Register your product and get support at
www.philips.com/welcome
EN User manual
If you read this user manual for BDP1305 and
your player's serial number starts with:
• DS - Please start to read from next page.
• 9C - Please start to read from page 49.
BDP1305
Blu-ray Disc™ /
DVD Player
EN For further assistance, call the customer
support service in your country.
• To obtain assistance, contact Philips customer
care center;
In the U.S.A., Canada, Puerto Rico, or the U.S.
Virgin Islands; 1- 866-515-1124
2
CONTENTS
INTRODUCTION ................................................. 3
Safety instruction ........................................................... 3
Included accessories .................................................... 6
FEATURES ........................................................... 7
Features .............................................................................7
Version info ......................................................................8
Symbols used in this owner’s manual ......................8
FUNCTIONAL OVERVIEW ................................9
Front panel ...................................................................... 9
Rear panel ....................................................................... 9
Remote control ..............................................................10
Guide to on-screen display ....................................... 12
CONNECTIONS ..................................................13
Connection to a TV ...................................................... 13
Connection to an audio system ............................... 13
HDMI Audio Output ..................................................... 14
BEFORE YOU START ........................................15
Finding a viewing video source input on your TV ... 15
Initial setup ..................................................................... 15
INFORMATION ON PLAYBACK ..................... 16
Information on playback ............................................ 16
Guide to file list .............................................................19
How to insert a disc .....................................................19
BASIC PLAYBACK ............................................20
Playing back a disc ..................................................... 20
Playing back contents from a USB memory stick .. 21
Using the title / disc / pop menu ............................ 22
SPECIAL PLAYBACK ........................................ 23
Fast forward / fast reverse ....................................... 23
Slow forward playback .............................................. 23
Step by step playback ............................................... 23
Repeat playback .......................................................... 24
Slide show ...................................................................... 24
PiP (BONUSVIEW™) setting ..................................... 25
Title / chapter search ................................................. 26
Track / file search ........................................................ 26
Time search ....................................................................27
Number select search .................................................27
Switching subtitles ...................................................... 28
Switching audio soundtrack ..................................... 29
Switching camera angles ..........................................30
Noise reduction ............................................................30
CLEAR+ ........................................................................... 30
LIST OF SETTINGS ............................................ 31
SETUPS .............................................................. 33
EasyLink (HDMI CEC) ................................................. 33
HDMI video resolution ............................................... 34
Parental control ........................................................... 35
Software update .......................................................... 36
Restore default settings .............................................37
TROUBLESHOOTING ......................................38
LANGUAGE CODE LIST .................................... 41
SPECIFICATIONS .............................................. 42
MAINTENANCE ................................................43
TRADEMARK INFORMATION........................44
GLOSSARY .........................................................45
LIMITED WARRANTY ...................................... 47
EN 3
For fastest support visit us online at www.philips.com/support
for chat and self service solutions.
The lightning ash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sucient
magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
Know these
safety symbols
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:
TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK). NO
USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
* Additional Benets
Registering your product guarantees that you’ll
receive all of the privileges to which you’re
entitled, including special money-saving oers.
* Product Safety Notication
By registering your product, you’ll receive
notication - directly from the manufacturer - in
the rare case of a product recall or safety defect.
Registering your model with Philips makes you eligible for all of the valuable benets
listed below, so don’t miss out. Register online at www.philips.com/welcome to ensure:
Register online at www.philips.com/welcome
today to get the most benets from your purchase.
The symbol for CLASS ll (Double Insulation)
WARNING
:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS
TO RAIN OR MOISTURE. APPARATUS SHALL NOT BE EXPOSED TO DRIPPING OR SPLASHING AND NO
OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES, SHALL BE PLACED ON THE APPARATUS.
CAUTION: To prevent electric shock, match wide blade of plug to wide slot, fully insert.
ATTENTION:
P our éviter les chocs électriques, introduire la lame la plus large de la che dans la borne
correspondante de la prise et pousser jusqu’au fond.
The important note and rating are located on the rear or bottom of the cabinet.
For Customer Use
Model No. ___________________________________________________________
Serial No. ___________________________________________________________
Please write the model and serial number of your
unit (located on the cabinet) in the space below for
future reference.
1. INTRODUCTION
1.1. Safety instruction
EN 4
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
11. Only use attachments / accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use caution when moving the cart / apparatus combination to
avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has
been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate
normally, or has been dropped.
FCC WARNING
This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may
cause harmful interference unless the modifications are expressly approved in the manual. The user could lose
the authority to operate this equipment if an unauthorized change or modification is made.
RADIO-TV INTERFERENCE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the device and the receiver.
3. Connect the device into an outlet on a circuit different from that to which the receiver is connected.
4. Consult the dealer or an experienced radio / TV technician for help.
Disconnect the mains plug (the AC plug) to shut the unit off when trouble is found or when not in use. The mains
plug (the AC plug) shall remain readily available. To completely turn off the unit, you must unplug the mains (AC)
power cord.
CAN ICES-3 (B)/NMB-3(B)
CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent
type.
WARNING: Batteries (Battery pack or battery installed) shall not be exposed to excessive heat such as sunshine,
fire or the like.
LASER SAFETY
This apparatus is classified as a CLASS 1 LASER PRODUCT.
This apparatus employs a laser. Only a qualified service person should remove the cover or
attempt to service this apparatus, due to possible eye injury.
CAUTION: Use of controls or adjustments or performance of procedures other than those specified herein may
result in hazardous radiation exposure.
EN 5
IMPORTANT COPYRIGHT INFORMATION
Unauthorized copying, broadcasting, public performance and lending of discs are prohibited. This item
incorporates copy protection technology that is protected by U.S. patents and other intellectual property rights
of Rovi Corporation. Reverse engineering and disassembly are prohibited.
Never use a gas duster on this unit.
The gas trapped inside of this unit may cause ignition and explosion.
Do not place the unit on furniture that is capable of being tilted by a child and an adult leaning, pulling, standing
or climbing on it. A falling unit can cause serious injury or even death.
In order to avoid interruption of ventilation, this unit should not be placed in built-in equipment such as a book
cabinet, rack, etc., and the vents of this unit should not be covered with anything such as a tablecloth, curtain,
newspaper, etc. Make sure to leave a space of 5.9 inches (15cm) or more around this apparatus.
When installing this unit in a temperate environment, avoid a place with rapid temperature changes.
This unit should not be used in a tropical environment as it has not been evaluated under such conditions.
No objects should be placed directly on or under this unit, especially lighted candles or other flaming objects.
To avoid the hazards of electrical shock and fire
Do not handle the power cord with wet hands.
Do not pull on the power cord when disconnecting it from an AC outlet. Grasp it by the plug.
Do not put your fingers or objects into the unit.
Location and handling
Do not install the unit in direct sunlight, near strong magnetic fields or in a place subject to dust or strong vibration.
Avoid a place with drastic temperature changes.
Install the unit in a horizontal and stable position. Do not place anything directly on top or bottom of the unit.
Depending on your external devices, noise or disturbance of picture and/or sound may be generated if the unit is
placed too close to them. In this case, please ensure enough space between external devices and the unit.
Depending on the environment, the temperature of this unit may increase slightly. This is not a malfunction.
Be sure to remove the disc and unplug the AC power cord from the outlet before carrying the unit.
Dew condensation warning
Dew condensation may form inside the unit in the following conditions. If so, do not use this unit at least for a few
hours until its inside gets dry.
– The unit is moved from a cold place to a warm place.
– Under conditions of high humidity.
– After heating a cold room.
Notice for progressive scan use
Consumers should note that not all high definition television sets are fully compatible with this product and may
cause artifacts to be displayed in the picture. In case of picture problems with 525 (480) progressive scan output,
it is recommended that the user switch the connection to the ‘standard definition’ output. If there are questions
regarding your TV set compatibility with this 525p (480p) DVD player, please contact our customer service center.
EN 6
Notice
Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips N.V. or their
respective owners. P&F USA reserves the right to change products at any time without being obliged to adjust
earlier supplies accordingly. The material in this manual is believed adequate for the intended use of the system.
If the product, or its individual modules or procedures, are used for purposes other than those specified herein,
confirmation of their validity and suitability must be obtained. P&F USA warrants that the material itself does not
infringe any United States patents. No further warranty is expressed or implied. P&F USA cannot be held responsible
for any errors in the content of this document, or for any problems as a result of the content in this document. Errors
reported to P&F USA will be adapted and published on the P&F USA support website as soon as possible.
Warranty
No components are user serviceable. Do not open or remove covers to the inside of the product. Repairs may only
be done by service centers and official repair shops. Failure to do so shall void any warranty, stated or implied. Any
adjustments or assembly procedures not recommended or authorized in this manual, or any operation expressly
prohibited in this manual shall void the warranty.
Important
Registering your model with Philips makes you eligible for all of the valuable benefits listed below, so don’t miss out.
Register online at www.philips.com/support to ensure:
Product safety notification
By registering your product you receive notification - directly from the manufacturer - in the rare case of a product
recall or safety defect.
Additional benefits of product ownership
Registering your product guarantees that you receive all of the privileges to which you’re entitled, including special
money-saving offers.
For further assistance
For further assistance, call the customer support service in your country.
To obtain assistance in the U.S.A., Canada, Puerto Rico, or the U.S. Virgin Islands, contact Philips customer care
center at 1- 866-515-1124
Environmental care
The packaging of this product is intended to be recycled. Contact your local authorities for information
about how to recycle the packaging. For product recycling information, please visit
- www.recycle.philips.com
Disposal of used batteries
The batteries included do not contain the heavy metals mercury and cadmium, however in certain localities,
disposing batteries with household waste is not permitted. Please ensure you dispose of batteries according to local
regulations.
1.2. Included accessories
• Quick Start Guide
• Remote control (NC270MH)
• Batteries (AAA, 1.5V x 2)
EN 7
2. FEATURES
2.1. Features
Blu-ray Disc™
You can enjoy Blu-ray Disc™ which is capable of storing
five times more data than a conventional DVD.
BD-Java
With some Blu-ray™ discs which contain Java
applications, you can enjoy interactive functions such
as games or interactive menus.
DVD upscaling for enhanced picture quality
Your current DVD will look even better than before
thanks to video upscaling. Upscaling will increase the
resolution of standard definition DVD to high definition
up to 1080p over an HDMI connection. The picture
will be less jagged and more realistic for a near high
definition experience.
Enjoy your content on different kinds of media
Full backwards compatibility with DVD, CD and USB
memory stick ensures that you can continue to enjoy
your current audio-video collection. Additionally, you
can enjoy AVCHD (for DVD-RW/-R only) / JPEG files.
Listen to rich multi-channel surround sound
Multi-channel surround sound, which realizes real-to-
life sound and makes you feel that you are really there.
Easy and simple connection to your HDTV via HDMI
Connect this unit to your HDTV with one single HDMI
(High-Definition Multimedia Interface) cable. It is
recommended to use a high speed HDMI cable for
better compatibility. The high definition video output
signal will be transferred to your HDTV without
conversion to analog signals, so you will get excellent
picture and sound quality, completely free from noise.
HDMI CEC (Consumer Electronics Control)
This unit supports HDMI CEC, which allows integrated
system control over an HDMI cable and is part of the
HDMI standard. This function may not work properly on
some devices.
PiP (BONUSVIEW™)
Some BD-videos have the PiP function which enables
you to display the secondary video in the primary
video. You can call up the secondary video by pressing
[OPTIONS] whenever the scene contains a secondary
video.
Pop menu
Some BD-videos have a pop menu which is a navigation
menu that can be called up and be operated on the TV
screen without interrupting playback. You can call up
the pop menu by pressing [DISC MENU]. Contents in
the pop menu vary depending on the disc.
HDMI deep color
Deep color reduces posterization (color banding) effect
of the playback image.
HDMI 1080p/24 output (Blu-ray Disc™ only)
This unit is equipped with the feature which can provide
smooth movement during playback of film originated
material with a frame rate of 24 frames per second with
progressive. (Available only when the display device is
connected with an HDMI cable.) Refer to ˝HDMI video
resolution˝ on page 34.
Playing back contents from a USB memory stick
You can play back JPEG files stored on a USB memory
stick. BD-ROM discs sometimes store picture-in-
picture commentary, subtitles or other extras on a USB
memory stick for use during playback with the BD-
video.
Playing back AVCHD files
This unit supports playback of AVCHD format files (new
format for high definition video camcorders) recorded
on a disc / SD memory card using USB card reader /
USB hub (not included). Your high definition personal
archive is playable in HD quality.
x.v.Color
This unit supports playback of video contents on
discs recorded with ˝x.v.Color˝ technology. To watch
this video content with the ˝x.v.Color˝ space, a TV or
other display device supporting both video image
reproduction using ˝x.v.Color˝ standard and capability
of manual switching of its color space setting is
required. Please refer to the user manual of your
display device for further information.
EN 8
2.2. Version info
˝Version info˝ screen provides information about this unit’s software version.
You can also download the latest software from the Philips website and update it yourself if it is newer than the
version currently on your unit. The current version of software on your unit can be seen on the ˝Version info˝ screen.
To access ˝Version Info˝, follow the procedure below.
1. Press [Q(HOME)].
2. Use [
] to select ˝Setup˝, then press [OK].
3. Use [
] to select ˝Advanced Setup˝, then press [OK].
4. Use [
] to select ˝Version info˝, then press [OK].
2.3. Symbols used in this owner’s manual
To specify which media type each function is applicable to, a combination of the symbols shown below will be
depicted next to that function's explanation.
Symbol Description
[BD Video]
Description refers to BD-video
[DVD Video]
Description refers to DVD-video
[CD]
Description refers to audio CD / DTS-CD
[AVCHD]
Description refers to DVD-RW/-R with AVCHD files
[JPEG]
Description refers to BD-RE/-R, DVD-RW/-R, CD-RW/-R and USB memory stick with JPEG files
If you do not find any of the symbols listed above under the function heading, the operation is applicable to all
media types.
EN 9
3. FUNCTIONAL OVERVIEW
3.1. Front panel
1 3 4*2 5 6
* The unit can also be turned on by pressing this button.
1. Disc tray
2. Power-On indicator
3. Infrared sensor window
4.
(OPEN/CLOSE) button*
5.
(STANDBY/ON) button
6. USB input
CautionC
• Do not connect any device other than USB memory stick or USB card reader into the USB input. (e.g. PC,
external HDD, digital camera, keyboard, mouse, etc.)
• When connecting a USB memory stick, connect it directly to the USB input. Do not use a USB extension cable.
NoteD
• Due to new ENERGY STAR
®
requirements, this unit will automatically turn on the screen saver after 5 minutes of
inactivity and enter standby mode after 25 minutes of inactivity.
3.2. Rear panel
1 2
1. AC power cord 2. HDMI OUT jack
CautionC
• Do not touch the inner pins of the jacks on the rear panel. Electrostatic discharge may cause permanent
damage to the unit.
• This unit does not have a TV RF modulator.
EN 10
3.3. Remote control
1
11
13
3
4
10
12
14
5
6
*7
15
16*
8
9
2
* The unit can also be turned on by pressing these
buttons.
1.
(STANDBY/ON) button
• Press to turn on the unit, or to switch the unit into
standby mode. (To completely turn Off the unit,
you must unplug the AC power cord.)
2.
(HOME) button
• Press to display the home menu.
3. DISC MENU button
• During playback (Blu-ray Disc™ or DVD), press to
select the menu (Top menu or pop menu/menu).
4.
buttons
• Press to select items or settings.
5. INFO button
• Press to Display the on-screen display menu.
6.
(REVERSE) button
• During playback, press to fast reverse the
playback.
7.
(PLAY/PAUSE) button*
• Press to start playback or resume playback.
• Press to pause playback.
8.
(SKIP) button
• During playback, press once to return to the
beginning of the current title, chapter, track or file.
• During playback, press twice to return to the
previous title, chapter, track or file.
• During JPEG playback, press to return to the
previous file.
9.
(STOP) button
• Press to stop playback.
10. RED / GREEN / YELLOW / BLUE buttons
• Press to activate shortcut keys on some BD-video
functions. When a file list is shown, press to
switch between pages.
11. OPTIONS button
• During playback, press to display the play menu.
12. OK button
• Press to confirm or select menu items.
13. BACK button
• Press to return to the previously displayed menu
or screen function.
14.
(FORWARD) button
• During playback, press to fast forward the
playback.
• When playback is in pause, press to slow forward
the playback.
15.
(SKIP) button
• During playback, press to skip to the next chapter,
track or file.
• When playback is in pause mode, press to forward
the playback picture by picture.
16.
(OPEN/CLOSE) button*
• Press to open or close the disc tray.
continued on next page
EN 11
NoteD
• Use the included remote control. Remote-control
operation on any other remote control, such as a
universal remote control, is not guaranteed.
C Installing the batteries in the remote control
Install 2 AAA (1.5V) batteries matching the polarity
indicated inside battery compartment of the remote
control.
1 2 3
CautionC
Incorrect use of batteries can result in hazards such
as leakage and bursting. Please follow the guidelines
below:
• Lithium or ni-cad and ni-mh rechargeable batteries
are not recommended to use for remote control.
• Do not mix different types of batteries such as
alkaline and standard (carbon-zinc).
• Do not mix new and old batteries together.
• Do not use different kinds of batteries together.
Although they may look similar, different batteries
may have different voltages.
• Make sure that the + and - ends of each battery
match the indications in the battery compartment.
• Remove batteries from battery compartment, when
the remote is not going to be used for a month or
more.
• When disposing of used batteries, please comply
with governmental regulations or environmental
public rules that apply in your country or area.
• Do not recharge, short-circuit, heat, burn or
disassemble batteries.
C Using the remote control
Remote control usage guidelines:
• Make sure that there are no obstacles between the
remote control and the infrared sensor window on
the unit.
• Remote operation may become unreliable if strong
sunlight or fluorescent light is shining on the infrared
sensor window of the unit.
• Remote controls of different devices can interfere
with each other. Avoid using a remote control from
another device which is located close to the unit.
• Replace the batteries when you notice a fall-off in
the operating range of the remote control.
• The maximum operable ranges from the unit are as
follows.
- Line of sight:
approx. 23 feet (7 m)
- Either side of the center:
approx. 16 feet (5 m) within 30°
- Above:
approx. 16 feet (5 m) within 15°
- Below:
approx. 10 feet (3 m) within 30°
30˚ 30˚
16 feet (5 m) 23 feet (7 m) 16 feet (5 m)
EN 12
3.4. Guide to on-screen display
C Home menu
When you turn on the unit, the home menu will appear automatically. Otherwise, press [ (HOME)].
Play Disc
Browse USB Setup
1
2
3
1. ˝Play Disc˝: Initiates playback of inserted disc, displays a list of tracks / files or the media filter menu
2. ˝Browse USB˝: Displays a list of tracks / files on the connected USB memory stick or the media filter menu
3. ˝Setup˝: To access the setup menu
C Setup Menu
Video Setup
Audio Setup
EasyLink Setup
Preference Setup
Advanced Setup
TV Display
HDMI Video
HDMI Deep Color
De-interlacing Mode
•
16:9 Widescreen
•
Auto
•
Auto
•
Auto
Video Setup
1
2
1. Category
2. Menus / Options: Displays options for the highlighted item on the left whenever available
C Play Menu
During playback, press [OPTIONS] to display the play menu.
e.g.) Blu-ray Disc™
Search
Audio
Subtitle
Repeat
Noise Reduction
CLEAR+
Search
EN 13
4. CONNECTIONS
4.1. Connection to a TV
C HDMI connection (Supports up to 1080i(
*
1), 1080p(
*
2), 1080p/24(
*
3) resolution.)
HDMI IN
Your TV
HDMI cable
(not included)
(*1) 1080i: Outputs video data with a frame rate of 30 frames per second.
(*2) 1080p: Outputs video data with a frame rate of 60 frames per second.
(*3) 1080p/24: Outputs video data with a frame rate of 24 frames per second.
• Do not tilt the connector when inserting it into the HDMI jack, and make sure the shapes of the jack and the
connector are matched.
• When connected to an HDCP incompatible display device, the picture will not be displayed properly.
• Use an HDMI cable with the HDMI logo (a certified HDMI cable) for this connection. High speed HDMI cable
(also known as HDMI category 2 cable) is recommended for better compatibility.
NoteD
• If the TV receives no audio / video signal after properly connecting the unit and the TV with an HDMI cable, it
may be the TV. Please refer to the TV’s user’s manual.
• If the TV receives no audio signal after properly connecting the unit and the TV with an HDMI cable, make sure
the TV input is not an HDMI-DVI Input terminal.
4.2. Connection to an audio system
• When you change the connections, all devices should be turned off.
• When connecting the unit to an external audio system, refer to the user manual for setup / configuration help.
C HDMI audio connection
HDMI IN
HDMI OUT
HDMI IN
AV receiver / amplier with
an HDMI input jack
HDMI cable
(not included)
HDMI cable
(not included)
Your TV
EN 14
4.3. HDMI Audio Output
˝HDMI Audio˝
setting A
˝Bitstream˝ ˝LPCM˝
˝Blu-ray Disc
Audio˝
setting A
˝Mix Audio
Output˝
˝Primary Audio
Only˝
˝Mix Audio Output˝
˝Primary Audio
Only˝
Media
È
Audio Source
È
Which audio format can be output depends on compatibility of the connected
device.
