www.warmlite.co
GLASS WALL MOUNTED
FIREPLACE
WL45038
YOUR SAFETY &
INSTRUCTION MANUAL
PLEASE READ CAREFULLY
2 CUSTOMER SUPPORT TEAM: +44 (0) 333 220 6056
TECHNICAL DATA
Description: Glass Wall Mounted Fireplace
Model: WL45038
Rated Voltage: 220-240V
Frequency: 50Hz
Power Consumption: 2000W
DOCUMENTATION
We declare that this product conforms to the following product legislation in accordance with the
following directive(s):
2014/30/EU Electromagnetic Compatibility Directive.
2014/35/EU Low Voltage Directive.
2011/65/EU Restriction of Hazardous Substances Directive.
2009/125/EC Eco-Design of Energy Related Products.
RK Wholesale LTD Quality Assurance, United Kingdom
WARRANTY
This product is guaranteed for 12 months from the date of original purchase. If any defect arises due
to faulty materials of workmanship, the faulty products must be returned to the place of purchase.
Refund or replacement is at the discretion of the retailer.
The following conditions apply:
• The product must be returned to the retailer with proof of purchase.
• The product must be installed and used in accordance with the instructions contained in this
instruction guide.
• It must be used only for domestic purposes.
• It does not cover wear and tear, damage, misuse or consumable parts.
• RK Wholesale LTD has limited liability for incidental or consequential loss or damage.
• This guarantee is only Valid in the UK and Eire Only.
An extended warranty is available for this appliance.
See back page for details.
3www.warmlite.co
WARNING:
This Appliance MUST be Earthed
WIRING SAFETY FOR UK USE ONLY
IMPORTANT
As the colours in the mains lead of this appliance
may not correspond with the coloured markings
identifying the terminals in your plug, please
proceed as follows:
The wires in the mains lead are labelled in
accordance with the following code:
Blue neutral [N] Brown live [L]
Green/Yellow [EARTH]
Plug Fitting Details (Where Applicable). The
wire labelled blue is the neutral and must be
connected to the terminal marked [N].
The wire labelled brown is the live wire and must
be connected to the terminal marked [L].
The wire labelled green/yellow must be
connected to the terminal marked with the letter
[E].
On no account must either the brown or the blue
wire be connected to the [EARTH] terminal.
Always ensure that the cord grip is fastened
correctly.
The plug must be tted with a fuse of the same
rating already tted and conforming to BS 1362
and be ASTA approved.
If in doubt consult a qualied electrician who will
be pleased to do this for you.
Non-Rewireable Mains Plug
If your appliance is supplied with a non-
rewireable plug tted to the mains lead and
should the fuse need replacing, you must use an
ASTA approved one (conforming to BS 1362 of
the same rating).
If in doubt, consult a qualied electrician who will
be pleased to do this for you.
If you need to remove the plug - disconnect it
from the mains - then cut it o of the mains lead
and immediately dispose of it in a safe manner.
Never attempt to reuse the plug or insert it into a
socket outlet as there is a danger of an electric
shock.
FUSE
Earth
(Green/Yellow)
Fuse
Neautral
(Blue)
Live
(Brown)
4 CUSTOMER SUPPORT TEAM: +44 (0) 333 220 6056
PRODUCT SAFETY
When using any electrical appliance, basic safety precautions should
always be followed including the following:
• Check that the voltage of the
main circuit corresponds with
the rating of the appliance
before operating.
• The intended use for this unit
is described in this manual.
The use of any accessory
or attachment or the
performance of any operation
with this appliance other
than those recommended in
this instruction manual may
present a risk of personal
injury.
• Retain this manual for future
reference.
• WARNING! When using
mains-powered appliances,
basic safety precautions,
including the following,
should always be followed to
reduce the risk of re, electric
shock and personal injury
and material damage.
• Check that the voltage of the
main circuit corresponds with
the rating of the appliance
before operating.
• Always ensure that the
appliance is placed on a rm
level surface. Ensure that the
air cooler is not positioned
close to curtains, furniture or
any combustible materials
as this could create a re
hazard. The appliance must
not be located immediately
below a mains socket outlet.
• DO NOT immerse cords,
plugs or any part of the
appliance in water or any
other liquid.
• DO NOT let the cord hang
over the edge of a table
or counter or let it come
into contact with any hot
surfaces.
• DO NOT carry the appliance
by the power cord.
• DO NOT use any extension
cord with this appliance.
• The use of accessory
attachments is not
recommended by the
appliance manufacturer,
apart from those supplied
with this product. DO NOT
use extension cords with the
appliance.
