BUTANE HEAT GUN
MODEL NO: AK2975
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
IMPORTANT: Read these instructions for use carefully to familiarize yourself with the appliance before connecting it to its gas
cartridge or gas cylinder. Keep these instructions for future reference.
9 Assemblyandadjustmentmadeinthefactoryshallnotbemodied.Itcanbedangeroustotrytomodifytheadjustmentorthe
construction of the appliance, to dismantle some parts or to use components other than those recommended.
8 DO NOT use grease or oil with parts in contact with oxygen.
9 Connectthecontainersinawell-ventilatedplace,inaameorignition-sourcefreeatmosphere,farfromotherpersons.
8 DO NOT smoke when changing containers.
9 Disconnect the containers if the appliance is not to be used for a prolonged period or in the case of transport by vehicle.
9 Store and transport with the containers upright.
9 Keep away from children.
9 Use only in a well-ventilated area.
8 DO NOT use the appliance if it has damaged or worn seals.
8 DO NOT use an appliance which is leaking, damaged or which does not operate properly.
9 Usetheproductawayfromammablematerials.
9 Check the seals (between the appliance and the gas cartridge) are in place and in good condition before connecting gas cartridge.
9 Gas cartridge shall be changed in a well-ventilated location, preferably outside, away from any sources of ignition, such as naked
ames,pilots,electricresandawayfromotherpeople.
9 Ifthereisaleakonyourappliance(smellofgas),takeitoutsideimmediatelyintoawellventilatedamefreelocationwheretheleak
maybedetectedandstopped.Ifyouwishtocheckforleaksonyourappliance,doitoutside.Donottrytodetectleaksusingaame,
use soapy water.
9 The appliance must be used in a well-ventilated location in accordance with national requirements, for the supply of combustion air
andtoavoidthedangerousbuildingupofun-burntgasesforappliancesnotttedwithaamesupervisiondevice.
9 Check that the connection (between the appliance and the gas cartridge are in place and in good condition before connecting to
the gas cartridge. Ensure that the safety trigger is fully engaged before loading a gas cartridge.
9 Itcanbedangeroustousecontainersotherthanthoserecommended.Onlyusewithgascartridgesprovided.
8 DO NOT use an appliance which shows any damage.
1.1. SPECIFIC OPERATIONAL SAFETY
8 DO NOT put an ignited heat gun down.
9 Be careful not to heat the gas containers.
8 DO NOT work in an enclosed space; maintain good ventilation. Operate at least 500mm away from any adjacent surfaces.
9 Work only in a clean place, far from combustible or greased materials. Wear non-greased clothes.
8 DO NOT use any gas container other than those provided with the unit.
9 Avoid breathing welding/soldering fumes.
9 Allow the heat gun to cool before stowing away.
8 DO NOT modify the appliance.
9 Useonlyspeciedspareparts.
9 Never use an appliance with a damaged part.
9 Wear eye and hand protection.
9 Failuretousetheheatguncorrectlymayresultinre,damageand/orpersonalinjury.
8 DO NOT look into the heat gun outlet when igniting.
8 DO NOT leave a lit heat gun unattended.
8 DO NOT get the heat gun wet or attempt to cool it with water.
CAUTION!Containsammablegasunderpressure.
8 DO NOTstorenearnakedamesorcombustiblematerials.
9 Use only high quality butane gas.
8 DO NOTusetheheatgunfor5minutesafterrellinginordertoallowanyresidualgastodisperse.
WARNING!Butaneishighlyammable,handlewithcare.
