WHITBY 2KW ELECTRIC FIRE INSET
WL45048/WL45049
YOUR SAFETY &
INSTRUCTION MANUAL
PLEASE READ CAREFULLY
This product is only suitable for well insulated spaces or occasional use
2 CUSTOMER SUPPORT TEAM: +44 (0) 333 220 6056
WHAT’S IN THE BOX
Instruction Manual
Fire Inset & Surround
Coals
Remote Control
Fire Guard Grille
1. Surround
2. Control Panel
3. Heater Grille
4. Flame Eect
5. Fire Guard Grille
6. LED Display
7. ON/OFF Switch
8. Remote Control
The images are for illustration purposes only and might not be a true indication of the actual product.
1
2
3
4
5
6
7
TECHNICAL DATA
Description: Whitby 2KW Electric Fire Inset
Model: WL45048 Chrome
WL45049 Brass
Rated Voltage: 220-240V
Frequency: 50Hz
Power Consumption: 1800 - 2000W
Lighting: LEDs
DOCUMENTATION
We declare that this product conforms to the following product legislation in accordance with the following directive(s):
2014/30/EU Electromagnetic Compatibility Directive.
2014/35/EU Low Voltage Directive.
2011/65/EU Restriction of Hazardous Substances Directive.
2009/125/EC Eco-Design of Energy Related Products.
RK Wholesale LTD Quality Assurance, United Kingdom
8
3www.warmlite.co
WIRING SAFETY FOR UK USE ONLY
IMPORTANT
As the colours in the mains lead of this appliance
may not correspond with the coloured markings
identifying the terminals in your plug, please
proceed as follows:
The wires in the mains lead are labelled in
accordance with the following code:
Blue neutral [N] Brown live [L] Green/Yellow
[EARTH]
Plug Fitting Details (Where Applicable).
The wire labelled blue is the neutral and must be
connected to the terminal marked [N].
The wire labelled brown is the live wire and must
be connected to the terminal marked [L].
The wire labelled green/yellow must be
connected to the terminal marked with the letter
[E].
On no account must either the brown or the blue
wire be connected to the [EARTH] terminal.
Always ensure that the cord grip is fastened
correctly.
The plug must be tted with a fuse of the same
rating already tted and conforming to BS 1362
and be ASTA approved.
If in doubt consult a qualied electrician who will
be pleased to do this for you.
Non-Rewireable Mains Plug.
If your appliance is supplied with a non-
rewireable plug tted to the mains lead and
should the fuse need replacing, you must use an
ASTA approved one (conforming to BS 1362 of
the same rating).
If in doubt, consult a qualied electrician who will
be pleased to do this for you.
If you need to remove the plug - disconnect it
from the mains - then cut it o of the mains lead
and immediately dispose of it in a safe manner.
Never attempt to reuse the plug or insert it into a
socket outlet as there is a danger of an electric
shock.
FUSE
Earth
(Green/Yellow)
Fuse
Neutral
(Blue)
Live
(Brown)
WARNING:
This appliance MUST be earthed!
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here may not be disposed of in domestic rubbish.
You are required to dispose of old electrical and electronic appliances like this separately.
Please visit www.recycle-more.co.uk or www.recyclenow.co.uk for access to information about the
recycling of electrical items.
Please visit www.weeeireland.ie for access to information about the recycling of
electrical items purchased in Ireland.
The WEEE directive, introduced in August 2006, states that all electrical items must be
recycled, rather than taken to landll.
Please arrange to take this appliance to your local Civic Amenity site for recycling,
once it has reached the end of its life.
4 CUSTOMER SUPPORT TEAM: +44 (0) 333 220 6056
PRODUCT SAFETY
When using any electrical appliance, basic safety precautions should
always be followed including the following:
• Check that the voltage of the
main circuit corresponds with
the rating of the appliance
before operating.
• The intended use for this unit
is described in this manual.
The use of any accessory
or attachment or the
performance of any operation
with this appliance other
than those recommended in
this instruction manual may
present a risk of personal
injury.
