2 DOOR LOCKER
MODEL NO: SL2D.V3
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are
adhered to when using these lockers. Wear protective gloves.
9 Locate locker in a suitable work area.
9 Keep the work area clean, uncluttered and ensure there is adequate lighting.
WARNING! Use locker on level and solid ground, preferably concrete.
9 Keep the locker clean and tidy in accordance with good workshop practice.
9 Keep children and unauthorised persons away from the work area.
8 DO NOT use the locker for any purpose other than that for which it is designed.
8 DO NOT use the locker outdoors.
8 DO NOT get the locker wet or use in damp or wet locations or areas where there
is condensation.
8 DO NOT clean the locker with any solvents which may damage the surfaces or the
protective coating.
2. INTRODUCTION
Double locker system suitable for a wide variety of commercial applications with clothes hanger
bar.Doorsareventilatedandttedwithcylinderlock.
3. SPECIFICATION
Model No:................................................................SL2D.V3
Doors: ..........................................................................2 door
Overall Size (W x D x H): ......................380 x 450 x 1850mm
4. ASSEMBLY
4.1. Layoutthebackpanelandthetwosidepanels(g.1).Thesidepanelshaveacut-outatthefront(g.2).Fitthelefthandsidepanelto
the back panel, secure using the bottom and two middle screws only.
4.2. Fittherighthandsidepaneltothebackpanel,usingthethreelowerscrewsonlytosecure(g.3).
4.3. Carefully stand the unit up, ensuring that the panels are not twisted.
4.4. Fitthedoorframepanelintotheunitfromtheinsidelocatingtheframewiththesidepanelsatthetopandbottom.
4.5. Fitthelockertopfromtheinsidewiththetwoholesatthebacklinedupwiththetwoholesinthebackpanel.
4.6. Bend the tabs in at the front of the top, making sure that they locate into the locking holes
inthedoorframe(gs.4&5).
SL2D.V3 Issue 2 (4) 19/06/23
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Indoor use only
g.1
Wear protective
gloves
SL2D.V3
g.2
Original Language Version
© Jack Sealey Limited
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
REGISTER YOUR
PURCHASE HERE
4.7. Placethebottomshelfintothelockerwiththetwocutoutsfacingtowardsthedoor(g.6),pushitdownintoplace.
4.8. Carefullytiplockeroverbackwardsandlowertotheoor.Securethebottomshelftothebackpanelusingtwoscrews(g.7).Stand
locker up.
4.9. Allshelvesarethesamedesignasthebottomshelfwithtwocut-outsthatfacetowardsthedoor.Locateeachoneandpushdowninto
place.Ifrequired,drillholesandxshelvesinpositionwitharetainingscrew(g.8).
4.10. Placehangingbarsinposition(g.9).
g.3
g.4
g.5
g.6
g.7
g.8
g.9
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice. Please note that other versions of this product are available. If you require documentation for alternative versions, please email or call
our technical team on technical@sealey.co.uk or 01284 757505.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
SL2D.V3 Issue 2 (4) 19/06/23
