Register your product and get support at
www.philips.com/welcome
User Manual
BDP7301
4K Ultra HD
Blu-ray Player
For further assistance, call the customer support
service in your country.
• To obtain assistance, contact Philips Customer
Care Center;
In the U.S.A., Canada, Puerto Rico, or the U.S.
Virgin Islands; 1-866-202-5960
EN 2
For fastest support visit us online at www.philips.com/support
for chat and self service solutions.
The lightning ash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sucient
magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
Know these
safety symbols
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION for UHD Blu-ray Disc™
Player and AC/DC adapter:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR BACK). NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
CAUTION for AC/DC adapter:
FOR INDOOR USE ONLY. DRY LOCATION USE
ONLY. USE WITH THE SPECIFIED AC POWER CORD
ONLY. MAY BECOME HOT DURING USE. THIS IS
NOT A MALFUNCTION. DO NOT USE OR CONNECT
WITH OTHER DEVICES.
* Additional Benets
Registering your product guarantees that you’ll
receive all of the privileges to which you’re
entitled, including special money-saving oers.
* Product Safety Notication
By registering your product, you’ll receive
notication - directly from the manufacturer - in
the rare case of a product recall or safety defect.
Registering your model with Philips makes you eligible for all of the valuable benets
listed below, so don’t miss out. Register online at www.philips.com/welcome to ensure:
Register online at www.philips.com/welcome
today to get the most benets from your purchase.
The symbol for CLASS ll (Double Insulation)
WARNING
:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS
TO RAIN OR MOISTURE. APPARATUS SHALL NOT BE EXPOSED TO DRIPPING OR SPLASHING AND NO
OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES, SHALL BE PLACED ON THE APPARATUS.
CAUTION: To prevent electric shock, match wide blade of plug to wide slot, fully insert.
ATTENTION:
Pour éviter les chocs électriques, introduire la lame la plus large de la che dans la borne
correspondante de la prise et pousser jusqu’au fond.
The important note and rating are located on the rear or bottom of the cabinet.
For Customer Use
M o d e l N o . _____________________________________________________________________________________________________
Serial No. _____________________________________________________________________________________________________
The Model and Serial Numbers of this Unit may be found on the cabinet. You
should Record and Retain those Letters / Numbers for future reference. Please
refer to the LIMITED WARRANTY for more information.
1. INTRODUCTION
1.1. Safety Instruction
EN 3
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If
the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the
manufacturer.
12. Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart / apparatus combination
to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when
unused for long periods of time.
14. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally,
or has been dropped.
Federal Communications Commission Notice
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If
this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and
receiver.
- Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
- Consult the dealer or an experienced radio / TV
technician for help.
This equipment may generate or use radio frequency
energy. Changes or modifications to this equipment
may cause harmful interference unless the
modifications are expressly approved in the manual.
The user could lose the authority to operate this
equipment if an unauthorized change or modification
is made.
Notice for CANADA: CAN ICES-3 (B)/NMB-3(B)
Disconnect the mains (AC) plug to shut the unit Off
when trouble is found or not in use. The mains (AC) plug
shall remain readily available. To completely turn Off
the unit, you must unplug the mains (AC) power cord.
CAUTION:
Danger of explosion if battery is incorrectly
replaced. Replace only with the same or
equivalent type.
WARNING:
Batteries (Battery pack or battery installed)
shall not be exposed to excessive heat
such as sunshine, fire or the like.
LASER SAFETY
This apparatus is classified as a CLASS 1 LASER PRODUCT.
This apparatus employs a laser. Only a qualified service
person should remove the cover or attempt to service this
apparatus, due to possible eye injury.
CAUTION: Use of controls or adjustments or
performance of procedures other than
those specified herein may result in
hazardous radiation exposure.
EN 4
IMPORTANT COPYRIGHT INFORMATION
Unauthorized copying, broadcasting, public
performance and lending of discs are prohibited.
This item incorporates copy protection technology
that is protected by U.S. patents and other intellectual
property rights of Rovi Corporation. Reverse
engineering and disassembly are prohibited.
Do not place the unit on the furniture that is capable
of being tilted by a child and an adult leaning, pulling,
standing or climbing on it. A falling unit can cause
serious injury or even death.
This apparatus should not be placed in a built-in
installation such as a bookcase or rack unless proper
ventilation is provided. Make sure to leave a space of 5.9
inches (15cm) or more around this apparatus.
Never use a gas duster on this unit. The gas trapped
inside of this unit may cause ignition and explosion.
To Avoid the Hazards of Electrical Shock and Fire
• Do not handle the AC Power cord with wet hands.
• Do not pull on the AC Power cord when disconnecting it
from an AC outlet. Grasp it by the plug.
• Do not put your fingers or objects into the unit.
Location and Handling
• Do not install the unit in direct sunlight, near strong
magnetic fields, or in a place subject to dust or strong
vibration.
• Avoid a place with drastic temperature changes.
• Install the unit in a horizontal and stable position.
Do not place anything directly on top or bottom of
the unit. Depending on your external devices, noise
or disturbance in the picture and/or sound may be
generated if the unit is placed too close to them. In
this case, please ensure enough space between the
external devices and the unit.
• Depending on the environment, the temperature of this
unit may increase slightly. This is not a malfunction.
• Be sure to remove the disc and unplug the AC Power
cord from the outlet before carrying the unit.
Dew Condensation Warning
• Dew condensation may form inside the unit in the
following conditions. If so, do not use this unit at least
for a few hours until its inside gets dry.
– The unit is moved from a cold place to a warm place.
– Under conditions of high humidity.
– After heating a cold room.
Notice for Progressive Scan Output
• Consumers should note that not all high definition
television sets are fully compatible with this product
and may cause artifacts to be displayed in the picture.
In case of picture problems with 525(480) progressive
scan output, it is recommended that the user switch
the connection to the ‘standard definition’ output. If
there are questions regarding your TV set compatibility
with this 525p(480p) Blu-ray Disc™/DVD player, please
contact our customer service center.
1.2. Maintenance
C Servicing
• Please refer to relevant topics in “TROUBLESHOOTING”
on page 51 before returning the product.
• If you need to call a customer service representative,
please know the model number and serial number
of your product before you call. This information is
displayed on the back of the product. Also, please
take a moment to identify the problem you are having,
and be prepared to explain this to the representative.
If you believe the representative will need to help you
with operations, please stay near the product. Our
representatives will be happy to assist you. For online
reference, please visit our website at
www.philips.com/support
C Cleaning the Cabinet
• Wipe the front panel and other exterior surfaces of the
unit with a soft cloth.
• Never use a solvent, thinner, benzene or alcohol to clean
the unit. Do not spray insecticide liquid near the unit.
Such chemicals may discolor the surface or damage the
unit.
C Cleaning Discs
• When a disc becomes dirty, clean it with a cleaning
cloth. Wipe the disc from the center to outside. Do not
wipe in a circular motion.
• Do not use solvents such as benzine, thinner,
commercially available cleaners, detergent, abrasive
cleaning agents or antistatic spray intended for analog
records.
EN 5
C Cleaning the Disc Lens
• If this unit still does not perform properly
although you refer to the relevant sections and to
“TROUBLESHOOTING” in this user manual, the laser
optical pickup unit may be dirty. Consult your dealer
or an Authorized Service Center for inspection and
cleaning of the laser optical pickup unit.
C Disc Handling
• Handle the discs so that fingerprints and dust do not
adhere to the surfaces of the discs.
• Always store the disc in its protective case when it is not
used.
• Note that discs with special shapes (heart-shaped discs,
octagonal discs, etc.) cannot be played back on this unit.
Do not attempt to play such discs, as they may damage
the unit.
C Testing the Remote Control
• If the remote control is not working properly, you can
use a digital camera (including a cellular phone with
built-in camera) to see if it is sending out an infrared
signal.
C How to perform the test
1. Point the IR transmitter of the remote
control towards the lens of the digital
camera (or cell phone camera).
2. Turn on the digital camera and look at
the IR transmitter of the remote control
through the LCD display of the digital
camera.
3. While looking at the LCD, press the
buttons on your remote control you
want to test.
a. If your remote control is working
properly, the IR transmitter of
the remote control will create a
noticeable flash on the LCD of the
digital camera.
b. if it does not flash, replace the
batteries in your remote with new
batteries and try again. If it still
does not flash, your remote control
may be damaged or defective.
Please contact customer service for
replacement options.
NoteD
• Some modern digital cameras have IR filters, in which
case you will not be able to see the flash in the LCD of
the camera even if the remote is working. For certain
cell phones you can try using the front facing camera
instead of the rear facing camera. You may also verify
the behavior of your camera by comparing results with
another remote which you know is working.
1.3. Notice
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
P&F USA/P&F MEXICANA reserves the right to change
products at any time without being obliged to adjust
earlier supplies accordingly.
The material in this manual is believed adequate for the
intended use of the system. If the product, or its individual
modules or procedures, are used for purposes other than
those specified herein, confirmation of their validity and
suitability must be obtained. P&F USA/P&F MEXICANA
warrants that the material itself does not infringe any
United States patents. No further warranty is expressed or
implied.
P&F USA/P&F MEXICANA cannot be held responsible
neither for any errors in the content of this document
nor for any problems as a result of the content in this
document. Errors reported to P&F USA/P&F MEXICANA
will be adapted and published on the P&F USA/P&F
MEXICANA support website as soon as possible.
C Warranty
No components are user serviceable. Do not open or
remove covers to the inside of the product. Repairs may
only be done by Service Centers and official repair shops.
Failure to do so shall void any warranty, stated or implied.
Any operation expressly prohibited in this manual, any
adjustments, or assembly procedures not recommended
or authorized in this manual shall void the warranty.
1.4. Important
Registering your model with Philips makes you eligible
for all of the valuable benefits listed below, so don’t miss
out. Complete and return your Product Registration Card
at once, or register online at www.philips.com/support to
ensure :
Product Safety Notification
By registering your product you receive notification
- directly from the manufacturer - in the rare case of a
product recall or safety defect.
Additional Benefits of Product Ownership
Registering your product guarantees that you receive all of
the privileges to which you’re entitled, including special
money-saving offers.
For further assistance
For further assistance, call the customer support service in
your country.
• To obtain assistance in the U.S.A., Canada, Puerto Rico,
or the U.S. Virgin Islands, contact Philips Customer Care
Center at 1-866-202-5960
EN 6
C Environmental Care
The packaging of this product is intended
to be recycled. Contact your local
authorities for information about how to
recycle the packaging.
For Product recycling information, please
visit -
www.recycle.philips.com
C End of life directives
Philips pays a lot of attention to produce
environment-friendly products in green
focal areas. Your new Blu-ray Disc™
Player contains materials which can be
recycled and reused. At the end of its life,
specialized companies can dismantle
the discarded Blu-ray Disc™ Player to
concentrate the reusable materials and
to minimize the amount of materials to be
disposed of. Please ensure you dispose of
your old Blu-ray Disc™ Player according to
local regulations.
C Disposal of used batteries
The batteries supplied do not contain the heavy metals
mercury and cadmium. Nevertheless, in many areas
batteries may not be disposed of with your household
waste. Please ensure you dispose of batteries according
to local regulations.
1.5. Supplied Accessories
• Quick Start Guide
• Remote Control (NC280UH)
• Batteries (AAA, 1.5V x 2)
• HDMI cable
• AC/DC Adapter (N1070UH)
1.6. Trademark Information
AUDIO
Manufactured under license from Dolby Laboratories.
Dolby, Dolby Audio and the double-D symbol are
trademarks of Dolby Laboratories.
For DTS patents, see http://patents.dts.com.
Manufactured under license from DTS Licensing Limited.
DTS, DTS-HD, the Symbol, & DTS and the Symbol together
are registered trademarks, and DTSHD Master Audio |
Essential is a trademark of DTS, Inc. © DTS, Inc. All Rights
Reserved.
The terms HDMI and HDMI High-Definition Multimedia
Interface, and the HDMI Logo are trademarks or registered
trademarks of HDMI Licensing LLC in the United States
and other countries.
“x.v.Color” and “x.v.Color” logo are trademarks of Sony
Corporation.
Java and all Java based trademarks and logos are
trademarks or registered trademarks of Oracle and/or its
affiliates.
“AVCHD” and the “AVCHD” logo are trademarks of
Panasonic Corporation and Sony Corporation.
EN 7
“BONUSVIEW™” and “BONUSVIEW™” logo are trademarks
of the Blu-ray Disc Association.
“BD-Live™” and “BD-Live™” logo are trademarks of the
Blu-ray Disc Association.
Netflix and the Netflix logo are trademarks or registered
trademarks of Netflix, Inc.
YouTube and the YouTube logo are trademarks of Google
Inc.
“Ultra HD Blu-ray™” and “Ultra HD Blu-ray™” logo are
trademarks of the Blu-ray Disc Association.
“Blu-ray 3D™”, “Blu-ray 3D™” logo are trademarks of the
Blu-ray Disc Association.
“Blu-ray Disc™”, “Blu-ray” and “Blu-ray Disc™” logo are
trademarks of the Blu-ray Disc Association.
is a trademark of DVD Format/Logo Licensing
Corporation.
THIS PRODUCT IS LICENSED UNDER THE AVC PATENT
PORTFOLIO LICENSE FOR THE PERSONAL AND NON-
COMMERCIAL USE OF A CONSUMER TO (i) ENCODE
VIDEO IN COMPLIANCE WITH THE AVC STANDARD
(˝AVC VIDEO˝) AND/OR (ii) DECODE AVC VIDEO THAT
WAS ENCODED BY A CONSUMER ENGAGED IN A
PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR
WAS OBTAINED FROM A VIDEO PROVIDER LICENSED
TO PROVIDE AVC VIDEO. NO LICENSE IS GRANTED OR
SHALL BE IMPLIED FOR ANY OTHER USE. ADDITIONAL
INFORMATION MAY BE OBTAINED FROM MPEG LA, L. L.
C. SEE HTTP://WWW.MPEGLA.COM
THIS PRODUCT IS LICENSED UNDER THE VC-1 PATENT
PORTFOLIO LICENSE FOR THE PERSONAL AND NON-
COMMERCIAL USE OF A CONSUMER TO (i) ENCODE
VIDEO IN COMPLIANCE WITH THE VC-1 STANDARD
(˝VC-1 VIDEO˝) AND/OR (ii) DECODE VC-1 VIDEO THAT
WAS ENCODED BY A CONSUMER ENGAGED IN A
PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR
WAS OBTAINED FROM A VIDEO PROVIDER LICENSED
TO PROVIDE VC-1 VIDEO. NO LICENSE IS GRANTED OR
SHALL BE IMPLIED FOR ANY OTHER USE. ADDITIONAL
INFORMATION MAY BE OBTAINED FROM MPEG LA,
L.L.C. SEE HTTP://WWW.MPEGLA.COM
Some features may require an always-on broadband
internet connection, firmware update and/or a minimum
bandwidth. Internet services vary by location.
P&F USA Inc./P&F MEXICANA, S.A.de C.V. do not warrant
access to the Portal or to any of the services, content,
software and advertising.
P&F USA Inc./P&F MEXICANA, S.A. de C.V. may, in its sole
discretion, add or remove access to any specific services,
content, software and advertising at any time.
Although P&F USA Inc./P&F MEXICANA, S.A. de C.V. will
strive to provide a good selection of services, content or
software, P&F USA Inc./P&F MEXICANA, S.A. de C.V. do
not warrant continued access to any specific services, and
content or software.
8
CONTENTS
INTRODUCTION ................................................. 2
Safety Instruction ..................................................................2
Maintenance .......................................................................... 4
Notice .........................................................................................5
Impo r t ant ..................................................................................5
Supplied Accessories .......................................................... 6
Trademark Information ...................................................... 6
FEATURES ...........................................................9
Features ................................................................................... 9
Firmware Version Information ...................................... 10
Symbols Used in this User Manual .............................. 10
FUNCTIONAL OVERVIEW ............................... 11
Top and Front Panel ............................................................11
Rear Panel ...............................................................................11
Remote Control .................................................................... 12
Guide to On-Screen Display ...........................................13
Connections .......................................................14
HDMI Video /Audio Connection....................................14
Connection to an Audio System ....................................16
Connection to the Network ............................................. 17
BEFORE YOU START ....................................... 19
Finding the Viewing Channel /Source on Your TV .19
Initial Setup ............................................................................19
INFORMATION ON PLAYBACK .....................20
Information on Playback .................................................20
Guide to File List ................................................................. 23
How to Insert a Disc .......................................................... 24
BASIC PLAYBACK ............................................ 25
Playing Back a Disc ........................................................... 25
Playing Back an Ultra HD Blu-ray™ Disc ..................26
Playing Back a Blu-ray 3D™ Disc ................................. 27
Playing Back Contents on a USB Storage Device .28
Using the Title / Disc / Pop-up Menu ........................28
Playing back from the File list .......................................29
SPECIAL PLAYBACK ........................................30
Fast Forward / Fast Reverse ..........................................30
Slow Forward Playback ...................................................30
Slow Reverse Playback ....................................................30
Frame by frame Playback ...............................................30
Frame Return Playback ...................................................30
Repeat Playback .................................................................31
Slide Show .............................................................................31
PiP (BONUSVIEW™) Setting .......................................... 32
Enjoying BD-Live™ Discs Using the Internet ........... 32
Title / Chapter Search....................................................... 33
Track Search ......................................................................... 33
Switching Subtitles ............................................................ 33
Switching Audio Soundtrack .........................................34
Switching Camera Angles ...............................................34
JPEG Status ..........................................................................35
JPEG Rotation ..................................................................... 35
Playback Information Window ..................................... 35
Reception ..............................................................................36
Closed Caption ....................................................................36
Luminance/Color Adjustment ....................................... 37
Progressive ........................................................................... 37
Reset to Default Picture Settings ................................ 37
Dialogue Enhancer ............................................................ 37
NETWORK SERVICES .....................................38
Before Using Network Services ....................................38
Information on Network Services ................................38
LIST OF SETTINGS ...........................................39
SETUPS .............................................................. 42
HDMI Video .......................................................................... 42
High Dynamic Range Output ......................................... 42
Network Installation..........................................................43
EasyLink Setup.................................................................... 47
BD-Video Ratings ..............................................................48
DVD-Video Ratings ...........................................................48
Software Update ................................................................49
Restore Default Settings .................................................50
License & Digital Rights Mgmt ......................................50
OTHER FUNCTION ...........................................50
Special mode .......................................................................50
TROUBLESHOOTING .......................................51
Downloading an Electronic Copy ................................ 53
Contact Us .............................................................................53
GLOSSARY ......................................................... 5 4
LANGUAGE CODE LIST ...................................56
SPECIFICATIONS .............................................. 57
IMPORTANT HEALTH AND SAFETY
INFORMATION FOR 3D TELEVISIONS ........58
ONE (1) YEAR LIMITED WARRANTY ............59
EN 9
Ultra HD Blu-ray™
Compared to the existing Blu-ray Disc
TM
, ULTRA HD Blu-
ray™ has much better in Resolution, Color gamut, and
Luminance. ULTRA HD Blu-ray™ also supports up to triple
layer discs - 50 GB (double layer), 66 GB (double layer),
and 100 GB (triple layer).
