14
21” LED GROW LIGHT
SKU Number: 346-0643
Model Number: 0005-0223
PACKAGE CONTENTS
Note: Hardware not shown to actual size.
Questions, problems, missing parts?
Before returning to your retailer, call our customer service at
1-844-255-9692 Monday – Friday 9:00 a.m. – 6:00 p.m. CST
Questions, problems, missing parts?
Before returning to your retailer, call our customer service at
1-844-255-9692 Monday – Friday 9:00 a.m. – 6:00 p.m. CST
• Periodically, dust the outside surface of the frosted lens with a dry soft cloth. Clean with a clean damp
cloth if needed. Do not use chemical solvents or harsh abrasives to clean xture.
CARE AND MAINTENANCE
WARRANTY
1) The light does not come on at all:
a)If “ON/OFF” button is in the “OFF” position, push button on xture once so that it is in the “ON” position.
b) If outlet is on a switched circuit, make sure the circuit breaker is on.
If unable to x the above issue, please consult a certied electrician.
TROUBLESHOOTING
PART DESCRIPTION QUANTITY
A 21” LED Grow Light with attached 5ft power cord 1
B Mounting Screw 2
C Wall Anchors 2
A
B
RV2135
This PATRIOT LIGHTING® brand light xture carries a ve (5) Year Limited Warranty to the original
purchaser. If, during normal use, this PATRIOT LIGHTING® light xture fails due to a defect in material
and workmanship within ve (5) years from the date of purchase, simply bring this light xture with your
original sales receipt back to your nearest MENARDS® retail store. At its discretion, PATRIOT LIGHTING®
agrees to have the lighting xture replaced with the same or similar PATRIOT LIGHTING® product free of
charge, within the stated warranty period, when returned by the original purchaser with original sales receipt.
Notwithstanding the foregoing, this limited warranty does not cover damage or failure caused by misuse
or abuse including but not limited to improper installation, accident, unauthorized repair, maintenance, or
modications of the merchandise. This warranty: (1) excludes expendable parts including but not limited
to light bulbs, batteries; (2) carries a 2-year nish warranty protecting nish against tarnishing, aking, and
discoloration; (3) shall be void if this lighting xture is not installed in the U.S.A; (4) does not cover products
installed within three miles of saltwater coastline or any area prone to salt spray; and (5) does not cover any
losses, labor, injuries to persons/property or costs. This warranty does give you specic legal rights and
you may have other rights, which vary from state to state. Be careful, it is recommended that installation be
done by a qualied professional; the purchaser has sole responsibility for proper installation in compliance
with all state and local code requirements. Seller’s employees are not qualied to advise you on the
use of this Merchandise. Any oral representation(s) made will not be binding on seller or its employees.
The rights under this limited warranty are to the original purchaser of the Merchandise and may not be
transferred to any subsequent owner. This limited warranty is in lieu of all warranties, expressed or implied
including warranties or merchantability and tness for a particular purpose. Seller shall not be liable for any
special, incidental, or consequential damages. The sole exclusive remedy against the seller will be for the
replacement of any defects as provided herein, as long as the seller is willing or able to replace this product
or is willing to refund the purchase price as provided above.
SAVE YOUR RECEIPTS. THIS WARRANTY IS VOID WITHOUT THEM.
Patriot Lighting® is a registered trademark
of Menard, Inc. All Rights Reserved.
C
32
Before beginning assembly, installation, or operation of product, make sure all parts are present. Compare
parts with package and hardware contents list on page 1. If any part is missing or damaged, do not attempt to
assemble, install or operate the product. Contact customer service for replacement parts: 1-844-255-9692
Monday – Friday 9:00 a.m. – 6:00 p.m. CST.
Tools Required for Assembly (not included): Screwdriver, Tape Measure, Pencil, Safety Glasses, and Ladder
SAFETY INFORMATION
PREPARATION
DANGER
• Be careful not to damage or cut the jacket of the power cord during xture installation. Do not permit power
cord to contact any surface having a sharp edge. To do so may damage or cut the wire insulation, which
could cause serious injury or death from electric shock.
• This xture requires a 120V AC electrical wall socket for operation and consumes 12W per xture.
INSTALLATION INSTRUCTIONS
WARNING: These products may represent a possible shock or re hazard if improperly installed or attached
in any way. Products should be installed in accordance with these instructions, current electrical codes, and/or
the current National Electric Code (NEC).
