MODEL WL45056
YOUR SAFETY &
INSTRUCTION MANUAL
PLEASE READ CAREFULLY
2KW DUNDEE 22" CURVED
GLASS ELECTRIC FIREPLACE
www.warmlite.co
2
SERVICE DEPARTMENT: +44 (0) 333 220 6056
TECHNICAL DATA
Description: 2KW Dundee 22" Curved Glass Electric Fireplace
Model: WL45056
Rated Voltage: 220-240V
Frequency: 50Hz
Power Consumption: 1750W - 2000W
WARRANTY
This product is guaranteed for 12 months from the date of original purchase. If any defect arises due
to faulty materials of workmanship, the faulty products must be returned to the place of purchase.
Refund or replacement is at the discretion of the retailer.
The following conditions apply:
• The product must be returned to the retailer with proof of purchase.
• The product must be installed and used in accordance with the instructions contained in this
instruction guide.
• It must be used only for domestic purposes.
• It does not cover wear and tear, damage, misuse or consumable parts.
• RK Wholesale LTD has limited liability for incidental or consequential loss or damage.
• This guarantee is only Valid in the UK and Eire Only.
An extended warranty is available for this appliance.
See back page for details.
3
www.warmlite.co
WARNING:
This Appliance MUST be Earthed
WIRING SAFETY FOR UK USE ONLY
IMPORTANT
As the colours in the mains lead of this appliance
may not correspond with the coloured markings
identifying the terminals in your plug, please
proceed as follows:
The wires in the mains lead are labelled in
accordance with the following code:
Blue neutral [N] Brown live [L]
Green/Yellow [EARTH]
Plug Fitting Details (Where Applicable). The
wire labelled blue is the neutral and must be
connected to the terminal marked [N].
The wire labelled brown is the live wire and must
be connected to the terminal marked [L].
The wire labelled green/yellow must be
connected to the terminal marked with the letter
[E].
On no account must either the brown or the blue
wire be connected to the [EARTH] terminal.
Always ensure that the cord grip is fastened
correctly.
The plug must be tted with a fuse of the same
rating already tted and conforming to BS 1362
and be ASTA approved.
If in doubt consult a qualied electrician who will
be pleased to do this for you.
Non-Rewireable Mains Plug
If your appliance is supplied with a non-
rewireable plug tted to the mains lead and
should the fuse need replacing, you must use an
ASTA approved one (conforming to BS 1362 of
the same rating).
If in doubt, consult a qualied electrician who will
be pleased to do this for you.
If you need to remove the plug - disconnect it
from the mains - then cut it o of the mains lead
and immediately dispose of it in a safe manner.
Never attempt to reuse the plug or insert it into a
socket outlet as there is a danger of an electric
shock.
FUSE
Earth
(Green/Yellow)
Fuse
Neutral
(Blue)
Live
(Brown)
4
SERVICE DEPARTMENT: +44 (0) 333 220 6056
HIGH VOLTAGE HOT SURFACE DO NOT COVER
PRODUCT SAFETY
When using any electrical appliance, basic safety precautions should
always be followed including the following:
• Check that the voltage of the
main circuit corresponds with
the rating of the appliance
before operating.
• The intended use for this unit
is described in this manual.
The use of any accessory
or attachment or the
performance of any operation
with this appliance other
than those recommended in
this instruction manual may
present a risk of personal
injury.
• Retain this manual for future
reference.
• DO NOT use this product
for anything other than its
intended use.
• DO NOT leave the appliance
unattended while it is
operating.
• This appliance is for
household use only.
• DO NOT use the appliance
outdoors.
• Please ensure that the
appliance is used on a stable,
level, and heat resistant
surface.
• Ensure that the appliance
is not positioned close to
curtains, furniture or any
combustible materials as this
could create a re hazard.
Keep them at least 1metre
from the front of the appliance
and away from the sides and
rear.
• The appliance should be
placed away from gasoline,
paint, or ammable liquids
or cooking stoves or other
combustibles and heat
sources.
• Use the appliance in a well
ventilated area.
• If the supply cord or appliance
is damaged, stop using
the appliance immediately
and seek advice from the
manufacturer, its service
agent or a similarly qualied
person. Check the appliance,
cord and plug connections at
each use.
• DO NOT attempt to dismantle
or repair any part of the
appliance. This should only
be done by a qualied service
agent. DO NOT modify the
appliance.
• The appliance must not be
located immediately below a
mains socket outlet.
