RECHARGEABLE TYRE INFLATOR &

TEMPORARY PUNCTURE REPAIR KIT

MODEL NO: MAC24

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,

and properly maintained, give you years of trouble free performance.

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE

THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR

PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.

1. SAFETY

9  Stopsomewheresafelyawayfromothertra󰀩c.Trytoavoidcausinganobstructiontoothers.

9  Makesureyourhandbrakeisonandthecarignitioniso󰀨.

9  Turnonthevehicleshazardlights.

9  Ensureyouarevisibletootherroaduserswhilstusingtheequipment.

9  Ifavailable,wearahigh-visvestandsetupawarningtriangle.

9 Keep the wholekitcleanandingoodcondition.

9  Replaceorrepairdamagedparts.Userecommendedpartsonly.Unauthorisedpartsmaybedangerousandwillinvalidatethe

 warranty.

9  Keepchildrenandnon-essentialpersonsawayfromtheworkarea.

 WARNING! Thiscompressoriscapableofproducingahighpressure.

8 DO NOTinflateanyitembeyondit’smaximumspecifiedpressure.

8 DO NOTusenearflammablesolids,liquidsorgases.

8 DO NOTdirectinflationhoseconnectorheadatyourself,othersoranimals.

8 DO NOTleavethecompressoroperatingunattended.Alwaysmonitoritandtheinflationpressure.

8 DO NOTcarrybythehose,oryankthehosefromaninflationvalve.

8 DO NOTpulltheplugfromtheaccessorysocketusingthelead.

8 DO NOTgetthecompressorwetoruseintherain.

8 DO NOTusethecompressorforataskthatitisnotdesignedfor.

8 DO NOToperatethecompressorwhenyouaretiredorundertheinfluenceofalcohol,drugsorintoxicatingmedication.

8 DO NOT operatethecompressorifanypartsaremissingorthecompressorisdamagedasthismaycausefailureand/orpersonal

 injury.

8 DO NOTwashtheproductwithwater.

8 DO NOTopentheunit.

8  Thereisabuilt-inlithiumbatteryinsidetheproduct.DO NOTplacetheproductinfireordumpthebattery.

 WARNING!:Thisproductisnotatoyandshouldnotbeusedbychildren.Usersshouldbeabove16yearsold.Keepasafedistance

 betweenchildrenandtheinflatorwhileinflating.

 WARNING:! Theproducthasabuilt-inDCmotorwhichmaygeneratesparksduringoperation. DO NOTuseitinanenvironmentwith

 dustorgasthatisliabletoexplode.

 WARNING:!Overheating,damage,orwatermayincreasetheriskoffireorexplosion.Keeptheproductawayfromheatsources,andnot

 leaveitforprolongedperiodsinahotcar.Iftheinflatorbecomesveryhot,thereisachanceitcouldexplode.

 WARNING:!Pleaseusetheproductinadryendcleanenvironment.Theintrusionorsandanddustmaycausedamagetotheproduct.

 WARNING! DO NOThandlepuncturerepairstripswithoutusingsuitableprotectivegloves.

 WARNING:!Afterrunningforalongtime,thetemperatureofthejunctionbetweentheairtubeandthemainbodycanbecomevery

 high.Toavoidburns,avoidtouchingit.

 WARNING:!Theinatorisequippedwithshortcircuitprotection.DO NOTtrytoconnectthewrongtypeofcabletotheUSB-Cport.

9  Pleasestoretheproductintemperaturerangingfrom-10

Cto45

C.Extremelyhotorcoldenvironmentsmaydamagethebatteryand

 shortenthelifetimeoftheinflator.

9  Long-limestorageoftheproductmaydecreasetheeffectivenessofthebattery.Chargetheinflatoralleastonceeverythreemonthsto

 maintainitsperformance.

  Ifthereisanunusualnoiseortheunitstemperaturebecomesveryhighduringinflating,tumofftheinflatorimmediately.

8  Beforesettingtheinflationpressurevalue,makesurethepressureunitiscorrectlyselected.Mixinguppsiandbarcouldleadto 

 dangerousoverinflation.NOTE:Unitconversion:1bar=14.5psi,1bar=100kPa.

9  Pleaseuseacertified5V/2Aadapterandtheincludedchargingcabletochargethisproduct.TheUSBcablemustnotbereplacedwith

 anyothertypeofplugorelectricalsupply.

2. INTRODUCTION

Idealforrepairingpuncturesontubelesstyresoncars,commercial,agriculturalando󰀨-roadvehiclesinsituwithoutremovingthetyresfromthe

wheel.Rechargeabledigitaltyreinatorwithanoutputof8L/min.Withvepresetmodes,car,bike,motorcycle,sportsballandmanual.Theunit

willstopautomaticallyoncethepressureisreached.Built-in0.5WSMDLEDlightwithanoutputof50lumensforeaseofuseatnightwithSOS

signalandstrobemode.Temporaryuseonly,nottobeusedasapermanentrepairforroadvehicles.