• Retain this manual for future
reference.
• WARNING! When using
mains-powered appliances,
basic safety precautions,
including the following,
should always be followed to
reduce the risk of re, electric
shock and personal injury
and material damage.
• Check that the voltage of the
main circuit corresponds with
the rating of the appliance
before operating.
• Always ensure that the
appliance is placed on a rm
level surface. Ensure that the
appliance is not positioned
close to curtains, furniture or
any combustible materials
as this could create a re hazard.
The appliance must not be
located immediately below a
mains socket outlet.
• DO NOT immerse cords,
plugs or any part of the
appliance in water or any
other liquid.
• DO NOT let the cord hang
over the edge of a table
or counter or let it come
into contact with any hot
surfaces.
• DO NOT carry the appliance
by the power cord.
• DO NOT use any extension
cord with this appliance.
• The use of accessory
attachments is not
recommended by the
appliance manufacturer,
apart from those supplied
with this product. DO NOT
use extension cords with the
appliance.
• DO NOT pull the plug out by
the cord as this may damage
the plug and/or the cable.
• Switch o at the wall socket
then remove the plug from
the socket when not in use
or before cleaning.
5www.warmlite.co
• Switch o and unplug before
tting or removing tools/
attachments, after use and
before cleaning.
• DO NOT use this product
for anything other than its
intended use.
• DO NOT leave the appliance
unattended while it is
operating.
• This appliance is for
household use only.
• DO NOT use the appliance
outdoors.
• DO NOT use the appliance
near water.
• Always place wires in a
regular and orderly manner
to prevent the appliance from
becoming a trip hazard or
the plug from accidentally
being pulled out.
• The appliance must not be
located immediately below a
socket outlet.
• Do not use this appliance in
the immediate surroundings
of a bath, a shower or a
swimming pool.
• In order to avoid overheating,
do not cover the appliance.
• Children of less than 3 years
should be kept away unless
continuously supervised.
• Children between the ages of
3 and 8 years old should only
switch the appliance on or
o when it has been placed
and installed in its intended,
normal operating position
and when they have been
given adequate supervision
or instruction concerning
safe use of the appliance
and understand the hazards
involved. Children between
the ages of 3 and 8 years
old should not plug in,
regulate, clean or perform
user maintenance on the
appliance.
• The appliance is not to be
used by persons (including
children) with reduced
physical, sensory or mental
capabilities, or lack of
experience and knowledge,
unless they have been given
supervision or instruction.
• Close supervision is
necessary when any
appliance is used by or near
children.
• Children should not play with
the appliance.
6 CUSTOMER SUPPORT TEAM: +44 (0) 333 220 6056
• This appliance can be
used by children aged
from 8 years and above
and persons with reduced
physical, sensory or mental
capabilities or lack of
experience and knowledge
if they have been given
supervision or instruction
concerning use of the
appliance in a safe way and
understand the hazards
involved.
• CAUTION! Some parts of
this product can become
very hot and cause burns.
Particular attention has to
be given where children
and vulnerable people are
present.
• Cleaning and user
maintenance should not
be undertaken by children
without supervision.
• Take care when any
appliance is used near pets.
• When not in use, please
unplug the portable
appliance from the mains
socket.
• Always unplug the appliance
and allow it to cool before
moving it from one location
to another.
• Please ensure that the
appliance is used on a
stable, level, and heat
resistant surface.
• If the supply cord or
appliance is damaged,
stop using the appliance
immediately and seek advice
from the manufacturer, its
service agent or a similarly
qualied person.
• DO NOT attempt to
dismantle or repair any part
of the appliance. This should
only be done by a qualied
service agent.
• DO NOT install the appliance
in washhouses or other
places with water and moist.
• DO NOT turn the appliance
on or o by inserting or
pulling out the plug.
• DO NOT place things on the
appliance.
• DO NOT put anything into
the air inlet and outlet.
• DO NOT use insecticide
spray or other ammable
matters in the vicinity of the
appliance.
• DO NOT splash oil or water
into the appliance.
