NEWCASTLE 1.8KW
ARCH FRONT FIREPLACE SUITE
WL45045
YOUR SAFETY &
INSTRUCTION MANUAL
PLEASE READ CAREFULLY
This product is only suitable for well insulated spaces or occasional use
2
CUSTOMER SUPPORT TEAM: +44 (0) 333 220 6056
TECHNICAL DATA
Description: Newcastle 1.8kW Arch Front Fireplace Suite
Model: WL45045
Rated Voltage: 220-240V
Frequency: 50/60Hz
Output: 14V
Power Consumption: 1800W
DOCUMENTATION
We declare that this product conforms to the following product legislation in accordance with the
following directive(s):
2014/30/EU Electromagnetic Compatibility Directive.
2014/35/EU Low Voltage Directive.
2011/65/EU Restriction of Hazardous Substances Directive.
2009/125/EC Eco-Design of Energy Related Products.
RK Wholesale LTD Quality Assurance, United Kingdom
WARRANTY
This product is guaranteed for 12 months from the date of original purchase. If any defect arises due
to faulty materials of workmanship, the faulty products must be returned to the place of purchase.
Refund or replacement is at the discretion of the retailer.
The following conditions apply:
• The product must be returned to the retailer with proof of purchase.
• The product must be installed and used in accordance with the instructions contained in this
instruction guide.
• It must be used only for domestic purposes.
• It does not cover wear and tear, damage, misuse or consumable parts.
• RK Wholesale LTD has limited liability for incidental or consequential loss or damage.
• This guarantee is only Valid in the UK and Eire Only.
An extended warranty is available for this appliance.
See back page for details.
3
www.warmlite.co
WARNING:
This Appliance MUST be Earthed
WIRING SAFETY FOR UK USE ONLY
IMPORTANT
As the colours in the mains lead of this appliance
may not correspond with the coloured markings
identifying the terminals in your plug, please
proceed as follows:
The wires in the mains lead are labelled in
accordance with the following code:
Blue neutral [N] Brown live [L]
Green/Yellow [EARTH]
Plug Fitting Details (Where Applicable). The
wire labelled blue is the neutral and must be
connected to the terminal marked [N].
The wire labelled brown is the live wire and must
be connected to the terminal marked [L].
The wire labelled green/yellow must be
connected to the terminal marked with the letter
[E].
On no account must either the brown or the blue
wire be connected to the [EARTH] terminal.
Always ensure that the cord grip is fastened
correctly.
The plug must be tted with a fuse of the same
rating already tted and conforming to BS 1362
and be ASTA approved.
If in doubt consult a qualied electrician who will
be pleased to do this for you.
Non-Rewireable Mains Plug
If your appliance is supplied with a non-
rewireable plug tted to the mains lead and
should the fuse need replacing, you must use an
ASTA approved one (conforming to BS 1362 of
the same rating).
If in doubt, consult a qualied electrician who will
be pleased to do this for you.
If you need to remove the plug - disconnect it
from the mains - then cut it o of the mains lead
and immediately dispose of it in a safe manner.
Never attempt to reuse the plug or insert it into a
socket outlet as there is a danger of an electric
shock.
FUSE
Earth
(Green/Yellow)
Fuse
Neautral
(Blue)
Live
(Brown)
4
CUSTOMER SUPPORT TEAM: +44 (0) 333 220 6056
PRODUCT SAFETY
When using any electrical appliance, basic safety precautions should
always be followed including the following:
• Check that the voltage of the
main circuit corresponds with
the rating of the appliance
before operating.
• The intended use for this unit
is described in this manual.
The use of any accessory
or attachment or the
performance of any operation
with this appliance other
than those recommended in
this instruction manual may
present a risk of personal
injury.
• Retain this manual for future
reference.
• WARNING! When using
mains-powered appliances,
basic safety precautions,
including the following,
should always be followed to
reduce the risk of re, electric
shock and personal injury
and material damage.
• Check that the voltage of the
main circuit corresponds with
the rating of the appliance
before operating.
• Always ensure that the
appliance is placed on a rm
level surface. Ensure that the
appliance is not positioned
close to curtains, furniture or
any combustible materials
as this could create a re hazard.
The appliance must not be
located immediately below a
mains socket outlet.
• DO NOT immerse cords,
plugs or any part of the
appliance in water or any
other liquid.
• DO NOT let the cord hang
over the edge of a table
or counter or let it come
into contact with any hot
surfaces.
• DO NOT carry the appliance
by the power cord.
• DO NOT use any extension
cord with this appliance.
• The use of accessory
attachments is not
recommended by the
appliance manufacturer,
apart from those supplied
with this product. DO NOT
use extension cords with the
appliance.
• DO NOT pull the plug out by
the cord as this may damage
the plug and/or the cable.
