7.4V Compact Lyte Wet & Dry Vacuum Cleaner
FLR00006
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
User Manual
User Manual
2
7.4V Compact Lyte Wet & Dry Vacuum Cleaner
FLR00006
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should
always be followed. These instructions should be saved for future
reference:
• Read and familiarise yourself with all operating instructions before
using this Vacuum Cleaner.
• Before plugging your unit into the mains, visually check that the unit is
intact and has not suffered any transit damage.
• Check that the voltage indicated on the data plate corresponds with
that of the local network before connecting the appliance to the mains
power supply.
• This appliance can be used by persons with reduced physical, sensory
or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
• Children shall not play with the appliance.
• Keep the appliance and its cord out of reach of children less than 8
years when it is energised or cooling down.
• Do not immerse the appliance or its cord in water or any other liquids.
• Do not leave the appliance unattended during use.
• Do not leave the appliance unattended whilst connected to the mains
supply.
• Do not use this appliance outdoors.
• It is imperative to unplug the power cord after the appliance has been
used, before it is cleaned and whilst being repaired.
• Repairs to electrical appliances should only be performed by qualified
personnel. Improper repairs may place user at serious risk.
• Do not operate this appliance with a damaged mains adaptor or cable,
after a malfunction or after being dropped or damaged in any way.
• Regular, periodic checks should be carried out on the mains adaptor
cable to ensure no damage is evident. Should there be any signs of
damage the appliance should not be used.
• If the cable is damaged, it should only be replaced by the
manufacturer or a suitable qualified after-sales-service in order to
avoid a hazard
• Do not allow the cable to hang over sharp edges or come in contact
with hot surfaces.
• Allow the unit to cool before storage.
• Before cleaning, disconnect the appliance from the mains supply and
3
7.4V Compact Lyte Wet & Dry Vacuum Cleaner
FLR00006
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
allow to cool.
• This appliance is intended for household use only and should not be
used for industrial purposes.
• Do not use any accessories or attachments with this appliance other
than those supplied or recommended by supplier.
• Do not use this appliance for anything other than its intended use.
• Do not push objects into any openings as damage to the appliance
and/or electric shock may occur.
• Unplug after each use. Grasp the mains adaptor, not the cable.
• Do not pull or carry the Vacuum Cleaner by the electrical cable, use
the handle provided.
• Ensure fingers and other objects are never placed in any part of the
vacuum cleaner. Clothing or hair may become trapped if the vacuum is
used improperly.
• Keep hair, loose clothing, jewellery, fingers and all parts of the body
away from openings and moving parts.
• Keep all air vents clear and free of dust, lint, hair and anything else
that may reduce airflow.
• Avoid directing the appliance towards naked flames as the air
discharged may extinguish gas fires or pilot lights and may disturb
ashes in open fires.
• Do not Vacuum hot ashes or lit cigarettes, etc.
• Never use the appliance without the filter in place.
• Do not use the Vacuum with no Dust Tank attached.
• Do not vacuum any large or broken objects such as glass.
• Do not vacuum anything that is burning or smoking such as cigarettes,
matches or hot ashes.
• Do not vacuum reactive liquids (solvents, corrosives, detergents)
• Do not vacuum flammable or explosive substances such as alcohol,
thinners etc.
4
7.4V Compact Lyte Wet & Dry Vacuum Cleaner
FLR00006
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Parts
1. Handle
2. On/off Switch
3. Indicator Light
4. Air Outlet
5. Dust Compartment Release Button.
6. Filter.
7. Dust Compartment
8. Air Intake.
9. Charging Station.
2
3
1
9
7
5
4
6
8
10. Flexible Hose
11. Crevice Tool for hard the get at areas
12. Rubber Nozzle for spillages & liquids
13. Adaptor for hose & brush
14. Brush Attachment.
10
11
12
13
14
5
7.4V Compact Lyte Wet & Dry Vacuum Cleaner
FLR00006
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Before the first time you use your Wet and Dry Vacuum Cleaner
Please read these operating instructions thoroughly and keep them in a safe place for
future reference.
Remove all packing materials and discard responsibly.
Charging the internal Battery
Before use, please ensure that the internal rechargeable battery is fully charged as follows:
1. Place the vacuum on the charging station as shown below:
2. Plug the Mains Charger into the nearest mains socket.
3. The Indicator Light (3) will light up red to show the internal battery is being charged.
4. Once the battery is fully charged (after approximately 5 hours), the Indicator Light (3) will
change to green showing that the internal battery is fully charged and the vacuum is ready to
use.
Charging
Charged
6
7.4V Compact Lyte Wet & Dry Vacuum Cleaner
FLR00006
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Selecting Your Wet and Dry Vacuum Cleaner Attachment
Before using the vacuum, attach the appropriate accessory if required as follows:
1. Insert the Crevice Tool (11) or the Rubber Nozzle (12) directly into the Air Outlet (8) of
the vacuum as below:
2. Attach the Brush Attachment (14) to the Air Outlet (8) using the Adaptor (13) as below:
3. If the Flexible Hose (10) is required to give a longer reach, attach this to the Air Outlet
(8) via the Adaptor (13)
4. Alternatively, the vacuum can be used without any attachment for general cleaning.
Using Your Wet and Dry Vacuum Cleaner
Right: Slide the On/off Switch (2)
forward to power up the vacuum. The
Indicator Light (3) will illuminate green.
