SMD LED EXTRA SLIM FLOODLIGHT WITH
PIR SENSOR
MODEL NO’S: LED112PIR.V2, LED113PIR.V2,
LED115PIR.V2
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. ELECTRICAL SAFETY
WARNING! It is the user’s responsibility to read, understand and comply with the following:
WARNING! THIS PRODUCT MUST BE INSTALLED BY A QUALIFIED ELECTRICIAN.
9 You must check all electrical equipment and appliances to ensure they are safe before using. You must inspect power supply leads
and all electrical connections for wear and damage.
9 You must ensure the risk of electric shock is minimised by the installation of appropriate safety devices.
9 You must also read and understand the following instructions concerning electrical safety.
9 Ensurethelightisconnectedtoanappropriateelectricalon/oswitch.
9 Ensure the insulation on all cables and the product itself is safe before connecting to the mains power supply.
9 Ensure that cables are always protected against short circuit and overload.
9 Regularly inspect power supply, leads and all electrical connections for wear and damage, especially power connections, to ensure
that none are loose.
9 Ensure the voltage marked on the product is the same as the electrical power supply to be used.
8 DO NOT pull power cable once installed.
8 DO NOTusewornordamagedleads,orconnections.ImmediatelyreplaceorhaverepairedbyaqualiedElectrician.
9 Ensuretheunitiscorrectlyearthedandwiredaccordingtothefollowing.(Installationshouldbeundertakenbyaqualiedelectrician).
a)Connectthegreen/yellowearthwiretotheearthterminal‘E’.
b)Connectthebrownlivewiretoliveterminal‘L’.
c)Connecttheblueneutralwiretotheneutralterminal‘N’.
9 After wiring, check there are no bare wires, that all wires have been correctly connected.
1.2. GENERAL SAFETY
WARNING!Turnothemainspowersupplybeforeservicingorperforminganymaintenance.
9 Maintainthelightingoodcondition(Repairsmustonlybeundertakenbyaqualiedelectrician).
9 Replace or repair damaged parts. Use genuine parts only, non authorised parts may be dangerous and will invalidate the warranty.
9 Ensure the light is installed correctly in accordance with these instructions.
9 Only install the light on a vertical surface.
8 DO NOTxthelightonanyhorizontalsurfacei.e.ceiling,oroverhang.
9 IdeallytheInstallationshouldbeawayfromammableorcombustiblematerialssuchaswood,cloth,paperetc.
▲ DANGER! DO NOT direct the light into a persons eyes. The units have a very intensive light output, which if incorrectly used could
cause eye damage.
8 DO NOT install the light where it is likely to be knocked or hit.
8 DO NOT install in bathrooms, shower rooms, sauna or such locations.
8 DO NOTinstallnearanexhaustoutlet.i.e.boilerue,dryeroutlet,etc.
8 DO NOTusethelightwithoutthefrontglassshieldtted.
2. INTRODUCTION
Mountedindie-castpowdercoatedaluminiumextraslimhousingwithwallbracket.SMDLEDtechnologyallowsultra-bright
illumination whilst still keeping costs lower than traditional halogen tubes. Even spread of light across a 110° angle. Features a PIR
motion detector. Supplied with power cable at 75cm only and suitable for outdoor mounting.
Original Language Version
© Jack Sealey Limited
Refer to
instructions
LED112PIR.V2,LED113PIR.V2,LED115PIR.V2Issue3(2)30/05/23
3. SPECIFICATION
4. OPERATION
WARNING! DO NOT connect unit to the mains power supply before installation.
4.1. INSTALLATION
4.1.1. Givecarefulconsiderationtothepositionofunittoensureyouobtainmaximumbenetfromthelightingrange,andthatan
appropriate electrical power source can be provided.
4.1.2. Anapproximateappropriatemountingheightfromthegroundis2.5m.Seeg.1.
4.1.3. ThisLEDoodlightdevelopsminimalheatandisnotsubjecttothesamemountingrestrictionsthatapplytohalogenlampsthat
becometoohottotouch.Wedohoweverrecommendthattheoodlightshouldnotbeplacedincrampedorrestrictivepositions
andshouldbexedatthefollowingminimumdistancesbetweenthelightandanysurface/object.Seeg.2.
●500mmminimumbetweenthetopofthelightandanyoverheadsurface,orobjects,i.e.ceilings,overhangs.
●200mmbetweensidesoflightandwall/surfaces.
●2metresminimumbetweenthefrontofthelightandanyobjecttobeilluminated.
Fixthelighttoaverticalsurfacewithappropriatexings.
Ensurethelampisconnectedtothemainsbyaqualiedelectrician.
4.2. SENSOR
Thesensormaybeangledindependentlyofthelight.Mountedatapproximately2.5mabovethegroundthesensorwillhave
approx12mrange(g.1)witha120ºspread(g.3)
4.2.1. Thesensorrangecanbereducedoropticallyadaptedtolocalconditionsbyadjustingthesensorangleaccordingly.
4.2.2. Furtheradjustmentmaybemadebytuningthethreeswitcheslocatedontheundersideofthesensorasfollows:(g.3).
4.2.2.1. Switch SENS: Sensitivity. The sensor range will vary with temperature and factors such as passing cars, shade from large trees
etc.Duringcoldweatherthesensorrangewillbegreaterthanwhenhotinsummertemperatures.Forexampleduringhotweather
theforwarddetectionrangecouldfallfrom12to6mandthesensorshouldbecheckedandadjusted.Note:thesensitivityfactoris
greaterwhenanobjectpassesacrossdetectionarea(g.3A)thanwhenanobjectapproachestowardsthedetector(g.3B).
4.2.2.2. Switch TIME: Time adjuster:Toadjusttheamountoftimethelightwillstayonwhenactivated.
4.2.2.3. Switch LUX: Daylight adjustment:Toadjustthesensortocomeoninaccordancewiththediminishingdaylight.
5. MAINTENANCE
5.1. Cleanthecasingexternally(nottheglass)withamoistcloth.
8 DO NOT use solvents or abrasives to clean the light.
5.2. Avoid touching the glass shield as handling may reduce its serviceable life and cause the glass to crack. If necessary clean the
glass shield with alcohol and a soft cloth.
8 DO NOT use the light without the glass shield.
8 DO NOT use the light without the weather seals intact.
g.1
g.2
g.1
g.3
Model No: .....................................LED112PIR.V2 .....................LED113PIR.V2 ...................... LED115PIR.V2
Colour Temperature: ................................... 6500k ................................... 6500k .................................... 6500k
Dimensions(WxDxH): ........157x56x128mm ................ 195x57x178mm .................235x57x217mm
Energy Rating: ..................................................F ........................................... F ............................................F
IP Rating: .....................................................IP65 ......................................IP65 .......................................IP65
LED Type: ................................................... SMD .....................................SMD ......................................SMD
Lumen Output:..........................................1900lm ................................. 5200lm ............................... 10,000lm
PIR Motion Sensor: ........................................Yes .......................................Yes ........................................ Yes
Plug Type: ............................................Bare Wire .............................Bare Wire .............................. Bare Wire
Power Supply Cable Length: ..................... 0.75m ...................................0.75m ....................................0.75m
Power: ..........................................................20W ...................................... 50W .....................................100W
Supply: ........................................................ 230V .....................................230V ......................................230V
Original Language Version
© Jack Sealey Limited
LED112PIR.V2,LED113PIR.V2,LED115PIR.V2Issue3(2)30/05/23