BD-video
Dolby Digital Dolby Digital or Multi LPCM Multi LPCM
Dolby Digital Plus
Dolby Digital
or
Multi LPCM
*
2
Dolby Digital Plus
or
Dolby Digital
or
Multi LPCM
*
1
Multi LPCM
*
2
Multi LPCM
*
1
Dolby TrueHD
Dolby Digital
or
Multi LPCM
*
4
Dolby TrueHD
or
Dolby Digital
or
Multi LPCM
*
3
Multi LPCM
*
4
Multi LPCM
*
3
DTS
®
DTS
®
or Downmix 2ch PCM Downmix 2ch PCM
DTS-HD
®
DTS
®
or
Downmix 2ch PCM
*
5
DTS-HD
®
or
DTS
®
or
Downmix 2ch PCM
*
5
Downmix 2ch PCM
*
5
LPCM Multi LPCM
DVD-video
Dolby Digital Dolby Digital or Multi LPCM Multi LPCM
DTS
®
DTS
®
or Downmix 2ch PCM Downmix 2ch PCM
MPEG MPEG or Multi LPCM Multi LPCM
LPCM Multi LPCM
Audio CD LPCM 2ch LPCM
DTS-CD DTS
®
DTS
®
or Downmix 2ch PCM Downmix 2ch PCM
AVCHD
Dolby Digital Dolby Digital or Multi LPCM Multi LPCM
LPCM Multi LPCM
*1) Fully decoded.
*2) Only the independent substream is decoded.
*3) Dolby TrueHD stream is decoded.
*4) Only the Dolby Digital substream is decoded.
*5) Only the core substream is decoded.
NoteD
• If the connected device is not compatible with HDMI BITSTREAM, audio will be output as multi LPCM or
2-channel down-mixed LPCM depending on the capability of the connected device even if you select
˝Bitstream˝ in ˝HDMI audio˝ setting.
• When playing back a BD-video which only contains primary audio, the audio output will be ˝Primary audio
only˝ even if the ˝Blu-ray Disc Audio˝ is set to ˝Mix Audio Output˝.
• HD Audio will not be output when ˝Blu-ray Disc Audio˝ is set to ˝Mix Audio Output˝ and the button sound
feature in the content is enabled. (Button sound setting may be found in Pop menu.)
EN 15
5. BEFORE YOU START
5.1. Finding a viewing video source input on your TV
After you have completed all of the connections to your TV, review the steps below.
1. Press [ (STANDBY/ON)] to turn on the unit.
2. Turn on your TV.
3. Please locate the source / input / AUX / video button on TV’s remote control. The button may vary
based on TV brand and model. Once you have located the button, press until you see welcome screen of
this unit.
Thank you for your purchase of this Philips Blu-ray Player. Please follow instructions to
make correct settings. Once complete, you can always go back to the menu and modify if
necessary.
Siguiente
Cancel
Next
This is the correct viewing of the video source input.
• If the TV is connected by an HDMI cable, it may take a few moments for the initial screen to appear.
• If a certain amount of time has passed since you turned on the unit, welcome screen only appears the first
time you turn on the unit.
5.2. Initial setup
Please follow the instructions below to complete the initial setup.
1. While welcome screen is displayed, use [ ] to select ˝Next˝, then press [OK].
2. Language setup screen will appear. Use [
] to select your language, then press [OK].
Please select your language for
on-screen display.
English
Espanol
Français
C How to reset the OSD language
You can reset the OSD language if you selected the wrong language.
1. Press [ (HOME)] to display the home menu.
2. Use [
] to select ˝ ˝, then press [OK].
• This item is ˝Setup˝ (English) / ˝Instalación˝ (Spanish) / ˝Installation˝ (French).
• From here on, please select one of the following items you can find on screen:
3. Use [ ] to select ˝Preference Setup˝ (English) / ˝Configuración de Preferencias˝ (Spanish) /
˝Configuration des préférences˝ (French), then press [OK].
4. Use [
] to select ˝Menu Language˝ (English) / ˝Menú Idioma˝ (Spanish) / ˝Langage du menu˝
(French), then press [OK].
5. Use [
] to select your desired language, then press [OK].
6. If the items that were set are displayed in your desired language, then press [
(HOME)] to exit.
EN 16
6. INFORMATION ON PLAYBACK
6.1. Information on playback
C Playable discs and files
Playable discs Logos
Blu-ray Disc™
- BD-video
- BD-RE* (ver. 2.1)
(Recorded in BDMV format)
- BD-R* (ver. 1.1 / 1.2 / 1.3)
(Recorded in BDMV format)
(Unfinalized disc may not be played back.)
DVD-video
DVD-RW
(finalized video mode discs only)
DVD-R
(finalized video mode discs only)
CD-DA (audio CD)
CD-RW
CD-R
DTS-CD -
(*) Due to the intentional progression of the Blu-ray Disc™ format by its standard setting authority, the company
cannot guarantee or warrant the playability of future extensions of the Blu-ray Disc™ format with this product.
Playable files Media
AVCHD
DVD-RW/-R
SD memory card using USB card reader / USB hub (not included)
JPEG
BD-RE/-R
DVD-RW/-R
CD-RW/-R
USB memory stick
Readable device Playable files / data
USB memory stick JPEG, picture-in-picture commentary, subtitles or other extras for some BD-ROM.
NoteD
• This unit may not be able to play back discs recorded on PC’s or other recorders.
continued on next page
EN 17
C Recommended specifications
AVCHD
This unit cannot play back stand-alone AVCHD files (*.m2ts, *.mts or *.m2t) written to a DVD or copied to an SD
memory card. The DVD or SD memory card containing AVCHD files must have a proper file and folder structure
meeting AVCHD format specifications. Please use AVCHD compliant device / software to burn or copy AVCHD files
to DVD or SD memory card. (Please refer to user manuals of your device / software for more information.)
JPEG
Resolution
• Upper limit: 4,096 x 4,096 dots (sub sampling is 4:4:4)
5,120 x 5,120 dots (sub sampling is up to 4:2:2 or 4:2:0)
• Lower limit: 32 x 32 dots
• Maximum file size of a picture: 12MB
C Folder / file number limitations
Blu-ray Disc™, DVD and USB memory stick
• 999 folders (groups) and 9,999 files
CD
• 255 folders (groups) and 999 tracks / files
Caution / note for USB memory stick
CautionC
• Do not try to open or modify the USB memory stick.
• Do not touch the terminal surface with your fingers or any metals.
NoteD
• This unit supports USB memory stick with FAT16 / FAT32 file system.
• This unit does not support NTFS file system.
• This unit may not read USB memory sticks formatted on a computer. If that is the case, please reformat the USB
memory sticks on this unit and try again. Please note that all files stored on the USB memory stick will be erased
upon format.
• Please keep the USB memory sticks in their cases when you are not using them.
• Some USB memory sticks may not work with this unit.
• This unit can read SD memory cards using a USB card reader (not included).
– Readable cards: SD memory card (8 MB - 2 GB)
miniSD memory card (16 MB - 2 GB)
microSD memory card (256 MB - 2 GB)
SDHC memory card (4 GB - 32 GB)
miniSDHC memory card (4 GB - 8 GB)
microSDHC memory card (4 GB - 16 GB)
– Readable files: AVCHD / JPEG
• Depending on a USB card reader or USB hub, connected card or device may not be recognized.
continued on next page
EN 18
C Unplayable media and files
The following discs will not be played back on this unit.
• CD-ROM • CD-I (compact disc-interactive)
• DVD-RAM • VSD (video single disc)
• DVD-audio • video CD
• HD DVD • SVCD
• SDXC memory card • microSDXC memory card
• unfinalized disc • BD-RE (ver. 1.0)
• BD-RE (ver. 2.1) (Recorded in BDAV format) • BD-R (ver. 1.1 / 1.2 / 1.3) (Recorded in BDAV format)
• B D X L™
• Blu-ray Disc™ / DVD / CD / USB memory stick / SD memory card containing DivX
®
files
• Blu-ray Disc™ / USB memory stick that contains AVCHD files
• Blu-ray Disc™ / DVD hybrid disc (played back as a BD-video only)
• DVD-RW/-R recorded in non compatible recording format
• Super audio CD - only the sound on the CD layer can be heard. The sound on the high-density super audio CD
layer cannot be heard.
• Playability of dual discs is not guaranteed.
• This unit cannot play back the disc contents protected by Windows Media™ Digital Rights Management (DRM).
C Region codes
This unit has been designed to play back BD-video with region ˝A˝ and DVD-video with
region ˝1˝ or ˝ALL˝. You cannot play back BD-video or DVD-video that is labeled for other
regions.
Look for the symbols on your BD-video or DVD-video. If these region symbols do not
appear on your BD-video or DVD-video, you cannot play back the disc on this unit. The
letter or number inside the globe refers to region of the world. BD-video or DVD-video discs
labeled for a specific region can only be played back on players with the same region code.
BD-video
DVD-video
C Hint for disc playback
The contents of a disc are generally divided into sections or folders (group of titles / files) as shown below.
BD-video, DVD-video, AVCHD
Audio CD
Track 1 Track 2 Track 3 Track 4 Track 5
Title 1
Chapter 1 Chapter 2 Chapter 1 Chapter 2 Chapter 3
Title 2
JPEG
File 1 File 2 File 3 File 4 File 5
folder (group) 1 folder (group) 2
continued on next page
EN 19
C Description for icons
[ ] : group (folder) icon
[
] : music file icon
[
] : photo file icon
- ˝Folders˝ refers to the group of files.
- ˝Track˝ refers to the contents recorded on the audio CD.
- ˝Files˝ refers to the contents on a disc which are recorded in AVCHD or JPEG file format.
NoteD
• Unrecognizable characters will be replaced with asterisks.
6.2. Guide to file list
C Picture file list
Page DownPage Up Media Mode
Folder_001 Folder_002
Thumbnail
Track 1/45
06051_1140
CD
DATA
Folder_001
1 2
3
4
1. Current file number / total number of files
2. Playback status symbol
3. Media type
4. Group (folder) / file list (thumbnails)
C How to navigate through the file list
• For picture file list, use [ ] to move the highlight up, down, left and right. Press
[BACK] to go back to the previous hierarchy.
• To access the files in a group (folder), select the desired group (folder), then press [OK].
• Press [RED] or [GREEN] to change the page list up or down.
• Press [BLUE] to go back to the file type (˝Photo˝ / ˝AVCHD˝) selection screen.
• Press [ (HOME)] to exit.
6.3. How to insert a disc
1. Press [ (OPEN/CLOSE)] to open the disc tray.
2. Place the disc on the disc tray with its label side facing up.
3. Press [
(OPEN/CLOSE)] to close the disc tray.
• It may take a while to load the disc.
Align the disc to the disc tray guide.
EN 20
7. BASIC PLAYBACK
7.1. Playing back a disc
[BD Video]
[DVD Video]
[CD]
[AVCHD]
[JPEG]
1. Insert a disc (refer to ˝How to insert a disc˝ on page 19).
• For Blu-ray Disc™ / DVD / audio CD or a disc containing only one type of file, playback will start automatically.
If not, press [ (PL AY/PAUS E)].
• Some discs may show a title or a disc menu. In this case, refer to ˝Using the title / disc / pop menu˝ on page 22.
2. Select the type of the file you want to play back, then press [OK].
AVCHD
a
b
a. For ˝Photo˝, thumbnail screen will appear.
• Refer to ˝Picture file list˝ on page 19 and ˝How to navigate through the file list˝ on page 19.
b. For ˝AVCHD˝, playback will start automatically.
To Skip to the next title / chapter / track / file: Press [
(SKIP)].
To Skip to the previous title / chapter / track / file: Press [
(SKIP)].
To Pause playback: Press [
(PLAY/PAUSE)].
To Return to normal playback: Press [
(PLAY/PAUSE)].
To Stop playback: Press [
(STOP)].
Playback will be in resume-on-stop mode. To clear the resume information, press [
(STOP)] again.
C Resume-on-stop mode
Blu-ray Disc™ / DVD / AVCHD
When you press [ (PL AY/PAUSE)] next time, playback will start from the point where it had been stopped.
Audio CD
Playback will start from the point where it was stopped next time you press [ (PL AY/PAUSE)]. If you press [OK]
instead of [ (PL AY/PAUSE)], playback will start from the beginning of the track / file instead of resuming from
the stop point.
JPEG
Playback will start from the beginning of the current file next time you press [ (PL AY/PAU SE )] or [OK].
NoteD
• Playback will also stop and the home menu will appear when you press [ (HOME)].
• For BD-Java application, the resume-on-stop may not be available.
• If you press [OK] instead of [ (PL AY/PAUS E)], playback can be started from the beginning of the disc even if it
was in the resume-on-stop mode.
• Resume-on-stop mode remains in effect even after Power is Turned Off, but will be cancelled once the disc is
ejected.
• With regard to the multi-border BD-RE/-R, additionally recorded sections cannot be recognized.
• With regard to the multi-border DVD-RW/-R, additionally recorded sections may not be recognized.
continued on next page
EN 21
NoteD for JPEG playback
• Every press of [ ] will turn the image by 90 degrees when an image is displayed.
• During playback, press [DISC MENU] to display thumbnail screen.
• Some unplayable folders or files may be listed due to the recording status.
• High-resolution JPEG files take longer to be displayed.
• Progressive JPEG files (JPEG files saved in progressive format) cannot be played back on this unit.
7.2. Playing back contents from a USB memory stick
[JPEG]
You can play back JPEG files stored on a USB memory stick. With the USB memory stick, you can also enjoy the
following functions.
• Special additional contents for BD-ROM.
(For more information about the special additional contents, refer to the instruction book that came with the disc.)
1. Connect a USB memory stick.
2. Press [
(HOME)].
3. Use [
] to select ˝Browse USB˝, then press [OK].
4. Follow step 2 in ˝Playing back a disc˝ on page 20.
CautionC
• Do not disconnect the USB memory stick or switch the unit to standby mode while contents on the USB memory
stick are being accessed. It may result in malfunction or loss of the stick's data.
• If you connect a USB memory stick or SD memory card via a USB card reader or USB hub, BD-ROM data will
be written onto the first connected card or device. Connecting a USB memory stick directly to this unit is
recommended.
• Occasionally, SD memory cards / Micro SD memory cards will not be recognized when using certain Adapters. In
such cases, try a different USB Adapter.
NoteD
• When connecting more than two USB memory sticks to a USB Hub, this unit may fail to recognize them. In such
cases, disconnect the USB Hub from the unit then reconnect it, or use less USB memory sticks at a time.
• The resume information will be cleared when;
- [ (STOP)] is pressed while in Resume-On-Stop mode.
- the USB memory stick is disconnected.
- the unit is switched to Standby mode.
• Do not delete folders or files on the USB memory stick with your computer. This unit may not read USB memory
sticks formatted on a computer.
• If a folder or file name includes one of the following unrecognizable characters, the folder or file name may not
be displayed correctly.
- Unrecognizable characters:
. , " = + [ ] ; / \ : | ¥
• This unit can read JPEG files and AVCHD on an SD memory card by using USB card reader / USB hub (not
included).
EN 22
7.3. Using the title / disc / pop menu
[BD Video]
[DVD Video]
[AVCHD]
Some BD-videos, DVD-videos or AVCHD files may contain a Title Menu which describes the contents of the disc, or
a Disc Menu which guides you through the available functions on the disc.
• With such discs, a Title Menu or a Disc Menu may appear automatically when you insert the disc. Otherwise, press
[DISC MENU] to call up the Menu Select Menu. Use [ ] to select ˝Top Menu˝ or ˝Pop-up Menu/Menu˝, then
press [OK]. Refer to the disc’s manual on how to navigate through the menu.
e.g.) Blu-ray Disc™
Pop-up Menu
Top Menu
Pop-up Menu
NoteD
• Menus vary among discs. Refer to the information accompanying the disc for details.
• [DISC MENU] may not work with some discs.
EN 23
8. SPECIAL PLAYBACK
8.1. Fast forward / fast reverse
[BD Video]
[DVD Video]
[CD]
[AVCHD]
1. During playback, press [ (FORWARD)] repeatedly for fast forward.
During playback, press [
(REVERSE)] repeatedly for fast reverse.
2. Press [
(PL AY/PAUSE)] to return to normal playback.
NoteD
• For Blu-ray Disc™, DVD and AVCHD, speed changes at 5 different levels.
• For audio CD, speed changes at 3 different levels.
• For audio CD, fast forward / fast reverse search between different files are not available.
8.2. Slow forward playback
[BD Video]
[DVD Video]
[AVCHD]
1. During playback, press [ (PL AY/PAUSE)]. Then press [ (FORWARD)].
Every time you press [
(FORWARD)], the playback speed changes at 3 different levels.
2. Press [
(PL AY/PAUSE)] to return to Normal playback.
NoteD
• Slow Reverse is not available.
8.3. Step by step playback
[BD Video]
[DVD Video]
[AVCHD]
1. In pause mode, press [ (SKIP)] repeatedly.
Every time you press [
(SKIP)], playback will advance one step at a time.
2. Press [
(PL AY/PAUSE)] to return to normal playback.
NoteD
• Step by step reverse is not available.
EN 24
8.4. Repeat playback
Available repeat functions vary depending on the disc.
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select ˝Repeat˝ then press [OK].
3. Use [
] to select the desired repeat mode.
REPEAT MODE AVAILABLE MEDIA
Chapter repeat
[BD Video]
[DVD Video]
[AVCHD]
The current chapter will be played back repeatedly.
Title repeat
[BD Video]
[DVD Video]
[AVCHD]
The current title will be played back repeatedly.
Track repeat
[CD]
[JPEG]
The current track or file will be played back repeatedly.
All repeat
[CD]
All tracks in the media will be played back repeatedly.
Group repeat
[JPEG]
The current group (folder) will be played back repeatedly.
Random repeat
[CD]
[JPEG]
Repeats the random playback. (CD)
Repeats the random playback in a folder. (JPEG)
4. Press [BACK] to Exit.
NoteD
• The repeat setting will be cancelled when you stop playback.
• When the repeat setting is set for an JPEG folder (file), the repeat setting will be cancelled if you select another
JPEG folder (file) to play back.
8.5. Slide show
[JPEG]
1. Follow steps 1 and 2 in ˝Playing back a disc˝ on page 20.
2. Open the folder which contains the desired JPEG files.
3. Use [
] to select a desired file to be played back, then press [ (PL AY/PAUSE)] or [OK].
• An image will be played back from the selected file and go to the next one in turn every 10 seconds.
4. Press [ (STOP)] to stop playback.
• When you press [DISC MENU] in the stop mode, the highlight goes back to the first item.
• When you press [DISC MENU] in the Resume-on-stop mode, the highlight goes back to the file played last.
NoteD
• Large-size JPEG files take time to load before being displayed on the screen.
EN 25
8.6. PiP (BONUSVIEW™) setting
[BD Video]
Some BD-videos have the PiP function which enables you to display the secondary video in the primary video.
PiP 1 / 8
Primary video
Secondary video
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select ˝PiP˝ then press [OK].
• PiP information will appear.
3. Use [ ] to select the secondary video you want to show.
• The secondary video will be displayed with secondary audio.
• Use [ ] to switch between current setting and ˝Off˝.
4. Press [BACK] to exit.
• To select the secondary audio output, refer to ˝Switching audio soundtrack˝ on page 29.
NoteD
• Secondary video may not be displayed all the time, depending on the scene, it may or may not be available for
display.
EN 26
8.7. Title / chapter search
[BD Video]
[DVD Video]
[AVCHD]
C Using [ (SKIP)] / [ (SKIP)]
1. During playback, press [ (SKIP)] to skip the current title or chapter and move to the next.
The Title or chapter will move forward one at a time.
• If there is no chapter in a title, the current title may be skipped.
To go back to the beginning of the current title or chapter, press [ (SKIP)].
Press [ (SKIP)] repeatedly to go to the previous title or chapter. The title or chapter may move backward one
at a time.
C Using ˝Search˝
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select ˝Search˝, then press [OK].
3. Use [
] to select ˝Title˝ or ˝Chapter˝, then press [OK].
e.g.) Blu-ray Disc™
Search 1 / 999
Title
4. Use [ ] to select the title / chapter number, then press [OK].
Playback will start from the beginning of the title / chapter.
NoteD
• As for BD-video, how it performs is strongly determined by the disc, and may not perform as described.
• For DVD, title search can be performed on the home menu by pressing [OPTIONS] while in stop mode or
resume-on-stop mode.
8.8. Track / file search
[CD]
[JPEG]
C Using [ (SKIP)] / [ (SKIP)]
1. During playback, press [ (SKIP)] to skip the current track or file and move to the next.
The track / file will move forward one at a time. To go back to the beginning of the current track / file, press
[ (SKIP)].
Press it repeatedly to go to the previous track / file. The track / file will move backward one at a time.
C Using ˝Search˝
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select ˝Search˝, then press [OK].
• For JPEG files, skip to step 4.
3. Use [ ] to select ˝Track˝, then press [OK].
4. Use [
] to select the track number, then press [OK].
Playback will start from the beginning of the track.
EN 27
8.9. Time search
[BD Video]
[DVD Video]
[CD]
[AVCHD]
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select ˝Search˝, then press [OK].
3. Use [
] to select ˝Time˝, then press [OK].
e.g.) Blu-ray Disc™
Search 00:12:44 / 11:13:14
Time
4. Enter the time count you want to jump to.
• Use [ ] to enter the first digit of the time counter, then press [ ].
• When the last digit is entered, press [OK].
Playback will start from the desired time entered.
8.10. Number select search
[BD Video]
[DVD Video]
[AVCHD]
Some BD-videos and DVD-videos or AVCHD files have button menus to jump to each button displayed scene.
During playback the scenes which have the button menu, you can enter the button number by using the number
select menu.
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select ˝Number˝, then press [OK].
e.g.) Blu-ray Disc™
Number
0000
• For BD-Java, a single-digit number select menu is displayed.
• For DVD, a double-digit number select menu is displayed.
• For BD-videos and AVCHD files, the number select menu is displayed even if there is no button menu in the
scene.
3. Use [ ] to enter the number you want to jump to.
• To move to the digit you wish to change, press [ ] .
4. After all digits are entered, press [OK].
Playback of the selected scene will start.
NoteD
• As for the BD-video, how it performs is strongly determined by the disc, and may not perform as described.