5
www.warmlite.co
• The appliance must be
positioned so that the plug is
accessible.
• Ensure the appliance is
switched to the o position
before plugging in.
• DO NOT immerse cords,
plugs or any part of the
appliance in water or any
other liquid.
• DO NOT let the cord hang
over the edge of a table or
counter or let it come into
contact with any hot surfaces.
• DO NOT carry the appliance
by the power cord.
• Use of an extension cable
with this appliance is not
recommended. However,
if it is necessary to use an
extension lead, ensure that
the lead is suited to the power
consumption of the appliance
to avoid overheating of
extension cable, appliance or
plug point. Do not place the
extension cable in a position
where it can be pulled on by
children or animals or tripped
over.
• Ensure that no other high
current appliances are
plugged into the same circuit
with your appliance as an
overload can occur.
• Do not use this appliance with
a programmer, timer or any
other device that will switch it
on automatically.
• The use of accessory
attachments is not
recommended by the
appliance manufacturer, apart
from those supplied with this
product.
• DO NOT pull the plug out by
the cord as this may damage
the plug and/or the cable.
• DO NOT turn the appliance
on or o by inserting or
pulling out the plug. Use the
appliance controls to switch
ON/OFF initially.
• Always place wires in a
regular and orderly manner to
prevent a trip hazard or the
plug from accidentally being
pulled out.
• DO NOT run the power cord
under carpeting and DO
NOT cover the power cord
with throws, rugs, runners or
similar coverings. DO NOT
route the power cord under
furniture or appliances.
• CAUTION! DO NOT operate
the appliance with wet hands.
• DO NOT use the appliance
near water.
6
SERVICE DEPARTMENT: +44 (0) 333 220 6056
• DO NOT use the unit near
open windows, as contact
with rain and other natural
elements could cause an
electrical hazard.
• DO NOT splash oil or water
into the appliance. If there
is water on the surface
of the appliance, unplug
immediately.
• DO NOT use or store this
appliance in the immediate
surroundings of a bath, a
shower, pool, a laundry room
or other places with water
and moisture.
• Never use the appliance
to dry clothes or any other
similar items.
• In order to avoid overheating,
do not cover the appliance.
• DO NOT permanently install
the unit in a recessed area
of wall. This may result in
blocked air ow, over heating
or re.
• For optimal airow circulation,
leave a distance of at least
15 centimetres around the
appliance.
• DO NOT place things on the
appliance.
• DO NOT put anything into the
air inlet and outlet.
• Regularly inspect air vents to
make sure they are free from
dust, lint or other blockages.
• Switch o at the appliance,
then wall socket before
removing the plug, when not
in use or before cleaning.
• DO NOT leave the appliance
switched on when leaving
your home or going to sleep.
• The appliance is not to be
used by persons (including
children) with reduced
physical, sensory or mental
capabilities, or lack of
experience and knowledge,
unless they have been given
supervision or instruction.
• Children of less than 3 years
should be kept away unless
continuously supervised.
• Children between the ages
of 3 and 8 years old should
only switch the appliance
on or o when it has been
placed and installed in its
intended, normal operating
position and when they
have been given adequate
supervision or instruction
concerning safe use of the
appliance and understand the
hazards involved. Children
between the ages of 3 and
8 years old should not plug
in, regulate, clean or perform
user maintenance on the
appliance.
7
www.warmlite.co
• This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical, sensory
or mental capabilities or
lack of experience and
knowledge if they have
been given supervision or
instruction concerning use of
the appliance in a safe way
and understand the hazards
involved.
• Close supervision is
necessary when any
appliance is used by or near
children.
• Children should not play with
the appliance.
• CAUTION! Some parts of this
product can become very hot
and cause burns. Particular
attention has to be given
where children and vulnerable
people are present.
• Cleaning and user
maintenance should not
be undertaken by children
without supervision.
• Take care when any appliance
is used near pets.
• Always unplug the appliance
and allow it to cool before
moving it from one location to
another.
• DO NOT clean the appliance
with water. Wipe it with a
damp soft cloth.
• DO NOT wipe the appliance
with chemical solvents
such as benzene, gasoline
or alcohol. Use neutral
detergents only.
• Always x the appliance to the
wall or attach the feet with the
xings supplied before use.
• Do not place on long piled
carpet.
• Protect the appliance from
direct sunlight.
• The appliance is tted with a
thermal cut out device.
