Compact Lyte 7.4V Cordless Cleaner
Model No.: FLR00158
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
User Manual
User Manual
2
Compact Lyte 7.4V Cordless Cleaner
Model No.: FLR00158
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should
always be followed. These instructions should be saved for future
reference:
• Read and familiarise yourself with all operating
instructions before using this Vacuum Cleaner.
• This appliance can be used by persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved.
• Children shall not play with the appliance.
• Keep the appliance and its cord out of reach of children
less than 8 years when it is energised or cooling down.
• Do not immerse the appliance or its cable in water or any
other liquids.
• Do not leave the appliance unattended during use.
• Do not leave the appliance unattended whilst connected
to the power supply.
• The Vacuum can be used outdoors but the power supply
must remain indoors.
• It is imperative to unplug the power supply after the
appliance has been used, before it is cleaned and whilst
being repaired.
• Repairs to electrical appliances should only be performed
by a qualified electrician. Improper repairs may place user
at serious risk.
• Do not operate this appliance with a damaged power
supply or cable, after a malfunction or after being
dropped or damaged in any way.
• Regular, periodic checks should be carried out on the
cable to ensure no damage is evident. Should there be any
signs of damage the appliance should not be used.
• If the cable is damaged, it should only be replaced by the
manufacturer or a suitable qualified after-sales-service in
order to avoid a hazard
3
Compact Lyte 7.4V Cordless Cleaner
Model No.: FLR00158
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
• Do not allow the power cable to hang over sharp edges or
come in contact with hot surfaces.
• Do not run the cable under carpets, rugs, etc.
• The Vacuum Cleaner is not to be used if it has been
dropped, if there are visible signs of damage.
• Allow the unit to cool before storage.
• Before cleaning, disconnect the appliance from the mains
supply and allow to cool.
• This appliance is intended for household use only and
should not be used for industrial purposes.
• Do not use any accessories or attachments with this
appliance other than those supplied or recommended by
supplier.
• Do not use this appliance for anything other than its
intended use.
• Do not push objects into any openings as damage to the
appliance and/or electric shock may occur.
• Unplug after each use. Grasp the power supply, not the
cable.
• Do not pull or carry the Vacuum Cleaner by the cable.
• Never use the appliance without the filter in place.
• Do not use the Vacuum with no Dust Tank attached.
• Use only on vehicle interior surfaces.
• Do not tilt the Vacuum towards the main body when
vacuuming liquids.
• Do not vacuum any large or broken objects such as glass.
• Do not vacuum anything that is burning or smoking such
as cigarettes, matches or hot ashes.
• Do not vacuum reactive liquids (solvents, corrosives,
detergents)
• Do not vacuum flammable or explosive substances such as
alcohol, thinners etc.
4
Compact Lyte 7.4V Cordless Cleaner
Model No.: FLR00158
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Parts
Before use of Your Vacuum Cleaner
Please read these operating instructions thoroughly and keep them in a safe
place for future reference.
Remove all packing materials and discard responsibly.
1. Charging Port (End of Handle)
2. Handle
3. On/Off Button
4. High/Low Button
5. Battery/Charging LED
6. Filter Assembly
7. Dust Compartment
8. Air Intake
9. Crevice Tool
10. Base Unit Charging Port
11. Brush Tool
12. Base Unit
13. Mains Charger
14. Small DC Plug
12
4
5
2
13
10
9
7
6
8
1
3
11
14
5
Compact Lyte 7.4V Cordless Cleaner
Model No.: FLR00158
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Charging the internal Battery
Before use, please ensure that the internal rechargeable battery is fully charged
as follows:
1. Insert the Small DC Plug (14) of the Mains Charger (13) into either of the
Charging Ports (1 or 10).
2. Plug the Mains Charger (13) into the nearest mains socket. The
Battery/Charging LED (5) will flash to show the internal battery is charging.
3. Once the battery is fully charged (after approximately 5 hours), the
Battery/Charging LED (5) will all light continuously showing that the internal
battery is fully charged and the Mains Charger (13) can be removed.
NB If the Battery/Charging LED (5) Indicator flashes during use the internal battery
will need recharging.
Using Your Vacuum
1. Grasp the vacuum cleaner firmly by the Handle (2) and press the On/off button
(3) to power up the cleaner.
2. Press the High/Low button (4) to select between the high and low suction
levels.