Blu-ray Disc™
You can enjoy Blu-ray Disc™ which is capable of storing
five times more data than a conventional DVD. Upscaling
will increase the resolution of a Blu-ray Disc™ to 4K Ultra
HD over an HDMI connection when connected to a 4K
Ultra HD TV.
Playing back Blu-ray 3D™ Disc
This unit can play back Blu-ray 3D™ discs which contain
stereoscopic 3D video. In order to enjoy 3D video, connect
this unit to a 3D capable TV using a 3D compatible HDMI
cable.
BD-J
With some Blu-ray™ discs which contain Java
applications, you can enjoy interactive functions such as
games or interactive menus.
DVD upscaling for enhanced picture quality
Your current DVD will look even better than before thanks
to video upscaling. Upscaling will increase the resolution
of standard definition DVD to high definition up to 4K over
an HDMI connection. The picture will be less jagged and
more realistic for a near high definition experience.
Enjoy your content on different kinds of media
Full backwards compatibility with DVD, CD and USB
storage device ensures that you can continue to enjoy your
current audio-video collection. Additionally, you can enjoy
AVCHD / MP3 / AAC / WAV /FLAC/ MP4 / JPEG files.
Listen to rich multi-channel surround sound
Multi-channel surround sound, which realizes real-to-life
sound and makes you feel that you are really there.
Intuitive user interface and remote control
The Philips logical user interface allows you to easily
navigate through your content and settings, so you can
quickly find what you are looking for.
Easy and simple connection to your HDTV via HDMI
Connect this unit to your HDTV with one single HDMI
(High-Definition Multimedia Interface) cable. Philips
recommends High Speed HDMI cable for better
compatibility. The high definition video output signal will
be transferred to your HDTV without conversion to analog
signals, so you will get excellent picture and sound quality
completely free from noise. Thanks to other multiple
outputs, you can also easily connect to your home theater
system or amplifier.
• For 4K/HDR content viewing:
– The connected TV must be 4K/HDR compatible.
– An 18 Gbps high-speed HDMI cable is required to
connect this unit and the TV.
About EasyLink (HDMI CEC) (Consumer Electronics
Control)
EasyLink allows you to operate the linked functions of this
player with Philips brand TV with EasyLink feature.
Philips does not guarantee 100 % interoperability with
other brands of HDMI CEC compliant devices.
PiP (BONUSVIEW™)
Some BD-videos have the PiP function which enables you
to display the secondary video in the primary video. You
can call up the secondary video by selecting [OPTIONS U]
“Secondary Video”whenever the scene contains it.
BD-Live™
BD-Live™ (BD-ROM version 2 Profile 2.0) that allows
interactive functions to be used when this unit is
connected to the Internet in addition to the BONUSVIEW™
function. The various functions differ depending on the
disc.
Pop-up menu
Some BD-videos have a pop-up menu which is a
navigation menu that can be called up and be operated
on the TV screen without interrupting playback. You
can call up the pop-up menu by pressing [TOP MENU].
Contents in the pop-up menu vary depending on the disc.
HDMI Deep Color
Deep Color reduces posterization (color banding) effect of
the playback image. Refer to the setting item “Deep Color
Output” on page 39
4K output with ULTRA HD Blu-ray
24p or 60p output in 4K resolution is available. Refer to
“HDMI Video /Audio Connection” on page 14.
2. FEATURES
2.1. Features
EN 10
Playing back contents on a USB storage device
You can play back MP3 / AAC / MP4 / FLAC / WAV /
MPEG-2 / JPEG files stored in a USB storage device. BD-
ROM Profile 2.0 (BD-Live™) and Profile 1.1 discs sometimes
store picture-in-picture commentary, subtitles or other
extras in the USB storage device for use during playback
with the BD-video.
Playing back AVCHD files
This unit supports playback of AVCHD format files (new
format for high definition video camcorders) recorded on
disc. Your high definition personal archive is playable in
HD quality.
x.v.Color
This unit supports playback of video contents on discs
recorded with “x.v.Color” technology. To watch this video
content with the “x.v.Color” space, a TV or other display
device supporting both video image reproduction using
“x.v.Color” standard and capability of manual switching of
its color space setting is required. Please refer to the user
manual of your display device for further information.
Enjoy contents stored on DLNA certified home
media servers
This unit is a DLNA certified media player that can play
video, music and photo files stored on DLNA certified
home media servers connected to your home network.
(not warranted for wireless environment)
Netflix
With this unit, you can enjoy movies and TV episodes
streamed instantly from Netflix via the Internet. In order to
use this feature, you must visit www.netflix.com/ on your
PC and become a Netflix member.
(This feature is available only in the United States.)
YouTube™
This unit enables you to access YouTube™.
On your TV screen, you can enjoy a large number of video
clips streamed from YouTube™.
Digital Rights Management
This product contains technology subject to certain
intellectual property rights of Microsoft.
Use or distribution of this technology outside of this
product is prohibited without the appropriate license(s)
from Microsoft.
HDR (High Dynamic Range)
HDR is the technology which processes picture colors so
that colors appear close to the natural view of the naked
eye, by controling the difference between the lightest and
the darkest colors.
2.2. Firmware Version Information
“Firmware Version Information” screen provides
information about this unit’s software version.
The current version of software on your unit can be seen
on the “Firmware Version Information” screen.
To access “Firmware Version Information”, follow the
procedure below.
1. Press [ Q (home)].
2. Use [ 0 / 1 ] to select “Setup”, then press [OK].
3. Use
[ K / L ] to select “Player Settings”, then press
[OK].
4. Use
[ K / L ] to select “System”, then press [OK].
5. Use
[ K / L ] to select “System Information”, then
press [OK].
6. Use
[ K / L ] to select “Firmware Version
Information”, then press [OK].
2.3. Symbols Used in this User Manual
To specify which media type each function is applicable
to, we put the following symbols at the beginning of each
item to operate.
Symbol Description
[UHDBD]
UHD
BD
UHD
BD
Description refers to Ultra HD Blu-ray
[BD Video]
BD
VIDEO
BD
VIDEO
Description refers to BD-video
[DVD Video]
DVD
VIDEO
DVD
VIDEO
Description refers to DVD-video
[DVD Video]
DVD
VR
DVD
VR
Description refers to DVD-RW/-R with VR mode
[CD]
CDCD
Description refers to audio CD / DTS-CD
[AVCHD]
AVC H DAVC H D
Description refers to DVD-RW/-R, DVD+RW/+R
with AVCHD files
[JPEG]
JPEGJPEG
Description refers to BD-RE/-R, DVD-RW/-R, CD-
RW/-R and USB storage device with JPEG files
[MP3]
MP3MP3
Description refers to DVD-RW/-R, CD-RW/-R and
USB storage device with MP3 files
[MPEG2]
MPEG2MPEG2
Description refers to DVD-RW/-R, CD-RW/-R and
USB storage device with MPEG-2 files
[MP4]
MP4MP4
Description refers to DVD-RW/-R, CD-RW/-R and
USB storage device with MP4 files
[AAC]
AACAAC
Description refers to DVD-RW/-R, CD-RW/-R and
USB storage device with AAC files
[WAV]
WAVWAV
Description refers to DVD-RW/-R, CD-RW/-R and
USB storage device with WAV files
[FLAC]
FLACFLAC
Description refers to DVD-RW/-R, CD-RW/-R and
USB storage device with FLAC files
[DLNA P]
DLNA
VIDEO
DLNA
VIDEO
Description refers to video files in the DLNA
Media Server
[DLNA M]
DLNA
MUSIC
DLNA
MUSIC
Description refers to music files in the DLNA
Media Server
[DLNA P]
DLNA
DLNA
Description refers to photo files in the DLNA
Media Server
EN 11
3.1. Top and Front Panel
1
2
3
4
1. A (open/close) button
• Press to open or close the disc tray.
2. . (standby/on) button / LED
• Press to turn on the unit, or to switch the unit into
standby mode. (To completely turn off the unit, you
must unplug the AC/DC Adapter.)
• The . (standby/on) LED lights up when the unit is
On, and goes out when the unit is Off.
3. Disc tray
• Place a disc after opening the disc tray.
4. Infrared sensor window
• Receives signals from your remote control so that
you can control the unit from a distance.
3.2. Rear Panel
12 3 4 5
1. DC IN jack
• Connect to the included AC/DC Adapter to supply
power to this unit.
• Unplug the AC Power cord from the AC outlet to
completely turn off the unit.
2. LAN port
• Used to connect to network provisioning equipment
such as a router or a modem, using a LAN cable.
3. HDMI OUT (AUDIO) port
• Used to connect to an AV receiver/amplifier with an
HDMI compatible port, using an HDMI cable.
• Audio output only.
4. HDMI OUT port
• Used to connect to a display with an HDMI
compatible port, using an HDMI cable. This HDMI
port will only output images when the HDMI OUT
(AUDIO) port is in use.
5. USB input port
• Connect a USB storage device or USB card reader.
CautionC
• Do not connect any device other than USB storage
device or USB card reader into USB input. (e.g. PC,
external HDD, MP3 player, digital camera, keyboard,
mouse, etc.)
• Do not use an extension cord or USB hub to connect
devices to this unit. Always connect one single USB
storage device or USB card reader into USB input
directly.
3. FUNCTIONAL OVERVIEW
EN 12
3.3. Remote Control
*
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
* The unit can also be turned on by pressing these
buttons.
1. B (standby/on) button
• Press to turn on the unit, or to switch the unit into
standby mode. (To completely turn off the unit, you
must unplug the AC Power cord.)
2. NETFLIX button*
• Press to launch Netflix.
3. Q (home) button
• Press to display the home menu.
4. TOP MENU button*
Ultra HD Blu-ray™, Blu-ray Disc™:
• Press to display the top menu or pop-up menu.
DVD:
• Press to display the title menu or disc menu.
5. OK button
• Press to confirm or select menu items.
6. K / L / 0 / 1 buttons
• Press to select items or settings.
• When playback is in pause mode, press [ 1 ] to
forward the playback picture by picture.
• When playback is in pause mode, press [ 0 ] to
reverse the playback picture by picture.
7. OPTIONS U button
• During playback, press to display the play menu.
8. Red / Green / Yellow / Blue buttons
• Press to activate shortcut keys on some BD-video
functions.
9. S (previous) button
• During playback, press once to return to the
beginning of the current title, chapter, track or file.
• During playback, press twice to return to the
previous title, chapter, track or file.
• During the JPEG playback, press to return to the
previous file.
C (stop) button
• Press to stop playback.
k (pause) button
• Press to pause playback.
T (next) button
• During playback, press to skip to the next chapter,
track or file.
E (reverse) button
• During playback, press to fast reverse the playback.
B (play) button*
• Press to start playback or resume playback.
D (forward) button
• During playback, press to fast forward the playback.
• When playback is in pause, press to slow forward
the playback.
10. -10s button
• Press to reverse the playback by 10 seconds.
11. +60s button
• Press to forward the playback by 60 seconds.
12. Number buttons
• Press to select a chapter during playback.
• Press to enter numbers and letters in the input field.
13. A (open/close) button*
• Press to open or close the disc tray.
14. BACK Y button
• Press to return to the previously displayed menu or
screen function.
15. INFO T button
• Press to display the information display.
16. YouTube button*
• Press to launch YouTube™.
EN 13
C Installing the Batteries in the Remote Control
Install 2 AAA (1.5V) batteries matching the polarity
indicated inside battery compartment of the remote
control.
123
CautionC
Incorrect use of batteries can result in hazards such as
leakage and bursting. Please observe the following:
• Do not mix alkaline, standard (carbon-zinc), or
rechargeable (ni-cad, ni-mh, etc) batteries.
• Do not mix new and old batteries together.
• Do not use different kinds of batteries together.
Although they may look similar, different batteries may
have different voltages.
• Make sure that the + and - ends of each battery match
the indications in the battery compartment.
• Remove batteries from battery compartment, when the
remote is not going to be used for a month or more.
• When disposing of used batteries, please comply with
governmental regulations or environmental public rules
that apply in your country or area.
• Do not recharge, short-circuit, heat, burn or disassemble
batteries.
C Using the Remote Control
Remote Control Usage Guidelines:
• Make sure that there are no obstacles between the
remote control and the infrared sensor window on the
unit.
• Remote operation may become unreliable if strong
sunlight or fluorescent light is shining on the infrared
sensor window of the unit.
• Remote controls of different devices can interfere with
each other. Avoid using a remote control from another
device which is located close to the unit.
• Replace the batteries when you notice a fall-off in the
operating range of the remote control.
• The maximum operable ranges from the unit are as
follows.
– Line of sight:
approx. 23 feet (7 m)
– Either side of the center:
approx. 16 feet (5 m) within 30°
– Above:
approx. 16 feet (5 m) within 15°
– Below:
approx. 10 feet (3 m) within 30°
30˚ 30˚
16 feet (5 m) 23 feet (7 m) 16 feet (5 m)
3.4. Guide to On-Screen Display
C Home Menu
When you turn on the unit, the Home Menu will appear
automatically. Otherwise, press [ Q (home)].
Photos SetupVideos Music
Home
Network
Browse
Net TV
Videos: Accesses the Video menu
Music: Accesses the Music menu
Photos: Accesses the Photo menu
Home Network: Accesses the DLNA Server menu
Browse Net TV: Accesses the Network Services
menu
Setup: Accesses the Setup Menu
C Setup Menu
HDMI
Video
Audio
3D
Language
Network
Ratings
System
Audio Language
Subtitle Language
Menu Language
On-screen Language
Closed Caption
Original
Auto
English
English
L
HDMI
Video
Au
d
i
o
3
D
Language
Netw
o
r
k
Rating
s
Sy
ste
m
Au
d
io Lan
g
ua
g
e
Su
b
tit
l
e Lan
g
ua
ge
Menu Lang
uage
On-screen Lan
g
ua
ge
C
losed Ca
ption
O
ri
g
ina
l
A
ut
o
English
English
L
12
1. Category
2. Menus / Options :
Displays options for the highlighted item on the left
whenever available.
C Play Menu
During playback, press [ OPTIONS U ] to display the play
menu.
e.g.) Blu-ray Disc™
Soundtrack
Subtitle Settings
Angle
Repeat Play
Secondary Video
Playback Information Window
Top Menu
Pop-up Menu
Closed Caption
1ENG DTS-HD MSTR Multi
1
O
Operation Menu
EN 14
4. Connections
• When you change the connections, all devices should be turned off.
• When making connections with external devices, please refer to their user manuals for additional setup help.
4.1. HDMI Video /Audio Connection
(Supports up to 1080i, 1080p, 1080p/24, 4K resolution.)
No analog audio connection required.
C Connecting with the HDMI OUT Port Only
HDMI IN
HDMI cable
(supplied)
or
HDMI OUTHDMI IN HDMI IN
HDMI cable
(supplied)
HDMI cable
(not supplied)
• With this connection, the HDMI OUT port outputs both video and audio.
• In order for Ultra HD Blu-ray™ video playback to work with this connection, a 4K/HDR compatible AV receiver/
amplifier and 18 Gbps high-speed HDMI cables are required.
• In order for Blu-ray 3D™ video playback to work with this connection, a 3D compatible AV receiver/amplifier and 3D
compatible HDMI cables are required.
C Connecting with the HDMI OUT and HDMI OUT (AUDIO) Ports
HDMI IN HDMI IN
HDMI cable
(supplied)
HDMI cable
(not supplied)
• With this connection, the HDMI OUT port only outputs video, and the HDMI OUT (AUDIO) port only outputs audio.
• The EasyLink function is only available for the HDMI OUT port.
• In order for Ultra HD Blu-ray™ content playback to work on this unit, a 4K/HDR compatible display device and AV
receiver/amplifier must be connected to this unit. Otherwise, the Audio will not be output.
• In order for 3D content playback to work on this unit, a 3D compatible display device and AV receiver/amplifier must
be connected to this unit. Otherwise, the Audio will not be output.
EN 15
In order to play 4K/HDR content, this unit must be connected to a 4K/60p/4:4:4 and Ultra HD Blu-ray HDR compliant
device.
• For 4K/60p/4:4:4, an 18Gbps high-speed HDMI cable is required.
Required TV
Specifications
Playback Content
Recommended Settings Video Signals from the Unit
HDMI
Resolution
4K60p Output
24p
Output
High Dynamic
Range Output
Output
Resolution
Frame Rate /
Color Space
Up to
4K
60p
4:4:4
BD-Video 24p
Auto 4K/60p (4:4:4)
Auto
Auto 4K
24p/4:4:4
Ultra HD Blu-ray
24p 24p/4:4:4
60p 60p/4:2:2
BD-Video 24p
Off
60p/4:4:4
Ultra HD Blu-ray
24p 60p/4:2:2
60p 60p/4:2:2
Up to
4K
60p
4:2:0
BD-Video 24p
Auto 4K/60p (4:2:0)
Auto
Auto 4K
24p/4:4:4
Ultra HD Blu-ray
24p 24p/4:2:2
60p 60p/4:2:0
BD-Video 24p
Off
60p/4:2:0
Ultra HD Blu-ray
24p 60p/4:2:0
60p 60p/4:2:0
Up to
4K
24p/30p
BD-Video 24p
Auto Off
Auto
Auto
4K
24p/4:4:4
Ultra HD Blu-ray
24p 24p/4:2:2
60p 2K 60p/4:4:4
BD-Video 24p
Off 2K
60p/4:4:4
Ultra HD Blu-ray
24p 60p/4:4:4
60p 60p/4:4:4
• Ultra HD Blu-ray content is created in 4K resolution.
• TVs supporting 4K60p are compatible with HDCP 2.2.
NoteD
• Do not tilt the HDMI connector when inserting it into the HDMI port, and make sure the shapes of the HDMI port and
the HDMI cable's connector match.
• If this unit is connected to an HDCP incompatible display device, video will not be displayed properly.
• Use a certified HDMI cable (an HDMI cable with the HDMI logo) for this connection. High-Speed HDMI cable (also
known as HDMI category 2 cable) is recommended for better compatibility.
