MICRO BUTANE HOT AIR BLOWER/HEATING
TORCH – HEAT SHRINK TUBE
MODEL NO: AK2974
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS &
CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO
SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE
FOR FUTURE USE.
1. SAFETY
9 Read these instructions before use.
9 Keep the torch out of reach of children.
9 Use only puried butane gas as fuel.
9 To avoid overheating the torch, allow short rest periods between each minute of uninterrupted use.
8 DO NOT run the torch for more than 3 minutes at a time.
9 Before attempting to remove the torch cap to replace the fuel cartridge, always allow the ame
nozzle to cool.
9 Keep your hands and face away from the torch when in use. The ame is dicult to see.
9 Always use the tool in a well ventilated place away from ammable and explosive products.
9 The ame nozzle becomes very hot. DO NOT let it touch your hands or combustible materials
during or after use until it has cooled.
8 DO NOT leave in direct sunlight or areas where a stove or heater generates high temperatures.
Always keep it at less than 104
o
F (40
o
C).
NOTE: if the temperature is too cold or insucient oxygen is available, the ame will not
ignite. The torch may not ignite in extreme temperatures due to the eect on the gas pressure.
Continuously holding the torch downwards may extinguish the ame.
2. INTRODUCTION
Professional micro design featuring piezoelectric ignition. Comfortable grip enables a simple
one-handed operation. Hot air blower and ame dual function with adjustable heat levels,
reaching up to 650°C. 10ml gas capacity giving up to 40mins of constant use. Includes 10mm
diameter nozzle suitable for working with heat shrink tubes. Portable design ideal for remote
jobs and heat shrinking in tight spaces. Supplied with heat deector and useful set of commonly
used heat shrink tubes (Sizes: Ø2, Ø2.5, Ø4, Ø5). Powered by Butane (lighter uid).
3. SPECIFICATION
MODEL NO: AK2974
Height: 110mm Nett Weight: 0.071kg
4. OPERATION
4.1. REFILLING (FIG.2)
4.1.1. Allow to cool before relling with high quality butane gas.
4.1.2. Hold the torch upside-down.
4.1.3. Invert universal gas rell and place nozzle into lling valve (g.1 - C).
4.1.4. Push down to pump the gas into the torch.
8 DO NOT overll the torch. Wait at least 2 minutes after relling before using the torch.
4.2. IGNITING
4.2.1. Before igniting the torch, make sure you are in a well ventilated place or outside away from any ammable or dangerous products.
4.2.2. Press the ignition button (g.1 - A) on the back of the torch to ignite.
4.2.3. To turn o the torch, simply release the ignition button.
4.2.4. In order to keep the ame going, you have to hold the ignition button down.
4.3. OPERATING FOR HOT AIR & HEAT SHRINK
4.3.1. Hot air: screw on the hot blower. Ignite the mini blow torch for hot air.
4.3.2. Heat shrink: screw on hot blower. Put the scoop under the hot blower. After igniting mini blow torch, you may use with heat shrink tubes
for shrinking work.
4.4. GAS LEVER
4.4.1. Gas lever (g.1 - B) is to adjust gas pressure to suit in dierent operating conditions - move right for high pressure, left for low pressure.
5. MAINTENANCE
8 DO NOT dismantle any parts of the blow torch as this may cause damage/malfunction.
Refer to
instructions
Wear eye
protection
AK2974 Issue 1 02/04/24
Original Language Version
© Jack Sealey Limited
FIG.1
FIG.2
WARNING!
Hot Surfaces
Wear protective
gloves
AK2974 Issue 1 02/04/24
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts without prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 36 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any uids (if applicable) into approved
containers and dispose of the product and uids according to local regulations.
