ROTATING FLASHING WARNING BEACON WITH

12MM BOLT FIXING SMD LED 12V/24V

MODEL NO: WB45LED, WB45LEDG

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these

instructions, and properly maintained, give you years of trouble free performance.

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE

THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR

PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.

1. SAFETY

9  Familiariseyourselfwiththisproduct’sapplicationandlimitations,aswellasanyspecicpotentialhazardspeculiartothebeacon.

9  Replaceorrepairdamagedparts.Userecommendedpartsonly.Nonauthorisedpartsmaybedangerousandwillinvalidatethe 

 warranty.

8 DO NOTusethebeaconforanypurposeotherthanforwhichitisdesigned.

8 DO NOTallowchildrentooperatethebeacon.

8 DO NOToperatethebeaconifanypartsaremissingordamagedasthismaycausefailureorpossiblepersonalinjury.

9  Whennotinuseswitchthebeaconoffandwhereappropriateremoveplugfrompowersupply.

9  Thisbeaconisintendedtobeusedonlyin12Vor24VDCsystems.

9  Thebeaconsaremeanttobeusedasawarningsignal.Applicationse.g.Trucks,excavators,agriculturalmachinesandtractorsetc.

8 DO NOTlookstraightintothelight.Thebrightlightmaycauseaseriouseyedamage.

9  Makesurethatthebeaconisproperlyinstalledbeforedrivingthevehicle.

9  Followthecountry-specicregulationswheninstallingthewarninglightsontheroofofthevehicle.

2. INTRODUCTION

 Fittedwith45x0.5WhighpowerSMDLEDswhichmakethebeaconhighlyvisible.BeaconisIP65rated,suitableforuseinall 

 weatherconditions,inadditiontoit’swideoperatingtemperaturerangeof-30°Cto50°C.12mmBoltxingforeasyinstallationon

 awiderangeofvehicles.LightpatterncanswitchbetweenRotating,SingleFlashandDoubleFlash.CertiedtoECER65andECE

 R10regulations.

3. SPECIFICATION

4. FIXING INSTRUCTIONS

4.1. SINGLE BOLT FIXING

4.1.1. Drilla12mmmountingholeinasuitablepointonthevehicle.

4.1.2. Connecttocablesofatleast2mm²sectionandusean8Afuse;checkpolarities.

4.1.3. Fixthebeaconbyusingnutsandwashersaccordingtothetypeandshapeofthemountingsurface

4.2. BOLT FIXING BASE

4.2.1. Drillmountinghole12mm.Alsomakeprovisiontoroutecablesintothevehicle.

4.2.2. Connecttocablesofatleast2mm²sectionandusean8Afuse;checkpolarities.

4.2.3. Fixthebeaconwith1x19mmnutwithspringwasherandatwasher.

WB45LEDWB45LEDGIssue122/10/24

Original Language Version

©JackSealeyLimited

Refer to

instructions

Model No WB45LED WB45LEDG

Lens colour Amber Green

Nett Weight 0.25kg

Voltage 12/24V

IPRating IP65

Functions

1 SingleFlashing(R65)

2 Doubleashing(R65)

3 Rotating

5. OPERATION

 WARNING! DO NOT lookdirectlyintotheLEDwhilstinoperation.Asthiscancausemomentaryblindnessand/oreyedamage.

DO NOTtouchlightuntilithascooled.

6. VOLTAGE SELECTION

6.1.  Thebeaconswillswitchbetween12Vand24Vautomatically.

Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR

01284 757500 sales@sealey.co.uk www.sealey.co.uk

ENVIRONMENT PROTECTION

Recycleunwantedmaterialsinsteadofdisposingofthemaswaste.Alltools,accessoriesandpackagingshouldbesorted,

takentoarecyclingcentreanddisposedofinamannerwhichiscompatiblewiththeenvironment.Whentheproduct

becomescompletelyunserviceableandrequiresdisposal,drainanyfluids(ifapplicable)intoapprovedcontainersand

disposeoftheproductandfluidsaccordingtolocalregulations.

WEEE REGULATIONS

DisposeofthisproductattheendofitsworkinglifeincompliancewiththeEUDirectiveonWasteElectricalandElectronicEquipment

(WEEE).Whentheproductisnolongerrequired,itmustbedisposedofinanenvironmentallyprotectiveway.Contactyourlocalsolid

wasteauthorityforrecyclinginformation.

Note:Itisourpolicytocontinuallyimproveproductsandassuchwereservetherighttoalterdata,specificationsandcomponentpartswithoutprior

notice.

Important:NoLiabilityisacceptedforincorrectuseofthisproduct.

Warranty:Guaranteeis12monthsfrompurchasedate,proofofwhichisrequiredforanyclaim.

WB45LEDWB45LEDGIssue122/10/24