EN 28
8.11. Switching subtitles
Some video materials may have subtitles in one or more languages. For commercially available discs, the
supported languages can be found on the disc case. Follow the steps below to switch the subtitle language during
playback.
[BD Video]
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select ˝Subtitle˝, then press [OK].
3. Use [
] to select ˝Primary˝, ˝Secondary˝ or ˝Style˝, then press [OK].
˝Primary˝: Sets the subtitle for primary video.
˝Secondary˝: Sets the subtitle for secondary video.
˝Style˝: Sets style of the subtitle.
4. Use [ ] to select your desired subtitle or style.
Subtitle Primary
Secondary
Style
1 ENG / 3
O
O
• Use [ ] to switch between current subtitle setting and ˝Off˝.
5. Press [BACK] repeatedly to exit.
[DVD Video]
[AVCHD]
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select ˝Subtitle˝, then press [OK].
3. Use [
] to select your desired subtitle.
Subtitle 1 ENG / 32
• Use [ ] to switch between current subtitle setting and ˝Off˝.
4. Press [BACK] to exit.
NoteD
• Some discs will only allow you to change the subtitles from the disc menu or pop menu. Press [DISC MENU] to
select the ˝Top menu˝ or ˝Pop-up menu˝ (or ˝Menu˝).
• If the disc has no subtitle language or subtitle style, ˝Not available˝ will be displayed on the TV screen.
• During playback of the secondary video, the primary subtitle setting is not available except when there is no
subtitle for the secondary video.
EN 29
8.12. Switching audio soundtrack
When playing back video material recorded with two or more soundtracks (these are often in different audio
languages or audio formats), you can switch between them during playback. For Blu-ray Disc™, available audio
varies depending on ˝Blu-ray Disc Audio˝ setting. Refer to page 31.
[BD Video]
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select ˝Audio˝, then press [OK].
3. Use [
] to select ˝Primary˝ or ˝Secondary˝, then press [OK].
˝Primary˝: Sets the audio for primary video.
˝Secondary˝: Sets the audio for secondary video.
4. Use [ ] to select your desired audio stream channel.
Audio Primary
Secondary
1 ENG Dolby D Multi-ch /3
1 ENG DTS Multi-ch /3
[Decoding Format] : Dolby D
• For ˝Secondary˝, use [ ] to switch between current audio setting and ˝Off˝.
5. Press [BACK] repeatedly to exit.
[DVD Video]
[CD]
[AVCHD]
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select ˝Audio˝, then press [OK].
3. Use [
] to select your desired audio stream channel.
Audio 1 ENG Dolby D Multi-ch /3
[Decoding Format] : Dolby D
• For audio CD, you can select following options.
˝Stereo˝: Both right and left channels are active (stereo).
˝L-ch˝: Only left channel is active.
˝R-ch˝: Only right channel is active.
4. Press [BACK] to Exit.
NoteD
• Secondary audio will not be output when secondary video is not displayed or when ˝Blu-ray Disc Audio˝ is set
to ˝Primary Audio Only˝. (For some Blu-ray™ discs, secondary audio will be output even when secondary video
is Off.)
• Sound mode cannot be changed during playback of discs not recorded in multiple audio mode.
• Some discs allow changing the audio language setting from disc menu. (Operation varies depending on the
discs. Refer to the manual accompanying the disc.)
• ˝Audio˝ may not work on some discs with multiple audio streams or channels (e.g. DVDs that allow changing
audio setting on the disc menu).
• If the disc has no audio language, ˝Not Available˝ will be displayed on the TV screen.
• For DTS-CD (5.1 music disc), selecting audio streams or channels is not available.
EN 30
8.13. Switching camera angles
[BD Video]
[DVD Video]
Some BD-videos and DVD-videos contain scenes which have been shot simultaneously from various angles. You
can change the camera angle when appears on the TV screen.
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select ˝Angle˝, then press [OK].
3. Use [
] to select your desired angle.
• The selected angle will be displayed on the display bar at the top of the TV screen.
4. Press [BACK] to exit.
NoteD
• If ˝Ang le Ico n˝ setting is set to ˝Off˝, will not appear on the TV screen.
8.14. Noise reduction
[BD Video]
[DVD Video]
[AVCHD]
Reduces the noise of the playback picture.
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select ˝Noise Reduction˝, then press [OK].
3. Use [
] to select your desired setting.
e.g.) Blu-ray Disc™
Noise Reduction
O
˝On˝: Activates noise reduction.
˝Off˝: Deactivates noise reduction.
4. Press [BACK] to exit.
NoteD
• The setting will remain the same even if the unit is switched to standby mode.
8.15. CLEAR+
[BD Video]
[DVD Video]
[AVCHD]
CLEAR+ enhances the contrast of the picture and makes edges crisp. It is effective especially for DVD’s.
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select ˝CLEAR+˝, then press [OK].
3. Use [
] to select your desired setting.
e.g.) Blu-ray Disc™
CLEAR+
O
˝On˝: Gives low-definition videos high-definition like picture quality.
˝Off˝: Shows the original picture as recorded.
4. Press [BACK] to exit.
NoteD
• Pictures may appear whiter depending on the material and the connected TV. In this case, turn ˝CLEAR+˝ Off.
• ˝CLEAR+˝ is not effective under the following conditions.
- When the material is in 1080p/24 which is commonly used in Blu-ray™ discs.
EN 31
In ˝Setup˝, you can customize various kinds of settings as you prefer.
Refer to the following instructions to navigate through the setup menu.
1. Press [ (HOME)] to access the home menu.
2. Use [
] to select ˝Setup˝, then press [OK].
3. Use [
] to select the desired category, then press [OK].
4. Use [
] to move up and down the list to select menus / options.
5. To make a selection or to access options of an item, select the desired item, then press [OK].
• To go back to the previous screen, press [BACK].
6. Press [ (HOME)] to exit.
Refer to the following table for the types of settings you can customize.
The item highlighted in gray is the default setting.
Category Menus / Options
Video Setup TV Display 4:3 Normal
4:3 Crop
16:9 Widescreen
16:9 Squeeze
HDMI Video Auto
480p
720p
1080i
1080p
1080p/24
HDMI Deep Color Auto
Off
De-interlacing Mode Auto
Video
Audio Setup Night Mode Auto
On
Off
HDMI Audio Bitstream
LPCM
Blu-ray Disc Audio Mix Audio Output
Primary Audio Only
EasyLink Setup EasyLink On
Off
One Touch Play On
Off
One Touch Standby On
Off
9. LIST OF SETTINGS
continued on next page
EN 32
Category Menus / Options
Preference Setup Menu Language Auto
English
Español
Français
Audio Original
Bulgarian Italian
Chinese Japanese
Czech Korean
Danish Norwegian
Dutch Polish
English Portuguese
Finnish Romanian
French Russian
German Slovak
Greek Spanish
Hungarian Swedish
Icelandic Turkish
Irish Other
Subtitle Off
Bulgarian Italian
Chinese Japanese
Czech Korean
Danish Norwegian
Dutch Polish
English Portuguese
Finnish Romanian
French Russian
German Slovak
Greek Spanish
Hungarian Swedish
Icelandic Turkish
Irish Other
Disc Menu Bulgarian Italian
Chinese Japanese
Czech Korean
Danish Norwegian
Dutch Polish
English Portuguese
Finnish Romanian
French Russian
German Slovak
Greek Spanish
Hungarian Swedish
Icelandic Turkish
Irish Other
Parental Control Off
8 [Adult] 4 [PG-13]
7 [NC-17] 3 [PG]
6 [R] 2 [G]
5 [PGR] 1 [Kid Safe]
Change Password
Screen Saver On
Off
Angle Icon On
Off
Advanced Setup Software update Disc
USB
Version Info
Restore default settings Reset Settings
Format USB
(Unit) Erase Saved BD-ROM Data
(USB) Erase Saved BD-ROM Data
OSS
EN 33
10. SETUPS
10.1. EasyLink (HDMI CEC)
HOME A ˝Setup˝ A ˝EasyLink Setup˝ A ˝EasyLink˝
EasyLink(HDMI CEC) allows integrated system control over HDMI and is part of the HDMI standard. This function
may not work properly depending on the device connected to the unit. When ˝EasyLink˝ setting is set to ˝On˝ the
functions listed below will be available.
C One touch play
When the buttons below are pressed then operations are performed on this unit, the TV will automatically be
turned on and switched to the appropriate video source input.
Buttons for one touch play:
• [ (PL AY/PAU SE)], [ (SKIP)], [ (SKIP)], [ (HOME)] (on the remote control)
• [DISC MENU] (on the remote control when the a disc is inserted in the unit)
C One touch standby
When you press and hold [ (STANDBY/ON)] for 2 seconds, it turns off the TV first and then turns off the power on
this unit.
When the connected HDMI CEC compatible display device is turned off first, then it turns off the power to this unit.
C System information
Get & set Menu Language
The unit recognizes the OSD language set on the TV and automatically sets the same language as the player menu
language (OSD menu language) for this unit. Go to ˝Menu Language˝ under ˝Preference Setup˝ on page 32 to
see available languages.
• Feature is available only when ˝Auto˝ is selected in the setup menu ˝Menu Language˝ section in ˝Setup˝ while
connected via an HDMI cable.
EN 34
10.2. HDMI video resolution
HOME A ˝Setup˝ A ˝Video Setup˝ A ˝HDMI Video˝
Set the resolution of the video signal being output from the HDMI OUT jack.
You can select the desired video resolution among the settings listed below: ˝Auto˝, ˝4 8 0 p˝, ˝720p˝, ˝1080i˝, ˝1080p˝,
˝1080p24˝.
Actual output resolution:
Setting in the
˝HDMI video˝
Source
480i/60 480p/60 720p/60 1080i/60 1080p/60 1080p/24
Auto The highest resolution supported by your display device will automatically be in effect.
480p 480p/60
720p 720p/60
1080i 1080i/60
1080p 1080p/60
1080p/24 1080p/60 1080p/24
• For AVCHD, outputting the video in 24 frames per second (1080p/24) is not available.
NoteD
• The selected resolution must also be supported by your display device.
• If your TV and the unit are connected by a DVI cable and if ˝Auto˝ is selected, ˝4 8 0 p ˝ will be automatically in
effect.
• Refer also to your TV’s manual.
• When connected to an HDCP incompatible display device, the picture will not be displayed properly.
• The audio signals from the HDMI OUT jack (including the sampling frequency, the number of channels and bit
length) may be limited by the connected device.
• Among the display devices that support HDMI, some do not support audio output (for example, projectors).
While connected to a device such as a projector, audio will not be output from the HDMI OUT jack.
• When this unit’s HDMI OUT jack is connected to a DVI-D compatible display device(s) (HDCP compatible) with an
HDMI-DVI converter cable, the signals are output in digital RGB.
• HDMI video resolution does not work during playback of a BD-video.
Copyright protection system
To play back digital video images of a BD-video or DVD-video via an HDMI connection, it is necessary that
both the player and display device (or an AV receiver / amplifier) support a copyright protection system called
HDCP (high-bandwidth digital content protection system). HDCP is copy protection technology which prevents
copying or playback of encrypted content when connected to a non-HDCP compliant AV device. This unit
supports HDCP. Please read the operating instructions of your display device (or an AV receiver / amplifier) for
more information.
EN 35
10.3. Parental control
Some BD-videos or DVD-videos feature parental lock levels. Playback will stop if the ratings of the content exceed
the levels you set on the player, it will require you to enter a password before the disc will play back. This feature
prevents your children from viewing inappropriate material.
1. Enter your 4-digit password.
• Use [ ] to enter the first digit of your password, then press [ ].
• When 4-digit numbers are entered, press [OK].
For the first time use:
Enter any 4-digit number (except for 4737). That number will be used as the password. Record your password,
in case you forget it.
• If you forget the password, enter ˝4737˝. The password will be cleared and rating level will be set to ˝Off˝.
C Rating level
HOME A ˝Setup˝ A ˝Preference Setup˝ A ˝Parental Control˝
1. Use [ ] to select ˝Setup˝ in the home menu, then press [OK].
2. Use [
] to select ˝Preference Setup˝, then press [OK].
3. Use [
] to select ˝Parental Control˝, then press [OK].
4. Enter your 4-digit password.
• Use [ ] to enter the first digit of your password, then press [ ].
• When 4-digit numbers are entered, press [OK].
5. Use [ ] to select your desired level, then press [OK].
6. Press [
(HOME)] to exit.
RATING EXPLANATIONS
Off Parental control is inactive; all discs can be played back.
8 [Adult] BD / DVD software of any grades (adult / general / children) can be played back.
7 [NC-17] No one under 18.
6 [R] Restricted; under 18.
5 [PGR] Parental guidance recommended.
4 [PG-13] Unsuitable for children under 13.
3 [PG] Parental guidance suggested.
2 [G] General audience.
1 [Kid Safe] Suitable for children.
C Password change
HOME A ˝Setup˝ A ˝Preference Setup˝ A ˝Change Password˝
1. Use [ ] to select ˝Setup˝ in the home menu, then press [OK].
2. Use [
] to select ˝Preference Setup˝, then press [OK].
3. Use [
] to select ˝Change Password˝, then press [OK].
4. Enter your 4-digit password.
• Use [ ] to enter the first digit of your password, then press [ ].
• When 4-digit numbers are entered, press [OK].
5. Enter a new 4-digit password in the same way as the step 4.
6. Reenter the same new 4-digit password in the same way as the step 4.
7. Press [
(HOME)] to exit.
To temporarily disable parental lock:
Some discs allow you to temporarily disable parental lock. When you try to play them back, the password entry
screen will be displayed.
Follow the instruction which appears on the TV screen to disable parental lock.
EN 36
10.4. Software update
HOME A ˝Setup˝ A ˝Advanced Setup˝ A ˝Software update˝
This unit lets you update the software yourself using a software update disc or USB memory stick.
The available discs are below:
• BD-RE/-R
• DVD-RW/-R
• CD-RW/-R
C Disc / USB memory stick update
You can update the software by using a disc or USB memory stick.
Prepare a blank disc or USB memory stick for software update:
Navigate to www.philips.com/support, and download the latest version software to a blank disc or USB memory
stick using a PC by following the directions described on the website.
• Use a blank disc or USB memory stick, download one software per disc or USB memory stick. Write the software
in the root directory of the disc or USB memory stick.
• For more details on how to download the software, please refer to the website.
1. Use [ ] to select ˝Setup˝ in the home menu, then press [OK].
2. Use [
] to select ˝Advanced Setup˝, then press [OK].
3. Use [
] to select ˝Software update˝, then press [OK].
4. Use [
] to select ˝Disc˝ or ˝USB˝, then press [OK].
5. Use [
] to select ˝Yes˝, then press [OK].
6. Insert the disc or connect the USB memory stick for software update.
7. After loading disc or USB memory stick, confirmation message will appear. Select ˝Yes˝ and press [OK].
8. The unit will restart automatically, then software update will start.
• It may take a while to complete the updating.
9. After the update finishes, this unit will restart. Remove the disc or the USB memory stick from the unit.
CautionC
• Please do not unplug the AC power cord, eject the disc or disconnect the USB memory stick or press
[ (STANDBY/ON)] to turn the unit to Standby mode while performing a ˝Disc / USB Update˝.
NoteD
• Software update will not change any of the current settings.
EN 37
10.5. Restore default settings
HOME A ˝Setup˝ A ˝Advanced Setup˝ A ˝Restore default settings˝
Menus to reset player settings, format a USB memory stick.
1. Use [ ] to select ˝Setup˝ in the home menu, then press [OK].
2. Use [
] to select ˝Advanced Setup˝, then press [OK].
3. Use [
] to select ˝Restore default settings˝, then press [OK].
4. Use [
] to select the desired setting, then press [OK].
˝Reset Settings˝:
All the settings except for ˝Parental Control˝ settings will be reset to default.
˝Format USB˝ (Only available when a USB memory stick is connected):
Initialize the USB memory stick.
˝(Unit) Erase Saved BD-ROM Data˝:
Clears the data saved for the BD-ROM contents, such as BD-ROM game scores, on this player.
˝(USB) Erase Saved BD-ROM Data˝
(Only available when a USB memory stick is connected):
Clears supplemental data for BD-ROM playback, such as subtitle data, from the USB memory stick.
5. Use [ ] to select ˝Yes˝, then press [OK].
6. Confirmation message will appear. Press [OK] to complete the setting.
7. Press [
(HOME)] to exit.
CautionC
• Do not remove the USB memory stick while executing ˝Format USB˝ or ˝(USB) Erase Saved BD-ROM Data˝. It
will damage the USB memory stick.
NoteD
• ˝Format USB˝ and ˝(USB) Erase Saved BD-ROM Data˝ are not available when a Blu-ray Disc™ is in the unit.
EN 38
11. TROUBLESHOOTING
Problems Tips
No power. Check the AC power cord, if it is properly connected.
Try another power outlet.
Unplug the AC power cord, and wait for about 5-10 seconds. Plug it back in
and attempt to power on the unit.
No sound or picture. Make sure both the TV and Blu-ray Disc™ player are turned on.
Confirm the connections to the TV are made properly as shown in the
˝CONNECTIONS˝ on page 13.
Check to see whether the connected TV or another device supports HDCP.
(This unit will not output a video signal unless the other device supports
HD CP.)
No reaction to the remote control. Reduce the distance to infrared sensor window.
Confirm that the player’s AC power cord is plugged into a power outlet.
Check the batteries in the remote control and make sure they are inserted
properly by + or - symbols.
Please check IR signal. Refer to ˝IR signal check˝ on page 43.
No audio / video signal on the
display device via HDMI cable.
If the unit is connected to a non-certified HDMI device, the audio / video
signal will not output to that device.
Make sure the display device is on the correct Input / video source.
Perform an HDMI hotplug: Disconnecting the HDMI cable from the display
device, turn on both devices, and replug the HDMI cable back in.
Check with the TV manufacturer, if there are any software updates available
for the TV.
Check to see if the HDMI cable is a certified version.
No high-definition video signal on
the TV screen.
Does the disc contain high-definition video? High-definition video is only
available when the disc contains it.
Does the TV support high-definition video? High-definition video is only
available when the TV supports it.
Distorted picture. Sometimes a small amount of picture distortion may appear. This is not a
malfunction.
Completely distorted picture or
black / white picture with Blu-ray
Disc™ / DVD.
Make sure the disc is compatible with this unit.
No sound or distorted sound. Adjust the volume.
Check to see if the speakers are connected correctly.
Check the HDMI connection.
Make sure the HDMI cable is not plugged into an HDMI-DVI adapter or
projector which does not handle digital sound.
Check the settings in ˝Audio Setup˝ menu.
Picture freezes momentarily during
disc playback.
Check the disc for fingerprints / scratches and clean with a soft cloth wiping
from the center to the outer edge.
Cannot play back a disc. Make sure that the disc is playable on this unit.
Check the region code of the disc. This unit supports the following region
codes.
- Blu-ray Disc™: ˝A˝
- DVD: ˝ALL˝ or ˝1˝
For DVD-RW/-R, make sure that the disc is finalized.
Clean the disc.
Is the disc a newer title? This problem may be solved by software update.
Refer to ˝Software update˝ on page 36.
No return to start-up screen when
disc is removed.
Soft reset this unit by turning it off for 30 seconds, then on again.
To completely reset the unit, press and hold [
(STANDBY/ON)] on the front
panel for 10 seconds to shut down the unit or unplug the AC power cord from
the AC outlet for 5-10 seconds.
will appear on the TV screen.
The operation is not possible.
continued on next page
EN 39
Problems Tips
Buttons do not work or the unit
stops responding.
To soft reset the unit, press and hold [
(STANDBY/ON)] on the front panel
for 10 seconds to shut down the unit or to hard reset the unit by unplugging
the AC power cord from the AC outlet for 5-10 seconds.
The unit does not respond to
some operating commands during
playback.
The operations may be prohibited by the disc. Refer to the instructions for
the disc.
The unit cannot read Blu-ray Disc™
/ DVD/ CD.
Condensation? (Let the unit sit and dry for 1 or 2 hours)
Check to see if the disc is compatible with this unit. (Refer to page 16.)
Wipe dirt off the disc from the center to the outside or replace the disc.
Refer to ˝Cleaning discs˝ on page 43.
Scene shooting angle does not
switch.
Angles cannot be switched for Blu-ray Disc™ / DVD which do not contain
multiple angles. In some cases multiple angles are only recorded for
specific scenes.
Playback does not start when a title
is selected.
Check the settings in ˝Parental Control˝ menu.
The password for rating level has
been forgotten.
Enter the default password ˝4737˝, then your forgotten password will be
cleared. Then to change password go to ˝Password change˝ on page 35.
Error message appears when I select
˝Auto˝ in the ˝Menu Language˝.
Make sure that the unit is connected to a TV that is compatible with HDMI
CEC and the ˝EasyLink˝ is set to ˝On˝.
This error message may appear when your TV's OSD language is not
supported by this unit.
Cannot play back AVCHD file. This unit cannot play back stand-alone AVCHD files (*.m2ts, *.mts or *.m2t)
written to a DVD. The DVD containing AVCHD files must have a proper file
and folder structure meeting AVCHD format specifications. Please use
AVCHD compliant device / software to burn or copy AVCHD files to DVD.
(Please refer to user manuals of the device / software for more information.)
The capacity of the USB memory
stick decreased.
Data may be written on the USB memory stick when a BD-video uses the
Virtual Package feature while a USB memory stick is connected to the unit.
Cannot play back a MPEG-2 video
and audio from the USB memory
stick.
MPEG-2 is not compatible with this unit.
Cannot read the contents on the
USB memory stick.
The USB memory stick is not compatible with this unit or the contents may
be damaged.
Try and turn off the unit, then turn it back on.