• Switch o at the wall socket
then remove the plug from
the socket when not in use
or before cleaning.
5
www.warmlite.co
• Switch o and unplug before
tting or removing tools/
attachments, after use and
before cleaning.
• DO NOT use this product
for anything other than its
intended use.
• DO NOT leave the appliance
unattended while it is
operating.
• This appliance is for
household use only.
• DO NOT use the appliance
outdoors.
• DO NOT use the appliance
near water.
• Always place wires in a
regular and orderly manner
to prevent the appliance from
becoming a trip hazard or
the plug from accidentally
being pulled out.
• The appliance must not be
located immediately below a
socket outlet.
• Do not use this appliance in
the immediate surroundings
of a bath, a shower or a
swimming pool.
• In order to avoid overheating,
do not cover the appliance.
• Children of less than 3 years
should be kept away unless
continuously supervised.
• Children between the ages of
3 and 8 years old should only
switch the appliance on or
o when it has been placed
and installed in its intended,
normal operating position
and when they have been
given adequate supervision
or instruction concerning
safe use of the appliance
and understand the hazards
involved. Children between
the ages of 3 and 8 years
old should not plug in,
regulate, clean or perform
user maintenance on the
appliance.
• The appliance is not to be
used by persons (including
children) with reduced
physical, sensory or mental
capabilities, or lack of
experience and knowledge,
unless they have been given
supervision or instruction.
• Close supervision is
necessary when any
appliance is used by or near
children.
• Children should not play with
the appliance.
6
CUSTOMER SUPPORT TEAM: +44 (0) 333 220 6056
• This appliance can be
used by children aged
from 8 years and above
and persons with reduced
physical, sensory or mental
capabilities or lack of
experience and knowledge
if they have been given
supervision or instruction
concerning use of the
appliance in a safe way and
understand the hazards
involved.
• CAUTION! Some parts of
this product can become
very hot and cause burns.
Particular attention has to
be given where children
and vulnerable people are
present.
• Cleaning and user
maintenance should not
be undertaken by children
without supervision.
• Take care when any
appliance is used near pets.
• When not in use, please
unplug the portable
appliance from the mains
socket.
• Always unplug the appliance
and allow it to cool before
moving it from one location
to another.
• Please ensure that the
appliance is used on a
stable, level, and heat
resistant surface.
• If the supply cord or
appliance is damaged,
stop using the appliance
immediately and seek advice
from the manufacturer, its
service agent or a similarly
qualied person.
• DO NOT attempt to
dismantle or repair any part
of the appliance. This should
only be done by a qualied
service agent.
• DO NOT install the appliance
in washhouses or other
places with water and moist.
• DO NOT turn the appliance
on or o by inserting or
pulling out the plug.
• DO NOT place things on the
appliance.
• DO NOT put anything into
the air inlet and outlet.
• DO NOT use insecticide
spray or other ammable
matters in the vicinity of the
appliance.
• DO NOT splash oil or water
into the appliance.
7
www.warmlite.co
• DO NOT clean the appliance
with water. Wipe it with a
semi-wet soft cloth.
• DO NOT wipe the appliance
with chemical solvents
such as benzene, gasoline
or alcohol. Use neutral
detergents only.
• Only install the appliance in
at and dry places. Keep the
appliance 50cm away from
surrounding objects.
• The appliance should be
placed away from gasoline,
cooking stoves or other
combustibles and heat
sources.
• Use the appliance in a well-
ventilated area.
• CAUTION! DO NOT operate
the appliance with wet
hands.
• DO NOT tip the appliance
over as this may cause
damage to the appliance and
create a re hazard.
• CAUTION! No wall xings are
provided with this replace
suite. Take care to ensure
the suite is set on a at and
stable surface and placed
against a wall to prevent it
from falling over or being
dislodged.
• In the unlikely event the
appliance develops a fault,
stop using it immediately
and seek advice from the
Customer Support Team.
HIGH VOLTAGE HOT SURFACE DO NOT COVER
8
CUSTOMER SUPPORT TEAM: +44 (0) 333 220 6056
WHAT’S IN THE BOX
Instruction Manual
Wall Fire Suite
1. Surround
2. Flame Eect
3. Control Panel
(Behind Door)
4. Grille
BEFORE YOUR FIRST USE:
The unit is supplied in a single package carton. Carefully unpack the product using the following
procedure:
1. Ensure that the product is in the correct position with the carton wording legible.
2. Remove the straps and sleeve.
3. Carefully lift the replace out of the box.
4. Remove the protective packaging and bag from the suite.
5. Carefully remove the protective lm covering the re.
6. Your appliance is now ready for normal use.
Dispose of the packaging in a responsible manner.
The images are for illustration purposes only and might not be a true indication of the actual product.
