RISQUE DE CHOC ÉLECTRIQUE
NE PAS OUVRIR
EN 4
continued on next page
Important safety instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use caution when moving the cart / apparatus combination to
avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has
been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally,
or has been dropped.
FCC WARNING
This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may
cause harmful interference unless the modifications are expressly approved in the manual. The user could lose
the authority to operate this equipment if an unauthorized change or modification is made.
Supplier’s declaration of conformity
Trade name : PHILIPS
Responsible party : Funai Corporation, Inc.
Model : BDP7303/F7
Address : 21061 S. Western Ave. Suite 210,
Torrance, CA 90501, USA
Telephone number : 1-866-202-5960
RADIO-TV INTERFERENCE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the device and the receiver.
3. Connect the device into an outlet on a circuit different from that to which the receiver is connected.
4. Consult the dealer or an experienced radio / TV technician for help.
Disconnect the mains plug (the AC plug) to shut the unit off when trouble is found or when not in use. The mains
plug (the AC plug) shall remain readily available. To completely turn off the unit, you must unplug the mains (AC)
power cord.
CAN ICES-3 (B)/NMB-3(B)
CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent
type.
WARNING: Batteries (Battery pack or battery installed) shall not be exposed to excessive heat such as sunshine,
fire or the like.
EN 5
continued on next page
LASER SAFETY
This apparatus is classified as a CLASS 1 LASER PRODUCT.
This apparatus employs a laser. Only a qualified service person should remove the cover
or attempt to service this apparatus, due to possible eye injury.
PRODUIT LASER DE CLASSE 1
CLASS 1 LASER PRODUCT
CAUTION: Use of controls or adjustments or performance of procedures other than those specified herein may
result in hazardous radiation exposure.
IMPORTANT COPYRIGHT INFORMATION
Unauthorized copying, broadcasting, public performance and lending of discs are prohibited. This item
incorporates copy protection technology that is protected by U.S. patents and other intellectual property rights
of Rovi Corporation. Reverse engineering and disassembly are prohibited.
Never use a gas duster on this unit.
The gas trapped inside of this unit may cause ignition and explosion.
Do not place the unit on furniture that is capable of being tilted by a child and an adult leaning, pulling, standing
or climbing on it. A falling unit can cause serious injury or even death.
In order to avoid interruption of ventilation, this unit should not be placed in built-in equipment such as a book
cabinet, rack, etc., and the vents of this unit should not be covered with anything such as a tablecloth, curtain,
newspaper, etc. Make sure to leave a space of 5.9 inches (15cm) or more around this apparatus.
When installing this unit in a temperate environment, avoid a place with rapid temperature changes.
This unit should not be used in a tropical environment as it has not been evaluated under such conditions.
No objects should be placed directly on or under this unit, especially lighted candles or other flaming objects.
Wireless LAN module
Contains FCC ID : ADTU9W33 Contains IC (ISED) : 1178A-U9W33
FCC CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.
5150-5350 MHz band is restricted to indoor operation only.
This device complies with part 15 of FCC Rules and Industry Canada ’s applicable licence-exempt RSSs. Operation
is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired operation.
This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled environment and
meets the FCC radio frequency (RF)
Exposure Guidelines and RSS-102 of the IC radio frequency (RF)
Exposure rules. This equipment should be installed and operated keeping the radiator at least 20cm or more away
from person’s body.
Compliance with FCC requirement 15.407(c) and IC requirement RSS-247 Issue 2 §6.4
Data transmission is always initiated by software, which is the passed down through the MAC, through the digital
and analog baseband, and finally to the RF chip. Several special packets are initiated by the MAC.
These are the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at
the end of the packet. Therefore, the transmitter will be on only while one of the aforementioned packets is
being transmitted. In other words, this device automatically discontinue transmission in case of either absence of
information to transmit or operational failure.
High-power radars are allocated as primary users (i.e. priority users) of the bands 5250-5350 MHz and 5650-5850
MHz and that these radars could cause interference and/or damage to LE-LAN devices.
To avoid the hazards of electrical shock and fire
Do not handle the power cord with wet hands.
Do not pull on the power cord when disconnecting it from an AC outlet. Grasp it by the plug.
Do not put your fingers or objects into the unit.
EN 6
Location and handling
Do not install the unit in direct sunlight, near strong magnetic fields or in a place subject to dust or strong vibration.
Avoid a place with drastic temperature changes.
Install the unit in a horizontal and stable position. Do not place anything directly on top or bottom of the unit.
Depending on your external devices, noise or disturbance of picture and/or sound may be generated if the unit is
placed too close to them. In this case, please ensure enough space between external devices and the unit.
Depending on the environment, the temperature of this unit may increase slightly. This is not a malfunction.
Be sure to remove the disc and unplug the AC power cord from the outlet before carrying the unit.
Dew condensation warning
Dew condensation may form inside the unit in the following conditions. If so, do not use this unit at least for a few
hours until its inside gets dry.
– The unit is moved from a cold place to a warm place.
– Under conditions of high humidity.
– After heating a cold room.
Notice
Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips N.V. or their
respective owners. Funai Corporation reserves the right to change products at any time without being obliged to
adjust earlier supplies accordingly. The material in this manual is believed adequate for the intended use of the
system. If the product, or its individual modules or procedures, are used for purposes other than those specified
herein, confirmation of their validity and suitability must be obtained. Funai Corporation warrants that the material
itself does not infringe any United States patents. No further warranty is expressed or implied. Funai Corporation
cannot be held responsible for any errors in the content of this document, or for any problems as a result of the content
in this document. Errors reported to Funai Corporation will be adapted and published on the Funai Corporation
support website as soon as possible.
Warranty
No components are user serviceable. Do not open or remove covers to the inside of the product. Repairs may only
be done by Service Centers and official repair shops. Failure to do so shall void any warranty, stated or implied. Any
adjustments or assembly procedures not recommended or authorized in this manual, or any operation expressly
prohibited in this manual shall void the warranty.
Important
Registering your model with Philips makes you eligible for all of the valuable benefits listed below, so don’t miss out.
Register online at www.philips.com/support to ensure:
Product safety notification
By registering your product you receive notification - directly from the manufacturer - in the rare case of a product
recall or safety defect.
Additional benefits of product ownership
Registering your product guarantees that you receive all of the privileges to which you’re entitled, including special
money-saving offers.
For further assistance
For further assistance, call the customer support service in your country.
To obtain assistance in the U.S.A., Canada, Puerto Rico, or the U.S. Virgin Islands, contact Philips Customer Care
Center at 1-866-202-5960
Environmental care
The packaging of this product is intended to be recycled. Contact your local authorities for information
about how to recycle the packaging. For Product recycling information, please visit - www.recycle.
philips.com
Disposal of used batteries
The batteries included do not contain the heavy metals mercury and cadmium, however in certain localities, disposing
batteries with household waste is not permitted. Please ensure you dispose of batteries according to local regulations.
1.2. Included accessories
• Quick start guide
• Remote control (NC290UL)
• Batteries (AAA, 1.5V x 2)
EN 7
2. FEATURES
2.1. Features
Ultra HD Blu-ray™ disc
You can enjoy Ultra HD Blu-ray™ disc which is capable
of storing twice more data than a conventional Blu-ray
Disc™.
Blu-ray Disc™
You can enjoy Blu-ray Disc™ which is capable of storing
five times more data than a conventional DVD.
BD-Java
With some Blu-ray™ discs which contain Java
applications, you can enjoy interactive functions such
as games or interactive menus.
DVD upscaling for enhanced picture quality
Your current DVD will look even better than before
thanks to video upscaling. Upscaling will increase the
resolution of standard definition DVD to high definition
up to 1080p over an HDMI connection. The picture
will be less jagged and more realistic for a near high
definition experience.
Enjoy your content on different kinds of media
Full backwards compatibility with DVD, CD and USB
memory stick ensures that you can continue to enjoy
your current audio-video collection. Additionally, you
can enjoy AVCHD (for DVD-RW/-R only) / video files /
photo files / music files.
Listen to rich multi-channel surround sound
Multi-channel surround sound, which realizes real-to-
life sound and makes you feel that you are really there.
Easy and simple connection to your HDTV via HDMI
Connect this unit to your HDTV with one single HDMI
(High-Definition Multimedia Interface) cable. It is
recommended to use a High Speed HDMI cable for
better compatibility. The high definition video output
signal will be transferred to your HDTV without
conversion to analog signals, so you will get excellent
picture and sound quality, completely free from noise.
EasyLink (HDMI CEC)
This unit supports HDMI CEC, which allows integrated
system control over an HDMI cable and is part of the
HDMI standard. This function may not work properly on
some devices.
PiP (BONUSVIEW™)
Some BD-Videos have the PiP function which enables
you to display the secondary video in the primary
video. You can call up the secondary video by pressing
[OPTIONS] whenever the scene contains a secondary
video.
BD-Live™
BD-Live™ (BD-ROM version 2 Profile 2.0) that
allows interactive functions to be used when this
unit is connected to the Internet in addition to the
BONUSVIEW™ function. The various functions differ
depending on the disc.
Pop menu
Some BD-Videos have a pop menu which is a navigation
menu that can be called up and be operated on the TV
screen without interrupting playback. You can call up
the pop menu by pressing [POP MENU]. Contents in the
pop menu vary depending on the disc.
HDMI 24p output
(Ultra HD Blu-ray™ disc / Blu-ray Disc™)
This unit is equipped with the feature which can provide
smooth movement during playback of film originated
material with a frame rate of 24 frames per second with
progressive. (Available only when the display device is
connected with an HDMI cable.) Refer to “HDMI video
resolution” on page 54.
BT.2020
BT.2020 is a color gamut standard enhanced from BT.709
adopted for the existing HDTV and Blu-ray Disc™ .
This new standard fulfills the color range expected for
4K / 8K ultra high definition televisions (UHDTV) which
is capable of reproducing 99.9 percent of the colors in
nature.
HDR10
HDR10 is an image standard adopted for Ultra HD
Blu-ray™ (UHD BD / 4K Blu-ray™) and its color depth is
10 bit which is capable of depicting contrast 4 times
more detailed than the existing SDR (8 bit). This
technology allows viewers to enjoy pictures with clarity
and more natural colors.
Deep Color
Deep Color reduces posterization (color banding) effect
of the playback image.
Playing back 4K or 4K HDR
This unit is equipped with the function to reproduce
4K or 4K HDR. (Video enhancement: progressive
scan, video upscaling, BT.2020 / BT.709, HDR to SDR
conversion, HDR 10, deep color) page 30.
Playing back contents from a USB memory stick
You can play back photo files / music files / video
files stored on a USB memory stick. BD-ROM discs
sometimes store picture-in-picture commentary,
subtitles or other extras on a USB memory stick for use
during playback with the BD-Video.
Playing back AVCHD files
This unit supports playback of AVCHD format files (new
format for high definition video camcorders) recorded on
a disc / SD memory card using USB card reader. Your high
definition personal archive is playable in HD quality.
EN 8
x.v.Color
This unit supports playback of video contents on
discs recorded with “x.v.Color” technology. To watch
this video content with the “x.v.Color” space, a TV or
other display device supporting both video image
reproduction using “x.v.Color” standard and capability
of manual switching of its color space setting is
required. Please refer to the User Manual of your
display device for further information.
Enjoy content stored on home media servers
This unit allows you to play music files, video files,
and view photo files stored on home media servers
connected to your home network.
Netflix
With this unit, you can enjoy movies and TV episodes
streamed instantly from Netflix via the Internet. In order
to use this feature, you must visit www.netflix.com/ on
your PC and become a Netflix member.
(This feature is available only in the United States.)
VUDU™
This unit supports VUDU™ which is a leading HD
on demand video service. With VUDU™, you can also
enjoy movies and TV episodes. In order to use this
feature, you must visit www.vudu.com
YouTube™
This unit enables you to access YouTube™.
On your TV screen, you can enjoy a large number of
video clips streamed from YouTube™.
Digital Rights Management
This product contains technology subject to certain
intellectual property rights of Microsoft.
Use or distribution of this technology outside of this
product is prohibited without the appropriate license(s)
from Microsoft.
Auto standby
20 minutes after the screen saver starts, this unit will be
placed in standby mode.
EN 9
2.2. Version information
“Version info” screen provides information about this unit’s software version.
You can also download the latest software from the Philips website and update it yourself if it is newer than the
version currently on your unit. The current version of software on your unit can be seen on the “Version info” screen.
To access “Version info”, follow the procedure below.
1. Press [Q (HOME)].
2. Use [
] to select “Setup”, then press [OK].
3. Use [
] to select “Advanced”, then press [OK].
4. Use [
] to select “Version info”, then press [OK].
2.3. Symbols used in this owner’s manual
To specify which media type each function is applicable to, a combination of the symbols shown below will be
depicted next to that function's explanation.
Symbol Description
[UHDBD]
UHD
BD
UHD
BD
Description refers to Ultra HD Blu-ray™
[BD Video]
BD
VIDEO
BD
VIDEO
Description refers to BD-Video
[DVD Video]
DVD
VIDEO
DVD
VIDEO
Description refers to DVD-Video
[DVD VR]
DVD
VR
DVD
VR
Description refers to DVD-RW/-R in VR mode
[CD]
C DC D
Description refers to Audio CD / DTS-CD
[AVCHD]
AVCHDAVCHD
Description refers to DVD-RW/-R with AVCHD files
[JPEG]
FILE
FILE
Description refers to BD-RE/-R, DVD-RW/-R, CD-RW/-R and USB memory stick with photo files
[MUSIC]
MUSIC
FILE
MUSIC
FILE
Description refers to BD-RE/-R, DVD-RW/-R, CD-RW/-R and USB memory stick with music files
[VIDE
VIDEOVIDEO
Description refers to H.264/H.265 (.mp4/.mov), MPEG2 (TS/PS) (.mpg/.mpeg/.m2ts/.mts/.ts), VOB
(.vob), VP9/VP8 (.webm) video files
[Media Server V]
Media Server
VIDEO
Media Server
VIDEO
Description refers to video files on the Home Media Server
[Media Server M]
Media Server
MUSIC
Media Server
MUSIC
Description refers to music files on the Home Media Server
[Media Server p]
Media Server
Media Server
Description refers to photo files on the Home Media Server
If you do not find any of the symbols listed above under the function heading, the operation is applicable to all
media types.
EN 10
3. FUNCTIONAL OVERVIEW
3.1. Top / front panel
1 5 6
3* 42
Top
Front
* The unit can also be turned on by pressing this button.
1. Disc tray
2. Power-on indicator
3.
(OPEN/CLOSE) button*
4.
(POWER) button
5. Infrared sensor window
6. USB input
CautionC
• Do not connect any device other than USB memory stick or USB card reader into the USB input. (e.g. PC,
external HDD, digital camera, keyboard, mouse, etc.)
• When connecting a USB memory stick, connect it directly to the USB input. Do not use a USB extension cable.
3.2. Rear panel
LAN HDMI OUT
1 2 3
1. AC power cord
2. LAN terminal
3. HDMI OUT jack
CautionC
• Do not touch the inner pins of the jacks on the rear panel. Electrostatic discharge may cause permanent
damage to the unit.
• This unit has neither a TV RF modulator, nor a digital audio output (optical/coaxial) jack.
EN 11
continued on next page
3.3. Remote control
1
13
14
15
17
16*
18
11*
2
3
4
5
12
6
7
8
9*
10
* The unit can also be turned on by pressing these
buttons.
1.
(STANDBY/ON) button
• Press to turn on the unit, or to switch the unit into
standby mode. (To completely turn off the unit,
you must unplug the AC power cord.)
2. AUDIO
• Press to select the audio channel (such as audio
languages) on a disc.
3.
(HOME) button
• Press to display the home menu.
4. TOP MENU
Blu-ray Disc™: Press to display the top menu.
DVD: Press to display the title menu.
5.
buttons
• Press to select items or settings.
6. BACK button
• Press to return to the previously displayed menu
or screen function.
7.
(STOP) button
• Press to stop playback.
8.
(SKIP) button
• During playback, press once to return to the
beginning of the current title, chapter, track or file.
• During playback, press twice to return to the
previous title, chapter, track or file.
• During photo playback, press to return to the
previous File.
9.
(PLAY/PAUSE) button*
• Press to start playback or resume playback.
• Press to pause playback.
10.
(REVERSE) button
• During playback, press to fast reverse the
playback.
11. NET FL IX/V UD U™/Y o uTub e ™ *
• Press to Launch VOD (Video On Demand).
12. POP MENU
Blu-ray Disc™: Press to display the pop menu.
DVD: Press to display the disc menu.
Photo/Music files: During playback, press to display
the file list.
13. OK button
• Press to confirm or select menu items.
14. OPTIONS button
• During playback, press to display the play menu.
15. RED / GREEN / YELLOW / BLUE buttons
• Press to activate shortcut keys on some BD-video
functions.
16.
(OPEN/CLOSE) button*
• Press to open or close the disc tray.
17.
(SKIP) button
• During playback, press to skip to the next chapter,
track or file.
• When playback is in pause mode, press to
Forward the playback picture by picture.
18.
(FORWARD) button
• During playback, press to fast forward the
playback.
• When playback is in pause, press to slow forward
the playback.
