10W COB LED RECHARGEABLE POCKET
FLOODLIGHT 1000 LUMENS, WITH FLIP OUT
MAGNETIC BRACKET
MODEL NO: LED1000
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. GENERAL
9 Ensure the lamp is fully charged before initial use.
8 DO NOT turn the lamp on when it is being charged.
8 DO NOT shine directly into your, another person’s or an animal’s eyes.
8 DO NOT allow children to use the lamp.
8 DO NOT handle or move the lamp whilst it is being charged.
8 DO NOT use the lamp if you suspect that the battery, the lamp casing or the cable is damaged. Consult your Sealey Stockist.
8 DO NOT leave battery in a discharged state, recharge battery immediately. Before storage, fully recharge the battery,
subsequently recharge the battery at least once every six months of non-use.
1.2. BATTERY SAFETY
WARNING! To reduce the risk of burns or re:
8 DO NOT Attempt to open, dismantle, modify or service the battery pack.
8 DO NOT Crush, puncture, short external contacts or dispose of in re or water.
8 DO NOT Expose to temperatures above 40°C or below -10°C.
8 DO NOT Expose to direct sunlight for long periods of time.
8 DO NOT Expose to moisture.
WARNING! DO NOT place the lamp face down while in use.
9 If the electrolyte in the cells gets on your skin, wash thoroughly with soap and water. If it gets in your eyes, rinse thoroughly with
cool water and seek immediate medical attention.
2. INTRODUCTION
Compact, lightweight design with a large 1000lm output. Made with a tough ABS plastic housing with ip-out magnetic bracket.
Includes small carabiner, which can be used when no ferrous surface is available for additional storage and application solutions.
Magnetic bracket can be angled at a range of 180° making it simple and easy to direct up to 1000 lumens of light. Three light output
settings; low, high and ashing. Features LED battery level indicator. Fitted with a high quality 3.7V 2Ah lithium polymer battery.
Charges via a USB-C lead. (Supplied, with charge time of 4 hours). IP rating: IPX4.
3. SPECIFICATION
Model No.: .......................................................LED1000
Battery: ................................................3.7V 2Ah Li-Poly
Charging Time: .........................................................4hr
IP Rating ................................................................ IPX4
LED Type: ......................................................10W COB
Length: ................................................................... 9cm
Lumen Output .................................................... 1000lm
Operating time: ......................................................4.5hr
The battery tted to this lamp is considered to be a consumable item and its ability to accept a charge will reduce over time.We
will provide warranty against mechanical and electrical defect for a period of one year. This does not cover fair wear and tear.If the
battery is not properly charged before rst use, or regularly conditioned, its capacity will diminish. Under these circumstances we will
not replace the battery regardless of whether it is less than one year old.
NOTE: The lithium battery does not suer from memory eect and once fully charged may be stored for up to six months without
another charge.
LED1000 Issue 3 (4) 03/06/24
Original Language Version
© Jack Sealey Limited
Refer to
instructions
4. OPERATION
4.1. CHARGING
4.1.1. Insert the Micro USB plug on the USB cable into the charging port on the side of the lamp.
4.1.2. Plug the other end of the USB cable into a 5V USB outlet.
WARNING! DO NOT turn lamp on whilst charging.
4.1.3. The battery indicator will blink blue during charging.
4.1.4. As the battery charges it will indicate 25% ashing blue light 50%, ashing blue light, 75% ashing blue light, 100% ashing blue light
until the battery has charged fully and all remain solid.
4.2. USE OF LAMP
4.2.1. Direct the lens away from your eyes, other people and animals before switching on.
4.2.2. Push the ON/OFF switch once for half power mode, twice for full power mode and a third time for ashing mode.
4.2.3. The lamp may be held by the handle or attached to any ferrous surface by using the magnet.
4.2.4. IMPORTANT: Only use the cable supplied with the product.
5. MAINTENANCE
5.1. Clean the casing externally (not the glass) with a moist cloth.
5.2. If necessary clean the glass with an alcohol dampened soft cloth.
8 DO NOT use solvents or abrasives.
8 DO NOT allow unit to get wet or use/store in a damp environment.
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
BATTERY REMOVAL
Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential purchasers of products
containing batteries (as defined within these regulations), that they are registered with Valpak’s registered compliance scheme. Jack
Sealey Ltd’s Batteries Producer Registration Number (BPRN) is BPRN00705.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
REGISTER YOUR
PURCHASE HERE
Mode
Selection
Button (On/
O)
USB
Connections
Cover/
Charging
Point
Tripod Mounting
Tripod Mounting
Mode
Selection
Button (On/
O)
Carabiner/magnetic stand
LED charge
indication
LED1000 Issue 3 (4) 03/06/24