1
2
3
4
9
www.warmlite.co
HANDLING
Before continuing any further with the
installation of this re please read the following:
• Two people should be sucient to lift the
re.
• When lifting always keep your back
straight. Bend your legs and not your
back.
• Avoid twisting at the waist. It is better to
reposition your feet.
• Avoid upper body / top heavy bending.
Always bend from the knees rather
than the waist. Do not lean forward or
sideways whilst handling the re.
• Always grip with the palm of your hand.
Do not use the tips of ngers for support.
• Always keep the product as close to the
body as possible to prevent unnecessary
and undue strain on the body.
• Use gloves to provide additional grip.
• Always use assistance if required.
USING YOUR APPLIANCE:
The appliance is operated through the switches
and temperature control dial located inside the
main door of the re.
Turning the Unit On and Off:
• When turning the unit on, make sure the
ON/OFF switch, located on the right side
panel, is in the OFF position. Plug the
power cord into a 220~240 grounded
outlet.
CAUTION! Make sure the outlet is in good
condition and that the plug is not loose. NEVER
exceed the maximum amperage for the circuit.
DO NOT plug other appliances into the same
circuit.
• Flick the On/O switch on the unit’s main
body to the ‘On’ position (represented by
the symbol ‘I’) to turn it on. The LED ame
eect will come on to indicate the unit is in
operation.
• Flick this switch to the ‘O’ position
(represented by the symbol ‘O’) while the
unit is in operation to turn it o. The LED
ame eect will turn o to indicate the unit
has been turned o.
Selecting the Heat Setting:
• This unit is equipped with a choice of
1000W or 2000W heat settings.
• Flick the corresponding switch on the
unit’s main body to the ‘On’ position to
select each of the two heat settings. Flick
the ‘I’ switch to the On position for the
Low heat setting, or the ‘II’ switch for the
High heat setting.
NOTE: Always ensure the ‘I’ switch is set to
the ‘On’ position before turning on the ‘II’ heat
switch.
• Flick either or both of these switches
to the ‘O’ position when the unit is in
operation to turn the heating function o.
NOTE: The LED ame eect operates
independently from the heating function, and
will stay on even after the heat switches have
been set to the ‘O’ position.
10
CUSTOMER SUPPORT TEAM: +44 (0) 333 220 6056
Selecting the Temperature:
• Once the desired heat setting has been
activated, the actual heating temperature
within the selected range can be adjusted
using the unit’s thermostat dial.
• Rotate the thermostat dial clockwise (to
the right) to increase the temperature, or
counter-clockwise (to the left) to decrease
it.
NOTE: The thermostat dial must be rotated
clockwise before heat begins emitting from the
unit. There will be a clicking sound to indicate
the heating function has been activated. The
same clicking sound will indicate the heating
function has been turned o when the dial is
rotated counter-clockwise.
NOTE: Once the desired ambient temperature
is reached, the heater will automatically stop
heating. Whenever the ambient temperature
drops more than 2°C below the desired
temperature, the heater will resume operation.
Safety Cut-Out:
• This appliance is tted with a safety cut-
o device, which will operate if the re
overheats (e.g. due to blocked air vents).
For safety reasons, the re will NOT
automatically reset.
• To reset the appliance, disconnect the
appliance from the mains supply for at
least 15 minutes. Reconnect to the mains
supply and switch on the appliance.
• If the re fails to operate, check the fuse in
the plug. If the fuse in the plug is OK and
the re is still not functioning, contact a
qualied service person.
CAUTION! Do not touch the re as it will be
hot. Set the heater switches to OFF and leave
the re to cool down fully. Once completely
cool, reconnect the heater and switch it on.
Do not open this product. There are no user-
serviceable parts inside.
CHECK THAT YOU HAVE NOTED ALL THE
FOLLOWING INSTRUCTIONS:
Do:
• Always install the re in accordance with
this guide. If in doubt obtain expert advice.
• Always make sure the electrical socket is
accessible and located adjacent to, but
not above or behind the re.
• Always disconnect the re from the
electrical supply before carrying out
cleaning or maintenance.
• Always make sure the re is rmly
secured.
• Always assemble the re in accordance
with this guide. If in doubt, obtain expert
advice.
• Always ensure the product is assembled
in an area that is free from dust, grease or
liquids.
• Always ensure that the correct tools are
used to assemble/install this product.
• Always make sure the re is rmly secured
in place when complete.
Don’t:
• Never leave children unsupervised in a
room where the re is ON and unguarded.
• Never obstruct or cover the fan outlet or
force items into the re openings.
• Never install or use the re anywhere
where water is in use, i.e. bathrooms,
kitchens, shower rooms, swimming pools
etc.
• Never use aerosols or steam cleaners on
or around the re.
