SUPER BEAM RECHARGEABLE POCKET LIGHT,
10W SMD LED, 1000LM, 3 LIGHT MODES
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
9 Inspect the cable and connector for wear and damage to ensure items are safe before connecting to the power supply. If worn or
damaged DO NOT use.
9 Ensure the light is fully charged before initial use.
8 DO NOT charge in damp conditions.
8 DO NOT turn the light on when it is being charged.
8 DO NOT shine directly into you’re, another person’s or an animal’s eyes.
8 DO NOT allow children to use the light.
8 DO NOT handle or move the light whilst it is being charged.
8 DO NOT use the light if you suspect that the battery or the light casing is damaged.
8 DO NOT leave battery in a discharged state, recharge battery immediately. Before storage, fully recharge the battery, subsequently
recharge the battery at least once every six months of non-use.
8 DO NOT attempt to open, disassemble, modify or service the battery pack.
8 DO NOT crush, puncture, short external contacts or dispose of in re or water.
8 DO NOT expose to temperatures above 60°C (140°).
9 Replace only with the battery pack designated for this product.
9 Recycle or dispose of used battery as stipulated by local regulation.
9 If the electrolyte in the cells gets on your skin, thoroughly wash with soap and water. If it gets in your eyes, rinse thoroughly with cool
water and seek immediate medical attention.
WARNING! DO NOT place the lampface down while in use.
2. INTRODUCTION
Powerful 10W SMD LED torch with 1000lm output on super boost mode for 30 seconds. 73mm Long conveniently sized yet powerful torch
is easy to transport and store. 1m Height impact resistance and water resistance rating of IPX4. Features a belt clip and magnetic base
for hands-free operation. Easy to read charge indicator displays the current battery level while charging. Charges via a USB Type-C cable
(Supplied).
3. SPECIFICATION
The battery tted to this light is considered to be a consumable item and its ability to accept a charge will reduce over time. We will
provide warranty against mechanical and electrical defect for a period of one year - this does not cover fair wear and tear. If the battery
is not properly charged before rst use, or regularly conditioned, its capacity will diminish. Under these circumstances we will not
replace the battery regardless of whether it is less than one year old.
Note: The lithium battery does not suer from memory eect and once fully charged may be stored for up to six months without
another charge.
Refer to
instructions
Original Language Version
© Jack Sealey Limited
LED1000SB Issue 1 13/06/24
Model No LED1000SB
Battery: 3.7V 0.6Ah Lithium-ion
Charging Time: 2.5hr
LED Type: SMD LED
Lumen Output: 1000lm
Nett Weight: 0.063kg
Operating Time: High/Med/Low: 2/4/15hr
MODEL NO: LED1000SB
4. OPERATION
4.1. Connect the USB lead to the socket. See g.1. Connect the other end
into a charging socket. Turn on power supply. The ON/OFF button will
ash to indicate charging. Once light has been charged the ON/OFF
button will stop ashing.
4.2. The charging time to fully charge takes 2.5hrs. The ON/OFF button will
ash when the light requires charging.
WARNING! Never direct light into eyes.
4.3. To operate the light press ON/OFF button. The button illuminates to
conrm operation. See g.2. To select the brightness level press the
ON/OFF button until desired brightness. There are three brightness
settings and a super beam to choose from.
4.4. To use the super beam function, hold the power button down, the light
will illuminate up to 1000lms for 30 seconds.
4.5. To switch the light o press ON/OFF button until the light turns o.
BATTERY REMOVAL
Unscrew the base of the light. Remove the battery. Dispose of according to local government guidelines.
Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential purchasers of products
containing batteries (as defined within these regulations), that they are registered with Valpak’s registered compliance scheme. Jack
Sealey Ltd’s Batteries Producer Registration Number (BPRN) is BPRN00705.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic
Equipment (WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact
your local solid waste authority for recycling information.
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts
without prior notice.
IMPORTANT: No Liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any uids (if applicable) into approved
containers and dispose of the product and uids according to local regulations.
g.1
ON/OFF.
brightness
settings
and
charge
indicator
Belt clip
USB
charging
socket
Battery
compartment
g.2
Magnetic
base
