TYRE INFLATOR WITH WORKLIGHT 12V
MODEL NO: MAC11
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
1. SAFETY
9 Read the manual before using this product. Thoroughly understand operating procedures, safety warnings and maintenance
requirements. Keep the manual in a convenient place for all users to see and use. Keep labels as per original.
9 The inator only operates with a 12V electrical system.
9 Consult your vehicle’s manual or a qualied mechanic for proper connection procedure.
9 After 30 minutes of continuous operation, allow the inator to cool before restarting.
9 Damage can occur from continued overuse.
9 The inator was permanently lubricated during assembly. DO NOT add oil or any other lubricant.
9 The inator will become HOT after using for a long period of time. When used for a long period of time, the compressed air hose and
device may become noticeably warm.
9 Please use caution when touching the inator in order to avoid burns. Allow the inater to cool down suciently before storing.
9 Only inate tyres to the manufacturer’s recommended pressure. DO NOT over inate as serious injury could occur.
9 Keep the inator away from small children.
9 Clean with a damp cloth only. DO NOT use chemicals or soap.
8 DO NOT use the inator for pumping any gas or liquid other than air.
9 The inator is not designed for use as a source for breathable air.
9 The inator is designed for use with car tyres. It is not designed for use with large tyres like tractor or truck tyres.
8 DO NOT use (or modify) the inator for any other purpose than that for which it was designed.
9 Use extra caution when inating small objects like bicycle tyres or sports balls.
9 The warnings, precautions, and instructions discussed in this instruction manual cannot cover all possible conditions and situations that
may occur. It must be understood by the operator that common sense and caution are applied when using this product.
9 Failure to heed these warnings may result in fatal personal injury and/or property damage.
2. INTRODUCTION
Suitable for inflating tyres on cars, vans, 4x4s, motorcycles and bicycles. Maximum pressure 120psi. Pressure units in psi, kPa, kg/cm²
and bar. Airflow 0.78cfm 22L/min with an inflation time 0-30psi in 263sec (175/70/R13). Analogue gauge with an LED worklight. Runtime:
30mins. Supplied with a 3m 12V plug, ball spike and inflatable adaptor.
3. SPECIFICATION
MODEL NO: MAC11
Hose Length 360mm
Maximum Current 10A
Maximum Pressure 120psi
Nett Weight 0.5kg
Operating Voltage 12V
Power Cord Length 3m
Typical Ination Time 0-30psi in 263sec (175/70/R13).
4. CONTENTS
MAC11 Issue 1 12/12/24
Original Language Version
© Jack Sealey Limited
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS,
WARNINGS & CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT
IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE
WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
5. OPERATION
IMPORTANT: ensure you have read and understand all safety instructions before operating the device.
STEP.4 STEP.5 STEP.6
5. Your current tire pressure will be displayed.
Adjust the ination psi with the “+” or “-”
buttons.
6. Press the power button to start inating. The
mini compressor will commence operation and
auto-stop at the preset pressure.
NOTE: If unit does not come on check the fuse
in the 12V plug. Replace if blown.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts without prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any uids (if applicable) into approved
containers and dispose of the product and uids according to local regulations.
REGISTER YOUR
PURCHASE HERE
Original Language Version
© Jack Sealey Limited
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
MAC11 Issue 1 12/12/24
STEP.1 STEP.2
1. Check the door jamb or fuel door for correct
tyre pressure. Alternatively check the vehicle’s
manual.
2. Connect the power cord to the 12V DC
power port on the vehicle. Place the unit on a
dry level surface. The built in LED work light
will immediately illuminate once connected to
power.
3 Connect the air hose to the tyre valve stem.
Ensure the connector is secure.
STEP.3
4. Press the power button to start inating. The
mini compressor will commence operation.
Press the power button to stop the unit once
desired pressure is reached.
NOTE: If unit does not come on check the fuse
in the 12V plug. Replace if blown.
STEP.4
