DS-K3G200(L)X Series Tripod Turnsle
UD32923B
Legal Informaon
About this Document
•
This Document includes instrucons for using and managing
the Product. Pictures, charts, images and all other informaon
hereinaer
are for descripon and explanaon only.
•
The
informaon contained in the Document is subject to
change, without
noce, due to rmware updates or other
reasons. Please nd the latest version of the Document at the
Hikvision website (
hps://www.hikvision.com ). Unless
otherwise agreed, Hangzhou Hikvision Digital Technology Co.,
Ltd. or its aliates (hereinaer referred to as "Hikvision")
makes no
warranes, express or implied.
•
Please use the Document with the guidance and assistance of
professionals trained in supporng the Product.
Acknowledgment of Intellectual Property Rights
•
Hikvision owns the copyrights and/or patents related to the
technology embodied in the Products described in this
Document, which may include licenses obtained from third
pares.
•
Any part of the Document, including text, pictures, graphics,
etc., belongs to Hikvision. No part of this Document may be
excerpted, copied, translated, or
modied in whole or in part
by any means without wrien permission.
•
and other Hikvision's trademarks and logos are
the
properes of Hikvision in various jurisdicons.
•
Other trademarks and logos menoned are the properes of
their
respecve owners.
LEGAL DISCLAIMER
•
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW,
THIS DOCUMENT AND THE PRODUCT DESCRIBED, WITH ITS
HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS
IS" AND "WITH ALL FAULTS AND ERRORS". HIKVISION MAKES
NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT
LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR
FITNESS FOR A PARTICULAR PURPOSE. THE USE OF THE
PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL
HIKVISION BE LIABLE TO YOU FOR ANY SPECIAL,
CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,
INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF
BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF
DATA, CORRUPTION OF SYSTEMS, OR LOSS OF
DOCUMENTATION, WHETHER BASED ON BREACH OF
CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT
LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF
THE PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES OR LOSS.
•
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET
PROVIDES FOR INHERENT SECURITY RISKS, AND HIKVISION
SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL
i
OPERATION, PRIVACY LEAKAGE OR OTHER DAMAGES
RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS
INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER,
HIKVISION WILL PROVIDE TIMELY TECHNICAL SUPPORT IF
REQUIRED.
•
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL
APPLICABLE LAWS, AND YOU ARE SOLELY RESPONSIBLE FOR
ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE
LAW. ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS
PRODUCT IN A MANNER THAT DOES NOT INFRINGE ON THE
RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION,
RIGHTS OF PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR
DATA PROTECTION AND OTHER PRIVACY RIGHTS. YOU SHALL
NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES,
INCLUDING THE DEVELOPMENT OR PRODUCTION OF
WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY
ACTIVITIES IN THE CONTEXT RELATED TO ANY NUCLEAR
EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT
OF HUMAN RIGHTS ABUSES.
•
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS DOCUMENT
AND THE APPLICABLE LAW, THE LATTER PREVAILS.
Data Protecon
•
To protect data, the development of Hikvision Products
incorporates privacy by design principles. For example, for
Products with facial
recognion features, biometrics data is
stored in your Products with encrypon method; for ngerprint
Products, only ngerprint template will be saved, which is
impossible to reconstruct a
ngerprint image.
•
As a data controller/processor, you may process personal data,
including
collecon, storage, use, processing, disclosure,
deleon, etc. You are advised to pay aenon to and comply
with applicable laws and
regulaons related to the protecon
of personal data, including without limitaon, conducng
security controls to safeguard personal data, such as,
implemenng reasonable administrave and physical security
controls, conduct periodic reviews and the assessments of the
eecveness of your security controls.
© Hangzhou Hikvision Digital Technology Co., Ltd. All rights
reserved.
ii
Regulatory Informaon
EU Conformity Statement
This product and - if applicable - the supplied
accessories too are marked with "CE" and
comply therefore with the applicable
harmonized European standards listed under
the EMC
Direcve 2014/30/EU, RE Direcve
2014/53/EU,the RoHS Direcve 2011/65/EU
2012/19/EU (WEEE direcve): Products marked
with this symbol cannot be disposed of as
unsorted municipal waste in the European
Union. For proper recycling, return this product
to your local supplier upon the purchase of
equivalent new equipment, or dispose of it at
designated collecon points. For more
informaon see: www.recyclethis.info
2006/66/EC (baery direcve): This product
contains a baery that cannot be disposed of as
unsorted municipal waste in the European
Union. See the product documentaon for
specic baery informaon. The baery is
marked with this symbol, which may include
leering to indicate cadmium (Cd), lead (Pb), or
mercury (Hg). For proper recycling, return the
baery to your supplier or to a designated
collecon point. For more informaon
see:www.recyclethis.info
iii
Safety Instrucon
These instrucons are intended to ensure that user can use the
product correctly to avoid danger or property loss.
The precauon measure is divided into Dangers and Cauons:
Dangers: Neglecng any of the warnings may cause serious injury
or death.
Cauons: Neglecng any of the cauons may cause injury or
equipment damage.
Dangers: Follow these safeguards
to prevent serious injury or death.
Cauons: Follow these precauons
to prevent potenal injury or
material damage.
Danger:
•
All the electronic operaon should be strictly compliance with
the electrical safety regulaons, re prevenon regulaons and
other related regulaons in your local region.
•
Please use the power adapter, which is provided by normal
company. The power consumpon cannot be less than the
required value.
•
Do not connect several devices to one power adapter as
adapter overload may cause over-heat or
re hazard.
•
Please make sure that the power has been disconnected
before you wire, install or dismantle the device.
If the top caps should be open and the device should be
powered on for maintenance, make sure:
1.Power
o the fan to prevent the operator from geng injured
accidentally.
2.Do not touch bare high-voltage components.
3.Make sure the switch’s wiring sequence is correct
aer
maintenance.
•
Please make sure that the power has been disconnected
before you wire, install or dismantle the device.
•
When the product is installed on wall or ceiling, the device
shall be
rmly xed.
•
If smoke, odors or noise rise from the device, turn
o the
power at once and unplug the power cable, and then please
contact the service center.
•
Do not ingest
baery, Chemical Burn Hazard.
This product contains a
coin/buon cell baery. If the coin/
buon cell baery is swallowed, it can cause severe internal
burns in just 2 hours and can lead to death.
Keep new and used
baeries away from children. If the baery
compartment does not close securely, stop using the product
and keep it away from children. If you think baeries might
iv
have been swallowed or placed inside any part of the body,
seek immediate medical aenon.
•
If the product does not work properly, please contact your
dealer or the nearest service center. Never aempt to
disassemble the device yourself. (We shall not assume any
responsibility for problems caused by unauthorized repair or
maintenance.)
Cauons:
•
Stainless steel may be corroded in some circumstances. You
need to clean and care the device by using the stainless steel
cleaner. It is suggested to clean the device every month.
•
Do not drop the device or subject it to physical shock, and do
not expose it to high
electromagnesm radiaon. Avoid the
equipment
installaon on vibraons surface or places subject
to shock (ignorance can cause equipment damage).
•
Do not place the device in extremely hot (refer to the
specicaon of the device for the detailed operang
temperature), cold, dusty or damp locaons, and do not
expose it to high electromagnec radiaon.
•
The device cover for indoor use shall be kept from rain and
moisture.
•
Exposing the equipment to direct sun light, low
venlaon or
heat source such as heater or radiator is forbidden (ignorance
can cause
re danger).
•
Do not aim the device at the sun or extra bright places. A
blooming or smear may occur otherwise (which is not a
malfuncon however), and aecng the endurance of sensor
at the same me.
•
Please use the provided glove when open up the device cover,
avoid direct contact with the device cover, because the acidic
sweat of the
ngers may erode the surface coang of the
device cover.
•
Please use a
so and dry cloth when clean inside and outside
surfaces of the device cover, do not use alkaline detergents.
•
Please keep all wrappers
aer unpack them for future use. In
case of any failure occurred, you need to return the device to
the factory with the original wrapper.
Transportaon without
the original wrapper may result in damage on the device and
lead to addional costs.
•
Improper use or replacement of the
baery may result in
hazard of explosion. Replace with the same or equivalent type
only. Dispose of used
baeries according to the instrucons
provided by the baery manufacturer.
•
Biometric
recognion products are not 100% applicable to
an-spoong environments. If you require a higher security
level, use mulple authencaon modes.
•
Do not stay in the lane when the device is
reboong.
•
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT
TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE
INSTRUCTIONS.
v
•
SUITABLE FOR MOUNTING ON CONCRETE OR OTHER NON-
COMBUSTIBLE SURFACE ONLY.
