Prepare the door and check dimensions
If drilling a new door, use the supplied template and the complete
door drilling instructions available at kwikset.com/doorprep
13/8" –2"
35 – 51 mm
1"
25 mm
23/8" or 23/4"
60 or 70 mm
backset
Measure to conirm that the backset is
either 23/8" or 23/4" (60 or 70 mm).
Measure to conirm that the hole
in the door edge is 1" (25 mm).
Measure to conirm the door is between
13/8" and 2" (35 mm and 51 mm) thick.
Remove your existing
deadbolt from your door.
C D E F
B
Measure to conirm that the hole in the door
is either 21/8" (54 mm) or 11/2" (38 mm).
or
21/8"
54 mm
11/2"
38 mm
Note: Additional door
preparation may be
required for doors with
11/2" (38 mm) holes.
Consult the deadbolt
drilling instructions at
kwikset.com/doorprep
A
Make sure your door is compatible. If you have a standard deadbolt mounted
separately from the handle below it, your door is compatible.
Mortise
Lock
Not CompatibleCompatible Not Compatible
Integrated
Interior
Not Compatible
Rim
Lock
K L N
A
Is the door edge chiseled?
actual
size
A B
YES NO
Use latch “A”. If the
latch bolt is not already
extended, extend the
latch bolt as shown.
Use latch “B” (not
included). If the latch
bolt is not already
extended, extend the
latch bolt as shown.
or
chiseled
not
chiseled
K or L
(x2)
A
B
D
Which latch are you installing?
wood
block
Latch “A” Latch “B”
N (x2)
C
M (x2
Longer screws
install closest to
the door jamb.
door frame
E
Install strike on the door frame.
Make sure the hole in the door frame is drilled a
minimum of 1" (25 mm) deep.
or
Install the latch and strike
Latch
“B” is not included. If needed,
please contact Kwikset to order
a drive-in latch for your lock.
Strike
C
A
B
Exterior Touchscreen
Adapter
Ring
D
Mounting
Plate
Parts in the box
Fasteners
03809 46780
K
M
N
L
64109
U
49191
T
F
E
64843
64845
Q
S
64844
R
M
A
B
A
B
B
C
Is the D-shaped hole centered in the door hole?
Hold the latch in front of the door hole, with the latch
face lush against the door edge.
YES NO
No adjustment is required.
Proceed to next step.
D-shaped hole D-shaped hole
Rotate latch face as
shown to extend latch.
or
(1-3/8" • 35 mm)
(2" • 51 mm)
(1-3/4" • 44 mm)
Batteries
Interior Assembly
G
H
J
V
Required tools
Ruler
Hammer Wood block
Phillips head screwdriver
Additional Tools (depending on application)
Begin with your smart home app
If you will be using a smart home app with your lock, download the app and set
up your controller or hub before proceeding further with lock installation.
1
2
3
1 / 4
ENGLISH
69790001
Rev 01
954
ZigBee
Installation and User Guide
Kwikset
Technical Support
1-866-863-6584
www.kwikset.com