• In order for Ultra HD Blu-ray™ video playback, connect this unit to a 4K/HDR compatible display device using an 18
Gbps high-speed HDMI cable.
• In order for Blu-ray 3D™ video playback, connect this unit to a 3D compatible display device using a 3D compatible
HDMI cable.
EN 16
4.2. Connection to an Audio System
C HDMI Audio Connection
AV receiver / amplifier with an HDMI input jack
HDMI IN
HDMI cable
(supplied)
C Audio Output from HDMI OUT jack
“DD/DD+/DTHD” Setting
“DTS/DTS-HD” Setting
“Bitstream” “LPCM”
“BD-Video Secondary Output” Setting
Off On Off On
Media
Audio Souce
Which audio format can be output depends on the compatibility of the
connected device.
Ultra HD Blu-ray
Blu-ray
Dolby Digital Dolby Digital Multi LPCM
Dolby Digital Plus Dolby Digital Plus Dolby Digital Multi LPCM*
1
Multi LPCM*
2
Dolby TrueHD Dolby TrueHD Dolby Digital Multi LPCM*
3
Multi LPCM*
4
DTS DTS Multi LPCM
DTS-HD DTS-HD DTS Multi LPCM*
1
Multi LPCM*
5
LPCM Multi LPCM Multi LPCM
DVD-Video Dolby Digital Dolby Digital Multi LPCM
DTS DTS Multi LPCM
LPCM Multi LPCM Multi LPCM
DTS-CD DTS DTS Multi LPCM
AVCHD Dolby Digital Dolby Digital Multi LPCM
LPCM Multi LPCM Multi LPCM
Audio CD LPCM 2ch LPCM 2ch LPCM
MP3 MP3 2ch LPCM 2ch LPCM
AAC AAC 2ch LPCM 2ch LPCM
FLAC FLAC 2ch/Multi LPCM 2ch LPCM
WAV WAV 2ch LPCM 2ch LPCM
MPEG2(TS/PS) Dolby Digital Dolby Digital Multi LPCM
Dolby Digital Plus Dolby Digital Plus Dolby Digital Multi LPCM*
1
Multi LPCM*
2
LPCM Multi LPCM Multi LPCM
Netflix Dolby Digital Plus Dolby Digital Plus Multi LPCM*
1
HE-AAC 2ch LPCM 2ch LPCM
YouTube™ HE-AAC 2ch LPCM 2ch LPCM
*1 Fully decoded.
*2 Only the independent substream is decoded.
*3 Dolby TrueHD stream is decoded.
*4 Only the Dolby Digital substream is decoded.
*5 Only the core substream is decoded.
NoteD
• If the connected device is not compatible with HDMI BITSTREAM, audio will be output as multi LPCM or 2-channel
down-mixed LPCM depending on the capability of the connected device even if you select “Bitstream” in “HDMI
Audio” setting.
• When playing back a BD-video which only contains the primary audio, the audio output will be the same case as
“Off” even if “BD-Video Secondary Audio” is set to “On”.
• Discs containing DTS audio with over 5.1ch surround signals at the sampling rate of 192kHz may not play correctly on
this unit.
When playing such discs while this unit is connected to an Audio System (over 5.1ch) such as an A/V amplifier, HDMI
receiver, etc., select “Bitstream” under the “DTS/DTS-HD” in “Digital Audio Output” of “Audio” setting of this unit. (If
“PCM” is selected, audio with over 5.1ch surround signals may not be output correctly.)
EN 17
4.3. Connection to the Network
By connecting this unit to the Internet, you can update the software via the Internet or access BD-Live™, Netflix, and
YouTube™ services.
• For a stable connection, wired connection is recommended when using following features. (Using following features
with Wireless LAN connection can be affected by other devices using radio frequencies.)
– Video streaming services (Netflix / YouTube™)
–Network update
C Wired Connection
WAN LAN
12345
LAN
Networking equipment (modem, etc.)
Internet
Broadband router or hub
LAN cable (not supplied)
LAN cable (not supplied)
CautionC
• Do not insert any cable other than a LAN cable to the LAN terminal to avoid damaging the unit.
• Do not connect your PC directly to the LAN terminal of this unit.
NoteD
• After you make a wired connection, set up necessary network settings.
(For network setting of wired connection, refer to “Wired” on page 44.)
• If your modem does not have router functions, connect a wired router.
• If your modem has router functions but there is no vacant port, add a hub.
• For a wired router, use a router which supports 10BASE-T / 100BASE-TX / 1000BASE-T ETHERNET standard.
• Please purchase shielded LAN cables at your local store and use them when you connect to network equipment.
EN 18
C Wireless LAN Connection
LAN WAN
Networking equipment (modem, etc.)
Internet
LAN cable (not supplied)
Wireless LAN router
NoteD
• After you made the Wireless LAN connection, set up necessary network settings.
(For the network setting of Wireless LAN connection, refer to “Wireless” on page 46.)
• For a Wireless LAN router, use a router which supports IEEE 802.11 b/g/n/ac.
(“ac” type is recommended for stable operation of the Wireless LAN network.)
• Set the Wireless LAN router to Infrastructure mode. This unit does not support Ad-hoc mode.
• Other radio devices or obstacles may cause interference to the Wireless LAN network connection.
• With a 2.4GHz wireless router (access point), using a USB3.0 compatible device with this unit may cause wireless
connection instability. Place the wireless router as far away as possible from this unit.
• When using a 5GHz compatible wireless router (access point), 5GHz bandwidth use is recommended.
EN 19
5. BEFORE YOU START
5.1. Finding the Viewing Channel /Source
on Your TV
After you have completed all the connections, you must
find the viewing channel (external input source) on your TV.
1. After you have made all the necessary
connections, press [ B (standby/on)] to turn on the
unit.
2. Turn on your TV.
3. Press the button on the TV’s remote control that
accesses the external input channel. It may be
labeled “SOURCE”, “AV”, “AUX” or “SELECT” (refer
to your TV’s user manual). Or press “2” on the TV’s
remote control, then press channel down button.
Please wait.
This is the correct viewing channel (external input
source).
• If the TV is connected by an HDMI cable, it may take
a while for the Philips splash screen to come up.
• If a certain amount of time has passed since you
turned on the unit, welcome screen appears the first
time you turn on this unit.
5.2. Initial Setup
Please follow the instructions below to complete the initial
setup.
1. While “On-Screen Language” screen is displayed,
use [ K / L ] to select your language, then press
[OK].
English
Français
Español
On-screen Language
Select the On-Screen Language.
Sélectionnez la langue d'achage.
Seleccione un Idooma para el menú en pantalla que
desee desplegar.
• When this unit is connected to a 4K-compatible TV,
the “4K/60p Output” screen will appear. Otherwise,
move on to step 3.
2. Follow the on-screen instructions, and if the “Is this
message displayed?” screen is displayed, select
“Yes”, then press [OK].
• If a confirmation screen* appears, select “Yes”, then
press [OK].
* It takes some time until the confirmation screen
appears.
3. The “Quick start” screen will appear. Use [ K / L ] to
select “On” or “Off”, then press [OK].
“On”: In order to make the unit start faster, then set to
"On". If done then this will increase the Power
Consumption during Standby mode.
“Off”: “Off” will reduce the Power Consumption during
Standby mode rather than “On”.
4. Press [OK].
• “Easy Settings” is finished.
5. “Easy Network Setting” screen will appear. Use
[ K / L ] to select the desired mode, then press [OK].
• If you select “Wired”, refer to “Wired” on page 43
for further operation.
• If you select “Wireless”, refer to “Wireless” on page
45 for further operation.
6. The Home menu will appear.
EN 20
6. INFORMATION ON PLAYBACK
6.1. Information on Playback
Before you start playing back a disc, read the following
information.
C Playable Discs and Files
Playable Discs Logo
Blu-ray Disc™
– Ultra HD Blu-ray™
–BD-video
– Blu-ray 3D™ Disc
– Blu-ray 3D™ only Disc
– BD-RE* (ver. 2.1/3.0)
(Recorded in BDMV format)
– BD-R* (ver. 1.1 / 1.2 / 1.3/2.0)
(Recorded in BDMV format)
(Unfinalized disc may not be played back.)
DVD-video
DVD-RW
(finalized VR mode discs only)
DVD-R
(finalized VR mode discs only)
CD-DA (audio CD)
CD-RW
CD-R
DTS-CD
-
*
Due to the intentional progression of the Blu-ray Disc™
format by its standard setting authority, the company
cannot guarantee or warrant the playability of future
extensions of the Blu-ray Disc™ format with this product.
Playable Files Media
AVCHD DVD-RW/-R, DVD+RW/+R
MP3
DVD-R, CD-RW/-R,
USB storage device
FLAC
WAV
AAC
JPEG BD-RE/-R, DVD-R, CD-RW/-R,
USB storage device
Readable devices Media
USB storage devices supporting
USB2.0 / USB3.0
MP4, MPEG2, MP3, FLAC,
WAV, AAC, JPEG, Picture-in-
Picture commentary, subtitles
or other extras for BD-ROM
ver. 2 (Profile 2.0 / Profile 1.1)
C Recommended Specifications
AVCHD
This unit cannot play back standalone AVCHD files (*.m2ts,
*.mts or *.m2t) written to a DVD. The DVD containing
AVCHD files must have a proper file and folder structure
meeting AVCHD format specifications.
Please use AVCHD compliant device / software to burn or
copy AVCHD files to DVD. (Please refer to user manuals of
the device / software for more information.)
MP3
• Maximum sampling frequency: 48kHz
• Maximum constant bit rate: 320kbps
• File extention: .mp3
JPEG
• Resplution
Upper limit: 4,096 x 4,096 dots (sub sampling: 4:4:4)
8,192 x 8,192 dots (sub sampling: 4:2:2)
8,192 x 8,192 dots
(sub sampling: up to 4:2:0)
Lower limit: 34 x 34 dots (sub sampling: 4:4:4)
34 x 34 dots (sub sampling: 4:2:2)
34 x 34 dots (sub sampling: up to 4:2:0)
• File extention: .jpg
FLAC
• Maximum sampling frequency: 192 kHz
• Correspond sampling frequency: Maximum 192 kHz
• Maximum quantization bit rate: 24 bit
• File extention: .flac
AAC
• Maximum sampling frequency: 48 kHz
• Correspond sampling frequency: Maximum 48 kHz
• Maximum constant bit rate: 320 kbps
• File extention: .m4a
WAV
• Maximum sampling frequency: 192 kHz
• Correspond sampling frequency: Maximum 192 kHz
• Maximum quantization bit rate: 24 bit
• File extention: .wav
MP4
• File extention: .mp4, .mov
MPEG2(TS/PS)
• File extention: .mpg, .mpeg, .m2ts, .mts, .ts
DLNA - PCM
• Maximum sampling frequency: 44.1, 48 kHz
• Correspond sampling frequency: Maximum 48 kHz
EN 21
C Folder / File Number Limitations
A total of 10,000 folders/files on any type of media can be
displayed.
Caution / Note for USB Storage Devices
CautionC
• Philips is not responsible if the USB storage device is
not supported nor is it responsible for damage or loss of
data from the device.
• Do not try to open or modify the USB storage device.
• Do not touch the terminal surface with your fingers or
any metals.
NoteD
• This unit supports USB storage devices with FAT16 /
FAT32 / NTFS / exFAT file system.
• Please keep the USB storage devices in their cases
when you are not using them.
• Some USB storage devices may not work with this unit.
• This unit can read SD cards using a USB card reader (not
supplied).
Readable cards:
SD Memory Card (8 MB - 2 GB)
miniSD Card (16 MB - 2 GB)
microSD Card (256 MB - 2 GB)
SDHC Memory Card (4 GB - 32 GB)
miniSDHC Card (4 GB - 8 GB)
microSDHC Card (4 GB - 16 GB)
SDXC Memory Card (64 GB - 2 TB)
C Unplayable Discs and Files
The following discs cannot be played on this unit.
• CD-ROM
• DVD-RAM
• DVD-audio
• HD DVD
• CD-I (compact disc-interactive)
• VSD (video single disc)
• video CD
• SVCD
• unfinalized disc
• BD-RE (ver.1.0)
• BD-RE (ver.2.1 / 3.0) (Recorded in BDAV format)
• BD-R (ver.1.1 / 1.2 / 1.3 / 2.0) (Recorded in BDAV format)
• Blu-ray Disc™ containing AVCHD files
• Blu-ray Disc™ / DVD / CD / USB storage device / SD
card containing DivX® files
• Blu-ray Disc™ / DVD hybrid disc (played back as a BD-
video only)
• DVD-RW/-R recorded in non compatible recording
format
• Super Audio CD - Only the sound on the CD layer can
be heard. The sound on the high-density Super Audio
CD layer cannot be heard.
• Playability of dual discs is not guaranteed.
• This unit cannot play back the disc content protected by
Windows Media™ Digital Rights Management (DRM).
C Region Codes
This unit has been designed to play back
BD-video with region “A”, DVD-video with
region “ALL” or “1”. You cannot play back
BD-video or DVD-video that are labeled for
other regions. Look for the symbols on the
right on your BD-video or DVD-video.
If these region symbols do not appear on
your BD-video or DVD-video, you cannot
play back the disc in this unit. The letter or
number inside the globe refers to region of
the world. A BD-video or DVD-video labeled
for a specific region can only be played back
in the unit with the same region code.
BD-video
DVD-video
DVD-video
NoteD
• Ultra HD Blu-ray™ discs have no region codes.
EN 22
C Hint for Disc Playback
The contents of a disc are generally divided into sections
or folders (groups of titles / files) as shown below.
Ultra HD Blu-ray, BD-video, DVD-video, AVCHD
Audio CD
MP3, FLAC,AAC,WAV,MP4,MPEG2
title 1
chapter 1
track 1
file 1
folder (group 1) folder (group 2)
chapter 1
track 3
file 3
chapter 2
track 2
file 2
chapter 2
track 4
file 4
chapter 3
track 5
file 5
title 2
C Description for Icons
: group (folder) icon
: music file icon
: video file icon
: photo file icon
– “Folders” refers to the groups of files.
– “Tracks” refers to the contents recorded on the audio
CD.
– “Files” refers to the contents on a disc which are
recorded in AVCHD, MP3, FLAC, AAC, WAV, MP4,
MPEG2, JPEG file format.
NoteD
• If there is an unrecognizable character in a file name, the
next recognizable character(s) moves over to the place
for the unrecognizable character.
EN 23
C Video File List
VIDEO
Parent Folder
Folder_1
Folder_2
Video_01.mkv
Video_02.mp4
Video_03.mp4
Video_04.mp4
12.12.2015
22.12.2015
25.12.2015
01.01.2016
9:00
10:00
19:00
5:00
USB \xxxxx\xxxxx
Play Previous Next Page 0001/0002
Parent F
o
l
d
e
r
Folder
_1
Fo
ld
er
_
2
Vi
d
eo
_
01.m
kv
Vi
d
eo_02.mp
4
Video_
03.mp
4
Vi
d
eo_04.mp
4
12.
1
2.
2015
22.
1
2.20
1
5
2
5
.
1
2.20
15
01.01.201
6
9:00
10:00
19:00
5
:0
0
US
B
\xxxxx\xxxx
x
P
la
y
Prev
i
ou
s
N
ex
t
P
1 2 3 4
6
5
1 Media type
2 Full path to the target directory
3 Folder/File List
4 Date and time at which this file was created
5 Folder/File icon
6 Operation guide
C Music File List
Playback
\xxxxx\xxxxx
Play Previous Next Page 0001/0002
MUSIC
Parent Folder
Folder_1
Folder_2
Music_01.mp3
Music_02.mp4
Music_03.aac
Music_04.ac
USB
Parent F
o
l
d
e
r
Folder
_1
Folder_
2
Music_
01.mp3
Music_
02.mp4
Music
_
03.aac
Music_
04.ac
USB
1 2
3
1 Media type
2 Folder/File List
3 Folder/File icon
C Photo File List
OK
RETURN
\xxxxx\xxxxx
Slideshow Previous Next Page 0001/0002
Photos
Parent Folder
Folder_1
Folder_2
12.12.2015
22.12.2015
25.12.2015
01.01.2016
9:00
10:00
19:00
5:00
USB
Parent F
old
er
Fo
ld
er
_1
Fo
ld
er
_
2
Photo_
Photo_02.jp
g
P
h
oto_03.jp
g
P
h
oto_04.
j
p
g
12.12.
2015
22.
1
2.20
1
5
2
5
.
1
2.20
15
0
1
.0
1
.20
1
6
9
:00
10:00
1
9:00
5:00
US
B
1 2 3
4
1 Media type
2 Folder/File List
3 Date and time at which this file was created
4 Folder icon / Thumbnail
C Music List (CD-DA)
Music Menu Music List
0.17 Repeat All Shuffle 3.57
Track1
CD
17 Tracks / Total Length 71.26
No.
01
02
03
04
05
06
07
08
09
Track1
Track2
Track3
Track4
Track5
Track6
Track7
Track8
Track9
3.57
3.41
4.30
4.36
3.42
4.55
3.53
4.04
3.23
Track Name Length
Page 0001/0002
2 3 4 5
7
8
2
1
6
1 Current track number
2 Playback status
3 Elapsed time of the current track
4 Playback options (Repeat mode/Shuffle)
5 Total play time of the current truck
6 Playback progress bar
7 Total truck numbers/total play time of the Disc
8 Music List
6.2. Guide to File List
EN 24
C Title/Play/Chapter List (VR)
Title List (VR)
USB \xxxxx\xxxxx
Play
Video Menu
DVD-R(VR)
Channel Date Title name
Simple PG
High Bitrate
New Resolution
Simple Seamless Connection
Resolution Changing
Aspect ratio changing
24.01
Start Time 17:15 Rec. Length 0:05
24.01
Low Bitrate
24.01
24.01
24.01
24.01
24.01
Previous Next
Page 001/003
1
S
S
S
S
S
S
S
S
S
S
S
3
Ti
tle
name
2
1 Media type
2 Title List
3 Recording start time/Recording length of the
selected Title
Playlist (VR)
01
02 03
04 05 06
12/16 (Fri) 0:01.38
PL_1
12/16 (Fri) 0:00.00
PL_2
12/16 (Fri) 0:00.59
PL_3
12/16 (Fri) 0:00.59
PL_6
12/16 (Fri) 0:02.00
PL_5
Page 01/17
Previous Next
Previous Next
12/16 (Fri) 0:00.40
PL_4
Playlists Playlist View
DVD-RW (VR)
4
5
4 Thumbnail
5 Title information
When a Disc containing the Playlist is inserted, and the
Home menu is displayed, select “Videos”
“Disc” to
display the Title/Playlist selection screen, then select
“Playlist”.