•
The instrucons shall require connecon of the equipment
protecve earthing conductor to the installaon protecve
earthing conductor.
vi
Available Models
Product Name Model
Tripod Turnsle DS-K3G200(L)X
vii
Contents
1 Overview .................................................................. 1
1.1 Introducon .......................................................... 1
1.2 Main Features ....................................................... 1
2 System Wiring .......................................................... 1
3
Installaon ............................................................... 2
3.1 Disassemble Pedestals .......................................... 2
3.2 Install Pedestals .................................................... 2
4 General Wiring ......................................................... 3
4.1 Components
Introducon ..................................... 3
4.2 Wiring Electric Supply ........................................... 4
4.3 Wiring ................................................................... 5
4.4 Terminal
Descripon ............................................. 5
4.4.1 Lane Control Board Terminal Descripon
............................................................................... 5
4.4.2 Access Control Board Terminal
Descripon
(Oponal) ............................................................. 5
4.4.3 Main Oponal Board Terminal Descripon
(Oponal)
............................................................. 6
4.4.4 Sub Oponal Board Terminal Descripon
(Oponal) ............................................................. 7
4.4.5 Card Reader Board Terminal
Descripon ..... 7
4.4.6 RS-485 Wiring .............................................. 8
4.4.7 RS-232 Wiring .............................................. 8
4.4.8 Alarm Input Wiring ...................................... 8
4.4.9 Exit Buon Wiring ........................................ 9
4.5 Device
Sengs via Buon .................................... 9
4.5.1 Conguraon via Buon .............................. 9
4.5.2 Inialize Device .......................................... 11
5 Acvaon ............................................................... 11
5.1
Acvate via SADP ................................................ 11
viii
5.2 Acvate Device via iVMS-4200 Client Soware
................................................................................... 12
5.3 Acvate via Web Browser ................................... 13
6 Operaon via Web Browser .................................... 13
6.1 Login ................................................................... 13
6.2 Forget Password .................................................. 14
6.3 Overview ............................................................. 14
6.4 Person Management ........................................... 15
6.5 Search Event ....................................................... 16
6.6
Conguraon ...................................................... 17
6.6.1 View Device Informaon ........................... 17
6.6.2 Set Time ..................................................... 17
6.6.3 Set DST ....................................................... 17
6.6.4 Change Administrator's Password ............. 18
6.6.5 Online Users .............................................. 18
6.6.6 View Device Arming/Disarming
Informaon
............................................................................. 18
6.6.7 Network Sengs ....................................... 19
6.6.8 Event Linkage ............................................. 20
6.6.9 Access Control Sengs .............................. 22
6.6.10 Turnsle ................................................... 25
6.6.11 Card
Sengs ............................................ 27
6.6.12 Set Privacy Parameters ............................ 27
6.6.13 Upgrade and Maintenance ...................... 28
6.6.14 Device Debugging .................................... 28
6.6.15 Component Status ................................... 29
6.6.16 Log Query ................................................ 29
6.6.17
Cercate Management .......................... 29
7 Client Soware Conguraon ................................. 30
7.1 Conguraon Flow of Client Soware ................ 30
ix
7.2 Device Management ........................................... 31
7.2.1 Add Device ................................................. 31
7.2.2 Reset Device Password .............................. 33
7.2.3 Manage Added Devices ............................. 34
7.3 Group Management ........................................... 35
7.3.1 Add Group ................................................. 35
7.3.2 Import Resources to Group ....................... 35
7.4 Person Management ........................................... 36
7.4.1 Add
Organizaon ....................................... 36
7.4.2 Import and Export Person Idenfy
Informaon ......................................................... 36
7.4.3 Get Person Informaon from Access Control
Device ................................................................. 38
7.4.4 Issue Cards to Persons in Batch ................. 39
7.4.5 Report Card Loss ........................................ 40
7.4.6 Set Card Issuing Parameters ...................... 40
7.5 Congure Schedule and Template ...................... 41
7.5.1 Add Holiday ............................................... 41
7.5.2 Add Template ............................................. 42
7.6 Set Access Group to Assign Access Authorizaon to
Persons ..................................................................... 43
7.7
Congure Advanced Funcons ........................... 45
7.7.1 Congure Device Parameters .................... 45
7.7.2 Congure Device Parameters .................... 49
7.8 Door Control ....................................................... 50
7.8.1 Control Door Status ................................... 50
7.8.2 Check Real-Time Access Records ............... 51
A. DIP Switch ............................................................. 53
A.1 DIP Switch
Descripon ....................................... 54
B.
Buon Conguraon Descripon .......................... 55
C. Event and Alarm Type ............................................ 57
x
1 Overview
1.1 Introducon
By adopng the turnsle integratedly with the access control
system, person should
authencate to pass through the lane via
presenng cards, face, or QR code, etc. It is widely used in
aracons, oce, construcon sites, residences and other indoor
scenes.
1.2 Main Features
•
Bidireconal (Entering/Exing) lane.
•
Support remote control and management by HCP soware.
•
High-brightness LED indicates the entrance/exit and passing
status except "Pg" type.
•
Fire alarm passing: When triggered, the arms will be dropped
automacally for emergency evacuaon.
•
Support PC web browser, easy to do the conguraon.
•
Support ISAPI protocol for 3rd party
integraon development.
2 System Wiring
The preparaon before installaon and general wiring.
Steps
1.
Draw a line based on the outer edge of the
le or right
pedestal or column.
2.
Draw other parallel lines for installing the other pedestals.
Note
The distance between the nearest two line is 836 mm.
3.
Slot on the
installaon surface and dig installaon holes
according to the hole posion. Put 4 expansion bolts for each
pedestal.
4.
Bury cables. Each lane buries 1 high voltage cable. For details,
see the system wiring diagram below.
1
Figure 2-1 System Wiring Diagram
Note
•
High voltage: AC power input
•
The suggested inner diameter of the high voltage conduit is
larger than 30 mm.
•
The external AC power cord should be double-insulated.
•
Before digging holes, evaluate the thickness of the
installaon surface to avoid puncturing.
•
The network cable must be CAT5e or the network cable has
beer performance.
•
If the usage scenarios of the equipment include kindergarten
and primary school, it is recommended to design dedicated
turnsles for young children and lower grade students to
reduce the safety risks.
If there is a scene where children pass through alone, it is
recommended to use a children's bracket for face
recognion terminal installaon. When installing, it is
recommended to choose a low angle installaon or an
external vercal children's bracket. The vercal children's
bracket is recommended to be installed about 0.5 meters in
front of the
turnsle.
3 Installaon
3.1 Disassemble Pedestals
Before installaon, you should use the key to open the pedestals.
View the pictures below to nd the lock holes.
Figure 3-1 Lock Holes
3.2 Install Pedestals
Before You Start
Prepare for the
installaon tools, check the device and the
accessories, and clear the installaon base.
2
Steps
Note
•
The device should be installed on the concrete surface or other
non-ammable surfaces.
•
To prevent stainless steel from rusng due to dirt during
construcon, it is recommended that the protecve lm be
removed
aer the installaon is completed. There may be
residual adhesive at the lm cung posion. It is
recommended to use WD-40 protecve liquid to wipe aer
tearing the lm.
•
The dimension is as follows.
Figure 3-2 Dimension
1.
Prepare for the installaon tools, check the components, and
prepare for the installaon base.
2.
Seal the boom of the turnsle to avoid water from entering.
3.
According to the entrance and exit marks on the pedestals,
move the pedestals to the corresponded posions.
Note
Make sure the installaon holes on the pedestals and the base
are aligned with each other.
4.
Secure the pedestals with expansion bolts.
Note
•
Do not immerse the pedestal in the water. In special
circumstances, the immersed height should be no more than
150 mm.
5.
Install the barrier arm.
4 General Wiring
Note
•
Aer maintenance, you should close the water-proof cover
over the high voltage module.
•
When you should maintain or disassemble the high voltage
modules, you should remove the enre high voltage modules
and maintain it outside the
turnsle. You should unplug the
cables that connected to the peripherals before maintenance
to avoid destroy of the device.
4.1 Components Introducon
3
By default, basic components of the turnsle are connected well.
The pedestals can communicate by wiring the interconnecng
cables. And the turnsle supports wiring the AC electric supply
for the whole system's power supply.
Note
The voltage uctuaon of the electric supply is between 100 VAC
and 240 VAC, 50 to 60 Hz.
The picture displayed below describes the serial port on the
entrance and exit direcon.
Figure 4-1 Serial Port
The picture displayed below describes each component's posion
on the turnsle.
Note
The diagram is for reference only.
Figure 4-2 Components Diagram 1
4.2 Wiring Electric Supply
Wire electric supply with the power switch or power adapter in
the pedestal. Terminal L (brown) and terminal N (Blue) are on the
switch, while terminal PE should connect to a ground wire (yellow
and green wire).
For product with power switch, the wiring diagram is as follows:
For product with power adapter, the wiring diagram is as follows:
4
Warning
Terminal PE should connect to a ground wire to avoid hazard
when people touching the device.
Note
•
The cable bare part should be no more than 8 mm. If possible,
wear an insulaon cap at the end of the bare cable. Make sure
there's no bare copper or cable aer the wiring.
•
The Terminal L and the Terminal N cannot be wired reversely.
Do not wire the input and output terminal reversely.
•
To avoid people injury and device damage, when
tesng, the
ground resistance of the equipotenal points should not be
larger than 2 Ω。
4.3 Wiring
Scan the QR code to view the wiring guide video.
4.4 Terminal Descripon
4.4.1 Lane Control Board Terminal Descripon
The lane control board contains power input interface, exit
buon and re input interface, access control board interface,
debugging port, indicator interface, etc.
The picture displayed below is the lane control board diagram.
4.4.2 Access Control Board Terminal
Descripon
(Oponal)
Access control board is mainly used for authority idencaon in
places with high security levels such as public security or judicial
place, external device accessing, and
communicaon with the
upper
plaorm and lane controller.
5
Note
•
RS-485A corresponds to UART 5 on web and is for QR code
scanner connecon at entrance by default; RS-485C
corresponds to UART 7 on web and is for card reader
connecon at entrance by default.
•
The SOC and MCU serial port are for maintenance and
debugging use only.
•
Press the Reset
buon for 5 s and the device will start to
restore to factory
sengs.
•
The DIP switch is for study mode seng. For detailed
informaon about the DIP switch, see DIP Switch Descripon.
The wiring diagram of extended interface of access control board
is shown as follows.
Figure 4-3 Wring Diagram of BUS3 Interface
Note
RS-232A corresponds to UART 1 on web.
4.4.3 Main Oponal Board Terminal Descripon
(Oponal)
6
The main oponal board contains the sub-1G antenna interface,
loudspeaker interface, debugging port, Wiegand/exit buon
interface, 5 VDC output and communicaon interface.
Figure 4-4 Main Oponal Board Terminal
4.4.4 Sub
Oponal Board Terminal Descripon
(Oponal)
Figure 4-5 Sub Oponal Board Terminal
Note
•
RS-485B corresponds to port 6 on web and is for QR code
scanner connecon by default.
•
RS-485D corresponds to port 4 on web and is for card reader
connecon by default.
•
RS-232B corresponds to port 2 on web and is for
ngerprint
reader connecon by default.
4.4.5 Card Reader Board Terminal Descripon
The card reader board can be connected to the access control
board via RS-485 interface.
7
Figure 4-6 Card Reader Board
4.4.6 RS-485 Wiring
The RS-485 interfaces on the access control board and sub
oponal board are suggested to connect with the face
recognion module or the card reader. Here takes connecng
with a card reader as an example.
