ENGINE OIL FUNNEL - BMW, MERCEDES,
TOYOTA/LEXUS
MODEL NO: VS7100
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Ensure Health and Safety, local authority and general workshop practice regulations are adhered to when using tools.
8 DO NOT use tools if damaged.
9 Maintain tools in a good, clean condition for best and safest performance.
9 Wear approved eye protection. A full range of personal safety equipment is available from your Sealey stockist.
9 Wear suitable clothing to avoid snagging. DO NOT wear jewellery and tie back long hair.
9 Keep children and unauthorised persons away from the work area.
9 When not in use, store in a secure, childproof location.
2. INTRODUCTION & APPLICATIONS
A completely new design of oil tunnel that fastens and seals into the engine filler. Hands free operation with no mess or spills.
FUNNEL WITH M37 X P3.0 THREADS
MAKE MODEL YEAR TYPE
Toyota 4Runner 2004-2019 4.0L - Gas
Toyota 4Runner 2009-2010 2.7L, 4.7L - Gas
Toyota Auris 2006-2012 1.4
Toyota Auris 2006-2012 2.0 D-4D
Toyota Auris 2006-2012 2.2 D
Toyota Auris 2012-2018 1.4 D-4D
Toyota Avalon 2005-2020 3.5L - Gas
Toyota Avalon 2013-2018 2.5L - Gas
Toyota Avensis 2003-2008 1.6, 1.8, 2.0 - Gas; 2.0D, 2.2D
Toyota Avensis 2008-2018 2.2 D-4D
Toyota Camry 2002-2010 2.4L - Gas
Toyota Camry 2007-2017 3.5L - Gas
Toyota Camry 2010-2020 2.5L - Gas
Toyota Celica 1999-2005 1.8 16V - Gas
Toyota C-HR 2018-2020 2.0L - Gas
Toyota Corolla 2000-2008 1.6, 1.8, 2.0 - Gas; 1.4D, 2.0D
Toyota Corolla 2003-2020 1.8L - Gas
Toyota Corolla 2009-2011 2.4L - Gas
Toyota Corolla iM 2017-2018 1.8L - Gas
Toyota Echo 2000-2005 1.5L - Gas
Toyota FJ Cruiser 2007-2014 4.0L - Gas
Toyota Hiace 1995-2020 2.7 - Gas; 2.5 D-4D
Refer to
instruction
manual
Wear eye
Protection
VS7100 Issue 2 (2) 07/09/23
Original Language Version
© Jack Sealey Limited
MAKE MODEL YEAR TYPE
Toyota Highlander 2001-2006 2.4L - Gas
Toyota Highlander 2009-2020 2.7L - Gas
Toyota Highlander 2011-2020 3.5L - Gas
Toyota IQ 2009-2015 1.4 D-4D
Toyota Land Cruiser 2008-2020 5.7L - Gas
Toyota Matrix 2003-2014 1.8L - Gas
Toyota Matrix 2009-2013 2.4L - Gas
Toyota MR2 Spyder 2002-2005 1.8L - Gas
Toyota Prius 1997-2009 1.5L - Gas/Hybrid
Toyota Prius 2010-2020 1.8L - Gas
Toyota Prius C 2010-2020 1.5L - Gas
Toyota Prius Plug-In 2012-2015 1.8L - Gas
Toyota Prius Prime 2017-2020 1.8L - Gas
Toyota Prius V 2012-2017 1.8L - Gas
Toyota RAV4 2005-2008 2.4L - Gas
Toyota RAV4 2005-2013 2.2 D
Toyota RAV4 2006-2012 3.5L - Gas
Toyota RAV4 2010-2018 2.5L - Gas
Toyota Sequoia 2010-2012 4.6L - Gas
Toyota Sequoia 2012-2020 5.7L - Gas
Toyota Sienna 2009-2020 3.5L - Gas
Toyota Sienna 2011-2012 2.7L - Gas
Toyota Solara 2002-2008 2.4L - Gas
Toyota Tacoma 2005-2015 4.0L - Gas
Toyota Tacoma 2009-2020 2.7L - Gas
Toyota Tacoma 2016-2020 3.5L - Gas
Toyota Tundra 2008-2016 4.0L - Gas
Toyota Tundra 2009-2020 5.7L - Gas
Toyota Tundra 2010-2019 4.6L - Gas
Toyota Venza 2009-2016 2.7L, 3.5L - Gas
Toyota Verso 2009-2018 2.0 D, 2.2 D
Toyota Yaris 2006-2011 1.5L - Gas
Toyota Yaris/Vitz 2010-2020 1.3 - Gas; 1.4 D-4D
FUNNEL WITH CLIP TYPE ADAPTER
MAKE MODEL YEAR TYPE