Chapter List (VR)
01
Chapter View
DVD-RW (VR)
Press OK to start playing from
the selected chapter.
Press BACK to go back to
previous menu.
0:00.05
Page 001/001
Play
PG_Play Test1
0:00.00
001
--- --- --- --- ---
6
6 Chapter thumbnail
How to Navigate through the Track / File List
• Use [ K / L ] to move the highlight up and down in the
list.
• To access the files in a group (folder), select the
desired group (folder), then press [OK].
• Press [ BACK Y ] to go back to the previous hierarchy.
• Press [S (previous)] or [T (next)] to change the
page of the list.
• Press [ Q (home)] to go back to the home menu.
6.3. How to Insert a Disc
1. Press [ A (open/close)] to open the disc tray.
2. Place the disc on the disc tray with its label side
facing up.
Align the disc to the
disc tray guide.
3. Press [ A (open/close)] to close the disc tray.
• It may take a while to load the disc.
EN 25
7. BASIC PLAYBACK
7.1. Playing Back a Disc
1. Insert a disc (refer to “How to Insert a Disc” on page
24).
• For Blu-ray Disc™ / DVD or a disc containing only
one type of file, playback will start automatically. If
not, press [ B (play)].
• For audio CD, CD-DA List will appear.
• Some discs may show a title or a disc menu. In this
case, refer to “Using the Title / Disc / Pop-up Menu”
on page 28.
• Media filter screen will appear.
2. Select the type of the file you want to play back,
then press [OK].
Play Video
View Photos
Play Music
DVD-RW
Please select a function and press OK.
3. Select the desired item.
For “Play Video”, file list will be displayed.
• Refer to “Photo File List” on page 23 and “How
to Navigate through the Track / File List” on page
24.
For “View Photos”, thumbnail screen will appear.
• Refer to “Photo File List” on page 23 and “How
to Navigate through the Track / File List” on page
24.
For “Play Music”, track / file list will be displayed.
Select a group (folder) or track / file you want to play
back then press [ B (play)] or [OK] to start playback.
• Refer to “Music File List” on page 23 and “How
to Navigate through the Track / File List” on page
24.
To skip to the next track / file :
Press [ T (next)].
To skip to the previous track / file :
Press [ S (previous)].
To pause playback :
Press [ k (pause)].
To return to normal playback :
Press [ B (play)].
To stop playback :
Press [ C (stop)].
Playback will be in Resume-On-Stop mode.
C Resume-On-Stop Mode
Ultra HD Blu-ray Disc™ / Blu-ray Disc™ / DVD /
AVCHD / DVD-VR / MP4 / MPEG2:
When you press [ B (play)] next time, the playback will
start from the point where it has been stopped.
Audio CD / JPEG / AAC / WAV / FLAC / MP3
Playback will start from the beginning of the current
track/file next time you press [ B (play)] or [OK].
NoteD
• Playback will also stop and the home menu will appear
when you press [ Q (home)]
• For BD-J application, the Resume-On-Stop may not be
available.
• Resume-On-Stop mode remains in effect even after
power is turned off, but will be canceled once the disc
is ejected.
• With regard to the multi-border BD-RE/-R, additionally
recorded sections cannot be recognized.
• With regard to the multi-border DVD-RW/-R,
additionally recorded sections may not be recognized.
TipsE for JPEG viewing
• Some unplayable folders or files may be listed due to
the recording status.
• High-resolution JPEG files take longer to be displayed.
• Progressive JPEG files (JPEG files saved in progressive
format) are not supported.
EN 26
7.2. Playing Back an Ultra HD Blu-ray™ Disc
[UHDBD]
UHD
BD
UHD
BD
This unit can play back Ultra HD Blu-ray ™ discs. In order
to view Ultra HD Blu-ray ™ videos, you need to have the
following:
– 4K/60p (color space 4:4:4) and HDCP 2.2
compatible device.
– HDR compatible device
– 18 Gbps high-speed HDMI cable
– Ultra HD Blu-ray
TM
Disc
1. Connect this unit to a 4K/60p (4:4:4) compatible TV
using an 18 Gbps high-speed HDMI cable.
• Refer to “HDMI Video /Audio Connection” on page
14
2. Insert an Ultra HD Blu-ray ™ Disc.
• Refer to “How to Insert a Disc” on page 24.
3. Playback may start automatically. If not, press
[ B (play)].
• Some discs may show a title or a disc menu. In this
case, refer to “Using the Title / Disc / Pop-up Menu”
on page 28.
To pause playback:
Press [ k (pause)].
To return to normal playback:
Press [ B (play)].
To stop playback:
Press [ C (stop)].
Playback will be in Resume-On-Stop mode, and the
background screen will appear.
C Resume-On-Stop mode
When you press [ B (play)] next time, the playback will
start from the point where it has been stopped.
NoteD
• If this unit is connected to a non-HDCP 2.2 compatible
device, HDR signals will be dynamically converted and
output in 2K resolution. Some discs may not be played
correctly.
• If this unit is connected to a non-4K/60p (color space
4:2:0) compatible device, and a 60p video is played,
HDR signals will be dynamically converted and output.
• If this unit is connected to a non-4K/60p compatible
device, HDR signals will be dynamically converted and
output in 2K resolution.
• If this unit is connected to a non-HDR compatible
device, HDR signals will be dynamically converted and
output. Some discs may output images in 2K resolution
or may not be played correctly.
EN 27
7.3. Playing Back a Blu-ray 3D™ Disc
[BD Video]
BD
VIDEO
BD
VIDEO
This unit can play back Blu-ray 3D™ discs which contain
stereoscopic 3D video. In order to view Blu-ray 3D™
videos, you need to have the following:
– 3D capable TV
– 3D compatible HDMI cable
– 3D glasses
– Blu-ray 3D™ Disc or Blu-ray 3D™ only Disc
1. Connect this unit to a 3D-compatible TV using a
3D-compatible HDMI cable.
• Refer to “HDMI Video /Audio Connection” on page
14.
2. Insert a Blu-ray 3D™ Disc or a Blu-ray 3D™ only
Disc.
• Refer to “How to Insert a Disc” on page 24.
3. Playback may start automatically. If not, press [ B
(play)]
.
• Some discs may show a title or a disc menu. In this
case, refer to “Using the Title / Disc / Pop-up Menu”
on page 28.
To pause playback:
Press [ k (pause)].
To return to normal playback:
Press [ B (play)].
To stop playback:
Press [ C (stop)].
Playback will be in Resume-On-Stop mode, and the
background screen will appear.
C Resume-On-Stop mode
When you press [ B (play)] next time, the playback will
start from the point where it has been stopped.
CautionC
• Watching 3D videos may cause headache, dizziness or
tiredness. To avoid such consequences, do not watch
3D videos for a long period of time.
• Watching 3D videos is not recommended for the
following people:
– People who are susceptible to motion sickness
– Children from walking age to seven years
–Pregnant woman
For more information, refer to “IMPORTANT HEALTH AND
SAFETY INFORMATION FOR 3D TELEVISIONS” on page
58.
NoteD
• For more information, refer to the 3D TV’s manual.
• When “3D BD-Video Playback” is set to “3D Playback”
and your TV is not 3D capable, playback of Blu-ray 3D™
discs will revert to 2D depending on the disc.
• For some Blu-ray 3D™ only discs, playback in 2D mode
is not possible.
• You can check the current output mode (2D or 3D) by
pressing [ INFO T ] during playback.
EN 28
7.4. Playing Back Contents on a USB
Storage Device
[MP3]
MP3MP3
[JPEG]
JPEGJPEG
[MP4]
MP4MP4
[MPEG2]
MPEG2MPEG2
[AAC]
AACAAC
[WAV]
WAVWAV
[FLAC]
FLACFLAC
You can play back MP3 / JPEG / MP4 / MPEG2 / AAC /
WAV / FLAC files from a USB storage device. With the USB
storage device, you can also enjoy the following functions.
– Special additional contents for BD-ROM Profile 1 ver.1.1.
(For more information about the special additional
contents, refer to the instruction book that came with
the disc.)
– BD-Live™ function (BD-ROM ver. 2 Profile 2.0). (For
more information about BD-Live™, refer to page 32.)
1. Connect a USB storage device to the USB input.
2. Use
[ K / L ] to select “Play Video”, “View Photos” or
“Play Music”, then press [OK].
3. Follow steps 3 in “Playing Back a Disc” on page
25.
To remove the USB storage device:
In stop mode, pull it out slowly.
CautionC
• Do not remove the USB storage device or switch the unit
to standby mode while the contents of the device are
being accessed. It may result in malfunction or loss of
the device data.
• Philips cannot be held responsible if your USB storage
device is not supported, nor will Philips accept any
liability for damage or loss of stored data.
• If a USB card reader is connected, files in an SD card
which is connected first to the slot of the reader will be
displayed.
NoteD
• The resume information will be cleared when:
– the USB storage device is removed.
– the unit is switched to standby mode.
• Do not delete the folders or files in the USB storage
device with your computer. This unit may not read USB
storage devices formatted on a computer.
• This unit can read MP3 / JPEG / MP4 / MPEG2 / AAC /
WAV / FLAC files in an SD card by using USB card reader
(not supplied).
7.5. Using the Title / Disc / Pop-up Menu
[UHDBD]
UHD
BD
UHD
BD
[BD Video]
BD
VIDEO
BD
VIDEO
[DVD Video]
DVD
VIDEO
DVD
VIDEO
[AVCHD]
AVC H DAVC H D
Some discs may contain a title menu which describes
the contents of the disc, or a disc menu which guides you
through the available functions in the disc.
With such discs, a title menu or a disc menu may appear
automatically when you insert the disc. Otherwise, press
[TOP MENU] to call up the menu. Refer to the disc’s
manual on how to navigate through the menu.
NoteD
• Menus vary among discs. Refer to the information
accompanying the disc for details.
• [TOP MENU] may not work with some discs.
• You can also call up the Title/Disc/Pop-up Menu from
the play menu. Play menu can be called up by pressing
[ OPTIONS U ] .
– Ultra HD Blu-ray/BD-Video/DVD-V/AVCHD:
[ OPTIONS U ]
“Operation Menu”“Top Menu”
– Ultra HD Blu-ray/BD-Video:
[ OPTIONS U ]
“Operation Menu”“Pop-up
Menu”
– DVD-Video:
[ OPTIONS U ]
“Operation Menu”“Menu”
EN 29
7.6. Playing back from the File list
If [ B (play)] or [OK] is pressed while the File list is
displayed, this unit will operate as follows:
[CD]
CDCD
[MP3]
MP3MP3
[FLAC]
FLACFLAC
[AAC]
AACAAC
[WAV]
WAVWAV
In stop mode:
[ B (play)] / [OK]:
Starts playing from the beginning of the Track/File
being highlighted.
While highlighting the Track/File being played:
[ B (play)] / [OK]: N/A
While highlighting any Track/File not being played:
[ B (play)] / [OK]:
Starts playing from the beginning of the Track/File
being highlighted.
While highlighting the Track/File being paused:
[ B (play)]: Resumes playback from where it was
paused.
[OK]: N/A
While highlighting any Track/File not being paused:
[ B (play)]: Resumes playback from where it was
paused.
[OK]: Starts playing from the beginning of the
Track/File being highlighted.
While highlighting the Track/File being FF/FR:
[ B (play)]: Cancels FF/FR and resumes playback.
[OK]: N/A
While highlighting any Track/File not being FF/FR:
[ B (play)]: Cancels FF/FR and resumes playback.
[OK]: Starts playing from the beginning of the
Track/File being highlighted.
[JPEG]
JPEGJPEG
In stop mode:
[ B (play)]: Starts Slideshow from the file being
highlighted. (Files in the root directory will
be shown as well.)
[OK]: Displays the file being highlighted.
(If [ B (play)] is pressed here, Slideshow will
start.)
[MP4]
MP4MP4
In stop mode, while any File is highlighted:
[ B (play)] / [OK]:
Starts playing from the beginning of the Track/File
being highlighted.
While highlighting the Track being in Resume stop mode:
[ B (play)] / [OK]:
Resumes playback from where it was stopped.
[DLNA M]
DLNA
MUSIC
DLNA
MUSIC
In stop mode:
[ B (play)] / [OK]:
Starts playing from the beginning of the Track/File
being highlighted.
While highlighting the Track/File being played:
[ B (play)]: N/A
[OK]: Pauses playback.
[ 0 ] or [ S (previous)]: Skips back to the beginning of
the Track/File.
[ 1 ] or [ T (next)]: Skips to the next Track/File.
While highlighting the Track/File being paused:
[ B (play)] / [OK]:
Resumes playback from where it was paused.
[DLNA P]
DLNA
DLNA
In stop mode, while any File is highlighted:
[ B (play)] / [OK]:
Displays the the highlighted file.
In stop mode, while any Folder is highlighted:
[ B (play)]: Starts Slideshow with files in the Folder
being highlighted*.
[OK]: Moves into the Folder being highlighted.
*
If there is no Photo File in the highlighted folder, photo
browsing will not start.
[DLNA P]
DLNA
VIDEO
DLNA
VIDEO
In stop mode, while any File is highlighted:
[ B (play)] / [OK]:
Starts playing from the beginning of the Track/File
being highlighted.
While highlighting the Track being in Resume stop mode:
[ B (play)] / [OK]:
Resumes playback from where it was stopped.
EN 30
8. SPECIAL PLAYBACK
8.1. Fast Forward / Fast Reverse
[UHDBD]
UHD
BD
UHD
BD
[BD Video]
BD
VIDEO
BD
VIDEO
[DVD Video]
DVD
VIDEO
DVD
VIDEO
[DVD Video]
DVD
VR
DVD
VR
[AVCHD]
AVC H DAVC H D
[MP3]
MP3MP3
[AAC]
AACAAC
[MP4]
MP4MP4
[FLAC]
FLACFLAC
[WAV]
WAVWAV
[CD]
CDCD
1. During playback, press [ D (forward)] repeatedly
for fast forward.
During playback, press [ E (reverse)] repeatedly
for fast reverse.
Every time you press [ D (forward)] or
[ E (reverse)], the playback speed will change.
2. Press [ B (play)] to return to normal playback.
NoteD
• For Ultra HD Blu-ray Disc™,Blu-ray Disc™, DVD, DVD-VR,
AVCHD, MP4 and MPEG2, speed changes in 5 different
levels.
• For audio CD, MP3, AAC, FLAC and WAV, speed
increases 1 level.
• For audio CD, fast forward / fast reverse search
between different tracks are not available during
random playback.
• For MP3, AAC, FLAC and WAV, fast forward / fast
reverse search between different files are not available.
When searching reaches the beginning/ending of the
track, it will return to normal playback.
8.2. Slow Forward Playback
[UHDBD]
UHD
BD
UHD
BD
[BD Video]
BD
VIDEO
BD
VIDEO
[DVD Video]
DVD
VIDEO
DVD
VIDEO
[DVD Video]
DVD
VR
DVD
VR
[AVCHD]
AVC H DAVC H D
1. During playback, press [ k (pause)], then press
[ D (forward)].
Every time you press [ D (forward)], the playback
speed changes in 5 different levels.
2. Press [ B (play)] to return to normal playback.
NoteD
• For Ultra HD Blu-ray Disc™, Blu-ray Disc™, AVCHD, only
slow forward is available.
8.3. Slow Reverse Playback
[DVD Video]
DVD
VIDEO
DVD
VIDEO
[DVD Video]
DVD
VR
DVD
VR
1. During playback, press [ k (pause)], then press
[ E (reverse)].
Every time you press [ E (reverse)], the playback
speed changes in 5 different levels.
2. Press [ B (play)] to return to normal playback.
8.4. Frame by frame Playback
[UHDBD]
UHD
BD
UHD
BD
[BD Video]
BD
VIDEO
BD
VIDEO
[DVD Video]
DVD
VIDEO
DVD
VIDEO
[DVD Video]
DVD
VR
DVD
VR
[AVCHD]
AVC H DAVC H D
1. In pause mode, press [ 1 ] repeatedly.
Every time you press
[ 1 ], playback will advance
one step at a time.
2. Press [ B (play)] or [ k (pause)] to return to normal
playback.
NoteD
• For Ultra HD Blu-ray Disc™, Blu-ray Disc™, AVCHD, only
frame by frame is available.
8.5. Frame Return Playback
[DVD Video]
DVD
VIDEO
DVD
VIDEO
[DVD Video]
DVD
VR
DVD
VR
1. During playback, press [ k (pause)], then press
[ 0 ].
Every time you press
[ 0 ], playback will reverse by
1 frame.
2. Press [ B (play)] or [ k (pause)] to return to normal
playback.
EN 31
8.6. Repeat Playback
Available repeat function varies depending on the disc.
1. During playback, press [ OPTIONS U ] .
2. Use [ K / L ] to select “Operation Menu”, then press
[OK].
3. Use [ K / L ] to select “Repeat Play”, then press [OK].
4. Use [ K / L ] to select the desired repeat mode.
REPEAT MODE AVAILABLE MEDIA
Chapter Repeat
[UHDBD]
UHD
BD
UHD
BD
[BD Video]
BD
VIDEO
BD
VIDEO
[DVD Video]
DVD
VIDEO
DVD
VIDEO
[DVD Video]
DVD
VR
DVD
VR
[AVCHD]
AVC H DAVC H D
The current chapter will be
played back repeatedly.
Title Repeat
[UHDBD]
UHD
BD
UHD
BD
[BD Video]
BD
VIDEO
BD
VIDEO
[DVD Video]
DVD
VIDEO
DVD
VIDEO
[DVD Video]
DVD
VR
DVD
VR
[AVCHD]
AVC H DAVC H D
[MP4]
MP4MP4
[MPEG2]
MPEG2MPEG2
The current title will be
played back repeatedly.
One Track Repeat
[CD]
CDCD
[MP3]
MP3MP3
[FLAC]
FLACFLAC
[AAC]
AACAAC
[WAV]
WAVWAV
The current track or file will
be played back repeatedly.
All Repeat
[CD]
CDCD
[FLAC]
FLACFLAC
[MP3]
MP3MP3
[AAC]
AACAAC
[WAV]
WAVWAV
All tracks in the media will
be played back repeatedly.
Playlist Repeat
[DVD Video]
DVD
VR
DVD
VR
Playlist in the media will be
played back repeatedly.
Folder Repeat
[MP4]
MP4MP4
[MPEG2]
MPEG2MPEG2
The current group (folder) will
be played back repeatedly.
Shuffle Repeat (Audio CD)
[CD]
CDCD
Repeats the random
playback.