To soft reset the unit, press and hold [
(STANDBY/ON)] on the front panel
for 10 seconds to shut down the unit or to hard reset the unit by unplugging
the AC power cord from the AC outlet for 5-10 seconds.
Cannot play back BD-Video. Connect a USB memory stick (256MB or more of available memory) which
is formatted on this unit. Some discs require memory when playing back
content.
Do not disconnect the USB memory stick during playback.
Cannot use BD-Live. Since this unit does not connect to the internet, BD-Live is not supported.
Cannot play back 3D. 3D Blu-ray™ discs are not supported by this unit.
Cannot load a Blu-ray Disc™ (stuck
in ˝Loading…˝ mode) and cannot
Open the disc tray to eject the disc.
Unplug unit from AC outlet for 20 seconds. Plug unit back in and press the
[
(OPEN/CLOSE)] on the unit to eject the disc.
The software update screen
appears after turning on the unit.
Please complete the software update.
When the software update has failed, the software update screen will keep
appearing after turning the unit on. If the software update continues failing,
please try it by using a USB memory stick with the update software installed
in its root directory. In this case, please change the file name as below.
˝ECM21UH10000PA1.bin˝ A ˝UPDATE10000PA1.BIN˝
Do not change the numbers. The file name is case sensitive.
Cannot read a USB memory stick. The format of the USB memory stick is not compatible with this unit. Please
try and format it on this unit (All data will be deleted).
Cannot play back JPEG files from a
disc.
Make sure that the disc was recorded in the UDF, ISO9660 or JOLIET
format.
continued on next page
EN 40
Problems Tips
Cannot find a JPEG file. Make sure that the selected group (folder) does not contain more than
9,999 files for Blu-ray Disc™ / DVD / USB memory stick and 999 files for CD.
Make sure that the file extension is .jpg / .JPG / .jpeg / or .JPEG.
No audio signal from surround
system of the audio system.
Make sure the audio system is turned on.
Check the Input mode on the audio system if it is on the correct channel.
Check if the Surround system is compatible with either Bitstream or
LPCM. If not sure please check the user manual or contact the Surround
manufacturer. Once confirmed check the setting in the ˝Setup˝ of this unit.
Increase the volume level of the Surround system.
NoteD
• Do not attempt to repair the Blu-ray Disc™ player yourself. This may cause severe injury, irreparable damage to
your Blu-ray Disc™ Player and void your warranty.
• Please have your Blu-ray Disc™ Player model and serial number available before contacting us. These numbers
are available on the cabinet, as well as on the packaging.
EN 41
12. LANGUAGE CODE LIST
Language Code Language Code Language Code Language Code
A-B French [FRE] 5264 Macedonian 5957 Siswat 6565
Abkhazian 4748 Frisian 5271 Malagasy 5953 Slovak [SLO] 6557
Afar 4747 Galician 5358 Malay 5965 Slovenian 6558
Afrikaans 4752 Georgian 5747 Malayalam 5958 Somali 6561
Albanian 6563 German [GER] 5051 Maltese 5966 Spanish [SPA] 5165
Amharic 4759 Greek [GRE] 5158 Maori 5955 Sundanese 6567
Arabic 4764 Greenlandic 5758 Marathi 5964 Swahili 6569
Armenian 5471 Guarani 5360 Moldavian 5961 Swedish [SWE] 6568
Assamese 4765 Gujarati 5367 Mongolian 5960 T
Aymara 4771 Hausa 5447 Nauru 6047 Ta galog 6658
Azerbaijani 4772 Hebrew 5451 Nepali 6051 Tajik 6653
Bashkir 4847 Hindi 5455 Norwegian [NOR] 6061 Tamil 6647
Basque 5167 Hungarian [HUN] 5467 O-R Tatar 6666
Bengali;Bangla 4860 I-K Occitan 6149 Telugu 6651
Bhutani 5072 Icelandic [ICE] 5565 Oriya 6164 Thai 6654
Bihari 4854 Indonesian 5550 Oromo (Afan) 6159 Tibetan 4861
Bislama 4855 Interlingua 5547 Panjabi 6247 Tigrinya 6655
Breton 4864 Interlingue 5551 Pashto;Pushto 6265 Tonga 6661
Bulgarian [BUL] 4853 Inupiak 5557 Persian 5247 Tsonga 6665
Burmese 5971 Irish [GLE] 5347 Polish [POL] 6258 Turk ish [TUR] 6664
Byelorussian 4851 Italian [ITA] 5566 Portuguese [POR] 6266 Turkmen 6657
C-E Japanese [JPN] 5647 Quechua 6367 Tw i 6669
Cambodian 5759 Javanese 5668 Rhaeto-Romance 6459 U-Z
Catalan 4947 Kannada 5760 Romanian [RUM] 6461 Ukrainian 6757
Chinese [CHI] 7254 Kashmiri 5765 Russian [RUS] 6467 Urdu 6764
Corsican 4961 Kazakh 5757 S Uzbek 6772
Croatian 5464 Kinyarwanda 6469 Samoan 6559 Vietnamese 6855
Czech [CZE] 4965 Kirghiz 5771 Sangho 6553 Volapuk 6861
Danish [DAN] 5047 Kirundi 6460 Sanskrit 6547 Welsh 4971
Dutch [DUT] 6058 Korean [KOR] 5761 Scots Gaelic 5350 Wolof 6961
English [ENG] 5160 Kurdish 5767 Serbian 6564 Xhosa 7054
Esperanto 5161 L-N Serbo-Croatian 6554 Yiddish 7155
Estonian 5166 Laothian 5861 Sesotho 6566 Yoruba 7161
F-H Latin 5847 Setswana 6660 Zulu 7267
Faroese 5261 Latvian;Lettish 5868 Shona 6560
Fiji 5256 Lingala 5860 Sindhi 6550
Finnish [FIN] 5255 Lithuanian 5866 Singhalese 6555
NoteD
• If you choose a language that has a 3-letter-language code (written in bracket), the code will be displayed every
time you change the Subtitle language setting on page 28 or audio language setting on page 29. If you
choose any other languages, ˝---˝ will be displayed instead.
EN 42
13. SPECIFICATIONS
General
Signal system NTSC Color
Power requirements 120 V AC, 60 Hz
Power consumption 15 W (standby: 0.5 W)
Dimensions (width x height x depth) 11.1 x 1.7 x 8.3 inches (280.0 x 41.0 x 201.0 mm)
Weight 1.0 kg. (2.21 lbs.)
Operating temperature 41°F (5°C) to 104°F (40°C)
Operating humidity Less than 80 % (no condensation)
Terminals
USB input
TYPE A
HDMI output
HDMI jack x 1
Digital video: 480p, 720p, 1080i, 1080p, 1080p/24
Digital audio
NoteD
• The specifications and design of this product are subject to change without notice.
EN 43
14. MAINTENANCE
C Servicing
• Please refer to relevant topics in ˝TROUBLESHOOTING˝ on page 38 before returning the product.
• If this unit becomes inoperative, do not try to correct the problem by yourself. There are no user-serviceable
parts inside. Eject the disc (if possible), disconnect the USB memory stick (if connected to the unit),
place the unit into Standby mode, unplug the AC power plug, and please contact: 1-866-515-1124 or visit :
www.philips.com/support
C Cleaning the cabinet
• Wipe the front panel and other exterior surfaces of the unit with a soft cloth.
• Never use a solvent, thinner, benzene or alcohol to clean the unit. Do not spray insecticide liquid near the unit.
Such chemicals may discolor the surface or damage the unit.
C Cleaning discs
• When a disc becomes dirty, clean it with a cleaning cloth. Wipe the disc from the center to outside. Do not wipe
in a circular motion.
• Do not use solvents such as benzine, thinner, commercially available cleaners, detergent, abrasive cleaning
agents or antistatic spray intended for analog records.
C Cleaning the disc lens
• If this unit still does not perform properly although you referred to relevant sections and ˝TROUBLESHOOTING˝
in this user manual, the laser optical pickup unit may be dirty. Consult your dealer or an authorized service
center for inspection and cleaning of the laser optical pickup unit.
C Disc handling
• Handle the discs so that fingerprints and dust do not adhere to the surfaces of the discs.
• Always store the disc in its protective case when it is not used.
• Note that discs with special shapes (heart-shaped discs, octagonal discs, etc.) cannot be played back on this
unit. Do not attempt to play such discs, as they may damage the unit.
C IR signal check
If the remote control does not work properly, you can test IR signal using a digital camera (including a cellphone
with a built-in camera) to see if the remote control sends out the infrared signal.
1. Turn on the digital camera.
2. Direct a digital camera to the remote control, then press and hold any button on the
remote control.
• If infrared light appears on the digital camera display, the remote control is working.
NoteD
• Some cameras have an IR filter and will not display the IR signal.
EN 44
15. TRADEMARK INFORMATION
˝Blu-ray Disc™˝, ˝Blu-ray˝ and ˝Blu-ray Disc™˝ logo are
trademarks of the Blu-ray Disc Association.
˝BONUSVIEW™˝ and ˝BONUSVIEW™˝ logo are
trademarks of the Blu-ray Disc Association.
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of
Dolby Laboratories.
Java and all Java based trademarks and logos are
trademarks or registered trademarks of Oracle and/or
its affiliates.
For DTS patents, see http://patents.dts.com.
Manufactured under license from DTS Licensing
Limited.
DTS, the Symbol, & DTS and the Symbol together are
registered trademarks, and DTS 2.0+Digital Out is a
trademark of DTS, Inc. © DTS, Inc. All Rights Reserved.
The terms HDMI and HDMI High-Definition Multimedia
Interface, and the HDMI Logo are trademarks or
registered trademarks of HDMI Licensing LLC in the
United States and other countries.
˝x.v.Color˝ and ˝x.v.Color˝ logo are trademarks of Sony
Corporation.
is a trademark of DVD Format/Logo Licensing
Corporation.
˝AVCHD˝ and the ˝AVCHD˝ logo are trademarks of
Panasonic Corporation and Sony Corporation.
THIS PRODUCT IS LICENSED UNDER THE AVC PATENT
PORTFOLIO LICENSE FOR THE PERSONAL AND NON-
COMMERCIAL USE OF A CONSUMER TO (i) ENCODE
VIDEO IN COMPLIANCE WITH THE AVC STANDARD
(˝AVC VIDEO˝) AND/OR (ii) DECODE AVC VIDEO
THAT WAS ENCODED BY A CONSUMER ENGAGED
IN A PERSONAL AND NON-COMMERCIAL ACTIVITY
AND/OR WAS OBTAINED FROM A VIDEO PROVIDER
LICENSED TO PROVIDE AVC VIDEO. NO LICENSE IS
GRANTED OR SHALL BE IMPLIED FOR ANY OTHER
USE. ADDITIONAL INFORMATION MAY BE OBTAINED
FROM MPEG LA, L. L. C. SEE
HTTP://WWW.MPEGLA.COM
THIS PRODUCT IS LICENSED UNDER THE VC-1
PATENT PORTFOLIO LICENSE FOR THE PERSONAL
AND NON-COMMERCIAL USE OF A CONSUMER TO
(i) ENCODE VIDEO IN COMPLIANCE WITH THE VC-1
STANDARD (˝VC-1 VIDEO˝) AND/OR (ii) DECODE
VC-1 VIDEO THAT WAS ENCODED BY A CONSUMER
ENGAGED IN A PERSONAL AND NON-COMMERCIAL
ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO
PROVIDER LICENSED TO PROVIDE VC-1 VIDEO. NO
LICENSE IS GRANTED OR SHALL BE IMPLIED FOR
ANY OTHER USE. ADDITIONAL INFORMATION MAY
BE OBTAINED FROM MPEG LA, L.L.C. SEE
HTTP://WWW.MPEGLA.COM
EN 45
16. GLOSSARY
AACS
Advanced Access Content System (AACS) is the content
protection scheme used with Blu-ray™ discs.
Analog audio
An electrical signal that directly represents sound.
Compare this to digital audio which can be an electrical
signal, but is an indirect representation of sound. See
also ˝Digital audio˝.
Aspect Ratio
The width of a TV screen relative to its height.
Conventional TVs are 4:3 (in other words, the TV screen
is almost square); widescreen models are 16:9 (the TV
screen is almost twice as wide as its height).
AVCHD
AVCHD is a new format for high definition video
camcorders which can record and play high-resolution
HD images.
Blu-ray Disc™
Blu-ray Disc™ is a next generation optical video disc
which is capable of storing much more data than a
conventional DVD. The large capacity makes it possible
to benefit from the features such as high-definition
videos, multi-channel surround sounds, interactive
menus and so on.
Chapter
Just as a book is split up into several chapters, a Title
on a BD-video or DVD-video is usually divided into
chapters. See also ˝Title˝.
Cinavia™
Cinavia Notice
This product uses Cinavia technology to limit the
use of unauthorized copies of some commercially-
produced film and videos and their soundtracks. When
a prohibited use of an unauthorized copy is detected, a
message will be displayed and playback or copying will
be interrupted.
More information about Cinavia technology is provided
at the Cinavia Online Consumer Information Center at
http://www.cinavia.com
To request additional information about Cinavia by mail,
send a postcard with your mailing address to: Cinavia
Consumer Information Center, P.O. Box 86851, San
Diego, CA, 92138, USA.
This product incorporates proprietary technology under
license from Verance Corporation and is protected by
U.S. Patent 7,369,677 and other U.S. and worldwide
patents issued and pending as well as copyright and
trade secret protection for certain aspects of such
technology.
Cinavia is a trademark of Verance Corporation.
Copyright 2004-2016 Verance Corporation. All
rights reserved by Verance. Reverse engineering or
disassembly is prohibited.
Digital audio
An indirect representation of sound by numbers. During
recording, the sound is measured at discrete intervals
(44,100 times a second for CD audio) by an analog-
to-digital converter, generating a stream of numbers.
On playback, a digital-to-analog converter generates
an analog signal based on these numbers. See also
˝Sampling frequency˝ and ˝Analog audio˝.
Dolby Digital
The system to compress digital sound developed by
Dolby Laboratories. It offers you sound of stereo (2ch)
or multi-channel audio.
Dolby Digital Plus
Dolby Digital Plus is the next generation digital audio
compression technology developed as an extension to
Dolby Digital. Blu-ray Disc™ supports 7.1 multi-channel
surround sound output.
Dolby TrueHD
Dolby TrueHD is a lossless coding technology
developed for next generation optical discs. Blu-
ray Disc™ supports 7.1 multi-channel surround sound
output.
DTS
®
(Digital Theater System)
DTS
®
is a multi-channel surround sound system. You
can enjoy movie dynamic and realistic sound like
movie theater. DTS surround sound technologies were
developed by DTS, Inc.
DTS-HD
®
DTS-HD
®
is a lossless coding technology developed as
an extension of the original DTS Coherent Acoustics
format. Blu-ray Disc™ supports 7.1 multi-channel
surround sound output.
HDMI (High-Definition Multimedia Interface)
A digital interface between an audio and video Source.
It can transmit component video, audio, and control
signal with one cable connection.
JPEG (Joint Photographic Experts Group)
JPEG is a method of compressing still picture files. You
can copy JPEG files on BD-RE/-R, DVD-RW/-R, CD-
RW/-R, or USB memory stick from a computer and play
back the files on this unit.
Local Storage
A storage area of sub contents for playing virtual
packages on BD-video.
continued on next page
EN 46
PCM (Pulse Code Modulation)
The most common system of encoding digital audio,
found on CD and DAT. Excellent quality, but requires a
lot of data compared to formats such as Dolby Digital
and MPEG audio. For compatibility with digital audio
recorders (CD, MD and DAT) and AV amplifiers with
digital Inputs, this unit can convert Dolby Digital, DTS,
and MPEG audio to PCM. See also ˝Digital audio˝.
Region Code
Regions associate discs and players with particular
areas of the world. This unit will only play back discs
that have compatible region codes. You can find the
region code of your unit by looking on the rear panel.
Some discs are compatible with more than one region
(or all regions).
Sampling frequency
The rate which sound is measured by a specified
interval to turn into digital audio data. The numbers of
sampling in one second defines as sampling frequency.
The higher the rate, the better the sound quality.
Title
A collection of chapters on BD-video or DVD-video.
See also ˝Chapter˝.
Track
Audio CD uses Tracks to divide up the content of a
disc. The BD-video or DVD-video equivalent is called a
Chapter.
See also ˝Chapter˝.
x.v.Color
˝x.v.Color˝ is a promotion name given to the products
that have the capability to realize a wide color space
based on the xvYCC specifications and is a trademark of
Sony Corporation.
17. LIMITED WARRANTY
back cover
NINETY (90) DAY LIMITED WARRANTY
WARRANTY COVERAGE:
This warranty obligation is limited to the terms as set forth below.
WHO IS COVERED:
This product is warranted to the original purchaser or the person
receiving the product as a gift against defects in materials
and workmanship as based on the date of original purchase
(“Warranty Period”) from an authorized dealer. The original sales
receipt showing the product name and the purchase date from an
authorized retailer is considered such proof.
WHAT IS COVERED:
This warranty covers new products if a defect in material or
workmanship occurs and a valid claim is received within the
Warranty Period. At its option, the company will either (1) repair
the product at no charge, using new or refurbished replacement
parts, or (2) exchange the product with a product that is new
or which has been manufactured from new, or serviceable used
parts and is at least functionally equivalent or most comparable
to the original product in current inventory, or (3) refund the
original purchase price of the product.
The Company warrants replacement products or parts provided
under this warranty against defects in materials and workmanship
from the date of the replacement or repair for ninety (90) days or for
the remaining portion of the original product’s warranty, whichever
provides longer coverage for you. When a product or part is exchanged,
any replacement item becomes your property and the replaced item
becomes the company’s property. When a refund is given, your
product becomes the company’s property.
Note: Any product sold and identified as refurbished or
renewed carries a ninety (90) day limited warranty.
Replacement product can only be sent if all warranty
requirements are met. Failure to follow all requirements
can result in delay.
WHAT IS NOT COVERED - EXCLUSIONS AND LIMITATIONS:
This Limited Warranty applies only to new company manufactured
products that can be identified by the trademark, trade name,
or logo affixed to it. This Limited Warranty does not apply to any
hardware product or any software, even if packaged or sold with
the product, as manufacturers, suppliers, or publishers may provide
a separate warranty for their own products packaged with the
bundled product. The company is not liable for any damage to or
loss of any programs, data, or other information stored on any media
contained within the product, or other additional product or part not
covered by this warranty. Recovery or reinstallation of programs,
data or other information is not covered under this Limited Warranty.
This warranty does not apply (a) to damage caused by accident,
abuse, misuse, neglect, misapplication, or non-supplied product,
(b) to damage caused by service performed by anyone other than
company approved authorized service location, (c) to a product or a
part that has been modified without written company permission, or
(d) if any serial number has been removed or defaced, or (e) product,
accessories or consumables sold “AS IS” without warranty of any kind
by including refurbished product sold “AS IS” by some retailers.
This Limited Warranty does not cover:
• Shipping charges to return defective product.
• Labor charges for installation or setup of the product,
adjustment of customer controls on the product, and
installation or repair of antenna/signal source systems outside
of the product.
• Product repair and/or part replacement because of improper
installation or maintenance, connections to improper voltage
supply, power line surge, lightning damage, retained images
or screen markings resulting from viewing fixed stationary
content for extended periods, product cosmetic appearance
items due to normal wear and tear, unauthorized repair or
other cause not within the control of the company.
• Damage or claims for products not being available for use, or
for lost data or lost software.
• Damage from mishandled shipments or transit accidents
when returning product.
• A product that requires modification or adaptation to enable
it to operate in any country other than the country for which it
was designed, manufactured, approved and/or authorized, or
repair of products damaged by these modifications.
• A product used for commercial or institutional purposes
(including but not limited to rental purposes).
• Product lost in shipment and no signature verification receipt
can be provided.
• Failure to operate per Owner’s Manual.
TO OBTAIN ASSISTANCE...
Contact Customer Care Center at:
1-866-515-1124
REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY
IS THE EXCLUSIVE REMEDY FOR THE CONSUMER, WITH THE
ISSUING COMPANY NOT LIABLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES FOR BREACH OF ANY EXPRESS OR
IMPLIED WARRANTY ON THIS PRODUCT. EXCEPT TO THE EXTENT
PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON
THIS PRODUCT IS LIMITED IN DURATION TO THE DURATION OF
THIS WARRANTY.
Some states do not allow the exclusions or limitation of incidental or
consequential damages, or allow limitations on how long an implied
warranty lasts, so the above limitations or exclusions may not apply
to you.
This warranty gives you specific legal rights. You may have other rights which vary from state/province to state/province.
Funai Service Corporation
1880 Braselton Hwy, Suite 118 #5012 Lawrenceville, GA 30043
P&F USA, Inc.
1880 Braselton Hwy, Suite 118 #5012 Lawrenceville,
GA 30043 U.S.A
P&F Mexicana, S.A. de C.V.
Av. La Palma No. 6, Col. San Fernando La Herradura.
Huixquilucan, Edo. de México. C.P. 52787
This product has been manufactured by and is sold
under the responsibility of P&F USA, Inc., and P&F
USA, Inc. is the warrantor in relation to this product.
The Philips trademark and the Philips Shield Emblem
are registered trademarks of Koninklijke Philips N.V.
used under license.
ECM21UH
Register your product and get support at
www.philips.com/welcome
EN User manual
EN For further assistance, call the customer
support service in your country.
• To obtain assistance, contact Philips customer
care center;
In the U.S.A., Canada, Puerto Rico, or the U.S.