• DO NOT pull the plug out by
the cord as this may damage
the plug and/or the cable.
• Switch o at the wall socket
then remove the plug from
the socket when not in use
or before cleaning.
5www.warmlite.co
• Switch o and unplug before
tting or removing tools/
attachments, after use and
before cleaning.
• DO NOT use this product
for anything other than its
intended use.
• DO NOT leave the appliance
unattended while it is
operating.
• This appliance is for
household use only.
• DO NOT use the appliance
outdoors.
• DO NOT use the appliance
near water.
• Always place wires in a
regular and orderly manner
to prevent the air cooler from
becoming a trip hazard or
the plug from accidentally
being pulled out.
• The heater must not be
located immediately below a
socket outlet.
• Do not use this heater in
the immediate surroundings
of a bath, a shower or a
swimming pool.
• In order to avoid overheating,
do not cover the heater.
• Children of less than 3 years
should be kept away unless
continuously supervised.
• Children between the ages of
3 and 8 years old should only
switch the appliance on or
o when it has been placed
and installed in its intended,
normal operating position
and when they have been
given adequate supervision
or instruction concerning
safe use of the appliance
and understand the hazards
involved. Children between
the ages of 3 and 8 years
old should not plug in,
regulate, clean or perform
user maintenance on the
appliance.
• The appliance is not to be
used by persons (including
children) with reduced
physical, sensory or mental
capabilities, or lack of
experience and knowledge,
unless they have been given
supervision or instruction.
• Close supervision is
necessary when any
appliance is used by or near
children.
• Children should not play with
the appliance.
6 CUSTOMER SUPPORT TEAM: +44 (0) 333 220 6056
• This appliance can be
used by children aged
from 8 years and above
and persons with reduced
physical, sensory or mental
capabilities or lack of
experience and knowledge
if they have been given
supervision or instruction
concerning use of the
appliance in a safe way and
understand the hazards
involved.
• CAUTION! Some parts of
this product can become
very hot and cause burns.
Particular attention has to
be given where children
and vulnerable people are
present.
• Cleaning and user
maintenance should not
be undertaken by children
without supervision.
• Take care when any
appliance is used near pets.
• When not in use, please
unplug the portable air cooler
from the mains socket.
• Always unplug the appliance
and allow it to cool before
moving it from one location
to another.
• Please ensure that the
appliance is used on a
stable, level, and heat
resistant surface.
• If the supply cord or
appliance is damaged,
stop using the appliance
immediately and seek advice
from the manufacturer, its
service agent or a similarly
qualied person.
• DO NOT attempt to
dismantle or repair any part
of the heater. This should
only be done by a qualied
service agent.
• DO NOT install the heater in
washhouses or other places
with water and moist.
• DO NOT turn the heater on
or o by inserting or pulling
out the plug.
• DO NOT place things on the
heater.
• DO NOT put anything into
the air inlet and outlet.
• DO NOT use insecticide
spray or other ammable
matters in the vicinity of the
heater.
• DO NOT splash oil or water
into the heater.
7www.warmlite.co
• DO NOT clean the heater
with water. Wipe it with a
semi-wet soft cloth.
• DO NOT wipe the heater with
chemical solvents such as
benzene, gasoline or alcohol.
Use neutral detergents only.
• Only install the heater in at
and dry places. Keep the
heater 50cm away from
surrounding objects.
• The heater should be placed
away from gasoline, cooking
stoves or other combustibles
and heat sources.
• Use the appliance in a well-
ventilated area.
• CAUTION! DO NOT operate
the appliance with wet
hands.
• DO NOT tip the appliance
over as this may cause
damage to the appliance and
create a re hazard.
• In the unlikely event the
appliance develops a fault,
stop using it immediately
and seek advice from the
Customer Support Team.
HIGH VOLTAGE HOT SURFACE DO NOT COVER
8 CUSTOMER SUPPORT TEAM: +44 (0) 333 220 6056
WHAT’S IN THE BOX
Instruction Manual
Fireplace
Wall Fixing Bracket
Wall Mounting Kit
Decorative Pebbles
Remote Control
1. Fireplace
2. Digital Display
3. Control Panel
4. Flame Eect
5. Pebbles
6. LED strip lights
BEFORE YOUR FIRST USE:
1. Remove your appliance from the packaging.
2. Install your appliance in accordance with the installation & safety instructions.
3. Your appliance is now ready for normal use.
Dispose of the packaging in a responsible manner.
1
4 5
2 3
6
9www.warmlite.co
HANDLING
Before continuing any further with the
installation of this re please read the following:
• Two people should be sucient to lift the
re.
