BALL JOINT SPLITTER - COMMERCIAL
MODEL NO: VS3812.V3
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
I
MPORTANT:
PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
Consult vehicle manufacturer’s handbook or a proprietary manual for guidance on securing and supporting vehicles being worked on.
WARNING! Ensure Health and Safety, local authority and general workshop practice regulations are adhered to when using tools.
DO NOT work under or around a vehicle until it is securely supported or held.
DO NOT use tools if damaged.
DO NOT use air tools to operate the force screw.
Maintain tool in good and clean condition for best and safest performance.
Wear approved eye protection. A full range of personal safety equipment is available from your Sealey stockist.
Wear suitable clothing to avoid snagging. DO NOT wear jewellery and tie back long hair.
IMPORTANT: The force screw must be kept well lubricated
2. INTRODUCTION
Chemically blackened forged steel body with thrust bolt. Suitable for commercial applications.
3. SPECIFICATION
Model No: ................................................... VS3812.V3
Jaw Opening Capacity: ........................................ 65mm
Jaw Width: ........................................................... 30mm
Overall Length: .................................................. 210mm
4. OPERATION
4.1. Position tool on joint.
4.2. Tighten thrust bolt using a spanner or ratchet to apply tension to the
vehicle’s joint.
4.3. Strike vehicle joint with a hammer to shock joint loose. Several strikes to the
joint may be necessary to loosen it suffi ciently to be disassembled.
NOTE: DO NOT strike the tool with a hammer or other heavy object.
4.4. A returned tool showing signs of abuse will be exempt from any Warranty claim.
VS3812.V3 Issue 2 (H,3,F) 10/08/23
Original Language Version
© Jack Sealey Limited
Refer to
instruction
manual
Wear protective
gloves
Wear eye
protection
Wear safety
footwear
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
