1
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Spotless Hurricane Floor Washer & Vacuum
Model No. FLR00163
User Manual
2
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Spotless Hurricane Floor Washer & Vacuum
Model No. FLR00163
User Manual
Contents
Page No.
2 Contents
3 Reading and Storing the User Manual
3 Important Safety Instructions for Proper Use
6 Explanation of Symbols
7 Description of Parts & Accessories
7 Before first use of Your Floor Washer
8 Attaching the Handle
8 Charging the Battery
9 Filling the Clean Water Tank
9 Using Your Floor Washer
10 Vacuum Only Mode
10 Emptying Your Floor Washer
11 Cleaning the Filter Assembly
12 Auto Cleaning
12 Removing the Roller for Cleaning
13 Care and Maintenance of Your Floor Washer
13 Troubleshooting Guide
14 Technical Specification
14 Customer Support
15 Recycling Information
Back Page Warranty Information
3
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Spotless Hurricane Floor Washer & Vacuum
Model No. FLR00163
User Manual
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, basic safety precautions
should always be followed.
Only use the product as described in this user manual. Any
other use is considered improper and may result in damage
to property or persons.
The manufacturer or vendor cannot be held liable for
damages or injury incurred through improper or incorrect
use.
• Read and familiarise yourself with all operating
instructions before using this Floor Washer & Vacuum.
• Before plugging your unit into the mains, visually check
that the unit is intact and has not suffered any transit
damage.
• Check that the voltage indicated on the data plate
corresponds with that of the local network before
connecting the appliance to the mains power supply.
• This appliance can be used by persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved.
• Children shall not play with the appliance.
• Keep the appliance and its cord out of reach of children
less than 8 years when it is energised or cooling down.
• DO NOT immerse the appliance or its cord in water or any
other liquids.
• DO NOT leave the appliance unattended during use.
4
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Spotless Hurricane Floor Washer & Vacuum
Model No. FLR00163
User Manual
• DO NOT leave the appliance unattended whilst connected
to the mains supply.
• DO NOT use this appliance outdoors.
• It is imperative to unplug the power cord after the
appliance has been used, before it is cleaned and whilst
being repaired.
• Repairs to electrical appliances should only be performed
qualified personnel. Improper repairs may place user at
serious risk.
• DO NOT operate this appliance with a damaged plug or
cord, after a malfunction or after being dropped or
damaged in any way.
• Regular, periodic checks should be carried out on the
mains cable to
• ensure no damage is evident. Should there be any signs of
damage the appliance should not be used.
• If the power cable is damaged, it should only be replaced
by the manufacturer or a suitable qualified after-sales-
service in order to avoid a hazard.
• DO NOT allow the mains cable to hang over sharp edges
or come in contact with hot surfaces.
• Allow the unit to cool before storage.
• Before cleaning, disconnect the appliance from the mains
supply and allow to cool.
• This appliance is intended for household use only and
should not be used for industrial purposes.
• DO NOT use any accessories or attachments with this
appliance other than those supplied or recommended by
supplier.
• DO NOT use this appliance for anything other than its
intended use.
• DO NOT push objects into any openings as damage to the
appliance and/or electric shock may occur.
• Unplug after each use. Grasp the plug, not the cord.
• DO NOT pull or carry the Vacuum Cleaner by the electrical
5
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Spotless Hurricane Floor Washer & Vacuum
Model No. FLR00163
User Manual
cord, use the handle provided.
• Ensure fingers and other objects are never placed in any
part of the vacuum cleaner. Clothing or hair may become
trapped if the vacuum is used improperly.
• Keep hair, loose clothing, jewellery, fingers and all parts of
the body away from openings and moving parts.
• Keep all air vents clear and free of dust, lint, hair and
anything else that may reduce airflow.
• Avoid directing the appliance towards naked flames as the
air discharged may extinguish gas fires or pilot lights and
may disturb ashes in open fires.
• DO NOT Vacuum water or any other liquids with this
vacuum.
• DO NOT Vacuum hot ashes or lit cigarettes, etc.
• Never use the appliance without the filter in place.
• DO NOT use the Vacuum without the Dust Compartment
fitted.
• DO NOT vacuum any large or broken objects such as glass.
• DO NOT vacuum anything that is burning or smoking such
as cigarettes, matches or hot ashes.
WARNING! The fixing pack contains small items which
should be kept away from young children.
6
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Spotless Hurricane Floor Washer & Vacuum
Model No. FLR00163
User Manual
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
This symbol means batteries and rechargeable batteries may
not be disposed of with household waste!
As the end user you are required by law to bring all batteries
and rechargeable batteries to a collection point run by the Local
Authority or to a retailer, so that they can be disposed of in an
environmentally friendly manner.
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste and not sent to landfill. Please
ensure it is taken to a suitable facility for disposal. Check with
your Local Authority or retailer for recycling advice or visit
www.recycle-more.co.uk, enter your postcode to find out your
nearest recycling site.
