ADJUSTABLE ANGLE GRINDER DUST SHROUD
MODEL NO: AGDS01
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Read all safety warnings, instructions, illustrations and specications provided with this power tool. Failure to follow all
instructions listed below may result in electric shock, re and/or serious injury. Save all warning and instructions for future reference.
9 This product is an accessory to an angle grinder. Apply all safety advice concerning the use of an angle grinder when using this
product.
WARNING! Ensure grinder is disconnected from mains supply during assembly.
2. INTRODUCTION
Professional dust control guard for grinding, sanding and polishing. Collar clip and spacers provided to adjust the shroud for Ø115mm
and Ø125mm angle grinders. Hose connector which allows the hose to swivel. Adjustable front end for grinding right to the edge.
Clearance provided by spring loaded brush. Collects harmful dust in concrete surfacing applications.
3. SPECIFICATION
Model No: ................................................................ AGDS01
Contents:
Dust Shroud (x1), Wrench (x1), Pressing Plate (x1), ring spacers (x4) 39mm, 42mm, 45mm, 48mm.
Diameter: ...............................................Ø115mm - Ø125mm
Weight: ...................................................................... 0.578kg
4. CONTENTS
AGDS01 Issue:1 17/02/25
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Wear eye
protection
Wear protective
gloves
Wear ear
protection
Wear safety
footwear
Wear protective
clothing
Wear a mask
Wear respiratory
protection
(fumes)
Vacuum
connection
Grinder ring (collar)
spacers
5. OPERATION
5.1. Connect to vacuum extraction. Risk assess the cutting task to be performed. Perform a run up test and operation of the shroud before
commencing work to ensure all parts are correctly aligned.
Adjust working position as required.
Secure with clip.
Select grinder ring spacer and t
onto grinder.
Fit dust shroud onto grinder.
Fit grinding wheel.
Secure with nut.
Open shroud until ‘click’ position. Check shroud is tted correctly, before use.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts
without prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