Virgin Islands; 1- 866-515-1124
BDP1305
Blu-ray Disc™ /
DVD Player
2
CONTENTS
INTRODUCTION ................................................. 3
Safety instruction ........................................................... 3
Included accessories .................................................... 6
FEATURES ........................................................... 7
Features .............................................................................7
Version info ......................................................................8
Symbols used in this owner’s manual ......................8
FUNCTIONAL OVERVIEW ................................9
Front panel ...................................................................... 9
Rear panel ....................................................................... 9
Remote control ..............................................................10
Guide to on-screen display ....................................... 12
CONNECTIONS ..................................................13
Connection to a TV ...................................................... 13
Connection to an audio system ............................... 13
HDMI audio output ...................................................... 14
BEFORE YOU START ........................................15
Finding a viewing video source input on your TV ... 15
Initial setup ..................................................................... 15
INFORMATION ON PLAYBACK ..................... 16
Information on playback ............................................ 16
Guide to file list .............................................................19
How to insert a disc .....................................................19
BASIC PLAYBACK ............................................20
Playing back a disc ..................................................... 20
Playing back contents from a USB memory stick .. 21
Using the title / disc / pop menu ............................ 22
SPECIAL PLAYBACK ........................................ 23
Fast forward / fast reverse ....................................... 23
Slow forward playback .............................................. 23
Step by step playback ............................................... 23
Repeat playback .......................................................... 24
Slide show ...................................................................... 24
PiP (BONUSVIEW™) setting ..................................... 25
Title / chapter search ................................................. 26
Track / file search ........................................................ 26
Time search ....................................................................27
Number select search .................................................27
Switching subtitles ...................................................... 28
Switching audio soundtrack ..................................... 29
Switching camera angles ..........................................30
Noise reduction ............................................................30
CLEAR+ ........................................................................... 30
LIST OF SETTINGS ............................................ 31
SETUPS .............................................................. 33
EasyLink (HDMI CEC) ................................................. 33
HDMI video resolution ............................................... 34
Parental control ........................................................... 35
Software update .......................................................... 36
Voice guide .....................................................................37
Restore default settings .............................................37
TROUBLESHOOTING ......................................38
LANGUAGE CODE LIST .................................... 41
SPECIFICATIONS .............................................. 42
MAINTENANCE ................................................43
TRADEMARK INFORMATION........................44
GLOSSARY .........................................................45
LIMITED WARRANTY ...................................... 47
EN 3
For fastest support visit us online at www.philips.com/support
for chat and self service solutions.
The lightning ash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sucient
magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
Know these
safety symbols
CAUTION:
TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK). NO
USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
* Additional Benets
Registering your product guarantees that you’ll
receive all of the privileges to which you’re
entitled, including special money-saving oers.
* Product Safety Notication
By registering your product, you’ll receive notication
- directly from the manufacturer - in the rare case of
a product recall or safety defect.
Registering your model with Philips makes you eligible for all of the valuable benefits
listed below, so don’t miss out. Register online at www.philips.com/welcome to ensure:
Register online at www.philips.com/welcome
today to get the most benets from your purchase.
The symbol for CLASS ll (Double Insulation)
WARNING
:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS
TO RAIN OR MOISTURE. APPARATUS SHALL NOT BE EXPOSED TO DRIPPING OR SPLASHING AND NO
OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES, SHALL BE PLACED ON THE APPARATUS.
CAUTION: To prevent electric shock, match wide blade of plug to wide slot, fully insert.
ATTENTION:
P our éviter les chocs électriques, introduire la lame la plus large de la che dans la borne
correspondante de la prise et pousser jusqu’au fond.
The important note and rating are located on the rear or bottom of the cabinet.
For Customer Use
Model No. ___________________________________________________________
Serial No. ___________________________________________________________
Please write the model and serial number of your
unit (located on the cabinet) in the space below for
future reference.
1. INTRODUCTION
1.1. Safety instruction
EN 4
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
11. Only use attachments / accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use caution when moving the cart / apparatus combination to
avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has
been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate
normally, or has been dropped.
FCC WARNING
This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may
cause harmful interference unless the modifications are expressly approved in the manual. The user could lose
the authority to operate this equipment if an unauthorized change or modification is made.
RADIO-TV INTERFERENCE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the device and the receiver.
3. Connect the device into an outlet on a circuit different from that to which the receiver is connected.
4. Consult the dealer or an experienced radio / TV technician for help.
Disconnect the mains plug (the AC plug) to shut the unit off when trouble is found or when not in use. The mains
plug (the AC plug) shall remain readily available. To completely turn off the unit, you must unplug the mains (AC)
power cord.
CAN ICES-3 (B)/NMB-3(B)
CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent
type.
WARNING: Batteries (Battery pack or battery installed) shall not be exposed to excessive heat such as sunshine,
fire or the like.
LASER SAFETY
This apparatus is classified as a CLASS 1 LASER PRODUCT.
This apparatus employs a laser. Only a qualified service person should remove the cover or
attempt to service this apparatus, due to possible eye injury.
CAUTION: Use of controls or adjustments or performance of procedures other than those specified herein may
result in hazardous radiation exposure.
EN 5
IMPORTANT COPYRIGHT INFORMATION
Unauthorized copying, broadcasting, public performance and lending of discs are prohibited. This item
incorporates copy protection technology that is protected by U.S. patents and other intellectual property rights
of Rovi Corporation. Reverse engineering and disassembly are prohibited.
Never use a gas duster on this unit.
The gas trapped inside of this unit may cause ignition and explosion.
Do not place the unit on furniture that is capable of being tilted by a child and an adult leaning, pulling, standing
or climbing on it. A falling unit can cause serious injury or even death.
In order to avoid interruption of ventilation, this unit should not be placed in built-in equipment such as a book
cabinet, rack, etc., and the vents of this unit should not be covered with anything such as a tablecloth, curtain,
newspaper, etc. Make sure to leave a space of 5.9 inches (15cm) or more around this apparatus.
When installing this unit in a temperate environment, avoid a place with rapid temperature changes.
This unit should not be used in a tropical environment as it has not been evaluated under such conditions.
No objects should be placed directly on or under this unit, especially lighted candles or other flaming objects.
To avoid the hazards of electrical shock and fire
Do not handle the power cord with wet hands.
Do not pull on the power cord when disconnecting it from an AC outlet. Grasp it by the plug.
Do not put your fingers or objects into the unit.
Location and handling
Do not install the unit in direct sunlight, near strong magnetic fields or in a place subject to dust or strong vibration.
Avoid a place with drastic temperature changes.
Install the unit in a horizontal and stable position. Do not place anything directly on top or bottom of the unit.
Depending on your external devices, noise or disturbance of picture and/or sound may be generated if the unit is
placed too close to them. In this case, please ensure enough space between external devices and the unit.
Depending on the environment, the temperature of this unit may increase slightly. This is not a malfunction.
Be sure to remove the disc and unplug the AC power cord from the outlet before carrying the unit.
Dew condensation warning
Dew condensation may form inside the unit in the following conditions. If so, do not use this unit at least for a few
hours until its inside gets dry.
– The unit is moved from a cold place to a warm place.
– Under conditions of high humidity.
– After heating a cold room.
Notice for progressive scan use
Consumers should note that not all high definition television sets are fully compatible with this product and may
cause artifacts to be displayed in the picture. In case of picture problems with 525 (480) progressive scan output,
it is recommended that the user switch the connection to the ‘standard definition’ output. If there are questions
regarding your TV set compatibility with this 525p (480p) DVD player, please contact our customer service center.
EN 6
Notice
Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips N.V. or their
respective owners. P&F USA reserves the right to change products at any time without being obliged to adjust
earlier supplies accordingly. The material in this manual is believed adequate for the intended use of the system.
If the product, or its individual modules or procedures, are used for purposes other than those specified herein,
confirmation of their validity and suitability must be obtained. P&F USA warrants that the material itself does not
infringe any United States patents. No further warranty is expressed or implied. P&F USA cannot be held responsible
for any errors in the content of this document, or for any problems as a result of the content in this document. Errors
reported to P&F USA will be adapted and published on the P&F USA support website as soon as possible.
Warranty
No components are user serviceable. Do not open or remove covers to the inside of the product. Repairs may only
be done by service centers and official repair shops. Failure to do so shall void any warranty, stated or implied. Any
adjustments or assembly procedures not recommended or authorized in this manual, or any operation expressly
prohibited in this manual shall void the warranty.
Important
Registering your model with Philips makes you eligible for all of the valuable benefits listed below, so don’t miss out.
Register online at www.philips.com/support to ensure:
Product safety notification
By registering your product you receive notification - directly from the manufacturer - in the rare case of a product
recall or safety defect.
Additional benefits of product ownership
Registering your product guarantees that you receive all of the privileges to which you’re entitled, including special
money-saving offers.
For further assistance
For further assistance, call the customer support service in your country.
To obtain assistance in the U.S.A., Canada, Puerto Rico, or the U.S. Virgin Islands, contact Philips Customer Care
Center at 1- 866-515-1124
Environmental care
The packaging of this product is intended to be recycled. Contact your local authorities for information
about how to recycle the packaging. For product recycling information, please visit
- www.recycle.philips.com
Disposal of used batteries
The batteries included do not contain the heavy metals mercury and cadmium, however in certain localities,
disposing batteries with household waste is not permitted. Please ensure you dispose of batteries according to local
regulations.
1.2. Included accessories
• Quick Start Guide
• Remote control (NC271UL)
• Batteries (AAA, 1.5V x 2)
EN 7
2. FEATURES
2.1. Features
Blu-ray Disc™
You can enjoy Blu-ray Disc™ which is capable of storing
five times more data than a conventional DVD.
BD-Java
With some Blu-ray™ discs which contain Java
applications, you can enjoy interactive functions such
as games or interactive menus.
DVD upscaling for enhanced picture quality
Your current DVD will look even better than before
thanks to video upscaling. Upscaling will increase the
resolution of standard definition DVD to high definition
up to 1080p over an HDMI connection. The picture
will be less jagged and more realistic for a near high
definition experience.
Enjoy your content on different kinds of media
Full backwards compatibility with DVD, CD and USB
memory stick ensures that you can continue to enjoy
your current audio-video collection. Additionally, you
can enjoy AVCHD (for DVD-RW/-R only) / JPEG files.
Listen to rich multi-channel surround sound
Multi-channel surround sound, which realizes real-to-
life sound and makes you feel that you are really there.
Easy and simple connection to your HDTV via HDMI
Connect this unit to your HDTV with one single HDMI
(High-Definition Multimedia Interface) cable. It is
recommended to use a high speed HDMI cable for
better compatibility. The high definition video output
signal will be transferred to your HDTV without
conversion to analog signals, so you will get excellent
picture and sound quality, completely free from noise.
HDMI CEC (Consumer Electronics Control)
This unit supports HDMI CEC, which allows integrated
system control over an HDMI cable and is part of the
HDMI standard. This function may not work properly on
some devices.
PiP (BONUSVIEW™)
Some BD-videos have the PiP function which enables
you to display the secondary video in the primary
video. You can call up the secondary video by pressing
[OPTIONS] whenever the scene contains a secondary
video.
Pop menu
Some BD-videos have a pop menu which is a navigation
menu that can be called up and be operated on the TV
screen without interrupting playback. You can call up
the pop menu by pressing [DISC MENU]. Contents in
the pop menu vary depending on the disc.
HDMI 1080p/24 output (Blu-ray Disc™ only)
This unit is equipped with the feature which can provide
smooth movement during playback of film originated
material with a frame rate of 24 frames per second with
progressive. (Available only when the display device is
connected with an HDMI cable.) Refer to ˝HDMI video
resolution˝ on page 34.
Playing back contents from a USB memory stick
You can play back JPEG files stored on a USB memory
stick. BD-ROM discs sometimes store picture-in-
picture commentary, subtitles or other extras on a USB
memory stick for use during playback with the BD-
video.
Playing back AVCHD files
This unit supports playback of AVCHD format files (new
format for high definition video camcorders) recorded
on a disc / SD memory card using USB card reader /
USB hub (not included). Your high definition personal
archive is playable in HD quality.
x.v.Color
This unit supports playback of video contents on
discs recorded with ˝x.v.Color˝ technology. To watch
this video content with the ˝x.v.Color˝ space, a TV or
other display device supporting both video image
reproduction using ˝x.v.Color˝ standard and capability
of manual switching of its color space setting is
required. Please refer to the user manual of your
display device for further information.
EN 8
2.2. Version info
˝Version Info˝ screen provides information about this unit’s software version.
You can also download the latest software from the Philips website and update it yourself if it is newer than the
version currently on your unit. The current version of software on your unit can be seen on the ˝Version Info˝ screen.
To access ˝Version Info˝, follow the procedure below.
1. Press [Q(HOME)].
2. Use [
] to select ˝Setup˝, then press [OK].
3. Use [
] to select ˝Advanced Setup˝, then press [OK].
4. Use [
] to select ˝Version Info˝, then press [OK].
2.3. Symbols used in this owner’s manual
To specify which media type each function is applicable to, a combination of the symbols shown below will be
depicted next to that function's explanation.
Symbol Description
[BD Video]
Description refers to BD-video
[DVD Video]
Description refers to DVD-video
[CD]
Description refers to audio CD / DTS-CD
[AVCHD]
Description refers to DVD-RW/-R with AVCHD files
[JPEG]
Description refers to BD-RE/-R, DVD-RW/-R, CD-RW/-R and USB memory Stick with JPEG files
If you do not find any of the symbols listed above under the function heading, the operation is applicable to all
media types.
EN 9
3. FUNCTIONAL OVERVIEW
3.1. Front panel
1 3 4*2 5 6
* The unit can also be turned on by pressing this button.
1. Disc tray
2. Power-On indicator
3. Infrared sensor window
4.
(OPEN/CLOSE) button*
5.
(POWER) button
6. USB input
CautionC
• Do not connect any device other than USB memory stick or USB card reader into the USB Input. (e.g. PC,
external HDD, digital camera, keyboard, mouse, etc.)
• When connecting a USB memory stick, connect it directly to the USB input. Do not use a USB extension cable.
NoteD
• Due to new ENERGY STAR
®
requirements, this unit will automatically turn on the screen saver after 5 minutes of
inactivity and enter standby mode after 25 minutes of inactivity.
3.2. Rear panel
1 2
1. AC power cord 2. HDMI OUT jack
CautionC
• Do not touch the inner pins of the jacks on the rear panel. Electrostatic discharge may cause permanent
damage to the unit.
• This unit does not have a TV RF modulator.
EN 10
3.3. Remote control
1
11
13
3
4
10
12
14
5
6
*7
15
16*
8
9
2
* The unit can also be turned on by pressing these
buttons.
1.
(POWER) button
• Press to turn on the unit, or to switch the unit into
standby mode. (To completely turn off the unit,
you must unplug the AC power cord.)
2.
(HOME) button
• Press to display the home menu.
3. DISC MENU button
• During playback (Blu-ray Disc™ or DVD), press to
select the menu (top menu or pop menu/menu).
4.
buttons
• Press to select items or settings.
5. INFO button
• Press to display the on-screen display menu.
6.
(REVERSE) button
• During playback, press to fast reverse the
playback.
7.
(PLAY/PAUSE) button*
• Press to start playback or resume playback.
• Press to pause playback.
8.
(SKIP) button
• During playback, press once to return to the
beginning of the current title, chapter, track or file.
• During playback, press twice to return to the
previous title, chapter, track or file.
• During JPEG playback, press to return to the
previous file.
9.
(STOP) button
• Press to stop playback.
10. RED / GREEN / YELLOW / BLUE buttons
• Press to activate shortcut keys on some BD-video
functions. When a file list is shown, press to
switch between pages.
11. OPTIONS button
• During playback, press to display the play menu.
12. OK button
• Press to confirm or select menu items.
13. BACK button
• Press to return to the previously displayed menu
or screen function.
14.
(FORWARD) button
• During playback, press to fast forward the
playback.
• When playback is in pause, press to slow forward
the playback.
15.
(SKIP) button
• During playback, press to skip to the next chapter,
track or file.
• When playback is in pause mode, press to
forward the playback picture by picture.
16.
(OPEN/CLOSE) button*
• Press to open or close the disc tray.
continued on next page
EN 11
NoteD
• Use the included remote control. Remote-control
operation on any other remote control, such as a
universal remote control, is not guaranteed.
C Installing the batteries in the remote control
Install 2 AAA (1.5V) batteries matching the polarity
indicated inside battery compartment of the remote
control.
1 2 3
CautionC
Incorrect use of batteries can result in hazards such
as leakage and bursting. Please follow the guidelines
below:
• Lithium or ni-cad and ni-mh rechargeable batteries
are not recommended to use for remote control.
• Do not mix different types of batteries such as
alkaline and standard (carbon-zinc).
• Do not mix new and old batteries together.
• Do not use different kinds of batteries together.
Although they may look similar, different batteries
may have different voltages.
• Make sure that the + and - ends of each battery
match the indications in the battery compartment.
• Remove batteries from battery compartment, when
the remote is not going to be used for a month or
more.
• When disposing of used batteries, please comply
with governmental regulations or environmental
public rules that apply in your country or area.
• Do not recharge, short-circuit, heat, burn or
disassemble batteries.
C Using the remote control
Remote control usage guidelines:
• Make sure that there are no obstacles between the
remote control and the infrared sensor window on
the unit.
• Remote operation may become unreliable if strong
sunlight or fluorescent light is shining on the infrared
sensor window of the unit.
• Remote controls of different devices can interfere
with each other. Avoid using a remote control from
another device which is located close to the unit.
• Replace the batteries when you notice a fall-off in
the operating range of the remote control.
• The maximum operable ranges from the unit are as
follows.
- Line of sight:
approx. 23 feet (7 m)
- Either side of the center:
approx. 16 feet (5 m) within 30°
- Above:
approx. 16 feet (5 m) within 15°
- Below:
approx. 10 feet (3 m) within 30°
30˚ 30˚
16 feet (5 m) 23 feet (7 m) 16 feet (5 m)
EN 12
3.4. Guide to on-screen display
C Home menu
When you turn on the unit, the home menu will appear automatically. Otherwise, press [ (HOME)].
Play Disc
Browse USB Setup
1
2
3
1. ˝Play Disc˝: Initiates playback of inserted disc, displays a list of tracks / files or the media filter menu
2. ˝Browse USB˝: Displays a list of tracks / files on the connected USB memory stick or the media filter menu
3. ˝Setup˝: To access the setup menu
C Setup menu
Video Setup
Audio Setup
EasyLink Setup
Preference Setup
Advanced Setup
TV Display
HDMI Video
De-interlacing Mode
•
16:9 Widescreen
•
Auto
•
Auto
Video Setup
1
2
1. Category
2. Menus / Options: Displays options for the highlighted item on the left whenever available
C Play menu
During playback, press [OPTIONS] to display the play menu.
e.g.) Blu-ray Disc™
Search
Audio
Subtitle
Repeat
Noise Reduction
CLEAR+
Search
EN 13
4. CONNECTIONS
4.1. Connection to a TV
C HDMI connection (Supports up to 1080i(
*
1), 1080p(
*
2), 1080p/24(
*
3) resolution.)
HDMI IN
Your TV
HDMI cable
(not included)
(*1) 1080i: Outputs video data with a frame rate of 30 frames per second.
(*2) 1080p: Outputs video data with a frame rate of 60 frames per second.
(*3) 1080p/24: Outputs video data with a frame rate of 24 frames per second.
• Do not tilt the connector when inserting it into the HDMI jack, and make sure the shapes of the jack and the
connector are matched.
• When connected to an HDCP incompatible display device, the picture will not be displayed properly.
• Use an HDMI cable with the HDMI logo (a certified HDMI cable) for this connection. high speed HDMI cable (also
known as HDMI category 2 cable) is recommended for better compatibility.
NoteD
• If the TV receives no audio / video signal after properly connecting the unit and the TV with an HDMI cable, it
may be the TV. Please refer to the TV’s user’s manual.
• If the TV receives no audio signal after properly connecting the unit and the TV with an HDMI cable, make sure
the TV input is not an HDMI-DVI input terminal.
4.2. Connection to an audio system
• When you change the connections, all devices should be turned off.
• When connecting the unit to an external audio system, refer to the user manual for setup / configuration help.
C HDMI audio connection
HDMI IN
HDMI OUT
HDMI IN
AV receiver / amplier with
an HDMI input jack
HDMI cable
(not included)
HDMI cable
(not included)
Your TV
EN 14
4.3. HDMI audio output
˝HDMI Audio˝
setting A
˝Bitstream˝ ˝LPCM˝
˝Blu-ray Disc
Audio˝
setting A
"All" or
"Primary/
Secondary audio"
˝Primary Audio
Only˝
"All" or
"Primary/
Secondary Audio"
˝Primary Audio
Only˝
Media
È
Audio Source
È
Which audio format can be output depends on compatibility of the connected
device.
BD-video
Dolby Digital Dolby Digital or Downmix 2ch PCM Downmix 2ch PCM
Dolby Digital Plus
Dolby Digital
or
Downmix 2ch PCM
*
1
Dolby Digital Plus
or
Dolby Digital
or
Downmix 2ch PCM
*
1
Downmix 2ch PCM
*
1
Dolby TrueHD
Dolby Digital
or
Downmix 2ch PCM
*
2
Dolby TrueHD
or
Dolby Digital
or
Downmix 2ch PCM
*
2
Downmix 2ch PCM
*
2
DTS
®
DTS
®
or Downmix 2ch PCM Downmix 2ch PCM
DTS-HD
®
DTS
®
or
Downmix 2ch PCM
*
3
DTS-HD
®
or
DTS
®
or
Downmix 2ch PCM
*
3
Downmix 2ch PCM
*
3
LPCM Multi LPCM
DVD-video
Dolby Digital Dolby Digital or Downmix 2ch PCM Downmix 2ch PCM
DTS
®
DTS
®
or Downmix 2ch PCM Downmix 2ch PCM
MPEG Multi LPCM Multi LPCM
LPCM Multi LPCM
Audio CD LPCM 2ch LPCM
DTS-CD DTS
®
DTS
®
or Downmix 2ch PCM Downmix 2ch PCM
AVCHD
Dolby Digital Dolby Digital or Downmix 2ch PCM Downmix 2ch PCM
LPCM Multi LPCM
*1 ) Only Dolby Digital parts in Dolby Digital Plus Stream are decoded, then it will Downmix 2ch PCM.