• When lifting always keep your back
straight. Bend your legs and not your
back.
• Avoid twisting at the waist. It is better to
reposition your feet.
• Avoid upper body / top heavy bending.
Always bend from the knees rather
than the waist. Do not lean forward or
sideways whilst handling the re.
• Always grip with the palm of your hand.
Do not use the tips of ngers for support.
• Always keep the product as close to the
body as possible to prevent unnecessary
and undue strain on the body.
• Use gloves to provide additional grip.
• Always use assistance if required.
UNPACKING THE PRODUCT
The unit is supplied in a single package
carton. Carefully unpack the product using the
following procedure:
• Ensure that the product is in the correct
position with the carton wording legible.
• Remove the straps and sleeve.
• Carefully lift the replace out of the box.
• Remove the protective packaging and
bag from the suite.
IMPORTANT:
Always ensure there is enough
room to place it.
Please ensure that there is an accessible
electrical socket within the space for
installation. The electrical socket must not be
behind or above the suite.
INSTALLATION
This appliance is designed to be permanently
xed to a wall at a minimum height of 30cm.
The wall bracket must be tted horizontally
and the cable routed to the bottom right of the
heater. It is recommended that the distance
between the bottom of the replace and the
oor is of at least 60cm.
To wall-mount the replace, carry out the
following instructions:
1. Using the bracket as a template, mark
ve drill positions on the wall. Make
sure these holes are level. Observe the
recommended xing dimensions.
2. Put the bracket aside and drill holes with a
depth of 35 mm using an 8 mm drill bit.
3. Clean the holes thoroughly and insert one
plug in each hole. Make sure the edge of
each plug is ush with the surface
4. Hold the bracket in position and x it with
screws.
5. Attach the xing angle to the bottom of
the appliance using the short screws.
6. Carefully lift the appliance and hook it to
the wall bracket. DO NOT let go of the
appliance until you are sure it is safely
engaged to the bracket, as this could
cause you physical harm as well as
damage the appliance.
7. Now mark the hole position for xing the
angle. Carefully remove the appliance from
the bracket and once again drill holes with
a depth of 35 mm using an 8 mm drill bit.
8. Clean these new holes thoroughly and
insert one plug in each hole. Make sure
the edge of each plug is ush with the
surface
9. Lift the appliance up again, engage it to
the bracket and x the angle with screws.
IMPORTANT: Do not connect the appliance
until it is properly xed to the wall and the
instructions have been read fully.
Select a location that is not prone to moisture
and is located at least 36” away from any
combustible materials, such as curtain drapes,
furniture, bedding, paper, etc.
10 CUSTOMER SUPPORT TEAM: +44 (0) 333 220 6056
Placing the Decorative Pebbles:
This unit comes complete with decorative
pebbles, to be placed on the inside of the
appliance.
To place the pebbles inside the re, begin by
opening the front panel. To do this, locate the
2 xing screws on either side of the unit, near
the bottom bracket, and use a screwdriver to
loosen them by turning them anti-clockwise (to
the left). Repeat this process with the 2 screws
on the opposite side of the replace, so that all
4 screws are loose.
When all 4 screws have been loosened, remove
them to one side and carefully pull the front
glass panel of the re away from the main body
of the unit. You can now place the decorative
pebbles inside the re.
Loosely scatter the pebbles over the main inner
area of the replace. Once you are happy with
the arrangement, place the front panel back
into position and insert the xing screws back
into their respective slots on either side of the
unit. Use a screwdriver to tighten each screw
into place by turning it clockwise (to the right).
so that the glass panel is secured and cannot
come loose.
NOTE: Ensure the glass panel is rmly secured
into place before attempting to use the re.
Your replace is now ready for use.
USING YOUR APPLIANCE
Turning the Appliance On and Off:
• To turn the appliance on, rst plug it into a
mains outlet.
• Once the appliance has been plugged
in, press the Power ON/OFF button on
the remote control or the unit’s control
panel to turn the appliance on. A red LED
indicator will light up to show the unit has
been turned on.
• Press this button again while the replace
is in operation to turn it o.
NOTE: When using the remote control, rst
ensure the Standby switch located on the top
right-hand side of the appliance is switched on;
otherwise, the remote operation function will
not work.
NOTE: When using the remote control to
operate the unit, there will be a delay between
the button press and the corresponding
function being activated. DO NOT press a
button more than once every two seconds to
ensure optimal operation.
Auto Function:
This replace is equipped with an Auto
function, in which the LED ame eect will
automatically change at 10-second intervals.
Long-press the Power ON/OFF button on the
remote control or the unit’s control panel to turn
the Auto ame function on.
