1. SAFETY
1.1. GENERAL SAFETY
8 DO NOT shine directly into your, another person’s or an animal’s eyes.
8 DO NOT allow children to use the torch.
8 DO NOT use the torch if you suspect that the battery or the torch casing is damaged.
8 DO NOT leave batteries in a discharged state. Before storage remove batteries and dispose of in the correct manner.
WARNING! Please keep out of reach of children, as lens generates heat on Super Beam setting.
1.2. BATTERY SAFETY
WARNING! To reduce the risk of burns or re:
8 DO NOT attempt to open the batteries.
8 DO NOT crush, puncture, short contacts or dispose of in re or water.
8 DO NOT expose to temperatures above 60°C (140°F).
9 Replace only with the batteries designed for this product.
9 Recycle or dispose of used batteries as stipulated by local regulation.
9 If the electrolyte in the batteries gets on your skin, thoroughly rinse with water. If it gets in your eyes, rinse thoroughly with cool
water and seek immediate medical attention.
2. INTRODUCTION
30W SMD LED produces extremely bright, white light with an output of 1400 lumens, with a super beam output of 3500lm for 35
seconds. Working range up to 250m. Powered by a rechargeable 3.7V 2Ah lithium-ion battery with a charging time of 3-4hrs. Supplied
with micro USB charging lead. ***WARNING*** Please keep out of reach of children, as lens generates heat on Super Beam setting.
3. SPECIFICATION
Model No: LED451
Battery: 3.7V 2Ah Li-ion
Charging Time: 4-5hr
LED Type: 3 X 10W SMD LED
Lumen Output: Super Beam; 3500lm for 35 seconds; High;1400lm
Operating Time: Super Beam for 35 seconds + High; 1.2hr, Low; 10hr
IMPORTANT WARRANTY INFORMATION
The batteries tted to this lamp are considered to be consumable items and their ability to accept a charge will reduce over time. We
will provide warranty against mechanical and electrical defect for a period of one year - this DOES NOT cover fair wear and tear.
If the batteries are not properly charged before rst use, or regularly conditioned, their capacity will diminish. Under these
circumstances we will not replace the battery regardless of whether it is less than one year old.
4. OPERATION
Note: Remove plastic disc between battery and spring before turning on.
4.1. LIGHTING SEQUENCE
4.1.1. Press the power button (g.1) once for lowest output, press twice for medium
output, three presses for highest output.
4.1.2. Press and hold power button for an ultra bright Super Beam mode.
4.1.3. Double press the power button for SOS mode.
4.2. CHARGING THE BATTERY
4.2.1. Connect to power source via usb.
4.2.2. Power button will glow red when charging and change to blue when fully charged.
Power Button
30W SMD LED SUPER BEAM
RECHARGEABLE POCKET LIGHT
MODEL NO: LED451
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
LED451 Issue 5 (H) 08/02/24
Original Language Version
© Jack Sealey Limited
Refer to
instructions
g.1
5. MAINTENANCE
5.1. Keep the torch clean by wiping with a damp cloth.
5.2. Remove batteries if not being used for a long period of time.
5.3. Store torch and batteries in a dry childproof area.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic
Equipment (WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact
your local solid waste authority for recycling information.
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts
without prior notice.
IMPORTANT: No Liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any uids (if applicable) into approved
containers and dispose of the product and uids according to local regulations.
LED451 Issue 5 (H) 08/02/24
Original Language Version
© Jack Sealey Limited
BATTERY REMOVAL
Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential purchasers of products
containing batteries (as defined within these regulations), that they are registered with Valpak’s registered compliance scheme. Jack
Sealey Ltd Batteries Producer Registration Number (BPRN) is BPRN00705.
