TELESCOPIC FLEXI RECHARGEABLE
MAGNETIC PICK-UP TOOL LIGHT 1W SMD LED
MODEL NO: LED100PTR
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. GENERAL SAFETY
9 Ensure the light is fully charged before initial use.
8 DO NOT turn the light on when it is being charged.
8 DO NOT shine directly into your, another person’s or an animal’s eyes.
8 DO NOT allow children to use the light.
8 DO NOT handle or move the light whilst it is being charged.
8 DO NOT use the light if you suspect that the battery or the light casing is damaged.
8 DO NOT leave battery in a discharged state, recharge battery immediately. Before storage, fully recharge the battery, subsequently
recharge the battery at least once every six months of non-use.
1.2. BATTERY SAFETY
WARNING! To reduce the risk of burns or re:
8 DO NOT attempt to open, disassemble, modify or service the battery pack.
8 DO NOT crush, puncture, short external contacts or dispose of in re or water.
8 DO NOT expose to temperatures above 60°C (140°F).
9 Recycle or dispose of used battery as stipulated by local regulation.
9 If the electrolyte in the cells gets on your skin, thoroughly wash with soap and water. If it gets in your eyes, rinse thoroughly with cool
water and seek immediate medical attention.
2. INTRODUCTION
Bright 1W SMD LED light produces 100 lumens to illuminate dark recesses. Light extends to give an extra 34cm of reach and bends in any
direction and holds it position wherever you need it. Features a magnetic ring on the end of the light for picking up nuts, bolts and small parts
up to 1.2kg. Features a rubber covered magnet on the end, along with a belt clip for hands-free operation. 3.7V 180mAh lithium-ion battery for
longer life, no memory eect and a much slower discharge than traditional Ni-MH batteries.
3. SPECIFICATION
Model No: ..........................................................LED100PTR
Battery: ..........................................3.7V 180mAh Lithium-ion
Charging time:................................................................2.5hr
LED Type: .............................................................. SMD LED
Lumen Output: ........................................High/Low: 100/30lm
Weight: ........................................................................ 0.09kg
Operating Time: ............................................High/Low: 2/6hr
4. OPERATION
4.1. CHARGING
Connect a USB lead to the port on the end, near the torch’s light.
4.2. On/o switch light pulses green whilst on charge. Solid green denotes full charge.
4.3. CHARGE STATE
On/o switch displays charge state when light is turned on and o: green ok/orange requires charging/red no charge.
4.4. OPERATION
Press On/o once for low power, again for full power, once more for o.
Extend segmented section and position light using exible section.
Base has a magnet as does ring around the light.
LED100PTR Issue 1 13/11/24
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the
product becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers
and dispose of the product and fluids according to local regulations.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
Original Language Version
© Jack Sealey Limited
5. MAINTENANCE
5.1. Keep the torch clean by wiping with a damp cloth.
5.2. Keep battery fully charged if left over long periods of time.
5.3. Store torch and batteries in a dry childproof area.
g.1
REGISTER YOUR
PURCHASE HERE
LED100PTR Issue 1 13/11/24
BATTERY REMOVAL
Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential purchasers of products
containing batteries (as defined within these regulations), that they are registered with Valpak’s registered compliance scheme. Jack
Sealey Ltd’s Batteries Producer Registration Number (BPRN) is BPRN00705.