*2) Only 2ch presentation parts in Dolby TrueHD Stream are decoded.
*3) Only the core substream is decoded.
NoteD
• If the connected device is not compatible with HDMI Bitstream, audio will be output as multi LPCM or
2-channel down-mixed LPCM depending on the capability of the connected device even if you select
˝Bitstream˝ in ˝HDMI Audio˝ setting.
• When playing back a BD-Video which only contains the primary audio, the audio output will be the same case
as ˝Primary Audio Only˝ even if the ˝Blu-ray Disc Audio˝ is set to ˝All˝ or ˝Primary/Secondary Audio˝.
• If “Blu-ray Disc Audio” is set to “All” or “Primary/Secondary Audio”, HD audio will not be output. In order to
enable the button sound feature, set “Blu-ray Disc Audio” to “All”. (The button sound setting may be found in the
pop menu.)
• In order to configure “HDMI Audio” in the “Audio Setup” settings, “Voice Guide” must be set to “Off”.
EN 15
5. BEFORE YOU START
5.1. Finding a viewing video source input on your TV
After you have completed all of the connections to your TV, review the steps below.
1. Press [ (POWER)] to Turn On the unit.
2. Turn On your TV.
3. Please locate the Source / Input / AUX / Video button on TV’s remote control. The button may vary
based on TV brand and model. Once you have located the button, press until you see welcome screen of
this unit.
5.2. Initial setup
Please follow the instructions below to complete the initial setup.
1. Language setup screen will appear. Use [ ] to select your language, then press [OK].
English
Espanol
Français
Please select your language
for on-screen display. If you
want to use the Voice Guide
function, please set to
"English" or "Español".
Por favor, seleccione su
idioma para el menú en
pantalla. Si desea usar la
función de Guía por voz,
ajuste "English" o "Español".
Veuillez choisir votre langue
pour l'achage à l'écran. Si
vous voulez utiliser la
fonction Guide vocal,
veuillez régler à «English»
ou «Español».
2. Voice guide setup screen will appear. Use [ ] to select ˝On˝ or ˝Off˝, then press [OK]
This screen will not appear when “Français” is selected under the “Menu Language” setting.
C How to reset the OSD language
You can reset the OSD language if you selected the wrong language.
1. Press [ (HOME)] to display the home menu.
2. Use [
] to select ˝ ˝, then press [OK].
• This item is ˝Setup˝ (English) / ˝Instalación˝ (Spanish) / ˝Installation˝ (French).
• From here on, please select one of the following items you can find on screen:
3. Use [ ] to select ˝Preference Setup˝ (English) / ˝Configuración de Preferencias˝ (Spanish) /
˝Configuration des préférences˝ (French), then press [OK].
4. Use [
] to select ˝Menu Language˝ (English) / ˝Menú Idioma˝ (Spanish) / ˝Langage du menu˝
(French), then press [OK].
5. Use [
] to select your desired language, then press [OK].
6. If the items that were set are displayed in your desired language, then press [
(HOME)] to exit.
EN 16
6. INFORMATION ON PLAYBACK
6.1. Information on playback
C Playable discs and files
Playable discs Logos
Blu-ray Disc™
- BD-video
- BD-RE* (ver. 2.1)
(Recorded in BDMV format)
- BD-R* (ver. 1.1 / 1.2 / 1.3)
(Recorded in BDMV format)
(Unfinalized disc may not be played back.)
DVD-video
DVD-RW
(finalized video mode discs only)
DVD-R
(finalized video mode discs only)
CD-DA (audio CD)
CD-RW
CD-R
DTS-CD -
(*) Due to the intentional progression of the Blu-ray Disc™ format by its standard setting authority, the company
cannot guarantee or warrant the playability of future extensions of the Blu-ray Disc™ format with this product.
Playable files Media
AVCHD
DVD-RW/-R
SD memory card using USB card reader / USB hub (not included)
JPEG
BD-RE/-R
DVD-RW/-R
CD-RW/-R
USB memory stick
Readable device Playable files / data
USB memory stick JPEG, picture-in-picture commentary, subtitles or other extras for some BD-ROM.
NoteD
• This unit may not be able to play back discs recorded on PC’s or other recorders.
continued on next page
EN 17
C Recommended specifications
AVCHD
This unit cannot play back stand-alone AVCHD files (*.m2ts, *.mts or *.m2t) written to a DVD or copied to an SD
memory card. The DVD or SD memory card containing AVCHD files must have a proper file and folder structure
meeting AVCHD format specifications. Please use AVCHD compliant device / software to burn or copy AVCHD files
to DVD or SD memory card. (Please refer to user manuals of your device / software for more information.)
JPEG
Resolution
• Upper limit: 4,096 x 4,096 dots (sub sampling is 4:4:4)
5,120 x 5,120 dots (sub sampling is up to 4:2:2 or 4:2:0)
• Lower limit: 32 x 32 dots
• Maximum file size of a picture: 12MB
C Folder / file number limitations
Blu-ray Disc™, DVD and USB memory stick
• 999 folders (groups) and 9,999 files
CD
• 255 folders (groups) and 999 tracks / files
Caution / note for USB memory stick
CautionC
• Do not try to open or modify the USB memory stick.
• Do not touch the terminal surface with your fingers or any metals.
NoteD
• This unit supports USB memory stick with FAT16 / FAT32 file system.
• This unit does not support NTFS file system.
• This unit may not read USB memory sticks formatted on a computer. If that is the case, please reformat the
USB memory sticks on this unit and try again. Please note that all files stored on the USB memory stick will be
erased upon format.
• Please keep the USB memory sticks in their cases when you are not using them.
• Some USB memory sticks may not work with this unit.
• This unit can read SD memory cards using a USB card reader (not included).
– Readable cards: SD memory card (8 MB - 2 GB)
miniSD memory card (16 MB - 2 GB)
microSD memory card (256 MB - 2 GB)
SDHC memory card (4 GB - 32 GB)
miniSDHC memory card (4 GB - 8 GB)
microSDHC memory card (4 GB - 16 GB)
– Readable files: AVCHD / JPEG
• Depending on the USB card reader or USB hub, connected card or device may not be recognized.
continued on next page
EN 18
C Unplayable media and files
The following discs will not be played back on this unit.
• CD-ROM • CD-I (compact disc-interactive)
• DVD-RAM • VSD (video single disc)
• DVD-audio • video CD
• HD DVD • SVCD
• SDXC memory card • microSDXC memory card
• unfinalized disc • BD-RE (ver. 1.0)
• BD-RE (ver. 2.1) (Recorded in BDAV format) • BD-R (ver. 1.1 / 1.2 / 1.3) (Recorded in BDAV format)
• B D X L™
• Blu-ray Disc™ / DVD / CD / USB memory stick / SD memory card containing DivX
®
files
• Blu-ray Disc™ / USB memory stick that contains AVCHD files
• Blu-ray Disc™ / DVD hybrid disc (played back as a BD-video only)
• DVD-RW/-R recorded in non compatible recording format
• Super Audio CD - Only the sound on the CD layer can be heard. The sound on the high-density Super Audio CD
layer cannot be heard.
• Playability of dual discs is not guaranteed.
• This unit cannot play back the disc contents protected by Windows Media™ Digital Rights Management (DRM).
C Region codes
This unit has been designed to play back BD-video with region ˝A˝ and DVD-video with
region ˝1˝ or ˝ALL˝. You cannot play back BD-video or DVD-video that is labeled for other
regions.
Look for the symbols on your BD-video or DVD-video. If these region symbols do not
appear on your BD-video or DVD-video, you cannot play back the disc on this unit. The
letter or number inside the globe refers to region of the world. BD-video or DVD-video discs
labeled for a specific region can only be played back on players with the same region code.
BD-video
DVD-video
C Hint for disc playback
The contents of a disc are generally divided into sections or folders (group of titles / files) as shown below.
BD-video, DVD-video, AVCHD
Audio CD
Track 1 Track 2 Track 3 Track 4 Track 5
Title 1
Chapter 1 Chapter 2 Chapter 1 Chapter 2 Chapter 3
Title 2
JPEG
File 1 File 2 File 3 File 4 File 5
folder (group) 1 folder (group) 2
continued on next page
EN 19
C Description for icons
[ ] : group (folder) icon
[
] : music file icon
[
] : photo file icon
- ˝Folders˝ refers to the group of files.
- ˝Track˝ refers to the contents recorded on the audio CD.
- ˝Files˝ refers to the contents on a disc which are recorded in AVCHD or JPEG file format.
NoteD
• Unrecognizable characters will be replaced with asterisks.
6.2. Guide to file list
C Picture file list
Page DownPage Up Media Mode
Folder_001 Folder_002
Thumbnail
Track 1/45
06051_1140
CD
DATA
Folder_001
1 2
3
4
1. Current file number / total number of files
2. Playback status symbol
3. Media type
4. Group (folder) / file list (thumbnails)
C How to navigate through the file list
• For picture file list, use [ ] to move the highlight up, down, left and right. Press
[BACK] to go back to the previous hierarchy.
• To access the files in a group (folder), select the desired group (folder), then press [OK].
• Press [RED] or [GREEN] to change the page list up or down.
• Press [BLUE] to go back to the file type (˝Photo˝ / ˝AVCHD˝) selection screen.
• Press [ (HOME)] to exit.
6.3. How to insert a disc
1. Press [ (OPEN/CLOSE)] to open the disc tray.
2. Place the disc on the disc tray with its label side facing up.
3. Press [
(OPEN/CLOSE)] to close the disc tray.
• It may take a while to load the disc.
Align the disc to the disc tray guide.
EN 20
7. BASIC PLAYBACK
7.1. Playing back a disc
[BD Video]
[DVD Video]
[CD]
[AVCHD]
[JPEG]
1. Insert a disc (refer to ˝How to insert a disc˝ on page 19).
• For Blu-ray Disc™ / DVD / audio CD or a disc containing only one type of file, playback will start automatically.
If not, press [ (PL AY/PAUS E)].
• Some discs may show a title or a disc menu. In this case, refer to ˝Using the title / disc / pop menu˝ on page 22.
2. Select the type of the file you want to play back, then press [OK].
AVCHD
a
b
a. For ˝Photo˝, thumbnail screen will appear.
• Refer to ˝Picture file list˝ on page 19 and ˝How to navigate through the file list˝ on page 19.
b. For ˝AVCHD˝, playback will start automatically.
To skip to the next title / chapter / track / file: Press [
(SKIP)].
To skip to the previous title / chapter / track / file: Press [
(SKIP)].
To pause playback: Press [
(PLAY/PAUSE)].
To return to normal playback: Press [
(PLAY/PAUSE)].
To stop playback: Press [
(STOP)].
Playback will be in resume-on-stop mode. To clear the resume information, press [
(STOP)] again.
C Resume-on-stop mode
Blu-ray Disc™ / DVD / AVCHD
When you press [ (PL AY/PAUSE)] next time, playback will start from the point where it had been stopped.
Audio CD
Playback will start from the point where it was stopped next time you press [ (PL AY/PAUSE)]. If you press [OK]
instead of [ (PL AY/PAUSE)], playback will start from the beginning of the track / file instead of resuming from
the stop point.
JPEG
Playback will start from the beginning of the current file next time you press [ (PL AY/PAU SE )] or [OK].
NoteD
• Playback will also stop and the home menu will appear when you press [ (HOME)].
• For BD-Java application, the resume-on-stop may not be available.
• If you press [OK] instead of [ (PL AY/PAUS E)], playback can be started from the beginning of the disc even if it
was in the resume-on-stop mode.
• Resume-on-stop mode remains in effect even after power is turned off, but will be cancelled once the disc is
ejected.
• With regard to the multi-border BD-RE/-R, additionally recorded sections cannot be recognized.
• With regard to the multi-border DVD-RW/-R, additionally recorded sections may not be recognized.
continued on next page
EN 21
NoteD for JPEG playback
• Every press of [ ] will turn the image by 90 degrees when an image is displayed.
• During playback, press [DISC MENU] to display thumbnail screen.
• Some unplayable folders or files may be listed due to the recording status.
• High-resolution JPEG files take longer to be displayed.
• Progressive JPEG files (JPEG files saved in progressive format) cannot be played back on this unit.
7.2. Playing back contents from a USB memory stick
[JPEG]
You can play back JPEG files stored on a USB memory stick. With the USB memory stick, you can also enjoy the
following functions.
• Special additional contents for BD-ROM.
(For more information about the special additional contents, refer to the instruction book that came with the disc.)
1. Connect a USB memory stick.
2. Press [
(HOME)].
3. Use [
] to select ˝Browse USB˝, then press [OK].
4. Follow step 2 in ˝Playing back a disc˝ on page 20.
CautionC
• Do not disconnect the USB memory stick or switch the unit to standby mode while contents on the USB memory
stick are being accessed. It may result in malfunction or loss of the stick's data.
• If you connect a USB memory stick or SD memory card via a USB card reader or USB hub, BD-ROM data will
be written onto the first connected card or device. Connecting a USB memory stick directly to this unit is
recommended.
• Occasionally, SD memory cards / Micro SD memory cards will not be recognized when using certain adapters.
In such cases, try a different USB adapter.
NoteD
• When connecting more than two USB memory sticks to a USB hub, this unit may fail to recognize them. In such
cases, disconnect the USB hub from the unit then reconnect it, or use less USB memory sticks at a time.
• The resume information will be cleared when;
- [ (STOP)] is pressed while in resume-on-stop mode.
- the USB memory stick is disconnected.
- the unit is switched to standby mode.
• Do not delete folders or files on the USB memory stick with your computer. This unit may not read USB memory
sticks formatted on a computer.
• If a folder or file name includes one of the following unrecognizable characters, the folder or file name may not
be displayed correctly.
- Unrecognizable characters:
. , " = + [ ] ; / \ : | ¥
• This unit can read JPEG files and AVCHD on an SD memory card by using USB card reader / USB hub (not
included).
EN 22
7.3. Using the title / disc / pop menu
[BD Video]
[DVD Video]
[AVCHD]
Some BD-videos, DVD-videos or AVCHD files may contain a title menu which describes the contents of the disc, or
a disc menu which guides you through the available functions on the disc.
• With such discs, a title menu or a disc menu may appear automatically when you insert the disc. Otherwise, press
[DISC MENU] to call up the menu select menu. Use [ ] to select ˝Top Menu˝ or ˝Pop-up menu/menu˝, then
press [OK]. Refer to the disc’s manual on how to navigate through the menu.
e.g.) Blu-ray Disc™
Pop-up Menu
Top Menu
Pop-up Menu
NoteD
• Menus vary among discs. Refer to the information accompanying the disc for details.
• [DISC MENU] may not work with some discs.
EN 23
8. SPECIAL PLAYBACK
8.1. Fast forward / fast reverse
[BD Video]
[DVD Video]
[CD]
[AVCHD]
1. During playback, press [ (FORWARD)] repeatedly for fast forward.
During playback, press [
(REVERSE)] repeatedly for fast reverse.
2. Press [
(PL AY/PAUSE)] to return to Normal playback.
NoteD
• For Blu-ray Disc™, DVD and AVCHD, speed changes at 5 different levels.
• For audio CD, speed changes at 3 different levels.
• For audio CD, fast forward / fast reverse search between different files are not available.
8.2. Slow forward playback
[BD Video]
[DVD Video]
[AVCHD]
1. During playback, press [ (PL AY/PAUSE)]. Then press [ (FORWARD)].
Every time you press [
(FORWARD)], the playback speed changes at 3 different levels.
2. Press [
(PL AY/PAUSE)] to return to normal playback.
NoteD
• Slow reverse is not available.
8.3. Step by step playback
[BD Video]
[DVD Video]
[AVCHD]
1. In pause mode, press [ (SKIP)] repeatedly.
Every time you press [
(SKIP)], playback will advance one step at a time.
2. Press [
(PL AY/PAUSE)] to return to normal playback.
NoteD
• Step by step reverse is not available.
EN 24
8.4. Repeat playback
Available repeat functions vary depending on the disc.
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select ˝Repeat˝ then press [OK].
3. Use [
] to select the desired repeat mode.
REPEAT MODE AVAILABLE MEDIA
Chapter repeat
[BD Video]
[DVD Video]
[AVCHD]
The current chapter will be played back repeatedly.
Title repeat
[BD Video]
[DVD Video]
[AVCHD]
The current title will be played back repeatedly.
Track repeat
[CD]
[JPEG]
The current track or file will be played back repeatedly.
All repeat
[CD]
All tracks in the media will be played back repeatedly.
Group repeat
[JPEG]
The current group (folder) will be played back repeatedly.
Random repeat
[CD]
[JPEG]
Repeats the random playback. (CD)
Repeats the random playback in a folder. (JPEG)
4. Press [BACK] to exit.
NoteD
• The repeat setting will be cancelled when you stop playback.
• When the repeat setting is set for an JPEG folder (file), the repeat setting will be cancelled if you select another
JPEG folder (file) to play back.
8.5. Slide show
[JPEG]
1. Follow steps 1 and 2 in ˝Playing back a disc˝ on page 20.
2. Open the folder which contains the desired JPEG files.
3. Use [
] to select a desired file to be played back, then press [ (PL AY/PAUSE)] or [OK].
• An image will be played back from the selected file and go to the next one in turn every 10 seconds.
4. Press [ (STOP)] to stop playback.
• When you press [DISC MENU] in the stop mode, the highlight goes back to the first item.
• When you press [DISC MENU] in the resume-on-stop mode, the highlight goes back to the file played last.
NoteD
• Large-size JPEG files take time to load before being displayed on the screen.
EN 25
8.6. PiP (BONUSVIEW™) setting
[BD Video]
Some BD-videos have the PiP function which enables you to display the secondary video in the primary video.
PiP 1 / 8
Primary video
Secondary video
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select ˝PiP˝ then press [OK].
• PiP information will appear.
3. Use [ ] to select the secondary video you want to show.
• The secondary video will be displayed with secondary audio.
• Use [ ] to switch between current setting and ˝Off˝.
4. Press [BACK] to exit.
• To select the secondary audio output, refer to ˝Switching audio soundtrack˝ on page 29.
NoteD
• Secondary video may not be displayed all the time, depending on the scene, it may or may not be available for
display.
EN 26
8.7. Title / chapter search
[BD Video]
[DVD Video]
[AVCHD]
C Using [ (SKIP)] / [ (SKIP)]
1. During playback, press [ (SKIP)] to skip the current title or chapter and move to the next.
The title or chapter will move forward one at a time.
• If there is no chapter in a title, the current title may be skipped.
To go back to the beginning of the current title or chapter, press [ (SKIP)].
Press [ (SKIP)] repeatedly to go to the previous title or chapter. The title or chapter may move backward one
at a time.
C Using ˝Search˝
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select ˝Search˝, then press [OK].
3. Use [
] to select ˝Title˝ or ˝Chapter˝, then press [OK].
e.g.) Blu-ray Disc™
Search 1 / 999
Title
4. Use [ ] to select the title / chapter number, then press [OK].
Playback will start from the beginning of the title / chapter.
NoteD
• As for BD-video, how it performs is strongly determined by the disc, and may not perform as described.
• For DVD, title search can be performed on the home menu by pressing [OPTIONS] while in stop mode or
resume-on-stop mode.
8.8. Track / file search
[CD]
[JPEG]
C Using [ (SKIP)] / [ (SKIP)]
1. During playback, press [ (SKIP)] to skip the current track or file and move to the next.
The track / file will move forward one at a time. To go back to the beginning of the current track / file, press
[ (SKIP)].
Press it repeatedly to go to the previous track / file. The track / file will move backward one at a time.
C Using ˝Search˝
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select ˝Search˝, then press [OK].
• For JPEG files, skip to step 4.
3. Use [ ] to select ˝Track˝, then press [OK].
4. Use [
] to select the track number, then press [OK].
Playback will start from the beginning of the track.
EN 27
8.9. Time search
[BD Video]
[DVD Video]
[CD]
[AVCHD]
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select ˝Search˝, then press [OK].
3. Use [
] to select ˝Time˝, then press [OK].
e.g.) Blu-ray Disc™
Search 00:12:44 / 11:13:14
Time
4. Enter the time count you want to jump to.
• Use [ ] to enter the first digit of the time counter, then press [ ].
• When the last digit is entered, press [OK].
Playback will start from the desired time entered.
8.10. Number select search
[BD Video]
[DVD Video]
[AVCHD]
Some BD-videos and DVD-videos or AVCHD files have button menus to jump to each button displayed scene.
During playback the scenes which have the button menu, you can enter the button number by using the number
select menu.
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select ˝Number˝, then press [OK].
e.g.) Blu-ray Disc™
Number
0000
• For BD-Java, a single-digit number select menu is displayed.
• For DVD, a double-digit number select menu is displayed.
• For BD-videos and AVCHD files, the number select menu is displayed even if there is no button menu in the
scene.
3. Use [ ] to enter the number you want to jump to.
• To move to the digit you wish to change, press [ ] .
4. After all digits are entered, press [OK].
Playback of the selected scene will start.
NoteD
• As for the BD-video, how it performs is strongly determined by the disc, and may not perform as described.
EN 28
8.11. Switching subtitles
Some video materials may have subtitles in one or more languages. For commercially available discs, the
supported languages can be found on the disc case. Follow the steps below to switch the subtitle language during
playback.
[BD Video]
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select ˝Subtitle˝, then press [OK].
3. Use [
] to select ˝Primary˝, ˝Secondary˝ or ˝Style˝, then press [OK].
˝Primary˝: Sets the subtitle for primary video.