Note
•
If there are other RS-485 devices connecng, the ID of the
RS-485 cannot be conicted.
•
The connected 12 V power interface for the face recognion
terminal cannot be connected with other 12 V devices.
Figure 4-7 Wiring RS-485
4.4.7 RS-232 Wiring
Note
•
There is 1 RS-232 interface on the extended interface of access
control board, see Access Control Board Terminal Descripon
(Oponal). The RS-232A corresponds to UART 1 on web.
•
There is 1 RS-232 interface on the sub extended interface
board, see Sub
Oponal Board Terminal Descripon
(Oponal). The RS-232B corresponds to UART 2 on web.
The RS-232C interface is reserved.
Figure 4-8 RS-232 Wiring
4.4.8 Alarm Input Wiring
On the main lane control board, you can wire the re alarm input
interface.
Figure 4-9 Remaining Open
8
Figure 4-10 Remaining Closed
4.4.9 Exit Buon Wiring
The main and sub lane control board each has 1 buon interface,
which can be connected to exit buon or face recognion device.
Figure 4-11 Exit Buon Wiring
Note
•
The face recognion devices are powered via 12 VDC power
output interface of the main and sub lane control board.
•
Barrier open at the entrance: connect to BTN1 and GND.
•
Barrier open at the exit: connect to BTN2 and GND.
4.5 Device Sengs via Buon
You can congure the device via buon on the lane control board.
4.5.1
Conguraon via Buon
Buon Descripon
The buons are on the lane control board.
Figure 4-12
Buon
Exit Buon
•
Single press to open the gate from the entrance posion.
•
Double press to open the gate from the exit posion.
Parameter Conguraon Buon
•
LEFT: Press to add ten to
conguraon data
•
RIGHT: Press to add one conguraon data
9
•
CANCEL: Return to the level-1 menu, or exit the conguraon
from the level-1 menu
•
OK: Conrm the data, or enter conguraon mode, or enter
the submenu
Note
•
Conguraon data is displayed by two digital tubes.
•
Level-1 Menu: If the decimal point on the right is on, it
indicates the level-1 menu. The number represents the
conguraon item number.
•
Level-2 Menu: if the decimal point in the middle is on, it
indicates the level -2 menu. The number represents the
parameters of a
conguraon item.
Buon Conguraon Procedure
Figure 4-13 Procedure
Steps:
1. Enter the conguraon mode. The number of 1 will show up
on the right side of the screen and the device is ready for
conguraon.
2. Press LEFT and RIGHT to set the conguraon No. Press OK to
enter the level-2 menu and view the parameters. Press
CANCEL, or conduct no operaon for 5 s to cancel
conguraon.
3. Press LEFT and RIGHT to set the parameters at your needs.
Press OK to save the changes or press CANCEL back to
conguraon No. seng without saving changes. Conduct no
operaons for 5 s to cancel conguraon.
10
4.5.2 Inialize Device
Steps
1.
Hold the inializaon buon on the access control board for 5
s.
Figure 4-14 Inializaon Buon Posion
2.
The device will start restoring to factory sengs.
3.
When the process is nished, the device will beep for 3 s.
Cauon
The inializaon of the device will restore all the parameters to
the default seng and all the device events are deleted.
Note
Make sure no persons are in the lane when powering on the
device.
5 Acvaon
You should acvate the device before the rst login. Aer
powering on the device, the system will switch to Device
Acvaon page.
Acvaon via the device, SADP tool and the client soware are
supported.
The default values of the device are as follows:
•
The default IP address: 192.0.0.64
•
The default port No.: 80
•
The default user name: admin
5.1 Acvate via SADP
SADP is a tool to detect, acvate and modify the IP address of the
device over the LAN.
Before You Start
•
Get the SADP
soware from the supplied disk or the ocial
website hp://www.hikvision.com/en/ , and install the SADP
according to the prompts.
•
The device and the PC that runs the SADP tool should be within
the same subnet.
The following steps show how to
acvate a device and modify its
IP address. For batch acvaon and IP addresses modicaon,
refer to User Manual of SADP for details.
Steps
1.
Run the SADP
soware and search the online devices.
2.
Find and select your device in online device list.
3.
Input new password (admin password) and
conrm the
password.
11
Cauon
STRONG PASSWORD RECOMMENDED-We highly recommend
you create a strong password of your own choosing (using a
minimum of 8 characters, including upper case leers, lower
case leers, numbers, and special characters) in order to
increase the security of your product. And we recommend you
reset your password regularly, especially in the high security
system,
reseng the password monthly or weekly can beer
protect your product.
Note
Characters containing admin and nimda are not supported to
be set as acvaon password.
4.
Click Acvate to start acvaon.
Status of the device becomes Acve aer successful acvaon.
5.
Modify IP address of the device.
1) Select the device.
2) Change the device IP address to the same subnet as your
computer by either modifying the IP address manually or
checking Enable DHCP.
3) Input the admin password and click Modify to
acvate your
IP address modicaon.
5.2 Acvate Device via iVMS-4200 Client
Soware
For some devices, you are required to create the password to
acvate them before they can be added to the iVMS-4200
soware and work properly.
Steps
Note
This funcon should be supported by the device.
1.
Enter the Device Management page.
2.
Click
on the right of Device Management and select Device.
3.
Click Online Device to show the online device area.
The searched online devices are displayed in the list.
4.
Check the device status (shown on Security Level column) and
select an
inacve device.
5.
Click
Acvate to open the Acvaon dialog.
6.
Create a password in the password eld, and conrm the
password.
12
Cauon
The password strength of the device can be automacally
checked. We highly recommend you change the password of
your own choosing (using a minimum of 8 characters, including
at least three kinds of following categories: upper case leers,
lower case leers, numbers, and special characters) in order to
increase the security of your product. And we recommend you
change your password regularly, especially in the high security
system, changing the password monthly or weekly can
beer
protect your product.
Proper conguraon of all passwords and other security
sengs is the responsibility of the service provider and/or end-
user.
Note
Characters containing admin and nimda are not supported to
be set as acvaon password.
7.
Click OK to acvate the device.
5.3 Acvate via Web Browser
You can acvate the device via the web browser.
Steps
1.
Enter the device default IP address (192.0.0.64) in the address
bar of the web browser, and press Enter.
Note
Make sure the device IP address and the computer's should be
in the same IP segment.
2.
Create a new password (admin password) and conrm the
password.
Cauon
STRONG PASSWORD RECOMMENDED-We highly recommend
you create a strong password of your own choosing (using a
minimum of 8 characters, including upper case leers, lower
case leers, numbers, and special characters) in order to
increase the security of your product. And we recommend you
reset your password regularly, especially in the high security
system,
reseng the password monthly or weekly can beer
protect your product.
Note
Characters containing admin and nimda are not supported to
be set as acvaon password.
3.
Click
Acvate.
4.
Edit the device IP address. You can edit the IP address via the
SADP tool, the device, and the client
soware.
6
Operaon via Web Browser
6.1 Login
13
You can login via the web browser or the remote conguraon of
the client soware.
Note
Make sure the device is acvated. For detailed informaon about
acvaon, see Acvaon.
Login via Web Browser
Enter the device IP address in the address bar of the web browser
and press Enter to enter the login page.
Enter the device user name and the password. Click Login.
Login via Remote Conguraon of Client Soware
Download and open the client soware. Aer adding the device,
click to enter the Conguraon page.
6.2 Forget Password
If you forget the password when logging in, you can change the
password by email address or security quesons.
On the login page, click Forget Password.
Select Vericaon Mode.
Security Queson Vericaon
Answer the security quesons.
E-mail Vericaon
1.Export the QR code and send it to
[email protected] as aachment.
2.You will receive a vericaon code within 5 minutes in your
reserved email.
3.Enter the
vericaon code into the vericaon code eld to
verify your idencaon.
Click Next, create a new password and conrm it.
6.3 Overview
You can view the device component status, real-me event,
person
informaon, network status, basic informaon, and device
capacity. You can also control the barrier remotely.
Funcon Descripons:
Device Component Status
You can check if the device is working properly. Click View
More to view the detailed component status.
Remote Control
/ / /
The door is opened/closed/remaining open/remaining closed.
Real-Time Event
You can view the event Employee ID, Name, Card No., Event
Type, Time, and
Operaon. You can also click View More to
enter the search condions, including the event type,
employee ID, the name, the card No., the start
me, and the
end me, and click Search. The results will be displayed on the
right panel.
Person Informaon
14
You can view the added and not added informaon of person
and card.
Network Status
You can view the network connecon status.
Basic Informaon
You can view the model, serial No. and rmware version.
Device Capacity
You can view the person, card and event capacity.
6.4 Person Management
Click Add to add the person's informaon, including the basic
informaon, cercate, and authencaon sengs.
Figure 6-1 Person Management
Add Basic Informaon
Click Person Management → Add to enter the Add Person page.
Add the person's basic informaon, including the employee ID,
the person's name, etc.
Click Save to save the sengs.
Set Permission Time
Click Person Management → Add to enter the Add Person page.
Enable Long-Term
Eecve User, or set Start Time and End Time
and the person can only has the permission within the
congured
me period according to your actual needs.
Click Save to save the sengs.
Authencaon
Sengs
Click Person Management → Add to enter the Add Person page.
Set the authencaon type.
Click Save to save the sengs.
Add Card
Click Person Management → Add to enter the Add Person page.
15
Click Add Card, enter the Card No. and select the Property, and
click Save to add the card.
Click Save to save the sengs.
Import/Export Person Data
Export Person Data
You can export added person data for back-up or
imporng to
other devices.
Click Export Person Data, set an encrypon password and
conrm it. Click OK.
Note
•
The person data will be downloaded to your PC.
•
The password you set will be required for imporng the data
le.
Imporng Person Data
Click Imporng Person Data and select the le. Click Import.
Enter the
encrypon password to import and synchronize the
person data to devices.
Note
•
Please ensure the name of the imported le is
"UserDataFile".
6.5 Search Event
Click Event Search to enter the Search page.