3. Left: Attach the Crevice Tool (9) to the Air
Intake (8) for those hard to get at places.
4. Right: Attach the Upholstery Brush
for use on upholstery and stairs, etc.
6
Compact Lyte 7.4V Cordless Cleaner
Model No.: FLR00158
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
1. Once the Dust Compartment (7) is full it
will need emptying and the filter
cleaned.
2. To empty the cleaner, hold the Handle
(2) and twist the Dust Compartment (7)
to the left.
3. Remove the Dust Compartment (7) and
empty the contents into a dust bin.
4. Twist the Filter Assembly (6) off to the
left and wash in warm running water
until clean. Allow the filter to thoroughly
dry for 24 hours before reuse.
Emptying and Cleaning Your Vacuum Cleaner
WARNING Always disconnect the cleaner from the Mains Charger (14) before
cleaning.
WARNING do not continue to use your vacuum cleaner once the Dust
Compartment (7) is full otherwise permanent damage may occur to the appliance.
Care and Maintenance of Your Vacuum Cleaner
• Always disconnect the cleaner from the Mains Charger before cleaning.
• Clean outside of the cleaner with a clean damp cloth. Never clean with harsh or
abrasive cleaners.
• Do not submerge the cleaner in water or any other liquids.
• Empty the Dust Compartment (7) as soon as it is full.*
• Wash the Filter regularly – see table below.
• Allow the filter to thoroughly dry out for 24 hours before reassembly and reuse.
WARNING do not continue to use your vacuum cleaner once the Dust
Compartment (7) is full otherwise permanent damage may occur to the appliance.
7
Compact Lyte 7.4V Cordless Cleaner
Model No.: FLR00158
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Recommended Filter Cleaning Intervals
Filter Type
Recommended cleaning period
WARNING Ensure the filter is cleaned periodically according to the table above,
failure to clean the filter regularly will severely impair the performance and
permanent damage may occur to the appliance and may also invalidate your
warranty.
NB Do not under any circumstances use the vacuum cleaner without the filters
fitted as damage to the appliance will occur.
Technical Specification
Model Number
FLR00158
Mains Charger Rating
Input: AC 100-240V ~ 50/60Hz 0.5A
Output: 9V 500mA DC
Vacuum Rating
7.4V DC 80W
Battery
2200mAh Li-Ion (2x 3.7V Batteries)
Capacity
120ml
Unpacked Weight (approx.)
490g
Dimensions (approx.)
67mm (d) x 67mm (w) x 406mm (h)
• Shake
out
debris
when
you
empty
the
dust container
•
Rinse
under
war
m
water
once
a
month
• Allow to dry thoroughly for 24 hours
before reuse.
Conical Hepa Filter
8
Compact Lyte 7.4V Cordless Cleaner
Model No.: FLR00158
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Recycling Information
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling facilities.
Dispose of non-recyclable plastics in the appropriate plastics collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste and not sent to landfill. Please ensure it is taken to
a suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or visit www.recycle-more.co.uk, enter
your postcode to find out your nearest recycling site.
This symbol means batteries and rechargeable batteries may not be
disposed of with household waste!
As the end user you are required by law to bring all batteries and
rechargeable batteries to a collection point run by the Local Authority
or to a retailer, so that they can be disposed of in an environmentally
friendly manner.
Troubleshooting Guide
Problem
Possible Cause
Solution
No Power
Battery Flat.
Place vacuum on charging
station until all three
indicator lights are lit.
Low suction or poor pick-
up.
Dust Compartment is
full.
Filters are clogged.
Empty the Dust
Compartment.
Check and clean the filter.
Low Operating Time
The airflow is
restricted
Empty the Dust
Compartment. Check and
clean the filters.
9
Compact Lyte 7.4V Cordless Cleaner
Model No.: FLR00158
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Notes
10
Compact Lyte 7.4V Cordless Cleaner
Model No.: FLR00158
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARRANTY
Thank you for purchasing your Daewoo Steam Mop.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof
of purchase or receipt. If any defect should occur due to faulty workmanship or material, your
faulty vacuum should be returned to the place of purchase, replacement or refund is at the
discretion of the retailer.
The guarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the
requirements contained in the instruction manual.
•
The product must be used solely for domestic purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at:
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo is a registered trademark.
Produced and imported under licence by
Eurosonic Group Limited
Brightgate House
1 Brightgate Way
Manchester M32 0TB UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
