1
650W Hurricane 1.4L Spot Washer
Model No. FLR00155
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
2
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
650W Hurricane 1.4L Spot Washer
Model No. FLR00155
User Manual
Contents
Page No.
2 Contents
3 Reading and Storing the User Manual
3 Important Safety Instructions for Proper Use
6 Explanation of Symbols
6 Information About Your Carpet Washer
6 Before First Use of Your Carpet Washer
7 Description of Parts & Accessories
8 Before First use of Your Spot Washer
8 Assembling Your Spot Washer
8 About Your Spot Washer
8 Filling the Clean Water Tank
9 Preparing the Carpet/Upholstery for Cleaning
9 Using Your Spot Washer
11 Emptying the Dirty Water Tank
11 Cleaning and Maintenance of Your Spot Washer
12 Cleaning the Dirty Water Tank Filter
12 Cleaning the Clean Water Filter
12 Cleaning the Multitool
13 Automatically Cleaning the Flexible Hose
13 Storing Your Spot Washer
13 Technical Specification
14 Troubleshooting Guide
14 Plug Wiring Information
14 Recycling Information
15 Customer Support
Back Page Warranty Information
3
650W Hurricane 1.4L Spot Washer
Model No. FLR00155
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, basic safety precautions should
always be followed.
Only use the product as described in this user manual. Any other use is
considered improper and may result in damage to property or persons.
The manufacturer or vendor cannot be held liable for damages or injury
incurred through improper or incorrect use.
• Read and familiarise yourself with all operating
instructions before using this Spot Washer.
• Before plugging your unit into the mains, visually check
that the unit is intact and has not suffered any transit
damage.
• Check that the voltage indicated on the data plate
corresponds with that of the local network before
connecting the appliance to the mains power supply.
• This appliance can be used by persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved.
• Children shall not play with the appliance.
• Keep the appliance and its cord out of reach of children
less than 8 years when it is energised or cooling down.
• DO NOT immerse the appliance or its cord in water or any
other liquids.
• DO NOT leave the appliance unattended during use.
• DO NOT leave the appliance unattended whilst connected
to the mains supply.
• DO NOT use this appliance outdoors.
4
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
650W Hurricane 1.4L Spot Washer
Model No. FLR00155
User Manual
• It is imperative to unplug the power cord after the
appliance has been used, before it is cleaned and whilst
being repaired.
• Repairs to electrical appliances should only be performed
by qualified personnel. Improper repairs may place user at
serious risk.
• DO NOT operate this appliance with a damaged plug or
cord, after a malfunction or after being dropped or
damaged in any way.
• Regular, periodic checks should be carried out on the
mains cable to ensure no damage is evident. Should there
be any signs of damage the appliance should not be used.
• If the power cable is damaged, it should only be replaced
by qualified personnel in order to avoid a hazard.
• DO NOT allow the mains cable to hang over sharp edges
or come in contact with hot surfaces.
• DO NOT run the mains cable under carpets, rugs, etc.
• The appliance is not to be used if it has been dropped, if
there are visible signs of damage or it is leaking.
• The plug must be removed from the socket outlet before
the reservoir is filled with water or the waste water tank
emptied.
• The filling aperture must not be opened during use.
• Allow the unit to cool before storage.
• Before cleaning, disconnect the appliance from the mains
supply and allow to cool.
• This appliance is intended for household use only and
should not be used for industrial purposes.
• DO NOT use any accessories or attachments with this
appliance other than those supplied or recommended by
supplier.
• DO NOT use this appliance for anything other than its
intended use.
• DO NOT push objects into any openings as damage to the
appliance and/or electric shock may occur.
• Unplug after each use. Grasp the plug, not the cord.
5
650W Hurricane 1.4L Spot Washer
Model No. FLR00155
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
• DO NOT pull or carry the appliance by the electrical cord.
• Caution: Always wear suitable shoes when using the Spot
Washer and when changing accessories, do not wear
slippers or open toed footwear.
• Ensure fingers and other objects are never placed in any
part of the Spot Washer. Clothing or hair may become
trapped if the Spot Washer is used improperly.
• Keep hair, loose clothing, jewellery, fingers and all parts of
the body away from openings and moving parts.
• Keep all air vents clear and free of dust, lint, hair and
anything else that may reduce airflow.
• Avoid directing the appliance towards naked flames as the
air discharged may extinguish gas fires or pilot lights and
may disturb ashes in open fires.
