Sealey MS0812D Helmet Hanger/Dryer User Manual

HELMET HANGER/DRYER

MODEL NO: MS0812D

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these

instructions, and properly maintained, give you years of trouble free performance.

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE

THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR

PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.

1. SAFETY

1.1. ELECTRICAL SAFETY FOR USE OF POWER SUPPLY

 WARNING! DO NOT use any other type of power supply with this product. Only use the one provided. Failure to observe this warning

 couldresultininjuryandorre.Theuseofanyothertypeofpowersupplywillinvalidatethewarranty.

8 DO NOT turn on mains supply until the power supply lead is connected to the fan assembly.

 WARNING! It is the user’s responsibility to read, understand and comply with the following instructions.

 WARNING! You must ensure the risk of electric shock is minimised by the installation of appropriate safety devices e.g. RCD.

9 NOTE: Iftheproductisusedinthecourseofbusinessduties,itmustbemaintainedinasafeconditionandroutinelyPAT 

 (PortableApplianceTest)tested.

9 Ensure that you inspect the power supply, cable and connections for wear and damage to ensure items are safe before connecting

them to the mains supply. If worn or damaged DO NOT use.

 WARNING! Therearenouserserviceablecomponentsinthepowersupply.DO NOT dismantle.

 WARNING! For indoor use only. DO NOT allow the power supply to become wet. DO NOT use in wet or damp conditions.

8 DO NOT pull the power supply plug from the mains socket by the lead.

8 DO NOT locate this product assembly in such a position as to create the risk of injury from contact with the head or any other

part of the body.

8 DO NOT overload this product; it should only be used for the designed purpose.

8 DO NOT locate in a position where items could fall from the product assembly owing to accidental contact.

9 Ensurethattheproductisrmlyxedtothewallreferto4.4below.

9 Ensure that, when installed, it can be accessed without over-reaching or over-balancing.

2. INTRODUCTION

A robust steel, powder paint coated, hanger. Can be mounted to your doors, walls or wardrobe. An integral, quiet running fan will

quickly and conveniently dry your helmet, whilst on the hanger. Inhibiting the build-up of damp and odour. Keep all your

 motorbikegearinoneplace.Thishangercomeswithanintegratedstrapthatwillholdyourgloves,anditcanalsobeusedtohang

your jacket, trousers or suit from. With the ability to mount the bracket where is convenient to you, this frees space from in your

 wardrobe,hallwayorcupboards,andcanplaceyourbikegearwhereyouwantit.Theangleofthebracketcanalsobestdisplaythe

decorative capabilities of a motorcycle helmet.

3. SPECIFICATION

Model No: .......................................................MS0812D

Electrical Class: ..........................................................III

PlugType: ..........................................3-PinTransformer

4. INSTALLATION & ASSEMBLY

4.1. Attach the wall plate to the bracket using the four bolts provided. Ensure the wall plates are perpendicular to the bracket.

4.2.  Holdtheassemblyinthedesiredpositionandmarkthewallthroughthefourholes,g.1.

4.3. Remove from wall.

4.4. Usewallxingsthataresuitableforthetypeofwallandtheweightoftheloadedproduct.

4.5.  Drillfourholessuitableforthewallxings.

4.6.  Fixthehookassemblytothewall.

5. OPERATION

5.1. FAN

5.1.1. Connect the power supply into the fan cooler plug connection.

5.1.2.  Turnonpowersupplywhenrequired,inordertooperatefan.

5.1.3.

MS812DIssue208/02/24

Original Language Version

Refer to

instructions

g.2

Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR

01284 757500 sales@sealey.co.uk www.sealey.co.uk

ENVIRONMENT PROTECTION

Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted,

taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product

becomescompletelyunserviceableandrequiresdisposal,drainanyfluids(ifapplicable)intoapprovedcontainersand

dispose of the product and fluids according to local regulations.

PURCHASE HERE

g.1

Strap for gloves

Power supply

plug connection

Fixingholesto

wallx4

Jacket hook

Hook for helmet

Fan Cooler

Wallplatexing

screwsx4

WEEE REGULATIONS

Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment

(WEEE).Whentheproductisnolongerrequired,itmustbedisposedofinanenvironmentallyprotectiveway.Contactyourlocalsolid

waste authority for recycling information.

Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior

notice.

Important: No Liability is accepted for incorrect use of this product.

Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.

MS812DIssue208/02/24

Original Language Version