Heat Selection:
This replace oers a choice of two heat
settings: Low (1000W) or High (2000W).
Each of these two settings is represented by
a corresponding button on the remote control
and the unit’s control panel.
To select your preferred heat settings, carry out
the following instructions:
• To select the Low heat setting, press the
1000W button on the remote control or
the unit’s control panel. Press this button
again to turn the heating function o.
• To select the High heat setting, press the
2000W button on the remote control or
the unit’s control panel. Press this button
again to turn the heating function o.
Setting The Time And Date:
• This unit is equipped with a built-in timer,
which allows for programmable, hands-
free timed operation. To make use of the
unit’s timer, begin by setting the correct
time and date.
11www.warmlite.co
• Press the ‘Correct’ button on the unit’s
control panel to begin selecting and
adjusting the time and date. Press this
button once to select the hours, press it
again to select the minutes, and press it a
third time to select the day of the week..
• The corresponding indicators or digits on
the LCD control panel will ash to indicate
they have been selected and can now be
adjusted.
• When each setting has been selected,
press the + or - buttons on the unit’s
remote control to manually adjust it.
• The unit will automatically save the
selected settings to memory after a few
seconds. The corresponding indicators or
digits on the LCD control panel will stop
ashing to indicate each setting has been
saved to memory.
Setting The Timer:
Note: Ensure the correct time and date have
been set before attempting to program a timer.
• Press the ‘Set’ button on the unit’s remote
control to begin setting a timer. The
‘Timer’ indicator on the unit’s control panel
will light up and begin to ash to indicate
timer selection mode has been activated.
• Once this mode is activated, press the
‘Set’ once to select the starting day for
the timer. The ‘ON’ indicator will light up
on the unit’s control panel to indicate the
start timer is now being selected. Once
this indicator is lit, press the ‘SET’ button
again to select the starting hour, press it
a third time to select the starting minutes,
and press it a fourth time to select the
desired operating temperature. The
corresponding indicators or digits on the
LCD control panel will ash to indicate
they have been selected and can now be
adjusted.
• When each setting has been selected,
press the Up and Down arrows on the
unit’s remote control to manually adjust
it. Press the ‘Set’ button again once each
setting has been adjusted to move on to
the next one.
Note: When selecting the starting or ending day
for each timer, ensure the Down arrow indicator
on the unit’s control panel lights up; otherwise,
the timer may not have been properly saved to
memory or activated.
• Press the ‘Set’ button again once all the
settings have been adjusted to move on
to the ending date and time selection. The
‘OFF’ indicator will light up on the unit’s
control panel to indicate the end timer is
now being selected. Once this indicator is
lit, repeat the process as detailed above to
set the ending time, date and temperature
for the currently selected timer.
• Press the ‘OK’ button once all the
settings have been adjusted to exit the
timer programming function. The unit will
automatically save the selected settings
to memory.
• Press the Power button on the remote
control or the unit’s control panel to reset
all programmed timers and temperature
settings.
Adjusting the Flame Effect:
• The re’s LED ame eect can be dimmed
or its colour changed between an array
of four primary colours and six mixed
colours, as required.
• Press the Dimmer button on the remote
control or the unit’s control panel to adjust
the brightness of the ame eect.
• Press the ‘Colour’ button on the unit’s
remote control while the LED ame
eect is activated to change its colour.
Repeatedly press this button to cycle
between the available colours.
12 CUSTOMER SUPPORT TEAM: +44 (0) 333 220 6056
Adjusting the LED Strip Lights:
This unit is equipped with colour-changing LED
strip lights to either side of the main panel.
• Press the ‘Backlight’ button on the unit’s
remote control to turn the LED strip lights
on.
• Repeatedly press the ‘Backlight’ button
once the lights have been turned on to
cycle through the 6 available colours.
Press this button a seventh time to turn
the LED strip lights o.
Overheat Protection:
• The replace is equipped with an overheat
protection function, which automatically
activates whenever the unit’s inner
temperature becomes too high.
• For safety reasons, when the overheat
protection function activates, the unit will
NOT automatically turn itself o; it will
need to be reset manually.
• To manually reset the unit, unplug the unit
from the mains and wait for approximately
15 minutes. Once this time elapses,
reconnect the unit to the mains supply
and turn it on.
• If after this time the replace still fails to
operate correctly, contact our Customer
Services team or a qualied repair
technician.
TROUBLE SHOOTING
Problem Cause Solution
The unit
doesn’t
operate
No power
supply
Heat
setting not
selected or
too low
Overheat
protection
feature
activated
Connect the unit
to a functioning
power outlet.
