Mattress Vacuum Cleaner
Please read this instruction carefully before using the product,
and keep it properly for review
Instruction Manual
MV11
Important Safety Instructions------------------------------------------------1
Introduction of Components----------------------------------------------2-3
Product Specifications--------------------------------------------------------3
Operating Instructions-----------------------------------------------------4-5
Cleaning & Maintenance-------------------------------------------------6-10
How to clean the dust cup?------------------------------------------------6-8
How to clean the roller brush?-----------------------------------------------9
How to clean the UV lights?-------------------------------------------------10
Common Troubleshooting--------------------------------------------------11
CONTENTS
When using this product, please follow the following basic warnings:
1.UV rays will harm the skin and eyes of people and animals. Do not directly illuminate human
body, plants and animals.
2.Conduct local test on the irradiated sterilization, purification and disinfection objects first to
avoid damage to light-sensitive objects or non-anti-uv objects.
3.Please do not intentionally damage the roller (safety switch) at the bottom of the product so
that the UV lamp is unprotected.
4.Please do not intentionally touch the conductive plug of the hand-held vacuum cleaner to
avoid the risk of electric shock.
5.Don't plug the vacuum into the power supply while you're away.Unplug when not in use or
before maintenance.
6.To reduce the risk of electric shock, do not use it outdoors or on wet ground.
7.Please use the bed vacuum cleaner correctly according to the user manual.
8.Do not use the plug or power cord when it is damaged.If the product falls, damages, is placed
outdoors or falls into water and cannot work, please send itto the service department for
maintenance.
9.This product is for general household use, please do not use for commercial or other
purposes.
10.Try not to absorb glass slag, screws and other sharp hard objects, and construction waste,
to avoid damage to the machine.
11.Do not use the power cord as a handle or pull it close to the sharp edge.Do not place the
vacuum cleaner on a hot surface.
12.Do not use when any air ducts are blocked.Otherwise it will damage the motor.Store away
from dust, lint, hair, and anything that may clog and reduce air volume.
13. Keep hair, clothing, cell phones and any part of the body away from vacuum cleaner
openings and moving parts.
15. Please disconnect the machine power before connecting the accessory.
16. Do not absorb anything that is burning or smoking.Such as cigarette butts, matches or hot
ashes.
14.Please turn off the machine switch before pulling out the power plug.
18. If the power cord is damaged and needs to be replaced, it must be carried out by a
17.Do not use when dust bucket or filter is not installed.Otherwise it will damage the motor.
professional or designated maintenance point.Do not dismantle it in case of danger.
Special Instruction:
The product should not be used by children, reduced physical, mental and sensory
capabilities, or anyone who lack of experience, this product is not a toy. Children
should be supervised to ensure they do not play with this product.
1
Important Safety Instructions
READ ALL INSTRUCTIONS BEFORE USING
WARNING – To reduce the risk of fire, electric shock, or injury:
SAVE THESE INSTRUCTIONS
Introduction of Components
Dust Cup
Remove Button
Power Cord
Handle
Power Switch
Dust Cup Assembly
Function Display
Main Body
Air Outlet
Big Roller
Mini Brush
Hot Wind Outlet
Roller Brush Cover Lock
Ultrasonic Hole
UV Lights
Transparent Cover
UV Lights Protection
Roller Brush
Roller Brush Cover
2
3
Introduction of Components
Hot Air
Ultrasonic
UV Lights
Vibration
Anion
Model MV11
Power 500W
Noise ≤70dB
Dust Cup 0.5L
Suction 16KPa
Motor Speed 40000 RPM
Size 11*9.45*7.48 IN
Operating Radius 5M
Rated Voltage 120V~60Hz
Roller Brush Speed 4000 RPM
Net/Gross Weight 3.9 LB/5.73 LB
Cord Length 16.5ft
Function Display
Product Specification
The Correct Way to Use the Machine
1. In order to protect users, our products adopt gravity sensing function in the machine. When the machine is
picked up, the UV and ultrasonic functions will stop working.
2. All daily maintenance work must be performed after the Bed Vacuum Cleaner is turned off.
3. Clean the dust cup frequently to avoid malfunction of the Mattress Vacuum Cleaner.
4. Do not use gasoline or oil to scrub the surface of the vacuum cleaner. It should be scrubbed with a soft cloth
or neutral detergent. The scrubbing cloth must be wrung out to prevent water from entering the Mattress
Vacuum Cleaner's electrical components.
