Wireless Keyfob
User Manual
UD20280B
Indicator
Open (Entrance)
Close/Pair
Press: Close Door
Hold for 10 s: Pair Keyfob
Open (Exit)
Remain Open
(Hold for 1.5 s)
Metal Hook
Disassembling Groove
Indicator (Red) Instruction:
Flash Once: Press the Key
Flash Twice: Keyfob Paired
Flash 2s: Low Battery
1. Disassemble the groove
according to the arrow.
2. Remove the rear panel and
you can see the battery slot.
Battery Slot
3. Place a supplied battery
(Model: 12V23A) into the slot.
Pay attention to the polarity
on the device. Do not install the
battery in the wrong direction.
Battery
4. Assemble the rear panel
back to the front panel.
Power On
1
Pair Keyfob
2
One-to-One Mode:
By default, the keyfob is in one-to-one mode. The keyfob's
DIP switch is towards 1 (OFF). In this mode, the keyfob can
only control one turnstile.
Power on the turnstile and make sure the turnstile is in the
normal mode. Set the DIP switch according to the turnstile's
user manual and make sure the turnstile has entered the
one-to one pairing mode.
Reboot the turnstile and make sure no other turnstiles have
paired with the keyfob within the available pairing distance.
Hold "Close" for more than 10 s, and the keyfob starts
pairing.
After pairing completed, the keyfob's indicator will flash
twice. If pairing failed, the indicator is off.
You can also pair the keyfob via the client software. For
details, see the turnstile's user manual.
One-to-Many Mode:
The keyfob's DIP switch is ON. In this mode, the keyfob can
control multiple turnstiles.
Power on the turnstile and make sure the turnstile is in the
normal mode. Set the DIP switch according to the turnstile's
user manual and make sure the turnstile has entered the
one-to-many pairing mode.
Reboot the turnstile. Hold "Close" for more than 10 s, and
the keyfob starts pairing.
After pairing, the keyfob's indicator will flash twice.
You can also pair the keyfob via the client software. For
details, see the turnstile's user manual.
1
ON
1 (Default):
One-to-One Pairing Mode
ON:
One-to-Many Pairing Mode
DIP
1 Appearance
The pictures here are for reference only.
2 Quick Operation
©2020 Hangzhou Hikvision Digital Technology Co., Ltd. All rights reser ved.
About this Manual
The Manual includes instructions for using and managing the Product. Pictures, charts, images
and all other information hereinafter are for description and explanation only. The information
contained in the Manual is subject to change, without notice, due to firmware updates or other
reasons. Please find the latest version of this Manual at the Hikvision website
(https://www.hikvision.com/).
Please use this Manual with the guidance and assistance of professionals trained in supporting
the Product.
Trademarks
and other Hikvision's trademarks and logos are the properties of Hikvision in various
jurisdictions.
Other trademarks and logos mentioned are the properties of their respective owners.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE PRODUCT
DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED “AS IS” AND
“WITH ALL FAULTS AND ERRORS”. HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS
FOR A PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO
EVENT WILL HIKVISION BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL,
OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS
PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF
DOCUMENTATION, WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING
NEGLIGENCE), PRODUCT LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF THE
PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR
LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF INTERNET PROVIDES FOR INHERENT SECURITY
RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK,
VIRUS INSPECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL
PROVIDE TIMELY TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU
ARE SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE
LAW. ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES
NOT INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS
OF PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY
RIGHTS. YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT
OR PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT
REL ATED TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF
HUMAN RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE
LATER PREVAILS.
Data Protection
During the use of device, personal data will be collected, stored and processed. To protect data,
the development of Hikvision devices incorporates privacy by design principles. For example,
for device with facial recognition features, biometrics data is stored in your device with
encr yption method; for fingerprint device, only fingerprint template will be saved, which is
impossible to reconstruct a fingerprint image.
As data controller, you are advised to collect, store, process and transfer data in accordance
with the applicable data protection laws and regulations, including without limitation,
conducting security controls to safeguard personal data, such as, implementing reasonable
administrative and physical security controls, conduct periodic reviews and assessments of the
effectiveness of your security controls.
Factors may affect the usage:
1. Obstacles (Wall, etc.);
2. People are walking near the turnstile
or the keyfob;
3. There are metals near the turnstile.