7www.warmlite.co
• DO NOT clean the appliance
with water. Wipe it with a
semi-wet soft cloth.
• DO NOT wipe the appliance
with chemical solvents
such as benzene, gasoline
or alcohol. Use neutral
detergents only.
• Only install the appliance in
at and dry places. Keep the
appliance 50cm away from
surrounding objects.
• The appliance should be
placed away from gasoline,
cooking stoves or other
combustibles and heat
sources.
• Use the appliance in a well-
ventilated area.
• CAUTION! DO NOT operate
the appliance with wet
hands.
• DO NOT tip the appliance
over as this may cause
damage to the appliance and
create a re hazard.
• CAUTION! No wall xings are
provided with this replace
suite. Take care to ensure
the suite is set on a at and
stable surface and placed
against a wall to prevent it
from falling over or being
dislodged.
• In the unlikely event the
appliance develops a fault,
stop using it immediately
and seek advice from the
Customer Support Team.
HIGH VOLTAGE HOT SURFACE DO NOT COVER
8 CUSTOMER SUPPORT TEAM: +44 (0) 333 220 6056
HANDLING
Before continuing any further with the installation of this
re please read the following:
• Two people should be sucient to lift the re.
• When lifting always keep your back straight. Bend
your legs and not your back.
• Avoid twisting at the waist. It is better to reposition
your feet.
• Avoid upper body / top heavy bending. Always
bend from the knees rather than the waist. Do not
lean forward or sideways whilst handling the re.
• Always grip with the palm of your hand. Do not
use the tips of ngers for support.
• Always keep the product as close to the body as
possible to prevent unnecessary and undue strain
on the body.
• Use gloves to provide additional grip.
• Always use assistance if required.
UNPACKING THE PRODUCT
The appliance is supplied in a single package carton.
Carefully unpack the product using the following
procedure:
• Ensure that the product is in the correct position
with the carton wording legible.
• Remove the straps and sleeve.
• Carefully lift the replace out of the box.
• Remove the protective packaging and bag from
the appliance.
• Ensure all parts including loose items have been
removed prior to discarding the packaging.
• Read all instructions prior to unpacking or installing
the appliance.
IMPORTANT: Please ensure there is adequate space
for installation. Please ensure that there is an accessible
electrical socket within the space for installation. The
electrical socket must not be behind or above the re
INSTALLATION
• The Electric re is supplied with approximately
1.7 meters of exible mains cable (1mm2).The
appliance should be located close to a suitable
mains socket and MUST be easily accessible to
allow proper connection.
• This appliance must not be directly installed on a
carpet or similar material. We recommend that it
is tted onto a hearth or similar non-combustible
material.
• This re MUST be earthed. If in any doubt consult
the manufacturer, its service center or a qualied
person.
The heater is suitable for installation into a location that
has an opening size within the guidelines shown below:
Width
Minimum 15 1/2”/390mm Maximum 19”/483mm
Height
Minimum 21 3/4”/555mm Maximum 23 1/4”/590mm
Depth
Minimum 4 1/4”/110mm Maximum 5”/125mm
BEFORE YOUR FIRST USE:
1. Remove your appliance from the packaging.
2. Install your appliance in accordance with the
installation & safety instructions.
3. Your appliance is now ready for normal use.
Dispose of the packaging in a responsible manner.
NOTE: Before connecting the re to the power, please
remove the two pieces of foam from the rear. You can
choose to use the rear surround or not.
USING YOUR APPLIANCE:
Standby status:
• The re displays standby symbol and timer
symbol (The timer symbol will not illuminate
if no time is set or the button on remote
control is at the OFF position).
Switch on status :
• The re displays date/time, room temperature and
ame brightness level.
NOTE: Set the actual date/time before rst use.
Turning the unit On and Off:
The appliance can be operated either by the touch
switches located to the right hand side of the re canopy
or by the remote control.
9www.warmlite.co
Manual Operation:
• Switch on the standby switch at the left hand side
of the re canopy.