8 DO NOT drop puncture or incinerate.
8 DO NOT store or operate at temperatures above 50°C.
Refer to
instruction
manual
Wear eye
protection
Wear protective
gloves
AK2975Issue:116/10/24
Original Language Version
© Jack Sealey Limited
Warning hot
surface
2. INTRODUCTION
Butanepoweredamelessheatgunwithpiezoelectricignition.Quicklyheatsupto500°Cin15seconds,reachingamaximum
temperatureof600°C.Continuousheatoutputforupto30mins.Cartridgestyleremovablesaferellsystem.Featuresheatcage
design and trigger safety lock for added user protection. Gun can also stand vertically for hands-free use. Suitable for a number of
applications including heat shrinking, paint and label removal, automotive repair, loosening rusted bolts, plastic bending and more.
Supplied in a storage case with three nozzles and spare gas cartridge.
3. SPECIFICATION
Model No: ................................................................. AK2975
Height: .......................................................................215mm
Run Time: ...................................................................30mins
Weight: ........................................................................ 1.30kg
4. CONTENTS
5. OPERATION
5.1. SAFETY TRIGGER Refer to gs.1 & 2
5.1.1. Release trigger A by moving latch to the left or right.
5.2. IGNITION: Depress trigger to light the heat gun. Flaring may occur during warm-up
ifthetorchisover-lledormovedabruptly.
5.3. CONTINUOUS GAS FLOW: depress trigger lock B whilst depressing trigger.
5.4. TURN OFF (EXTINGUISH): Press trigger A and release.
5.5. FILL GAS CANNISTER
5.5.1. Removerefertog.3andinvert,refertog.4,theninsertthegascontainer’s
nozzleverticallyintothellingvalvefromabove.
8 DO NOTattempttollfromunderneath,g.4.
8 DO NOT use heat gun for 5 minutes in order to let residual gas disperse.
5.5.2. Gasconsumptionperrell60g/h.
5.6. STAND Refer to g.5
5.6.1. Pull tabs out and to stand heat
gun upright.
5.7. ACCESSORIES g.1:
Slide the accessories over the end
of the hot air outlet.
NOTE: Allow to cool before
removing and storing in case.
fig.
2
fig.
3
fig.
4
fig.
5
fig.
1
Original Language Version
© Jack Sealey Limited
AK2975Issue:116/10/24
Ref: Description
A Trigger
B Triggerlock(continuousow)
C Hot air outlet
D Heat guard
E Gas cannister
F Stand
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note:Itisourpolicytocontinuallyimproveproductsandassuchwereservetherighttoalterdata,specificationsandcomponentparts
without prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty:Guaranteeis36monthsfrompurchasedate,proofofwhichisrequiredforanyclaim.
6. MAINTENANCE
6.1. REFILL
6.1.1. Fillonlywithbutanegas.Itmaybehazardoustoattempttotothertypesofgas.
6.1.2. Rellinawell-ventilatedarea,awayfromame,combustiblematerialsandanotherperson.
6.1.3. Pleasemakesuretheunitisobeforerelling.
6.1.4. Placingthesolderingironinanupside-downposition,Insertthegascanisterintothetorchrellingvalve.
6.1.5. Fill slowly. DO NOToverll.Whengasstartstooverowstoplling
6.1.6. Afterlling,wipelighterandhandsdrybeforeigniting.
6.1.7. Therellingoperationtakessomeminutestoallowthegastostabilize.
6.1.8. Fornextrelling,letthetorchcooldownfor5Minutesbeforellingthetank.
6.2. REPLACEMENT OR INSTALLATION OF ATTACHMENTS
WARNING! Always leave to cool completely the tool before to remove or replace the inserts.
6.2.1. Be sure to use the attachment right for the job you want to do.
6.2.2. Useonlytheattachmentthattperfectlyonthetool.TheattachmentthatDO NOTtperfectlycanresultinuncontrolledand
dangerousame.
6.3. CLEANING
6.3.1. Turnotheheatgunandletitcoolcompletelybeforecleaning.
6.3.2. Clean the gun and attachments with a damp cloth or sponge when still warm. DO NOT use solvents.
6.4. STORAGE
6.4.1. DO NOT store at ambient temperatures greater than 50
o
C.
6.4.2. Store in dry environment.
.