Figure 6-2 Search Event
Select the event type and enter the search
condions, including
the employee ID, name, card No., start
me, and end me, and
click Search.
The results will be displayed on the right panel.
16
6.6 Conguraon
6.6.1 View Device Informaon
Click Conguraon → System → System Sengs → Basic
Informaon to enter the conguraon page.
You can view the device name, language, model, serial No.,
version, IO input, IO output, and local RS-485 number.
You can change Device Name and click Save.
You can view the device capacity, including person, card and
event.
6.6.2 Set Time
Set the device's me zone, synchronizaon mode, server address,
NTP port, and interval.
Click Conguraon → System → System Sengs → Time
Sengs .
Figure 6-3 Time Sengs
Click
Save to save the
sengs aer the conguraon.
Time Zone
Select the device located me zone from the drop-down list.
Time Sync.
Manual
By default, the device
me should be synchronized
manually. You can set the device me manually or check
Sync. with Computer Time to synchronize the device
me
with the computer's me.
Server IP Address/NTP Port/Interval
You can set the server IP address, NTP port, and interval.
6.6.3 Set DST
Steps
1.
Click
Conguraon → System → System Sengs → Time
Sengs .
17
Figure 6-4 DST Page
2.
Enable DST.
3.
Set the DST start
me, end me and bias me.
4.
Click Save to save the sengs.
6.6.4 Change Administrator's Password
Steps
1.
Click
Conguraon → User Management .
2.
Click .
3.
Enter the old password and create a new password.
4.
Conrm the new password.
5.
Click Save.
Cauon
The password strength of the device can be automacally
checked. We highly recommend you change the password of
your own choosing (using a minimum of 8 characters, including
at least three kinds of following categories: upper case leers,
lower case leers, numbers, and special characters) in order to
increase the security of your product. And we recommend you
change your password regularly, especially in the high security
system, changing the password monthly or weekly can
beer
protect your product.
Proper conguraon of all passwords and other security
sengs is the responsibility of the service provider and/or end-
user.
6.6.5 Online Users
The informaon of users logging into the device is shown.
Go to Conguraon → User Management → Online Users to
view the list of online users.
6.6.6 View Device Arming/Disarming
Informaon
18
View device arming type and arming IP address.
Go to Conguraon → User Management → Arming/Disarming
Informaon .
You can view the device arming/disarming informaon. Click
Refresh to refresh the page.
6.6.7 Network Sengs
Set Basic Network Parameters
Click Conguraon → Network → Network Sengs → TCP/IP .
Figure 6-5 TCP/IP Sengs Page
You can view the mac address and MTU.
Set the parameters and click Save to save the
sengs.
NIC Type
Select a NIC type from the drop-down list. By default, it is Self-
Adapve
.
DHCP
If you disable DHCP, you should manually set the IPv4 address,
IPv4 subnet mask, IPv4 default gateway, preferred DNS server,
and alternate DNS server.
19
If you enable DHCP, the system will automacally allocate the
IPv4 address, IPv4 subnet mask, the IPv4 default gateway
preferred DNS server and alternate DNS server.
DNS Server
Set the preferred DNS server and the Alternate DNS server
according to your actual need.
Set Port Parameters
Set the HTTP, HTTPS, HTTP Listening parameters.
Click
Conguraon → Network → Network Service → HTTP(S) .
Figure 6-6 Network Service
HTTP
It refers to the port through which the browser accesses the
device. For example, when the HTTP Port is modied to 81, you
need to enter hp://192.0.0.65:81 in the browser for login.
HTTPS
Set the HTTPS for accessing the browser. Cercate is required
when accessing.
HTTP Listening
The device can send alarm informaon to the event alarm IP
address or domain name via HTTP protocol/HTTPS protocol.
Edit the event alarm IP address or domain name, URL, port,
and protocol.
Note
The event alarm IP address or domain name should support
the HTTP protocol/HTTPS protocol to receive the alarm
informaon.
6.6.8 Event Linkage
Set linked acons for events.
Steps
1.
Click
Conguraon → Event → Event Detecon → Linkage
Sengs to enter the page.
20
Figure 6-7 Event Linkage
2.
Set event source.
-
If you choose Linkage Type as Event Linkage, you need to
select event types from the drop-down list.
-
If you choose Linkage Type as Card Linkage, you need to
enter the card No. and select the card reader.
-
If you choose Linkage Type as Link Employee ID, you need
to enter the employee ID and select the card reader.
3.
Set linked acon.
Buzzer Linkage
Enable Buzzer Linkage and select Start Buzzing or Stop
Buzzing for the target event.
Door Linkage
21
Enable Door Linkage, check Entrance or Exit, and set the
door status for the target event.
Linked Alarm Output
Enable Linked Alarm Output, check Alarm Output 1 or
Alarm Output 2, and set the alarm output status for the
target event.
6.6.9 Access Control Sengs
Set Authencaon Parameters
Click Conguraon → Access Control → Authencaon Sengs .
Note
The funcons vary according to dierent models. Refers to the
actual device for details.
Figure 6-8 Set Authencaon Parameters
Click Save to save the sengs aer the conguraon.
Terminal
Choose Entrance or Exit for sengs.
Terminal Type/Terminal Model
Get terminal descripon. They are read-only.
Enable Authencaon Device
Enable the authencaon funcon.
Authencaon
Select an authencaon mode according to your actual needs
from the drop-down list.
Authencaon Interval
You can set the authencaon interval of the same person
when authencang. The same person can only authencate
once in the congured interval. A second authencaon will be
failed.
Alarm of Max. Failed Aempts
Enable to report alarm when the card reading aempts reach
the set value.
Max.
Authencaon Failed Aempts
Enable to report alarm when the card reading aempts reach
the set value.
Communicaon with Controller Every
22
When the access control device cannot connect with the card
reader for longer than the set me, the card reader will turn
oine automacally.
Note
The authencaon interval value ranges from 2 s to 255 s.
Set Door Parameters
Click Conguraon → Access Control → Door Parameters .
Click Save to save the sengs aer the conguraon.
Door No.
Select Entrance or Exit for sengs.
Door Name
You can create a name for the door.
Open Duraon
Set the door unlocking duraon. If the door is not opened for
the set
me, the door will be locked.
Note
The open duraon ranges from 5 s to 60 s.
Exit Buon Type
You can set the exit buon as Remain Open or Remain Closed
according to your actual needs. By default, it is Remain Open.
Door Remain Open Duraon with First Person
Set the door open duraon when rst person is in. Aer the
rst person is authorized, it allows mulple persons access the
door or other authencaon acons.
Serial Port Sengs
Set serial port parameters.
Steps
1.
Click
Conguraon → Access Control → Serial Port Sengs .
23
Figure 6-9 Serial Port Sengs
2.
Set the No., Baud Rate, Data Bit, Stop Bit and Parity.
3.
Set the Peripheral Type as Card Reader, Card Receiver, QR
Code Scanner or Disable.
4.
Set the Peripheral
Posion as Entrance or Exit.
5.
You can view the serial port type, external device model and
peripheral
soware version.
6.
Click Save.
Set Terminal Parameters
You can set terminal parameters for accessing.
Click
Conguraon → Access Control → Terminal Parameters .
You can set Working Mode as Permission Free Mode or Access
Control Mode.
Permission Free Mode
The device only judge your
credenal is in the valid duraon,
and will not authencate the permission.
Enable Verify Credenal Locally, the device will check
permission but not esmate the plan template.
Access Control Mode
24
The access control mode is the device normal mode. You
should authencate your credenal for accessing.
You can enable Remote Vericaon according to your actual
needs. Aer enabling, you can verify remotely. And you can
enable Verify Credenal Locally according to your actual needs.
Click Save to save the
sengs aer the conguraon.
6.6.10 Turnsle
Basic Parameters
Set turnsle basic parameters.
Steps
1.
Click Conguraon → Turnsle Conguraon → Basic Sengs
to enter the page.
Figure 6-10 Basic Parameters
2.
View the Channel Type, Channel Model and Working Status.
3.
Set the passing mode.
-
If you choose General Passing, you can select the barrier
status for the entrance and exit from the drop-down list.
-
If you choose Weekly Schedule, you can set a weekly
schedule for entrance and exit barriers.
4.
Click Save.
People Counng
Set people counng .
Steps
1.
Click
Conguraon → Turnsle Conguraon → People
Counng Sengs to enter the page.
25
Figure 6-11 People Counng
2.
Enable People Counng.
3.
Enable Device Oine People Counng at your actual needs.
Note
Passing Event Recording is reserved.
4.
Select Person Stascs Type as Invalid, Passing Detecon or
Authencaon Number.
5.
Oponal: Click Clear to clear all the people counng
informaon.
Other Sengs
Set other parameters.
Steps
1.
Click
Conguraon → Turnsle Conguraon → Other
Sengs to enter the page.
2.
Set Alarm Output Duraon.
Note
The alarm output duraon ranges from 0 s to 3599 s.
3.
Set Temperature Unit.
4.
Drag the block or enter the value to adjust the light board
brightness.
5.
Set the alarm buzzer
duraon.
6.
Enable Memory Mode at your actual needs.
Note
Mulple cards presenng for mulple person passing is
allowable when enabling the memory mode. When the passing
person's number exceeds the card presenng number, or aer
the latest person passing with no other person passing within
the door open duraon, the door will close automacally.
26
7.
Set Fire Input Type.
8.
Click Save.
6.6.11 Card Sengs
Set Card Security
Click Conguraon → Card Sengs → Card Type to enter the
sengs page.
Set the parameters and click Save.
Enable NFC Card
Reserved.
Enable M1 Card
Enable M1 card and authencang by presenng M1 card is
available.
M1 Card
Encrypon
Sector
M1 card encrypon can improve the security level of
authencaon.
Enable the funcon and set the encrypon sector. By default,
Sector 13 is encrypted. It is recommended to encrypt sector
13.
Enable EM Card
Enable EM card and
authencang by presenng EM card is
available.
Note
If the peripheral card reader supports presenng EM card, the
funcon is also supported to enable/disable the EM card
funcon.
