POCKET FLOODLIGHT 5W COB LED
MODEL NO: LED500P
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. GENERAL
9 Ensure the lamp is fully charged before initial use.
8 DO NOT turn the lamp on when it is being charged.
8 DO NOT shine directly into your, other person’s or an animal’s eyes.
8 DO NOT allow children to use the lamp.
8 DO NOT handle or move the lamp whilst it is being charged.
8 DO NOT use the lamp if you suspect that the battery, the lamp casing or the cable is damaged. Consult your Sealey Stockist.
8 DO NOT leave battery in a discharged state, recharge battery immediately. Before storage, fully recharge the battery,
subsequently recharge the battery at least once every six months of non-use.
1.2. BATTERY SAFETY
WARNING! To reduce the risk of burns or re:
8 DO NOT Attempt to open, dismantle, modify or service the battery pack.
8 DO NOT Crush, puncture, short external contacts or dispose of in re or water.
8 DO NOT Expose to temperatures above 40°C or below -10°C.
8 DO NOT Expose to direct sunlight for long periods of time.
8 DO NOT Expose to moisture.
WARNING! DO NOT place the lamp face down while in use.
9 Replace only with the battery pack designated for this product.
9 Recycle or dispose of used battery as stipulated by local regulation.
9 If the electrolyte in the cells gets on your skin, wash thoroughly with soap and water. If it gets in your eyes, rinse thoroughly with
cool water and seek immediate medical attention.
2. INTRODUCTION
5W COB LED produces up to 500 lumens with a wide spread of light, illuminating the whole work area. Compact oodlight ts in the palm
of your hand, easy to transport and store and provides impressive performance. Rotating arm features built-in magnet, an M6 thread for
mounting onto a tripod and rotates 180° for easy direction of light. Can be switched between four light temperatures, for use in a variety
of different environments. Compact and durable construction ideal for use in any environment. Easy-to-read charge indicator displays the
battery level during use and while charging. Charges via a USB Type-C cable (supplied).
3. SPECIFICATION
The battery tted to this lamp is considered to be a consumable item and its ability to accept a charge will reduce over time. We will provide
warranty against mechanical and electrical defect for a period of one year - this does not cover fair wear and tear. If the battery is not properly
charged before rst use, or regularly conditioned, its capacity will diminish. Under these circumstances we will not replace the battery
regardless of whether it is less than one year old.
NOTE: The lithium battery does not suffer from memory effect and once fully charged may be stored for up to six months
without another charge.
LED500P Issue 2 09/01/25
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Model No LED500P
Battery 3.7V 1200mAh Li-ion
Charging Time 3hr
IP Rating IP44
LED Type COB
Lumen Output High/Med/Low: 500/250/125lm
Nett Weight 0.09kg
Operating Time High/Med/Low: 1/4/10hr
4. OPERATION
4.1. CHARGING
4.1.1. Insert the USB-C on the USB cable into the charging port on the top of the lamp.
4.1.2. Plug the other end of the USB cable into a 5V USB outlet.
WARNING! DO NOT turn lamp on whilst charging.
4.1.3. The battery indicator will blink during charging.
4.1.4. When the battery has charged fully the battery indicator will remain lit.
4.2. USE OF LAMP
4.2.1. Direct the lens away from your eyes, other people and animals before switching on.
4.2.2. Push the ON/OFF switch once for ECO mode, twice for Normal mode and a third time for Full power mode. Touch a forth time for a
red light and once more to make the red light ash.
4.2.3. The lamp is also equipped with a in light intensity switch which operates in all white light modes.
4.2.4. Rotating arm features a built-in magnet, an M6 thread for mounting onto a tripod and rotates 270° for easy direction of light.
IMPORTANT: Only use the cable supplied with the product.
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
BATTERY REMOVAL
Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential purchasers of products
containing batteries (as defined within these regulations), that they are registered with Valpak’s registered compliance scheme. Jack
Sealey Ltd’s Batteries Producer Registration Number (BPRN) is BPRN00705.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
Battery Indicator
Charging Port
Light intensity mode
On/Off Switch mode
Rotating armFront
Strap mounting point
LED500P Issue 2 09/01/25