EN 12
NoteD
• Use the included remote control. Remote-control
operation on any other remote control, such as a
universal remote control, is not guaranteed.
• Make sure the component code on your universal
remote control is set to our brand. Refer to the
instruction book accompanying your remote control
for more details.
C Installing the batteries in the remote control
Install 2 AAA (1.5V) batteries matching the polarity
indicated inside battery compartment of the remote
control.
1 2 3
CautionC
Incorrect use of batteries can result in hazards such
as leakage and bursting. Please follow the guidelines
below:
• Lithium or ni-cad and ni-mh rechargeable batteries
are not recommended to use for remote control.
• Do not mix different types of batteries such as
alkaline and standard (carbon-zinc).
• Do not mix new and old batteries together.
• Do not use different kinds of batteries together.
Although they may look similar, different batteries
may have different voltages.
• Make sure that the + and - ends of each battery
match the indications in the battery compartment.
• Remove batteries from battery compartment, when
the remote is not going to be used for a month or
more.
• When disposing of used batteries, please comply
with governmental regulations or environmental
public rules that apply in your country or area.
• Do not recharge, short-circuit, heat, burn or
disassemble batteries.
C Using the remote control
Remote control usage guidelines:
• Make sure that there are no obstacles between the
remote control and the infrared sensor window on
the unit.
• Remote operation may become unreliable if strong
sunlight or fluorescent light is shining on the infrared
sensor window of the unit.
• Remote controls of different devices can interfere
with each other. Avoid using a remote control from
another device which is located close to the unit.
• Replace the batteries when you notice a fall-off in
the operating range of the remote control.
• The maximum operable ranges from the unit are as
follows.
- Line of sight:
approx. 23 feet (7 m)
- Either side of the center:
approx. 16 feet (5 m) within 30°
- Above:
approx. 16 feet (5 m) within 15°
- Below:
approx. 10 feet (3 m) within 30°
30˚ 30˚
16 feet (5 m) 16 feet (5 m)23 feet (7 m)
EN 13
3.4. Guide to on-screen display
C Home menu
When you turn on the unit, the home menu will appear automatically. Otherwise, press [ (HOME)].
Disc not inserted.
Disc USB/Home Network
Setup
NETFLIX YouTubeVudu
1
4
2 3
5 6
1. ˝Disc˝: Initiates playback of inserted disc, displays thumbnails of tracks / files.
2. ˝USB/Home Network˝: Displays a USB/Home Network selection menu.
If you select "USB", displays the file list on the connected USB memory stick.
If you select "Home Network", home network menu.
3. ˝Setup˝: Accesses the setup menu
4. ˝NETFLIX˝: Accesses NETFLIX
5. ˝Vudu˝: Accesses VUDU™
6. ˝YouTube˝: Accesses YouTube™
C Setup menu
Audio
Network
Video
3D Output
TV Display
HDMI Video
View HDMI Video
24p Output
Color Space
High Dynamic Range Output
Noise Reduction
Auto(2D)
16:9 Widescreen
Auto
Auto
YCbCr(4:4:4)
Auto
O
Advanced
Preferences
Accessibility
1
2
1. Category
2. Menus / Options: Displays options for the highlighted item on the left whenever available
C Play menu
During playback, press [OPTIONS] to display the play menu.
(e.g.) Blu-ray Disc™
Options
Info
Search
Audio
Subtitle
Subtitle Style
Repeat
Angle
EN 14
4. CONNECTIONS
There are four ways to connect this unit. Refer to the following instructions to connect this unit to your TV.
• When you change the connections, all devices should be turned off.
• When making connections with external devices, please refer to their user manuals for additional setup help.
• This unit supports a TV up to 1080i, 1080p, 4K resolution.
• This unit is not required for analog audio connection.
4.1. HDMI video /audio connection
Method 1
Page 15
C Connecting the unit directly to a TV
Method 2
Page 15
C Connecting the unit through a soundbar or AV receiver
or
Method 3
Page 16
C Connection to a TV and a non-4K compatible soundbar or AV receiver
or
continued on next page
EN 15
C Connecting the unit directly to a TV
With this connection method, the video and audio are output from the TV.
LAN HDMI OUT
HDMI IN
HDMI cable
NoteD
• For 4K or 4K HDR playback, please confirm that your TV supports 4K or 4K HDR input, and make certain that
your TV settings are configured to display the correct format.
• The HDMI port on the TV accepts 4K or 4K HDR signal. You have set the correct setting in the TV menu for the TV
to accept and display 4K or 4K HDR signals.
• Use an 18 Gbps high-speed HDMI cable which supports 4K or 4K HDR when you connect to TV.
• If you have questions regarding the capabilities and settings of your TV, please contact their manufacturer.
C Connecting the unit through a soundbar or AV receiver
With this connection method, the video is output from the TV, and the sound is output from the soundbar or AV
receiver.
HDMI IN HDMI OUT
HDMI IN
LAN HDMI OUT
4K / 4K HDR
Pass-through
or
and
HDMI cable
HDMI cable
NoteD
• For 4K or 4K HDR playback, please confirm that your TV supports 4K or 4K HDR input, and make certain that
your TV settings are configured to display the correct format.
• Use an 18 Gbps high-speed HDMI cable which supports 4K or 4K HDR when you connect to TV.
• If you have questions regarding the capabilities and settings of your TV or AV receiver, please contact their
manufacturer(s).
• When voice guide is set to on:
- The HDMI audio settings are fixed to LPCM.
- The unit will automatically set the voice guide function to off if “Bitstream” or “Re-encode” is selected in
“HDMI audio”.
Method 1
Method 2
continued on next page
EN 16
C Connection to a TV and a non-4K compatible soundbar or AV receiver
Connect as follows if your AV receiver or soundbar is not 4K-compatible.
With this connection method, the video is output from the TV, and the sound is output from the AV receiver or
soundbar.
DIGITAL AUDIO
IN
HDMI IN
DIGITAL AUDIO
OUT
or
and
LAN HDMI OUT
oror
Optical cable
Coaxial cable
HDMI cable
NoteD
• For 4K or 4K HDR playback, please confirm that your TV supports 4K or 4K HDR input, and make certain that
your TV settings are configured to display the correct format.
• Use an 18 Gbps high-speed HDMI cable which supports 4K or 4K HDR when you connect to TV.
• If you have questions regarding the capabilities and settings of your TV or AV receiver, please contact their
manufacturer(s).
• When voice guide is set to on:
- The HDMI audio settings are fixed to LPCM.
- The unit will automatically set the voice guide function to off if “Bitstream” or “Re-encode” is selected in
“HDMI audio”.
Method 3
continued on next page
EN 17
In order to play 4K/HDR content, this unit must be connected to a 4K/60p/4:4:4 and Ultra HD Blu-ray™ compliant
device for best possible picture. See chart below for all options.
• For 4K/60p/4:4:4, an 18Gbps high-speed HDMI cable is required.
Required TV
specifications
Playback content
Recommended settings Video signals from the unit
HDMI
video
resolution
HDMI
Color space
24p
output
High Dynamic
Range output
Output
resolution
Frame rate /
Color space
Color depth
Up to
4K
60p
4:4:4
BD-Video 24p
Auto YCbCr (4:4:4)
Auto
Auto
4K
24p/4:4:4 12 bit
Ultra HD Blu-ray™
24p 24p/4:4:4 12 bit
60p 60p/4:2:2 12 bit
BD-Video 24p
Off
60p/4:2:2 12 bit
Ultra HD Blu-ray™
24p 60p/4:2:2 12 bit
60p 60p/4:2:2 12 bit
Up to
4K
60p
4:2:0
BD-Video 24p
Auto YCbCr (4:4:4)
Auto
Auto 4K
24p/4:4:4 8 bit
Ultra HD Blu-ray™
24p 24p/4:2:2 12 bit
60p 60p/4:2:0 8 bit
BD-Video 24p
Off
60p/4:2:0 8 bit
Ultra HD Blu-ray™
24p 60p/4:2:0 8 bit
60p 60p/4:2:0 8 bit
Up to
4K
24p/30p
BD-Video 24p
Auto YCbCr (4:4:4)
Auto
Auto 4K
24p/4:4:4 8 bit
Ultra HD Blu-ray™
24p 24p/4:4:4 8 bit
60p 30p/4:4:4 8 bit
BD-Video 24p
Off
30p/4:4:4 8 bit
Ultra HD Blu-ray™
24p 30p/4:4:4 8 bit
60p 30p/4:4:4 8 bit
• Ultra HD Blu-ray™ content is created in 4K resolution.
• TVs supporting 4K60p are compatible with HDCP 2.2.
• When playing back 4K Ultra HD Blu-ray™ discs with HDR, if you set Color space to RGB or High Dynamic Range
output to SDR, this unit will not output HDR.
NoteD
• If this unit is connected to an HDCP incompatible display device, video will not be displayed properly.
• Use a certified HDMI cable (an HDMI cable with the HDMI logo) for this connection. High-Speed HDMI cable
(also known as HDMI category 2 cable) is recommended for better compatibility.
• In order for Ultra HD Blu-ray™ video playback, connect this unit to a 4K/HDR compatible display device using an
18 Gbps high-speed HDMI cable.
• In order for Blu-ray 3D™ video playback, connect this unit to a 3D compatible display device using a 3D
compatible HDMI cable.
• Do not tilt the HDMI connector when inserting it into the HDMI port, and make sure the shapes of the HDMI port
and the HDMI cable's connector match.
EN 18
4.2. HDMI audio output
Media Source
HDMI audio
Bitstream(*4) LPCM Re- enco de(*4)
BD
Dolby Digital Dolby Digital Multi LPCM Dolby Digital
Dolby Digital Plus Dolby Digital Plus Multi LPCM Dolby Digital Plus(*1)
Dolby TrueHD Dolby TrueHD Multi LPCM Dolby TrueHD
(*1)
DTS DTS 2ch PCM DTS
DTS-HD
High Resolution
DTS-HD
High Resolution
2ch PCM(*2)
DTS-HD
High Resolution(*3)
DTS-HD
Master Audio
DTS-HD
Master Audio
2ch PCM(*2)
DTS-HD
Master Audio(*3)
LPCM Multi LPCM Multi LPCM Multi LPCM(*1)
DVD
Dolby Digital Dolby Digital Multi LPCM Dolby Digital
DTS DTS 2ch PCM DTS
MPEG Multi LPCM Multi LPCM Multi LPCM
PCM Multi LPCM Multi LPCM Multi LPCM
Audio CD LPCM 2ch PCM 2ch PCM 2ch PCM
DTS-CD DTS DTS 2ch PCM DTS
AVCHD
Dolby Digital Dolby Digital Multi LPCM Dolby Digital
LPCM Multi PCM Multi PCM Multi PCM
Audio file
MP3/FLAC/WAV/Vorbis/
ALAC/AIFF/Monkey's
Audio
2ch PCM 2ch PCM 2ch PCM
AAC AAC(*5) 2ch PCM AAC(*5)
Netflix
Dolby Digital Plus Dolby Digital Plus Multi LPCM Dolby Digital Plus
HE-AAC AAC 2ch PCM AAC
VUDU™
Dolby Digital Plus Dolby Digital Plus Multi LPCM Dolby Digital Plus
HE-AAC AAC 2ch PCM AAC
YouTube™ HE-AAC AAC 2ch PCM AAC
(*1) When there is the secondary audio and/or interactive audio, it will be output in Dolby Digital.
(*2) Only the core substream will be decoded.
(*3) When there is the secondary audio and/or interactive audio, it will be output in DTS.
(*4) While the HDMI audio is set to Bitstream or Re-encode, turning on voice guide will automatically set HDMI
audio to LPCM.
(*5) AAC Raw only supports the source with sample rate between 32kHz and 48kHz.
continued on next page
EN 19
continued on next page
4.3. Connection to the network
By connecting this unit to the Internet, you can update software via the Internet and access BD-Live™ and other
Network Services such as Netflix, VUDU™, and YouTube™.
– Software Update: For more information, refer to “Software update” on page 56.
– BD-Live™: For more information, refer to “Enjoying BD-Live™ discs using Internet” on page 37.
– Netflix / VUDU™ / YouTube™: For more information, refer to “Information on network services” on page 43.
NoteD
• A wired connection is the preferred method of connecting this unit to the Internet, especially while performing
a Software update of this unit via the Internet. It also provides a more stable connection while streaming HD
video versus Wireless LAN. Wireless LAN performance could be unstable if there are other devices near this unit
which also operate in the same frequency spectrum.
C Network connection (wired)
WAN LAN
12345
LAN
LAN HDMI OUT
Nerwork equipment
(Modem, etc.)
Broadband router or
hub
Ethernet cable
(not included)
Ethernet cable
(not included)
Internet
CautionC
• Do not insert any cable other than an ethernet cable to the LAN terminal to avoid damaging the unit.
• Do not connect your PC directly to the LAN terminal of this unit.
NoteD
• When you connect an ethernet cable from a router with internet access to this unit, it will automatically
configure network settings. (You do not need to manually configure network settings unless particular settings
are required.) However, when switching from wireless to wired, “Wired” in the setup needs to be selected.
• If your modem does not have router functions, connect a wired router.
• If your modem has router functions but there is no vacant port, add a switch / hub.
• Please purchase shielded ethernet cables at your local store and use them when you connect to network
equipment.
EN 20
C Network connection (wireless)
LAN WAN
Ethernet cable
(not included)
Internet
Wireless router
NoteD
• If using the wireless connection, refer to “Network configuration (wireless)” on page 51 to configure network
settings.
• For a wireless router, use a router that supports IEEE 802.11 a/b/g/n/ac specifications.
(“ac” is preferred type for a faster stable operation of the wireless network.)
• This unit supports infrastructure mode when using a wireless router.
• This unit does not support ad-hoc mode.
• Other radio devices or obstacles may cause interference to the wireless network connection.
• If you are experiencing signal issues with your wireless connection, please confirm that your wireless router is
placed close enough to the unit.
EN 21
continued on next page
5. BEFORE YOU START
5.1. Initial setup
After you have completed all of the connections to your TV, review the steps below.
1. Press [ (POWER)] to turn on the unit.
2. Turn on your TV.
3. Language setup screen will appear. Use [
] to select your language, then press [OK].
Please select your language. If
you want to use voice guide,
please select “English” or
“Español” .
English
Français
Español
Veuillez choisir votre langue
pour l'achage à l'écran. Si
vous voulez utiliser la fonction
Guide vocal, veuillez régler à
« English » ou « Español ».
Por favor, seleccione su idioma
para el menú en pantalla. Si
desea usar la función de Guía
por voz, ajuste “English” o
“Español” .
4. Output confirmation screen will appear.
• If 4K resolution can be output, this “Output confirmation screen” will be skipped.
Current HDMI video resolution
1080p
Select “Yes” to
continue with this resolution.
If you want to check
recommended connections for
4K playback, please refer to
“Help Guide” .
Yes
Back
Help Guide
• Playback is possible on conventional 2K High-Definition TV’s, however, the picture quality will be down-
converted to match the TV resolution (720p / 1080i / 1080p).
Selecting “Yes” on the output confirmation screen leads you to step 5, the “Voice Guide” settings.
C How to output 4K signals:
To enjoy 4K, you need a 4K-compatible TV and an HDMI cable that supports 18Gbps.
- Make sure the player is connected to a 4K compatible TV or HDMI port which supports 4K signals.
- Details can be confirmed by selecting “Help Guide”.
C Diagnostic result screen:
This screen appears when the player successfully
outputs 4K signals to the TV.
Updated HDMI video resolution
HDMI video resolution is updated.
4K
Close
This screen appears when the player fails to output 4K
signals to the TV.
Updated HDMI video resolution
HDMI video resolution is updated.
1080p
Select “Yes” to continue with thisr
esolution.
If you want to check the Help Guide,
select “No” .
Yes No
EN 22
5. Voice guide setup screen will appear. Use [
] to select “On” or “Off”, then press [OK].
• If French is selected during the language setting, the voice guide setting will be skipped.
6. Quick start setup screen will appear. Use [ ] to select “On” or “Off”, then press [OK].
7. Auto software update setup screen will appear. Use [
] to select “On” or “Off”, then press [OK].
8. Network service setup screen will appear. Use [
] to select “Set up now” or “Skip”, then press [OK].
• If you select “Set up now”, the “Please select the connection method” screen will appear. See step 8 below.
• If you select “Skip”, the home menu screen will appear.
9. Select connection method will appear. Use [ ] to select “Wired” or “Wireless”, then press [OK].
Please select the connection
method.
Cancel
Back
Wired
Wireless
1 7
• If you select “Wired”, the network setup screen will appear. See step 9 below.
• If you select “Wireless”, refer to “Network configuration (wireless)” on page 51 to configure network
settings.
10. Network setup screen will appear. Use [ ] to select “Auto setup” or “Manual setup”, then press [OK].
Cancel
Back
Auto Setup
Manual Setup
41 7
Please select your preferred
network setup mode.
• If you select “Auto setup”, network setting will automatically be performed.
• If you select “Manual setup”, refer to step 7 - 14 in “Manual setup” on page 50.
C How to reset the OSD language
You can reset the OSD language if you selected the wrong language.
1. Press [ (HOME)] to display the home menu.
2. Use [
] to select “ ”, then press [OK].
• This item is “Setup” (English) / “Installation” (French) / “Instalación” (Spanish).