• Never operate the appliance without water.
• Never fill the water tanks past the maximum level mark.
• DO NOT run the Spot Washer over hot ashes or lit
cigarettes, etc.
• Do not use the Spot Washer without the water tanks
fitted.
• DO NOT run the Spot Washer over any large or broken
objects such as glass.
• DO NOT run the Spot Washer over anything that is
burning or smoking such as cigarettes, matches or hot
ashes.
6
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
650W Hurricane 1.4L Spot Washer
Model No. FLR00155
User Manual
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable provisions
of the European Economic Area.
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste and not sent to landfill. Please ensure it is taken
to a suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or visit www.recycle-more.co.uk, enter
your postcode to find out your nearest recycling site.
This symbol provides useful additional information on the use of
this product.
This symbol indicates that the supply uses an alternating current
mains supply.
This symbol indicates that the appliance is electrically double
insulated and therefore does not require an earth connection.
WARNING! This designates a hazard with moderate risk, which may result
in severe injury or damage to the product if not adhered to.
7
650W Hurricane 1.4L Spot Washer
Model No. FLR00155
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Parts & Accessories
1. Multi Tool (with Brush).
2. Spray Jet.
3. Water Release Trigger.
4. Multi Tool Holder.
5. Multi Tool Holder Slot (left).
6. On/Off Switch.
7. Flexible Hose.
8. Dirty Water Tank.
9. Multi Tool Holder Slot (right).
10. Dirty Water Tank Lid.
11. Carrying Handle.
12. Clean Water Tank Lid.
13. Clean Water Tank.
14. Adjustable Cable Tidies.
15. Mains Cable
16. Hose Release Catch.
17. Clean Water Filter.
18. Dirty Water Tank Filter.
19. Hose Cleaning Attachment.
Front View
Rear View
1
2
6
7
8
9
10
7
3
5
12
4
14
13
11
15
16
4
17
1
18
19
8
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
650W Hurricane 1.4L Spot Washer
Model No. FLR00155
User Manual
Before First use of Your 1.4L Spot Washer
• Remove all packing materials and discard responsibly.
• Take care whilst opening the carton as a sharp blade may damage the product.
• Ensure that all parts are present – see ‘Description of Parts & Accessories’
above:
Assembling Your Spot Washer
About Your Spot Washer
• This Spot Washer is designed to clean small areas of household fabric surfaces,
such as patches of carpets and upholstery, it is not suitable for use as a
conventional vacuum cleaner.
• Do not use the Spot Washer on other materials.
• Do not add cleaning solutions to the water tank. Only use the spot cleaner with
tap water (or purified/distilled water).
• Ensure the water does not enter electrical parts.
Filling the Clean Water Tank (13)
1. Grasp the lid and lift the Clean Water Tank (13) straight up out of Spot Washer.
2. Turn the tank upside down and
unscrew the filling cap (circled
right) from the bottom of the tank.
Left: Attach the Flexible Hose (7)
to the Spot Washer by using the
Hose Release Catch (16) as
follows: Pull back the lock and
press the ‘square’ so that the
catch opens.
Push the Flexible Hose (7) onto
the outlet on the unit and let go
of the square. Lock the hose in
place by pushing the lock
forwards.
Repeat the above process to
attach the Multi Tool (1) to the
other end of the Flexible Hose (7).
Lock
Unlock
Press this
square to
open the
catch.
2
9
650W Hurricane 1.4L Spot Washer
Model No. FLR00155
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
3. Fill the tank with warm water (max. 40⁰C) as
shown left, ensuring that the water level is not
above the ‘MAX’ mark (arrowed) on the side of
the tank:
In hard water areas it is strongly recommended that distilled/purified
water is used to avoid calcium build up which may damage the Spot Washer.
4. Screw the filling cap back on, turn the tank the correct way up and replace the
Clean Water Tank (13) into the spot washer.
DO NOT overfill the tank as this will cause a spillage/leakage.
DO NOT operate the Spot Washer with an empty clean water tank.
Preparing the Carpet/Upholstery for Cleaning
WARNING! DO NOT
use this Spot Washer as a dry vacuum cleaner as this
will damage the appliance.
Before cleaning, dampen a white cloth and rub the cloth gently over a small test
area on the carpet or upholstery to be cleaned and check for any colour bleeding.
If the cloth remains clean, it should be safe to continue.