Make sure
the relevant
heat selection
button has been
pressed.
Unplug the unit
from the mains,
wait for about
15 minutes and
plug it back in.
If it still does not
operate correctly
after this time,
consult a
qualied repair
technician or
contact our
Customer
Support team.
Low
heating
power
No LED
ame
eect/
Flame
eect too
dim
High heat
setting not
selected
Faulty or
blown LED
lamp.
Select the High
heat setting by
pressing the
2000W button
on the remote
control or the
unit’s control
panel.
Contact our
Customer
Support team
or a qualied
service engineer
for replacement.
13www.warmlite.co
CLEANING AND CARE
WARNING! Always disconnect from the mains
supply before cleaning the wall re.
CAUTION! Allow the product to completely
cool before handling or cleaning it.
• Clean the surface of the unit with a soft
damp cloth. Never use detergents, harsh
cleaning agents or sprays, as these could
cause damage to the surface.
• To clean the glass viewing panel, wipe it
carefully with a soft cloth. DO NOT use
proprietary glass cleaners to clean this
panel, as they could cause damage to the
glass surface.
CAUTION! Do not use harsh detergents,
chemical cleaners or solvents as they may
damage the surface nish of any plastic
components.
Replacing the Lamp:
This unit is tted with a replaceable LED lamp.
This should only be repaired or replaced by a
professionally trained person. DO NOT attempt
to replace or repair the LED lamp yourself.
Should it develop a fault, contact our Customer
Support team or a qualied repair technician.
WARNING:
DO NOT IMMERSE ANY ELECTRICAL PART
OF THE APPLIANCE IN WATER SUCH AS
MOTOR UNITS OR PLUGS.
PLEASE SEE CLEANING SECTION FOR
FURTHER INSTRUCTIONS.
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here
may not be disposed of in domestic rubbish.
You are required to dispose of old electrical
and electronic appliances like this separately.
Please visit www.recycle-more.co.uk or
www.recyclenow.co.uk
for access to information about the recycling
of electrical items.
Please visit www.weeeireland.ie for access to
information about the recycling of electrical
items purchased in Ireland.
The WEEE directive, introduced in August
2006, states that all electrical items must be
recycled, rather than taken to landll.
Please arrange to take this appliance to your
local Civic Amenity site for recycling, once it
has reached the end of its life.
14 CUSTOMER SUPPORT TEAM: +44 (0) 333 220 6056
Model Identifier(s): WL45038
Item Symbol Valve Unit Item Unit
Heat Output
Type of heat input for electric storage, local
space heaters only (select one)
Nominal heat
output
Pnom 2.0 kW
Manual heat charge with integrated
thermostat
NA
Minimum heat
output (indicative)
Pmin 0.0053 kW
Manual heat charge control with room
and/or outdoor temperature feedback
NA
Maximum
continuous heat
output
Pmax, c 2.0 kW
Electronic heat charge control with
room
and/or outdoor temperature feedback
NA
Auxiliary electricity
consumption
Fan assisted heat output NA
At nominal heat
output
elmax NA kW
Type of heat output/room temperature control
(select one)
At minimum heat
output
elmin NA kW
Single stage heat output and no room
temperature control
No
In standby mode eISB 0.00023 kW
Two or more manual stages, no room
temperature control
No
Heat Output
With mechanic thermostat room
temperature control
No
Nominal heat
output
Pnom NA kW
With electronic room temperature
control
Yes
Minimum heat
output (indicative)
Pmin NA kW
Electronic room temperature control
plus day timer
Yes
Maximum
continuous heat
output
Pmax, c NA kW
Electronic room temperature control
plus week timer
Yes
Auxiliary electricity
consumption
Other control options (multiple selections
possible)
At nominal heat
output
elmax NA kW
Room temperature control with pres-
ence detection
No
At minimum heat
output
elmin NA kW
Room temperature control with open
window detection
Yes
In standby mode eISB NA kW With distance control option No
With adaptive start control No
With working time limitation Yes
With black bulb sensor No
Contact Details: Imported by RK Wholesale LTD., Berryhill Road, Stoke-on-Trent ST4 2NL
15www.warmlite.co
We hope you enjoy your appliance for many years.
As a thank you for purchasing one of our fantastic products,
we are oering you an extra 1 year peace of mind.
*To receive your extra guarantee period, register your appliance online
within 28 days of purchase by visiting:
www.warmlite.co
Make sure to retain your original receipt.
Should you have a problem
with your appliance or need any spare parts please call our
Customer Support Team on:
+44 (0) 333 220 6056
Distributed throughout the UK by RK Wholesale LTD
1219.V2