Refer to

instruction

manual

Wearaface

shield

Wearprotective

clothing

Wearprotective

gloves

Keepoutof

rain

Original Language Version

©JackSealeyLimited

MAC24Issue:103/09/24

Original Language Version

©JackSealeyLimited

3. SPECIFICATION

ModelNo.:................................................................. MAC24

Inator Spec:

Battery:...................................................................2600mAh

ChargingTime:...........................................................2Hours

Input:........................................................................... USB-C

MaxAmps:.......................................................................10A

MaxPower:.....................................................................85W

NettWeight:................................................................ 1.05kg

OperatingTemperature:................................. -10

Cto+60

PressureUnits:.................................................. psi,bar,kPa

Range:..................................................................... 0-120psi

4. CONTENTS

150mmextensiontubewithaSchraderconnection

Tyrevalveservicetool

Valvecores

Sportsballpinadaptor

Balloon/inatablesadaptor

Prestavalveadaptorforbicycletyres

Rasp

Insertionneedle

Repairstrips(x15)

Pliers

Siliconlube

USBCchargingcable

Storagecase

5. OPERATION

5.1. PUNCTURE REPAIR

 WARNING! Ifthepuncturepointinthetyreisnotwithin3/4widthofthetyretread,DO NOTattemptarepair.

5.1.1. Removeobject(causingpuncture)fromtyreifrequired.

5.1.2. Coattheraspwiththinlmofsiliconlubricantandclean/widenpunctureholebyinsertingandrotatingtherasp. 

5.1.3. Fitrepairstripintoinsertionneedleslotwith50%protrudingfromeachside.

5.1.4. Usingtheinsertionneedle,pushthestripmostofthewaythroughthetyrewiththeinsertionneedle,leave13mmofthestripsticking

 out.

5.1.5. Asyoupulltheinsertionneedlebackout,useyourotherhandtopushdowntheinsertiontoolcollaragainstthetyreleavingtherepair

 stripinplace.

5.1.6. Therepairstripendsprotrudingfromtyrewillneedtobecuto󰀨.

5.1.7. Wipecleanitemsinthekit.Storekitinasafe,childprooflocation.

5.1.8. Allow30minutesminimumforgluestriptosetbeforeinatingthetyre.

5.2. OPERATING INFLATOR

Batterylevel

PressureUnit

Mode

Pressure

Valuedetection

g.1

Figure2Key

ItemNo. Description

1 Powerbutton

2 Modebutton

3 Minusbutton

4 Lightbutton

5 Plusbutton

g.2

MAC24Issue:103/09/24

5.2.1. Fullychargetheinatorwithasuitable5V/2AUSBpoweradapterbeforerstuseandasnecessarywhenrequired.

5.2.2. Tochargetheinator,connecttheUSB-Ccabletotheunit(g.3.3).ThebatterylevelstateisindicatedbytheLEDs(g.1).

 1litbarindicateschargeisunder25%andfourlitbarsindicate100%.

NOTE: Whenthebatteryisfullycharged,itstotalbatterylifewillbearound30minutesat25°Cambienttemperatureandwithoutanypressure

 load.

NOTE: Batterylifeandperformancewilldeclineastheambienttemperaturefallsorthepressureloadclimbs.

NOTE: Defaultmodesalloperatewithunitssettopsi.

NOTE: Eachmodehasadefaultunit.PressandholdtheModeButtonfor3secondstoswitchthecurrentunitbetweenthe3unit 

 options(bar,psi,andkPa).

NOTE: Thememoryfunctionenablestheinatortostorethemode,unit,andpressurevalueandautomaticallyretrievethemafterstart-up.

5.2.3. PressureValueDetection:Thenumbericonindicatesthepressurevalue.

5.2.4. Whenthenumbericonashes,itindicatesthepresetpressurevalue.

5.2.5. Whenthenumbericonisconstantlyon,itindicatesthecurrentlydetectedtyrepressurevalue.

5.3. BUTTON FUNCTION

 PressandholdthePowerButtontoturnontheinator.

 ShortpressthePowerButtontostartinating.

 Inthepower-onstate,pressandholdthePowerButtontoturno󰀨theinator.

 Afterthemodeisset,pressthePlusButtontoincreasethepresetpressurevalue.

 Afterthemodeisset,presstheMinusButtontodecreasethepresetpressurevalue.

 PressthelightButtontoswitchbetweenllluminator,SOSSignal,andStrobe.

 ShortpresstheModeButtontoswitchmodes.

 Selectthecorrectpressurevaluebeforeinating.

 PressandholdtheModeButtontoswitchtheunitbetweenkPa,psi,andbar.

 PressandholdtheModeandPlusbuttonstogetherfor3secondstoresetthesystem.

5.3.1. Connecttheairtubeontotheinator’sairoutletbyrotatingclockwise.

5.3.2. Chooseanadapteraccordingtotheitemtobeinated.

5.4. MODES

5.4.1. AvailablemodesareBicycle,Car,Motorcycle,BallandManual.Alldefaulttopsiunits.

 Bicycleicon(bicyclemode).Presetpressure:45psi.Adjustablerange:30to150psi.

 Motorcycleicon(motorcyclemode).Presetpressure:35psi.Adjustablerange:26to43psi.