WARNING: To reduce risk of re, electric shock, or injury to persons, be sure that power supply is turned o
at fuse box or circuit breaker before attempting installation or servicing of the xture. For safest operation, read
and become familiar with complete installation instructions prior to use. Pay close attention to this manual and
stay within its guidelines when using this product.
SAVE THESE INSTRUCTIONS
ADDITIONAL SAFETY MEASURES
1. To avoid electrical shock, do not turn on xture with missing or damaged lens.
2. There are no serviceable parts inside LED module.
3. LEDs emit bright light. Avoid looking directly at the light source.
4. Do not alter the power cord in any way.
5. Do not use with any other cord, cable, or connector other than those provided with the xture.
6. Not to be used with a dimming circuit.
7. This xture is suitable for dry and damp locations.
8. Do not mount over a sink, tub or shower.
1. Select a suitable location for the Grow Light that does not
move, can support its weight, and has an available 120V outlet
within 5 feet of the front of the xture to ensure that the xture
is powered properly. Mark two locations on the mounting
surface that are 20-3/8 inches apart. Make the holes wide
enough for the wall anchors to t snug.
Fig. 1
20-3/8in.
2. Start holes in mounting surface with screw-gun or awl, then
insert the supplied wall anchors (C) to the holes, and attach
the xture (A) by screwing in the mounting screws (B) at these
locations through the mounting holes on either end of the
xture (A).
Fig. 2
3. Insert the attached power cord into an appropriate 120V AC
receptacle.
Fig. 3
6. Use the switches on the power cord end of the xture (A) to
adjust the spectrum via Red + Blue + White settings.
Color Changing:
Red light promotes owering.
Blue light enhances vegative growth.
White light provides usable task light.
Switch color spectrums throughout plant growth to increase
yield of plant.
4. Multiple xtures (up to twelve) can be linked together and
powered by one power cord. WARNING: When linking
multiple xtures,
UNPLUG POWER CORD FROM OUTLET
BEFORE PROCEEDING.
Follow steps 1-2 for the additional
xture(s). Ensure each xture end is no more than 5 feet apart
to allow for power cord to reach.
5. Link xtures (A) by plugging the power cord from one end
of the xture (A) into the receptacle on the other end of the
subsequent xture (A).
Fig. 6
Fig. 4
Fig. 5
20-3/8in.
20-3/8in.
<5ft.
A
C
B
32
Before beginning assembly, installation, or operation of product, make sure all parts are present. Compare
parts with package and hardware contents list on page 1. If any part is missing or damaged, do not attempt to
assemble, install or operate the product. Contact customer service for replacement parts: 1-844-255-9692
Monday – Friday 9:00 a.m. – 6:00 p.m. CST.
Tools Required for Assembly (not included): Screwdriver, Tape Measure, Pencil, Safety Glasses, and Ladder
SAFETY INFORMATION
PREPARATION
DANGER
• Be careful not to damage or cut the jacket of the power cord during xture installation. Do not permit power
cord to contact any surface having a sharp edge. To do so may damage or cut the wire insulation, which
could cause serious injury or death from electric shock.
• This xture requires a 120V AC electrical wall socket for operation and consumes 12W per xture.
INSTALLATION INSTRUCTIONS
WARNING: These products may represent a possible shock or re hazard if improperly installed or attached
in any way. Products should be installed in accordance with these instructions, current electrical codes, and/or
the current National Electric Code (NEC).
WARNING: To reduce risk of re, electric shock, or injury to persons, be sure that power supply is turned o
at fuse box or circuit breaker before attempting installation or servicing of the xture. For safest operation, read
and become familiar with complete installation instructions prior to use. Pay close attention to this manual and
stay within its guidelines when using this product.
SAVE THESE INSTRUCTIONS
ADDITIONAL SAFETY MEASURES
1. To avoid electrical shock, do not turn on xture with missing or damaged lens.
2. There are no serviceable parts inside LED module.
3. LEDs emit bright light. Avoid looking directly at the light source.
4. Do not alter the power cord in any way.
5. Do not use with any other cord, cable, or connector other than those provided with the xture.
6. Not to be used with a dimming circuit.
7. This xture is suitable for dry and damp locations.
8. Do not mount over a sink, tub or shower.
1. Select a suitable location for the Grow Light that does not
move, can support its weight, and has an available 120V outlet
within 5 feet of the front of the xture to ensure that the xture
is powered properly. Mark two locations on the mounting
surface that are 20-3/8 inches apart. Make the holes wide
enough for the wall anchors to t snug.
Fig. 1
20-3/8in.
