Sealey SDL10 Rechargeable Soldering Iron 12W User Manual

12W LITHIUM-ION RECHARGEABLE

SOLDERING IRON

MODEL NO: SDL10

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these

instructions, and properly maintained, give you years of trouble free performance.

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE

THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR

PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.

1. SAFETY

 WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using this

 equipment,makesureyouknowwherethenearestreextinguisheris.

 WARNING!Alwayswearapprovedeye/faceprotectionwhenoperatingthesolderingiron.

 WARNING!Donotusethesolderingironifyounoticedamagetotheworkpiece.

 WARNING!Alwayspointthesolderingironawayfromtheeyesandbodywhenduringoperation.

 WARNING!Donotputthesolderingirondown,putitbackinitsholder.

 WARNING!Onlyuseinawellventilatedarea.

9  Keepammablematerialawayfromthetorchwhenoperating.

8 DO NOToperatethesolderingironwhenyouaretiredorundertheinuenceofalcohol,drugsorintoxicatingmedication.

8 DO NOTusethesolderingironinanareawherepaintfumes,solventsorotherammablesolids,liquidsorgasesposeapotential

 hazard.

8 DO NOTholdanyworkpiecebyhand.

8 DO NOTtouchtheworkpiececlosetotheheatedareaasitwillbeveryhot.Allowtocool.

8 DO NOToperatethesolderingironifitisdamagedasthismaycausefailureand/orpossiblepersonalinjury.

8 DO NOTtouchthetopofthesolderingironduringorimmediatelyafteruse,asitwillbeveryhot.Allowtocool.

8 DO NOTallowchildrentooperatethesolderingiron.

9  Whennotinuse,storeawayfromdirectsunlightinasafe,dry,childprooflocation.

8 DO NOTstoreatover40°C,suchasinacarinhotweather.

2. INTRODUCTION

 Cordlessandlightweightsolderingiron.InbuiltLEDtoilluminatesolderingareainlowlightareassuchasenginebays.Heatsuptoa

 maximumtemperatureof600°Candhasa40minuteworkingtime.

3. SPECIFICATION

Model No.:.................................................................. SDL10

Battery:...................................................... 2.5AhLithium-ion

Charging time:................................................................3.5hr

MaximumTemperature:............................................... 600

OperatingTime:........................................................... 40min

Power Rating:.................................................................12W

4. CONTENTS

SDL10Issue111/06/20

Original Language Version

Refer to

instructions

Warning:

Hot surfaces

Do not cover

Wear eye

protection

Item Description Part number

1 Charging cord for SDL10 SDL10.CC

2 Soldering stand for SDL10 SDL10.S

3 12W Cone tip SDL11.CT

4 TransparentcapforSDL10NOTSHOWN SDL10TC

Indooruse

only

g.1

5. OPERATION

5.1. CHANGING SOLDERING TIP

5.1.1. Ensure that the soldering iron tip is cold, select the appropriate tip and remove the current tip by applying a quarter turn to the tip

 collar.Mounttherequiredtipbyliningupthelugs,slidingthecollardownthetoolandapplyingaquarterturn.

5.2. CHARGING

5.2.1. WhenconnectedtoaUSBpowersupplytheLEDinthehandlewillshowredwhilechargingandwillturngreenwhenfullycharged.

5.3. USING THE SOLDERING IRON

5.3.1. SlidetheHeatingandLEDcontrolslider(g.2)forwardtopreparethetoolforsoldering.

5.3.2. DepresstheredbuttonontopoftheslidecontroltoheatthetipandtoturnontheLED.Whiletheredbuttonisdepressedthetip

 willcontinuetoheat.Ifthebuttonisreleasedthepowerise󰀨ectivelyswitchedo󰀨.

5.3.3. WhentheworkisdoneensurethattheHeatingandLEDcontrolsliderisreturnedtotheO󰀨position(g.2)andthatthetipiscold

 beforestoring.

6. MAINTENANCE

6.1. Ifsoiled,cleanthetoolusingusingaclean,dampcloth.DO NOTgetthetoolwet.

Original Language Version

Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR

01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk

ENVIRONMENT PROTECTION

Recycleunwantedmaterialsinsteadofdisposingofthemaswaste.Alltools,accessoriesandpackagingshouldbesorted,takento

arecyclingcentreanddisposedofinamannerwhichiscompatiblewiththeenvironment.Whentheproductbecomescompletely

unserviceableandrequiresdisposal,drainanyfluids(ifapplicable)intoapprovedcontainersanddisposeoftheproductandfluids

accordingtolocalregulations.

WEEE REGULATIONS

Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment

(WEEE).Whentheproductisnolongerrequired,itmustbedisposedofinanenvironmentallyprotectiveway.Contactyourlocalsolid

wasteauthorityforrecyclinginformation.

BATTERY REMOVAL

Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential purchasers of products

containingbatteries(asdefinedwithintheseregulations),thattheyareregisteredwithValpak’sregisteredcompliancescheme.Jack

SealeyLtd’sBatteriesProducerRegistrationNumber(BPRN)isBPRN00705.

BATTERY REMOVAL

Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential purchasers of products

containingbatteries(asdefinedwithintheseregulations),thattheyareregisteredwithValpak’sregisteredcompliancescheme.Jack

SealeyLtdBatteriesProducerRegistrationNumber(BPRN)isBPRN00705.

Note:Itisourpolicytocontinuallyimproveproductsandassuchwereservetherighttoalterdata,specificationsandcomponentpartswithoutprior

notice.

Important:NoLiabilityisacceptedforincorrectuseofthisproduct.

Warranty:Guaranteeis12monthsfrompurchasedate,proofofwhichisrequiredforanyclaim.

SDL10Issue111/06/20

g.2