This symbol provides useful additional information on the
use of this product.
This symbol indicates that the supply uses an alternating current
mains supply.
This symbol identifies voltage and the current rating for direct
current.
WARNING!
This designates a hazard with moderate risk, which may result
in severe injury or damage to the product if not adhered to.
7
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Spotless Hurricane Floor Washer & Vacuum
Model No. FLR00163
User Manual
Description of Parts & Accessories
Before first use of Your Floor Washer and Vacuum
Before use, retain all packaging until all the parts are present against the parts
list – see Description of Parts & Accessories above.
Discard packaging responsibly.
9
1. Handle
2. Spray Trigger & Indicator
3. Roller & Vacuum On/Off button
4. Water Tank/Handle Release
5. Water Tank
6. Charging Indicators
7. Vacuum Only On/Off
8. Charging Socket
9. Dust Compartment Release Catch
10. Dust Compartment
11. Roller Cover Release Catches
12. Roller
13. Roller Cover
14. Battery
15. Handle Securing Screw (rear)
16. Small Power Plug
17. Mains Charger
18. Cleaning Brush
19. Base Stand
1
2
3
4
6
7
10
12
15
16
19
18
17
14
8
11
5
13
8
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Spotless Hurricane Floor Washer & Vacuum
Model No. FLR00163
User Manual
Attaching the Handle
Insert the Handle (1) into the top of the cleaner,
press the Handle Release (4) button as the handle is
inserted ensuring that the handle fits fully inside the
top of the cleaner. Insert and tighten the Handle
Securing Screw (15) using a suitable screwdriver (not
supplied) into the rear (as shown right) of the unit to
hold the handle in place.
If the handle is not fully inserted, the Floor Washer &
Vacuum will not operate.
Charging the Battery
Ensure that the rechargeable Battery (14) is fully charged as follows:
1. Insert the Small Power Plug (16) of the Mains Charger (17) into the Charging
Socket (8).
2. Plug the Mains Charger (17) into the nearest mains socket.
3. The Charging/Battery Indicators (6) will light in the sequence as in a, b, c below
to show the Battery (14) is charging.
4. Once the battery is fully charged (after approximately 5 hours), the
Charging/Battery Indicators (6-arrowed below) will all light as in ‘c’ below
showing that the Battery (14) is fully charged and the Mains Charger (17) can be
removed.
The Charging/Battery Indicators will go out one at a time during use, at a pint
when none of the indicators are illuminated the Battery (14) will need recharging.
IMPORTANT Only use the Charger supplied with the product, using any other
charger may result in permanent damage to the cleaner and could invalidate your
warranty.
b.
c.
a.
Please note, the
unit will not operate
whilst the Mains
Charger (17) is
plugged into the
Charging Socket (8).
The Mains Charger
must be disconnected
before use.
9
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Spotless Hurricane Floor Washer & Vacuum
Model No. FLR00163
User Manual
Filling the Clean Water Tank (5)
1. Remove the Water Tank (5) by pressing
the Water Tank Release button (4) and
removing the tank towards you.
2. Lift the filling cap up and fill the tank
with warm water (max. 40⁰C/104⁰F) as
shown right.
In hard water areas it is strongly recommended
that demineralised or filtered water is used to
avoid calcium build up which may damage the
floor washer.
Using Your Floor Washer
3. Place your foot gently on the base and
pull the cleaner back by the Handle (1).
Press the Roller & Vacuum On/Off
button (3) once to start the roller.
4. Squeeze the Spray Trigger (2) once to
start releasing the water solution, the
Spray Indicator (2) LED above the
button will flash to show the water
solution is being released. move the
cleaner back and forth to clean the
surface.
Squeeze the Spray Trigger (2) once
again to stop releasing the water
solution.
5. Once the surface is clean, press the
Roller & Vacuum On/Off button (3)
again start the vacuum to remove any
excess liquid.
6. After use, press and hold the Roller &
Vacuum On/Off button (3) down for 2
seconds to switch the unit off.
3
1
2
10
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Spotless Hurricane Floor Washer & Vacuum
Model No. FLR00163
User Manual
Vacuum Only Mode
Press the Vacuum Only On/Off button (7
arrowed right) to operate just the vacuum
mode without the roller brush.
The cleaner will power up in low power
mode, press the Vacuum Only On/Off button
(7) again to enable the high power suction
mode.
Press the Vacuum Only On/Off button (7)
again to switch the vacuum off.
Emptying Your Floor Washer
1. Once the ‘MAX’ mark on the Dust
Compartment (10) has been reached, the
Dust Compartment (10) will require
emptying.
2. Slide the Dust Compartment Release
Catch (9) up and remove the Dust
Compartment (10).