 Caricon(carmode).Presetpressure:36psi.Adjustablerange:26to50psi.

 Ballicon(ballmode).Presetpressure:8psi.Adjustablerange:4to16psi.

 Noicon(manualmode).Presetpressure:35psi.Adjustablerange:3to150psi.

 WARNING!:Itemssuchasballoons,toyballs,andswimmingringscannotbeinatedusingapresetpressurevaluebecauseoftheir

 lowinationpressure.Becarefulwheninatingtheseitemsasitiseasytoover-inatethem,causingthemtoburst.

5.4.2. Whenpoweredon,thenumberonthedisplayisthecurrentpressurevalueoftheitemconnectedtotheinftator.

5.4.3. Pleasechecktheinationpressurerangeoftheobjectbeinginatedonthemodestable(section5.4).Over-inationcouldcause

 explosionandpersonalinjury.

5.4.4. Fortyres,thesafepressurelimitdependontheweightofthecar.Pleaserefertotheinstructionsforthetyresthemselves.

5.4.5. Beforeinating,pleasedoublecheckthemaximumpressuremarkedonthetyre.

5.4.6. Themaximumpressureforfootballs,rugbyballsetc.istypicallymarkedattheairvalvelocation.

g.3

Figure3Key

ItemNo. Description

1 Airoutlet

2 LEDLight

3 USB-CPort

Original Language Version

MAC24Issue:103/09/24

Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR

01284 757500 sales@sealey.co.uk www.sealey.co.uk

ENVIRONMENT PROTECTION

Recycleunwantedmaterialsinsteadofdisposingofthemaswaste.Alltools,accessoriesandpackagingshouldbesorted,takento

arecyclingcentreanddisposedofinamannerwhichiscompatiblewiththeenvironment.Whentheproductbecomescompletely

unserviceableandrequiresdisposal,drainanyfluids(ifapplicable)intoapprovedcontainersanddisposeoftheproductandfluids

accordingtolocalregulations.

Note:Itisourpolicytocontinuallyimproveproductsandassuchwereservetherighttoalterdata,specificationsandcomponentparts

withoutpriornotice.

Important:NoLiabilityisacceptedforincorrectuseofthisproduct.

Warranty:Guaranteeis12monthsfrompurchasedate,proofofwhichisrequiredforanyclaim.

WEEE REGULATIONS

DisposeofthisproductattheendofitsworkinglifeincompliancewiththeEUDirectiveonWasteElectricalandElectronicEquipment

(WEEE).Whentheproductisnolongerrequired,itmustbedisposedofinanenvironmentallyprotectiveway.Contactyourlocalsolid

wasteauthorityforrecyclinginformation.

Original Language Version

PURCHASE HERE

Problem Cause Solution

Slowination Lowbattery.

Airleakage.

Fullyrechargeandtryagain.

Checkjoints.

Inationfailure Lowbattery.

Pressurevaluehigherthanpreset.

Fullyrechargeandtryagain.

Setinatortoapplicablemode.

Unchangeablepresetpressure

value

Valuesethasreachedlimitformodeset. Changemodeandretry.

Pressurevaluereads“Zero” Pressurevalueofballoons,toyballsetc.could

belowerthandetectablerange.

Batterylevelindicatornot

lightingupwhencharging.

Improperadaptororcable. Replaceadaptorandrechargewithoriginalchargingcable.

MAC24Issue:103/09/24

5.5. INFLATING

5.5.1. Pleasestoretheproductintemperaturerangingfrom-10

Cto45

C.Extremelyhotorcoldenvironmentsmaydamagethebatteryand

 shortenthelifetimeoftheinator.

5.5.2. Longtermstorageoftheproductmaydecreasethee󰀨ectivenessofthebattery.Chargetheinatoralleastonceeverythreemonths

 tomaintainitsperformance.

5.5.3. Theproducthasabuilt-inDCmotorwhichmaygeneratesparksduringoperation.DO NOTuseitinanenvironmentwithdustorgas

 thatisliabletoexplode.

5.5.4. Ifthereisanunusualnoiseorthetemperaturebecomesveryhighduringinating,pleasetumo󰀨theinatorimmediately.

5.5.5. Beforesettingtheinationpressurevalue,makesurethepressureunitiscorrectlyselected.Mixinguppsiandbarcouldleadto 

 dangerousover-ination.

5.5.6. Unitconversion:1bar=14.5psi,1bar=100kPa

5.5.7. DO NOTleavetheinatorunattendedwhileitisinoperation.

5.5.8. Pleaseusetheproductinadryandcleanenvironment.Theintrusionofsandanddustmaycausedamagetotheproduct.Don’twash

 theproductwithwater.

5.5.9. Pleaseuseacertied5V/2Aadapterandtheincludedchargingcabletochargethisproduct.

 WARNING!:Afterrunningforalongtimethejunctionbetweentheairtubeandthemainbodycanbecomeveryhot.Toavoidburns

 allowittocoolbeforetouching.

NOTE: Theinatorisequippedwithshortcircuitprotection.DO NOTattempttoconnectthewrongtypeofcabletotheUSB-Cport.