• From here on, please select one of the following items you can find on screen:
3. Use [ ] to select “Preferences” (English) / “Préférences” (French) / “Preferencias” (Spanish), then
press [OK].
4. Use [
] to select “Menu language” (English) / “Langage du menu” (French) / “Menú Idioma” (Spanish),
then press [OK].
5. Use [
] to select your desired language, then press [OK].
6. If the items that were set are displayed in your desired language, then press [
(HOME)] to exit.
EN 23
6. INFORMATION ON PLAYBACK
6.1. Information on playback
C Playable discs and files
Playable discs Logos
Blu-ray Disc™
- Ultra HD Blu-ray™
- BD-video
- Blu-ray 3D™ Disc
- Blu-ray 3D™ only Disc
- BD-RE* (ver. 2.1)
(Recorded in BDMV format)
- BD-R* (ver. 1.1 / 1.2 / 1.3)
(Recorded in BDMV format)
(Unfinalized disc may not be played back.)
DVD-video
DVD-RW
DVD-R
CD-DA (audio CD)
CD-RW
CD-R
DTS-CD -
(*) Due to the intentional progression of the Blu-ray Disc™ format by its standard setting authority, the company
cannot guarantee or warrant the playability of future extensions of the Blu-ray Disc™ format with this product.
Playable files Media
AVCHD
DVD-RW/-R
SD memory card using USB card reader
JPEG / PNG / GIF / MP3 / FLAC / AAC / WAV /
Vorbis / AIFF / Monkey's Audio / ALAC / H.264 /
H.265 / MPEG2 (TS/PS) / VOB / VP9 / VP8
BD-RE/-R
DVD-RW/-R
CD-RW/-R
USB memory stick
Readable device Playable files / data
USB memory stick
Video files, photo files, music files, Picture-in-Picture commentary,
subtitles or other extras for some BD-ROM
NoteD
• This unit may not be able to play back discs recorded on PC’s or other recorders.
continued on next page
EN 24
C Recommended specifications
Photo file
JPEG (.jpg/.jpeg)
PNG (.png)
GIF (.gif)
Music file
MP3 (.mp3)
Sampling frequency: up to 48kHz
Bit rate: up to 320kbps
FLAC (.flac)
Sampling frequency: up to 192kHz
Bit rate: up to 16.2Mbps
AAC (.m4a)
Sampling frequency: up to 98kHz
Bit rate: up to 320kbps
WAV (.wav)
Sampling frequency: up to 192kHz
Bit rate: up to 36Mbps
Vorbis (.ogg)
Sampling frequency: up to 96kHz
AIFF (.aif)
Sampling frequency: up to 192kHz
Bit rate: up to 36Mbps
Monkey’s Audio (.ape)
Sampling frequency: up to 192kHz
Bit rate: up to 1Mbps
Home Network - PCM
Sampling
frequency
: up to 44.1, 48 kHz
Video file
H.264/H.265
MPEG2 (TS/PS)
VOB
VP9
VP8
AVCHD
AVCHD (.m2ts)
AVCHD (.mts / .m2t)
NoteD for AVCHD
• This unit cannot play back
stand-alone AVCHD files
written to a DVD or copied
to an SD memory card.
The DVD or SD memory
card containing AVCHD
files must have a proper
file and folder structure
meeting AVCHD format
specifications. Please use
AVCHD compliant device /
software to burn or copy
AVCHD files to DVD or SD
memory card. (Please refer
to user manuals of your
device / software for more
information.)
NoteD
• Regardless of the file type, some files may be unplayable due to their incompatible file structure.
Caution / Note for USB memory stick
CautionC
• Do not try to open or modify the USB memory stick.
• Do not touch the terminal surface with your fingers or any metals.
NoteD
• This unit supports USB memory stick with FAT16 / FAT32 file system.
• This unit does not support NTFS file system.
• Please keep the USB memory sticks in their cases when you are not using them.
• Some USB memory sticks may not work with this unit.
• This unit can read SD memory cards using a USB card reader.
– Readable cards: SD memory card (8 MB - 2 GB)
miniSD memory card (16 MB - 2 GB)
microSD memory card (256 MB - 2 GB)
SDHC memory card (4 GB - 32 GB)
miniSDHC memory card (4 GB - 8 GB)
microSDHC memory card (4 GB - 16 GB)
– Readable files: AVCHD / JPEG / PNG / GIF / MP3 / FLAC / AAC / WAV /
Vorbis / AIFF / Monkey's Audio
• Depending on a USB card reader, connected card or device may not be recognized.
continued on next page
EN 25
C Unplayable media and files
The following discs will not be played back on this unit.
• CD-ROM • CD-I (compact disc-interactive)
• DVD-RAM • VSD (video single disc)
• DVD-audio • video CD
• HD DVD • SVCD
• SDXC memory card • microSDXC memory card
• unfinalized disc • BD-RE (ver. 1.0)
• BD-RE (ver. 2.1) (Recorded in BDAV format) • BD-R (ver. 1.1 / 1.2 / 1.3) (Recorded in BDAV format)
• B D X L™
• Blu-ray Disc™ / DVD / CD / USB memory stick / SD memory card containing DivX
®
files
• Blu-ray Disc™ / USB memory stick that contains AVCHD files
• Blu-ray Disc™ / DVD hybrid disc (played back as a BD-video only)
• DVD-RW/-R recorded in non compatible recording format
• Super Audio CD - Only the sound on the CD layer can be heard. The sound on the high-density Super Audio CD
layer cannot be heard.
• Playability of dual discs is not guaranteed.
• This unit cannot play back the disc contents protected by Windows Media™ Digital Rights Management (DRM).
• Attempting to play these discs will display “Disc not supported”.
C Region codes
This unit has been designed to play back BD-video with region “A” and DVD-video with
region “1” or “ALL”. You cannot play back BD-video or DVD-video that is labeled for other
regions.
Look for the symbols on your BD-video or DVD-video. If these region symbols do not
appear on your BD-video or DVD-video, you cannot play back the disc on this unit. The
letter or number inside the globe refers to region of the world. BD-video or DVD-video discs
labeled for a specific region can only be played back on players with the same region code.
NoteD
• Ultra HD Blu-ray™ discs have no region codes.
BD-video
DVD-video
C Hint for disc playback
The contents of a disc are generally divided into sections or folders (group of titles / files) as shown below.
Ultra HD Blu-ray™, BD-video, DVD-video, AVCHD
Audio CD
Title 1 Title 2
Track 1 Track 2 Track 3 Track 4 Track 5
Chapter 1 Chapter 2 Chapter 1 Chapter 2
Chapter 3
Photo / Music / Video
Folder 1
File 1 File 2 File 3 File 4 File 5
Folder 2
continued on next page
EN 26
continued on next page
C Description for icons
[ ] : group (folder) icon
[
] : music file icon
[
] : photo file icon
[
] : AVCHD / video file icon
- ˝Folders” refers to the group of files.
- ˝Track” refers to the contents recorded on the audio CD.
- ˝Files” refers to the contents on a disc which are recorded in AVCHD or JPEG / PNG / GIF / MP3 / FLAC / AAC / WAV /
Vorbis / AIFF / Monkey's Audio file format.
NoteD
• Unrecognizable characters will not be displayed.
6.2. Guide to file list
C Photo file list
Photo Video AVCHDMusic
USB
Playable file(s) File information
RED GREEN YELLOW BLUE
Folder_1 Folder_2 Folder_3 Folder_4 Folder_5
Folder_6 Folder_7 Folder_8 Photo_1.jpg Photo_2.jpg
1
2
4
3
1. Folder
2. Photo thumbnail
3. Page(s)
4. Operation guide
C Music file list
Photo VideoMusic AVCHD
Music
Root Folder/Current Folder
Playable file(s) File information
RED GREEN YELLOW BLUE
Music Title
Artist Name
Album Name
4:50
Music Title
Artist Name
Album Name
4:50
Music Title
Artist Name
Album Name
4:50
Music Title
Artist Name
Album Name
4:50
Music Title
Artist Name
Album Name
4:50
Music Title
Artist Name
Album Name
4:50
Music Title
Artist Name
Album Name
4:50
Music Title
Artist Name
Album Name
4:50
Music Title
Artist Name
Album Name
4:50
Playable file(s) File information
RED GREEN YELLOW BLUE
5
4
3
1
2
1. Music file
2. Summary information on the file (when available)
3. Cover art (when available)
4. Page(s)
5. Operation guide
EN 27
C Video file list
Video
Root Folder/Current Folder
Photo VideoMusic AVCHD
Playable file(s) File information
RED GREEN YELLOW BLUE
Movie Title
Direction Name
10/10/201X
Movie Title
Direction Name
10/10/201X
Movie Title
Direction Name
10/10/201X
Movie Title
Direction Name
10/10/201X
Movie Title
Direction Name
10/10/201X
Movie Title
Direction Name
10/10/201X
4
3
1
2
1. Video file
2. Summary information on the file (when available)
3. Page(s)
4. Operation guide
C DVD-VR title list
DVD Title List (Original)
Disc Name
Page 1/2
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
Title_1
Title_2
Title_3
Title_4
Title_5
Title_6
Title_7
Title_8
Title_9
Title_10
Title_11
10/10
10/10
10/10
10/10
10/10
10/10
10/10
10/10
10/10
10/10
10/10
Time : 2:22:22
Date : 10/10/201X
Start : 12:50 AM
1
2
5
6
3
4
1. DVD title (Original or Playlist)
2. Disc name
3. Title
4. Recording date
5. Page
6. Recording length of the selected title / recording
date / recording start time
C How to navigate through the file list
• Use [ ] to move the highlighted item. Press [BACK] to move back to the previous
directory.
• If the list has multiple pages, you can switch pages using [ / (SKIP)].
• To access files in a folder, select the desired folder, then press [OK].
• Press [Q (HOME)] to exit.
6.3. How to insert a disc
1. Press [ (OPEN/CLOSE)] to open the disc tray.
2. Place the disc on the disc tray with its label side facing up.
3. Press [
(OPEN/CLOSE)] to close the disc tray.
• It may take a while to load the disc.
Align the disc to the disc tray guide.
EN 28
7. BASIC PLAYBACK
7.1. Playing back a disc
[UHDBD]
UHD
BD
UHD
BD
[BD Video]
BD
VIDEO
BD
VIDEO
[DVD Video]
DVD
VIDEO
DVD
VIDEO
[DVD VR]
DVD
VR
DVD
VR
[CD]
C DC D
[AVCHD]
AVCHDAVCHD
[JPEG]
FILE
FILE
[MUSIC]
MUSIC
FILE
MUSIC
FILE
[VIDE
VIDEOVIDEO
1. Insert a disc (refer to “How to insert a disc” on page 27).
• For Blu-ray Disc™ / DVD / AVCHD / audio CD or a disc containing only one type of file, playback will start
automatically. If not, press [ (PL AY/PAUSE)].
• When photo / music / video files are contained on the disc, the file list will be displayed.
• Some discs may show a title or a disc menu. In this case, refer to “Using the title / disc / pop menu” on page 34.
(e.g.) File list: Music
Photo VideoMusic AVCHD
Music
Root Folder/Current Folder
Playable file(s) File information
RED GREEN YELLOW BLUE
Music Title
Artist Name
Album Name
4:50
Music Title
Artist Name
Album Name
4:50
Music Title
Artist Name
Album Name
4:50
Music Title
Artist Name
Album Name
4:50
Music Title
Artist Name
Album Name
4:50
Music Title
Artist Name
Album Name
4:50
Music Title
Artist Name
Album Name
4:50
Music Title
Artist Name
Album Name
4:50
Music Title
Artist Name
Album Name
4:50
Playable file(s) File information
RED GREEN YELLOW BLUE
• File list will be displayed.
2. Use [ ] to select a media tab (photo / music / video / AVCHD), then press [OK].
3. Use [
] to select a file to play, then press [OK].
To Skip to the next title / chapter / track / file: Press [ (SKIP)].
To Skip to the previous title / chapter / track / file: Press [
(SKIP)].
To Pause playback: Press [
(PLAY/PAUSE)].
To Return to normal playback: Press [
(PLAY/PAUSE)].
To stop playback: Press [
(STOP)].
• Playback will be in resume-on-stop mode.
continued on next page
EN 29
C Resume-on-stop mode
[UHDBD]
UHD
BD
UHD
BD
[BD Video]
BD
VIDEO
BD
VIDEO
[DVD Video]
DVD
VIDEO
DVD
VIDEO
[DVD VR]
DVD
VR
DVD
VR
[AVCHD]
AVCHDAVCHD
While the disc icon is selected on the home screen, pressing [OK] or [ (PL AY/PAUSE)] will resume playback.
Pressing [OK] while the message “To playback from the beginning, press [OK].” is displayed will start playback from
the beginning of the currently selected title.
[CD]
C DC D
While the disc icon is selected on the home screen, pressing [OK] or [ (PL AY/PAUSE)] will resume playback.
Pressing [OK] while the message “To playback from the beginning, press [OK].” is displayed will start playback from
the beginning of the first track on the Audio CD.
[MUSIC]
MUSIC
FILE
MUSIC
FILE
[VIDE
VIDEOVIDEO
When you press [ (PLAY/PAUSE)] or [OK] next time, the playback will start from the point where it has been
stopped.
NoteD
• Playback will also stop and the home menu will appear when you press [ (HOME)].
• For BD-Java application, the resume-on-stopmay not be available.
• For BD / DVD / AVCHD / Audio CD, except for photo / music / video files, resume-on-stop mode remains in
effect even after power is turned off. It will be canceled once the disc is ejected.
• Discs containing AVCHD and photo / music / video files will be played back as AVCHD.
• CDs/DVDs containing FLAC (.flac), WAV (.wav), AIFF (.aif), or video files with high frequency and large
quantization bit rates may not play properly.
• With regard to the multi-border BD-RE/-R, additionally recorded sections cannot be recognized.
• With regard to the multi-border DVD-RW/-R, additionally recorded sections may not be recognized.
NoteD for photo playback
• For photo files except GIF files, every press of [ ] will turn the image by 90 degrees when an image is
displayed.
• Some unplayable folders or files may be listed due to the recording status.
• High-resolution photo files take longer to be displayed.
• Progressive JPEG files (JPEG files saved in progressive format) cannot be played back on this unit.
• Interlaced GIF files over 7 Mb cannot be played back on this unit.
EN 30
7.2. 4K or 4K HDR playback
In order for 4K or 4K HDR playback, make sure the following before you start:
AV receiver
HDMI Cable
TV
Blu-ray Disc™
AV receiver
HDMI Cable
TV
Blu-ray Disc™
AV receiver
HDMI Cable
TV
Blu-ray Disc™
• Your TV supports 4K or 4K HDR
input.
• Your TV has an HDMI port that
accepts 4K or 4K HDR signal.
• Your TV is enabled to display 4K or
4K HDR image.
• An 18 Gbps high-speed HDMI
cable that supports 4K or 4K HDR
is used to connect the TV and the
player.
• The Blu-ray™ title to play contains
4K or 4K HDR content.
NoteD
• When connecting this unit to a TV through an AV receiver, make sure that the AV receiver supports 4K or 4K HDR
pass-through.
C How to confirm if the current signal is for 4K or 4K HDR
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select “INFO” then press [OK].
Title 001 / 010 Chapter 001/029
00:21:34 02:05:08
Disc : 4K / 24Hz / HDR
Output : 4K / 24Hz / HDR
1 2 23 34 4
Playback media
information
Output video signal
information
1. Playback media
2. Video resolution
3. Video frame rate
4. Dynamic range information
NoteD
• If you have questions regarding the capabilities and settings of your TV or AV receiver, please contact their
manufacturer(s).
• Refer to your TV’s manual if additional settings need to be changed to enable 4K or 4K HDR playback.
• Playback is possible when connecting this unit to a 4K or 4K HDR incompatible TV
(conventional 2K High-Definition TV of 720p/1080i/1080p resolutions).
The picture quality, however, is not 4K or 4K HDR best quality.
• 4K output is not possible when “HDMI video” on this unit is set to “480p”, “720p”, “1080i”, or “1080p”.
• 4K HDR output is not possible when “HDMI video” on this unit is set to other than “Auto” or “4K”, or when
“High Dynamic Range output” is set to “SDR”.
• For playback media information, “Video resolution” is shown as “-” instead when resolution is under “480p” or “480i”.
“Video frame rate” and “Dynamic range information” are shown as “-” instead when the signal is not detected.
EN 31
7.3. Playing back an Ultra HD Blu-ray™ disc
[UHDBD]
UHD
BD
UHD
BD
This unit can play back Ultra HD Blu-ray ™ discs. In order to view Ultra HD Blu-ray ™ videos, you need to have the
following:
- 4K/60p (color space 4:4:4) and HDCP 2.2 compatible device.
- HDR compatible device
- 18 Gbps high-speed HDMI cable
- Ultra HD Blu-ray™ disc
1. Connect this unit to a 4K/60p (4:4:4) compatible TV using an 18 Gbps high-speed HDMI cable.
• Refer to “HDMI video /audio connection” on page 14.
2. Insert an Ultra HD Blu-ray ™ disc.
• Refer to “How to insert a disc” on page 27.
3. Playback may start automatically. If not, press
[
(P L AY/PAU SE )] .