Audi A1 2010-2018 1.4 TFSI
Audi A3 2003-2012 1.4 TFSI, 1.6, 3.2 V6
Audi A3 2004-2013 2.0 TDI
Audi A4 2000-2004 1.8 - Gas; 1.9 TDI, 2.5 TDI
Audi A4 2002-2009 2.5 TDI
Audi A4 2004-2008 1.8 - Gas; 2.0 TDI
Audi A6 1997-2005 1.8 - Gas; 1.9 TDI, 2.5 TDI
VS7100 Issue 2 (2) 07/09/23
Original Language Version
© Jack Sealey Limited
MAKE MODEL YEAR TYPE
Audi A6 2004-2011 2.0 TDI
Audi A8 2002-2010 6.0 W12 quattro - Gas
Audi Q7 2006-2015 3.6 FSI quattro
Audi TT 1999-2006 1.8 - Gas
BMW 1 Series 2004-2012 116i, 118i, 120i, 130i; 118d, 120d
BMW 3 Series E46 1998-2007 323 Ci, 325 Ci, 330 Ci; 330 Cd
BMW 3 Series E90 2004-2011 316i, 320i, 325i; 318d, 320d, 330d,
335d
BMW 3 Series E92 2005-2013 320i, 330i; 325d, 330d, 335d
BMW 5 Series E60 2001-2010 523i, 540i, 550i; 520d, 525d
BMW 5 Series E61 2004-2010 525i, 530i, 545i; 530d
BMW 6 Series E63 2003-2010 630i, 645 Ci, 650i; 635d
BMW 7 Series E65 2001-2009 730i, 740i, 760i, Li; 730 Ld, 745d
BMW 8 Series E31 1990-1999 840i, 850 Ci
BMW X3 E83 2003-2011 2.0i, 2.5i; 18d, 20d, 30d
BMW X5 E53 2000-2006 3.0i, 4.4i, 4.8is; 3.0d
BMW X5 E70 2006-2013 XDrive 48i; xDrive 35d
BMW X6 E71, E72 2007-2014 XDrive 30d
BMW Z3 E36 1997-2003 2.8i, 3.0i
BMW Z3 Roadster E36 1995-2003 1.9i, 2.0i, 2.2i, 2.8i, 3.0i
BMW Z4 E86 2006-2008 3.0 Si
BMW Z4 Roadster E85 2002-2009 2.0i, 2.5i, 3.0i
BMW Z8 Roadster E52 2000-2003 4.9
Chrysler Crossre 2003-2008 3.2 - Gas
Chrysler PT Cruiser 2000-2010 2.2 CRD
Ford Galaxy 1995-2006 2.8 - Gas; 1.9 TDI
Jeep Grand Cherokee 1998-2005 2.7 CRD 4x4
Mercedes-Benz A-Class W168 1997-2004 A 160 CDi, A 170 CDi
Mercedes-Benz A-Class W169 2004-2012 A 160 CDi, A 180 CDi, A 200 CDi
Mercedes-Benz B-Class W245 2005-2011 B 180 CDi, B 200 CDi
Mercedes-Benz C-Class CL203 2001-2008 C 160, 180, 200, 230; C 30 CDi AMG
Mercedes-Benz C-Class W202 1993-2000 C 180, 200, 220; C 200 CDi
Mercedes-Benz C-Class W203 2000-2007 C 180, 200, 240, 280, 320; C 220, 270
CDi
Mercedes-Benz C-Class W204 2007-2014 C 230, 250, 280, 300, 350 - Gas; C 320
CDi
Mercedes-Benz CLK C208 1997-2002 CLK 200, CLK 230
Mercedes-Benz CLS C219 2004-2010 CLS 350, CLS 500
Mercedes-Benz E-Class W211 2007-2008 E 230, 320, 350, 500; E 280 CDI, E 320
CDI
Mercedes-Benz G-Class W463 2006-2020 G 320, 500; G 400 CDI
Mercedes-Benz M-Class W163 2001-2005 ML 230, 430, 500; ML 400 CDI
Mercedes-Benz R-Class W251 2006-2012 R 350, 500; 280 CDI, 300 CDI
Mercedes-Benz S-Class W220 1998-2005 S 280, 350, 430, 500; S 320 CDI, 400
CDI
VS7100 Issue 2 (2) 07/09/23
Original Language Version
© Jack Sealey Limited
4. INSTRUCTIONS
Locate and remove oil ller cap (if unsure, consult vechicle handbook for location) and lock VS7100 funnel in place using the bayonet xing
previously occupied by the ller cap.
MAKE MODEL YEAR TYPE
Volvo 850 1992-1997 2.5 TDI
Volvo S70 1996-2000 2.5 TDI
Volvo S80 1998-2006 2.5 TDI
Volvo V70 1999-2008 2.5 TDI
VS7100
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts
without prior notice.
IMPORTANT: No Liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any uids (if applicable) into approved
containers and dispose of the product and uids according to local regulations.
