3W COB + 1W SMD LED RECHARGEABLE
ALUMINIUM POCKET LIGHT WITH UV
MODEL NO: LED220UV
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. GENERAL
9 Ensure the light is fully charged before initial use.
8 DO NOT turn the light on when it is being charged.
8 DO NOT shine directly into your, other person’s or an animal’s eyes.
8 DO NOT allow children to use the light.
8 DO NOT handle or move the light whilst it is being charged.
8 DO NOT use the light if you suspect that the battery, the light casing or the cable is damaged. Consult your Sealey Stockist.
8 DO NOT leave battery in a discharged state, recharge battery immediately. Before storage, fully recharge the battery,
subsequently recharge the battery at least once every six months of non-use.
1.2. BATTERY SAFETY
WARNING! To reduce the risk of burns or re:
8 DO NOT Attempt to open, dismantle, modify or service the battery pack.
8 DO NOT Crush, puncture, short external contacts or dispose of in re or water.
8 DO NOT Expose to temperatures above 40°C or below -10°C.
8 DO NOT Expose to direct sunlight for long periods of time.
8 DO NOT Expose to moisture.
WARNING! Do not place the light face down while in use.
9 Replace only with the battery pack designated for this product.
9 Recycle or dispose of used battery as stipulated by local regulation.
9 If the electrolyte in the cells gets on your skin, wash thoroughly with soap and water. If it gets in your eyes, rinse thoroughly with cool
water and seek immediate medical attention.
2. INTRODUCTION
Powerful 3W COB with 1W SMD and 2 x UV SMD. USB rechargeable lithium-ion battery with small green/red charging indicator light.
Made from aluminium, anodized and nished with rubber coating for a more premium feel. A strong magnet in the pocket/belt clip
allows for hands-free use as well as a second strong magnet in the base. Features two longwave UV-A SMDs at 390-400nm.
3. SPECIFICATION
Model No: .....................................................LED220UV
Battery .................................................3.7V 2.2Ah Li-ion
Charging Time: .........................................................3hrs
LED Type: 3W COB, 1W SMD, 2 x UV-A 390-400nm SMD
Length: ................................................................ 110mm
Lumen Output: ...................................................... 220lm
Operating Time: ......................Worklight/Torch 3hrs/7hrs
4. CHARGING
NOTE: The battery fitted to this light is considered to be a consumable item and its ability to accept charge will reduce over time. We will
warranty it against mechanical and electrical defect for a period of one year, this does not cover fair wear and tear. If the battery is not
properly charged before first use, or regularly conditioned, its capacity will diminish. Under these circumstances we will not replace the
battery even if it is less than one year old.
4.1. Connect the charger into the charge socket on the light, see fig.1.
4.2. Plug into power supply and turn on. The red charge LED on the light next to the charging port will light as the battery charges.
4.3. When fully charged the LED turns green.
4.4. When the battery has fully charged (approx 3hrs) Disconnect from mains supply.
NOTE: The Lithium battery does not suffer from memory effect and once fully charged may be stored for up to six months without another
charge.
Refer to
Instruction
Manual
fig.1
Original Language Version
© Jack Sealey Limited
LED220UV Issue 2 (2,3,4,F) 21/06/23
Original Language Version
© Jack Sealey Limited
5. OPERATION
5.1. Press on/o switch (see g.1):
A). First press: lights top 1W SMD
B). Second press: lights front 3W COB,
C). Third press: switches everything o.
D). Hold for 2 seconds: UV lights
6. MAINTENANCE
6.1. Keep light clean and check for damage before every use. If damage is observed, remove from use until unit is repaired.
6.2. The battery is not designed to be removed.
LED220UV Issue 2 (2,3,4,F) 21/06/23
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