5. The storage place should be kept dry.
6. No heavy objects should be stacked on the top of the machine.
7. It is normal for the machine to blow out hot air when it is working.
Do not use the machine
on sloping ground
Do not use the machine
suspended in the air
4
Operating Instructions
1. Plug the power cord into the socket, then press the Power Switch
to turn it on/off.
2. Press the switch button once to start working.
Press the switch button again to stop working.
3. Place the machine on the object to be cleaned
(such as bed, sofa, short-pile carpet), and slowly
push and pull the machine to clean.
(The recommended cleaning speed is
less than 20 seconds per meter and
more than 3 times).
4.Aromatherapy Placement
Place the aromatherapy tablets in the aromatherapy container. Enjoy the romantic
atmosphere and fresh, pleasant smell as you clean your home.
Operating Instructions
Open the Lid
Aroma Tablet
Close the Lid
5
Cleaning and Maintenance
Please clean the dust cup, roller brush and UV lights regularly.
How to clean the dust cup?
3.Hold the dust cup with one hand and open the dust cup cover buckle with
the other hand.
1.Turn off the bed vacuum cleaner and unplug the power plug.
2.Press the dust cup remove button, then take the dust cup out according
to the picture.
Dust Cup
Remove Button
6
Tip: Please replace the filter HEPA every two to three months.
Tip: The double dust cup separates dust and mites, making it less likely to get
clogged and avoid secondary pollution.
4.Take out the stainless steel filter and filter Hepa and clean it with water.
Cleaning and Maintenance
7
5.Tilt it to pour out the dust and wash the dust cup with water.
Cleaning and Maintenance
6.Clean the inner parts one by one and
wash them with water, reinstall them
after completely dry.
7.After the dust cup parts are reinstalled in place, install thhe upper cover component
Align the two buckles with the installation groove as show in the figure.
Filter Hepa
Dust Cup Cover
Stainless Steel Filter
Dust Cup
8
Click
Dust Cup Buckles
Tip: 1. It is recommended to clean the dust cup and filter Hepa after each use.
2. When the dust cup is full, it is recommended to clean it immediately, otherwise it
will affect the use effect.
3. Do not scrub the filter Hepa vigorously.
4. After washing the dust cup assembly with water, make sure that all parts of
the dust cup are completely dry before placing them into the main unit.
Cleaning and Maintenance
1. Please turn off the power first, press and hold the cover locks on both sides to
pop up the cover, and then take out the roller brush.
2. Rinse the roller brush with clean water, dry it and reinstall it.
3. First align one side of the roller brush and return it to its original position to
ensure that its angle is correct.
4. Align the tip of the cover with the card slot and place it.
9
12
6
111
57
210
48
39
UV Lights
Transparent Cover
Cleaning and Maintenance
How to clean the UV lights?
10
Tip:
1. Do not use UV rays to irradiate people or pets, and make sure the power is
disconnected before cleaning the UV light cover.
2. Do not look directly at the UV light when it is on.
3. Please wipe the transparent cover of the UV lamp before use to ensure its best
sterilization effect.
Users can check the problem with the following general problems:
Note: If the following problems, turn off the switch imnnediately to prevent damage to the machine
and other hazards.
Common Troubleshooting
Problem
Possible reason Solution
Not plug in Plug in
The socket is out of power Try another socket
Bed vacuum cleaner
is damaged
Replace bed vacuum cleaner
(contact customer service)
Unnormal noise or weak
suction
The dust cup is full, or the
air outlet is blocked
Clean the dust cup, the
lter and the
air outlet
The bed vacuum cleaner is
li ed too high
Put the bed vacuum cleaner on the
working su ace (bed, sofa ect.)
UV lights are broken Contact customer service
The roller brush is
entangled or stuck
Clean the roller brush
The motor is damaged
Replace the bed vacuum cleaner
(contact customer service)
Bed vacuum cleaner won't
start
UV lights do not w
Functional display
not working
Circuit board failure Contact customer service
ork
T
The product makes
abnormal sounds
Dust is blown out
during use
It is full of dust or the air
duct is blocked
The filter device in the
dust bucket is damaged
Stop using it immediately and
replace it with a new filter
Stop using it immediately
and install the filter in place
Forgot to install filter
Take out the dust bucket and
clean out any garbage
or blockage
he roller brush does not
work
11
If you have any problems, please scan the QR code below to contact us directly,
we will solve your problem as soon as possible!