• Some discs may show a title or a disc menu. In this case, refer to “Using the title / disc / pop menu” on page 34.
To pause playback:
Press [
(P L AY/PA USE )] .
To return to normal playback:
Press [
(P L AY/PA USE )] .
To stop playback:
Press [ C (STOP)].
Playback will be in resume-on-stop mode, and the background screen will appear.
C Resume-on-stop mode
When you press [ ( PL AY/ PA US E) ] next time, the playback will start from the point where it has been
stopped.
NoteD
• If this unit is connected to a non-HDCP 2.2 compatible device, HDR signals will be dynamically converted and
output in 2K resolution. Some discs may not be played correctly.
• If this unit is connected to a non-4K/60p (color space 4:2:0) compatible device, and a 60p video is played, HDR
signals will be dynamically converted and output.
• If this unit is connected to a non-4K/60p compatible device, HDR signals will be dynamically converted.
• If this unit is connected to a non-HDR compatible device, HDR signals will be dynamically converted and output.
Some discs may output images in 2K resolution or may not be played correctly.
EN 32
7.4. Playing back a Blu-ray 3D™ disc
[BD Video]
BD
VIDEO
BD
VIDEO
This unit can play back Blu-ray 3D™ discs which contain stereoscopic 3D video. In order to view Blu-ray 3D™
videos, you need to have the following:
- 3D capable TV
- 3D compatible HDMI cable
- 3D glasses
- Blu-ray 3D™ disc or Blu-ray 3D™ only disc
1. Connect this unit to a 3D-compatible TV using a 3D-compatible HDMI cable.
• Refer to “HDMI video /audio connection” on page 14.
2. Insert a Blu-ray 3D™ disc or a Blu-ray 3D™ only disc.
• Refer to “How to insert a disc” on page 27.
3. Playback may start automatically. If not, press [ (P L AY/PAU SE )].
• Some discs may show a title or a disc menu. In this case, refer to “Using the title / disc / pop menu” on page 34.
To pause playback:
Press [
(P L AY/PA USE )] .
To return to normal playback:
Press [
(P L AY/PA USE )] .
To stop playback:
Press [ C (STOP)].
Playback will be in resume-on-stop mode, and the background screen will appear.
C Resume-on-stop mode
When you press [ ( PL AY/ PA US E) ] next time, the playback will start from the point where it has been
stopped.
CautionC
• Watching 3D videos may cause headache, dizziness or tiredness. To avoid such consequences, do not watch 3D
videos for a long period of time.
• Watching 3D videos is not recommended for the following people:
– People who are susceptible to motion sickness
– Children from walking age to seven years
– Pregnant woman
For more information, refer to “IMPORTANT HEALTH AND SAFETY INFORMATION FOR 3D TELEVISIONS” on page 70.
NoteD
• For more information, refer to the 3D TV’s manual.
• When “3D BD-Video Playback” is set to “3D Playback” and your TV is not 3D capable, playback of Blu-ray 3D™
discs will revert to 2D depending on the disc.
• For some Blu-ray 3D™ only discs, playback in 2D mode is not possible.
EN 33
7.5. Playing back content from a USB memory stick
[JPEG]
FILE
FILE
[MUSIC]
MUSIC
FILE
MUSIC
FILE
[VIDE
VIDEOVIDEO
You can play back photo files (JPEG, PNG, GIF), music files (MP3, FLAC, AAC, WAV, Vorbis, AIFF, Monkey's Audio,
ALAC), video files (H.264, H.265, MPEG2 (TS/PS), VOB, VP9, VP8) stored on a USB memory stick. With the USB
memory stick, you can also enjoy the following functions:
• Special additional contents for BD-ROM.
(For more information about the special additional contents, refer to the instruction book that came with the disc.)
1. Connect a USB memory stick.
• This unit will automatically recognize the content type in the media, and display the file list.
(e.g.) File list: Music
Photo VideoMusic AVCHD
Music
Root Folder/Current Folder
Playable file(s) File information
RED GREEN YELLOW BLUE
Music Title
Artist Name
Album Name
4:50
Music Title
Artist Name
Album Name
4:50
Music Title
Artist Name
Album Name
4:50
Music Title
Artist Name
Album Name
4:50
Music Title
Artist Name
Album Name
4:50
Music Title
Artist Name
Album Name
4:50
Music Title
Artist Name
Album Name
4:50
Music Title
Artist Name
Album Name
4:50
Music Title
Artist Name
Album Name
4:50
Playable file(s) File information
RED GREEN YELLOW BLUE
2. Use [ ] to select a media tab (photo / music / video / AVCHD), then press [OK].
3. Use [
] to select a file to play, then press [OK].
CautionC
• Do not disconnect the USB memory stick or switch the unit to standby mode while content on the USB memory
stick is being accessed. It may result in malfunction or loss of the stick's data.
• If you connect a USB memory stick or SD memory card via a USB card reader or USB hub, BD-ROM data will
be written onto the first connected card or device. Connecting a USB memory stick directly to this unit is
recommended.
• Occasionally, SD memory cards / Micro SD memory cards will not be recognized when using certain adapters.
In such cases, try a different USB adapter.
NoteD
• During playback, press [POP MENU] or [ C (STOP)] to go back to the file list.
• The resume information will be cleared when;
- the USB memory stick is disconnected.
- the unit is switched to standby mode.
• If a folder / file name contains an unrecognizable character, the character will not be displayed.
• This unit can read photo files (JPEG, PNG, GIF), music files (MP3, FLAC, AAC, WAV, Vorbis, AIFF, Monkey's Audio,
ALAC), video files (H.264, H.265, MPEG2 (TS/PS), VOB, VP9, VP8), and AVCHD on an SD memory card by using a
USB card reader.
EN 34
7.6. Using the title / disc / pop menu
[UHDBD]
UHD
BD
UHD
BD
[BD Video]
BD
VIDEO
BD
VIDEO
[DVD Video]
DVD
VIDEO
DVD
VIDEO
[AVCHD]
AVCHDAVCHD
Some BD-videos, DVD-videos or AVCHD files may contain a title menu which describes the contents of the disc, or
a disc menu which guides you through the available functions on the disc.
• With such discs, a title menu or a disc menu may appear automatically when you insert the disc. Otherwise, press
[TOP MENU] or [POP MENU] to call up the menu. Refer to the disc’s manual on how to navigate through the Menu.
NoteD
• Menus vary among discs. Refer to the information accompanying the disc for details.
• [TOP MENU] or [POP MENU] may not work with some discs.
EN 35
8. SPECIAL PLAYBACK
8.1. Fast forward / fast reverse
[UHDBD]
UHD
BD
UHD
BD
[BD Video]
BD
VIDEO
BD
VIDEO
[DVD Video]
DVD
VIDEO
DVD
VIDEO
[DVD VR]
DVD
VR
DVD
VR
[CD]
C DC D
[AVCHD]
AVCHDAVCHD
[MUSIC]
MUSIC
FILE
MUSIC
FILE
[VIDE
VIDEOVIDEO
1. During playback, press [ (FORWARD)] repeatedly for fast forward.
During playback, press [
(REVERSE)] repeatedly for fast reverse.
2. Press [
(PLAY/PAUSE)] to return to normal playback.
NoteD
• For Ultra HD Blu-ray™ Disc, Blu-ray Disc™, DVD, DVD-VR, AVCHD, Audio CD, music, video files, speed changes at
5 different levels.
• For Audio CD and music files, fast forward / fast reverse search between different tracks/files are not available.
8.2. Slow forward playback
[UHDBD]
UHD
BD
UHD
BD
[BD Video]
BD
VIDEO
BD
VIDEO
[DVD Video]
DVD
VIDEO
DVD
VIDEO
[DVD VR]
DVD
VR
DVD
VR
[AVCHD]
AVCHDAVCHD
[VIDE
VIDEOVIDEO
1. During playback, press [ (PL AY/PAU SE)]. Then press [ (FORWARD)].
Every time you press [
(FORWARD)], the playback speed changes at 4 different levels.
2. Press [
(PLAY/PAUSE)] to return to normal playback.
NoteD
• Slow reverse is not available.
8.3. Frame by frame playback
[UHDBD]
UHD
BD
UHD
BD
[BD Video]
BD
VIDEO
BD
VIDEO
[DVD Video]
DVD
VIDEO
DVD
VIDEO
[DVD VR]
DVD
VR
DVD
VR
[AVCHD]
AVCHDAVCHD
[VIDE
VIDEOVIDEO
1. In pause mode, press [ (SKIP)] repeatedly.
Every time you press [
(SKIP)], playback will advance one step at a time.
2. Press [
(PLAY/PAUSE)] to return to normal playback.
NoteD
• Frame by frame reverse is not available.
EN 36
8.4. Repeat playback
Available repeat functions vary depending on the disc.
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select “Repeat” then press [OK].
3. Use [
] to select the desired repeat mode.
REPEAT MODE AVAILABLE MEDIA
Chapter repeat
[UHDBD]
UHD
BD
UHD
BD
[BD Video]
BD
VIDEO
BD
VIDEO
[DVD Video]
DVD
VIDEO
DVD
VIDEO
[DVD VR]
DVD
VR
DVD
VR
[AVCHD]
AVCHDAVCHD
The current chapter will be played back repeatedly.
Title repeat
[UHDBD]
UHD
BD
UHD
BD
[BD Video]
BD
VIDEO
BD
VIDEO
[DVD Video]
DVD
VIDEO
DVD
VIDEO
[DVD VR]
DVD
VR
DVD
VR
[AVCHD]
AVCHDAVCHD
[VIDE
VIDEOVIDEO
The current title will be played back repeatedly.
Track repeat
[CD]
C DC D
[JPEG]
FILE
FILE
[MUSIC]
MUSIC
FILE
MUSIC
FILE
The current track or file will be played back repeatedly.
All repeat
[DVD VR]
DVD
VR
DVD
VR
[CD]
C DC D
[JPEG]
FILE
FILE
[MUSIC]
MUSIC
FILE
MUSIC
FILE
[VIDE
VIDEOVIDEO
[Media Server p]
Media Server
Media Server
[Media Server M]
Media Server
MUSIC
Media Server
MUSIC
[Media Server V]
Media Server
VIDEO
Media Server
VIDEO
All content in the media will be played back repeatedly.
4. Press [OPTIONS] to exit.
NoteD
• The repeat setting will be cancelled when you stop playback.
• Repeat setting may be unavailable with some Blu-ray™ discs.
8.5. Shuffle / random playback
Available shuffle and random functions vary depending on the disc.
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select “Mode”, then press [OK].
3. Use [
] to select the desired playback mode, then press [OK].
SHUFFLE / RANDOM MODE AVAILABLE MEDIA
Shuffle playback
[CD]
C DC D
[JPEG]
FILE
FILE
[MUSIC]
MUSIC
FILE
MUSIC
FILE
Plays all songs or photo / music files in the current folder one at
a time in Random order.
Random playback
[CD]
C DC D
[JPEG]
FILE
FILE
[MUSIC]
MUSIC
FILE
MUSIC
FILE
Plays all songs or photo / music files in the current folder
repeatedly in random order.
4. Press [OPTIONS] to exit.
8.6. Slide show
[JPEG]
FILE
FILE
1. Follow steps 1 and 2 in “Playing back a disc” on page 28.
2. Open the folder which contains the desired photo files.
3. Use [
] to select a desired file to be played back, then press [ (PL AY/PAU SE)] or [OK].
• An image will be played back from the selected file.
4. Press [ (STOP)] to stop playback.
NoteD
• Large-size photo files take time to load before being displayed on the screen.
EN 37
8.7. PiP (BONUSVIEW™) setting
[UHDBD]
UHD
BD
UHD
BD
[BD Video]
BD
VIDEO
BD
VIDEO
Some BD-videos have the PiP function which enables you to display the secondary video in the primary video.
1 / 2 MPEG
Primary video
Secondary video
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select “PiP” then press [OK].
• PiP information will appear.
3. Use [ ] to select the secondary video you want to show.
• The secondary video will be displayed with secondary audio.
4. Press [OPTIONS] to exit.
• To select the secondary audio output, refer to “Switching audio soundtrack” on page 41.
NoteD
• Secondary video may not be displayed all the time, depending on the scene, it may or may not be available for
display.
8.8. Enjoying BD-Live™ discs using Internet
[UHDBD]
UHD
BD
UHD
BD
[BD Video]
BD
VIDEO
BD
VIDEO
You can enjoy BD-Live™ which enables you to use interactive features when the unit is connected to the Internet.
Examples of BD-Live™ features:
• Online access to additional content such as movie trailers, subtitles, BD-Java applications, etc.
• While downloading, special video data may be played back.
- Service and functions differ depending on the disc. Follow the instructions given by the disc when using the
BD-Live™ function.
- Connect a USB memory stick with at least 1 GB of available memory before using BD-Live™ features on a
Blu-ray Disc™.
- Do not disconnect the USB memory stick while using BD-Live™ features.
NoteD
• You must connect the unit to the Internet and set up necessary settings in order to use BD-Live™.
• For the network connection, refer to “Connection to the network” on page 19.
• For the network setup, refer to “Network connection” on page 48.
• For certain discs, “BD-Live access level” under “Network” under “Setup” may need to be changed.
• Depending on your connection environment, it may take a few moments to connect to the Internet or the
Internet may not be connected. Refer to “TROUBLESHOOTING” on page 59.
• Some discs with BD-Live™ function require memory when playing back the content. If you cannot play back a
disc with BD-Live™ function, connect a USB memory stick (1 GB or more of available memory).
• Not all BD-Video discs have a BD-Live™ content. To enjoy the BD-Live™ features, please use discs with a BD-
Live™ content.
NoteD for AACS online
• The player or disc ID may be sent to the content provider when playing back a disc with BD-Live™ function.
• If you save your viewing history on the server by using these ID’s, you will be introduced to other similar movies.
• You can save game score histories.
EN 38
8.9. Title / chapter search
[UHDBD]
UHD
BD
UHD
BD
[BD Video]
BD
VIDEO
BD
VIDEO
[DVD Video]
DVD
VIDEO
DVD
VIDEO
[DVD VR]
DVD
VR
DVD
VR
[AVCHD]
AVCHDAVCHD
[VIDE
VIDEOVIDEO
C Using [ (SKIP)] / [ (SKIP)]
1. During playback, press [ (SKIP)] to skip the current title or chapter and move to the next.
The title or chapter will move forward one at a time.
• If there is no chapter in a title, the current title may be skipped.
To go back to the beginning of the current title or chapter, press [ (SKIP)].
Press [ (SKIP)] repeatedly to go to the previous title or chapter. The title or chapter may move backward one
at a time.
C Using “Search˝
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select “Search”, then press [OK].
3. Use [
] to select “Title” or “Chapter”, then press [OK].
(e.g.) Blu-ray Disc™
Title 001/025
4. Use [ ] to select the title / chapter number, then press [OK].
Playback will start from the beginning of the title / chapter.
NoteD
• As for BD-video, how it performs is strongly determined by the disc, and may not perform as described.
• For DVD, title search can be performed on the Home menu by pressing [OPTIONS] while in stop mode or
resume-on-stop mode.
8.10. Track / file search
[CD]
C DC D
[JPEG]
FILE
FILE
[MUSIC]
MUSIC
FILE
MUSIC
FILE
C Using [ (SKIP)] / [ (SKIP)]
1. During playback, press [ (SKIP)] to skip the current track or file and move to the next.
The track / file will move forward one at a time. To go back to the beginning of the current track / file, press
[ (SKIP)].
Press it repeatedly to go to the previous track / file. The track / file will move backward one at a time.
• For photo files, press [ (SKIP)] once to go to the previous file.
C Using “Search˝
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select “Search”, then press [OK].
• For photo files, skip to step 4.
3. Use [ ] to select “Track”, then press [OK].
4. Use [
] to select the track number, then press [OK].
Playback will start from the beginning of the track.
EN 39
8.11. Time search
[UHDBD]
UHD
BD
UHD
BD
[BD Video]
BD
VIDEO
BD
VIDEO
[DVD Video]
DVD
VIDEO
DVD
VIDEO
[DVD VR]
DVD
VR
DVD
VR
[CD]
C DC D
[AVCHD]
AVCHDAVCHD
[MUSIC]
MUSIC
FILE
MUSIC
FILE
[VIDE
VIDEOVIDEO
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select “Search”, then press [OK].
3. Use [
] to select Time Search, then press [OK].
• Blu-ray Disc™ / DVD-Video / AVCHD: “Title Time” or “Chapter Time”.
Audio CD: “Track Time” or “Disc Time”.
(e.g.) Blu-ray Disc™
Title Time 00:00:00/02:03:45
4. Enter the time count you want to jump to.
• Use [ ] to enter the time count, then press [OK].
Playback will start from the desired time entered.
8.12. Number select search
[UHDBD]
UHD
BD
UHD
BD
[BD Video]
BD
VIDEO
BD
VIDEO
[DVD Video]
DVD
VIDEO
DVD
VIDEO
[DVD VR]
DVD
VR
DVD
VR
[AVCHD]
AVCHDAVCHD
Some BD-videos and DVD-videos or AVCHD files have button menus to jump to each button displayed scene.
During playback the scenes which have the button menu, you can enter the button number by using the number
select menu.