Using Your Spot Washer
1. Ensure the Dirty Water Tank (8) is in place.
Remove the Mains Cable (15) from the
back of the Spot Washer by rotating the
Adjustable Cable Tidies (14) inwards as
shown right and then remove the Mains
Cable (15):
NOTE rotate the Adjustable Cable Tidies
(14) outwards before winding the mains
cable back onto the Spot Washer after use.
1
3
10
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
650W Hurricane 1.4L Spot Washer
Model No. FLR00155
User Manual
2. Fully unravel the Mains Cable (15) and insert the
mains plug into the nearest mains socket and switch
the socket on (if applicable).
3. Press the On/Off Switch (6 – arrowed left) to
power up the Spot Washer.
4. Hold the Multi Tool (1) by the handle and hold it over the area to be cleaned.
5. Press and hold the Water Release Trigger (3) on the underside of the handle to
expel water through the Spray Jet (2).
NOTE: Do not spray water continually in the same place, as the water will quickly
be absorbed after spraying. If the water penetrates too deeply and is not
sufficiently re-absorbed, mildew could start to form.
6. Once the area is sufficiently saturated,
release the Water Release Trigger (3).
Press the Multi Tool (1) evenly and firmly
against the material. Pull the handle
slowly towards you, keeping it pressed
against the carpet or upholstery to
vacuum up the water. The dirty water
will go into the Dirty Water Tank (8).
7. Repeat step 5 & 6 if necessary if the spot
to be cleaned requires further cleaning.
If the spot mark is heavily soiled, use a separate solution for heavily soiled areas
such as Daewoo Carpet & Upholstery Stain Remover which is available by
contacting Daewoo Customer Services on 0161 831 7879 or email
help@daewooelectricals.com.
2
3
6
11
650W Hurricane 1.4L Spot Washer
Model No. FLR00155
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Emptying the Dirty Water Tank (8)
A. Ensure the mains plug is removed from the
socket before emptying the Dirty Water Tank
(8).
B. Once the dirty water has reached the ‘MAX’
mark, the Dirty Water Tank (8) must be
emptied.
C. Lift the Dirty Water Tank (8) up clear of the Spot
Washer. Remove the Dirty Water Tank Lid (10)
and pour out the contents.
D. Rinse the Dirty Water Tank (8) out with warm
water and replace the Dirty Water Tank Lid (10)
before refitting the tank back into the Spot
Washer.
NOTE The Spot Washer will automatically stop
vacuuming water once the Dirty Water Tank (8) is
at the MAX mark.
Cleaning & Maintenance of Your Spot Washer
WARNING! Always disconnect the spot washer from the mains power supply
before cleaning.
• Empty both water tanks after use ensuring that the Dirty Water Tank (8) has
been cleaned out as described above.
• Wipe the outside of the main body with a clean, soft cloth that has been soaked
in warm water and gently wrung out.
• If there is any stubborn dirt or grime, apply a small amount of a gentle kitchen
detergent to the cloth and wipe the area until it is clean. Thoroughly rinse the
cloth and wipe the area again until no detergent residue remains.
• Do not submerge the appliance in water or any other liquids.
A
B & C
12
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
650W Hurricane 1.4L Spot Washer
Model No. FLR00155
User Manual
Cleaning the Dirty Water Tank Filter (18)
1. Remove the Dirty Water Tank Lid (10)
and twist off the filter cap anticlockwise
and remove the Dirty Water Tank Filter
(18) as shown left:
2. Rinse the Dirty Water Tank Filter (18) in
warm running water until clean.
3. Allow the filter to dry for 24 hours before
refitting it to the tank.
Cleaning the Clean Water Filter (17)
1. Whilst the Dirty Water Tank (8) is
removed, lift out the Clean Water Filter
(17) at the bottom of the compartment
arrowed left.
2. Rinse the Clean Water Filter (17) in
warm running water until clean.
3. Allow the filter to dry for 24 hours before
refitting it to the compartment.
Cleaning the Multi Tool (1)
1. Press the button (arrowed right)
on the back of the Multi Tool (1)
and detach the brush head from
the handle.
2. Lift the clip (in the direction of the
arrow shown right) on the brush
head and remove the brush from
the cover.
3. Thoroughly rinse all the Multi Tool
(1) parts with water. Carefully
remove any dirt/blockages.