Shuffle Repeat
(MP3 / FLAC / AAC)
[MP3]
MP3MP3
[FLAC]
FLACFLAC
[AAC]
AACAAC
[WAV]
WAVWAV
Repeats the random
playback in a folder.
5. Press [ OPTIONS U ] to exit.
NoteD
• The repeat setting will be canceled when you stop
playback.
• When the repeat setting is set for an audio CD track, the
repeat setting will be canceled if you select other track
to play back.
• When the repeat setting is set for an MP3, FLAC, AAC or
WAV folder (file), the repeat setting will be canceled if
you select other MP3, FLAC, AAC or WAV folder (file) to
play back.
8.7. Slide Show
[JPEG]
JPEGJPEG
1. Follow steps 1 to 2 in “Playing Back a Disc” on page
25.
2. Open the folder which contains the desired JPEG
files.
3. Use [ K / L / 0 / 1 ] to select a desired file to be
played back, then press [ B (play)].
• An image will be played back from the selected file
and go to the next one in turn every 10 seconds.
• If [OK] is pressed instead of [ B (play)], only selected
files will be repeatedly displayed.
If [ B (play)] is pressed or [ OPTIONS U ]
“Operation Menu” “Start Slideshow” is selected,
Slideshow will start.
NoteD
• Large-size JPEG files take a few moments to be
displayed.
EN 32
8.8. PiP (BONUSVIEW™) Setting
[BD Video]
BD
VIDEO
BD
VIDEO
Some BD-videos have the PiP function which enables you
to display the secondary video in the primary video.
Primary
video
Secondary
video
1. During playback, press [ OPTIONS U ] .
2. Use [ K / L ] to select “Operation Menu”, then press
[OK].
3. Use [ K / L ] to select “Secondary Video”, then press
[OK].
4. Use [ K / L ] to select “Video”, then press [OK].
5. Use [ K / L ] to select the secondary video you want
toshow.
• The secondary video will be displayed with the
secondary audio.
6. Press [ OPTIONS U ] to exit.
• On how to output the secondary audio, refer to
“Switching Audio Soundtrack” on page 34 and
“BD-Video Secondary Audio” on page 39.
8.9. Enjoying BD-Live™ Discs Using the
Internet
[BD Video]
BD
VIDEO
BD
VIDEO
You can enjoy BD-Live™ which enables you to use
interactive features when the unit is connected to the
Internet.
Examples of BD-Live™ features:
• Online access to additional content such as movie
trailers, subtitles, BD-J applications, etc.
• While downloading, special video data may be played
back.
– Service and functions differ depending on the disc.
Follow the instructions given by the disc when
using the BD-Live™ function.
– Insert a USB storage device of at least 1GB capacity
before using BD-Live™ features on a Blu-ray Disc™.
– Do not remove the USB storage device while using
BD-Live™ features.
NoteD
• You must connect the unit to the Internet and set up
necessary settings in order to use BD-Live™.
• For the network connection, refer to “Connection to the
Network” on page 17.
• For the network setup, refer to “Network Installation” on
page 43.
• Depending on your connection environment, it may
take time to connect to the Internet or the Internet may
not be connected.
• When BD-Live™ functions are used and the unit is
connected to the Internet, you may be charged for this
communication.
• Some discs with BD-Live™ function require memory
when playing back the content. If you cannot play back
a disc with BD-Live™ function, insert a USB storage
device (1 GB or more) which is formatted on this unit.
NoteD for AACS Online
• The player or disc IDs may be sent to the content
provider when playing back a disc with BD-Live™
function.
• If you save your viewing history on the server by using
these IDs, you will be introduced to other similar movies.
EN 33
8.10. Title / Chapter Search
[UHDBD]
UHD
BD
UHD
BD
[BD Video]
BD
VIDEO
BD
VIDEO
[DVD Video]
DVD
VIDEO
DVD
VIDEO
[DVD Video]
DVD
VR
DVD
VR
[AVCHD]
AVC H DAVC H D
C Using [ S (previous)] / [ T (next)]
1. During playback, press [ T (next)] to skip the
current title or chapter and move to the next.
The title or chapter will move forward one at a time.
• If there is no chapter in one title, the current title
may be skipped.
To go back to the beginning of the current title or
chapter, press [ S (previous)].
Press [ S (previous)] repeatedly to go to the previous
title or chapter. The title or chapter may move
backward one at a time.
C Using [the Number buttons] (Direct Search)
Chapter Search
1. During playback of a title, enter the chapter number
you want to search using [the Number buttons].
2. Press [OK].
Title Search
1. While the background screen is displayed, enter
the title number to search using
[the Number
buttons]
.
2. Press [OK].
NoteD
• Playback of the title/chapter will start in a few seconds.
• As for the BD-video, how it performs will be strongly
determined by the disc, and may not perform as
described.
• If a non-existent chapter is specified, it jumps to the last
chapter.
8.11. Track Search
[CD]
CDCD
[MP3]
MP3MP3
[AAC]
AACAAC
[MP4]
MP4MP4
[FLAC]
FLACFLAC
[WAV]
WAVWAV
[JPEG]
JPEGJPEG
1. During playback, press [ T (next)] to skip the
current track or file and move to the next.
The track / file will move forward one at a time. To go
back to the beginning of the current track / file, press
[ S (previous)].
Press it repeatedly to go to the previous track / file.
The track / file will move backward one at a time.
8.12. Switching Subtitles
Some video materials may have subtitles in one or
more languages. For commercially available discs, the
supported languages can be found on the disc case.
Follow the steps below to switch the subtitle language
during playback.
[UHDBD]
UHD
BD
UHD
BD
[BD Video]
BD
VIDEO
BD
VIDEO
1. During playback, press [ OPTIONS U ] .
2. Use [ K / L ] to select “Operation Menu”, then press
[OK].
3. Use [ K / L ] to select “Subtitle Settings”, then press
[OK].
4. Use [ K / L ] to select “Subtitle” or “Subtitle Style”,
then press [OK].
“Subtitle”: Sets the subtitle for the primary/
secondary video.
“Subtitle Style”: Sets style of the subtitle.
5. Use [ K / L ] to select your desired subtitle or style.
6. Press [ OPTIONS U ] to exit.
[DVD Video]
DVD
VIDEO
DVD
VIDEO
[AVCHD]
AVC H DAVC H D
1. During playback, press [ OPTIONS U ] .
2. Use [ K / L ] to select “Operation Menu”, then press
[OK].
3. Use [ K / L ] to select “Subtitle Settings”, then press
[OK].
4. Use [ K / L ] to select “Subtitle”, then press [OK].
5. Use [ K / L ] to select your desired subtitle.
6. Press [ OPTIONS U ] to exit.
NoteD
• Some discs will only allow you to change the subtitles
from the disc menu or pop-up menu.
Press [TOP MENU] to display the disc menu or pop-up
menu.
• If the disc has no subtitle language, “Off” will be
displayed on the TV screen.
• If the disc has no subtitle style, “ None ” will be displayed
on the TV screen.
EN 34
8.13. Switching Audio Soundtrack
When playing back video material recorded with two
or more soundtracks (these are often in different audio
languages or audio formats), you can switch them during
playback. For Blu-ray Disc™, available audio varies
depending on the “BD-Video Secondary Audio” setting.
Refer to page 39 for more information.
[UHDBD]
UHD
BD
UHD
BD
[BD Video]
BD
VIDEO
BD
VIDEO
C Primary setting
1. During playback, press [ OPTIONS U ] .
2. Use [ K / L ] to select “Operation Menu”, then press
[OK].
3. Use [ K / L ] to select “Soundtrack”, then press [OK].
4. Use [ K / L ] to select your desired audio stream
channel.
5. Press [ OPTIONS U ] to exit.
C Secondary setting
1. During playback, press [ OPTIONS U ] .
2. Use [ K / L ] to select “Operation Menu”, then press
[OK].
3. Use [ K / L ] to select “Secondary Video”, then press
[OK].
4. Use [ K / L ] to select “Soundtrack”, then press [OK].
5. Use [ K / L ] to select your desired audio stream
channel.
6. Press [ OPTIONS U ] to exit.
[DVD Video]
DVD
VIDEO
DVD
VIDEO
[AVCHD]
AVC H DAVC H D
1. During playback, press [ OPTIONS U ] .
2. Use [ K / L ] to select “Operation Menu”, then press
[OK].
3. Use [ K / L ] to select “Soundtrack”, then press [OK].
4. Use [ K / L ] to select your desired audio stream
channel.
5. Press [ OPTIONS U ] to exit.
[DVD Video]
DVD
VR
DVD
VR
[MP4]
MP4MP4
[MPEG2]
MPEG2MPEG2
1. During playback, press [ OPTIONS U ] .
2. Use [ K / L ] to select “Operation Menu”, then press
[OK].
3. Use [ K / L ] to select “Audio Channel”, then press
[OK].
4. Use [ K / L ] to select your desired audio channel.
“LR” : Both right and left channels are active (stereo).
“L ” : Only left channel is active.
“R” : Only right channel is active.
5. Press [ OPTIONS U ] to exit.
NoteD
• The secondary audio will not be output when the
secondary video is not displayed or when “BD-Video
Secondary Audio” is set to “Off”. (For some Blu-ray™
discs, secondary audio will be output even when
secondary video is off.)
• The sound mode cannot be changed during playback of
discs not recorded in multiple audio mode.
• Some discs allow changing the audio language setting
on the disc menu. (Operation varies depending on the
discs. Refer to the manual accompanying the disc.)
• If the disc has no audio language, “Off” will be displayed
on the TV screen.
8.14. Switching Camera Angles
[UHDBD]
UHD
BD
UHD
BD
[BD Video]
BD
VIDEO
BD
VIDEO
[DVD Video]
DVD
VIDEO
DVD
VIDEO
Some BD-videos and DVD-videos contain scenes which
have been shot simultaneously from various angles. You
can change the camera angle.
1. During playback, press [ OPTIONS U ] .
2. Use [ K / L ] to select “Operation Menu”, then press
[OK].
3. Use [ K / L ] to select “Angle”, then press [OK].
4. Use [ K / L ] to select your desired angle.
5. Press [ OPTIONS U ] to exit.
EN 35
8.15. JPEG Status
[JPEG]
JPEGJPEG
You can confirm the status of the JPEG file being
displayed.
1. During playback, press [ OPTIONS U ] .
2. Use [ K / L ] to select “Operation Menu”, then press
[OK].
3. Use [ K / L ] to select “Status”, then press [OK].
4. Use [ K / L ] to select your desired setting.
“Off” : Date and detailed information will not be
displayed.
“Date” : The date and time at which this picture file
was created
“Details” : Detailed information on the picture file
– Date:
The date and time at which this picture
was taken
– Size:
The size of this picture (width x height)
– Manufacturer:
The manufacturer's name of the device
used to shoot this picture
– Equipment:
The model name of the device used to
shoot this picture
– Track Number:
The Track number of the picture file
being displayed
5. Press [ OPTIONS U ] to exit.
8.16. JPEG Rotation
[JPEG]
JPEGJPEG
You can rotate the JPEG picture 90 degrees to the Left/
Right.
1. While viewing, press [ OPTIONS U ] .
2. Use [ K / L ] to select “Operation Menu”, then press
[OK].
3. Use [ K / L ] to select “Rotate Left” or "Rotate Right",
then press [OK].
“Rotate Left” : Turns the picture 90 degrees to the Left.
“Rotate Right” : Turns the picture 90 degrees to the
Right.
NoteD
• Rotation setting will be cleared when viewing is
stopped.
8.17. Playback Information Window
[UHDBD]
UHD
BD
UHD
BD
[BD Video]
BD
VIDEO
BD
VIDEO
[DVD Video]
DVD
VIDEO
DVD
VIDEO
You can confirm the information on the video
being played.
1. During playback, press [ OPTIONS U ] .
2. Use [ K / L ] to select “Operation Menu”, then press
[OK].
3. Use [ K / L ] to select “Playback Information
Window”, then press [OK].
C Playback Information Window
1920x1080/24p HDR/BT.2020 YCbCr4:2:0/8bit
YCbCr4:4:4/8bit
MPEG-4 AVC
0.6Mbps
16.3Mbps
5.1ch
1080/60i SDR/BT.709
-- - - --
---
HTDH
1920x1080/24
p
H
DR/BT.202
0
Y
CbCr4:2:0/8
bit
MPE
G
-4 A
VC
0.6Mbps
1
6
5.1ch
HTDH
1 2 3 4 5 6 7 8 9 10
1 Audio icon
2 Video icon
3 Video Resolution / Video Frame Rate
4 Stream Type
5 Dynamic Range Information / Color Gamut
6 Chroma Sampling / Bits per Primary Color
7 Number of Audio Channels
8 Video Codec
9 Audio Bit Rate
10 Video Bit Rate
44.1kHz
-
1920x1080/24p HDR/BT.2020 YCbCr4:2:0/8bit
YCbCr4:4:4/8bit
MPEG-4 AVC
0.6Mbps
16.3Mbps
5.1ch
1080/60i SDR/BT.709
- - - 5.1ch
--
HTDH
Digital
44
.
1kH
z
-
1
920x108
0/24
p
HDR/
BT.2
020
YCbCr4:2
:0/8
bit
YCbCr4:4:4
/
8bi
t
MPEG
-4 A
VC
0.6Mb
ps
16.3
Mbps
5
.1c
h
1
080
/
60
i
S
DR
/
BT.70
9
--
-
5
.1c
h
--
H
TDH
Digita
l
1 2
3 4 5 6 7
8 9 10
Digita
l
1 Video information from the HDMI OUT port
2 Audio information from the HDMI OUT (AUDIO) port
3 HDMI Video icon
4 HDMI Audio icon
5 HDMI Video Resolution / HDMI Video Frame Rate
6 Dynamic Range Information/Color Gamut
7 Chroma Sampling / Bits per Primary Color
8 Audio Codec
9 Number of Audio Channels
10 Audio Sampling Frequency
EN 36
8.18. Reception
[DLNA P]
DLNA
VIDEO
DLNA
VIDEO
[DLNA M]
DLNA
MUSIC
DLNA
MUSIC
[DLNA P]
DLNA
DLNA
You can confirm the wireless network status.
1. During playback, press [ OPTIONS U ] .
2. Use
[ K / L ] to select “Operation Menu”, then press
[OK].
3. Use
[ K / L ] to select “Reception", then press [OK].
• It is not available for wired connection.
4. Press [ BACK Y ] to exit.
8.19. Closed Caption
This unit supports Closed Caption. Available media are as
follows:
BD BD-RE (BDMV)
BD-R (BDMV)
Ultra HD Blu-ray, Blu-ray
DVD DVD-R (Video Format/VR/AVCHD)
DVD-RW (Video Format/VR/AVCHD)
+R (AVCHD)
+RW (AVCHD)
DVD-Video
USB storage device MP4/MPEG2 (TS/PS)
DLNA MP4/MPEG2 (TS/PS)
Network Service Netflix/YouTube™
Closed Caption will be displayed when:
– “Closed Caption Display” is set to “On”
– The video being played has Closed Caption
– Playing in normal speed
C Closed Caption Display
Enables/Disables Closed Caption.
1. During playback, press [ OPTIONS U ] .
2. Use [ K / L ] to select “Operation Menu”, then press
[OK].
3. Use [ K / L ] to select “Closed Caption Display” then
press [OK].
4. Use [ K / L ] to select “On” or “Off”, then press [OK].
“On”: Enables Closed Caption
“Off”: Disables Closed Caption
5. Press [ OPTIONS U ] to exit.
C Closed Caption Type
Configures the Closed Caption Type.
1. During playback, press [ OPTIONS U ] .
2. Use
[ K / L ] to select “Operation Menu”, then press
[OK].
3. Use
[ K / L ] to select “Closed Caption Type", then
press [OK].
4. Use
[ K / L ] to select “Analog CC" or "Digital CC”,
then press [OK].
“Analog CC” : Enables Analog Closed Caption. It is
effective for disc, USB, DLNA playback.
“Digital CC” : Enables Digital Closed Caption. It is
effective for content playback on the
network services, disc, USB, DLNA.
5. Press [ OPTIONS U ] to exit.
C Analog CC
Configures Analog Closed Caption settings.
1. During playback, press [ OPTIONS U ] .
2. Use
[ K / L ] to select “Operation Menu”, then press
[OK].
3. Use
[ K / L ] to select “Analog CC", then press [OK].
4. Use
[ K / L ] to select “CC1”-“CC4”, then press [OK].
5. Press
[ OPTIONS U ] to exit.
C Digital CC
Configures Digital Closed Caption settings.
1. 1. During playback, press [ OPTIONS U ] .
2. 2. Use [ K / L ] to select “Operation Menu”, then
press [OK].
3. 3. Use [ K / L ] to select “Digital CC”, then press [OK].
4. 4. Use [ K / L ] to select “CC1”-“CC6”, then press
[OK].
5. Press
[ OPTIONS U ] to exit.
EN 37
8.20. Luminance/Color Adjustment
[UHDBD]
UHD
BD
UHD
BD
[BD Video]
BD
VIDEO
BD
VIDEO
[DVD Video]
DVD
VIDEO
DVD
VIDEO
[DVD Video]
DVD
VR
DVD
VR
[AVCHD]
AVC H DAVC H D
[JPEG]
JPEGJPEG
[MP4]
MP4MP4
[MPEG2]
MPEG2MPEG2
Adjusts the picture quality.
1. During playback, press [ OPTIONS U ] .
2. Use [ K / L ] to select “Video Settings”, then press
[OK].
3. Use [ K / L ] to select “Luminance/Color
Adjustment”, then press [OK].
4. Use [ K / L ] to select “Contrast”,“Brightness”,“Color
Saturation” or “Hue”, then press [OK].
5. Use [ 0 / 1 ] to change the value.
6. After completion of value change, then press
[ BACK Y ] .
7. Press
[ OPTIONS U ] to exit.
8.21. Progressive
[BD Video]
BD
VIDEO
BD
VIDEO
[DVD Video]
DVD
VIDEO
DVD
VIDEO
[DVD Video]
DVD
VR
DVD
VR
[AVCHD]
AVC H DAVC H D
[MP4]
MP4MP4
[MPEG2]
MPEG2MPEG2
Configures the optimal picture output method for
progressive videos.
1. During playback, press [ OPTIONS U ] .
2. Use [ K / L ] to select “Video Settings”, then press
[OK].
3. Use [ K / L ] to select “Progressive”, then press [OK].
4. Use [ K / L ] to select “Auto” or “Video”, then press
[OK].
“
Auto”: Automatically adjusts the picture.
“Video”: Used if the picture is flickering or blurred
with “Auto”.
5. Press
[ OPTIONS U ] to exit.
