8W COB & 1W SMD LED RECHARGEABLE
INSPECTION LIGHT
MODEL NO: LED1001.V2, LED1001G
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. GENERAL SAFETY
9 Ensure the light is fully charged before initial use.
8 DO NOT turn the light on when it is being charged.
8 DO NOT shine directly into your, another person’s or an animal’s eyes.
8 DO NOT allow children to use the light.
8 DO NOT handle or move the light whilst it is being charged.
8 DO NOT use the light if you suspect that the battery or the light casing is damaged.
8 DO NOT leave battery in a discharged state, recharge battery immediately. Before storage, fully recharge the battery, subsequently
recharge the battery at least once every six months of non-use.
1.2. BATTERY SAFETY
WARNING! To reduce the risk of burns or re:
8 DO NOT attempt to open, disassemble, modify or service the battery pack.
8 DO NOT crush, puncture, short external contacts or dispose of in re or water.
8 DO NOT expose to temperatures above 60°C (140°F).
9 Recycle or dispose of used battery as stipulated by local regulation.
9 If the electrolyte in the cells gets on your skin, thoroughly wash with soap and water. If it gets in your eyes, rinse thoroughly with cool
water and seek immediate medical attention.
2. i INTRODUCTION
Smooth 90° flex with additional 360° twist function enables the light source to be
positioned in any direction. Super bright 8W COB LED provides up to 1000 lumens
output with 120° spread of light, illuminating the whole work area. Includes an additional
high power 1W SMD LED directional torch. Features a swivel hanging hook and rubber
covered magnet on the base, which allow hands-free operation. Two high quality 2.6Ah
lithium-ion batteries for longer life. Supplied with Type-C USB cable.
3. i SPECIFICATION
Model No: ...............................LED1001.V2, LED1001G
Battery: ................................3.7V 2.6Ah Lithium-ion (x2)
Charging Time: ...........................................................5hr
IP Rating: .................................................................IP54
LED Type: .......................................8W COB + 1W SMD
Length: ................................................................240mm
Lumen Output -Side (High/Low) ................... 1000/500lm
Lumen Output - Top: ............................................. 100lm
Nett Weight: ....................................................... 0.407kg
Operating Time - Side (High/Low): ..........................2-4hr
Operating Time - Top: ...............................................16hr
IMPORTANT WARRANTY INFORMATION
The battery tted to this light is considered to be a consumable item and its ability to accept a charge will reduce over time. We will
provide warranty against mechanical and electrical defect for a period of one year - this DOES NOT cover fair wear and tear.
If the battery is not properly charged before rst use, or regularly conditioned, its capacity will diminish. Under these circumstances we
will not replace the battery regardless of whether it is less than one year old.
4. OPERATION
4.1. CHARGING THE LIGHT
4.1.1. Connect the USB lead to the socket on the rear of the light.
4.1.2. Plug USB lead into a power supply and turn on.
4.1.3. When the battery has fully charged the four LEDs on the front of the light will light green.
4.1.4. The LEDs will light upon initial switch on to indicate battery charge state.
Refer to
instruction
manual
On/O/Mode
Control
Battery state
LEDs
g.1
Original Language Version
© Jack Sealey Limited
LED1001.V2, LED1001G Issue 1 03/06/24
4.1.5. As battery charge decreases LEDs will switch o.
4.2. OPERATING THE LIGHT
4.2.1. Direct the lens away from your eyes before switching on.
4.2.2. The light ON/OFF/MODE button is located on the front of the light, as shown in g.1.
4.2.3. The operation sequence is:
A). One press - 50% light.
B). Two presses - 100% light.
C). Three presses - torch on
D). Four presses - light turns o.
4.2.4. When the battery has approximately 5 to 15 minutes of charge left, the LEDs will ash every 20 seconds as a warning.
4.2.5. The light may be suspended by the hook on rear of light or attached to any ferrous surface by using the magnet in the base.
5. MAINTENANCE
5.1. Keep the torch clean by wiping with a damp cloth.
5.2. Store torch in a dry childproof area.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice. Please note that other versions of this product are available. If you require documentation for alternative versions, please email or call
our technical team on technical@sealey.co.uk or 01284 757505.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