• Never route the mains supply cable under
carpet etc.
• Never install the re close to curtains or
combustible materials.
• Never use the re to dry clothes etc.
• Never sit or stand on the re.
• Never cut the o the plug and hard wire
into a xed fused spur.
11
www.warmlite.co
NOTE: Any new wiring required, must be in
accordance with local and national codes and
other applicable regulations in order to reduce
the risk of re, electric shock, or other injuries.
NOTE: When the re is turned on for the rst
time or when it has not been used for some
time, it may release a slight, harmless odour.
This odour is a normal occurrence caused
by the initial heating of the internal heating
elements or dust, and will disappear with use.
TROUBLE SHOOTING
Symptom Corrective action
No operation
No fan.
Check that the
safety cut-o has not
activated.
Check that the unit is
plugged into the mains
and that the On/O
switch has been set to
the ON position.
Ensure the temperature
control dial is not in the
OFF position.
Check that the fuse
is working. If broken,
a replacement is
necessary.
No light Check that the LED
is working. If broken,
a replacement is
necessary.
CLEANING AND CARE
WARNING! Always disconnect from the mains
supply before cleaning the wall re.
CAUTION! Allow the product to completely cool
before handling or cleaning it.
• For general cleaning use a soft clean
duster - never use harsh abrasives or
cleaners.
• The glass viewing screen should be
cleaned carefully with a soft cloth.
• Do not allow water or other liquids to run
into the interior of the product, as this
could cause a re and/or electrical hazard.
• We also recommend the periodic cleaning
of this appliance by lightly running a
vacuum cleaner nozzle over the guards
to remove any dust or dirt that may have
accumulated inside or on the unit.
CAUTION! Do not use harsh detergents,
chemical cleaners or solvents as they may
damage the surface nish of the plastic
components.
WARNING:
DO NOT IMMERSE ANY ELECTRICAL PART
OF THE APPLIANCE IN WATER SUCH AS
MOTOR UNITS OR PLUGS.
PLEASE SEE CLEANING SECTION FOR
FURTHER INSTRUCTIONS.
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here
may not be disposed of in domestic rubbish.
You are required to dispose of old electrical
and electronic appliances like this separately.
Please visit www.recycle-more.co.uk or
www.recyclenow.co.uk
for access to information about the recycling
of electrical items.
Please visit www.weeeireland.ie for access to
information about the recycling of electrical
items purchased in Ireland.
The WEEE directive, introduced in August
2006, states that all electrical items must be
recycled, rather than taken to landll.
Please arrange to take this appliance to your
local Civic Amenity site for recycling, once it
has reached the end of its life.
12
CUSTOMER SUPPORT TEAM: +44 (0) 333 220 6056
Model Identifier(s): WL45045
Item Symbol Valve Unit Item Unit
Heat Output
Type of heat input for electric storage, local
space heaters only (select one)
Nominal heat
output
Pnom 1.85 kW
Manual heat charge with integrated
thermostat
NA
Minimum heat
output (indicative)
Pmin 0.95 kW
Manual heat charge control with room
and/or outdoor temperature feedback
NA
Maximum
continuous heat
output
Pmax, c 1.85 kW
Electronic heat charge control with
room
and/or outdoor temperature feedback
NA
Auxiliary electricity
consumption
Fan assisted heat output NA
At nominal heat
output
elmax 0.012 kW
Type of heat output/room temperature control
(select one)
At minimum heat
output
elmin 0.012 kW
Single stage heat output and no room
temperature control
No
In standby mode eISB 0 kW
Two or more manual stages, no room
temperature control
No
With mechanic thermostat room
temperature control
Yes
With electronic room temperature
control
No
Electronic room temperature control
plus day timer
No
Electronic room temperature control
plus week timer
No
Other control options (multiple selections
possible)
Room temperature control with pres-
ence detection
No
Room temperature control with open
window detection
No
With distance control option No
With adaptive start control No
With working time limitation No
With black bulb sensor No
Contact Details: Imported by RK Wholesale LTD., Berryhill Road, Stoke-on-Trent ST4 2NL
13
www.warmlite.co
NOTES
14
CUSTOMER SUPPORT TEAM: +44 (0) 333 220 6056
NOTES
15
www.warmlite.co
NOTES
We hope you enjoy your appliance for many years.
As a thank you for purchasing one of our fantastic products,
we are oering you an extra 1 year peace of mind.
*To receive your extra guarantee period, register your appliance online
within 28 days of purchase by visiting:
www.warmlite.co
Make sure to retain your original receipt.
Should you have a problem
with your appliance or need any spare parts please call our
Customer Support Team on:
+44 (0) 333 220 6056
Distributed throughout the UK by RK Wholesale LTD
0120.V2