8.22. Reset to Default Picture Settings
[UHDBD]
UHD
BD
UHD
BD
[BD Video]
BD
VIDEO
BD
VIDEO
[DVD Video]
DVD
VIDEO
DVD
VIDEO
[DVD Video]
DVD
VR
DVD
VR
[AVCHD]
AVC H DAVC H D
[JPEG]
JPEGJPEG
[MP4]
MP4MP4
[MPEG2]
MPEG2MPEG2
Resets the picture qulity settings to their default settings.
1. During playback, press [ OPTIONS U ] .
2. Use [ K / L ]to select “Video Settings”, then press
[OK].
3. Use [ K / L ] to select “Reset to Default Picture
Settings”, then press [OK].
4. Use [ 0 / 1 ] to select “Yes” or “No”, then press [OK].
“Yes”: Resets the picture settings.
“No”: Will not reset the picture settings.
5. Press [ OPTIONS U ] to exit.
8.23. Dialogue Enhancer
[UHDBD]
UHD
BD
UHD
BD
[BD Video]
BD
VIDEO
BD
VIDEO
[DVD Video]
DVD
VIDEO
DVD
VIDEO
[DVD Video]
DVD
VR
DVD
VR
[AVCHD]
AVC H DAVC H D
[MP4]
MP4MP4
[MPEG2]
MPEG2MPEG2
Enhances voices in movies.
1. During playback, press [ OPTIONS U ] .
2. Use [ K / L ] to select “Audio Settings”, then press
[OK].
3. Use [ K / L ] to select “Dialogue Enhancer”, then
press [OK].
4. Use [ K / L ] to select “On” or “Off”, then press [OK].
“On”: Enables “Dialogue Enhancer”.
“Off”: Disables “Dialogue Enhancer”
5. Press [ OPTIONS U ] to exit.
EN 38
9. NETWORK SERVICES
9.1. Before Using Network Services
Please follow the instructions below before using network
features.
1. Connect this unit to the Internet.
• Refer to “Connection to the Network” on page 17.
2. Set up the necessary network connection settings.
• Refer to “Network Installation” on page 43.
3. Press [NETFLIX] or [YouTube].
• Net TV screen will appear.
• Network Services can also be accessed by
[ Q (home)] “Browse Net TV”.
When Net TV is launched from “Browse Net TV” in
the Home menu for the first time, the Terms of Use
message screen will appear.
4. Press [ Q (home)] to exit.
C Guide to Net TV menu screen
NetTV
1
1 Network Service icons:
• Display service icons
9.2. Information on Network Services
For detailed information on 3rd party Internet services,
please visit the service providers website:
Netflix: http://www.netflix.com/HowItWorks
YouTube: http://www.youtube.com
EN 39
10. LIST OF SETTINGS
In the setup menu, you can customize various kinds of settings as you prefer.
Refer to the following instructions to navigate through the setup menu.
1. Press [ Q (home)] to access the home menu.
2. Use [ K / L / 0 / 1 ] to select “Setup”, then press [OK].
3. Use [ K / L ] to select the desired setting, then press [OK].
4. Use [ K / L ] to move the highlight up and down in the list.
5. To make a selection or to access options of an item, select the desired item, then press [OK].
• To go back to the previous screen, press [ BACK Y ] .
6. Press [ Q (home)] to exit.
Refer to the following table for the types of settings you can customize.
The item with the grey is the default setting.
Category Menus / Oprions
HDMI
Resolution
Auto / 480p / 1080i / 1080p / 4K
4k/60p Output
4K/60p(4:4:4) / 4K/60p(4:2:0) / Off
24p Output
Auto / Off
Advanced Settings
Deep Color Output
Auto / Off
High Dynamic Range Output
Auto / Off
Contents Type Flag
Auto / Off
7.1ch Audio Reformatting
Auto / Off
Video
Still Mode (paused video)
Auto / Field / Frame
Audio
Dynamic Range Compression
On / Off / Auto
Digital Audio Output
DD/DD+/DTHD
Bitstream / PCM
DTS/DTS-HD
Bitstream / PCM
BD-Video Secondary Audio
On / Off
Downmix
Stereo / Surround encoded
Audio Delay 0 - 250ms (by 10ms)
3D
3D BD-Video Playback
Auto / Set before play
EN 40
Category Menus / Oprions
Language
Audio Language
English / French / Spanish / Original / Other
Subtitle Language
Auto / English / French / Spanish / Other
Menu Language
English / French/ Spanish / Other
On-screen Language
English / French / Spanish
Closed Caption
Closed Caption Display
On / Off
Closed Caption Type
Analog CC / Digital CC
Analog CC
CC1 - CC4
Digital CC
CC1 - CC6
Manual setting
Font Color
Auto / White / Black / Red / Green / Blue / Yellow /
Magenta / Cyan
Font Size
Auto / Normal / Small / Large
Font Style
Auto / Monospaced with serifs / Proportionally
spaced with serifs / Monospaced without serifs /
Proportionally spaced without serifs / Casual font
type / Cursive font type / Small capitals
Font Opacity
Auto / Solid / Translucent / Transparent
Font Edge
Auto / None / Raised / Depressed / Uniform / Left
drop shadowed / Right drop shadowed
Font Edge Color
Auto / White / Black / Red / Green / Blue / Yellow /
Magenta / Cyan
BG Color
Auto / White / Black / Red / Green / Blue / Yellow /
Magenta / Cyan
BG Opacity
Auto / Solid / Translucent / Transparent
Window Color
(
*
)
Auto / White / Black / Red / Green / Blue / Yellow /
Magenta / Cyan
Window Opacity
(
*
)
Auto / Solid / Translucent / Transparent
CC Reset
Network
Easy Network Setting
Network Settings
LAN Connection Mode
Wired / Wireless
Wireless Settings
IP Address/DNS Settings
Connection Test
IP Address Auto Configuration
On / Off
IP Address Displays the input screen.
Subnet Mask Displays the input screen.
Default Gateway Displays the input screen.
DNS Auto Configuration
On / Off
Primary DNS Displays the input screen.
Secondary DNS Displays the input screen.
Proxy Server Settings
Reset to factory preset
Yes / No
Proxy Address
Proxy Port Number Displays the input screen.
Connection Test
Network Service Settings
Setting Unit Name
Audio Auto Gain Control
On / Off
Terms of Use
BD-Live Internet Access
Allow (ALL) / Allow (Limited) / Prohibit
Ratings
DVD-Video Ratings
8 No Limit / 7 / 6 / 5 /4 /3 /2 /1 / 0 Lock All
BD-Video Ratings
No Limit / 0-21 year(s) / Enter year(s)
(
*
)
These settings are not available for the analog closed captioning.
EN 41
Category Menus / Oprions
System
Easy Setting Yes / No
Display Settings
Status Message
Auto / Off
EasyLink
On / Off
Quick Start
On / Off
Firmware Update
Automatic Update Check
On / Off
Update Now
System Information
License & Digital Rights Mgmt
Firmware Version Information Main Version:
Wireless LAN module:
ESN:
Restore Default Settings Yes / No
EN 42
11. SETUPS
11.1. HDMI Video
Q (home) “Setup” “Player Settings” “HDMI” “Resolution”
Set the resolution of the video signal being output from
the HDMI OUT jack.
You can select the desired “HDMI Video” among the
settings listed below:
“Auto”, “480p”, “1080i”, “1080p”, “4K”
Actual Output Resolution:
Setting in the
“HDMI Video”
Source
720 x 480
(30i)
1280 x 720
(60p)
1920 x 1080
(30i)
1920 x 1080
(24p)
1920 x 1080
(60p)
3840 x 2160
(24p)
3840 x 2160
(60p)
480p
720x480
(60p)
720x480
(60p)
720x480
(60p)
720x480
(60p)
720x480
(60p)
720x480
(60p)
720x480
(60p)
1080i
1920x1080
(60i)
1920x1080
(60i)
1920x1080
(60i)
1920x1080
(24p)
1920x1080
(60i)
1920x1080
(24p)
1920x1080
(60i)
1080p
1920x1080
(60p)
1920x1080
(60p)
1920x1080
(60p)
1920x1080
(24p)
1920x1080
(60p)
1920x1080
(24p)
1920x1080
(60p)
4K
3840x2160
(60p)
3840x2160
(60p)
3840x2160
(60p)
3840x2160
(24p)
3840x2160
(60p)
3840x2160
(24p)
3840x2160
(60p)
Auto
The highest resolution supported by your display device will be
in effect automatically.
• The resolution listed in the above chart will be enabled
on this unit when the “4K/60p Output” is set to
“4K/60p(4:4:4)”, and the “24p Output” is set to “Auto”.
• For AVCHD, outputting the video in 24 frames per
second (1080p/24) is not available.
NoteD
• The selected resolution must also be supported by your
display device.
• Even if “HDMI Resolution” is set to “4K”, the video of
a non-4K compatible Blu-ray Disc™ will be output in
the video resolution that is specified by the Disc and
supported by the display device.
• Refer also to your TV’s manual.
• When connected to an HDCP incompatible display
device, the picture will not be displayed properly.
• The audio signals from the HDMI OUT jack (including
the sampling frequency, the number of channels and bit
length) may be limited by the device that is connected.
• Among the display device(s) that support HDMI, some
do not support audio output (for example, projectors).
While connected to a device such as a projector, audio
will not be output from the HDMI OUT jack.
• When this unit’s HDMI OUT jack is connected to a DVI-D
compatible display device(s) (HDCP compatible) with
an HDMI-DVI converter cable, the signals are output in
digital RGB.
• When playing back a Frame Sequential 3D Disc, video
resolution of output picture will depend on contents
on the disc. (“HDMI Video” setting is not applicable for
Frame Sequential 3D Discs.)
Copyright protection system
To play back the digital video images of a BD-video
or DVD-video via an HDMI connection, it is necessary
that both the player and the display device (or an AV
receiver / amplifier) support a copyright protection
system called HDCP (high-bandwidth digital content
protection system). HDCP is copy protection technology
that comprises data encryption and authentication of the
connected AV device. This unit supports HDCP.Please
read the operating instructions of your display device (or
an AV receiver / amplifier) for more information.
Note that 4K content viewing requires an HDCP 2.2
compatible TV and cables.
11.2. High Dynamic Range Output
Q (home) “Setup”
“Player
Settings”
“HDMI”
“Advanced
Settings”
“High Dynamic
Range Output”
This setting is only available during Ultra HD Blu-ray
playback.
“Auto”: outputs an HDR-enhanced video according to the
video and the connected devices' specifications.
Note that the display device must also be HDR-
compatible.
“Off”: Outputs a video in 2K quality.
NoteD
• If a video does not display correctly, select “Off”.
EN 43
11.3. Network Installation
Q (home) “Setup”
“Player
Settings”
“Network” “Network Settings”
Set up network connection settings in order to use the
BD-Live™, Netflix / YouTube™ or network update function.
C Connection Test
After you enable a network connection or change the
network settings, always perform the connection test to
check if the connection is correctly made.
1. Use [ 0 / 1 ] to select “Setup” in the home menu,
then press [OK].
2. Use [ K / L ] to select “Player Settings”, then press
[OK].
3. Use [ K / L ] to select “Network”, then press [OK].
4. Use [ K / L ] to select “Network Settings”, then press
[OK].
5. Use [ K / L ] to select “IP Address/DNS Settings” or
“Proxy Server Settings”, then press [OK].
6. Use [ K / L ] to select “Connection Test”, then press
[OK].
• Connection test will start automatically and the test
result will appear right after the connection test
finishes.
– “Testing...”: The test is in progress.
– “Pass”: Connection test is successfully
completed.
– “Failed”: Connection test failed. Check the
connection settings.
7. Press [OK] to go back to the setup menu, or press
[ Q (home)] to exit.
NoteD
• If the connection test passes, you are ready to use
the BD-Live™, Netflix / YouTube™ or network update
function, using the Internet without making any
additional settings.
• If the connection test fails, you may need to check your
router settings and make sure the physical connection
is secure. If you need the MAC address of this unit to
complete your router settings you can view it on the
“Network Settings” screen.
• When connecting this unit directly to a modem for
the first time or connecting it to a modem which was
previously connected to any other network device (e.g.
a router, PC, etc.), you may have to power cycle the
modem to reset the settings on the modem.
C Wired
Easy Network Setting
Select “Easy Network Setting” to set the network setting
automatically.
1. Press [ Q (home)] and select “Setup” “Player
Settings”
“Network”, then press [OK].
2. Use [ K / L ] to select “Easy Network Setting”, then
press [OK].
3. Use [ K / L ] to select “Wired”, then press [OK].
• The unit will start the connection test automatically
and the test result will appear right after the
connection test finishes.
4. Press [OK].
Network Settings
In following cases, select “Network Settings” to configure
each setting as necessary.
– When connection test failed with the setting of “Easy
Network Setting”.
– When instructed by your Internet service provider to
make specific settings in accordance with your network
environment.
1. Press [ Q (home)] and select “Setup” “Player
Settings”
“Network”, then press [OK].
2. Use [ K / L ] to select “Network Setting”, then press
[OK].
3. Use [ K / L ] to select “Wired”, then press [OK].
4. Use [ K / L ] to select “IP Address/DNS Settings”
“IP Address Auto Configuration”
”Off”, then press
[OK].
5. Use [ K / L ] to select “IP Address”, then press [OK].
6. “IP Address” setting screen will appear. Enter IP
address with cursor buttons and number buttons.
H
DMI
Vi
d
e
o
Audio
3
D
L
anguage
Network
R
at
i
ngs
Syste
m
IP Address
Please input IP Address.
192 . . .168 XXX XXX
L
• Enter the IP address after checking the
specifications of your router.
• If the IP address is unknown, check the IP address
of other devices. (e.g. PC connected via LAN cable)
and assign a different number from those of other
devices.
EN 44
7. After completion of value entry, press [OK].
8. A confirmation screen will appear. Select “Yes”,
then press [OK].
9. Select “Subnet Mask”, “Default Gateway”,
“DNS Auto Configuration”, “Primary DNS” and
“Secondary DNS” in turn, and enter each address
number with cursor buttons and number buttons,
then press [OK].
• Enter the DNS addresses provided by your Internet
provider.
• If the DNS address is unknown, check the DNS
address of other devices (e.g. PC connected via LAN
cable) and assign the same DNS address.
HDMI
Vide
o
Audio
3D
L
anguage
Network
Ratin
g
s
S
yste
m
Connection Test
IP Address Auto Conguration
IP Address
Subnet Mask
Default Gateway
DNS Auto Conguration
Primary DNS
Secondary DNS
----
O
192.168.XXX.XXX
255.255.255. 0
192.168.XXX.XXX
O
192.168.XXX.XXX
---.---.---.---
IP Address/DNS Settings
L
10. After completing this series of settings, perform the
“Connection Test”.
If your Internet connection requires Proxy Server
settings, perform the following:
1. Select “Network” “Network Settings”, then press
[OK].
2. Use [ K / L ] to select “Proxy Server Settings”, then
press [OK].
3. Use [ K / L ] to select “Proxy Address”, then press
[OK].
4. The “Proxy Address” setting screen will appear.
Enter a proxy address with cursor buttons, number
buttons and color key.
1 2
Shift
3 4 5 6 7 8 9 0
q w e r t y u i o p
a s d f g h j k l .
z x c v b n m @ * #
Space
/ : _ - , ; ‘ “
Delete
Finish
Symbols Alphanumeric Other Characters
Proxy Address
[ K / L / 0 / 1 ] : Move the highlight.
[OK] : Enter the highlighted number / letter.
*[Red] : Switches the Software Keyboard to
Symbol mark mode.
[Green] : Switches the Software Keyboard to
Number/Alphabet mode.
*[Blue] : Switches the Software Keyboard to
External character mode.
* These buttons can be used in other network settings.
5. After completion of address entry, select “Finish”,
then press [OK].
6. If necessary, select “Proxy Port Number” using
[ K / L ], then press [OK]
7. The “Proxy Port Number” setting screen will
appear. Enter a number using [ K / L / 0 / 1 ].
HDMI
V
ide
o
A
u
d
i
o
3
D
L
anguage
Network
Ratin
g
s
Sy
ste
m
Proxy Port Number
Input Proxy Server Port Number.
00000
L
8. After completion of value entry, press [OK].
9. A confirmation screen will appear. Select “Yes”,
then press [OK].
10. Use [ K / L ] to select “Connection Test”, then press
[OK].
11. Press [OK] to go back to the setup menu, or press
[ Q (home)] to exit.
EN 45
NoteD for “IP Address”, “Subnet Mask”, “Default
Gateway”, “Primary DNS” and “Secondary DNS”
• The range of input numbers is between 0 and 255.
• If you enter a number larger than 255, the number will
automatically be reset to 255.
NoteD for “Proxy Address” and “Proxy Port”
• The range of input numbers for the port number is
between 0 and 65535. (If you enter a number larger
than 65535, it will be regarded as 65535.)
• For proxy port, certain ports might be closed, blocked or
unusable depending on your network environment.
• Choose a connection speed in accordance with your
network environment.
• When the settings are changed, the network connection
may be disabled depending on the device.
C Wireless
Please make a note of your Wireless LAN network name
(SSID) and its WEP / TKIP+AES key before proceeding with
the setup.
Easy Network Setting
Search for Wireless LAN networks automatically and
select the Wireless LAN network name (SSID) from the list.
1. Press [ Q (home)] and select “Setup” “Player
Settings”
“Network”, then press [OK].
2. Use [ K / L ] to select “Easy Network Setting”, then
press [OK].
3. Use [ K / L ] to select “Wireless”, then press [OK].
• This unit will start searching for Wireless LAN
networks automatically.
4. The result of Wireless LAN network searching will
be displayed.
Use [ K / L ] to select the appropriate Wireless LAN
network name (SSID), then press [OK].
• If you select an SSID without “ ”, please go to step
7.
xxxxxxxxxx
xxxxxxxxxxxxxx
xxxxxxxxxxxx
xxxxxx
xxxxxxxx
Wireless Settings
Search again Easy Connect (PUSH)
Select a wireless network for connection.
Press the green button to connect via
Easy Connect (PUSH button method).
Network name (SSID) Reception
5. “Encryption Key” screen will appear. Enter the
Encryption Key of the selected Wireless LAN
network using cursor buttons, number buttons and
color key.
• If you do not know the Encryption Key for your
Wireless LAN network, ask your ISP or the person
who set up your Wireless LAN Network.
1 2
Shift
3 4 5 6 7 8 9 0
q w e r t y u i o p
a s d f g h j k l .
z x c v b n m @ * #
Space
/ : _ - , ; ‘ “
Delete
Finish
Symbols Alphanumeric Other Characters
Encryption Key (Password)
6. Use [ K / L / 0 / 1 ] to select “Finish”, then press [OK].
7. Confirmation screen will appear. Press [OK].
• Network configuration will start automatically.