• In the unlikely event the
appliance develops a fault,
stop using it immediately
and seek advice from the
Customer Support Team.
8
SERVICE DEPARTMENT: +44 (0) 333 220 6056
WHAT’S IN THE BOX
Instruction Manual
Fireplace Suite
Remote Control
Feet
Wall xings
1. Fire Surround
2. Electric Fire
3. Control Panel
4. Air outlets
5. Power ON/OFF Switch
Control Panel
6. Heat key
7. Timer key
8. Flame eect key
9. ON/Stand-by key
10. + Timer adjustment
11. - Timer adjustment
Remote Control
12. ON/Stand-by key
13. Heat ON/OFF key
14. DAY
15. Week/Time setting key
16. + day/ time adjustment keys
17. Flame eect ON/OFF key
18. - day/ time adjustment keys
19. HOUR
20. SET UP key – Timer ON/OFF mode
21. MIN
Control Panel Remote Control
5
4
16
18
20
1713
6 9
7 10
8 11
12
14
15
19
21
1
3
2
BEFORE FIRST USE:
1. Remove your appliance from the packaging.
2. Check that there is no damage to the cord or any visible damage to the appliance.
3. Read the Instruction Manual and retain for future reference.
4. Your appliance is now ready for normal use.
Dispose of the packaging in a responsible manner.
9
www.warmlite.co
LED Display/ Icons
1. ON/Stand-by
2. Heat ON/ OFF/ Levels
3. Temperature
4. Days of the week
5. Timer set
6. Remote Sensor
7. Time
8. Timer ON/ OFF
9. Open window detection
10. Flame eect intensity
BEFORE FIRST USE:
1. Remove your appliance from the
packaging. Check the contents are
all present and that there is no visible
damage to the cord or appliance.
2. Install your appliance in accordance with
the installation & safety instructions.
3. Your appliance is now ready for normal
use.
Dispose of the packaging in a responsible
manner.
INSTALLING THE BATTERY
WARNING: Danger of explosion if battery is
incorrectly replaced.
WARNING: DO NOT INGEST BATTERY;
CHEMICAL BURN HAZARD. This product
contains a coin/button cell battery. If the coin/
button cell battery is swallowed, it can cause
severe internal burns in just 2 hours and can
lead to death.
Keep new and used batteries away from
children. If the battery compartment does not
close securely, stop using the product and
keep it away from children.
If you think batteries might have been
swallowed or placed inside any part of the
body, seek immediate medical attention.
If the coin cell battery contents come into
contact with the skin, immediately wash area
with mild soap and water. If coin cell battery
liquid gets into the eye, rinse water over the
open eye for 15 minutes or until irritation
ceases. If medical attention is needed, the
battery electrolyte is composed of an organic
solvent and lithium salts.
Do not incinerate or dispose of tool together
with household waste material! Tool that has
reached the end of its life must be collected
separately and returned to an environmentally
compatible recycling facility.
To install the battery, rst detach the battery
cover from the remote.
Insert 1 x CR2025 battery into the battery
compartment, taking care to ensure the
positive polarity is facing upwards.
1
3
4
5
6
9
8
7
10
2
10
SERVICE DEPARTMENT: +44 (0) 333 220 6056
Once the battery is in place, slide the battery
cover back into the remote. It will automatically
lock into place and secure the battery inside.
INSTALLING THE APPLIANCE
The appliance is designed to be wall mounted
or free standing.
Wall Mounting:
1. This appliance is designed to be xed to a
wall at a minimum height of 300mm and
the minimum distance from the top of the
unit to the ceiling should be 1000mm.
2. A distance of 600mm from the bottom
of the unit to the oor is recommended
for optimum viewing of the fuel bed;
see below for recommended xing
dimensions.
3. Drill two 8Ø mm holes in the wall (See
Figure 1) 26.7cm apart.
4. Insert the dry wall anchors into the holes,
gently tapping them with a hammer until
the ange of the wall anchor is ush with
the wall surface and rmly tighten them
with the screws provided (See gure 2).
This unit is provided with a wall mounting
brackets, screws and wall plugs.
Note: The screws and plugs provided are only
suitable for a solid wall xing.
If the installation is onto a hollow/stud wall,
heavy duty wall anchors or equivalent are
recommended.
11
www.warmlite.co
Wall Mounting:
1. Fix the feet supplied to the bottom of the
appliance with the screws supplied.
USING YOUR APPLIANCE
Turning the Unit On and O:
Note: Do not press buttons more than once
within two seconds, in order to allow time for
the receiver to respond to the transmitter.