11
12
8
14
13
8
7
7.4V Compact Lyte Wet & Dry Vacuum Cleaner
FLR00006
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
1. Once the Dust Compartment (7) is
full it will need emptying and the
filter cleaned.
2. To empty the cleaner, hold the Dust
Compartment (7) and press the
Dust Compartment Release Button
(5) and remove the Dust
Compartment (7). Lift out the Filter
(6) and empty the dust out into a
bin.
Wet Vacuuming
Fit the Rubber Nozzle (12) to the Air Outlet (8) to vac up small spillages and liquids.
Slide the On/off Switch forward to power up the vacuum.
Empty the Dust Compartment (7) of water immediately after use.
WARNING Do not tip the vacuum upwards (as above) whilst vacuuming spillages and
liquids. Keep the vacuum horizontal or downwards.
Emptying and Cleaning Your Wet & Dry Vacuum Cleaner
WARNING Always disconnect the cleaner from the mains charger before cleaning.
WARNING do not continue to use your vacuum cleaner once the Dust Compartment (7) is
full otherwise permanent damage may occur to the appliance.
2
1
8
7.4V Compact Lyte Wet & Dry Vacuum Cleaner
FLR00006
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
3. Wash the Filter (6) in warm running water
until the Filter (7) is clean. Allow the filter
to thoroughly dry for 24 hours before
reuse.
Care and Use of your Wet & Dry Vacuum Cleaner
• Always disconnect the cleaner from the mains charger before cleaning.
• Clean outside of the cleaner with a clean damp cloth. Never clean with harsh or abrasive
cleaners.
• Do not submerge the cleaner in water or any other liquids.
• Empty the Dust Compartment (7) as soon as it is full.*
• Wash the Filter (6) regularly – see table below.
• Allow the filter to thoroughly dry out for 24 hours before reassembly and reuse.
WARNING do not continue to use your vacuum cleaner once the Dust Compartment (6) is full
otherwise permanent damage may occur to the appliance.
Recommended filter cleaning intervals
Filter Type
Recommended cleaning period
WARNING Ensure the filter is cleaned periodically according to the table above, failure to
clean the filter regularly will severely impair the performance and permanent damage may
occur to the appliance.
NB Do not under any circumstances use the vacuum cleaner with the filter removed as
damage to the appliance will occur.
• Shake
out
debris
when
you
empty
the dust
container
•
Rinse
under
war
m
water
once
a
month
• Allow to dry thoroughly for 24 hours before
reuse.
Cloth Filter (6)
3
9
7.4V Compact Lyte Wet & Dry Vacuum Cleaner
FLR00006
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Technical Data
Troubleshooting Guide
Problem
Possible Cause
Solution
No Power
Battery Flat.
Place vacuum on charging
station until indicator light turns
green.
Low suction or poor pick-up.
Dust Compartment is full.
Filters are clogged.
Empty the Dust Compartment.
Check and clean the filter.
Low Operating Time
The airflow is restricted
Empty the Dust Compartment.
Check and clean the filters.
Model Number
FLR00006
Mains Charger
Input: AC 100-240V ~ 50-60Hz Output: 9.6V DC
Rated Power
50W
Battery
7.4V 2200mAh Li-Ion
Unpacked Weight (approx.)
0.85 Kgs
Dimensions (approx.)
410mm (d) x 100mm (w) x 125mm (h)
Vacuum
>4kpa
10
7.4V Compact Lyte Wet & Dry Vacuum Cleaner
FLR00006
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Waste electrical products should not be disposed of with household waste. Please
recycle where facilities exist. Check with your Local Authority or retailer for recycling advice.
Waste batteries should not be disposed of with household waste. Please recycle
where facilities exist. Check with your Local Authority or retailer for recycling advice.
11
7.4V Compact Lyte Wet & Dry Vacuum Cleaner
FLR00006
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
GUARANTEE
This product is guaranteed for twelve months from the date of original purchase. If
any defect should occur due to faulty materials or workmanship, please return it to
the store it was purchased from.
You will need to have your receipt of purchase to hand. The guarantee is subject to
the following provisions:
•
It is only valid within the boundaries of the country of purchase.
•
The product must be correctly installed and operated in accordance with the
instructions contained in the
User Manual.
•
The product must be used solely for domestic purposes.
•
The guarantee will be rendered invalid if the product is re-sold or has been
damaged by inexpert repair.
•
The manufacturer disclaims any liability for incidental or consequential damages.
•
The guarantee is in addition to, and does not diminish, your statutory or legal
rights.
WARRANTY
Thank you for purchasing your Daewoo Vacuum.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo vacuum product is guaranteed for 1 year from the date of original purchase,
with proof of purchase or receipt. If any defect should occur due to faulty workmanship or
material, your faulty vacuum should be returned to the place of purchase, replacement or refund is
at the discretion of the retailer.
The guarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the
requirements contained in the instruction manual.
•
The product must be used solely for domestic purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at
www.daewoowarrantyregistration.com/warranty-registration
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo® is a registered trademark.
Produced and imported under licence by ESG Ltd
Manchester M3 1JS www.esgltd.com
