3-IN-1 BUTANE INDEXING SOLDERING IRON

MODEL NO: AK2970

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these

instructions, and properly maintained, give you years of trouble free performance.

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE

THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR

PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.

1. SAFETY

 WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using this

 equipment,makesureyouknowwherethenearestreextinguisheris.

 WARNING!Alwayswearapprovedeye/faceprotectionwhenoperatingthetorch.

 WARNING! DO NOTusethetorchifyounoticethatitisdamagedoriftherecouldbeagasleakfromit.

 WARNING!Butanegasisextremelyammable,handlewithcare.

 WARNING!Alwayspointthetorchawayfromtheeyesandbodywhenignitingandduringoperation.

 WARNING! DO NOT put the torch down when it is lit, DO NOTleaveitunattended.

 WARNING!Theameisnoteasilyvisibleinbrightdaylight.

 WARNING!Ensuretheameiscompletelyextinguishedafteruse.DO NOTusewatertocoolthetorchdown.

 WARNING!Onlyuseinawellventilatedarea.

8 DO NOTusethetorchinanareawherepaintfumes,solventsorotherammablesolids,liquidsorgasesposeapotentialhazard.

 Keepammablematerialawayfromthetorchwhenoperating.

8 DO NOToperatethetorchwhenyouaretiredorundertheinuenceofalcohol,drugsorintoxicatingmedication.

8 DO NOTholdanyworkpiecebyhand.

8 DO NOTtouchtheworkpiececlosetotheheatedareaasitwillbeveryhot.Allowtocool.

8 DO NOToperatethetorchifitisdamagedasthismaycausefailureand/orpossiblepersonalinjury.

8 DO NOTtouchthetopofthetorchduringorimmediatelyafteruse,asitwillbeveryhot.Allowtocool.

8 DO NOTallowchildrentooperatethetorch.

9  Afteruse,allowthetorchtocoolbeforestoringit.

9  Whennotinuse,storeawayfromdirectsunlightinasafe,dry,childprooflocation.

8 DO NOTstoreatover40°C,suchasinacarinhotweather.

8 DO NOTmodifytheappliance.

9  Theapplianceshouldbeoperatedawayfromammablematerials

9  Whenlled,itwillcontainammablegasunderpressure

8 DO NOTpunctureorputinre.

9  Makesurethereiso󰀨beforerelling.

8 DO NOTkeeplitformorethan5minutes.

9  Makesurethereiso󰀨beforerelling.

9  Allowthemicrotorchtocooldownbeforestorage.Storingtheapplianceinwellventilatedareaandensuretheameisoverafterthe

 operation.

9  UseonlySealeyoriginalspareparts.

8 DO NOTusetorchasacigarettelighter.

9  Beextracarefulwhenusingthetorchoutdoorsonsunnyorwindydays.Windmaycarrythetorch’sheatbacktowardyouorother

 areaswhicharenotintendedtobeheated.

9  Alwayschecktomakesurenounintendedpartsormaterialsarebeingheated.

9  Wheneverthereisapossibilitythatunintendedmaterialhasbeenheated,waitatleasttwohoursbeforeleavingthearea.

8 DO NOTinhalesolderingfumes.

9  Followrellingproceduretoavoidseriousaccidents.

2. INTRODUCTION

3-in-1devicethatcanbeusedforheating,solderingandshrinking.Fittedwithindexingheadforthreedi󰀨erentpositionsaswellasmagnetic

stand.Poweredbybutane(lighterfuel)andfeaturesapiezoelectricignitionswitch.Viewingwindowatbottomofdevicetomonitorfuel.Flame

temperature1300°C,solderingtemperature450°Candhotairtemperatureof600°C(Approximately).60-75Minuteruntimewith30mlfuel

capacity.

3. SPECIFICATION

MODEL NO: ............................................................. AK2970

Height:....................................................................... 260mm

AK2970Issue116/07/2020

Original Language Version

Refer to

instructions

Hot surfaces Wear eye

protection

Wear protective

gloves

4. OPERATION

4.1.  Thetipoftheappliancecanbeadjustedto3di󰀨erentdegreesofangle.Pressthe

 inclineadjustmentbutton(g.1.1)andpositiontheapplianceheadaccordingtothe

 desiredinclination.

