Reolink Go PT Plus
2K 5MP 4G Pan-Tilt Camera,
Battery or Solar Powered, with
Person/Vehicle Detection
• 4G LTE Network
• 2K+ 5MP Super HD
• Person/Vehicle Detection
Specifications
Video & Audio
Image Sensor 1/2.7" CMOS sensor
Video Resolution 2880 x 1660 (5 megapixels) @15fps
Lens f=4mm, F1.6
Video Compression H.265
Field of View
Horizontal: 90°
Vertical: 47°
Diagonal: 110°
Infrared Night Vision
Up to 10 meters (33ft) ; LED: 2pcs/1.2W/
850nm (Auto-switching with IR-cut
filter)
Color Night Vision 2pcs/2.4W/6500K
Audio two-way audio
Power
Battery
6000mAh rechargeable battery
(Battery life varies based on settings,
usage & temperature)
Solar Reolink Solar Panel
Interface
Power Port USB Type-C port
Reset Button YES
Audio In/Out Built-in microphone and speaker
Storage
microSD Card Slot
Supports Max.128GB microSD card
(32GB included)
Pan & Tilt
PT Angle(Max.) Pan: 355°; tilt: 140°
Preset Points
Supports 1 guard position & up to 32
preset positions
3G/4G Bandwidth
Frequency Bands
• Europe Version: LTE FDD:B1/B3/B7/
B8/B20/B28A WCDMA: B1/B8
• U.S. Version: LTE FDD:B2/B4/B5/B12/
B13/B14/B66/B71
• Australia Version: LTE FDD: B1/B3/B5/
B7/B8/B28 WCDMA:B1/B5/B8
Software
OS Supported
PC: Windows, Mac OS; Smartphone:
iOS, Android
Protocols & Standards
SSL, TCP/IP, UDP, UPNP, SMTP, NTP,
P2P
User Access
Max. 12 simultaneous streams (2 main
& 10 sub streams)
Other Features
Smart Alarm
PIR detection/person detection/
vehicle detection/animal detection
PIR Detecting Distance Adjustable up to 10m (33 ft)
PIR Detecting Angle 120° horizontal
Recording Modes Triggered recording
Time Lapse YES
Smart Home Compatibility Google Assistant, Alexa
Cloud Storage
Supports Reolink Cloud (available in
selected countries)
Working Environment
Operating Temperature -10 to 55° C (14° to 131° F)
Weather Resistance IP64
Mechanical
Size Φ98 x 112mm (Φ3.7 x 4.4 in)
Weight Battery Included 485 g (17.1 oz)
Warranty
Limited Warranty
2-year limited warranty. For support,
visithttps://support.reolink.com/hc/en-
us/
Gallery & Specs
1. Speaker
2. IR LEDs
3. Spotlights
4. Daylight Sensor
5. Lens
6. Status LED
7. PIR Motion Sensor
8. Built-in Microphone
1. Antenna
2. USB Port
3. Power Switch
4. Nano SIM Card Slot
5. microSD Card Slot
www.reolink.com