Enable DESFire Card
The device can read the data from DESFire card when enabling
the DESFire card
funcon.
DESFire Card Read Content
Aer enable the DESFire card content reading funcon, the
device can read the DESFire card content.
Enable FeliCa Card
The device can read the data from FeliCa card when enabling
the FeliCa card
funcon.
Set Card No. Authencaon Parameters
Set the card reading content when authencate via card on the
device.
Go to
Conguraon → Card Sengs → Card No. Auth. Sengs .
Select a card
authencaon mode and enable reversed card No.
at your actual needs. Click Save.
6.6.12 Set Privacy Parameters
Set the event storage type.
Go to Conguraon → Security → Privacy Sengs
The event storage type is overwring by default. The earliest 5%
events will be deleted when the system detects the stored events
has been over 95% of the full space.
27
6.6.13 Upgrade and Maintenance
Reboot device, restore device parameters, and upgrade device
version.
Reboot Device
Click Maintenance and Security → Maintenance → Restart .
Click Restart to reboot the device.
Upgrade
Click Maintenance and Security → Maintenance → Upgrade .
Select an upgrade type from the drop-down list. Click
and
select the upgrade
le from your local PC. Click Upgrade to start
upgrading.
Note
Do not power o during the upgrading.
Restore Parameters
Click Maintenance and Security → Maintenance → Backup and
Reset .
Restore All
All parameters will be restored to the factory sengs. You
should acvate the device before usage.
Restore
The device will restore to the default sengs, except for the
network parameters and the user
informaon.
Import and Export Parameters
Click
Maintenance and Security → Maintenance → Backup and
Reset .
Export
Click Export to export the device parameters.
Note
You can import the exported device parameters to another
device.
Import
Click and select the le to import. Click Import to start
import
conguraon le.
6.6.14 Device Debugging
You can set device debugging parameters.
Steps
1.
Click Maintenance and Security → Maintenance → Device
Debugging .
2.
You can set the following parameters.
Enable SSH
To raise network security, disable SSH service. The
conguraon is only used to debug the device for the
professionals.
Print Log
28
You can select a component from drop-down list and click
Export to export log.
Capture Network Packet
You can set the Capture Packet Duraon, Capture Packet
Size, and click Start Capture to capture.
6.6.15 Component Status
You can view the main lane and other status.
Main Lane Status
Device Component
You can view the status of the access control board, lane
control board, user extended interface board.
Peripheral
You can view the status of the RS-485 card reader.
Others
Passing Mode
You can view the entrance and exit mode.
Input and Output Status
You can view the status of the event input, alarm output and
re alarm.
Other Status
You can view the status of the barrier.
6.6.16 Log Query
You can search and view the device logs.
Go to Maintenance and Security → Maintenance → Log .
Set the major and minor type of the log type. Set the start
me
and end me for searching, and click Search.
The results will be displayed below, which including the No., me,
the major type the minor type, the channel No., the local/remote
user
informaon, the remote host IP, etc.
6.6.17
Cercate Management
It helps to manage the server/client cercates and CA
cercate.
Note
The funcon is only supported by certain device models.
Create and Install Self-signed Cercate
Steps
1.
Go to Maintenance and Security → Security →
Cercate
Management .
2.
In the
Cercate Files area, select a Cercate Type from the
drop-down list.
3.
Click Create.
4.
Input
cercate informaon.
5.
Click OK to save and install the cercate.
The created cercate is displayed in the Cercate Details
area.
29
The cercate will be saved automacally.
6.
Download the cercate and save it to an asking le in the
local computer.
7.
Send the asking le to a cercaon authority for signature.
8.
Import the signed
cercate.
1) Select a cercate type in the Import Passwords area, and
select a
cercate from the local, and click Install.
2) Select a cercate type in the Import Communicaon
Cercate area, and select a cercate from the local, and
click Install.
Install Other Authorized Cercate
If you already has an authorized cercate (not created by the
device), you can import it to the device directly.
Steps
1.
Go to Maintenance and Security → Security →
Cercate
Management .
2.
In the Import Passwords and Import Communicaon
Cercate areas, select cercate type and upload cercate.
3.
Click Install.
Install CA Cercate
Before You Start
Prepare a CA
cercate in advance.
Steps
1.
Go to Maintenance and Security → Security → Cercate
Management .
2.
Create an ID in the Import CA
Cercate area.
Note
The input cercate ID cannot be the same as the exisng
ones.
3.
Upload a cercate le from the local.
4.
Click Install.
7 Client
Soware Conguraon
You can call the hotline to get the iVMS-4200 client soware
installaon
package.
7.1 Conguraon Flow of Client Soware
Follow the ow diagram below to congure on the client
soware.
30
Figure 7-1 Flow Diagram of Conguraon on Client Soware
7.2 Device Management
The client supports managing access control devices and video
intercom devices.
Example
You can control entrance & exit and manage
aendance aer
adding access control devices to the client; you can perform video
intercom with the indoor staons and door staons.
7.2.1 Add Device
The client provides three device adding modes including by IP/
domain and IP segment. The client also supports imporng
mulple
devices in a batch when there are large amount of
devices to be added.
Add Device by IP Address or Domain Name
If you know the IP address or domain name of the device to add,
you can add devices to the client by specifying the IP address (or
domain name), user name, password, etc.
Steps
1.
Enter Device Management module.
2.
Click Device tab on the top of the right panel.
The added devices are displayed on the right panel.
3.
Click Add to open the Add window, and then select IP/Domain
as the adding mode.
4.
Enter the required
informaon.
Name
Create a descripve name for the device. For example, you
can use a nickname that can show the locaon or feature of
the device.
Address
The IP address or domain name of the device.
Port
The devices to add share the same port number. The default
value is 80.
User Name
31
Enter the device user name. By default, the user name is
admin.
Password
Enter the device password.
Cauon
The password strength of the device can be automacally
checked. We highly recommend you change the password of
your own choosing (using a minimum of 8 characters,
including at least three kinds of following categories: upper
case leers, lower case leers, numbers, and special
characters) in order to increase the security of your product.
And we recommend you change your password regularly,
especially in the high security system, changing the
password monthly or weekly can
beer protect your
product.
Proper
conguraon of all passwords and other security
sengs is the responsibility of the service provider and/or
end-user.
5.
Oponal: Check Transmission Encrypon (TLS) to enable
transmission encrypon using TLS (Transport Layer Security)
protocol for security purpose.
Note
•
This funcon should be supported by the device.
•
If you have enabled Cercate Vericaon, you should click
Open Cercate Directory to open the default folder, and
copy the cercate le exported from the device to this
default directory to strengthen the security.
•
You can log into the device to get the cercate le by web
browser.
6.
Check Synchronize Time to synchronize the device
me with
the PC running the client aer adding the device to the client.
7.
Oponal: Check Import to Group to create a group by the
device name, and import all the channels of the device to this
group.
Example
For access control device, its access points, alarm inputs/
outputs, and encoding channels (if exist) will be imported to
this group.
8.
Finish adding the device.
-
Click Add to add the device and back to the device list page.
-
Click Add and New to save the sengs and connue to add
other device.
Import Devices in a Batch
You can add mulple devices to the client in a batch by entering
the device parameters in a
pre-dened CSV le.
Steps
1.
Enter the Device Management module.
2.
Click Device tab on the top of the right panel.
3.
Click Add to open the Add window, and then select Batch
Import as the adding mode.
32
4.
Click Export Template and then save the pre-dened template
(CSV le) on your PC.
5.
Open the exported template le and enter the required
informaon of the devices to be added on the corresponding
column.
Note
For detailed descripon of the required elds, refer to the
introducons in the template.
Adding Mode
Enter 0 or 1 or 2.
Address
Edit the address of the device.
Port
Enter the device port number. The default port number is
8000.
User Name
Enter the device user name. By default, the user name is
admin.
Password
Enter the device password.
Cauon
The password strength of the device can be automacally
checked. We highly recommend you change the password of
your own choosing (using a minimum of 8 characters,
including at least three kinds of following categories: upper
case leers, lower case leers, numbers, and special
characters) in order to increase the security of your product.
And we recommend you change your password regularly,
especially in the high security system, changing the
password monthly or weekly can
beer protect your
product.
Proper
conguraon of all passwords and other security
sengs is the responsibility of the service provider and/or
end-user.
Import to Group
Enter 1 to create a group by the device name. All the
channels of the device will be imported to the
corresponding group by default. Enter 0 to disable this
funcon.
6.
Click
and select the template le.
7.
Click Add to import the devices.
7.2.2 Reset Device Password
If you forgot the password of the detected online devices, you
can reset the device password via the client.
Steps
1.
Enter Device Management page.
2.
Click Online Device to show the online device area.
33
All the online devices sharing the same subnet will be
displayed in the list.
3.
Select the device from the list and click on the Operaon
column.
4.
Reset the device password.
-
Click Generate to pop up the QR Code window and click
Download to save the QR code to your PC. You can also take
a photo of the QR code to save it to your phone. Send the
picture to our technical support.
Note
For the following operaons for reseng the password,
contact our technical support.
Cauon
The password strength of the device can be automacally
checked. We highly recommend you change the password of
your own choosing (using a minimum of 8 characters, including
at least three kinds of following categories: upper case leers,
lower case leers, numbers, and special characters) in order to
increase the security of your product. And we recommend you
change your password regularly, especially in the high security
system, changing the password monthly or weekly can
beer
protect your product.
Proper conguraon of all passwords and other security
sengs is the responsibility of the service provider and/or end-
user.
7.2.3 Manage Added Devices
Aer adding devices to device list, you can manage the added
devices including eding device parameters, remote
conguraon, viewing device status, etc.
Table 7-1 Manage Added Devices
Edit Device
Click to edit device informaon
including device name, address, user
name, password, etc.
Delete
Device
Check one or more devices, and click
Delete to delete the selected devices.
Remote
Congurao
n
Click to set remote conguraon of
the corresponding device. For details,
refer to the user manual of device.
View Device
Status
Click to view device status, including
door No., door status, etc.
Note
For dierent devices, you will view
dierent informaon about device
status.