8. The connection result screen will appear. Press
[OK].
NoteD
• The internal wireless LAN supports following
specifications
– Wireless LAN standards
: IEEE 802.11 b / g / n / ac
– Frequency spectrum: 2.4 / 5 GHz
– Security protocol: WEP / TKIP+AES (Strong) /
TKIP+AES (Weak)
• With a 2.4GHz wireless router (access point), using a
USB3.0 compatible device with this unit may cause
wireless connection instability. Place the wireless router
as far away as possible from this unit.
• When using a 5GHz compatible wireless router (access
point), 5GHz bandwidth use is recommended.
EN 46
Network Settings
Set up the connection to the Wireless LAN network
manually by entering the Wireless LAN network name
(SSID).
1. Press [ Q (home)] and select “Setup” “Player
Settings”
“Network”, then press [OK].
2. Use [ K / L ] to select “Network Settings”, then press
[OK].
3. Use [ K / L ] to select “Wireless”, then press [OK].
4. Use [ K / L ] to select “Wireless Settings”, then press
[OK].
5. Use [ K / L ] to select “Manual Setting”, then press
[OK].
6. “SSID” screen will appear.
Enter the SSID using cursor buttons, number
buttons and color key.
7. Use [ K / L / 0 / 1 ] to select “Finish”, then press [OK].
8. Encryption type selection screen will appear.
Select the Encryption type of the entered SSID,
then press [OK].
• If you select “No encryption”, please go to step .
• If you select “AES”, select “TKIP+AES (Strong)” or
“TKIP+AES (Weak)”, then press [OK].
AES
WEP
No encryption
Wireless Settings
Select the encryption type.
9. “Encryption Key” screen will appear.
Enter the Encryption Key of the Wireless LAN
network using cursor buttons, number buttons and
color key.
• If you do not know the Encryption Key for your
Wireless LAN network, ask your ISP or the person
who set up your Wireless LAN Network.
10. Use [ K / L / 0 / 1 ] to select “Finish”, then press [OK].
11. The connection result screen will appear. Press
[OK].
Easy Connect
You can set up the Wireless LAN connection quickly. (Easy
Connect is only available when your router supports it. For
details, please refer to the user manual of your Wireless
LAN router.)
Push Button Method
Please confirm your Wireless LAN router has a PBC
button.
1. Press [ Q (home)] and select “Setup” “Player
Settings”
“Network”, then press [OK].
2. Use [ K / L ] to select “Easy Network Setting”, then
press [OK].
3. Use [ K / L ] to select “Wireless”, then press [OK].
4. Use [ K / L ] to select the appropriate Wireless LAN
network name (SSID), then press [GREEN].
xxxxxxxxxx
xxxxxxxxxxxxxx
xxxxxxxxxxxx
xxxxxx
xxxxxxxx
Wireless Settings
Search again Easy Connect (PUSH)
Select a wireless network for connection.
Press the green button to connect via
Easy Connect (PUSH button method).
Network name (SSID) Reception
5. Push the PBC (Push Button Configuration) on your
Wireless LAN router.
6. Select “Start”, then press [OK].
• The unit will start the connection test automatically
and the test result will appear right after the
connection test finishes.
7. The connection result screen will appear. Press
[OK].
EN 47
PIN Code Method
1. Press [ Q (home)] and select “Setup” “Player
Settings”
“Network”, then press [OK].
2. Use [ K / L ] to select “Network Settings”, then press
[OK].
3. Use [ K / L ] to select “Wireless”, then press [OK].
4. Use [ K / L ] to select “Wireless Settings”, then press
[OK].
5. Use [ K / L ] to select “Easy Connect (PIN code
method)”, then press [OK].
6. Use [ K / L ] to select the appropriate router, then
press [OK].
7. Set up your Wireless LAN router with PIN code
shown on the TV screen.
• For details about setting method of your Wireless
LAN router, please refer to the user manual of the
router.
8. Select “Start”, then press [OK].
9. The unit will start the connection test automatically
and the test result will appear right after the
connection test finishes.
10. The connection result screen will appear. Press
[OK].
C Netflix ESN
You can view the ESN number which is a serial
number used by Netflix to identify a device. Netflix
customer service might ask you for this number during
troubleshooting.
1. Use [ 0 / 1 ] to select “Setup” in the home menu,
then press [OK].
2. Use [ K / L ] to select “Player Settings”, then press
[OK].
3. Use [ K / L ] to select “System”, then press [OK].
4. Use [ K / L ] to select “System Information”, then
press [OK].
5. Use [ K / L ] to select “Firmware Version
Information”, then press [OK].
6. Press [ Q (home)] to exit.
11.4. EasyLink Setup
Q (home) “Setup”
“Player
Settings”
“System”
“Display
Settings”
“Easy Link”
This unit supports Philips EasyLink, which enables your TV
(limited to Philips brand EasyLink TV) to act in conjunction
with this unit, or vice versa. Compliant TV must be
connected to the HDMI OUT jack.
When “EasyLink” setting is set to “On”, functions listed
below will be available.
One Touch Play
When the operations with following buttons of the remote
control of this unit are performed, the TV will automatically
be turned on and switched to the appropriate input
channel. (“One Touch Play” can be turned off by setting it
to “Off”.)
Buttons for one touch play:
– [ B (play)]
– [TOP MENU]
(when a disc is inserted in the unit)
System Information
Get & Set Menu Language
The unit recognizes the OSD language set of the TV, and
automatically sets the same language as the player menu
language (OSD menu language) for this unit.
• This function is only available when this unit supports
the language set on the TV.
EN 48
11.5. BD-Video Ratings
Q (home) “Setup” “Player Settings” “Ratings” “BD-Video Ratings”
Some BD-videos support parental lock which prevents
your children from viewing inappropriate videos. If the
video rating exceeds the parental lock level you have set
on your unit, playback will automatically stop. In order
to continue playback, enter your password to unlock the
function.
For the first time only:
1. Use [ 0 / 1 ] to select “Setup” in the home menu,
then press [OK].
2. Use [ K / L ] to select “Player Settings”, then press
[OK].
3. Use [ K / L ] to select “Ratings”, then press [OK].
4. Use [ K / L ] to select “BD-Video Ratings ”, then
press [OK].
5. Use [ K / L ] to select “No Limit”, “1 year”-“21 year(s)”,
“Enter Limit”, then press [OK].
6. Set any level.
7. Use [the Number buttons] to enter any 4-digit
number for your password.
Once a password is set:
1. Use [ 0 / 1 ] to select “Setup” in the home menu,
then press [OK].
2. Use [ K / L ] to select “Player Settings”, then press
[OK].
3. Use [ K / L ] to select “Ratings”, then press [OK].
4. Use [ K / L ] to select “BD-Video Ratings”, then
press [OK].
5. The Password entry screen will appear. Enter a
Password using [the Number Buttons].
6. Use [ K / L ] to select “No Limit”, “1 year” - “21 year(s)”,
“Enter Limit”, then press [OK].
7. Use [ K / L ] to select “Unlock Player”, “Change
Password”, “Change Level” or “Temporary Unlock”,
then press [OK].
“Unlock Player”: Sets the Parental Level to “No
Limit”.
“Change Password”: Changes the current Password.
“Change Level”: Changes the Parental Level.
“Temporary Unlock”: Temporarily changes the
Parental Level to “No Limit”.
(Turning this unit Off resets it to
the level previously set.)
8. Use [ K / L ] to select any level, then press [OK].
11.6. DVD-Video Ratings
For the first time only:
1. Use [ 0 / 1 ] to select “Setup” in the home menu,
then press [OK].
2. Use [ K / L ] to select “Player Settings”, then press
[OK].
3. Use [ K / L ] to select “Ratings”, then press [OK].
4. Use [ K / L ] to select “DVD-Video Ratings”, then
press [OK].
5. Use [ K / L ] to select “8 No Limit” - “0 Lock All”,
then press [OK].
6. If an option other than “8 No Limit” is selected,
the Password entry screen will appear. Use [the
Number buttons] to enter any 4-digit number for
your password.
Once a password is set :
1. Use [ 0 / 1 ] to select “Setup” in the home menu,
then press [OK].
2. Use [ K / L ] to select “Player Settings”, then press
[OK].
3. Use [ K / L ] to select “Ratings”, then press [OK].
4. Use [ K / L ] to select “DVD-Video Ratings”, then
press [OK].
5. The Password entry screen will appear. Enter a
Password using [the Number Buttons].
6. Use [ K / L ] to select “8 No Limit” - “0 Lock All”,
then press [OK].
• If an option with a lower number than the current
setting is selected, the Password entry screen
will appear. Enter a Password using [the Number
Buttons].
7. Use [ K / L ] to select “Unlock Player”, “Change
Password”, “Change Level” or “Temporary Unlock”,
then press [OK].
“Unlock Player”: Sets the Parental Level to “No
Limit”.
“Change Password”: Changes the current Password.
“Change Level”: Changes the Parantal Level.
“Temporary Unlock”: Temporarily changes the
Parental Level to “No Limit”.
(Turning this unit Off resets it to
the level previously set.)
8. Use [ K / L ] to select any level, then press [OK].
EN 49
RATING EXPLANATIONS
8 No Limit Parental control is inactive; all discs can play back.
7 DVD software of any grades
(adult / general / children) can be played back.
6 No one under 17
5 Restricted; under 17
4 Parental Guidance Recommended
3 Unsuitable for children under 13
2 Parental Guidance suggested
1 General Audience
0 Lock All Suitable for children
To cancel parental lock temporarily:
Some discs allow you to cancel parental lock temporarily.
With these discs, the message below will appear when
you try to play them back.
“Enter current password.”
Follow the instruction which appears on the TV screen
to cancel parental lock. After entering the password,
“Parental Control” appears. Select desired parental lock
level, then press [OK].
11.7. Software Update
Q
(home)
“Setup”
“Player Settings”
“System”
Firmware Update
Philips continuously tries to improve its products and we
strongly recommend that you update the software when
updates are available.
C Network Update
You can update the software by connecting the unit to the
Internet.
1. Use [ 0 / 1 ] to select “Setup” in the home menu,
then press [OK].
2. Use [ K / L ] to select “Player Settings”, then press
[OK].
3. Use [ K / L ] to select “System”, then press [OK].
4. Use [ K / L ] to select “Firmware Update”, then press
[OK].
5. Use [ K / L ] to select “Update Now”, then press
[OK].
6. Use [ 0 / 1 ] to select “Yes”, then press [OK].
• This unit will then start checking for the latest
software version.
7. Confirmation message will appear. Select “Yes”,
then press [OK].
• This unit will start downloading the latest software
version.
• When the download completes, the unit will start
updating the software version.
• It may take a while to complete the update.
8. After updating finishes, this unit will restart
automatically.
CautionC
• Please do not unplug the AC Power cord or LAN
cablewhile executing the network update.
NoteD
• In order to update the software via the Internet, you
must connect the unit to the Internet and set up
necessary settings.
• For the network connection, refer to “Connection to the
Network” on page 17.
• For the network setup, refer to “Network Installation” on
page 43.
• All settings will remain the same even if you update the
software version.
• The version of Netflix/YouTube™ will also be updated
if newer version of Netflix/YouTube™ is available when
updating the software.
EN 50
11.8. Restore Default Settings
Q (home) “Setup” “Player Settings” “System” “Default Settings”
This unit can be reset to its factory default state.
1. Use [ 0 / 1 ] to select “Setup” in the home menu,
then press [OK].
2. Use [ K / L ] to select “Player Settings”, then press
[OK].
3. Use [ K / L ] to select “System”, then press [OK].
4. Use [ K / L ] to select “Default Settings”, then press
[OK].
5. Use [ 0 / 1 ] to select “Yes”, then press [OK].
• Confirmation message will appear. Press [OK] to
complete the setting.
6. Press [ Q (home)] to exit.
11.9. License & Digital Rights Mgmt
Q (home) “Setup”
“Player
Settings”
“System”
“System
Information”
“License & Digital
Rights Mgmt”
This product includes some open source software that
is subject to the GNU General Public License (GPL), GNU
Lesser General Public License (LGPL) and/or copyright
licenses, disclaims and notices. You can confirm further
information about these in the “License & Digital Rights
Mgmt” section in “Setup” of this product. If you are
interested in obtaining GPL source code used in this
product, please contact
Open Source Team
P&F USA, Inc., PO Box 2248, Alpharetta, GA 30023-2248
USA
P&F USA Inc. does not warrant access to the Portal or to
any of the services, content, software and advertising. P&F
USA Inc. may, in its sole discretion, add or remove access
to any specific services, content, software and advertising
at any time. Although P&F USA Inc. will strive to provide a
good selection of services, content or software, P&F USA
Inc. does not warrant continued access to any specific
services, and content or software.
12. OTHER FUNCTION
12.1. Special mode
In Special mode, BD/DVD-Video Ratings (Parental Lock
settings), Progressive settings, and 4K60p Output settings
can be initialized.
1. With no Disc inserted in the unit, press [T (next)]
[1] [2] [3] on the Remote Control.
• This unit will go into Special mode, and the
. (standby/on) LED on the unit will start blinking.
2. Press [2], [3], or [4] on the Remote Control.
[2]: Initializes the Parental Lock setting.
[3]: Initializes the Progressive setting.
[4]: Initializes the 4K60p Output setting.
• After initializing any of above, or If [1] is pressed, this
unit will exit Special mode.
NoteD
• This unit will automatically exit Special mode when:
– there is no button operation for 2 minutes.
– an invalid button is pressed on the unit or Remote
Control.
EN 51
13. TROUBLESHOOTING
Problem Tip
No reaction to the remote control. Connect the product to the power outlet.
Point the remote control at the product.
Insert the batteries with the correct polarity.
Insert new batteries in the remote control.
No video signal on the display
device.
Turn on the TV.
Set the TV to the correct external input.
Ensure that the HDMI OUT (AUDIO) is NOT used to connect to the TV. The HDMI
OUT (AUDIO) port outputs the Audio only.
No audio / video signal on the
display device via HDMI cable.
If the unit is connected to the unauthorized display device with an HDMI cable,
the audio / video signal may not be output.
Perform an HDMI cable hotplug, wherein you disconnect the HDMI cable from
the TV and this unit and then reconnect it to both the devices while they are
Powered On.
Ensure that your HDMI cable is certified.
No high-definition video signal on
the TV screen.
Does the disc contain high-definition video? High-definition video is not
available when the disc does not contain it.
Does the TV support high-definition video? High-definition video is not
available when the TV does not support it.
No Ultra HD video on the TV screen. Check if your TV is 4K/HDR capable.
Use an 18Gbps high-speed HDMI cable to connect the 4K/HDR capable TV.
Set “4k/60p Output” to “4K/60p(4:4:4)”. (Refer to page 39.)
Depending on the content, it may take some time for the 4K/60p Output setting
to become effective. If the image is not output correctly after changing this
setting, stop playback, then start playback again.
Refer to your 4K/HDR TV's user manual for more information.
No 3D video on the TV screen. Check if your TV is 3D capable.
Use a 3D compatible HDMI cable to connect the 3D capable TV.
Set “3D BD-Video Playback” to “Auto”. (Refer to page 39.)
Wear 3D glasses and make sure they are switched on and in sync with your TV.
Check the battery levels of your glasses.
Refer to your 3D TV's user manual for more information.
No audio signal from the
loudspeakers of the TV screen.
Assign the audio input of the TV to the corresponding video input.
Ensure that the TV's speakers are turned on in the TV menu.
Ensure that the TV's speakers are not muted.
No audio signal from the
loudspeakers of the audio system.
Turn on the audio system.
Set the audio system to the correct external audio input.
Increase the volume level of the audio system.
Cannot play back a disc. Make sure that the product supports the disc.
Check the region code of the disc. This unit supports following region codes.
–Blu-ray Disc™: “A”
– DVD: “ALL” or “1”
For DVD-RW/-R, make sure that the disc is finalized.
Clean the disc.
USB storage device cannot be read. The format of the device is not accepted by this unit or the device is not
compatible.
Cannot play back JPEG files from
a disc.
Make sure that the disc was recorded in the UDF, ISO9660 or JOLIET format.
EN 52
Problem Tip
Cannot play back MP3/WAV/AAC/
FLAC files from a disc.
Make sure that the disc was recorded in the ISO9660 or JOLIET format.
Refer to “Recommended Specifications” on page 20
Cannot find a JPEG file. Make sure that the selected group (folder) does not contain more than 10,001
files for Blu-ray Disc™, DVD, CD, and USB storage device.
Make sure that the file extension is .jpg.
Cannot find an MP3 and WAV, AAC,
and FLAC Audio file.
Make sure that the selected group (folder) does not contain more than 10,001
files for DVD-R, CD-RW/-R, and USB storage device.
Make sure that the file extension is .mp3 for MP3, and .wav for WAV, and .m4a for
AAC, and .flac for FLAC.
Cannot play back AVCHD file. This unit cannot play back standalone AVCHD files (*.m2ts, *.mts or *.m2t) written
to a DVD. The DVD containing AVCHD files must have a proper file and folder
structure meeting AVCHD format specifications.
Please use AVCHD compliant device / software to burn or copy AVCHD
files to DVD. (Please refer to user manuals of the device / software for more
information.)
Cannot find an mp4 and MPEG2
video file.
Make sure that the selected group (folder) does not contain more than 10,001
files for USB storage device.
Make sure that the file extension is .mp4 / .mov for MP4, and .mpg / .mpeg /
.m2ts / .mts / .ts for MPEG2.
Cannot connect to the network. Check if the network connection is properly made.
Turn on the modem or router.
Check the network settings.
Check if the router and/or modem is correctly connected.
Check the BD-Live™ setting in “BD-Live Internet Access” on page 40.
When connecting directly to a modem via a LAN cable, you might need to power
cycle the modem to reset settings on the modem.
Turn Off this unit and the modem/router (if it has a Power button), then unplug
their AC Power cords. After 30 seconds, plug them back in and turn the devices
back On. If you have a telephone / Internet modem with your cable service, then
you may have to use its reset button or remove the backup battery to reset this
type of modem. Now wait for the lights to show activity and try reconnecting.
Cannot use the Wireless LAN
connection.
Once you have activated the Wireless LAN connection, please wait for 30
seconds for the connection to be established after turning on the unit, before
trying to access network features such as BD-Live™, Netflix, and YouTube™.
With Netflix, 4K titles are not
displayed, or 4K images are not
output correctly during playback.
Images may not be output correctly after changing the 4K60p Output setting. In
this case, turn Off the unit, then turn it back On.
