12V/24V LED WARNING BEACON-

VARIOUS FITTINGS

MODEL NO: WB951LED.V2, WB952LED.V2,

WB954LED.V2, WB955LED.V2

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these

instructions, and properly maintained, give you years of trouble free performance.

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE

THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR

PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.

1. SAFETY

9  Familiariseyourselfwiththisproduct’sapplicationandlimitations,aswellasanyspecicpotentialhazardspeculiartothebeacon.

9  Replaceorrepairdamagedparts.Use recommended parts only. Non authorised parts may be dangerous and will invalidate the

warranty.

8 DO NOTusethebeaconforanypurposeotherthanforwhichitisdesigned.

8 DO NOTallowchildrentooperatethebeacon.

8 DO NOToperatethebeaconifanypartsaremissingordamagedasthismaycausefailureorpossiblepersonalinjury.

9  Whennotinuseswitchthebeaconoffandwhereappropriateremoveplugfrompowersupply.

2. INTRODUCTION

3-FunctioncontrolallowsfordifferentLEDashcongurations.Heavy-dutyABSbase.Quickrelease,UVstabiliseddomewillnot

 fadeifexposedtoprolongedsunlight.

WB951LED.V2 - Singlepointmountingbeaconsuitablefordirectmountingtovehicleroofusing12mmbolt.

WB952LED.V2-Directmountingbeaconpre-drilledwith3x6.5mmholes.

WB954LED.V2-Fittedwithsixpowerfulmagnets,strongenoughtocopewithnormalroadspeeds.Suppliedwith3mcoiledexand

  universalvehicleaccessorysocketplug.

WB955LED.V2 - FlexibleDINelementsuitableforagriculturalvehicleswherestandardbeaconsmaybebroken.

3. SPECIFICATION

MODEL No’s: WB951LED.V2,WB952LED.V2,WB954LED.V2,WB955LED.V2

Voltage:............................................................12V/24V(DC)

LightSource................................................SMD2835,45pcs

Max.Current....................................................... 1.6A@12V

Max.Current........................................................ 0.8A@24V

WorkingTemperature...........................................-30/+50

EMC........................................................... E910R0516099

R65...............................................................TA1E9006105

Waterproof......................................................................IP56

4. FIXING INSTRUCTIONS

4.1. WB951LED.V2: 12mmSingleBoltFixing

4.1.1. Drilla13mmmountingholeinasuitablepointonthevehicle.

4.1.2. Connecttocablesofatleast2mm²sectionandusean8Afuse;checkpolarities.

4.1.3. Fixthebeaconbyusingnutsandwashersaccordingtothetypeandshapeofthemountingsurface

WB951LED.V2,WB952LED.V2,WB954LED.V2,WB955LED.V2Issue114/12/20

Original Language Version

©JackSealeyLimited

Refer to

instructions

WB951LED.V2

WB952LED.V2

WB954LED.V2

WB955LED.V2

4.2. WB952LED.V2:ThreeBoltFixingBase

4.2.1. Drillmountingholesusingthebeaconbaseasatemplate.Alsomakeprovisiontoroutecablesintothevehicle.

4.2.2. Connecttocablesofatleast2mm²sectionandusean8Afuse;checkpolarities.

4.2.3. Fixthebeaconwith3xM6screws.

4.3. WB954LED.V2:MagneticBase

4.3.1. Fittedwithhighpowermagnetstrongenoughtocopewithnormalroadspeeds.

4.3.2. Suppliedwith3mcoiledexanduniversalauxiliarypoweroutletplug.

4.3.3. Thebeaconmustbeplacedonasurfaceparalleltotheground.

4.3.4. Thesurfaceshouldbeatandcleantoensuregoodadherence.

4.4. WB955LED.V2:FlexibleBasewithDINSpigotMounting.

4.4.1. Fitasuitableadaptersocketontothevehicle.Makesureitisperfectlyvertical.

4.4.2. Usecablesofatleast2mm²sectionandusean8Afuse;checkpolarities.

4.4.3. Pushthebeaconspigotdownfullyontotheadaptersocketandsecurebytighteningthewingnut.

4.4.4. Whenthebeaconisremoved,alwaysclosetheadaptersocketoutletusingtherubbercap.

5. FLASH PATTERN SELECTION

5.1.  Threeashpatternsareavailableforselectionusingbuttononthetopoftheunitasing.2.Thebuttonisaccessedbyremoving

 thedomeasing.1.

5.2.  Pattern1:Rotatingash;ashrotatesmimickingarotarybeacon.

 Pattern2:Rapidashes.

 Pattern3:Threerapidashesfollowedbyabreak.

NOTE:Whenswitchedontheunitwilldisplayasthelastpatternsetting.

6. VOLTAGE SELECTION

6.1. Thebeaconswillswitchbetween12Vand24Vautomatically.

Original Language Version

Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR

01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk

ENVIRONMENT PROTECTION

Recycleunwantedmaterialsinsteadofdisposingofthemaswaste.Alltools,accessoriesandpackagingshouldbesorted,takento

arecyclingcentreanddisposedofinamannerwhichiscompatiblewiththeenvironment.Whentheproductbecomescompletely

unserviceableandrequiresdisposal,drainanyfluids(ifapplicable)intoapprovedcontainersanddisposeoftheproductandfluids

accordingtolocalregulations.

WEEE REGULATIONS

DisposeofthisproductattheendofitsworkinglifeincompliancewiththeEUDirectiveonWasteElectricalandElectronicEquipment

(WEEE).Whentheproductisnolongerrequired,itmustbedisposedofinanenvironmentallyprotectiveway.Contactyourlocalsolid

wasteauthorityforrecyclinginformation.

Note:Itisourpolicytocontinuallyimproveproductsandassuchwereservetherighttoalterdata,specificationsandcomponentpartswithoutprior

notice.Pleasenotethatotherversionsofthisproductareavailable.Ifyourequiredocumentationforalternativeversions,pleaseemailorcall

ourtechnicalteamontechnical@sealey.co.ukor01284757505.

Important:NoLiabilityisacceptedforincorrectuseofthisproduct.

Warranty:Guaranteeis12monthsfrompurchasedate,proofofwhichisrequiredforanyclaim.

g.1

WB951LED.V2,WB952LED.V2,WB954LED.V2,WB955LED.V2Issue114/12/20

Pattern

Selector

g.2