View Online
User
Click to view the details of online user
who access the device, including user
34
name, user type, IP address and login
me.
Refresh
Device
Informaon
Click to refresh and get the latest
device informaon.
7.3 Group Management
The client provides groups to manage the added resources in
dierent groups. You can group the resources into dierent
groups according to the resources' locaons.
Example
For example, on the 1st oor, there mounted 16 doors, 64 alarm
inputs, and 16 alarm outputs. You can organize these resources
into one group (named 1st Floor) for convenient management.
You can control door status, and do some other
operaons of the
devices aer managing the resources by groups.
7.3.1 Add Group
You can add group to organize the added device for convenient
management.
Steps
1.
Enter the Device Management module.
2.
Click Device Management → Group to enter the group
management page.
3.
Create a group.
-
Click Add Group and enter a group name as you want.
-
Click Create Group by Device Name and select an added
device to create a new group by the name of the selected
device.
Note
The resources (such as alarm inputs/outputs, access points,
etc.) of this device will be imported to the group by default.
7.3.2 Import Resources to Group
You can import the device resources (such as alarm inputs/
outputs, access points, etc.) to the added group in a batch.
Before You Start
Add a group for managing devices. Refer to Add Group.
Steps
1.
Enter the Device Management module.
2.
Click Device Management → Group to enter the group
management page.
3.
Select a group from the group list and select the resource type
as Access Point, Alarm Input, Alarm Output, etc.
4.
Click Import.
5.
Select the thumbnails/names of the resources in the
thumbnail/list view.
Note
You can click or to switch the resource display mode to
thumbnail view or to list view.
35
6.
Click Import to import the selected resources to the group.
7.4 Person Management
You can add person informaon to the system for further
operaons such as access control, video intercom, me and
aendance, etc. You can manage the added persons such as
issuing cards to them in a batch, imporng and exporng person
informaon in a batch, etc.
7.4.1 Add Organizaon
You can add an organizaon and import person informaon to
the organizaon for eecve management of the persons. You
can also add a surbodinate
organizaon for the added one.
Steps
1.
Enter Person module.
2.
Select a parent organizaon in the le column and click Add in
the upper-le corner to add an organizaon.
3.
Create a name for the added organizaon.
Note
Up to 10 levels of organizaons can be added.
4.
Oponal: Perform the following operaon(s).
Edit
Organizaon
Hover the mouse on an added
organizaon and click to edit its name.
Delete
Organizaon
Hover the mouse on an added
organizaon and click to delete it.
Note
•
The lower-level organizaons will be
deleted as well if you delete an
organizaon.
•
Make sure there is no person added
under the
organizaon, or the
organizaon cannot be deleted.
Show Persons
in Sub
Organizaon
Check Show Persons in Sub Organizaon
and select an organizaon to show
persons in its sub organizaons.
7.4.2 Import and Export Person Idenfy
Informaon
You can import the informaon of mulple persons to the client
soware in a batch. Meanwhile, you can also export the person
informaon and save them in your PC.
Import Person Informaon
You can enter the informaon of mulple persons in a predened
template (CSV/Excel le) to import the informaon to the client in
a batch.
Steps
1.
Enter the Person module.
2.
Select an added
organizaon in the list, or click Add in the
upper-le corner to add an organizaon and then select it.
3.
Click Import to open the Import panel.
36
4.
Select Person Informaon as the imporng mode.
5.
Click Download Template for Imporng Person to download
the template.
6.
Enter the person
informaon in the downloaded template.
Note
•
If the person has mulple cards, separate the card No. with
semicolon.
•
Items with asterisk are required.
•
By default, the Hire Date is the current date.
7.
Click to select the CSV/Excel le with person informaon
from local PC.
8.
Click Import to start imporng.
Note
•
If a person No. already exists in the client's database, delete
the exisng informaon before imporng.
•
You can import informaon of no more than 2,000 persons.
Import Person Pictures
Aer imporng face pictures for the added persons to the client,
the persons in the pictures can be idened by an added face
recognion terminal. You can either import person pictures one
by one, or import mulple pictures at a me according to your
need.
Before You Start
Be sure to have imported person
informaon to the client
beforehand.
Steps
1.
Enter the Person module.
2.
Select an added
organizaon in the list, or click Add in the
upper-le corner to add an organizaon and then select it.
3.
Click Import to open the Import panel and check Face.
4.
Oponal: Enable Verify by Device to check whether face
recognion device managed in the client can recognize the face
in the photo.
5.
Click
to select a face picture le.
Note
•
The (folder of) face pictures should be in ZIP format.
•
Each picture le should be in JPG format and should be no
larger than 200 KB.
•
Each picture
le should be named as "Person ID_Name". The
Person ID should be the same with that of the imported
person informaon.
6.
Click Import to start imporng.
The imporng progress and result will be displayed.
Export Person Informaon
You can export the added persons' informaon to local PC as a
CSV/Excel le.
37
Before You Start
•
Make sure you have added persons to an organizaon.
•
Make sure you have enabled the Export Person Informaon
funcon
to display the Export buon. See for details.
Steps
1.
Enter the Person module.
2.
Oponal: Select an organizaon in the list.
Note
All persons' informaon will be exported if you do not select
any organizaon.
3.
Click Export.
4.
Enter the super user name and password for vericaon.
The Export panel is displayed.
5.
Check Person Informaon as the content to export.
6.
Check desired items to export.
7.
Click Export to save the exported
le in CSV/Excel le on your
PC.
Export Person Pictures
You can export face picture le of the added persons and save in
your PC.
Before You Start
•
Make sure you have added persons and their face pictures to
an organizaon.
•
Make sure you have enabled the Export Person Informaon
funcon to display the Export buon. See for details.
Steps
1.
Enter the Person module.
2.
Oponal: Select an organizaon in the list.
Note
All persons' face pictures will be exported if you do not select
any organizaon.
3.
Click Export on the top menu bar.
4.
Enter the super user name and password for
vericaon.
The Export panel is displayed.
5.
Check Face as the content to export.
6.
Click Export and set an encrypon key to encrypt the exported
le.
Note
•
The exported le is in ZIP format.
•
The exported face picture is named as "Person ID_Name_0"
("0" is for a full-frontal face).
7.4.3 Get Person Informaon from Access Control
Device
38
If the access control device has been congured with person
informaon (including person details, ngerprint, and issued card
informaon), you can get the person informaon from the added
device and import them to the client for further operaons.
Steps
Note
•
If the person name stored in the device is empty, the person
name will be lled with the issued card No. aer imporng to
the client.
•
If the card number or person ID (employee ID) stored on the
device already exists in the client database, the person with
this card number or person ID will not be imported to the
client.
1.
Enter Person module.
2.
Select an organizaon to import the persons.
3.
Click Get from Device.
4.
Select an added access control device or the enrollment
staon
from the drop-down list.
Note
If you select the enrollment staon, you should click Login, and
enter IP address, port No., user name and password of the
device.
5.
Select the Geng Mode.
Note
The geng mode varies according to dierent devices. The
access control device supports geng the person informaon
by employee ID. Up to 5 employee IDs can be specied each
me.
6.
Click Import to start imporng the person informaon to the
client.
Note
Up to 2,000 persons and 5,000 cards can be imported.
The person informaon, including person details, person's
ngerprint informaon (if congured), and the linked cards (if
congured), will be imported to the selected organizaon.
7.4.4 Issue Cards to Persons in Batch
The client provides a convenient way to issue cards to mulple
persons in a batch.
Steps
1.
Enter Person module.
2.
Oponal: Select a person group, and select the persons with
no card issued.
•
The selected persons with no card issued in the person
group will be displayed in the right panel.
•
If you do not select the persons with no card issued in a
person group, all the added persons with no card issued will
be displayed in the right panel.
39
3.
Click Batch Issue Cards.
4.
Oponal: Enter key words (name or person ID) in the input box
to lter the person(s) that need issuing cards.
5.
Oponal: Click Sengs to set the card issuing parameters. For
details, refer to .
6.
Click Inialize to inialize the card enrollment staon or card
reader to make it ready for issuing cards.
7.
Click the Card No. column and enter the card number.
-
Place the card on the card enrollment
staon.
-
Swipe the card on the card reader.
-
Manually enter the card number and press the Enter key.
The person(s) in the list will be issued with card(s).
7.4.5 Report Card Loss
If the person lost his/her card, you can report the card loss so
that the card's related access authorizaon will be inacve.
Steps
1.
Enter Person module.
2.
Select the person you want to report card loss for and click Edit
to open the Edit Person window.
3.
In the Credenal → Card panel, click on the added card to
set this card as lost card.
Aer reporng card loss, the access authorizaon of this card
will be invalid and
inacve. Other person who gets this card
cannot access the doors by swiping this lost card.
4.
Oponal: If the lost card is found, you can click to cancel the
loss.
Aer cancelling card loss, the access authorizaon of the
person will be valid and acve.
5.
If the lost card is added in one access group and the access
group is applied to the device already,
aer reporng card loss
or cancelling card loss, a window will pop up to nofy you to
apply the changes to the device.
Aer applying to device, these
changes can take eect on the device.
7.4.6 Set Card Issuing Parameters
The client provides two modes for reading a card's number: via
card enrollment staon or via the card reader of the access
control device. If a card enrollment
staon is available, connect it
to the PC running the client by USB interface or COM, and place
the card on the card enrollment to read the card number. If not,
you can also swipe the card on the card reader of the added
access control device to get the card number. As a result, before
issuing a card to one person, you need to set the card issuing
parameters including the issuing mode and related parameters.
When adding a card to one person, click
Sengs to open the
Card Issuing
Sengs window.
Local Mode: Issue Card by Card Enrollment
Staon
Connect a card enrollment staon to the PC running the client.
You can place the card on the card enrollment staon to get the
card number.
Card Enrollment
Staon
40
Select the model of the connected card enrollment staon
Note
Currently, the supported card enrollment staon models
include DS-K1F100-D8, DS-K1F100-M, DS-K1F100-D8E, and DS-
K1F180-D8E.
Card Type
This eld is only available when the model is DS-K1F100-D8E or
DS-K1F180-D8E.
