12V/230V AC TYRE INFLATOR & HIGH VOLUME
PUMP, AIR COMPRESSOR, 120PSI, DUAL POWER,
LED WORKLIGHT
MODEL NO’S: MAC13D
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. ELECTRICAL SAFETY
WARNING! It is the user’s responsibility to check the following:
9 Check all electrical equipment and appliances to ensure that they are safe before using. Inspect power supply leads, plugs and all
electrical connections for wear and damage. Sealey recommend that an RCD (Residual Current Device) is used with all electrical
products.
9 Electrical safety information. It is important that the following information is read and understood:
9 Ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply.
9 Regularly inspect power supply cables and plugs for wear or damage and check all connections to ensure that they are secure.
IMPORTANT: Ensure that the voltage rating on the appliance suits the power supply to be used and that the plug is tted with the
correct fuse.
8 DO NOT pull or carry the appliance by the power cable.
8 DO NOT pull the plug from the socket by the cable.
8 DO NOT use worn or damaged cables, plugs or connectors. Ensure that any faulty item is repaired or is replaced immediately by a
qualied electrician.
9 If the cable or plug is damaged during use, switch o the electricity supply and remove from use.
9 Ensure that repairs are carried out by a qualied electrician.
1.2. POWER CORDS
1.2.1. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualied persons in order to avoid
a hazard.
WARNING! Read instructions before use.
WARNING! This compressor is capable of producing a high pressure. DO NOT inate any item beyond its maximum capacity.
WARNING! This device may be used by aged 8 years and older, and by persons with reduced physical, sensory or mental capacities,
or a lack of experience and knowledge, if they are supervised or have been instructed in how to use the device safely and understand
the dangers that may arise when using it.
WARNING! The user is responsible for any damage or injury to third parties that was caused by the use of the device.
WARNING! During operation, never point the device at yourself or other individuals, and keep the device well way from your ears and
eyes.
WARNING! Children shall NOT play with the appliance.
WARNING! Cleaning and user maintenance on the appliance shall not be made by children without supervision.
9 Children from age 8 years and above, persons with reduced physical, sensory, or mental capabilities those with lack of experience and
knowledge can use the appliance, if they have been given supervision or instruction concerning use of the appliance in a safe way to
understand the hazards involved.
WARNING! The appliance shall be disconnected from its power source during service and when replacing parts.
WARNING! The removal of the plug has to be such that an operator can check from any of the points to which he has access that the
plug remains removed.
9 There is a risk of injury!
8 DO NOT leave the unit unattended while in operation.
9 Check capacity and maximum pressure of inatable before commencing ination.
9 Monitor the pressure gauge while in operation.
9 The gauge should be used as an indication of pressure only. We recommend the use of a dial pressure gauge for denitive reading.
9 Locate compressor on an appropriate surface for use.
8 DO NOT direct ination hose connector head at yourself, others or animals.
8 DO NOT allow to play with the device.
9 Keep yourself and non essential persons away from the ination area.
8 DO NOT carry by the hose, or pull the hose sharply from a valve.
8 DO NOT pull the power cable from the vehicle accessory socket or battery terminal by the power lead.
8 DO NOT get the compressor wet or use in the rain.
8 DO NOT use the compressor for a task it was not designed to perform.
8 DO NOT operate the compressor when you are tired, under the inuence of alcohol, drugs or intoxicating medication.
8 DO NOT operate the compressor if any parts are missing as this may cause failure or possible personal injury.
MAC13D Issue:2 20/03/25
Original Language Version
© Jack Sealey Limited
Refer to
instruction
manual
Keep away
from rain
8 DO NOT open the unit.
8 DO NOT leave the device unsupervised while running. Comply with the lling instructions for the inatable item. The inatable item
could burst and cause serious injuries.
WARNING! When inating tyres which are completely at or articles with high volume low pressure, monitor temperature, as it can
overheat rapidly in the absence of back pressure. A 10 minute rest period should be observed after 15 minutes of continuous run time
to extend compressor service life.
9 Keep the compressor clean and in good condition.
9 Replace or repair damaged parts. Use recommended parts only. Non authorised parts may be dangerous and will invalidate the
warranty.
9 The integrated compressor unit is designed to adjust the pressure in tyres (e.g. car, motorbike and bicycle tyres), and for the generation
of pressure for balls and other low-pressure inatable items.