• Press the O/I button once to turn on the appliance
and re eect. A red indicator light will appear to
indicate that the function is ON.
• Press the O/I button for 3 seconds this will operate
the dimmer mode. There are 5 levels of ame
brightness available.
• Press the 1000W button once for the low heat
setting. A red indicator light will appear to indicate
the function; press twice to switch o the heat
setting.
• Press the 2000W button once for the high heat
setting. A red indicator light will appear to indicate
the function; press twice to switch o the heat
setting.
Remote Operation:
Adjusting the Flame Effect Brightness:
• Press the “DIMMER” button on the remote control
to operate the dimmer mode. There are 5 levels
ame brightness available. The ame brightness
changes, step by step, with each press of the
button.
Setting the Time and Date:
• Settings are made using the remote control.
• Press the “DATE TIME” button, then press the “▲”
or “▼” button to select the date.
• Press the “DATE TIME” button again, then press
the “+” or “-” button to set the hour.
• Press the “DATE TIME” button again, then press
the “+” or “-” button to set the minute.
• Press the “OK” button to conrm and complete.
Selecting the Temperature:
NOTE: The set temperature must be higher than the
room temperature for the heat to be emitted.
• Press the “+” or “-” button on the remote control
to set the temperature, which ranges from 15 to
30℃. The default set temperature is 20 ℃.
Selecting the Heating Operation:
• Press the ON/OFF button once on the remote
control to turn the re and ame eect ON/OFF.
• Press the “1000W” button once to turn the low-
level heating on and press twice to stop heating.
• Press the “2000W” button once to turn the high-
level heating on and press twice to stop heating.
NOTE: The set temperature must be higher than the
room temperature for heat to be emitted.
The AUTO Function (Intelligent Control):
• Press the “IC” button on the remote control to turn
the automatic heating ON or OFF.
• When turned on, the re will automatically
change the heating mode depending on the set
temperature and the room temperature.
• During a timed starting process, it is possible to
start heating ahead of schedule.
NOTE: The set temperature must be higher than the
room temperature for heat to be emitted.
The Timer Function:
• Up to 10 dierent timer settings can be
programmed.
• Each timer setting consists of a Date, Timer ON
time and Timer OFF time.
• The maximum duration of each setting is 23 hours
50 minutes.
• The date for each setting can be any day or days
of a week.
• The date in each timer setting represents the date
of the Timer ON time.
• If the Timer OFF time being set falls on the second
day, it is unnecessary to set the date – you just set
the Timer OFF time.
Setting the Timer:
1. Select the settings
• Press the “TIMER SET” button, and the “serial
number” of the setting starts blinking.
• Press the “+” or “-” button to change the “serial
number” until you arrive at the serial number of
setting that you need to set or modify.
2. Select the date
• Press the “TIMER SET” button once again, and the
cursor on the left side of date starts blinking.
10 CUSTOMER SUPPORT TEAM: +44 (0) 333 220 6056
• Press the “▲” or “▼”button to move the cursor
to the corresponding date, press the “+” button to
add the corresponding date, or press “-” button to
delete the date. Continue until you have completed
the selection of all dates.
3. Set the Timer ON time
• Press the “TIMER SET” button; the hour starts
blinking.
• Press the “+” or “-” button to adjust the hour.
• Press the “TIMER SET” button; the minute starts
blinking.
• Press the “+” or “-” button to adjust the minute.
4. Set the Timer OFF time
• Press the “TIMER SET” button; the display is OFF,
and the hour starts blinking.
• Press the “+” or “-” button to adjust the hour.
• Press the “TIMER SET” button; the minute starts
blinking.
• Press the “+” or “-” button to adjust the minute.
5. Set the temperature
• Press the “TIMER SET” button, and the
temperature set starts blinking. At this moment,
the temperature displayed is normally the set
temperature, which can then be adjusted by
pressing “+” or “-” button.
6. Press the “TIMER SET” button and then press the
“OK” button to complete the setting programme.
Steps to view the timer setting:
• Press the “TIMER SET” button.