Select the card type as EM card or IC card according to the
actual card type.
Serial Port
It is only available when the model is DS-K1F100-M.
Select the COM the card enrollment
staon connects to.
Buzzing
Enable or disable the buzzing when the card number is read
successfully.
Card No. Type
Select the type of the card number according to actual needs.
M1 Card Encrypon
This eld is only available when the model is DS-K1F100-D8,
DS-K1F100-D8E, or DS-K1F180-D8E.
If the card is M1 card, and if you need to enable the M1 Card
Encrypon funcon, you should enable this funcon and select
the sector of the card to encrypt.
Remote Mode: Issue Card by Card Reader
Select an access control device added in the client and swipe the
card on its card reader to read the card number.
7.5 Congure Schedule and Template
You can congure the template including holiday and week
schedule. Aer seng the template, you can adopt the
congured template to access groups when seng the access
groups, so that the access group will take eect in the me
duraons
of the template.
Note
For access group sengs, refer to Set Access Group to Assign
Access Authorizaon to Persons.
7.5.1 Add Holiday
You can create holidays and set the days in the holidays, including
start date, end date, and holiday duraon in one day.
Steps
Note
You can add up to 64 holidays in the soware system.
1.
Click Access Control → Schedule → Holiday to enter the
Holiday page.
2.
Click Add on the
le panel.
41
3.
Create a name for the holiday.
4.
Oponal: Enter the descripons or some nocaons of this
holiday in the Remark box.
5.
Add a holiday period to the holiday list and
congure the
holiday duraon.
Note
Up to 16 holiday periods can be added to one holiday.
1) Click Add in the Holiday List eld.
2) Drag the cursor to draw the me duraon, which means in
that
duraon of me, the congured access group is
acvated.
Note
Up to 8 me duraons can be set to one holiday period.
3) Oponal: Perform the following operaons to edit the me
duraons.
•
Move the cursor to the me duraon and drag the me
duraon on the meline bar to the desired posion when
the cursor turns to .
•
Click the me duraon and directly edit the start/end me
in the appeared dialog.
•
Move the cursor to the start or the end of me duraon and
drag to lengthen or shorten the me duraon when the
cursor turns to .
4) Oponal: Select the me duraon(s) that need to be
deleted, and then click in the Operaon column to delete
the selected me duraon(s).
5)
Oponal: Click in the Operaon column to clear all the
me duraon(s) in the me bar.
6)
Oponal: Click in the Operaon column to delete this
added holiday period from the holiday list.
6.
Click Save.
7.5.2 Add Template
Template includes week schedule and holiday. You can set week
schedule and assign the me duraon of access authorizaon for
dierent person or group. You can also select the added
holiday(s) for the template.
Steps
Note
You can add up to 255 templates in the soware system.
1.
Click Access Control → Schedule → Template to enter the
Template page.
Note
There are two default templates: All-Day Authorized and All-
Day Denied, and they cannot be edited or deleted.
All-Day Authorized
The access authorizaon is valid in each day of the week and
it has no holiday.
42
All-Day Denied
The access authorizaon is invalid in each day of the week
and it has no holiday.
2.
Click Add on the le panel to create a new template.
3.
Create a name for the template.
4.
Enter the descripons or some nocaon of this template in
the Remark box.
5.
Edit the week schedule to apply it to the template.
1) Click Week Schedule tab on the lower panel.
2) Select a day of the week and draw
me duraon(s) on the
meline bar.
Note
Up to 8 me duraon(s) can be set for each day in the week
schedule.
3) Oponal: Perform the following operaons to edit the me
duraons.
•
Move the cursor to the me duraon and drag the me
duraon on the meline bar to the desired posion when
the cursor turns to .
•
Click the me duraon and directly edit the start/end me
in the appeared dialog.
•
Move the cursor to the start or the end of
me duraon and
drag to lengthen or shorten the
me duraon when the
cursor turns to .
4) Repeat the two steps above to draw more
me duraons on
the other days of the week.
6.
Add a holiday to apply it to the template.
Note
Up to 4 holidays can be added to one template.
1) Click Holiday tab.
2) Select a holiday in the le list and it will be added to the
selected list on the right panel.
3)
Oponal: Click Add to add a new holiday.
Note
For details about adding a holiday, refer to Add Holiday.
4) Oponal: Select a selected holiday in the right list and click
to remove the selected one, or click Clear to clear all the
selected holiday(s) in the right list.
7.
Click Save to save the
sengs and nish adding the template.
7.6 Set Access Group to Assign Access
Authorizaon to Persons
Aer adding the person and conguring the person's credenals,
you can create the access groups to dene which person(s) can
get access to which door(s) and then apply the access group to
the access control device to take
eect.
43
Steps
When the access group sengs are changed, you need to apply
the access groups to the devices again to take eect. The access
group changes include changes of template, access group
sengs, person's access group sengs, and related person
details (including card number, face picture, linkage between card
number and linkage between card number and card password,
card eecve period, etc).
1.
Click Access Control → Authorizaon → Access Group to enter
the Access Group interface.
2.
Click Add to open the Add window.
3.
In the Name text eld, create a name for the access group as
you want.
4.
Select a template for the access group.
Note
You should congure the template before access group
sengs. Refer to Congure Schedule and Template for details.
5.
In the le list of the Select Person eld, select person(s) to
assign access authority.
6.
In the le list of the Select Access Point eld, select door(s),
door staon(s) or oor(s) for the selected persons to access.
7.
Click Save.
You can view the selected person(s) and the selected access
point(s) on the right side of the interface.
Figure 7-2 Display the Selected Person(s) and Access Point(s)
8.
Aer adding the access groups, you need to apply them to the
access control device to take eect.
1) Select the access group(s) to apply to the access control
device.
2) Click Apply All to Devices start applying all the selected
access group(s) to the access control device or door
staon.
3) Click Apply All to Devices or Apply Changes to Devices.
Apply All to Devices
This
operaon will clear all the existed access groups of
the selected devices and then apply the new access group
to the device.
Apply Changes to Devices
This
operaon will not clear the existed access groups of
the selected devices and only apply the changed part of
the selected access group(s) to the device(s).
44
4) View the applying status in the Status column or click
Applying Status to view all the applied access group(s).
Note
You can check Display Failure Only to lter the applying
results.
The selected persons in the applied access groups will have the
authorizaon to enter/exit the selected doors/door staons
with their linked card(s).
9.
Oponal: Click to edit the access group if necessary.
Note
If you change the persons' access informaon or other related
informaon, you will view the prompt Access Group to Be
Applied on the right corner of the client.
You can click the prompt to apply the changed data to the
device. You can select either Apply Now or Apply Later.
Figure 7-4 Data Synchronizaon
7.7 Congure Advanced Funcons
You can congure the advanced funcons of access control to
meet some special requirements in
dierent scene.
Note
•
For the card related funcons(the type of access control card),
only the card(s) with access group applied will be listed when
adding cards.
•
The advanced funcons should be supported by the device.
•
Hover the cursor on the Advanced
Funcon, and then Click
to customize the advanced funcon(s) to be displayed.
7.7.1 Congure Device Parameters
Aer adding the access control device, you can congure the
parameters of access control device, access control points.
Congure Parameters for Access Control Device
Aer adding the access control device, you can congure its
parameters, including overlaying user informaon on picture,
uploading pictures aer capturing, saving captured pictures, etc.
Before You Start
Add access control device to the client.
Steps
1.
Click Access Control → Advanced
Funcon → Device
Parameters .
45
Note
If you can not nd Device Parameter in the Advanced Funcon
list, hover the cursor on the Advanced Funcon, and then Click
to select the Device Parameter to be displayed.
2.
Select an access device to show its parameters on the right
page.
3.
Turn the switch to ON to enable the corresponding
funcons.
Note
•
The displayed parameters may vary for dierent access
control devices.
•
Some of the following parameters are not listed in the Basic
Informaon page, click More to edit the parameters.
Enable NFC
If enable the funcon, the device can recognize the NFC
card. You can present NFC card on the device.
Enable M1 Card
If enable the funcon, the device can recognize the M1 card.
You can present M1 card on the device.
Enable EM Card
If enable the funcon, the device can recognize the EM card.
You can present EM card on the device.
4.
Click OK.
5.
Oponal: Click Copy to, and then select the access control
device(s) to copy the parameters in the page to the selected
device(s).
Congure Parameters for Door/Elevator
Aer adding the access control device, you can congure its
access point (door or
oor) parameters.
Before You Start
Add access control device to the client.
Steps
1.
Click Access Control → Advanced
Funcon → Device
Parameter .
2.
Select an access control device on the
le panel, and then click
to show the doors or oors of the selected device.
3.
Select a door or
oor to show its parameters on the right page.
4.
Edit the door or oor parameters.
Note
•
The displayed parameters may vary for dierent access
control devices.
•
Some of the following parameters are not listed in the Basic
Informaon page, click More to edit the parameters.
Name
Edit the card reader name as desired.
Exit Buon Type
46
You can set the exit buon as remaining closed or remaining
open. Usually, it is remaining open.
Open Duraon
The door contact can be enabled with appropriate delay
aer person with extended access needs swipes her/his
card.
5.
Click OK.
6.
Oponal: Click Copy to , and then select the door/oor(s) to
copy the parameters in the page to the selected doors/oor(s).
Note
The door or oor's status duraon sengs will be copied to
the selected door/oor(s) as well.
Congure Parameters for Card Reader
Aer adding the access control device, you can congure its card
reader parameters.
Before You Start
Add access control device to the client.
Steps
1.
Click Access Control → Advanced
Funcon → Device
Parameter .
2.
In the device list on the le, click to expand the door, select a
card reader and you can edit the card reader's parameters on
the right.
3.
Edit the card reader basic parameters in the Basic
Informaon
page.
Note
•
The displayed parameters may vary for dierent access
control devices. There are part of parameters listed as
follows. Refer to the user manual of the device for more
details.
•
Some of the following parameters are not listed in the Basic
Informaon page, click More to edit the parameters.
Name
Edit the card reader name as desired.