4.2.  Pressthesafetylockbutton(g.1.2)andatthesametimelowertheignitionlever

 (g.1.3)usingyourthumb.Thisactionwillignitetheappliance.

NOTE: Thebutaneamemaybebarelyvisibleincertainlightconditions.

4.3.  Holdtheignitionlever(g.1.3)andreleasethesafetylockbutton(g.1.2).

4.4.  Movethecontinuousameswitch(g.1.4)totherightforaconstantame.

4.5.  Adjusttheamepowerbymovingtheadjustmentlever(g.1.5)totherighttoincreasethepowerortothelefttodecreaseit.

4.6.  Toswitcho󰀨theappliance,movethecontinuousameswitch(g.1.4)totheleft,thiswillcuto󰀨thegassupplyandextinguishthe

 ame.

4.7.  Ensureameisextinguishedandgasiso󰀨aftereachuse.

4.8.  Stoptheoperationevery5minutestocoolthetool.

5. MAINTENANCE

5.1. REFILL

5.1.1. Fillonlywithbutanegas.Itmaybehazardoustoattempttotothertypesofgas.

5.1.2. Rellinawell-ventilatedarea,awayfromame,combustiblematerialsandanotherperson.

5.1.3. Pleasemakesurethereiso󰀨beforerelling.

5.1.4. Placingthesolderingironinanupside-downposition,Insertthegascanisterintothetorchrellingvalve.

5.1.5. Fillslowly.DO NOToverll.WhengasstarttoFlowout,stoplling

5.1.6. Afterlling,wipelighterandhandsdrybeforeIgniting.

5.1.7. Therellingoperationtakessomeminutestoallowthegastostabilize.

5.1.8. Fornextrelling,letthetorchcooldownfor5Minutesbeforellingthetank.

5.2. REPLACEMENT OR INSTALLATION OF INSERTS

 WARNING!ALWAYSLEAVETOCOOLCOMPLETELYTHETOOLBEFORETOREMOVEORREPLACETHEINSERTS.

5.2.1. Besuretousetheinsertrightforthejobyouwant.

5.2.2. Useonlytheinsertsthattperfectlyonthetool.TheinsertsthatDO NOTtperfectlycanresultinuncontrolledanddangerous 

 ame.Removethetipbyturningtheringnut(g.1.6)anticlockwise.Removethetipandinstallthedesiredone.Tightenwiththe 

 ringnut(g.1.6)byturningitclockwise.

5.2.3. Tightentheinsertssecurely.Forthecompletelyheatingoftheinsertsitisnecessarytowaitfor25seconds.

5.3. CLEANING

5.3.1. Turno󰀨thesolderingironandletitcoolcompletelybeforecleaning.

5.3.2. Theoutsideunitcanbecleanedwithadampclothwithalittlemilddetergent.

5.3.3. Cleanthetiponthespongewhenitisstillwarm.

g.1

Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR

01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk

ENVIRONMENT PROTECTION

Recycleunwantedmaterialsinsteadofdisposingofthemaswaste.Alltools,accessoriesandpackagingshouldbesorted,takento

arecyclingcentreanddisposedofinamannerwhichiscompatiblewiththeenvironment.Whentheproductbecomescompletely

unserviceableandrequiresdisposal,drainanyfluids(ifapplicable)intoapprovedcontainersanddisposeoftheproductandfluids

accordingtolocalregulations.

WEEE REGULATIONS

Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment

(WEEE).Whentheproductisnolongerrequired,itmustbedisposedofinanenvironmentallyprotectiveway.Contactyourlocalsolid

wasteauthorityforrecyclinginformation.

Note:Itisourpolicytocontinuallyimproveproductsandassuchwereservetherighttoalterdata,specificationsandcomponentpartswithoutprior

notice.

Important:NoLiabilityisacceptedforincorrectuseofthisproduct.

Warranty:Guaranteeis12monthsfrompurchasedate,proofofwhichisrequiredforanyclaim.

AK2970Issue116/07/2020

Original Language Version