Cannot connect to the network while
my PC is connected to the network.
Check the content of your Internet service contract to see if your Internet Service
Provider prevents multiple terminals connecting at the same time.
The capacity of the USB storage
device decreased.
Data may be written to the USB storage device when a BD-video that supports
the virtual package is used and a USB storage device is connected.
The contents of the USB storage
device cannot be read.
The USB storage device is not compatible or the contents on the USB storage
device may be damaged.
Turn off and then turn the unit on again.
Cannot use the BD-Live™ function or
download of data does not perform
properly.
Insert a USB storage device with enough capacity (1GB or more).
Check if a USB storage device is correctly inserted.
Cannot play back BD-video (BDROM
Profile 2.0).
Insert a USB storage device (1GB or more) which is formatted on this unit. Some
discs with BD-Live™ function require memory when playing back the content.
Do not remove the USB storage device during playback.
YouTube™ videos do not play
correctly.
Performance of this unit may decrease due to defects in video sources. In such
cases, turn the unit Off and turn it back On, then play a YouTube™ video again.
EN 53
13.1. Downloading an Electronic Copy
To obtain an electronic copy of this manual :
1. Point your browser to www.philips.com/support
2. Choose your country of location.
3. Enter the model number or a keyword in the “Find your product” field.
Alternatively, you can browse the catalog.
4. Click the description or model.
5. Under Product support, click “User manuals”.
13.2. Contact Us
• If you cannot resolve your problem, refer to the FAQ for this Blu-ray Disc™ Player at www.philips.com/support
If the problem remains unresolved, contact the Customer Support Center in your country.
NoteD
• Do not attempt to repair the Blu-ray Disc™ Player yourself. This may cause severe injury, irreparable damage to your
Blu-ray Disc™ Player or void your warranty.
• Please have your Blu-ray Disc™ Player model and serial number available before contacting us.
These numbers are available on the cabinet, as well as on the packaging.
EN 54
14. GLOSSARY
Aspect Ratio
The width of a TV screen relative to its height.
Conventional TVs are 4:3 (in other words, the TV screen is
almost square); widescreen models are 16:9 (the TV screen
is almost twice as wide as its height).
AVCHD
AVCHD is a new format for high definition video
camcorders which can record and play high-resolution HD
images.
BD-Live™
BD-Live™ is a BD-video (BD-ROM version 2 Profile 2.0)
which contains new functions (e.g. Internet connection), in
addition to the BONUSVIEW™ function.
Blu-ray Disc™
Blu-ray Disc™ is a next generation optical video disc which
is capable of storing much more data than a conventional
DVD. The large capacity makes it possible to benefit from
the features such as high-definition videos, multi-channel
surround sounds, interactive menus and so on.
Chapter
Just as a book is split up into several chapters, a title on a
BD-video or DVD-video is usually divided into chapters.
See also “Title”.
Cinavia™
Cinavia Notice
This product uses Cinavia technology to limit the use of
unauthorized copies of some commercially-produced
film and videos and their soundtracks. When a prohibited
use of an unauthorized copy is detected, a message will
be displayed and playback or copying will be interrupted.
More information about Cinavia technology is provided at
the Cinavia Online Consumer Information Center at http://
www.cinavia.com
To request additional information about Cinavia by mail,
send a postcard with your mailing address to: Cinavia
Consumer Information Center, P.O. Box 86851, San Diego,
CA, 92138, USA.
This product incorporates proprietary technology under
license from Verance Corporation and is protected by U.S.
Patent 7,369,677 and other U.S. and worldwide patents
issued and pending as well as copyright and trade secret
protection for certain aspects of such technology.
Cinavia is a trademark of Verance Corporation. Copyright
2004-2016 Verance Corporation. All rights reserved
by Verance. Reverse engineering or disassembly is
prohibited.
DNS Server
A server which translates Internet domain names into IP
addresses.
Dolby Audio - Dolby Digital
The system to compress digital sound developed by
Dolby Laboratories. It offers you sound of stereo (2ch) or
multichannel audio.
Dolby Audio - Dolby Digital Plus
Dolby Audio - Dolby Digital Plus is the next generation
digital audio compression technology developed as an
extension to Dolby Audio - Dolby Digital. Blu-ray Disc™
supports 7.1 multi-channel surround sound output.
Dolby Audio - Dolby TrueHD
Dolby Audio - Dolby TrueHD is a lossless coding
technology developed for next generation optical discs.
Blu-ray Disc™ supports 7.1 multi-channel surround sound
output.
DTS® (Digital Theater System)
DTS® is a multi channel surround sound system. You
can enjoy movie dynamic and realistic sound like
movie theater. DTS surround sound technologies were
developed by DTS, Inc.
DTS-HD®
DTS-HD® is a lossless coding technology developed as an
extension of the original DTS Coherent Acoustics format.
Blu-ray Disc™ supports 7.1 multi-channel surround sound
output.
Gateway
IP address of the electronic devices (such as router) which
provide Internet access.
HDMI (High-Definition Multimedia Interface)
A digital interface between audio and video source. It can
transmit component video, audio, and control signal with
one cable connection.
HDR (High Dynamic Range)
HDR is a color enhancement technology which expands
the range of the image's color luminance.
Hub
A device used for connecting multiple device to the
network.
IP Address
A set of numbers which are assigned to devices
participating in a computer network.
JPEG (Joint Photographic Experts Group)
JPEG is a method of compressing still picture files. You can
copy JPEG files on BD-RE/-R, DVD-RW/-R, CD-RW/-R,
or USB storage device from a computer and play back the
files on this unit.
EN 55
LAN (Local Area Network)
A group of computer networks covering a small area like a
company, school or home.
Local Storage
A storage area of sub contents for playing virtual packages
on BD-video.
MP3 (MPEG audio layer 3)
MP3 is a method of compressing files. You can copy MP3
files on DVD-R, CD-RW/-R, or USB storage device from
the computer and play back the files on this unit.
Netflix
Netflix is online movie rental service, offering online
streaming to customers in the United States.
PCM (Pulse Code Modulation)
The most common system of encoding digital audio,
found on CD and DAT. Excellent quality, but requires a lot
of data compared to formats such as Dolby Digital and
MPEG audio. For compatibility with digital audio recorders
(CD, MD and DAT) and AV amplifiers with digital inputs,
this unit can convert Dolby Digital, DTS, and MPEG audio
to PCM.
Proxy Server
Proxy server is a server which acts as an intermediary
between a workstation user and the Internet to ensure
security.
Region Code
Regions associate discs and players with particular areas
of the world. This unit will only play back discs that have
compatible region codes. You can find the region code
of your unit by looking on the rear panel. Some discs are
compatible with more than one region (or all regions).
Router
A networking device which distinguishes the IP address
assigned to each device and routing and forwarding
information in the computer network.
Sampling Frequency
The rate which sound is measured by a specified interval
to turn into digital audio data. The numbers of sampling in
one second defines as sampling frequency. The higher the
rate, the better the sound quality.
Subnet Mask
A mask which is used to determine what subnet an IP
address belongs to.
Title
A collection of chapters on BD-video or DVD-video. See
also “Chapter”.
Track
Audio CD uses tracks to divide up the content of a disc.
The BD-video or DVD-video equivalent is called a chapter.
See also “Chapter”.
UHD (Ultra High Definition)
Compared to HD, 4K UHD has four times the HD pixel
count.
Virtual Package
The function which copies data to other media (local
storage) from the Internet and plays secondary video,
secondary audio and subtitles at the same time. The
method of the playback varies depending on discs.
x.v.Color
“x.v.Color” is a promotion name given to the products that
have the capability to realize a wide color space based
on the xvYCC specifications and is a trademark of Sony
Corporation.
EN 56
15. LANGUAGE CODE LIST
In order to change the Language, select Q (home) “Setup” “Player Settings” “Language”, then select “Other” from
“Audio Language” / “Subtitle Language” / “Menu Language”. Use [ K / L ] to select a number and use [ 0 / 1 ] to select a
digit for the Language Code.
Language: Code
Abkhazian:
6566
Afar:
6565
Afrikaans:
6570
Albanian:
8381
Amharic:
6577
Arabic:
6577
Armenian:
7289
Assamese:
6583
Aymara:
6589
Azerbaijani:
6590
Bashkir:
6665
Basque:
6985
Bengali; Bangla:
6678
Bhutani:
6890
Bihari:
6672
Breton:
6682
Bulgarian:
6671
Burmese:
7789
Byelorussian:
6669
Cambodian:
7577
Catalan:
6765
Chinese:
9072
Corsican:
6779
Croatian:
7282
Czech:
6783
Danish:
6865
Dutch:
7876
English:
6978
Esperanto:
6979
Estonian:
6984
Faroese:
7079
Fiji:
7074
Language: Code
Finnish:
7073
French:
7082
Frisian:
7089
Galician:
7176
Georgian:
7565
German:
6869
Greek:
6976
Greenlandic:
7576
Guarani:
7178
Gujarati:
7185
Hausa:
7265
Hebrew:
7387
Hindi:
7273
Hungarian:
7285
Icelandic:
7383
Indonesian:
7378
Interlingua:
7365
Irish:
7165
Italian:
7384
Japanese:
7465
Javanese:
7487
Kannada:
7578
Kashmiri:
7583
Kazakh:
7575
Kirghiz:
7589
Korean:
7579
Kurdish:
7585
Laotian:
7679
Latin:
7665
Latvian; Lettish:
7686
Lingala:
7678
Lithuanian:
7684
Language: Code
Macedonian:
7775
Malagasy:
7771
Malay:
7783
Malayalam:
7776
Maltese:
7784
Maori:
7773
Marathi:
7782
Moldavian:
7779
Mongolian:
7778
Nauru:
7865
Nepali:
7869
Norwegian:
7879
Oriya:
7982
Pashto; Pushto:
8083
Persian:
7065
Polish:
8076
Portuguese:
8084
Punjabi:
8065
Quechua:
8185
Rhaeto-Romance:
8277
Romanian:
8279
Russian:
8285
Samoan:
8377
Sanskrit:
8365
Scots Gaelic:
7168
Serbian:
8382
Serbo-Croatian:
8372
Shona:
8378
Sindhi:
8368
Singhalese:
8373
Slovak:
8375
Slovenian:
8376
Language: Code
Somali:
8379
Spanish:
6983
Sundanese:
8385
Swahili:
8387
Swedish:
8386
Tagalog:
8476
Tajik:
8471
Tamil:
8465
Tatar:
8484
Telugu:
8469
Thai:
8472
Tibetan:
6679
Tigrinya:
8473
Tonga:
8479
Turkish:
8482
Turkmen:
8475
Twi:
8487
Ukrainian:
8575
Urdu:
8582
Uzbek:
8590
Vietnamese:
8673
Volapük:
8679
Welsh:
6789
Wolof:
8779
Xhosa:
8872
Yiddish:
7473
Yoruba:
8979
Zulu:
9085
EN 57
16. SPECIFICATIONS
General
Signal System NTSC Color
Power requirements 120 V AC, 60 Hz
Power consumption 26 W (standby: 0.2 W) when using included AC/DC Adapter (N1070UH)
Dimensions (width x height x depth) 220 x 59.5 x 220mm (8.7 x 2.4 x 8.7 inches)
Weight 3.53 lbs. (1.6 kg)
Operating temperature 41 °F (5 °C) to 95 °F (35 °C)
Operating humidity Less than 80 % (no condensation)
Terminals
USB input
TYPE A USB 3.0
Bus power current: MAX. 900mA
HDMI OUT port
HDMI jack Video: 480p, 720p, 1080i, 1080p, 1080p24, 4K/Audio
HDMI OUT(Audio) port
HDMI jack Audio
LAN terminal 10BASE-T / 100BASE-TX / 1000BASE-T
Wireless LAN (Internal) IEEE 802.11 b/g/n/ac
NoteD
• The specifications and design of this product are subject to change without notice.
EN 58
17. IMPORTANT HEALTH AND SAFETY INFORMATION FOR 3D
TELEVISIONS
Read the following information before viewing 3D television images.
CAUTION NOTICE:
1. Ambient fluorescent lighting may cause a flickering effect and direct sunlight may adversely affect the
operation of your 3D glasses.
2. DO NOT place your television near open stairwells, balconies or other objects as viewing in 3D images may
cause disorientation for some viewers resulting in falls, tripping or walking into objects.
3. If you experience (1) altered vision; (2) lightheadedness; (3) dizziness; (4) involuntary movements such as eye
or muscle twitching; (5) confusion; (6) nausea; (7) loss of awareness; (8) convulsions; (9) cramps; and/or (10)
disorientation, immediately stop watching 3D images and consult your doctor.
4. Parents should regularly monitor their children concerning the above symptoms as children and teenagers
may be more likely to experience these symptoms more frequently than adults. Watching 3D television is not
recommended for children under the age of 6 as their visual system is not yet fully developed.
5. Prolonged viewing of 3D images might cause discomfort, dizziness, eye strain, headaches or disorientation.
WARNING NOTICE:
1. Some viewers may experience an epileptic seizure or stroke when exposed to certain flashing images or
lights contained in certain television pictures or video games. If you or any of your family has a history of
epilepsy or stroke, please consult your doctor before viewing 3D images.
2. DO NOT watch 3D television if you are pregnant, elderly, sleep-deprived, suffering from serious medical
conditions, in poor physical condition or under the influence of alcohol.
3. Sitting too close to the screen for an extended period of time may damage your eyesight. The ideal distance
should be at least three times the height of the TV screen and at the viewer’s eyes level.
4. Wearing the 3D glasses for any reason other than viewing 3D television (as general spectacles, sunglasses,
protective goggles, etc.) may physically harm you or weaken your eyesight.
5. If you experience any discomfort while viewing 3D images, stop and do not immediately engage in any
potentially hazardous activity such as driving a car until your symptoms have disappeared. If your symptoms
persist, do not resume watching 3D images without consulting your doctor.
EN 59
18. ONE (1) YEAR LIMITED WARRANTY
This warranty gives you specific legal rights. You may have other rights which vary from state/province to state/province.
P&F USA, Inc.
PO Box 2248 Alpharetta, GA 30023-2248
WARRANTY COVERAGE:
This warranty obligation is limited to the terms set forth below.
WHO IS COVERED:
This product is warranted to the original purchaser or the person
receiving the product as a gift against defects in materials
and workmanship as based on the date of original purchase
(“Warranty Period”) from an Authorized Dealer. The original sales
receipt showing the product name and the purchase date from an
authorized retailer is considered such proof.
WHAT IS COVERED:
This warranty covers new products if a defect in material or
workmanship occurs and a valid claim is received within the
Warranty Period. At its option, the company will either (1) repair
the product at no charge, using new or refurbished replacement
parts, or (2) exchange the product with a product that is new or
which has been manufactured from new, or serviceable used
parts and is at least functionally equivalent or most comparable to
the original product in current inventory, or (3) refund the original
purchase price of the product.
The Company warrants replacement products or parts provided
under this warranty against defects in materials and workmanship
from the date of the replacement or repair for ninety (90) days
or for the remaining portion of the original product’s warranty,
whichever provides longer coverage for you. When a product or
part is exchanged, any replacement item becomes your property
and the replaced item becomes the company’s property. When a
refund is given, your product becomes the company’s property.
Note: Any product sold and identified as refurbished or renewed
carries a ninety (90) day limited warranty.
Replacement product can only be sent if all warranty
requirements are met. Failure to follow all requirements can
result in delay.
WHAT IS NOT COVERED - EXCLUSIONS AND
LIMITATIONS:
This Limited Warranty applies only to the new products that can
be identified by the trademark, trade name, or logo affixed to it.
This Limited Warranty does not apply to any non-Philips hardware
product or any software, even if packaged or sold with the
product. Non-Philips manufacturers, suppliers, or publishers may
provide a separate warranty for their own products packaged with
the bundled product.
The Company is not liable for any damage to or loss of any
programs, data, or other information stored on any media
contained within the product, or any non-Philips product or
part not covered by this warranty. Recovery or reinstallation of
programs, data or other information is not covered under this
Limited Warranty.
This warranty does not apply (a) to damage caused by accident,
abuse, misuse, neglect, misapplication, or non-Philips product,
(b) to damage caused by service performed by anyone other
than an Authorized Service Location, (c) to a product or a part
that has been modified without written permission, or (d) if any
serial number has been removed or defaced, or (e) product,
accessories or consumables sold “AS IS” without warranty of any
kind by including refurbished Philips product sold “AS IS” by some
retailers.
This Limited Warranty does not cover:
• Sh
ipping charges to return defective product.
• Labor charges for installation or setup of the product,
adjustment of customer controls on the product, and
installation or repair of antenna/signal source systems outside
of the product.
• Product repair and/or part replacement because of improper
installation or maintenance, connections to improper voltage
supply, power line surge, lightning damage, retained images or
screen markings resulting from viewing fixed stationary content
for extended periods, product cosmetic appearance items due
to normal wear and tear, unauthorized repair or other cause not
within the control of the company.
• Damage or claims for products not being available for use, or
for lost data or lost software.
• Damage from mishandled shipments or transit accidents when
returning product.
• A product that requires modification or adaptation to enable
it to operate in any country other than the country for which it
was designed, manufactured, approved and/or authorized, or
repair of products damaged by these modifications.
• A product used for commercial or institutional purposes
(including but not limited to rental purposes).
• Product lost in shipment and no signature verification receipt
can be provided.
• Failure to operat
e per Owner’s Manual.
TO OBTAIN ASSISTANCE IN THE U.S.A., CANADA,
PUERTO RICO, OR U.S. VIRGIN ISLANDS...
Contact Customer Care Center at:
1-866-202-5960
REPAIR OR REPLACEMENT AS PROVIDED UNDER
THISWARRANTY IS THE EXCLUSIVE REMEDY FOR THE
CONSUMER. PHILIPS SHALL NOT BE LIABLE FOR ANY
INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF
ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT.
EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW,
ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED IN
DURATION TO THE DURATION OF THIS WARRANTY.
Some states do not allow the exclusions or limitation of incidental
or consequential damages, or allow limitations on how long
an implied warranty lasts, so the above limitations or exclusions
may not apply to you.
P&F USA, Inc.
PO Box 2248 Alpharetta, GA 30023-2248 U.S.A.
P&F Mexicana, S.A. de C.V.
Av. La Palma No. 6, Col. San Fernando La Herradura.
Huixquilucan, Edo. de México. C.P. 52787
This product has been manufactured by and is sold
under the responsibility of P&F USA, Inc., and P&F
USA, Inc. is the warrantor in relation to this product.
The Philips trademark and the Philips Shield Emblem
are registered trademarks of Koninklijke Philips N.V.
used under license.
EGB20UH