Card Authencaon Interval
The me interval between two connuous card recognions
when authencang.
Repeated Authencaon Interval
Within the specied interval, repeated authencaon of the
same card number (uploaded by dierent devices) is invalid,
and only one
authencaon is performed.
Enable Failed Aempts Limit of Authencaon/Max. Failed
Aempts for Authencaon
Enable to report alarm when the card reading aempts
reach the set value.
Card Reader Type/Card Reader Descripon
Get card reader type and descripon. They are read-only.
4.
Click OK.
47
5.
Oponal: Click Copy to, and then select the card reader(s) to
copy the parameters in the page to the selected card reader(s).
Congure Parameters for Alarm Output
Aer adding the access control device, if the device links to alarm
outputs, you can
congure the parameters.
Before You Start
Add access control device to the client, and make sure the device
supports alarm output.
Steps
1.
Click Access Control → Advanced Funcon → Device
Parameter to enter access control parameter conguraon
page.
2.
In the device list on the
le, click to expand the door, select
an alarm input and you can edit the alarm input's parameters
on the right.
3.
Set the alarm output parameters.
Name
Edit the card reader name as desired.
Alarm Output
Acve Time
How long the alarm output will last aer triggered.
4.
Click OK.
5.
Oponal: Set the switch on the upper right corner to ON to
trigger the alarm output.
Congure Parameters for Lane Controller
Aer adding the lane controller to the client, you can congure its
parameters for passing through the lane.
Before You Start
Add access control device to the client.
Steps
1.
Click Access Control → Advanced
Funcon → Device
Parameter to enter Parameter
Sengs page.
2.
In the device list on the le, select a lane controller and you
can edit the lane controller's parameters on the right.
3.
Edit the parameters.
Passing Mode
Select the controller which will control the barrier status of
the device.
Alarm Voice Prompt Time
Duraon
Set how long the audio will last, which is played when an
alarm is triggered .
Note
0 refers to the alarm audio will be played unl the alarm is
ended.
Temperature Unit
Select the temperature unit that displayed in the device
status.
Lightboard Brightness
Adjust the brightness of the device light.
48
Memory Mode
Mulple cards presenng for mulple persons passing is
allowable when enabling the memory mode. When the
passing person's number exceeds the card presenng
number, or aer the latest person passing with no other
person passing within the door open duraon, the door will
closed automacally.
4.
Click OK.
7.7.2 Congure Device Parameters
Aer adding the access control device, you can set its parameters
such as network parameters.
Set RS-485 Parameters
You can set the access control device's RS-485 parameters
including the baud rate, data bit, the stop bit, parity type,
ow
control type, communicaon mode, work mode, and connecon
mode.
Before You Start
Add access control device to the client, and make sure the device
supports RS-485 interface.
Steps
1.
Enter the Access Control module.
2.
On the
navigaon bar on the le, enter Advanced Funcon →
More Parameters .
3.
Select an access control device in the device list and click
RS-485 to enter the RS-485 Sengs page.
4.
Select the serial port number from the drop-down list to set
the RS-485 parameters.
5.
Set the baud rate, data bit, the stop bit, parity type, and
connecon mode in the drop-down list.
6.
Click Save.
•
The
congured parameters will be applied to the device
automacally.
•
When you change the connecon mode, the device will
reboot automacally.
Enable M1 Card Encrypon
M1 card encrypon can improve the security level of
authencaon.
Steps
Note
The funcon should be supported by the access control device
and the card reader.
1.
Enter the Access Control module.
2.
On the
navigaon bar on the le, enter Advanced Funcon →
More Parameters .
3.
Select an access control device in the device list and click M1
Card
Encrypon to enter the M1 Card Encrypon page.
4.
Set the switch to on to enable the M1 card
encrypon
funcon.
5.
Set the sector ID.
49
The sector ID ranges from 1 to 100.
6.
Click Save to save the sengs.
7.8 Door Control
In Monitoring module, you can view the real-me status of the
doors managed by the added access control device. You can also
control the doors such as open/close the door, or remain the
door open/closed via the client remotely. The
real-me access
event are displayed in this module. You can view the access
details and person details.
Note
For the user with door control permission, the user can enter the
Monitoring module and control the door. Or the icons used for
control will not show. For seng the user permission, refer to
Person Management.
7.8.1 Control Door Status
You can control the status for the door(s), including unlock door,
locking door, remaining the door unlock, remaining the door
locked, remain all unlocked, etc.
Before You Start
•
Add person and assign access
authorizaon to designed
person, and person will have the access authorizaon to the
access points (doors). For details, refer to Person Management
and Set Access Group to Assign Access
Authorizaon to
Persons.
•
Make sure the operaon user has the permission of the access
points (doors).
Steps
1.
Click Monitoring to enter the status monitoring page.
2.
Select an access point group on the upper-right corner.
Note
For managing the access point group, refer to Group
Management.
The doors in the selected access control group will display.
3.
Click a door icon to select a door, or press Ctrl and select
mulple doors.
Note
For Remain All Unlocked and Remain All Locked, ignore this
step.
4.
Click the following
buons to control the door.
Unlock Door
When the door is locked, unlock it and it will be open for
once.
Aer the open duraon, the door will be closed and
locked again automacally.
Lock Door
When the door is unlocked, lock it and it will be closed. The
person who has the access
authorizaon can access the
door with credenals.
Remain Unlocked
50
The door will be unlocked (no maer closed or open). All the
persons can access the door with no credenals required.
Remain Locked
The door will be closed and locked. No person can access
the door even if he/she has the authorized credenals,
except the super users.
Remain All Unlocked
All doors in the group will be unlocked (no maer closed or
open). All the persons can access the doors with no
credenals required.
Remain All Locked
All doors in the group will be closed and locked. No person
can access the doors even if he/she has the authorized
credenals, except the super users.
Capture
Capture a picture manually.
Note
The Capture buon is available when the device supports
capture funcon. The picture is saved in the PC running the
client.
Remotely Unlocking Door Staon
When the group includes door staons, you can check Lock1
or Lock2, then click Unlock Door to unlock the door staon.
Note
By default, Lock1 is checked for door staons.
Refresh Status
Click Refresh Status to get the door's newest status.
Result
The icon of the doors will change in real-me according to the
operaon if the operaon is succeeded.
7.8.2 Check Real-Time Access Records
The real-me access records can be displayed in the client,
including card swiping records, face recognion records, skin-
surface temperature
informaon, etc. Also, you can view the
person informaon and view the picture captured during access.
Before You Start
You have added person(s) and access control device(s) to the
client. For details, refer to Person Management and Add Device.
Steps
1.
Click Monitoring to enter monitoring module.
Real-me access records are displayed on the boom of the
page. You can view record details, including card No., person
name, event
me, door locaon, temperature, authencaon
type etc.
51
Figure 7-5 Real-me Access Records
Note
You can right click the column name of access event table to
show or hide the column according to actual needs.
2.
Oponal: Select an access point group from the drop-down list
in the upper-right corner to show the real me access records
of the selected group.
3.
Oponal: Check the event type and event status.
The detected events of checked type and status will be
displayed in the list below.
4.
Oponal: Check Show Latest Event to view the latest access
record.
The record list will be listed reverse chronologically.
5.
Oponal: Check Enable Abnormal Temperature Prompt to
enable abnormal skin-surface temperature prompt.
Note
When enabled, if there is abnormal temperature informaon,
an Abnormal Temperature window pops up when you enter
Monitoring module, displaying person's picture, skin-surface
temperature, card No., person name, etc.
6.
Oponal: Click an event to view person pictures (including
captured picture and
prole).
Note
In Linked Capture Picture eld, you can double click the
captured picture to view an enlarged picture.
7.
Oponal: Click to view details (including person's detailed
informaon and the captured picture).
Note
In the pop-up window, you can click to view details in full
screen.
52
A. DIP Switch
53
A.1 DIP Switch Descripon
The DIP switch is on the access control board. No.1 and No 2 is
from the low bit to the high bit.
Figure A-1 DIP Switch
When the switch is towards ON, it means the switch is enabled,
otherwise, the switch is
o.
54
B. Buon Conguraon Descripon
Refer to the table below for device conguraon via buon on
the lane control board.
Level-1 Conguraon
No.
Descripon
Level-1 Conguraon
No. and Funcons
3 Passing Mode
1-Both sides under
control
Note
By default, 1 will be
displayed on the
display screen.
2-Entrance under
control; exit
prohibited
3-Entrance under
control; exit free
4-Both sides free
5-Entrance free; exit
under control
6-Entrance free; exit
prohibited
7-Both sides
prohibited
8-Entrance prohibited;
exit under control
9-Entrance prohibited;
exit free
4
Memory Mode
1-Disable
2-Enable
Note
By default, 2 will be
displayed on the
display screen.
9 Enter Duraon
5-5s，6-6s，7-7s, ...,
60-60s
Note
By default, 5 will be
displayed on the
display screen.
10 Exit Duraon
5-5s，6-6s，7-7s, ...,
60-60s
Note
By default, 5 will be
displayed on the
display screen.
39 Brightness of Light
0-0，1-1，2-2, … , 10-
10
55
Level-1 Conguraon
No.
Descripon
Level-1 Conguraon
No. and Funcons
Note
By default, 6 will be
displayed on the
display screen.
42
Clearing People
Counng
1-Default
2-Enable
Note
By default, 1 will be
displayed on the
display screen.
43 Fire Protecon Type
1-Remain Closed
2-Remain Open
Note
By default, 2 will be
displayed on the
display screen.
99 Restore to Default
1-Default
2-Enable
Note
By default, 1 will be
displayed on the
display screen.
56
C. Event and Alarm Type
Event Alarm Type
Passing Timeout None
57
D. Error Code Descripon
The turnsle will display the error code on the seven-segment
display if error occurred. Refer to the table below to nd the
descripon of each number.
Error Reason Code Error Reason Code
Oponal Board Oine
(If the board is not
installed, the error
code of "49" or "59"
will appear but the
device funcons
normally)
49/59 Obstrucon 55
Encoder Excepon 57 Motor Excepon 58
58