• Press the “+” or “-” button to check the Timer ON
times one by one.
• To check the Timer OFF times, press the “▲”
button.
• Press the “+” or “-” button to continue viewing.
• For deleting the current item of timer setting, press
the “C” button to delete.
Safety Cut-Out:
• This appliance is tted with a safety cut-out
which will operate if the re overheats (e.g. due to
blocked air vents). For safety reasons, the re will
NOT automatically reset.
• To reset the appliance, disconnect the appliance
from the mains supply for at least 15 minutes.
• Reconnect the supply to the mains and switch on
the appliance.
CAUTION! Do not touch the re as it will be hot. Set the
heater switches to OFF and leave the re to cool down
fully. Once completely cool, reconnect the heater and
switch it on. Do not open this product. There are no
user-serviceable parts inside.
CHECK THAT YOU HAVE NOTED ALL THE
FOLLOWING INSTRUCTIONS:
Do:
• Always install the re in accordance with this
guide. If in doubt obtain expert advice.
• Always make sure the electrical socket is
accessible and located adjacent to, but not above
or behind the re.
• Always disconnect the re from the electrical
supply before carrying out cleaning or
maintenance.
• Always make sure the re is rmly secured.
• Always assemble the re in accordance with this
guide. If in doubt, obtain expert advice.
• Always ensure the product is assembled in an area
that is free from dust, grease or liquids.
• Always ensure that the correct tools are used to
assemble/install this product.
• Always make sure the re is rmly secured in place
when complete.
Don’t:
• Never leave children unsupervised in a room where
the re is ON and unguarded.
• Never obstruct or cover the fan outlet or force
items into the re openings.
• Never install or use the re anywhere where water
is in use, i.e. bathrooms, kitchens, shower rooms,
swimming pools etc.
• Never use aerosols or steam cleaners on or
around the re.
• Never route the mains supply cable under carpet
etc.
• Never install the re close to curtains or
combustible materials.
• Never use the re to dry clothes etc.
• Never sit or stand on the re.
• Never cut the o the plug and hard wire into a
xed fused spur.
NOTE: Any new wiring required, must be in accordance
with local and national codes and other applicable
regulations in order to reduce the risk of re, electric
shock, or other injuries.
NOTE: When the re is turned on for the rst time
or when it has not been used for some time, it may
release a slight, harmless odour. This odour is a normal
occurrence caused by the initial heating of the internal
heating elements or dust, and will disappear with use.
11www.warmlite.co
TROUBLE SHOOTING
Safety Cut-Out device:
To ensure against the potential hazard caused by
blockage of the air outlet, this unit is equipped with
an automatic overheat safety cut-out device. When
the device is activated the heater will not operate. If
this occurs, the unit can be reset using the following
procedure.
1. Turn the re o by depressing the on/o switch on
the unit.
2. Unplug the power cord form the electrical mains
supply socket and leave it disconnected for at
least 15 minutes.
3. Ensure that the air vents are free from obstruction.
4. Plug the power cord back into the mains socket.
5. Turn the re back on.
6. If the re fails to operate, check the fuse in the
plug.
7. If the fuse in the plug is OK and the re is still not
functioning, contact a qualied person.
Symptom Corrective action
No operation
No fan.
Check that the
safety cut-o has not
activated.
Check that the unit is
plugged into the mains
and that the On/O
switch has been set to
the ON position.
Ensure the temperature
control dial is not in the
OFF position.
Check that the fuse
is working. If broken,
a replacement is
necessary.
No light Check that the LED
is working. If broken,
a replacement is
necessary.
CLEANING AND CARE
WARNING! Always disconnect from the mains supply
before cleaning the wall re.
CAUTION! Allow the product to completely cool before
handling or cleaning it.
• Never use abrasive cleaners and chemical agents
as damage may occur to the nish.
• For general cleaning use a soft clean duster.
• The glass viewing screen should be cleaned
carefully with a soft cloth.
• Do not allow water or other liquids to run into the
interior of the product, as this could cause a re
and/or electrical hazard.