˝Secondary˝: Sets the subtitle for secondary video.
˝Style˝: Sets style of the subtitle.
4. Use [ ] to select your desired subtitle or style.
Subtitle Primary
Secondary
Style
1 ENG / 3
O
O
• Use [ ] to switch between current subtitle setting and ˝Off˝.
5. Press [BACK] repeatedly to exit.
[DVD Video]
[AVCHD]
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select ˝Subtitle˝, then press [OK].
3. Use [
] to select your desired subtitle.
Subtitle 1 ENG / 32
• Use [ ] to switch between current subtitle setting and ˝Off˝.
4. Press [BACK] to exit.
NoteD
• Some discs will only allow you to change the subtitles from the disc menu or pop menu. Press [DISC MENU] to
select the ˝Top Menu˝ or ˝Pop-up Menu˝ (or ˝Menu˝).
• If the disc has no subtitle language or subtitle style, ˝Not Available˝ will be displayed on the TV screen.
• During playback of the secondary video, the primary subtitle setting is not available except when there is no
subtitle for the secondary video.
EN 29
8.12. Switching audio soundtrack
When playing back video material recorded with two or more soundtracks (these are often in different audio
languages or audio formats), you can switch between them during playback. For Blu-ray Disc™, available audio
varies depending on ˝Blu-ray Disc Audio˝ setting. Refer to page 31.
[BD Video]
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select ˝Audio˝, then press [OK].
3. Use [
] to select ˝Primary˝ or ˝Secondary˝, then press [OK].
˝Primary˝: Sets the audio for primary video.
˝Secondary˝: Sets the audio for secondary video.
4. Use [ ] to select your desired audio stream channel.
Audio Primary
Secondary
1 ENG DD Multi-ch /3
1 ENG DTS Multi-ch /3
[Decoding Format] : Dolby Audio - Dolby Digital
• For ˝Secondary˝, use [ ] to switch between current audio setting and ˝Off˝.
5. Press [BACK] repeatedly to exit.
[DVD Video]
[CD]
[AVCHD]
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select ˝Audio˝, then press [OK].
3. Use [
] to select your desired audio stream channel.
Audio 1 ENG DD Multi-ch /3
[Decoding Format] : Dolby Audio - Dolby Digital
• For audio CD, you can select following options.
˝Stereo˝: Both right and left channels are active (stereo).
˝L-ch˝: Only left channel is active.
˝R-ch˝: Only right channel is active.
4. Press [BACK] to exit.
NoteD
• Secondary audio will not be output when secondary video is not displayed or when ˝Blu-ray Disc Audio˝ is set
to ˝Primary Audio Only˝. (For some Blu-ray™ discs, secondary audio will be output even when secondary video
is Off.)
• Sound mode cannot be changed during playback of discs not recorded in multiple audio mode.
• Some discs allow changing the audio language setting from disc menu. (Operation varies depending on the
discs. Refer to the manual accompanying the disc.)
• ˝Audio˝ may not work on some discs with multiple audio streams or channels (e.g. DVDs that allow changing
audio setting on the disc menu).
• If the disc has no audio language, ˝Not Available˝ will be displayed on the TV screen.
• For DTS-CD (5.1 music disc), selecting audio streams or channels is not available.
EN 30
8.13. Switching camera angles
[BD Video]
[DVD Video]
Some BD-videos and DVD-videos contain scenes which have been shot simultaneously from various angles. You
can change the camera angle when appears on the TV screen.
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select ˝Angle˝, then press [OK].
3. Use [
] to select your desired angle.
• The selected angle will be displayed on the display bar at the top of the TV screen.
4. Press [BACK] to exit.
NoteD
• If ˝Ang le Ico n˝ setting is set to ˝Off˝, will not appear on the TV screen.
8.14. Noise reduction
[BD Video]
[DVD Video]
[AVCHD]
Reduces the noise of the playback picture.
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select ˝Noise Reduction˝, then press [OK].
3. Use [
] to select your desired setting.
e.g.) Blu-ray Disc™
Noise Reduction
O
˝On˝: Activates noise reduction.
˝Off˝: Deactivates noise reduction.
4. Press [BACK] to exit.
NoteD
• The setting will remain the same even if the unit is switched to standby mode.
8.15. CLEAR+
[BD Video]
[DVD Video]
[AVCHD]
CLEAR+ enhances the contrast of the picture and makes edges crisp. It is effective especially for DVD’s.
1. During playback, press [OPTIONS] to display the play menu.
2. Use [
] to select ˝CLEAR+˝, then press [OK].
3. Use [
] to select your desired setting.
e.g.) Blu-ray Disc™
CLEAR+
O
˝On˝: Gives low-definition videos high-definition like picture quality.
˝Off˝: Shows the original picture as recorded.
4. Press [BACK] to exit.
NoteD
• Pictures may appear whiter depending on the material and the connected TV. In this case, turn ˝CLEAR+˝ Off.
• ˝CLEAR+˝ is not effective under the following conditions.
- When the material is in 1080p/24 which is commonly used in Blu-ray™ discs.
EN 31
In ˝Setup˝, you can customize various kinds of settings as you prefer.
Refer to the following instructions to navigate through the setup menu.
1. Press [ (HOME)] to access the home menu.
2. Use [
] to select ˝Setup˝, then press [OK].
3. Use [
] to select the desired category, then press [OK].
4. Use [
] to move up and down the list to select menus / options.
5. To make a selection or to access options of an item, select the desired item, then press [OK].
• To go back to the previous screen, press [BACK].
6. Press [ (HOME)] to exit.
Refer to the following table for the types of settings you can customize.
The item highlighted in gray is the default setting.
Category Menus / Options
Video Setup TV Display 4:3 Normal
4:3 Crop
16:9 Widescreen
16:9 Squeeze
HDMI Video Auto
480p
720p
1080i
1080p
1080p/24
De-interlacing Mode Auto
Video
Audio Setup Voice Guide On
Off
Night Mode Auto
On
Off
HDMI Audio Bitstream
LPCM
Blu-ray Disc Audio All
Primary/Secondary Audio
Primary Audio Only
EasyLink Setup EasyLink On
Off
One Touch Play On
Off
One Touch Standby On
Off
Preference Setup Menu Language Auto
English
Español
Français
9. LIST OF SETTINGS
continued on next page
EN 32
Category Menus / Options
Preference Setup Audio Original
Bulgarian Italian
Chinese Japanese
Czech Korean
Danish Norwegian
Dutch Polish
English Portuguese
Finnish Romanian
French Russian
German Slovak
Greek Spanish
Hungarian Swedish
Icelandic Turkish
Irish Other
Subtitle Off
Bulgarian Italian
Chinese Japanese
Czech Korean
Danish Norwegian
Dutch Polish
English Portuguese
Finnish Romanian
French Russian
German Slovak
Greek Spanish
Hungarian Swedish
Icelandic Turkish
Irish Other
Disc Menu Bulgarian Italian
Chinese Japanese
Czech Korean
Danish Norwegian
Dutch Polish
English Portuguese
Finnish Romanian
French Russian
German Slovak
Greek Spanish
Hungarian Swedish
Icelandic Turkish
Irish Other
Parental Control Off
8 [Adult] 4 [PG-13]
7 [NC-17] 3 [PG]
6 [R] 2 [G]
5 [PGR] 1 [Kid Safe]
Change Password
Screen Saver On
Off
Angle Icon On
Off
Advanced Setup Software update Disc
USB
Version Info
Restore default settings Reset Settings
Format USB
(Unit) Erase Saved BD-ROM Data
(USB) Erase Saved BD-ROM Data
Reset All Settings
OSS
EN 33
10. SETUPS
10.1. EasyLink (HDMI CEC)
HOME A ˝Setup˝ A ˝EasyLink Setup˝ A ˝EasyLink˝
EasyLink(HDMI CEC) allows integrated system control over HDMI and is part of the HDMI standard. This function
may not work properly depending on the device connected to the unit. When ˝EasyLink˝ setting is set to ˝On˝ the
functions listed below will be available.
C One touch play
When the buttons below are pressed then operations are performed on this unit, the TV will automatically be
turned on and switched to the appropriate video Source Input.
Buttons for one touch play:
• [ (PL AY/PAU SE)], [ (SKIP)], [ (SKIP)], [ (HOME)] (on the remote control)
• [DISC MENU] (on the remote control when the a disc is inserted in the unit)
C One touch standby
When you press and hold [ (POWER)] for 2 seconds, it turns off the TV first and then turns off the power on this
unit.
When the connected HDMI CEC compatible display device is turned off first, then it turns off the power to this unit.
C System information
Get & set menu language
The unit recognizes the OSD language set on the TV and automatically sets the same language as the player menu
language (OSD menu language) for this unit. Go to ˝Menu Language˝ under ˝Preference Setup˝ on page 31 to
see available languages.
• Feature is available only when ˝Auto˝ is selected in the setup menu ˝Menu Language˝ section in ˝Setup˝ while
connected via an HDMI cable.
EN 34
10.2. HDMI video resolution
HOME A ˝Setup˝ A ˝Video Setup˝ A ˝HDMI Video˝
Set the resolution of the video signal being output from the HDMI OUT jack.
You can select the desired video resolution among the settings listed below: ˝Auto˝, ˝4 8 0 p˝, ˝720p˝, ˝1080i˝, ˝1080p˝,
˝1080p24˝.
Actual output resolution:
Setting in the
˝HDMI Video˝
Source
480i/60 480p/60 720p/60 1080i/60 1080p/60 1080p/24
Auto The highest resolution supported by your display device will automatically be in effect.
480p 480p/60
720p 720p/60
1080i 1080i/60
1080p 1080p/60
1080p/24 1080p/60 1080p/24
• For AVCHD, outputting the video in 24 frames per second (1080p/24) is not available.
NoteD
• The selected resolution must also be supported by your display device.
• If your TV and the unit are connected by a DVI cable and if ˝Auto˝ is selected, ˝4 8 0 p ˝ will be automatically in
effect.
• Refer also to your TV’s manual.
• When connected to an HDCP incompatible display device, the picture will not be displayed properly.
• The audio signals from the HDMI OUT jack (including the sampling frequency, the number of channels and bit
length) may be limited by the connected device.
• Among the display devices that support HDMI, some do not support audio output (for example, projectors).
While connected to a device such as a projector, audio will not be output from the HDMI OUT jack.
• When this unit’s HDMI OUT jack is connected to a DVI-D compatible display device(s) (HDCP compatible) with an
HDMI-DVI converter cable, the signals are output in digital RGB.
• HDMI video resolution does not work during playback of a BD-video.
Copyright protection system
To play back digital video images of a BD-video or DVD-video via an HDMI connection, it is necessary that
both the player and display device (or an AV receiver / amplifier) support a copyright protection system called
HDCP (high-bandwidth digital content protection system). HDCP is copy protection technology which prevents
copying or playback of encrypted content when connected to a non-HDCP compliant AV device. This unit
supports HDCP. Please read the operating instructions of your display device (or an AV receiver / amplifier) for
more information.
EN 35
10.3. Parental control
Some BD-videos or DVD-videos feature parental lock levels. Playback will stop if the ratings of the content exceed
the levels you set on the player, it will require you to enter a password before the disc will play back. This feature
prevents your children from viewing inappropriate material.
1. Enter your 4-digit password.
• Use [ ] to enter the first digit of your password, then press [ ].
• When 4-digit numbers are entered, press [OK].
For the first time use:
Enter any 4-digit number (except for 4737). That number will be used as the password. Record your password,
in case you forget it.
• If you forget the password, enter ˝4737˝. The password will be cleared and rating level will be set to ˝Off˝.
C Rating level
HOME A ˝Setup˝ A ˝Preference Setup˝ A ˝Parental Control˝
1. Use [ ] to select ˝Setup˝ in the home menu, then press [OK].
2. Use [
] to select ˝Preference Setup˝, then press [OK].
3. Use [
] to select ˝Parental Control˝, then press [OK].
4. Enter your 4-digit password.
• Use [ ] to enter the first digit of your password, then press [ ].
• When 4-digit numbers are entered, press [OK].
5. Use [ ] to select your desired level, then press [OK].
6. Press [
(HOME)] to exit.
RATING EXPLANATIONS
Off Parental control is inactive; all discs can be played back.
8 [Adult] BD / DVD software of any grades (adult / general / children) can be played back.
7 [NC-17] No one under 18.
6 [R] Restricted; under 18.
5 [PGR] Parental guidance recommended.
4 [PG-13] Unsuitable for children under 13.
3 [PG] Parental guidance suggested.
2 [G] General audience.
1 [Kid Safe] Suitable for children.
C Password change
HOME A ˝Setup˝ A ˝Preference Setup˝ A ˝Change Password˝
1. Use [ ] to select ˝Setup˝ in the home menu, then press [OK].
2. Use [
] to select ˝Preference Setup˝, then press [OK].
3. Use [
] to select ˝Change Password˝, then press [OK].
4. Enter your 4-digit password.
• Use [ ] to enter the first digit of your password, then press [ ].
• When 4-digit numbers are entered, press [OK].
5. Enter a new 4-digit password in the same way as the step 4.
6. Reenter the same new 4-digit password in the same way as the step 4.
7. Press [
(HOME)] to exit.
To temporarily disable parental lock:
Some discs allow you to temporarily disable parental lock. When you try to play them back, the password entry
screen will be displayed.
Follow the instruction which appears on the TV screen to disable parental lock.
EN 36
10.4. Software update
HOME A ˝Setup˝ A ˝Advanced Setup˝ A ˝Software update˝
This unit lets you update the software yourself using a software update disc or USB memory stick.
The available discs are below:
• BD-RE/-R
• DVD-RW/-R
• CD-RW/-R
C Disc / USB memory stick update
You can update the software by using a disc or USB memory stick.
Prepare a blank disc or USB memory stick for software update:
Navigate to www.philips.com/support, and download the latest version software to a blank disc or USB memory
stick using a PC by following the directions described on the website.
• Use a blank disc or USB memory stick, download one software per disc or USB memory stick. Write the
software in the root directory of the disc or USB memory stick.
• For more details on how to download the software, please refer to the website.
1. Use [ ] to select ˝Setup˝ in the home menu, then press [OK].
2. Use [
] to select ˝Advanced Setup˝, then press [OK].
3. Use [
] to select ˝Software Update˝, then press [OK].
4. Use [
] to select ˝Disc˝ or ˝USB˝, then press [OK].
5. Use [
] to select ˝Yes˝, then press [OK].
6. Insert the disc or connect the USB memory stick for software update.
7. After loading disc or USB memory stick, confirmation message will appear. Select ˝Yes˝ and press [OK].
8. The unit will restart automatically, then software update will start.
• It may take a while to complete the updating.
9. After the update finishes, this unit will restart. Remove the disc or the USB memory stick from the unit.
CautionC
• Please do not unplug the AC power cord, eject the disc or disconnect the USB memory stick or press
[ (POWER)] to turn the unit to standby mode while performing a ˝Disc / USB Update˝.
NoteD
• Software update will not change any of the current settings.
EN 37
10.5. Voice guide
HOME A ˝Setup˝ A ˝Audio Setup˝ A ˝Voice Guide˝
1. Use [ ] to select ˝Setup˝ in the home menu, then press [OK].
2. Use [
] to select ˝Audio Setup˝, then press [OK].
3. Use [
] to select ˝Voice Guide˝, then press [OK].
4. Use [
] to select ˝On˝ or ˝Of˝, then press [OK].
5. Press [
(HOME)] to exit.
NoteD
• In order to enable the voice guide function, the OSD language needs to be set to English or Spanish.
Voice guide is not available in French.
• When voice guide is set to on, the HDMI audio output setting (Settings A HDMI A Audio Output) is fixed to
LPCM. Changing the HDMI audio output setting is only possible when voice guide is set to off.
10.6. Restore default settings
HOME A ˝Setup˝ A ˝Advanced Setup˝ A ˝Restore default settings˝
Menus to reset player settings, format a USB memory stick.
1. Use [ ] to select ˝Setup˝ in the home menu, then press [OK].
2. Use [
] to select ˝Advanced Setup˝, then press [OK].
3. Use [
] to select ˝Restore default settings˝, then press [OK].
4. Use [
] to select the desired setting, then press [OK].
˝Reset Settings˝:
All the settings except for ˝Parental Control˝ settings will be reset to default.
˝Format USB˝ (Only available when a USB memory stick is connected):
Initialize the USB memory stick.
˝(Unit) Erase Saved BD-ROM Data˝:
Clears the data saved for the BD-ROM contents, such as BD-ROM game scores, on this player.
˝(USB) Erase Saved BD-ROM Datac
(Only available when a USB memory stick is connected):
Clears supplemental data for BD-ROM playback, such as subtitle data, from the USB memory stick.
˝Reset All Settings˝:
Resets this unit to its factory default settings.
5. Use [ ] to select ˝Yes˝, then press [OK].
6. Confirmation message will appear. Press [OK] to complete the setting.
7. Press [
(HOME)] to exit.
CautionC
• Do not remove the USB memory stick while executing ˝Format USB˝ or ˝(USB) Erase Saved BD-ROM Data˝. It
will damage the USB memory stick.
NoteD
• ˝Format USB˝ and ˝(USB) Erase Saved BD-ROM Data˝ are not available when a Blu-ray Disc™ is in the unit.
EN 38
11. TROUBLESHOOTING
Problems Tips
No power. Check the AC power cord, if it is properly connected.
Try another power outlet.
Unplug the AC power cord, and wait for about 5-10 seconds. Plug it back in
and attempt to power on the unit.
No sound or picture. Make sure both the TV and Blu-ray Disc™ player are turned on.
Confirm the connections to the TV are made properly as shown in the
˝CONNECTIONS˝ on page 13.
Check to see whether the connected TV or another device supports HDCP.
(This unit will not output a video signal unless the other device supports
HD CP.)
No reaction to the remote control. Reduce the distance to infrared sensor window.
Confirm that the player’s AC power cord is plugged into a power outlet.
Check the batteries in the remote control and make sure they are inserted
properly by + or - symbols.
Please check IR signal. Refer to ˝IR signal check˝ on page 43.
No audio / video signal on the
display device via HDMI cable.
If the unit is connected to a non-certified HDMI device, the audio / video
signal will not output to that device.
Make sure the display device is on the correct input / video source.
Perform an HDMI hotplug: Disconnecting the HDMI cable from the display
device, turn on both devices, and replug the HDMI cable back in.
Check with the TV manufacturer, if there are any software updates available
for the TV.
Check to see if the HDMI cable is a certified version.
No high-definition video signal on
the TV screen.
Does the disc contain high-definition video? High-definition video is only
available when the disc contains it.
Does the TV support high-definition video? High-definition video is only
available when the TV supports it.
Distorted picture. Sometimes a small amount of picture distortion may appear. This is not a
malfunction.
Completely distorted picture or
black / white picture with Blu-ray
Disc™ / DVD.
Make sure the disc is compatible with this unit.
No sound or distorted sound. Adjust the volume.
Check to see if the speakers are connected correctly.
Check the HDMI connection.
Make sure the HDMI cable is not plugged into an HDMI-DVI adapter or
projector which does not handle digital sound.
Check the settings in ˝Audio Setup˝ menu.
Picture freezes momentarily during
disc playback.
Check the disc for fingerprints / scratches and clean with a soft cloth wiping
from the center to the outer edge.
Cannot play back a disc. Make sure that the disc is playable on this unit.
Check the region code of the disc. This unit supports the following region
codes.
- Blu-ray Disc™: ˝A˝
- DVD: ˝ALL˝ or ˝1˝
For DVD-RW/-R, make sure that the disc is finalized.
Clean the disc.
Is the disc a newer title? This problem may be solved by software update.
Refer to ˝Software update˝ on page 36.
No return to start-up screen when
disc is removed.
Soft reset this unit by turning it off for 30 seconds, then on again.
To completely reset the unit, press and hold [
(POWER)] on the front panel
for 10 seconds to shut down the unit or unplug the AC power cord from the AC
outlet for 5-10 seconds.
will appear on the TV screen.
The operation is not possible.
continued on next page
EN 39
Problems Tips
Buttons do not work or the unit
stops responding.
To soft reset the unit, press and hold [
(POWER)] on the front panel for 10
seconds to shut down the unit or to hard reset the unit by unplugging the
AC power cord from the AC outlet for 5-10 seconds.
The unit does not respond to
some operating commands during
playback.
The operations may be prohibited by the disc. Refer to the instructions for
the disc.
The unit cannot read Blu-ray Disc™
/ DVD/ CD.
Condensation? (Let the unit sit and dry for 1 or 2 hours)
Check to see if the disc is compatible with this unit. (Refer to page 16.)
Wipe dirt off the disc from the center to the outside or replace the disc.
Refer to ˝Cleaning discs˝ on page 43.
Scene shooting angle does not
switch.
Angles cannot be switched for Blu-ray Disc™ / DVD which do not contain
multiple angles. In some cases multiple angles are only recorded for
specific scenes.
Playback does not start when a title
is selected.
Check the settings in ˝Parental Control˝ menu.
The password for rating level has
been forgotten.
Enter the default password ˝4737˝, then your forgotten password will be
cleared. Then to change password go to ˝Password change˝ on page 35.
Error message appears when I select
˝Auto˝ in the ˝Menu Language˝.
Make sure that the unit is connected to a TV that is compatible with HDMI
CEC and the ˝EasyLink˝ is set to ˝On˝.
This error message may appear when your TV's OSD language is not
supported by this unit.
Cannot play back AVCHD file. This unit cannot play back stand-alone AVCHD files (*.m2ts, *.mts or *.m2t)
written to a DVD. The DVD containing AVCHD files must have a proper file
and folder structure meeting AVCHD format specifications. Please use
AVCHD compliant device / software to burn or copy AVCHD files to DVD.
(Please refer to user manuals of the device / software for more information.)