1. Insert the plug in a suitable power socket.
2. Press the ON/OFF switch to the ON
position.
3. There will be an audible signal, the LED
display will briey ash on and then the
appliance will enter stand-by mode.
4. The LED display will show the power
icon.
5. Press the key on the control panel or
the remote to turn the unit ON. The unit
will emit an audible signal and the LED
display will illuminate. The unit’s default
is with the ame intensity at its highest
setting.
Note: If no further keys are pressed the display
screen will go o. It can be re activated by
pressing any key.
6. Press the key again to turn the unit
o to stand-by.
Note: The fan will continue to work for a few
seconds without heat.
7. Press the ON/OFF switch to the OFF
position.
Setting the Date and Time
On the control panel:
press the key, the day will ash. Press
the and keys to set the current
day.
8. Press the key, the hour will ash.
Press the and keys to set the
current hour.
9. Press the key, the minute will ash.
Press the and keys to set the
current minutes.
On the remote:
1. Press the key followed by the
and
keys to select the current day.
2. Press the key followed by the
and
keys to set the current hour.
3. Press the key followed by the
and
keys to set the current minutes.
4. The day and time will show on the
display screen.
Weekly Timer
Pre-set the time of operation using the
remote control.
1. To set the day, press the key. The
time will show 00:00 and ‘day’ and
‘ON’ will ash on the display screen.
2. Press the
and
keys to select the
day the timer is to be set for.
Set the time the unit is to start operation:
1. Press the key followed by the
and
keys to set the hour.
2. Press the key followed by the
and
keys to set the minutes.
12
SERVICE DEPARTMENT: +44 (0) 333 220 6056
To set the auto-o time:
1. Press the key. The display screen
will show 00:00 and the ‘day’ and ‘OFF’
will ash.
2. Press the
and
keys to select the
day the auto-o time is to be set for.
3. Press the key followed by the
and
keys to set the hour.
4. Press the key followed by the
and
keys to set the minutes.
5. Once the timer has been set the
icon will illuminate on the display
screen.
Flame Eect
1. On the control panel or remote control,
press the key to cycle through the 5
ame intensity levels.
2. The LED display icon will show the
ame intensity level selected.
Heating Selection
This unit can operate with or without the
heating function. To activate the heating
function:
3. On the control panel or remote control,
press the key to cycle through
low heat 1750W, high heat 2000W
and OFF. The heat icons will illuminate
accordingly.
Note:
Once switched o the fan will continue
to operate for a few seconds.
Temperature Selection
Once the ambient temperature is reached,
the unit will automatically stop heating. When
the ambient temperature drops below the
desired temperature by approximately 2°C,
the unit will resume heating.
1. Activate the heating function by
pressing the key on the control
panel or remote control. The
temperature display will ash.
2. Press the
and
keys to set the
required room temperature, within the
range of 15°C-30°C. The temperature
will change in increments of 1°C.
3. The display shows the current room
temperature. Press the key to
check the selected temperature setting.
Open Window Detection
WARNING: The unit will turn o automatically
when the temperature drops suddenly by
5-10℃. The corresponding indicator light
on the display will illuminate to indicate that
this function has been activated.
Safety System
• In the event of abnormal overheating, a
safety device shuts down the appliance
automatically. After a short cooling
down phase, inspect for blockage of air
inlet or outlet and then the appliance is
ready for use again.
• If you still notice the same defect as
above mentioned, remove the plug
from the socket and consult your
authorised dealer or your after-sales
service department.
• During use, do not touch or cover
the air outlet. This may cause the unit
to overheat, and the safety device to
operate.
CHECK THAT YOU HAVE NOTED ALL THE
FOLLOWING INSTRUCTIONS:
Do:
• Always install the re in accordance
with this guide. If in doubt obtain expert
advice.
13
www.warmlite.co
• Always make sure the electrical socket
is accessible and located adjacent to,
but not above or behind the re.
• Always disconnect the re from the
electrical supply before carrying out
cleaning or maintenance.
• Always make sure the re is rmly
secured.
• Always ensure the product is
assembled in an area that is free from
dust, grease or liquids.
• Always ensure that the correct tools are
used to assemble/install this product.
Don’t:
• Never leave children unsupervised
in a room where the re is ON and
unguarded.
• Never obstruct or cover the fan outlet or
force items into re openings.
