1.95M ADJUSTABLE PAINT HANGER
MODEL NO: MK80
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
9 Only use on firm, level, unobstructed surfaces which are capable of supporting the stand and wheels.
8 DO NOT overload.
9 Always load evenly with the centre of gravity of the load as near the centre as possible.
9 Apply the brakes before commencing work.
8 DO NOT stand/ride on the stand, or allow others to do so.
9 Replace or repair damaged parts. Use only recommended parts. Unauthorised parts may be dangerous and will invalidate the warranty.
WARNING! Failure to comply with these instructions may result in loss of load, damage to the rack or other property and/or personal
injury.
WARNING! The warnings, cautions and instructions discussed in this instruction manual cannot cover all possible conditions
and situations that may occur. It must be understood that common sense and caution are factors which cannot be built into this
product, but must be applied by the operator.
2. INTRODUCTION
Adjustable height from 1.3m to 1.95m. Six hooks with a combined capacity of 75kg for hanging small parts. Suitable for hanging
bumpers, bonnets, doors, wings and spoilers. Fitted with four castors, two with brakes for maximum manoeuvrability and safe
positioning.
3. SPECIFICATION
Model No: .............................................................. MK80
Max. Capacity: ....................................................... 75kg
Maximum Height: ............................................. 1950mm
Minimum Height: .............................................. 1300mm
4. ASSEMBLY
4.1. Start assembly by attaching the base of the frame (1 & 3) together with the frame bracket clamp (6).
4.2. Attach the 4 wheels (10) to the base of the frame, and lock the brake on the 2 with brakes, before the next step.
4.3. Build upwards, by joining the vertical frame parts (2 & 5) with the adjusting pins (9) and set to the desired height.
4.4. Complete the frame by attaching the top frame (4) and securing with the frame bracket clamp (6).
4.5. Attach the 6 hanging hooks as required (7).
4.6. See diagram & parts list on page 2.
MK80 Issue 2 02/02/23
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Wear
protective
gloves
Wear
protective
footwear
Wear eye
protection
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
MK80 Issue 2 02/02/23
Original Language Version
© Jack Sealey Limited
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice. Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
REGISTER YOUR
PURCHASE HERE
NO Description Quantity
1 Frame Axle 2
2 Main Frame 2
3 Bottom Frame 2
4 Top Frame 2
5 Adjusting Frame 2
6 2- Hole Frame Bracket Clamp 4
7 Hanging Hooks 6
8 Bolt (M8x50) 14
9 Adjusting Pin 2
10 Castors 4
