LOADING BAY FLOODLIGHT WITH FLEXIBLE

ARM 20W SMD LED

MODEL NO: LED20WDL

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these

instructions, and properly maintained, give you years of trouble free performance.

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE

THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR

PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.

1. SAFETY

1.1. ELECTRICAL SAFETY

 WARNING! It is the user’s responsibility to check the following:

9 Check all electrical equipment and appliances to ensure that they are safe before using.

9 Inspect power supply leads, plugs and all electrical connections for wear and damage.

9 Ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply.

8 DO NOT use worn or damaged cables, plugs or connectors.

9  EnsurethatanyfaultyitemisrepairedorreplacedimmediatelybyaSealeyqualiedtechnician.

9  Ifthecableorplugisdamagedduringuse,switcho󰀨theelectricitysupplyandremovefromuse.

9 SealeyrecommendthatanRCD(ResidualCurrentDevice)isusedwithallelectricalproducts.

Important:Ensurethatthevoltageratingontheappliancesuitsthepowersupplytobeusedandthattheplugisttedwiththe

correct fuse.

8 DO NOT pull or carry the appliance by the power cable.

8 DO NOT pull the plug from the socket by the cable.

9  Toreducetheriskofstrangulationtheexiblewiringconnectedtothisluminaireshallbee󰀨ectivelyxedtothewallifthewiringis

within arms reach.

9  Thelightsourcecontainedinthisluminaireshallonlybereplacedbythemanufacturerorhisserviceagentorasimilarqualied 

person.

2. INTRODUCTION

 Powerful20WSMDLEDprovidesup3000lmwithawidespreadoflight.Illuminatingthewholeworkarea.Reducesriskofaccidents

 ordamagebyclearlylightingloadingbays.Weatherproofexiblearmcanextendupto70cminanydirection.Providestheoptimum

 electricalinputforthelightwhichensuresthemaximumlifespanfortheLEDs.Suitableforuseinindustrialandprofessional 

 environmentswithIP65rating.

3. SPECIFICATION

Original Language Version

Refer to

instructions

LED20WDLIssue122/04/25

Model No LED20WDL

Fuse Rating 13A

IP Rating IP65

LED Type 20W SMD

Lumen Output 3000lm

Nett Weight 1.9kg

Plug Type 3-PinBS

Power Supply Cable Length 1.5m

Supply 230V~50Hz

Risk of shock

4. INSTALLATION

 WARNING!Mountoodlightonaatandsolidwallsuchasbreezeblockthatisstrongenoughtosecurelyholdtheunitwhenfully

 extended.

4.1.  SecuresolidtostructuresusinganM6plasticexpansionwallplugandscrew(g.2).

4.2.  Toaccesstheenclosure,rstdetachthecoverbyunscrewingthetwofastenerspositionedontheenclosure’sside.Then,slidethe

 coverupwardalongtheexibletubeuntiltheback-plateassemblyisfullyexposed(g.3).

4.3.  Therecommendedmountingheightfortheunitisbetween1.22mand1.5240mfromtheoor,measuredfromthebottomofthe 

 enclosure.Usingthetwokey-holeslotsintheback-plateassemblyasatemplate,drillappropriatelysizedholesforthefastenersor

 wallanchors.Securetheback-plateinplaceusingM4screws.Positiontheunitasclosetothedoortrackaspossible,ensuringitdoes

 notinterferewithanymovingpartsofthedoor(g.4).

4.4.  Oncetheunitissecurelymountedtothewall,lowerthecoverintoplaceandreattachthetwosidefasteners(g.5).

4.5.  Connecttheunittoanelectricaloutletthatmeetsthespecicationslistedontheproductlabel(g.6).

5. MAINTENANCE

 WARNING! Disconnect from mains supply.

5.1. Cleanthecasingexternally(not the glass)withamoistcloth.

8 DO NOTusesolventsorabrasives.

5.2. If necessary, clean the glass with alcohol and a soft cloth.

Original Language Version

Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR

01284 757500 sales@sealey.co.uk www.sealey.co.uk

ENVIRONMENT PROTECTION

Recycleunwantedmaterialsinsteadofdisposingofthemaswaste.Alltools,accessoriesandpackagingshouldbesorted,takento

arecyclingcentreanddisposedofinamannerwhichiscompatiblewiththeenvironment.Whentheproductbecomescompletely

unserviceableandrequiresdisposal,drainanyfluids(ifapplicable)intoapprovedcontainersanddisposeoftheproductandfluids

according to local regulations.

WEEE REGULATIONS

DisposeofthisproductattheendofitsworkinglifeincompliancewiththeEUDirectiveonWasteElectricalandElectronicEquipment

(WEEE).Whentheproductisnolongerrequired,itmustbedisposedofinanenvironmentallyprotectiveway.Contactyourlocalsolid

waste authority for recycling information.

Note:Itisourpolicytocontinuallyimproveproductsandassuchwereservetherighttoalterdata,specificationsandcomponentparts

without prior notice.

Important: No Liability is accepted for incorrect use of this product.

Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.

PURCHASE HERE

LED20WDLIssue122/04/25