The capacity of the USB memory
stick decreased.
Data may be written on the USB memory stick when a BD-video uses the
virtual package feature while a USB memory stick is connected to the unit.
Cannot play back a MPEG-2 video
and audio from the USB memory
stick.
MPEG-2 is not compatible with this unit.
Cannot read the contents on the
USB memory stick.
The USB memory stick is not compatible with this unit or the contents may
be damaged.
Try and turn off the unit, then turn it back on.
To soft reset the unit, press and hold [
(POWER)] on the front panel for 10
seconds to shut down the unit or to hard reset the unit by unplugging the
AC power cord from the AC outlet for 5-10 seconds.
Cannot play back BD-Video. Connect a USB memory stick (256MB or more of available memory) which
is formatted on this unit. Some discs require memory when playing back
content.
Do not disconnect the USB memory stick during playback.
Cannot use BD-Live. Since this unit does not connect to the internet, BD-Live is not supported.
Cannot play back 3D. 3D Blu-ray™ discs are not supported by this unit.
Cannot load a Blu-ray Disc™ (stuck
in ˝Loading…˝ mode) and cannot
open the disc tray to eject the disc.
Unplug unit from AC outlet for 20 seconds. Plug unit back in and press the
[
(OPEN/CLOSE)] on the unit to eject the disc.
The software update screen
appears after Turning on the unit.
Please complete the software update.
When the software update has failed, the software update screen will keep
appearing after turning the unit on. If the software update continues failing,
please try it by using a USB memory stick with the update software installed
in its root directory. In this case, please change the file name as below.
˝ECS21UL10000PA1.bin˝ A ˝UPDATE10000PA1.BIN˝
Do not change the numbers. The file name is case sensitive.
Cannot read a USB memory stick. The format of the USB memory stick is not compatible with this unit. Please
try and format it on this unit (All data will be deleted).
Cannot play back JPEG files from a
disc.
Make sure that the disc was recorded in the UDF, ISO9660 or JOLIET
format.
continued on next page
EN 40
Problems Tips
Cannot find a JPEG file. Make sure that the selected group (folder) does not contain more than
9,999 files for Blu-ray Disc™ / DVD / USB memory stick and 999 files for CD.
Make sure that the file extension is .jpg / .JPG / .jpeg / or .JPEG.
No Audio signal from Surround
system of the audio system.
Make sure the audio system is turned on.
Check the Input mode on the audio system if it is on the correct channel.
Check if the surround system is compatible with either Bitstream or
LPCM. If not sure please check the user manual or contact the surround
manufacturer. Once confirmed check the setting in the ˝Setup˝ of this unit.
Increase the volume level of the surround system.
NoteD
• Do not attempt to repair the Blu-ray Disc™ player yourself. This may cause severe injury, irreparable damage to
your Blu-ray Disc™ player and void your warranty.
• Please have your Blu-ray Disc™ player model and serial number available before contacting us. These numbers
are available on the cabinet, as well as on the packaging.
EN 41
12. LANGUAGE CODE LIST
Language Code Language Code Language Code Language Code
A-B French [FRE] 5264 Macedonian 5957 Siswat 6565
Abkhazian 4748 Frisian 5271 Malagasy 5953 Slovak [SLO] 6557
Afar 4747 Galician 5358 Malay 5965 Slovenian 6558
Afrikaans 4752 Georgian 5747 Malayalam 5958 Somali 6561
Albanian 6563 German [GER] 5051 Maltese 5966 Spanish [SPA] 5165
Amharic 4759 Greek [GRE] 5158 Maori 5955 Sundanese 6567
Arabic 4764 Greenlandic 5758 Marathi 5964 Swahili 6569
Armenian 5471 Guarani 5360 Moldavian 5961 Swedish [SWE] 6568
Assamese 4765 Gujarati 5367 Mongolian 5960 T
Aymara 4771 Hausa 5447 Nauru 6047 Tagalog 6658
Azerbaijani 4772 Hebrew 5451 Nepali 6051 Tajik 6653
Bashkir 4847 Hindi 5455 Norwegian [NOR] 6061 Tamil 6647
Basque 5167 Hungarian [HUN] 5467 O-R Tatar 6666
Bengali;Bangla 4860 I-K Occitan 6149 Telugu 6651
Bhutani 5072 Icelandic [ICE] 5565 Oriya 6164 Thai 6654
Bihari 4854 Indonesian 5550 Oromo (Afan) 6159 Tibetan 4861
Bislama 4855 Interlingua 5547 Panjabi 6247 Tigrinya 6655
Breton 4864 Interlingue 5551 Pashto;Pushto 6265 Tonga 6661
Bulgarian [BUL] 4853 Inupiak 5557 Persian 5247 Tsonga 6665
Burmese 5971 Irish [GLE] 5347 Polish [POL] 6258 Turk ish [TUR] 6664
Byelorussian 4851 Italian [ITA] 5566 Portuguese [POR] 6266 Turkmen 6657
C-E Japanese [JPN] 5647 Quechua 6367 Tw i 6669
Cambodian 5759 Javanese 5668 Rhaeto-Romance 6459 U-Z
Catalan 4947 Kannada 5760 Romanian [RUM] 6461 Ukrainian 6757
Chinese [CHI] 7254 Kashmiri 5765 Russian [RUS] 6467 Urdu 6764
Corsican 4961 Kazakh 5757 S Uzbek 6772
Croatian 5464 Kinyarwanda 6469 Samoan 6559 Vietnamese 6855
Czech [CZE] 4965 Kirghiz 5771 Sangho 6553 Volapuk 6861
Danish [DAN] 5047 Kirundi 6460 Sanskrit 6547 Welsh 4971
Dutch [DUT] 6058 Korean [KOR] 5761 Scots Gaelic 5350 Wolof 6961
English [ENG] 5160 Kurdish 5767 Serbian 6564 Xhosa 7054
Esperanto 5161 L-N Serbo-Croatian 6554 Yiddish 7155
Estonian 5166 Laothian 5861 Sesotho 6566 Yoruba 7161
F-H Latin 5847 Setswana 6660 Zulu 7267
Faroese 5261 Latvian;Lettish 5868 Shona 6560
Fiji 5256 Lingala 5860 Sindhi 6550
Finnish [FIN] 5255 Lithuanian 5866 Singhalese 6555
NoteD
• If you choose a language that has a 3-letter-language code (written in bracket), the code will be displayed every
time you change the Subtitle language setting on page 28 or audio language setting on page 29. If you
choose any other languages, ˝---˝ will be displayed instead.
EN 42
13. SPECIFICATIONS
General
Signal system NTSC Color
Power requirements 120 V AC, 60 Hz
Power consumption 15 W (standby: 0.5 W)
Dimensions (width x height x depth) 11.1 x 1.7 x 8.3 inches (280.0 x 41.0 x 201.0 mm)
Weight 1.0 kg. (2.21 lbs.)
Operating temperature 41°F (5°C) to 104°F (40°C)
Operating humidity Less than 80 % (no condensation)
Terminals
USB input
TYPE A
HDMI output
HDMI jack x 1
Digital video: 480p, 720p, 1080i, 1080p, 1080p/24
Digital audio
NoteD
• The specifications and design of this product are subject to change without notice.
EN 43
14. MAINTENANCE
C Servicing
• Please refer to relevant topics in ˝TROUBLESHOOTING˝ on page 38 before returning the product.
• If this unit becomes inoperative, do not try to correct the problem by yourself. There are no user-serviceable
parts inside. Eject the disc (if possible), disconnect the USB memory stick (if connected to the unit),
place the unit into standby mode, unplug the AC power plug, and please contact: 1-866-515-1124 or visit :
www.philips.com/support
C Cleaning the cabinet
• Wipe the front panel and other exterior surfaces of the unit with a soft cloth.
• Never use a solvent, thinner, benzene or alcohol to clean the unit. Do not spray insecticide liquid near the unit.
Such chemicals may discolor the surface or damage the unit.
C Cleaning discs
• When a disc becomes dirty, clean it with a cleaning cloth. Wipe the disc from the center to outside. Do not wipe
in a circular motion.
• Do not use solvents such as benzine, thinner, commercially available cleaners, detergent, abrasive cleaning
agents or antistatic spray intended for analog records.
C Cleaning the disc lens
• If this unit still does not perform properly although you referred to relevant sections and ˝TROUBLESHOOTING˝
in this user manual, the laser optical pickup unit may be dirty. Consult your dealer or an authorized Service
center for inspection and cleaning of the laser optical pickup unit.
C Disc handling
• Handle the discs so that fingerprints and dust do not adhere to the surfaces of the discs.
• Always store the disc in its protective case when it is not used.
• Note that discs with special shapes (heart-shaped discs, octagonal discs, etc.) cannot be played back on this
unit. Do not attempt to play such discs, as they may damage the unit.
C IR signal check
If the remote control does not work properly, you can test IR signal using a digital camera (including a cellphone
with a built-in camera) to see if the remote control sends out the infrared signal.
1. Turn on the digital camera.
2. Direct a digital camera to the remote control, then press and hold any button on the
remote control.
• If infrared light appears on the digital camera display, the remote control is working.
NoteD
• Some cameras have an IR filter and will not display the IR signal.
EN 44
15. TRADEMARK INFORMATION
˝Blu-ray Disc™˝, ˝Blu-ray˝ and ˝Blu-ray Disc™˝ logo are
trademarks of the Blu-ray Disc Association.
˝BONUSVIEW™˝ and ˝BONUSVIEW™˝ logo are
trademarks of the Blu-ray Disc Association.
Manufactured under license from Dolby Laboratories.
Dolby, Dolby Audio, and the double-D symbol are
trademarks of Dolby Laboratories.
Java and all Java based trademarks and logos are
trademarks or registered trademarks of Oracle and/or
its affiliates.
For DTS patents, see http://patents.dts.com.
Manufactured under license from DTS Licensing
Limited.
DTS, the Symbol, & DTS and the Symbol together are
registered trademarks, and DTS 2.0+Digital Out is a
trademark of DTS, Inc. © DTS, Inc. All Rights Reserved.
The terms HDMI and HDMI High-Definition Multimedia
Interface, and the HDMI Logo are trademarks or
registered trademarks of HDMI Licensing LLC in the
United States and other countries.
˝x.v.Color˝ and ˝x.v.Color˝ logo are trademarks of Sony
Corporation.
is a trademark of DVD Format/Logo Licensing
Corporation.
˝AVCHD˝ and the ˝AVCHD˝ logo are trademarks of
Panasonic Corporation and Sony Corporation.
THIS PRODUCT IS LICENSED UNDER THE AVC PATENT
PORTFOLIO LICENSE FOR THE PERSONAL AND NON-
COMMERCIAL USE OF A CONSUMER TO (i) ENCODE
VIDEO IN COMPLIANCE WITH THE AVC STANDARD
(˝AVC VIDEO˝) AND/OR (ii) DECODE AVC VIDEO
THAT WAS ENCODED BY A CONSUMER ENGAGED
IN A PERSONAL AND NON-COMMERCIAL ACTIVITY
AND/OR WAS OBTAINED FROM A VIDEO PROVIDER
LICENSED TO PROVIDE AVC VIDEO. NO LICENSE IS
GRANTED OR SHALL BE IMPLIED FOR ANY OTHER
USE. ADDITIONAL INFORMATION MAY BE OBTAINED
FROM MPEG LA, L.L.C. SEE
HTTP://WWW.MPEGLA.COM
THIS PRODUCT IS LICENSED UNDER THE VC-1
PATENT PORTFOLIO LICENSE FOR THE PERSONAL
AND NON-COMMERCIAL USE OF A CONSUMER TO
(i) ENCODE VIDEO IN COMPLIANCE WITH THE VC-1
STANDARD (˝VC-1 VIDEO˝) AND/OR (ii) DECODE
VC-1 VIDEO THAT WAS ENCODED BY A CONSUMER
ENGAGED IN A PERSONAL AND NON-COMMERCIAL
ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO
PROVIDER LICENSED TO PROVIDE VC-1 VIDEO. NO
LICENSE IS GRANTED OR SHALL BE IMPLIED FOR
ANY OTHER USE. ADDITIONAL INFORMATION MAY
BE OBTAINED FROM MPEG LA, L.L.C. SEE
HTTP://WWW.MPEGLA.COM
EN 45
16. GLOSSARY
AACS
Advanced Access Content System (AACS) is the content
protection scheme used with Blu-ray™ discs.
Analog audio
An electrical signal that directly represents sound.
Compare this to digital audio which can be an electrical
signal, but is an indirect representation of sound. See
also ˝Digital audio˝.
Aspect ratio
The width of a TV screen relative to its height.
Conventional TVs are 4:3 (in other words, the TV screen
is almost square); widescreen models are 16:9 (the TV
screen is almost twice as wide as its height).
AVCHD
AVCHD is a new format for high definition video
camcorders which can record and play high-resolution
HD images.
Blu-ray Disc™
Blu-ray Disc™ is a next generation optical video disc
which is capable of storing much more data than a
conventional DVD. The large capacity makes it possible
to benefit from the features such as high-definition
videos, multi-channel surround sounds, interactive
menus and so on.
Chapter
Just as a book is split up into several chapters, a title
on a BD-video or DVD-video is usually divided into
chapters. See also ˝Title˝.
Cinavia™
Cinavia Notice
This product uses Cinavia technology to limit the
use of unauthorized copies of some commercially-
produced film and videos and their soundtracks. When
a prohibited use of an unauthorized copy is detected, a
message will be displayed and playback or copying will
be interrupted.
More information about Cinavia technology is provided
at the Cinavia Online Consumer Information Center at
http://www.cinavia.com
To request additional information about Cinavia by mail,
send a postcard with your mailing address to: Cinavia
Consumer Information Center, P.O. Box 86851, San
Diego, CA, 92138, USA.
This product incorporates proprietary technology under
license from Verance Corporation and is protected by
U.S. Patent 7,369,677 and other U.S. and worldwide
patents issued and pending as well as copyright and
trade secret protection for certain aspects of such
technology.
Cinavia is a trademark of Verance Corporation.
Copyright 2004-2017 Verance Corporation. All
rights reserved by Verance. Reverse engineering or
disassembly is prohibited.
Digital audio
An indirect representation of sound by numbers. During
recording, the sound is measured at discrete intervals
(44,100 times a second for CD audio) by an analog-
to-digital converter, generating a stream of numbers.
On playback, a digital-to-analog converter generates
an analog signal based on these numbers. See also
˝Sampling frequency˝ and ˝Analog audio˝.
Dolby Digital
The system to compress digital sound developed by
Dolby Laboratories. It offers you sound of stereo (2ch)
or multi-channel audio.
Dolby Digital Plus
Dolby Digital Plus is the next generation digital audio
compression technology developed as an extension to
Dolby Digital. Blu-ray Disc™ supports 7.1 multi-channel
surround sound output.
Dolby TrueHD
Dolby TrueHD is a lossless coding technology
developed for next generation optical discs. Blu-
ray Disc™ supports 7.1 multi-channel surround sound
output.
DTS
®
(Digital Theater System)
DTS
®
is a multi-channel surround sound system. You
can enjoy movie dynamic and realistic sound like
movie theater. DTS surround sound technologies were
developed by DTS, Inc.
DTS-HD
®
DTS-HD
®
is a lossless coding technology developed as
an extension of the original DTS Coherent Acoustics
format. Blu-ray Disc™ supports 7.1 multi-channel
surround sound output.
HDMI (High-Definition Multimedia Interface)
A digital interface between an audio and video source.
It can transmit component video, audio, and control
signal with one cable connection.
JPEG (Joint Photographic Experts Group)
JPEG is a method of compressing still picture files. You
can copy JPEG files on BD-RE/-R, DVD-RW/-R, CD-
RW/-R, or USB memory stick from a computer and play
back the files on this unit.
Local storage
A storage area of sub contents for playing virtual
packages on BD-video.
continued on next page
EN 46
PCM (Pulse Code Modulation)
The most common system of encoding digital audio,
found on CD and DAT. Excellent quality, but requires a
lot of data compared to formats such as Dolby Digital
and MPEG audio. For compatibility with digital audio
recorders (CD, MD and DAT) and AV amplifiers with
digital Inputs, this unit can convert Dolby Digital, DTS,
and MPEG audio to PCM. See also ˝Digital audio˝.
Region code
Regions associate discs and players with particular
areas of the world. This unit will only play back discs
that have compatible region codes. You can find the
region code of your unit by looking on the rear panel.
Some discs are compatible with more than one region
(or all regions).
Sampling frequency
The rate which sound is measured by a specified
interval to turn into digital audio data. The numbers of
sampling in one second defines as sampling frequency.
The higher the rate, the better the sound quality.
Title
A collection of chapters on BD-video or DVD-video.
See also ˝Chapter˝.
Track
Audio CD uses Tracks to divide up the content of a
disc. The BD-video or DVD-video equivalent is called a
Chapter.
See also ˝Chapter˝.
x.v.Color
˝x.v.Color˝ is a promotion name given to the products
that have the capability to realize a wide color space
based on the xvYCC specifications and is a trademark of
Sony Corporation.
17. LIMITED WARRANTY
back cover
NINETY (90) DAY LIMITED WARRANTY
WARRANTY COVERAGE:
This warranty obligation is limited to the terms as set forth below.
WHO IS COVERED:
This product is warranted to the original purchaser or the person
receiving the product as a gift against defects in materials
and workmanship as based on the date of original purchase
(“Warranty Period”) from an authorized dealer. The original sales
receipt showing the product name and the purchase date from an
authorized retailer is considered such proof.
WHAT IS COVERED:
This warranty covers new products if a defect in material or
workmanship occurs and a valid claim is received within the
Warranty Period. At its option, the company will either (1) repair
the product at no charge, using new or refurbished replacement
parts, or (2) exchange the product with a product that is new
or which has been manufactured from new, or serviceable used
parts and is at least functionally equivalent or most comparable
to the original product in current inventory, or (3) refund the
original purchase price of the product.
The Company warrants replacement products or parts provided
under this warranty against defects in materials and workmanship
from the date of the replacement or repair for ninety (90) days or for
the remaining portion of the original product’s warranty, whichever
provides longer coverage for you. When a product or part is exchanged,
any replacement item becomes your property and the replaced item
becomes the company’s property. When a refund is given, your
product becomes the company’s property.
Note: Any product sold and identified as refurbished or
renewed carries a ninety (90) day limited warranty.
Replacement product can only be sent if all warranty
requirements are met. Failure to follow all requirements
can result in delay.
WHAT IS NOT COVERED - EXCLUSIONS AND LIMITATIONS:
This Limited Warranty applies only to new company manufactured
products that can be identified by the trademark, trade name,
or logo affixed to it. This Limited Warranty does not apply to any
hardware product or any software, even if packaged or sold with
the product, as manufacturers, suppliers, or publishers may provide
a separate warranty for their own products packaged with the
bundled product. The company is not liable for any damage to or
loss of any programs, data, or other information stored on any media
contained within the product, or other additional product or part not
covered by this warranty. Recovery or reinstallation of programs,
data or other information is not covered under this Limited Warranty.
This warranty does not apply (a) to damage caused by accident,
abuse, misuse, neglect, misapplication, or non-supplied product,
(b) to damage caused by service performed by anyone other than
company approved authorized service location, (c) to a product or a
part that has been modified without written company permission, or
(d) if any serial number has been removed or defaced, or (e) product,
accessories or consumables sold “AS IS” without warranty of any kind
by including refurbished product sold “AS IS” by some retailers.
This Limited Warranty does not cover:
• Shipping charges to return defective product.
• Labor charges for installation or setup of the product,
adjustment of customer controls on the product, and
installation or repair of antenna/signal source systems outside
of the product.
• Product repair and/or part replacement because of improper
installation or maintenance, connections to improper voltage
supply, power line surge, lightning damage, retained images
or screen markings resulting from viewing fixed stationary
content for extended periods, product cosmetic appearance
items due to normal wear and tear, unauthorized repair or
other cause not within the control of the company.
• Damage or claims for products not being available for use, or
for lost data or lost software.
• Damage from mishandled shipments or transit accidents
when returning product.
• A product that requires modification or adaptation to enable
it to operate in any country other than the country for which it
was designed, manufactured, approved and/or authorized, or
repair of products damaged by these modifications.
• A product used for commercial or institutional purposes
(including but not limited to rental purposes).
• Product lost in shipment and no signature verification receipt
can be provided.
• Failure to operate per Owner’s Manual.
TO OBTAIN ASSISTANCE...
Contact Customer Care Center at:
1-866-515-1124
REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY
IS THE EXCLUSIVE REMEDY FOR THE CONSUMER, WITH THE
ISSUING COMPANY NOT LIABLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES FOR BREACH OF ANY EXPRESS OR
IMPLIED WARRANTY ON THIS PRODUCT. EXCEPT TO THE EXTENT
PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON
THIS PRODUCT IS LIMITED IN DURATION TO THE DURATION OF
THIS WARRANTY.
Some states do not allow the exclusions or limitation of incidental or
consequential damages, or allow limitations on how long an implied
warranty lasts, so the above limitations or exclusions may not apply
to you.
This warranty gives you specific legal rights. You may have other rights which vary from state/province to state/province.
Funai Service Corporation
1880 Braselton Hwy, Suite 118 #5012 Lawrenceville, GA 30043
P&F USA, Inc.
1880 Braselton Hwy, Suite 118 #5012 Lawrenceville,
GA 30043 U.S.A.
P&F Mexicana, S.A. de C.V.
Av. La Palma No. 6, Col. San Fernando La Herradura.
Huixquilucan, Edo. de México. C.P. 52787
This product has been manufactured by and is sold
under the responsibility of P&F USA, Inc., and P&F
USA, Inc. is the warrantor in relation to this product.
The Philips trademark and the Philips Shield Emblem
are registered trademarks of Koninklijke Philips N.V.
used under license.
ECS21UL