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select “Number Select”, then press [OK].
(e.g.) Blu-ray Disc™
0000
• For BD-Java, a single-digit number select menu is displayed.
• For DVD, a double-digit number select menu is displayed.
• For BD-videos and AVCHD files, the number select menu is displayed even if there is no button menu in the
scene.
3. Use [ ] to enter the number you want to jump to.
• To move to the digit you wish to change, press [ ].
4. After all digits are entered, press [OK].
Playback of the selected scene will start.
NoteD
• As for the BD-video, how it performs is strongly determined by the disc, and may not perform as described.
EN 40
8.13. Switching subtitles
[UHDBD]
UHD
BD
UHD
BD
[BD Video]
BD
VIDEO
BD
VIDEO
[DVD Video]
DVD
VIDEO
DVD
VIDEO
[DVD VR]
DVD
VR
DVD
VR
[AVCHD]
AVCHDAVCHD
[VIDE
VIDEOVIDEO
Some video materials may have subtitles in one or more languages. For commercially available discs, the
supported languages can be found on the disc case. Follow the steps below to switch the subtitle language during
playback.
C Using [OPTIONS]
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select “Subtitle”, then press [OK].
3. Use [
] to select your desired subtitle, then press [OK].
(e.g.) Blu-ray Disc™
2 / 5 English
4. Press [OPTIONS] to exit.
C Subtitle Style
For Blu-ray™ discs, the text style can be changed if subtitle Style is available.
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select “Subtitle Style”, then press [OK].
3. Use [
] to select your desired style, then press [OK].
4. Press [OPTIONS] to exit.
NoteD
• Some discs will only allow you to change the subtitles from the disc menu or pop menu. Press [TOP MENU] or
[POP MENU] to display the disc menu or pop menu.
• If the disc has no subtitle language or subtitle style, “ ” will appear if you press [ ].
• During playback of the secondary video, the primary subtitle setting is not available except when there is no
subtitle for the secondary video.
EN 41
8.14. Switching audio soundtrack
[UHDBD]
UHD
BD
UHD
BD
[BD Video]
BD
VIDEO
BD
VIDEO
[DVD Video]
DVD
VIDEO
DVD
VIDEO
[DVD VR]
DVD
VR
DVD
VR
[AVCHD]
AVCHDAVCHD
[VIDE
VIDEOVIDEO
When playing back video material recorded with two or more soundtracks (these are often in different audio
languages or audio formats), you can switch between them during playback.
C Using [AUDIO]
1. During playback, press [AUDIO].
• Pressing [AUDIO] repeatedly switches the audio.
(e.g.) Blu-ray Disc™
1 / 7 English Dolby Audio-Dolby TrueHD Multi
• For Blu-ray™ discs, [AUDIO] is only available in primary audio.
C Using [OPTIONS]
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select “Audio”, then press [OK].
3. Use [
] to select your desired audio, then press [OK].
(e.g.) Blu-ray Disc™
1 / 7 English Dolby Audio-Dolby TrueHD Multi
4. Press [OPTIONS] to exit.
C Secondary Audio
For Blu-ray™ discs, the audio in PiP can be switched. (Refer to “PiP (BONUSVIEW™) setting” on page 37.)
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select “Secondary Audio”, then press [OK].
3. Use [
] to select your desired audio, then press [OK].
4. Press [OPTIONS] to exit.
NoteD
• Secondary audio will not be output when secondary video is not displayed or when the HDMI setting for audio
output is set to “Bitstream”. (For some Blu-ray™ discs, secondary audio will be output even when secondary
video is off.)
• Sound mode cannot be changed during playback of discs not recorded in multiple audio mode.
• Some discs allow changing the audio language setting from disc menu. (Operation varies depending on the
discs. Refer to the Manual accompanying the disc.)
• [AUDIO] may not work on some discs with multiple audio streams or channels (e.g. DVDs that allow changing
audio setting on the disc menu).
• If the disc has no audio language, “ ” will appear if you press [ ] or [AUDIO].
EN 42
8.15. Switching camera angles
[UHDBD]
UHD
BD
UHD
BD
[BD Video]
BD
VIDEO
BD
VIDEO
[DVD Video]
DVD
VIDEO
DVD
VIDEO
Some BD-videos and DVD-videos contain scenes which have been shot simultaneously from various angles. You
can change the camera angle when appears on the TV screen.
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select “Angle”, then press [OK].
3. Use [
] to select your desired angle.
4. Press [OPTIONS] to exit.
NoteD
• If “Angle icon” setting is set to “Off”, will not appear on the TV screen.
8.16. Noise reduction
[UHDBD]
UHD
BD
UHD
BD
[BD Video]
BD
VIDEO
BD
VIDEO
[DVD Video]
DVD
VIDEO
DVD
VIDEO
[DVD VR]
DVD
VR
DVD
VR
[AVCHD]
AVCHDAVCHD
Reduces the noise of the playback picture.
1. Use [ ] to select “Setup” in the home menu, then press [OK].
2. Use [
] to select “Video”, then press [OK].
3. Use [
] to select “Noise reduction”, then press [OK].
4. Use [
] to select your desired setting, then press [OK].
5. Press [Q (HOME)] to exit.
8.17. Closed caption
[UHDBD]
UHD
BD
UHD
BD
[BD Video]
BD
VIDEO
BD
VIDEO
[DVD Video]
DVD
VIDEO
DVD
VIDEO
[DVD VR]
DVD
VR
DVD
VR
[AVCHD]
AVCHDAVCHD
[VIDE
VIDEOVIDEO
Closed Caption displays subtitles in synchronization with the video.
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select “CC Select”, then press [OK].
3. Use [
] to select your desired stream, then press [OK].
4. Press [OPTIONS] to exit.
NoteD
• Configure the closed caption display settings (font color, size, style, etc.) in the “Setup” A “Accessibility”.
Refer to page 46.
EN 43
9. NETWORK SERVICES
9.1. Before using network services
Please follow the instructions below before.
1. Connect this unit to the Internet.
• Refer to “Connection to the network” on page 19.
2. Configure necessary network connection settings.
• Refer to “Network connection” on page 48.
3. In the home menu, use [ ] to select your desired network service, then press [OK].
4. Press [Q (HOME)] to exit.
NoteD
• Pressing [Netflix] / [Vudu] / [YouTube] allows you to directly access the corresponding network service.
• Terms of Use will be displayed for the first-time use of network service. Confirm it, then press [OK].
9.2. Information on network services
For detailed information on the third-party Internet services, please visit each service provider's website:
Netflix : http://www.Netflix.com
VUDU™: http://www.vudu.com
YouTube™: ht tp://w ww.YouTube.com
9.3. Deactivate the network services
Netflix / VUDU™ / YouTube™ can be deactivated in Setup.
1. Press [Q (HOME)] to access the home menu.
2. Use [
] to select “Setup”, then press [OK].
3. Use [
] to select “Network”, then press [OK].
4. Use [
] to select “Deactivation”, then press [OK].
• The corresponding network service will be deactivated.
• When selecting a network service (Any one of “Netflix”, “Vudu”, “YouTube”) at the rightmost and pressing [OK],
a pop-up screen will be displayed.
• Select “OK”, then press [OK] and press [OK] again to clear your ID and password.
• Please be aware that deactivating the network service on this unit does not withdrawal from membership of
Netflix.
CautionC
• Some features may require an always-on broadband internet connection, firmware update and/or a minimum
bandwidth. Internet services vary by location.
Funai Corporation, Inc. do not warrant access to the portal or to any of the services, content, software and
advertising.
Funai Corporation, Inc. or third party content/service providers may, in their sole discretion, add
or remove access to
any specific services, content, software and advertising at any time.
Although Funai Corporation, Inc.
will strive to provide a good selection of services, content or software,
Funai Corporation, Inc.
do not warrant continued access to any specific services, and content or software.
EN 44
10. LIST OF SETTINGS
continued on next page
In “Setup”, you can customize various kinds of settings as you prefer.
Refer to the following instructions to navigate through the setup menu.
1. Press [ (HOME)] to access the home menu.
2. Use [
] to select “Setup”, then press [OK].
3. Use [
] to select the desired category, then press [OK].
4. Use [
] to move up and down the list to select menus / options.
5. To make a selection or to access options of an item, select the desired item, then press [OK].
• To go back to the previous screen, press [BACK].
6. Press [ (HOME)] to exit.
Refer to the following table for the types of settings you can customize.
Category Menus / Options
Video 3D output
Auto(**)
2D
TV display
4:3 Normal
4:3 Crop
16:9 Widescreen
16:9 Squeeze
HDMI video
Auto 1080i
480p 1080p
720p 4K
View HDMI video
24p output
Auto
Off
Color space
YCbCr(4:4:4)
YCbCr(4:2:2)
RGB
High Dynamic Range
output
Auto
SDR
Noise reduction
Off
Low
Medium
High
Audio Night mode
Auto
On
Off
HDMI audio
Bitstream
LPCM
Re-encode
Network Network installation
Start
Connection Test
View network settings
View Wireless settings
BD-Live access level
Allow
Limited Allow
Prohibit
Digital Rights Mgmt
Terms of Use
Netflix ESN
Unit Name
Wake-on-LAN
On
Off
Deactivation
Netflix
Vudu
YouTube
EN 45
Category Menus / Options
Preferences Menu language Auto(XXX)
English
Français
Español
Audio Bulgarian Italian
Chinese Japanese
Czech Korean
Danish Norwegian
Dutch Polish
English Portuguese
Finnish Romanian
French Russian
German Slovak
Greek Spanish
Hungarian Swedish
Icelandic Turk ish
Irish More
Subtitle Off Italian
Bulgarian Japanese
Chinese Korean
Czech Norwegian
Danish Polish
Dutch Portuguese
English Romanian
Finnish Russian
French Slovak
German Spanish
Greek Swedish
Hungarian Turkish
Icelandic More
Irish
Disc menu Bulgarian Italian
Chinese Japanese
Czech Korean
Danish Norwegian
Dutch Polish
English Portuguese
Finnish Romanian
French Russian
German Slovak
Greek Spanish
Hungarian Swedish
Icelandic Turk ish
Irish More
Parental controls Off 4 [PG-13]
8 [Adult] 3 [PG]
7 [NC-17] 2 [G]
6 [R] 1 [Kid Safe]
5 [PGR]
Change password
Screen saver On
Off
Angle icon On
Off
EasyLink On
Off
continued on next page
EN 46
Category Menus / Options
Preferences One Touch Play On
Off
One Touch Standby On
Off
Advanced Software update Disc
Network
USB
Automatically check for
latest software
On
Off
Quick Start mode On
Off
Version info
Restore default settings Reset AV settings
Erase unit BD-ROM data
Erase USB BD-ROM data
Reset network settings
Reset All settings
OSS
Accessibility Voice Guide On
Off
Voice Guide volume Loud
Medium
Soft
Voice Guide speed Fast
Normal
Slow
Voice Guide pitch High
Medium
Low
Voice Guide verbosity Detailed
Basic
CC style Auto
Custom
CC font color Default Blue
White Yellow
Black Magenta
Red Cyan
Green
CC font size Default
Standard
Small
Large
CC font style Default
Monospaced with serifs
Proportionally spaced with serifs
Monospaced without serifs
Proportionally spaced without serifs
Casual
Cursive
Small capitals
CC font opacity Solid
Translucent
Transparent
CC font outline Default Uniform
None Left drop shadowed
Raised Right drop shadowed
Depressed
continued on next page
EN 47
Category Menus / Options
Accessibility CC font outline color White Blue
Black Yellow
Red Magenta
Green Cyan
CC background color Default Blue
White Yellow
Black Magenta
Red Cyan
Green
CC background opacity Solid
Translucent
Transparent
CC window color Default Blue
White Yellow
Black Magenta
Red Cyan
Green
CC window opacity Solid
Translucent
Transparent
NoteD
• In order to enable the voice guide function, the OSD language needs to be set to English or Spanish. Voice guide
is not available in French.
• There may be grayed-out (unselectable) items while the unit is in resume-on-stop mode.
Unselectable items:
Video settings: TV display (when aspect ratio of the content cannot be changed)
Audio settings: All settings
Preference settings: Audio/Subtitle/Disc menu/Parental controls/Change password
Advanced settings: Restore default setting
Accessibility Settings: All settings
In order to configure these settings, exit resume-on-stop mode by pressing [
(STOP)] when the home menu
screen is displayhed.
EN 48
continued on next page
11. SETUPS
11.1. Network connection
Q (HOME) A “Setup” A “Network” A “Network installation”
Perform the network connection setup in order to use network features, such as BD-Live™, Netflix, VUDU™, YouTube™,
and the network update function.
C Connection test
After you enable a network connection or change network settings, always perform the connection test to check to
see if the connection is correctly made.
1. Press [Q (HOME)] and use [ ] to select “Setup” in the home menu, then press [OK].
2. Use [
] to select “Network”, then press [OK].
3. Use [
] to select “Network installation”, then press [OK].
4. Use [
] to select “Connection Test”, then press [OK].
• Connection test will automatically start. The test result will appear right after the test finishes.
5. After the test results display, press [OK].
NoteD
• If the connection test passes, you are ready to use BD-Live™, Netflix, VUDU™, YouTube™, and the Network update
function, using the Internet without making any additional settings.
• If the connection test fails, you may need to check your router settings and make sure the physical connection
is secure. If you need the MAC address of this unit to complete your router settings, you can view it in “View
network setting”.
• When connecting this unit directly to a modem for the first time or connecting it to a modem which was
previously connected to any other network device (e.g. a router, PC, etc.), you may have to power cycle the
modem (unplug the modem’s and/or router’s AC power cord from its AC outlet for 30 seconds and then plug
it back in), this may reset the settings in the modem. If you have a telephone/internet modem with your cable
service then you may have to use its reset button or remove the backup battery to reset this type of modem.
• If the connection test fails, this unit is not connected to the Internet. In this case, you cannot use the network
features, such as BD-Live™, Netflix, VUDU™, YouTube™, and the network update function. Please confirm router
settings or contact your ISP (Internet Service Provider) for troubleshooting assistance.
EN 49
continued on next page
C Network configuration (wired)
Auto setup
In order to make a wired connection, connect an ethernet cable from a router with Internet access. A network will
automatically be established.
• In order to confirm that this unit is connected to the Internet, perform “Connection test” (refer to page 48).
• In order to switch from wireless connection to wired, perform the following steps:
1. Connect an ethernet cable from a router with internet access.
2. Press [Q (HOME)] and use [
] to select “Setup” in the home menu, then press [OK].
3. Use [
] to select “Network”, then press [OK].
4. Use [
] to select “Network installation”, then press [OK].
5. Use [
] to select “Start”, then press [OK].
6. Use [
] to select “Wired”, then press [OK].
7. Use [
] to select “Auto setup”, then press [OK].
• Network setting will automatically be performed.
8. The following screen will be displayed. Select “Finish”, then press [OK] to complete the settings.
Finish
Home Network
Internet
Network connection successful.
: Pass
: Pass
1 7
EN 50
continued on next page
Manual setup
In the following cases, configure each setting as necessary.
– When connection test failed with auto setting.
– When instructed by your Internet service provider to make specific settings in accordance with your network
environment.
1. Press [Q (HOME)] and use [ ] to select “Setup” in the home menu, then press [OK].
2. Use [
] to select “Network”, then press [OK].
3. Use [
] to select “Network installation”, then press [OK].
4. Use [
] to select “Start”, then press [OK].
5. Use [
] to select “Wired”, then press [OK].
6. Use [
] to select “Manual setup”, then press [OK].
7. Use [
] to select the desired setting (IP Address / Subnet Mask / Default Gateway / Primary DNS /
Secondary DNS), then press [OK].
• The range of input numbers is between 0 and 255.
• Use [ ] to move between input fields. Use [ ] changes the number by 1. If you want to exit this
setting, press [BACK].
8. When all items are entered, use [ ] to select “Continue”, then press [OK].
9. Use [
] to select “Yes” or “No” for proxy server, then press [OK].
• If you use a proxy server, select “Yes” then press [OK] to go to the next step.
• If you do not use a proxy server, select “No” then press [OK] to go to step 13.
10. “Proxy Address” setting screen will appear. Enter a proxy address using the cursor buttons, the color
keys, and [OK].
11. Press [RED] to go to the “Proxy Port” setting screen.
• If you Use [ ] to select “Done” then press [OK] instead of [RED], you can go to the “Proxy Port”
setting screen.
12. Use [ ] to change the proxy port number, then press [OK].
13. Connection test confirmation screen will appear. Select “Yes”, then press [OK] to start the connection
test. The test result will appear right after the connection test finishes.
14. The following screen will be displayed. Select “Finish”, then press [OK] to complete the settings.
Finish
Home Network
Internet
Network connection successful.
: Pass
: Pass
1 7
NoteD
• Enter an IP address after checking the specifications of your router.
• If an IP address is unknown, check the IP address of other devices (e.g. PC connected with a LAN cable). Then, in
the fourth cell to the right, assign a different number from those other devices.
• Enter the DNS addresses provided by your Internet service provider.
• If the DNS address is unknown, check the DNS address of other devices (e.g. PC connected via LAN cable) and
assign the same DNS address.
• The range of input numbers for the port number is between 0 and 65535. (This number must be no greater than
65535.)