2. INTRODUCTION
Suitable for inflating tyres on cars, vans, 4x4s, motorcycles and bicycles. High volume air pump with inflate/deflate function suitable
for air mattresses and inflatables. Dual powered by 12V and 230V AC mains power. Maximum pressure 120psi. Air flow rate 22L/min
with an inflation time of 0-35psi in 210sec (195/55R15). Pressure units psi, kPa, kg/cm² and bar. Auto-Shut-off safety feature when
pre-set pressure is reached. Integrated SMD LED worklight with red SOS and flashing light function. Easy-to-read backlit LED digital
display screen. Compact and lightweight unit with accessories fixed to the housing. Anti-vibration feet. Accessory kit includes Schrader
connection, Presta type adaptor, ball spike and inflatable adaptor.
3. SPECIFICATION
MAC13D Issue:2 20/03/25
Original Language Version
© Jack Sealey Limited
Model No: MAC13D
Airow: Compressor: 22L/min
High Volume Air Pump: 350L/min
Accuracy: ±1%
Fuse Rating: 13A
Maximum Air Supply: 120psi(8.3bar)
Nett Weight: 1.495kg
Plug Type: 3-Pin BS
Pressure Units: Psi, kPa, kg/cm², bar
Range: 0-120psi
Hose Length: 700mm
Maximum Pressure: 120psi
High Volume Hose Length: 450mm
Supply: 230V~50HZ or
12V ⎓ - 10A
Power Supply Cable: 1.8m, D.C: 3m
High Pressure Hose Length: 550mm
Continuous Working Time: 30mins
LED Light: 3 Modes
Ination Time (175/70/R13): 0-30psi in 194sec (230V)
0-30psi in 226sec (12V)
Max Current: 10A
Power: 120W
4. FEATURES
5. SPARES
Original Language Version
© Jack Sealey Limited
MAC13D Issue:2 20/03/25
Part Description
1 Light Button
2 Mode Select Button
3 Digital Display
4 “+” Button
5 “-” Button
6 High-volume Tapered Nozzle
7 High Volume Ination Mode On Button
8 Power Supply Button and High Pressure Mode
On Button
9 Deation
MAC13DR-01 Tyre Inator/Air Pump Hose
MAC13DR-02 Presta Type Adaptor
MAC13DR-03 Ball Spike
MAC13DR-04 Inatable Adaptor
MAC13DR-05 Charging Cable (USB - C-type)
17
16
15
18
14
12
13
1
2
3
4
5
6
7
8
9
10
11
Part Description
10 Ination
11 Storage Compartment
12 LED Light(Mode 1:Bright Light,Mode 2:Strobe
Light 3:Red Light)
13 High-volume Hose
14 High-pressure Hose
15 Presta Valve Adaptor
16 Needle Nozzle
17 Tapered Nozzle
18 12V Cigarette Lighter Plug
19 Mains Plug
19
Original Language Version
© Jack Sealey Limited
MAC13D Issue:2 20/03/25
6. OPERATION
6.1. HIGH PRESSURE ITEMS - 12V DC POWER SUPPLY
Step 1. Start the car engine before plugging in the power cord.
Step 2. Plug the power cord into the DC socket.
Step 3. Attach the universal inating valve adaptor to the item, using the clip to lock into place.
Step 4. Press and hold the power On/O button to start the power supply.
Step 5. Press the “M” button to select the display unit, then press “-” or “+” to set the desired pressure.
Step 6. Select the ination mode button the air pump will automatically start.
Step 7. The air pump will automatically stop inating once the preset pressure is reached.
NOTE: Press the “LED” button to select the torch function, choose between the LED light remaining on, or red ashing for the red SOS
function.
6.2. LOW PRESSURE ITEMS - 12V DC POWER SUPPLY
Step 1. Start the car engine before plugging in the power cord.
Step 2. Plug the power cord into the DC socket.
Step 3. For deation, connect the high volume hose to the air pumps’s air inlet. For ination, connect the high-volume hose to the air
pumps air outlet, and twist the hose to lock in place.
Step 4. Connect the high volume hose to the low pressure product. (if the inating nozzles are required, install correctly before use).
Step 5. Press and hold the On/O button to start the power supply.
Step 6. Press the “M” button to select the ination mode, and then select mode.
Step 7. Press the ination mode button. The air pump will automatically start.
Step 8. When the desired pressure is reached, it is important to manually press to turn o the air pump.
1 2 3
4 5 6
1 2 3
4
5 6
6.3. POWER SUPPLY-HIGH PRESSURE ITEMS - 230V POWER SUPPLY
Step 1. Plug the power cord into a mains supply.