• We also recommend the periodic cleaning of this
appliance by lightly running a vacuum cleaner
nozzle over the guards to remove any dust or dirt
that may have accumulated inside or on the unit.
Maintenance
• Before any maintenance of the exterior of the
replace, disconnect the unit form the power
supply and leave until cool.
• Remote control battery replacement: this remote
control uses 2x1.5V AAA battery. Ensure the
batteries are installed correctly in the remote
control.
• This product does not use a standard bulb for its
ame eect. The appliance uses an electronically
controlled LED system to create the ame eect
therefore no parts need to be replaced. There
are no user-serviceable parts on this appliance.
Under no circumstances should the appliance
be serviced by anyone other than a qualied
electrician.
WARNING:
DO NOT IMMERSE ANY ELECTRICAL PART
OF THE APPLIANCE IN WATER SUCH AS
MOTOR UNITS OR PLUGS.
PLEASE SEE CLEANING SECTION FOR
FURTHER INSTRUCTIONS.
12 CUSTOMER SUPPORT TEAM: +44 (0) 333 220 6056
Model Identifier(s): WL45048 & WL45049
Item Symbol Valve Unit Item Unit
Heat Output
Type of heat input for electric storage, local
space heaters only (select one)
Nominal heat
output
Pnom 1.9 kW
Manual heat charge with integrated
thermostat
NA
Minimum heat
output (indicative)
Pmin 0.95 kW
Manual heat charge control with room
and/or outdoor temperature feedback
NA
Maximum
continuous heat
output
Pmax, c 1.9 kW
Electronic heat charge control with
room
and/or outdoor temperature feedback
NA
Auxiliary electricity
consumption
Fan assisted heat output NA
At nominal heat
output
elmax 0.014 kW
Type of heat output/room temperature control
(select one)
At minimum heat
output
elmin 0.014 kW
Single stage heat output and no room
temperature control
No
In standby mode eISB 0.48 kW
Two or more manual stages, no room
temperature control
No
With mechanic thermostat room
temperature control
No
With electronic room temperature
control
No
Electronic room temperature control
plus day timer
No
Electronic room temperature control
plus week timer
Yes
Other control options (multiple selections
possible)
Room temperature control with pres-
ence detection
No
Room temperature control with open
window detection
No
With distance control option No
With adaptive start control Yes
With working time limitation No
With black bulb sensor No
Contact Details: Imported by RK Wholesale LTD., Berryhill Road, Stoke-on-Trent ST4 2NL
13www.warmlite.co
NOTES
14 CUSTOMER SUPPORT TEAM: +44 (0) 333 220 6056
NOTES
15www.warmlite.co
NOTES
0620.V1
Thank You!
We hope you enjoy your appliance for many years.
This product is guaranteed for 12 months from the date of original purchase.
If any defect arises due to faulty materials of workmanship, the faulty products must be returned to the
place of purchase.
Refund or replacement is at the discretion of the retailer.
The Following Conditions Apply:
The product must be returned to the retailer with proof of purchase or a receipt.
The product must be installed and used in accordance with the instructions contained in this instruction guide.
It must be used only for domestic purposes.
It does not cover wear and tear, damage, misuse or consumable parts.
RKW has limited liability for incidental or consequential loss or damage.
This guarantee is valid in the UK and Eire only.
The standard one year guarantee is only extended to the maximum available for each particular product upon
registration of the product within 28 days of purchase. If you do not register the product with us within the 28 day
period, your product is guaranteed for 1 year only.
To validate your extended warranty, please visit
www.warmlite.co and register with us online.
Please note that length of extended warranty oered is dependent on product type and that each qualifying
product needs to be registered individually in order to extend its warranty past the standard 1 year.
Extended warranty is only valid with proof of purchase or receipt.
Your warranty becomes void should you decide to use non Warmlite spare parts.
Spare parts can be purchased from www.warmlite.co
Should you have a problem with your appliance, or need any spare parts,
please call our Customer Support Team on:
+44 (0) 333 220 6056