• For proxy port, certain ports might be closed, blocked or unusable depending on your network environment.
• When the settings are changed, the network connection may be disabled depending on the device.
EN 51
continued on next page
C Network configuration (wireless)
If you connect this unit to a wireless network, select “Wireless” and configure necessary settings.
Please make a note of your SSID (Service Set IDentifier – wireless network name) and its security key* before
proceeding with the setup.
* “Easy Connect” cannot be used when the security protocol is set to “WEP”.
Easy Connect
PBC (Push Button Configuration)
You can set up a wireless connection quickly.
(“PBC” is only available when your router supports it. For details, please refer to the user manual of your wireless
router.)
Please confirm your wireless router has a PBC* (Push Button Configuration) button.
1. Press [Q (HOME)] and use [ ] to select “Setup” in the home menu, then press [OK].
2. Use [
] to select “Network”, then press [OK].
3. Use [
] to select “Network installation”, then press [OK].
4. Use [
] to select “Start”, then press [OK].
5. Use [
] to select “Wireless”, then press [OK].
6. Use [
] to select “Easy Connect”, then press [OK].
7. Use [
] to select “Push Button Method”, then press [OK].
Then within 2 minutes push the PBC* (Push Button Configuration) button on your wireless router.
* PBC button may be called differently on your wireless router.
• The unit will automatically start the connection test. The test result will appear right after the test finishes.
8. The following screen will be displayed. Select “Finish”, then press [OK] to complete the settings.
Finish
Home Network
Internet
Network connection successful.
: Pass
: Pass
1 7
NoteD
“Easy Connect” cannot be used when the security mode of your access point is set to “WEP”.
Please try either method below:
• Connect the unit to the access point using “Auto setup” or “Manual setup” mode.
• Change the access point’s security mode from “WEP*” to AES + TKIP.
* “WEP” is not recommended to be used due to its “Major security flaws”. Change the security protocol on the
wireless router to AES + TKIP mode.
(For access point configuration, please consult the user manual of your wireless router or manufacturer.)
EN 52
Auto scan
1. Follow steps 1 to 5 in “Easy Connect” on page 51.
2. Use [
] to select “Auto Scan”, then press [OK].
• This unit will automatically start searching for nearby wireless networks.
3. The search result will be displayed. Use [ ] to select an appropriate SSID, then press [OK].
• If you select an SSID with “ ” in the security column, press [OK] and move on to step 4.
• If you select an SSID without “ ” (no security) in the security column, select “Continue” and press [OK], then
move on to step 6.
4. The security key (WEP / AES + TKIP Key) entry screen will appear. Enter the security password (WEP /
AES + TKIP Key) of the selected wireless network using cursor buttons, [OK], and color keys, then press
[RED] to confirm the password.
• If you do not know the security key (WEP / AES + TKIP Key) for your wireless network, please confirm the
sticker on the router.
• The security key (WEP / AES + TKIP Key) entries are case-sensitive.
• If you Use [ ] to select “Done” then press [OK] instead of [RED], you can confirm the password.
5. Use [ ] to select “Continue”, then press [OK].
6. Use [
] to select “Auto setup” or “Manual setup”, then press [OK].
• If you select “Auto setup”, follow step 7 in “Auto setup” on page 49.
• If you select “Manual setup”, follow steps 7 to 14 in “Manual setup” on page 50.
NoteD
• The internal wireless LAN supports following specifications:
– Wireless standards: IEEE 802.11 a/b/g/n/ac
– Frequency: 2.4 GHz + 5GHz
– Security protocol: WEP* / AES + TKIP
* “WEP” is not recommended to be used due to its “Major security flaws”. Change the security protocol on the
wireless router to AES + TKIP mode.
Manual entry
Set up the connection to the wireless router manually by entering the SSID.
In the following cases, select “Manual setup” to set each setting as necessary.
– When connection test failed with the setting of “Auto setup”.
1. Follow steps 1 to 5 in “Easy Connect” on page 51.
2. Use [
] to select “Manual Entry”, then press [OK].
3. SSID entry screen will appear. Enter the SSID using the cursor buttons, [OK], and the color keys, then
press [RED].
• If you use [ ] to select “Done” then press [OK] instead of [RED], you can confirm the password.
4. Security mode selection screen will appear. Use [ ] to select the desired security mode, then press
[OK].
• If you select “None”, please go to step 6.
5. The security key (WEP / AES + TKIP Key) entry screen will appear. Enter the security password (WEP /
AES + TKIP Key) of the selected wireless network using cursor buttons, [OK], and color keys, then press
[RED] to confirm the password.
• If you do not know the security key (WEP / AES + TKIP Key) for your wireless network, please confirm the
sticker on the router.
• The security key (WEP / AES + TKIP Key) entries are case-sensitive.
• If you use [ ] to select “Done” then press [OK] instead of [RED], you can confirm the password.
6. Use [ ] to select “Continue”, then press [OK].
7. Use [
] to select “Auto setup” or “Manual setup”, then press [OK].
• If you select “Auto setup”, follow step 7 in “Auto setup” on page 49.
• If you select “Manual setup”, follow steps 3 to 14 in “Manual setup” on page 50.
EN 53
continued on next page
11.2. EasyLink (HDMI CEC)
Q (HOME) A “Setup” A “Preferences” A “EasyLink”
EasyLink(HDMI CEC) allows integrated system control over HDMI and is part of the HDMI standard. This function
may not work properly depending on the device connected to the unit. When “EasyLink” setting is set to “On” the
functions listed below will be available.
C One touch play
When the buttons below are pressed then operations are performed on this unit, the TV will automatically be
turned on and switched to the appropriate video source Input.
Buttons for one touch play:
• [ (OPEN/CLOSE)], [ (PLAY/PAUSE)], [ (SKIP)], [ (SKIP)], [ (HOME)] (on the remote control)
• [TOP MENU], [POP MENU] (on the remote control when the a disc is inserted in the unit)
C One touch standby
This unit will automatically be turned off after the connected HDMI CEC compatible display device is turned off.
C System information
Get & set menu language
The unit recognizes the OSD language set on the TV and automatically sets the same language as the player menu
language (OSD menu language) for this unit. Go to “Menu language” under “Preferences” on page 45 to see
available languages.
• Feature is available only when “Auto” is selected in the setup menu “Menu language” section in “Setup” while
connected via an HDMI cable.
EN 54
11.3. HDMI video resolution
Q (HOME) A “Setup” A “Video” A “HDMI video”
Set the resolution of the video signal being output from the HDMI OUT jack.
You can select the desired video resolution among the settings listed below:
“Auto”,˝4 8 0 p ”,˝720p”,˝1080i”,˝1080p”, “4K”.
Actual output resolution:
Setting in
“HDMI video”
Source
720 x 480
(30i)
1280 x 720
(60p)
1920 x 1080
(30i)
1920 x 1080
(24p)
1920 x 1080
(60p)
3840 x 2160
(24p)
3840 x 2160
(60p)
Auto
The highest resolution supported by your display device will be in effect automatically.
480p
720x480
(60p)
720x480
(60p)
720x480
(60p)
720x480
(60p)
720x480
(60p)
720x480
(60p)
720x480
(60p)
720p
1280x720
(60p)
1280x720
(60p)
1280x720
(60p)
1280x720
(60p)
1280x720
(60p)
1280x720
(60p)
1280x720
(60p)
1080i
1920x1080
(60i)
1920x1080
(60i)
1920x1080
(60i)
1920x1080
(24p)
1920x1080
(60i)
1920x1080
(24p)
1920x1080
(60i)
1080p
1920x1080
(60p)
1920x1080
(60p)
1920x1080
(60p)
1920x1080
(24p)
1920x1080
(60p)
1920x1080
(24p)
1920x1080
(60p)
4K
3840x2160
(60p)
3840x2160
(60p)
3840x2160
(60p)
3840x2160
(24p)
3840x2160
(60p)
3840x2160
(24p)
3840x2160
(60p)
• The resolution listed in the above chart will be enabled on this unit when the “24p output” is set to “Auto”.
• For AVCHD, outputting the video in 24 frames per second (1080/24p) is not available.
NoteD
• The selected resolution must also be supported by your display device.
• Even if “HDMI video” is set to “4K”, the video of a non-4K compatible Blu-ray Disc™ will be output in the video
resolution that is specified by the disc and supported by the display device.
• If your TV and the unit are connected by a DVI cable and if “Auto” is selected, “4 80p” will be automatically in
effect.
• Refer also to your TV’s manual.
• When connected to an HDCP incompatible display device, the picture will not be displayed properly.
• The audio signals from the HDMI OUT jack (including the sampling frequency, the number of channels and bit
length) may be limited by the connected device.
• Among the display devices that support HDMI, some do not support audio output (for example, projectors).
While connected to a device such as a projector, audio will not be output from the HDMI OUT jack.
• When this unit’s HDMI OUT jack is connected to a DVI-D compatible display device(s) (HDCP compatible) with an
HDMI-DVI converter cable, the signals are output in digital RGB.
• HDMI video resolution does not work during BD-Video playback.
• When playing back a Frame Sequential 3D disc, video resolution of output picture will depend on contents on
the disc. (“HDMI video” setting is not applicable for Frame Sequential 3D discs.)
Copyright protection system
To play back the digital video images of a BD-video or DVD-video via an HDMI connection, it is necessary that
both the player and the display device (or an AV receiver / amplifier) support a copyright protection system
called HDCP (high-bandwidth digital content protection system). HDCP is copy protection technology that
comprises data encryption and authentication of the connected AV device. This unit supports HDCP. Please
read the operating instructions of your display device (or an AV receiver / amplifier) for more information.
Note that 4K content viewing requires an HDCP 2.2 compatible TV and cables.
EN 55
11.4. Parental controls
Some BD-videos or DVD-videos feature parental lock levels. Playback will stop if the ratings of the content exceed
the levels you set on the player, it will require you to enter a password before the disc will play back. This feature
prevents your children from viewing inappropriate material.
C Change password
Q (HOME) A “Setup” A “Preferences” A “Change password”
1. Press [Q (HOME)] and use [ ] to select “Setup” in the home menu, then press [OK].
2. Use [
] to select “Preferences”, then press [OK].
3. Use [
] to select “Change password”, then press [OK].
4. Enter your 4-digit password.
• The default value is “0000”.
• Use [ ] to enter the first digit of your Password, then press [ ].
• When 4-digit numbers are entered, press [OK].
5. Set a new password.
• Use [ ] to enter numbers, then use [ ] to move the input field. When 4-digit numbers are entered,
press [OK].
• Record your new password, in case you forget it.
6. Re-enter the same new 4-digit password in the same way as step 4.
7. Press [Q (HOME)] to exit.
To temporarily disable parental lock:
Some discs allow you to temporarily disable parental lock. When you try to play them back, the password entry
screen will be displayed.
Follow the instruction which appears on the TV screen to disable parental lock.
C Rating level
Q (HOME) A “Setup” A “Preferences” A “Parental controls”
1. Press [Q (HOME)] and use [ ] to select “Setup” in the home menu, then press [OK].
2. Use [
] to select “Preferences”, then press [OK].
3. Use [
] to select “Parental controls”, then press [OK].
4. Enter your 4-digit password.
• Use [ ] to enter the first digit of your password, then press [ ].
• When 4-digit numbers are entered, press [OK].
5. Use [ ] to select your desired level, then press [OK].
6. Press [
(HOME)] to exit.
RATING EXPLANATIONS
Off “Parental controls” is inactive; all discs can be played back.
8 [Adult] BD / DVD software of any grades (adult / general / children) can be played back.
7 [NC-17] Content unsuitable for ages 17 and under is blocked.
6 [R] Restricted; under 18.
5 [PGR] Parental guidance recommended.
4 [PG-13] Unsuitable for children under 13.
3 [PG] Parental guidance suggested.
2 [G] General audience.
1 [Kid Safe] Suitable for children.
NoteD
• When this unit is in resume-on-stop mode, the “Parental controls” setting item is grayed-out and is not configurable.
• In order to configure “Parental controls”, remove the disc to exit resume-on-stop mode or press [ (STOP)]
when the home menu screen is displayed.
EN 56
11.5. Software update
Q (HOME) A “Setup” A “Advanced” A “Software update”
This unit lets you update the software yourself using a software update disc or USB memory stick, or via the
Internet.
The available discs are below:
• BD-RE/-R
• DVD-RW/-R
• CD-RW/-R
C Disc / USB memory stick update
You can update the software by using a disc or USB memory stick.
Prepare a blank disc or USB memory stick for software update:
Navigate to www.philips.com/support, and download the latest version software to a blank disc or USB memory
stick using a PC by following the directions described on the website.
• Use a blank disc or USB memory stick, download one software per disc or USB memory stick. Write the software
in the root directory of the disc or USB memory stick.
• For more details on how to download the software, please refer to the website.
1. Insert the disc or connect the USB memory stick for software update.
• If a disc is inserted, the file list screen will appear. Press [Q (HOME)].
• After connecting a USB memory stick, wait 10-20 seconds, then move on to step 2.
2. Use [ ] to select “Setup” in the home menu, then press [OK].
3. Use [
] to select “Advanced”, then press [OK].
4. Use [
] to select “Software update”, then press [OK].
5. Use [
] to select “Disc” or “USB”, then press [OK].
• This unit now starts loading the update file, then Installs it. Update will take a while. Leave the unit until it
automatically restarts.
6. After Updating finishes, this unit will restart automatically. Remove the disc or USB memory stick from this unit.
CautionC
• Please do not unplug the AC power cord, eject the disc or disconnect the USB memory stick or press
[ (POWER)] to turn the unit to standby mode while performing a “Disc / USB Update”.
NoteD
• Software update will not change any of the current settings.
C Network update
You can update the software of this unit via the Internet if it is connected to the Internet.
1. Follow steps 2 to 4 in “Disc / USB memory stick update” on this page.
2. Press [Q (HOME)] and use [
] to select “Network”, then press [OK].
• The unit will connect to the server, then check for the latest software version.
3. Software version confirmation screen will appear. Press [OK].
• Downloading of the latest software will start. (Download may take some time.)
After completing the download, update will start.
4. After updating finishes, this unit will restart automatically.
CautionC
• Please Do Not Unplug the AC Power cord, ethernet cable, wireless modem / router, or press [ (POWER)] to turn
the unit to standby mode while using “Network Update”.
NoteD
• In order to update the software via the Internet, you must connect the unit to the Internet and Set up necessary
Settings.
• For the network connection, refer to “Connection to the network” on page 19.
• For the network setup, refer to “Network connection” on page 48.
• Software update will not change any of the current settings.
EN 57
11.6. Voice guide
Q (HOME) A “Setup” A “Accessibility”
Menus to configure various settings for the voice guide function.
1. Press [Q (HOME)] and use [ ] to select “Setup” in the home menu, then press [OK].
2. Use [
] to select “Accessibility”, then press [OK].
3. Use [
] to select the desired setting, then press [OK].
“Voice Guide”:
Turns on/off the voice guide function.
“Voice Guide volume”:
Configures the volume of the voice.
“Voice Guide speed”:
Configures the speech rate.
“Voice Guide pitch”:
Configures the voice pitch.
“Voice Guide verbosity”:
Configures whether to read detailed information on the current item/operation.
4. Use [ ] to select the desired setting, then press [OK].
5. Press [Q (HOME)] to exit.
NoteD
• In order to enable the voice guide function, the OSD language needs to be set to English or Spanish. Voice guide
is not available in French.
• When voice guide is set to on, the HDMI audio settings are fixed to LPCM.
When switching HDMI audio to Bitstream or Re-encode while voice guide is set to on, voice guide will
automatically be set to off.
• Voice Guide is not available with VUDU™ and YouTube™.
• While the Voice Guide function is enabled, operations may slow down.
• When this unit is in resume-on-stop mode, the “Voice Guide” setting item is grayed-out and is not configurable.
In order to configure “Voice Guide”, remove the disc to exit resume-on-stop mode or press [ (STOP)] when the
home menu screen is displayed.
EN 58
11.7. Restore default settings
Q (HOME) A “Setup” A “Advanced” A “Restore default settings”
Menus to reset player settings.
1. Press [Q (HOME)] and use [ ] to select “Setup” in the home menu, then press [OK].
2. Use [
] to select “Advanced”, then press [OK].
3. Use [
] to select “Restore default settings”, then press [OK].
4. Use [
] to select the desired setting, then press [OK].
“Reset AV settings”:
All the settings except for “Parental controls” and “Network installation” settings will be reset to default.
“Erase unit BD-ROM data”:
Clears the data saved for the BD-ROM contents, such as BD-ROM game scores, on this player.
“Erase USB BD-ROM data” (Only available when a USB memory stick is connected):
Clears supplemental data for BD-ROM playback, such as subtitle data, from the USB memory stick.
“Reset network settings”:
Resets the network installation settings menu to the default.
“Reset All settings”:
Resets this unit to its factory default settings.
5. Use [ ] to select “OK”, then press [OK].
6. Confirmation message will appear. Press [OK] to complete the setting.
CautionC
• Do not remove the USB memory stick while executing “Erase USB BD-ROM data”. It will damage the USB
memory stick.
NoteD
• “Restore default settings” cannot be performed while a BD-V / DVD-V / AVCHD / Audio CD disc is inserted in this
unit, and this unit is in resume-on-stop mode.