Filter Cap
Dirty Water Tank
Filter (18)
Handle
Brush
head
13
650W Hurricane 1.4L Spot Washer
Model No. FLR00155
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Automatically Cleaning the Flexible Hose (7)
1. Remove the Multitool (1) from the Flexible Hose (7) and attach the Hose
Cleaning Attachment (19) to the end of the hose in place of the Multitool (1) as
shown below:
2. Ensure the Dirty Water Tank (8) is empty and fill the Clean Water Tank (13)
with water.
3. Press the On/Off Switch (6) to power up the Spot Washer and let the water
flow through the Hose Cleaning Attachment (19) and into the hose to clean it.
4. Run the Spot Washer until the water in the Clean Water Tank (13) has run out
and/or the hose is clean.
5. Remove the Hose Cleaning Attachment (19) once the hose has been cleaned.
NOTE There is intentionally a hole in the Hose Cleaning Attachment (19).
Storing Your Spot Washer
• Rotate the Adjustable Cable Tidies (14) on the back of the Spot Washer
outwards and wrap the Mains Cable (15) around them.
• DO NOT store the Spot Washer with water in either tank – rinse the tanks out
and allow to thoroughly dry before storage.
• Store the Spot Washer in a cool, dry place away from direct sunlight.
Technical Specification
Rated Voltage
220-240V AC ~ 50-60Hz
Rated Power
650W
Protection Class
II
Model Number
FLR00155
Clean Water Tank Capacity
1400ml (max.)
Dirty Water Tank Capacity
1200ml (max.)
Water Jet Flow
350ml/min. (approx.)
Water Temperature
40⁰C (max.)
IP Rating
IPX4
Weight (without accessories)
4.5kg
Dimensions
318mm (h) x 249mm (w) x 374mm (d)
14
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
650W Hurricane 1.4L Spot Washer
Model No. FLR00155
User Manual
Troubleshooting Guide
Problem
Possible Cause
Solution
Unit fails to turn on.
The unit may not be
properly plugged in.
Ensure the plug is fully
inserted into the socket and
the socket is switched on.
The fuse may have blown.
Check the fuse by
substitution.
The motor has overheated
Switch off and allow the unit
to cool before reuse.
The power is not switched
on.
Press the On/Off Switch
The appliance is not
producing any spray.
The water tank is empty.
Fill the water tank with up to
1.4 L of clean water.
The vacuum hose is dirty or
clogged.
Clean the vacuum hose
The spray trigger is stuck.
Release the trigger, and try to
press it again
Low suction during cleaning.
The Dirty Water Tank is full.
Empty the Dirty Water Tank.
The Dirty Water Tank is not
installed properly.
Check the Dirty Water Tank is
installed properly.
Automatic suction stop
device
Turn off the appliance and
empty the dirty water tank.
The vacuum hose is dirty,
clogged
Clean the vacuum hose
The filters are blocked
Clean the Filters
Non-Rewireable Mains Plug
If your appliance is supplied with a non-rewireable plug fitted to the mains lead
and should the fuse need replacing, you must use an ASTA approved one
(conforming to BS 1362 of the same rating). Never use a plug with the fuse cover
missing. If in doubt, consult a qualified electrician.
If you need to remove the plug – DISCONNECT FROM THE MAINS – and then cut
it off the mains lead and immediately dispose of it safely. Never attempt to reuse
the plug or insert it into a socket outlet as there is a danger of electric shock.
Recycling Information
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling facilities.
Dispose of non-recyclable plastics in the appropriate plastics collection service.
15
650W Hurricane 1.4L Spot Washer
Model No. FLR00155
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Disposal of the Product
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste and not sent to landfill. Please
ensure it is taken to a suitable facility for disposal. Check with
your Local Authority or retailer for recycling advice or visit
www.recycle-more.co.uk, enter your postcode to find out your
nearest recycling site.
16
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
650W Hurricane 1.4L Spot Washer
Model No. FLR00155
User Manual
WARRANTY
Thank you for purchasing your Daewoo Vacuum.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo vacuum product is guaranteed for 1 year from the date of original purchase,
with proof of purchase or receipt. If any defect should occur due to faulty workmanship or
material, your faulty vacuum should be returned to the place of purchase, replacement or refund is
at the discretion of the retailer.
The guarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the
requirements contained in the instruction manual.
•
The product must be used solely for domestic purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at:
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo is a registered trademark.
Produced and imported under licence by
Eurosonic Group Limited
Brightgate House
1 Brightgate Way
Manchester M32 0TB UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