2. Start holes in mounting surface with screw-gun or awl, then
insert the supplied wall anchors (C) to the holes, and attach
the xture (A) by screwing in the mounting screws (B) at these
locations through the mounting holes on either end of the
xture (A).
Fig. 2
3. Insert the attached power cord into an appropriate 120V AC
receptacle.
Fig. 3
6. Use the switches on the power cord end of the xture (A) to
adjust the spectrum via Red + Blue + White settings.
Color Changing:
Red light promotes owering.
Blue light enhances vegative growth.
White light provides usable task light.
Switch color spectrums throughout plant growth to increase
yield of plant.
4. Multiple xtures (up to twelve) can be linked together and
powered by one power cord. WARNING: When linking
multiple xtures,
UNPLUG POWER CORD FROM OUTLET
BEFORE PROCEEDING.
Follow steps 1-2 for the additional
xture(s). Ensure each xture end is no more than 5 feet apart
to allow for power cord to reach.
5. Link xtures (A) by plugging the power cord from one end
of the xture (A) into the receptacle on the other end of the
subsequent xture (A).
Fig. 6
Fig. 4
Fig. 5
20-3/8in.
20-3/8in.
<5ft.
A
C
B
14
21” LED GROW LIGHT
SKU Number: 346-0643
Model Number: 0005-0223
PACKAGE CONTENTS
Note: Hardware not shown to actual size.
Questions, problems, missing parts?
Before returning to your retailer, call our customer service at
1-844-255-9692 Monday – Friday 9:00 a.m. – 6:00 p.m. CST
Questions, problems, missing parts?
Before returning to your retailer, call our customer service at
1-844-255-9692 Monday – Friday 9:00 a.m. – 6:00 p.m. CST
• Periodically, dust the outside surface of the frosted lens with a dry soft cloth. Clean with a clean damp
cloth if needed. Do not use chemical solvents or harsh abrasives to clean xture.
CARE AND MAINTENANCE
WARRANTY
1) The light does not come on at all:
a)If “ON/OFF” button is in the “OFF” position, push button on xture once so that it is in the “ON” position.
b) If outlet is on a switched circuit, make sure the circuit breaker is on.
If unable to x the above issue, please consult a certied electrician.
TROUBLESHOOTING
PART DESCRIPTION QUANTITY
A 21” LED Grow Light with attached 5ft power cord 1
B Mounting Screw 2
C Wall Anchors 2
A
B
RV2135
This PATRIOT LIGHTING® brand light xture carries a ve (5) Year Limited Warranty to the original
purchaser. If, during normal use, this PATRIOT LIGHTING® light xture fails due to a defect in material
and workmanship within ve (5) years from the date of purchase, simply bring this light xture with your
original sales receipt back to your nearest MENARDS® retail store. At its discretion, PATRIOT LIGHTING®
agrees to have the lighting xture replaced with the same or similar PATRIOT LIGHTING® product free of
charge, within the stated warranty period, when returned by the original purchaser with original sales receipt.
Notwithstanding the foregoing, this limited warranty does not cover damage or failure caused by misuse
or abuse including but not limited to improper installation, accident, unauthorized repair, maintenance, or
modications of the merchandise. This warranty: (1) excludes expendable parts including but not limited
to light bulbs, batteries; (2) carries a 2-year nish warranty protecting nish against tarnishing, aking, and
discoloration; (3) shall be void if this lighting xture is not installed in the U.S.A; (4) does not cover products
installed within three miles of saltwater coastline or any area prone to salt spray; and (5) does not cover any
losses, labor, injuries to persons/property or costs. This warranty does give you specic legal rights and
you may have other rights, which vary from state to state. Be careful, it is recommended that installation be
done by a qualied professional; the purchaser has sole responsibility for proper installation in compliance
with all state and local code requirements. Seller’s employees are not qualied to advise you on the
use of this Merchandise. Any oral representation(s) made will not be binding on seller or its employees.
The rights under this limited warranty are to the original purchaser of the Merchandise and may not be
transferred to any subsequent owner. This limited warranty is in lieu of all warranties, expressed or implied
including warranties or merchantability and tness for a particular purpose. Seller shall not be liable for any
special, incidental, or consequential damages. The sole exclusive remedy against the seller will be for the
replacement of any defects as provided herein, as long as the seller is willing or able to replace this product
or is willing to refund the purchase price as provided above.
SAVE YOUR RECEIPTS. THIS WARRANTY IS VOID WITHOUT THEM.
Patriot Lighting® is a registered trademark
of Menard, Inc. All Rights Reserved.
C