• Reset AV settings does not clear the password, the parental settings, or the network installation settings.
• Reset AV settings clears the BD-Live access level and the unit name settings. Also, each net app will be
deactivated.
• Reset network settings only clears the network installation settings (connection settings).
EN 59
12. TROUBLESHOOTING
Problem Tip
No power. Check the AC power cord, if it is properly connected.
Try another power outlet.
Unplug the AC power cord, and wait for about 5-10 seconds. Plug it back in
and attempt to power on the unit.
No sound or picture. Make sure both the TV and Blu-ray Disc™ player are turned on.
Confirm the connections to the TV are made properly as shown in the
“CONNECTIONS” on page 14.
Check to see whether the connected TV or another device supports HDCP.
(This unit will not output a video signal unless the other device supports
HD CP.)
No reaction to the remote control. Reduce the distance to infrared sensor window.
Confirm that the player’s AC power cord is plugged into a power outlet.
Check the batteries in the remote control and make sure they are inserted
properly by + or - symbols.
Please check IR signal. Refer to “IR signal check” on page 65.
4K or 4K HDR signal does not output. Confirm that the unit is connected to a 4K or 4K HDR-compatible TV.
Confirm that the HDMI cable from the unit is connected to an HDR-compatible
HDMI port on the TV.
Confirm that the 4K or 4K HDR settings on the TV are enabled.
Confirm the “HDMI video” settings on this unit:
– 4K output is not possible when “HDMI video” on this unit is set to “480p”,
“720p”, “1080i”, or “1080p”.
– 4K HDR output is not possible when “HDMI video” on this unit is set to other
than “Auto” or “4K”, or when “High Dynamic Range output” is set to “SDR”.
Refer to the table on page 17 for details.
If the unit is connected via a cable box, set-top box, etc., that device might
be blocking the 4K or 4K HDR signal. Connect the unit directly to a 4K or 4K
HDR-compatible TV.
No Audio / video signal on the
display device via HDMI cable.
If the unit is connected to a non-certified HDMI device, the audio / video
signal will not output to that device.
Make sure the display device is on the correct input / video source.
Perform an HDMI hotplug: Disconnecting the HDMI cable from the display
device, turn on both devices, and replug the HDMI cable back in.
Check with the TV manufacturer, if there are any software updates available
for the TV.
Check to see if the HDMI cable is a certified version.
No high-definition video signal on
the TV screen.
Does the disc contain high-definition video? High-definition video is only
available when the disc contains it.
Does the TV support high-definition video? High-definition video is only
available when the TV supports it.
Distorted picture. Sometimes a small amount of picture distortion may appear. This is not a
malfunction.
Completely distorted picture or
black / white picture with Blu-ray
Disc™ / DVD.
Make sure the disc is compatible with this unit.
No sound or distorted sound. Adjust the volume.
Check to see if the speakers are connected correctly.
Check the HDMI connection.
Make sure the HDMI cable is not plugged into an HDMI-DVI adapter or
projector which does not handle digital sound.
Check the settings in the “Audio” menu.
Cannot mute Voice Guide
Configure the Voice Guide display settings in the “Setup” A “Accessibility” A
“Voice Guide” A “Off”. Refer to “Voice guide” on page 57
Picture freezes momentarily during
disc playback.
Check the disc for fingerprints / scratches and clean with a soft cloth wiping
from the center to the outer edge.
continued on next page
EN 60
Problem Tip
Cannot play back a disc. Make sure that the disc is playable on this unit.
Check the region code of the disc. This unit supports the following region
codes.
– Blu-ray Disc™: “A˝
– DVD: “ALL” or “1˝
For DVD-RW/-R, make sure that the disc is finalized.
Please use clean soft cloth and wipe the disc from inside rim to the outside
rim with straight stroke.
Is the disc a newer title? This problem may be solved by software update.
Refer to “Software update” on page 56.
A music/photo file does not play. Confirm that the file type is supported.
Refer to page 20 for the compatible file extentions.
The file may be corrupted.
Check to see if it is playable on a PC or other devices.
No return to start-up screen when
disc is removed.
Soft reset this unit by turning it off for 30 seconds, then on again.
will appear on the TV screen. The operation is not possible.
The unit does not respond to
some operating commands during
playback.
The operations may be prohibited by the disc. Refer to the instructions for
the disc.
The unit cannot read Blu-ray Disc™ /
DVD / CD.
Condensation? (Let the unit sit and dry for 1 or 2 hours)
Check to see if the disc is compatible with this unit. (Refer to page 23.)
Wipe dirt off the disc from the center to the outside or replace the disc.
Refer to “Cleaning discs” on page 65.
Scene shooting Angle does not
switch.
Angles cannot be switched for Blu-ray Disc™ / DVD which do not contain
multiple angles. In some cases multiple angles are only recorded for
specific scenes.
Playback does not start when a title
is selected.
Check the settings in “Parental controls” menu.
Error message appears when I select
“Auto” in the “Menu language”.
Make sure that the unit is connected to a TV that is compatible with HDMI
CEC and the “EasyLink” is set to “On”.
This error message may appear when your TV's OSD language is not
supported by this unit.
Cannot play back AVCHD file. This unit cannot play back stand-alone AVCHD files (*.m2ts, *.mts or *.m2t)
written to a DVD. The DVD containing AVCHD files must have a proper file
and folder structure meeting AVCHD format specifications. Please use
AVCHD compliant device / software to burn or copy AVCHD files to DVD.
(Please refer to user manuals of the device / software for more information.)
The capacity of the USB memory
stick decreased.
Data may be written on the USB memory stick when a BD-video uses the
virtual package feature while a USB memory stick is connected to the unit.
Cannot play back a MPEG-2 video
and audio from the USB memory
stick.
MPEG-2 is not compatible with this unit.
Cannot read the contents on the
USB memory stick.
The USB memory stick is not compatible with this unit or the contents may
be damaged.
Try and turn off the unit, then turn it back on.
Cannot play back BD-Video. Connect a USB memory stick (256MB or more of available memory) which
is formatted on this unit. Some discs require memory when playing back
content.
Do not disconnect the USB memory stick during playback.
Cannot load a Blu-ray Disc™ (stuck
in “Loading…” mode) and cannot
Open the disc tray to eject the disc.
Unplug unit from AC outlet for 20 seconds. Plug unit back in and press the
[
(OPEN/CLOSE)] on the unit to eject the disc.
Cannot read a USB memory stick. The format of the USB memory stick is not compatible with this unit. If the
USB memory stick has been formatted on a PC or another device, the file
system may be incompatible with this unit. This unit supports the FAT16 /
FAT32 file systems.
continued on next page
EN 61
continued on next page
Problem Tip
Cannot play back photo files from
a disc.
Make sure that the disc was recorded in the UDF, ISO9660 or JOLIET
format.
Cannot find a photo file. Make sure that the file extension is .jpg (.JPG) / .jpeg (.JPEG) / .png (.PNG) or
.gif (.GIF) .
Cannot play back music files from
a disc.
Make sure that the disc was recorded in the UDF, ISO9660 or JOLIET
format.
Confirm that the bitrate and sampling frequency are compatible with this
unit. (Refer to page 24)
Cannot find a music file. Make sure that the file extension is either MP3 / FLAC / AAC / WAV /Vorbis /
AIFF / Monkey's Audio for music files.
Music files play choppy. CDs / DVDs containing FLAC (.flac) / WAV (.wav) files with high frequency
and large quantization bit rates may not play properly. In such cases, copy
the music files to a Blu-ray Disc™ or USB memory stick, then try playing.
How do I switch to view a currently
airing TV program?
Stop playback and press the source button on your TV or TV’s remote to
switch to a TV channel.
How do I have my Bluetooth-
compatible speakers output the
audio?
The unit does not support Bluetooth.
No audio signal from surround
system of the audio system.
Make sure the audio system is turned on.
Check the Input mode on the audio system if it is on the correct channel.
Check if the surround system is compatible with either Bitstream or
LPCM. If not sure, please check the user manual or contact the surround
manufacturer. Once confirmed, check the setting in the “Setup” of this unit.
Increase the volume level of the surround system.
Cannot connect to the Internet
although the connection test
passes.
Make sure that the ethernet cable is properly connected to the modem and
router.
Confirm that another device, such as a PC, can connect to the Internet.
Cannot connect to the network. Check to see if the modem and router have power turned on.
Make sure that the ethernet cable is properly connected to the modem and
router.
Confirm if the Internet light is showing activity (light blinking) on the modem
and router.
Check network settings on the unit.
Turn off this unit and the modem and router (if it has a power button), then
unplug their AC cords. After 30 seconds, plug them back in and turn the
devices back on. If you have a telephone / internet modem with your cable
service, then you may have to use its reset button or remove the Backup
battery to reset this type of modem. Now wait for the lights to show activity
and try reconnecting.
Check the cable connection to the router when connecting with an ethernet
cable.
Confirm “View network settings” in the setup.
Turn on the DHCP function on the router.
Confirm that the LAN cable is connected properly.
Cannot use “Easy Connect” to
connect to the access point.
If the access point's security mode is set to “WEP”, change the setting to
“AES + TKIP”, then try “Easy Connect” again. Refer to “
Note
D
” on page
51. (For access point configuration, please consult its user manual or
manufacturer.)
Connect the unit to the access point using “Auto setup” or “Manual setup”
mode.
Cannot use the wireless connection. Once you have activated the wireless connection please wait 30 seconds for
the connection to be established after turning on the unit, before trying to
access network features such as BD-Live™ and third-party network services.
Cannot connect to the network
while my PC is connected to the
network.
Check the content of your Internet service contract to see if your Internet
Service Provider prevents multiple terminals connecting at the same time.
EN 62
Problem Tip
You are not sure if the unit is
connected to the Internet.
Perform the connection test. (refer to page 48)
Cannot use the BD-Live™ function
or Internet data does not download
properly.
Confirm that this unit is successfully connected to the Internet.
Confirm the BD-Live access level setting in the setup.
Connect a USB memory stick before inserting a disc. The USB memory stick
must have 1GB or more free space.
Confirm that the USB memory stick is properly connected to this unit.
Make sure that the USB memory stick connected to this unit is not write-
protected.
Cannot add network services. On this unit, the network services of Netflix, VUDU™, and YouTube™ are only
available.
Cannot use Netflix service. Check to see if the network connection is properly made.
Visit www.Netflix.com on your PC and become a Netflix member.
The picture quality of Netflix
streaming movie is poor.
Check your Internet connection speed.
Contact your Internet Service Provider. (You may need to improve the
broadband speed.)
Netflix streaming movie often stops
or starts buffering during playback.
Contact your Internet Service Provider. (You may need to improve the
broadband speed.)
Cannot use the VUDU™ service. VUDU™ is only available in the United States.
Check to see if the network connection is properly made.
Cannot rent or buy movies / TV
shows on VUDU™.
You need to activate the VUDU™ account.
Log into your account at http://my.vudu.com and check your payment
information.
The picture quality of VUDU™ movie
is poor.
Check your Internet connection speed. You need speeds of at least 9 Mbps
to this player for high quality uninterrupted playback.
VUDU™ movie often stops or starts
buffering during playback.
Check your internet speed. The following are the required connection
speeds for picture quality for uninterrupted streaming.
SD quality (1 Mbps - 2 Mbps), HD quality (2.25 Mbps - 4.5 Mbps),
HDX quality (4.5 Mbps - 9 Mbps).
Can not use the YouTube™ service. Check to see if the network connection is properly made.
No sound with YouTube™. If this unit is connected to an AAC-compliant device, the sound may not be
output. In such cases, configure as follows:
“Setup” A “Audio” A “HDMI audio” A “LPCM”.
The picture quality of the YouTube™
video is poor.
You may experience frequent buffering, distorted pictures or no picture at
all depending on your network environment and internet traffic.
The picture and sound quality differ depending on the Internet Service
Provider.
NoteD
• Do not attempt to repair the Blu-ray Disc™ player yourself. This may cause severe injury, irreparable damage to
your Blu-ray Disc™ player and void your warranty.
• Please have your Blu-ray Disc™ player model and serial number available before contacting us. These numbers
are available on the cabinet, as well as on the packaging.
EN 63
13. SPECIFICATIONS
General
Signal system NTSC Color
Power requirements 120 V AC, 60 Hz
Power consumption 18 W (standby: 0.4 W)
Dimensions (width x height x depth) 17.0 x 1.9 x 8.2 inches
Weight 1.7 kg. (3.75 lbs)
Operating temperature 41°F (5°C) to 95°F (35°C)
Operating humidity Less than 80 % (no condensation)
Terminals
USB input
TYPE A
HDMI OUT port
HDMI jack Video: 480p, 720p, 1080i, 1080p, 4K/Audio
LAN terminal 10BASE-T / 100BASE-TX
Wireless LAN (Internal) IEEE 802.11 a/b/g/n/ac
NoteD
• The specifications and design of this product are subject to change without notice.
EN 64
14. NETWORK SERVICE DISCLAIMER
Content and services made available through this product are transmitted by third parties by means of networks
and transmission facilities over which Company has no control and third party services may be terminated or
interrupted at any time, and Company makes no representation or warranty that any content or service will remain
available for any period of time. Without limiting the generality of this disclaimer, Company expressly disclaims
any responsibility for any interruption or suspension of any content or service made available through this product.
Company is not responsible for customer service related to the content and services. Any question or request for
service relating to the content or services should be made directly to the respective content and service providers.
THIRD PARTY CONTENT AND SERVICES MADE AVAILABLE THROUGH THIS PRODUCT ARE PROVIDED “AS IS.”
COMPANY DOES NOT WARRANT CONTENT OR SERVICES SO PROVIDED, FOR ANY PURPOSE WHATSOEVER.
COMPANY EXPRESSLY DISCLAIMS ANY WARRANTIES, EXPRESS OR IMPLIED INCLUDING WITHOUT LIMITATION,
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ACCURACY, VALIDITY,
TIMELINESS, LEGALITY, SUITABILITY, OR QUALITY OF ANY CONTENT OR SERVICE MADE AVAILABLE THROUGH
THIS PRODUCT.
IN NO EVENT SHALL COMPANY BE LIABLE FOR, ANY DAMAGES, WHETHER ARISING IN CONTRACT OR TORT,
INCLUDING WITHOUT LIMITATION, ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES,
LOST PROFITS, ATTORNEY FEES, EXPENSES, OR ANY OTHER DAMAGES ARISING OUT OF, OR IN CONNECTION
WITH, ANY CONTENT (OR ANY INFORMATION CONTAINED THEREIN) OR SERVICE PROVIDED TO THE USER OR
ANY THIRD PARTY, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
All content and services accessible through this product belong to third parties and are protected by copyright,
patent, trademark and/or other intellectual property rights. Such content and services are provided solely for
the User’s personal noncommercial use. User may not use any content or services in a manner that has not been
authorized by the content owner or service provider. Without limiting the foregoing, unless expressly authorized
by the applicable content owner or service provider, you may not modify, copy, republish, upload, post, transmit,
translate, sell, create derivative works, exploit, or distribute in any manner or medium any content or services made
available through this product.
Funai Corporation, Inc. do not warrant access to the portal or to any of the services, content, software and
advertising.
Funai Corporation, Inc. or third party content/service providers may, in their sole discretion, add
or remove access to
any specific services, content, software and advertising at any time.
Although Funai Corporation, Inc.
will strive to provide a good selection of services, content or software,
Funai Corporation, Inc.
do not warrant continued access to any specific services, and content or software.
EN 65
15. MAINTENANCE
C Servicing
• Please refer to relevant topics in “TROUBLESHOOTING” on page 59 before returning the product.
• If this unit becomes inoperative, do not try to correct the problem by yourself. There are no user-serviceable
parts inside. Eject the disc (if possible), disconnect the USB memory stick (if connected to the unit),
place the unit into standby mode, unplug the AC power plug, and please contact: 1-866-202-5960 or visit :
www.philips.com/support
C Cleaning the cabinet
• Wipe the front panel and other exterior surfaces of the unit with a soft cloth.
• Never use a solvent, thinner, benzene or alcohol to clean the unit. Do not spray insecticide liquid near the unit.
Such chemicals may discolor the surface or damage the unit.
C Cleaning discs
• When a disc becomes dirty, clean it with a cleaning cloth. Wipe the disc from the center to outside. Do not wipe
in a circular motion.
• Do not use solvents such as benzine, thinner, commercially available cleaners, detergent, abrasive cleaning
agents or antistatic spray intended for analog records.
C Cleaning the disc lens
• If this unit still does not perform properly although you referred to relevant sections and “TROUBLESHOOTING”
in this user manual, the laser optical pickup unit may be dirty. Consult your dealer or an authorized service
center for inspection and cleaning of the laser optical pickup unit.
C Disc handling
• Handle the discs so that fingerprints and dust do not adhere to the surfaces of the discs.
• Always store the disc in its protective case when it is not used.
• Note that discs with special shapes (heart-shaped discs, octagonal discs, etc.) cannot be played back on this
unit. Do not attempt to play such discs, as they may damage the unit.
C IR signal check
If the remote control does not work properly, you can test IR signal using a digital camera (including a cellphone
with a built-in camera) to see if the remote control sends out the infrared signal.