3. Remove the filter assembly from the Dust
Compartment (10) as shown right:
1
2
3
11
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Spotless Hurricane Floor Washer & Vacuum
Model No. FLR00163
User Manual
Cleaning the Filter Assembly
Once dismantled, wash all parts of the filter and Dust Compartment (10) in warm
running water until clean.
Allow all parts to dry for 24 hours before reassembling and reusing your floor
washer.
The Dust Compartment (10) and filter assembly should be washed once a month
to maintain the efficient performance of your cleaner.
Hepa Filter
Float Holder
Float
4. Pour out any dirty water
collected in the Dust
Compartment (10).
5. Dismantle the filter assembly
as follows:
6. Rotate the Hepa Filter at the
top of the filter in the
direction of the arrow shown
and lift off.
7. Lift the Float from the Float
Holder.
Left: Whilst reassembling the
filter, align the ‘locked’ symbol
on the side of the Hepa filter as
shown and rotate in the direct
of the arrow shown.
12
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Spotless Hurricane Floor Washer & Vacuum
Model No. FLR00163
User Manual
Auto Cleaning
In normal use the Roller (12) will self clean and generally will not require cleaning.
However, if after cleaning a particularly heavy soiled surface the Roller (12) will
require removing and cleaning as below:
Removing the Roller (12) for Cleaning
1. Push both Roller Catches (11)
inwards and remove the Roller
Cover (13).
2. Press the Roller release button
(arrowed right).
3. The roller catch will pop out of the
side of the cleaner.
4. Pull the Roller (12) to the left as shown
which can now be removed for cleaning.
1
2
3
4
13
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Spotless Hurricane Floor Washer & Vacuum
Model No. FLR00163
User Manual
NOTE: DO NOT use the floor cleaner with the Roller (12) not fitted otherwise
permanent damage may occur to the appliance.
Care and Maintenance of Your Floor Washer
• Always disconnect the cleaner from the mains charger before cleaning.
• Clean the outside of the cleaner with a clean damp cloth. Never clean with harsh
or abrasive cleaners.
• Do not submerge the cleaner or its charger in water or any other liquids.
• Empty the Dust Compartment (10) as soon as it has reached maximum capacity.
• Wash the filter assembly regularly.
• Allow the filters to thoroughly dry out for 24 hours before reassembly and
reuse.
* WARNING! DO NOT continue to use your cleaner once the Dust
Compartment (10) is full as permanent damage may occur to the appliance which
may invalidate your warranty.
Troubleshooting Guide
Problem
Possible Cause
Possible Solution
Unit fails to turn on.
Internal battery not
charged.
The charger is not
plugged into the
mains socket.
Charge the internal battery.
Ensure the charger is fully
inserted into the socket and
the socket is switched on.
Low suction or poor pick-
up.
Dust Compartment
is full.
Filters are clogged.
Empty the compartment.
Check and clean the filters.
The vacuum is making a
“hissing” sound.
The airflow is
restricted
Empty the Dust
Compartment.
Check and clean the filters.
Clear any blockages if
necessary.
14
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Spotless Hurricane Floor Washer & Vacuum
Model No. FLR00163
User Manual
Technical Specification
Model Number
FLR00163
Mains Charger
Input: AC 100-240V ~ 50/60Hz 0.5A max.
Output: 27V DC 0.5A 13.5W
Vacuum Rating
22.2V 200W
Battery
22.2V 2200mAh Li-Ion (6 cells)
Run Time
Up to 30 minutes
Unpacked Weight (approx.)
3.6 Kgs
Dust Compartment/Dirty
Water Tank Capacity
400ml
Clean Water Tank Capacity
800ml
15
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Spotless Hurricane Floor Washer & Vacuum
Model No. FLR00163
User Manual
Recycling Information
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling facilities.
Dispose of non-recyclable plastics in the appropriate plastics collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste and not sent to landfill. Please ensure it is taken to
a suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or visit www.recycle-more.co.uk, enter
your postcode to find out your nearest recycling site.
This symbol means batteries and rechargeable batteries may not be
disposed of with household waste!
As the end user you are required by law to bring all batteries and
rechargeable batteries to a collection point run by the Local Authority
or to a retailer, so that they can be disposed of in an environmentally
friendly manner.
16
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Spotless Hurricane Floor Washer & Vacuum
Model No. FLR00163
User Manual
WARRANTY
Thank you for purchasing your Daewoo Floor Washer.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee.
Your Daewoo vacuum product is guaranteed for 1 year from the date of original purchase,
with proof of purchase or receipt. If any defect should occur due to faulty workmanship or
material, your faulty vacuum should be returned to the place of purchase, replacement or refund is
at the discretion of the retailer.
The guarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the
requirements contained in the instruction manual.
•
The product must be used solely for domestic purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at:
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo is a registered trademark.
Produced and imported under licence by
Eurosonic Group Limited
Brightgate House
1 Brightgate Way
Manchester, M32 0TB, UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