• Never install or use the re anywhere
where water is in use, i.e. bathrooms,
kitchens, shower rooms swimming
pools etc.
• Never use aerosols or steam cleaners
on or around the re.
• Never route the mains supply cable
under carpet etc.
• Never install the re close to curtains or
combustible materials.
• Never use the re to dry clothes etc.
• Never sit or stand on the re.
• Never cut o the plug and hard wire
into a xed fused spur.
Note:
When the re is turned on for the rst
time or when it has not been used for some
time, it may release a slight, harmless odour.
This odour is a normal occurrence caused
by the initial heating of the internal heating
elements or dust, and will disappear with
use.
TROUBLESHOOTING
The re is not operating
Check the mains socket to ensure that the plug
is inserted correctly and switched on at the
socket.
Check that the ON/OFF switch for the re has
been pressed ON.
Be aware that the safety cut-out may have
activated.
No heat
Check the functions set.
Be aware that the room temperature may
have reached 30°C and the re therefore has
automatically switched OFF.
Fire stops operating
The safety cut-out may have operated. Follow
the procedures outlined in the Safety System.
CLEANING AND CARE
• WARNING! Before cleaning and
maintenance, switch the appliance o
and remove the plug from the socket,
to prevent electric shock. Allow the
appliance to cool down.
CAUTION! Allow the unit to completely cool
before handling or cleaning it.
• Do not immerse any part of the appliance,
power cord or plug in liquids.
• Use a soft damp cloth to wipe the surface.
Avoid using abrasives, detergent, spray or
chemicals as these may cause damage to
the appliance.
• Check all inlets and outlets from time to
time for accumulated dust. Remove dust
with a soft cloth or vacuum. ♦WARNING:
DO NOT allow water or steam to enter
any part of the appliance, as this could
cause it to malfunction.
14
SERVICE DEPARTMENT: +44 (0) 333 220 6056
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here
may not be disposed of in domestic rubbish.
You are required to dispose of old electrical
and electronic appliances like this separately.
Please visit www.recycle-more.co.uk or
www.recyclenow.co.uk
for access to information about the recycling
of electrical items.
Please visit www.weeeireland.ie for access to
information about the recycling of electrical
items purchased in Ireland.
The WEEE directive, introduced in August
2006, states that all electrical items must be
recycled, rather than taken to landll.
Please arrange to take this appliance to your
local Civic Amenity site for recycling, once it
has reached the end of its life.
WARNING:
DO NOT IMMERSE ANY ELECTRICAL PART
OF THE APPLIANCE IN WATER SUCH AS
MOTOR UNITS OR PLUGS.
PLEASE SEE CLEANING SECTION FOR
FURTHER INSTRUCTIONS.
Notes
15
www.warmlite.co
Model Identier(s): WL45056
Item Symbol Valve Unit Item Unit
Heat Output
Type of heat input for electric storage, local space
heaters only (select one)
Nominal heat
output
Pnom 1.8 kW
Manual heat charge with integrated
thermostat
N/A
Minimum heat
output (indicative)
Pmin 0.9 kW
Manual heat charge control with room
and/or outdoor temperature feedback
N/A
Maximum
continuous heat
output
Pmax, c 1.8 kW
Electronic heat charge control with room
and/or outdoor temperature feedback
N/A
Auxiliary electricity
consumption
Fan assisted heat output N/A
At nominal heat
output
elmax 1.836 kW
Type of heat output/room temperature control
(select one)
At minimum heat
output
elmin 0.916 kW
Single stage heat output and no room
temperature control
No
In standby mode eISB 0 kW
Two or more manual stages, no room
temperature control
No
With mechanic thermostat room temperature
control
No
With electronic room temperature control Yes
Electronic room temperature control plus day
timer
No
Electronic room temperature control plus
week timer
Yes
Other control options (multiple selections possible)
Room temperature control with presence
detection
No
Room temperature control with open
window detection
Yes
With distance control option No
With adaptive start control No
With working time limitation No
With black bulb sensor No
Contact Details: Imported by RK Wholesale LTD., Berryhill Road, Stoke-on-Trent ST4 2NL
We hope you enjoy your appliance for many years.
As a thank you for purchasing one of our fantastic products,
we are giving you an extra year peace of mind.
To receive your extra year guarantee, register your appliance online by visiting
www.warmlite.co
Should you have a problem
with your appliance or need any spare parts please call our
Service Department on:
+44 (0) 333 220 6056
Distributed throughout the UK by RKW LTD
0521.V1