Step 2. Attach the universal inating valve adapter to the item, using the clip to lock into place.
Step 3. Press and hold the power On/O button to start the power supply.
Step 4. Press the “M” button to select the display unit, then press “-” or “+” to set the desired pressure.
Step 5. Press the ination mode switch, the air pump will automatically start.
Step 6. The air pump will automatically stop inating once the preset pressure is reached.
6.4. POWER SUPPLY-LOW PRESSURE ITEMS - 230V POWER SUPPLY
Step 1. Plug the power cord into a power socket.
Step 2. For deation, connect the high volume hose to the air pumps’s air inlet. For ination, connect the high-volume hose to the air
pumps air outlet, and twist the hose to lock in place.
Step 3. Connect the high volume hose to the low pressure product. (if the inating nozzles are required, install correctly before use).
Step 4. Press and hold the power On/O button to start the power supply.
Step 5. Press the “M” button to select the ination mode, and then select mode.
Step 6. Press the ination mode button. The air pump will automatically start.
Step 7. When the desired pressure is reached, it is important to manually press to turn o the air pump.
7
1 2 3
4
1 2 3
5
For reference only
For reference only
Original Language Version
© Jack Sealey Limited
MAC13D Issue:2 20/03/25
Original Language Version
© Jack Sealey Limited
MAC13D Issue:2 20/03/25
6.5. LED LIGHT
6.5.1. Press the LED light button to select the LED light function, choose between ON, red ashing and red SOS function.
6.6. BALL INFLATION
6.7. Make sure the needle adapter is inserted correctly. (See illustrations below for reference).
6.8. Press the “M” button to select the ball mode, select the desired pressure, press ination button (monitor ball pressure and remove
needle if excessive pressure is reached).
NOTE: 100PSI=689.47KPA=6.89BAR
5 6
1
4
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic
Equipment (WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact
your local solid waste authority for recycling information.
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts
without prior notice. Please note that other versions of this product are available. If you require documentation for alternative versions, please
email or call our technical team on technical@sealey.co.uk or 01284 757505.
IMPORTANT: No Liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any uids (if applicable) into approved
containers and dispose of the product and uids according to local regulations.
Original Language Version
© Jack Sealey Limited
MAC13D Issue:2 20/03/25
7. MAINTENANCE
7.1. HOW TO REPLACE A FUSE IN THE 12V PLUG
7.1.1. Unscrew the top of the plug using a pair of long nose pliers.
7.1.2. Remove the fuse.
7.1.3. Insert a new fuse.
7.1.4. Screw the top plug back into socket.
7.2. GENERAL
7.2.1. Keep the device in a dry location and out of the reach of children. This helps prevent device damage and possible personal injuries.
7.3. SERVICING AND EMERGENCY REPAIR
7.3.1. For service and repair contact Sealey Service Centre.
7.4. PREVENTATIVE MAINTENANCE MEASURES
7.4.1. Always keep tyre inator clean.
7.4.2. Clean the surfaces with a soft damp cloth only. DO NOT submerge in water, or use chemicals to clean tyre inator.
7.5. CONDITION OF THE MACHINE
7.5.1. For best results always keep tyre inator clean, and check on a weekly basis for damaged parts.
7.6. RESTRICTED USE OF THE PRODUCT
7.6.1. Only use tyre inator for it’s intended use only.
7.7. DISMANTLING THE PRODUCT WHEN OUT OF SERVICE
8 DO NOT attempt to dismantle tyre inator contact Sealey Service Centre.
7.8. TRANSPORT, HANDLING AND STORAGE OF THE PRODUCT
7.8.1. When transporting tyre inator always use the carry handle only. Store tyre inator in a dry clean place out of the reach of children.
7.9. REPAIR OF THE MACHINE
7.9.1. For repair contact Sealey Service Centre.
7.10. OPERATING METHODS IN THE EVENT OF AN ACCIDENT/BREAKDOWN
7.10.1. In the event of an accident or breakdown turn o the tyre inflator immediately and contact sealey service centre.
7.11. SPARE PART SPECIFICATION, WHEN THEY AFFECT HEALTH AND SAFETY
7.11.1. Refer to the spares list accompanied with these instructions. Always observe health and safety when inating products with this
product.
8. END OF LIFE
8.11.1. Through years of normal wear, the tyre inator will eventually become unserviceable. When this happens ensure that it is disposed of in
accordance with local authority regulations.