1. Turn on the digital camera.
2. Direct a digital camera to the remote control, then press and hold any button on the
remote control.
• If infrared light appears on the digital camera display, the remote control is working.
NoteD
• Some cameras have an IR filter and will not display the IR signal.
EN 66
continued on next page
16. TRADEMARK INFORMATION
˝Blu-ray Disc™”, “Blu-ray™”, and “Blu-ray Disc™” logo are
trademarks of the Blu-ray Disc Association.
“Ultra HD Blu-ray™” and “Ultra HD Blu-ray™” logo are
trademarks of the Blu-ray Disc Association.
˝BD-Live™” and “BD-Live™” logo are trademarks of the
Blu-ray Disc Association.
˝BONUSVIEW™” and “BONUSVIEW™” logo are
trademarks of the Blu-ray Disc Association.
AUDIO
™
Manufactured under license from Dolby Laboratories.
Dolby, Dolby Audio, and the double-D symbol are
trademarks of Dolby Laboratories.
Java and all Java based trademarks and logos are
trademarks or registered trademarks of Oracle and/or
its affiliates.
For DTS patents, see http://patents.dts.com.
Manufactured under license from DTS Licensing
Limited.
DTS, the Symbol, & DTS and the Symbol together are
registered trademarks, and DTS 2.0+Digital Out is a
trademark of DTS, Inc. © DTS, Inc. All Rights Reserved.
The terms HDMI and HDMI High-Definition Multimedia
Interface, and the HDMI Logo are trademarks or
registered trademarks of HDMI Licensing LLC in the
United States and other countries.
˝x.v.Color” and “x.v.Color” logo are trademarks of Sony
Corporation.
is a trademark of DVD Format/Logo Licensing
Corporation.
“AVCHD 3D/Progressive” and the “AVCHD 3D/Progressive”
logo are trademarks of Panasonic Corporation and Sony
Corporation.
Netflix is available in certain countries. Streaming
membership required. More information at
www.netflix.com.
VUDU™ is a trademark of VUDU, Inc.
YouTube™ and the YouTube™ logo are trademarks of
Google LLC.
EN 67
THIS PRODUCT IS LICENSED UNDER THE AVC PATENT
PORTFOLIO LICENSE FOR THE PERSONAL AND NON-
COMMERCIAL USE OF A CONSUMER TO (i) ENCODE
VIDEO IN COMPLIANCE WITH THE AVC STANDARD
(˝AVC VIDEO˝) AND/OR (ii) DECODE AVC VIDEO
THAT WAS ENCODED BY A CONSUMER ENGAGED
IN A PERSONAL AND NON-COMMERCIAL ACTIVITY
AND/OR WAS OBTAINED FROM A VIDEO PROVIDER
LICENSED TO PROVIDE AVC VIDEO. NO LICENSE IS
GRANTED OR SHALL BE IMPLIED FOR ANY OTHER
USE. ADDITIONAL INFORMATION MAY BE OBTAINED
FROM MPEG LA, L. L. C. SEE
HTTP://WWW.MPEGLA.COM
THIS PRODUCT IS LICENSED UNDER THE VC-1
PATENT PORTFOLIO LICENSE FOR THE PERSONAL
AND NON-COMMERCIAL USE OF A CONSUMER TO
(i) ENCODE VIDEO IN COMPLIANCE WITH THE VC-1
STANDARD (˝VC-1 VIDEO˝) AND/OR (ii) DECODE
VC-1 VIDEO THAT WAS ENCODED BY A CONSUMER
ENGAGED IN A PERSONAL AND NON-COMMERCIAL
ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO
PROVIDER LICENSED TO PROVIDE VC-1 VIDEO. NO
LICENSE IS GRANTED OR SHALL BE IMPLIED FOR
ANY OTHER USE. ADDITIONAL INFORMATION MAY
BE OBTAINED FROM MPEG LA, L.L.C. SEE
HTTP://WWW.MPEGLA.COM
EN 68
17. GLOSSARY
AACS
Advanced Access Content System (AACS) is the content
protection scheme used with Blu-ray™ discs.
Analog audio
An electrical signal that directly represents sound.
Compare this to digital audio which can be an electrical
signal, but is an indirect representation of sound. See
also “Digital audio”.
Aspect ratio
The width of a TV screen relative to its height.
Conventional TVs are 4:3 (in other words, the TV screen
is almost square); widescreen models are 16:9 (the TV
screen is almost twice as wide as its height).
AVCHD
AVCHD is a new format for high definition video
camcorders which can record and play high-resolution
HD images.
Blu-ray Disc™
Blu-ray Disc™ is a next generation optical video disc
which is capable of storing much more data than a
conventional DVD. The large capacity makes it possible
to benefit from the features such as high-definition
videos, multi-channel surround sounds, interactive
menus and so on.
Chapter
Just as a book is split up into several chapters, a title
on a BD-video or DVD-video is usually divided into
chapters. See also “Title”.
Cinavia™
Cinavia Notice
This product uses Cinavia technology to limit the
use of unauthorized copies of some commercially-
produced film and videos and their soundtracks. When
a prohibited use of an unauthorized copy is detected, a
message will be displayed and playback or copying will
be interrupted.
More information about Cinavia technology is provided
at the Cinavia Online Consumer Information Center at
http://www.cinavia.com
To request additional information about Cinavia by mail,
send a postcard with your mailing address to: Cinavia
Consumer Information Center, P.O. Box 86851, San
Diego, CA, 92138, USA.
This product incorporates proprietary technology under
license from Verance Corporation and is protected by
U.S. Patent 7,369,677 and other U.S. and worldwide
patents issued and pending as well as copyright and
trade secret protection for certain aspects of such
technology.
Cinavia is a trademark of Verance Corporation.
Copyright 2004-2019 Verance Corporation. All
rights reserved by Verance. Reverse engineering or
disassembly is prohibited.
Digital audio
An indirect representation of sound by numbers. During
recording, the sound is measured at discrete intervals
(44,100 times a second for CD audio) by an analog-
to-digital converter, generating a stream of numbers.
On playback, a digital-to-analog converter generates
an analog signal based on these numbers. See also
“Sampling frequency” and “Analog audio”.
Dolby Digital
The system to compress digital sound developed by
Dolby Laboratories. It offers you sound of stereo (2ch)
or multi-channel audio.
Dolby Digital Plus
Dolby Digital Plus is the next generation digital audio
compression technology developed as an extension to
Dolby Digital. Blu-ray Disc™ supports 7.1 multi-channel
surround sound output.
Dolby TrueHD
Dolby TrueHD is a lossless coding technology
developed for next generation optical discs. Blu-
ray Disc™ supports 7.1 multi-channel surround sound
output.
DTS
®
(Digital Theater System)
DTS
®
is a multi channel surround sound system. You
can enjoy movie dynamic and realistic sound like
movie theater. DTS surround sound technologies were
developed by DTS, Inc.
DTS-HD
®
DTS-HD
®
is a lossless coding technology developed as
an extension of the original DTS Coherent Acoustics
format. Blu-ray Disc™ supports 7.1 multi-channel
surround sound output.
HDMI (High-Definition Multimedia Interface)
A digital interface between an audio and video Source.
It can transmit component video, audio, and control
signal with one cable connection.
HDR (High Dynamic Range)
HDR is a display technology which enables TV’s to
display contrast in a wider dynamic range compared
to the existing SDR (standard dynamic range). This
technology improves and optimizes the ratio between
the minimum and maximum brightness in order to
display pictures close to views in nature.
For the best HDR view, your TV needs to be compatible
with HDR signals.
Connecting a TV with higher brightness and contrast
capability is recommended for dynamic, beautiful
pictures.
JPEG (Joint Photographic Experts Group)
JPEG is a method of compressing still picture files. You
can copy JPEG files on BD-RE/-R, DVD-RW/-R, CD-
RW/-R, or USB memory stick from a computer and play
back the files on this unit.
continued on next page
EN 69
Local storage
A storage area of sub contents for playing virtual
packages on BD-video.
PCM (Pulse Code Modulation)
The most common system of encoding digital audio,
found on CD and DAT. Excellent quality, but requires a
lot of data compared to formats such as Dolby Digital
and MPEG audio. For compatibility with digital audio
recorders (CD, MD and DAT) and AV amplifiers with
digital Inputs, this unit can convert Dolby Digital, DTS,
and MPEG audio to PCM. See also “Digital audio”.
Region code
Regions associate discs and players with particular
areas of the world. This unit will only play back discs
that have compatible region codes. You can find the
region code of your unit by looking on the rear panel.
Some discs are compatible with more than one region
(or all regions).
Sampling frequency
The rate which sound is measured by a specified
interval to turn into digital audio data. The numbers of
sampling in one second defines as sampling frequency.
The higher the rate, the better the sound quality.
Title
A collection of chapters on BD-video or DVD-video.
See also “Chapter”.
Track
Audio CD uses Tracks to divide up the content of a
disc. The BD-video or DVD-video equivalent is called a
chapter.
See also “Chapter”.
Ultra HD Blu-ray™
4K/HDR playback requires devices and HDMI cables
that meet the following standards:
Device: HDCP2.2, 4K/60p/4:4:4, HDR signal for
Ultra HD Blu-ray™ standards
HDMI c able: 18Gbps high-speed cables (HDMI 2.0)
If your devices or their HDMI ports to be used do not
meet these standards (e.g. only compatible with up
to 4K/60p/4:2:2 or incompatible with HDR and/or
HDCP2.2), the video output will be dynamic range-
converted to 2K resolution.
x.v.Color
˝x.v.Color” is a promotion name given to the products
that have the capability to realize a wide color space
based on the xvYCC specifications and is a trademark of
Sony Corporation.
EN 70
18. IMPORTANT HEALTH AND SAFETY INFORMATION FOR 3D
TELEVISIONS
Read the following information before viewing 3D television images.
CAUTION NOTICE:
1. Ambient fluorescent lighting may cause a flickering effect and direct sunlight may adversely affect the
operation of your 3D glasses.
2. DO NOT place your television near open stairwells, balconies or other objects as viewing in 3D images
may cause disorientation for some viewers resulting in falls, tripping or walking into objects.
3. If you experience (1) altered vision; (2) lightheadedness; (3) dizziness; (4) involuntary movements such as
eye or muscle twitching; (5) confusion; (6) nausea; (7) loss of awareness; (8) convulsions; (9) cramps; and/
or (10) disorientation, immediately stop watching 3D images and consult your doctor.
4. Parents should regularly monitor their children concerning the above symptoms as children and
teenagers may be more likely to experience these symptoms more frequently than adults. Watching
3D television is not recommended for children under the age of 6 as their visual system is not yet fully
developed.
5. Prolonged viewing of 3D images might cause discomfort, dizziness, eye strain, headaches or
disorientation.
WARNING NOTICE:
1. Some viewers may experience an epileptic seizure or stroke when exposed to certain flashing images or
lights contained in certain television pictures or video games. If you or any of your family has a history of
epilepsy or stroke, please consult your doctor before viewing 3D images.
2. DO NOT watch 3D television if you are pregnant, elderly, sleep-deprived, suffering from serious medical
conditions, in poor physical condition or under the influence of alcohol.
3. Sitting too close to the screen for an extended period of time may damage your eyesight. The ideal
distance should be at least three times the height of the TV screen and at the viewer’s eyes level.
4. Wearing the 3D glasses for any reason other than viewing 3D television (as general spectacles,
sunglasses, protective goggles, etc.) may physically harm you or weaken your eyesight.
5. If you experience any discomfort while viewing 3D images, stop and do not immediately engage in
any potentially hazardous activity such as driving a car until your symptoms have disappeared. If your
symptoms persist, do not resume watching 3D images without consulting your doctor.
19. LIMITED WARRANTY
back cover
This warranty gives you specific legal rights. You may have other rights which vary from state/province to state/province.
Funai Service Corporation
2425 Spiegel Drive, Groveport, OH 43125, USA
License
Funai Corporation, Inc. hereby offers to deliver, upon request, a copy of the complete corresponding source code for the copyrighted
open source code packages, on an “AS IS” basis, used in this product for which such offer is requested by the respective licenses.
This offer is valid up to three years after the product purchase to anyone in receipt of this information. To obtain source code, please
contact Funai Corporation, Inc. You should write to Funai Service Corporation OSS Request, 2425 Spiegel Drive, Groveport, OH
43125, USA. Funai Corporation, Inc. disclaims any and all warranties and representations with respect to such software and related
source code including quality, reliability, usability, and accuracy, and further disclaim all express, implied, statutory or otherwise,
including without limitation, any implied warranties of title, non-infringement, merchantability, or fitness for a particular purpose.
Funai Corporation, Inc. shall not be liable to make any corrections to the open source software or source code or to provide any
support or assistance with respect to it. Funai Corporation, Inc. disclaims any and all liability arising out of or in connection with the
use of this software and/or source code.
WARRANTY COVERAGE:
This warranty obligation is limited to the terms as set forth
below.
WHO IS COVERED:
This product warranty is issued to the original purchaser or
the person receiving the product as a gift against defects in
materials and workmanship as based on the date of original
purchase (“Warranty Period”) from an Authorized Dealer.
The original sales receipt showing the product name and the
purchase date from an authorized retailer is considered such
proof.
WHAT IS COVERED:
This warranty covers new products if a defect in material or
workmanship occurs and a valid claim is received within the
Warranty Period. At its option, the company will either (1) repair
the product at no charge, using new or refurbished replacement
parts, or (2) exchange the product with a product that is new or
which has been manufactured from new, or serviceable used
parts and is at least functionally equivalent or most comparable to
the original product in current inventory, or (3) refund the original
purchase price of the product.
Replacement products or parts provided under this warranty are
covered against defects in materials and workmanship from the
date of the replacement or repair for ninety (90) days or for the
remaining portion of the original product’s warranty, whichever
provides longer coverage for you. When a product or part is
exchanged, any replacement item becomes your property and
the replaced item becomes company property. When a refund is
given, your product becomes company property.
Note: Any product sold and identified as refurbished or
renewed carries a ninety (90) day limited warranty.
Replacement product can only be sent if all warranty
requirements are met. Failure to follow all requirements can
result in delay.
WHAT IS NOT COVERED - EXCLUSIONS AND LIMITATIONS:
This Limited Warranty applies only to new company
manufactured products that can be identified by the trademark,
trade name, or logo affixed to it. This Limited Warranty does
not apply to any hardware product or any software, even if
packaged or sold with the product, as manufacturers, suppliers,
or publishers may provide a separate warranty for their own
products packaged with the bundled product.
The company is not liable for any damage to or loss of any
programs,
data, or other information stored on any media contained
within the product, or other additional product or part
not covered by this warranty. Recovery or reinstallation of
programs,
data or other information is not covered under this Limited
Warranty.
This warranty does not apply (a) to damage caused by
accident, abuse, misuse, neglect, misapplication, or non-
supplied product, (b) to damage caused by service performed
by anyone other than company approved Authorized Service
Location, (c) to a product or a part that has been modified
without written company permission, or (d) if any serial number
has been removed or defaced, or (e) product, accessories or
consumables sold “AS IS” without warranty of any kind by
including refurbished product sold “AS IS” by some retailers.
This Limited Warranty does not cover:
•Shippingchargestoreturndefectiveproduct.
•Laborchargesforinstallationor setupoftheproduct,
adjustment of customer controls on the product, and
installation or repair of antenna/signal source systems
outside of the product.
•Productrepairand/orpartreplacementbecauseofimproper
installation or maintenance, connections to improper voltage
supply, power line surge, lightning damage, retained images
or screen markings resulting from viewing fixed stationary
content for extended periods, product cosmetic appearance
items due to normal wear and tear, unauthorized repair or
other cause not within the control of the company.
•Damageorclaimsforproductsnotbeingavailableforuse,or
for lost data or lost software.
•Damagefrommishandled shipments ortransitaccidents
when returning product.
•Aproductthatrequiresmodification oradaptationtoenable
it to operate in any country other than the country for which it
was designed, manufactured, approved and/or authorized, or
repair of products damaged by these modifications.
•Aproductusedfor commercialorinstitutionalpurposes
(including but not limited to rental purposes).
•Productlostinshipmentandnosignatureverificationreceipt
can be provided.
•FailuretooperateperOwner’sManual.
TO OBTAIN ASSISTANCE...
Contact Customer Care Center at:
1-866-202-5960
REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS
WARRANTY IS THE EXCLUSIVE REMEDY FOR THE CONSUMER,
WITH THE ISSUING COMPANY NOT LIABLE FOR ANY
INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF
ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT.
EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW,
ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE
ON THIS PRODUCT IS LIMITED IN DURATION TO THE
DURATION OF THIS WARRANTY.
Some states do not allow the exclusions or limitation of
incidental or consequential damages, or allow limitations on
how long an implied warranty lasts, so the above limitations or
exclusions may not apply to you.
LIMITED WARRANTY ONE
(
1
)
YEAR
Funai Corporation, Inc.
21061 S. Western Ave. Suite 210,
Torrance, CA 90501, USA
This product has been manufactured by and is sold
under the responsibility of Funai Corporation, Inc., and
Funai Corporation, Inc. is the warrantor in relation to
this product.
The Philips trademark and the Philips Shield Emblem
are registered trademarks of Koninklijke Philips N.V.
used under license.
EGH20UL
