1
AMW 836AMW 832
INSTALLATION, QUICK START
INSTALLATIE, SNEL AAN DE SLAG
INSTALLATION, HURTIG START
INSTALLASJON, HURTIG START
ASENNUS, PIKAOPAS
ÜZEMBE HELYEZÉS, RÖVID
KEZDÉSI ÚTMUTATÓ
INSTALACE, NÁVOD VE ZKRATCE
INSTALACJA, SKRÓCONA
INSTRUKCJA OBSŁUGI
УСТАНОВКА, КРАТКОЕ
СПРАВОЧНОЕ РУКОВОДСТВО
INŠTALÁCIA, ÚVODNÁ PRÍRUČKA
INSTALLATION, DÉMARRAGE RAPIDE
AUFSTELLUNG, KURZANLEITUNG
INSTALLAZIONE, GUIDA RAPIDA
INICIO RÁPIDO PARA LA INSTALACIÓN
INSTALAÇÃO, GUIA DE INICIAÇÃO RÁPIDA
INSTALLATION, SNABBGUIDE
2
INSTALLATION
PRIOR TO CONNECTING
E
NSURE THAT THE APPLIANCE IS NOT DAMAGED. Check
that the oven door closes firmly against the
door support and that the internal door seal is
not damaged. Empty the oven and clean the
interior with a soft, damp cloth.
AFTER CONNECTING
T
HE FIRST TIME THE OVEN IS SWITCHED ON, you will be
asked to set the language and current time.
Follow the instructions under the headline
“Changing settings” in this instructions for use.
The appliance is ready to use after these two
steps have been taken.
The manufacturers are not liable for any
problems caused by the user’s failure to ob-
serve these instructions.
D
O NOT OPERATE THIS APPLIANCE if it has a damaged
mains cord or plug, if it is not working proper-
ly, or if it has been damaged or dropped. Do
not immerse the mains cord or plug in water.
Keep the cord away from hot surfaces. Electri-
cal shock, fire or other hazards may result.
D
O NOT REMOVE THE MICROWAVE INLET PROTECTION
PLATES located on the side
of the oven cavity wall.
They prevent grease & food
particles from entering the
microwave inlet channels.
E
NSURE the oven cavity is
empty before mounting.
C
HECK THAT THE VOLTAGE on the rating plate corre-
sponds to the voltage in your home.
T
HE OVEN CAN BE OPERATED ONLY if the oven door is
firmly closed.
THE EARTHING OF THIS APPLIANCE is compulsory. The
manufacturer will accept no responsibility for
injury to persons, animals or damage to ob-
jects arising from the non-observance of this
requirement.
MOUNTING THE APPLIANCE
FOLLOW THE SUPPLIED separate mounting in-
structions when installing the appliance.
DO NOT USE EXTENSION CORD:
I
F THE POWER SUPPLY CORD IS TOO SHORT, have a
qualified electrician or serviceman install
an outlet near the appliance.
3
3
3
IMPORTANT SAFETY INSTRUCTIONS
DO NOT HEAT, OR USE FLAMMABLE MATERIALS in or
near the oven. Fumes can create a fire hazard
or explosion.
D
O NOT USE YOUR MICROWAVE oven for drying
textiles, paper, spices, herbs, wood, flowers,
fruit or other combustible materials. Fire could
result.
D
O NOT OVER-COOK FOOD. Fire could result.
D
O NOT LEAVE THE OVEN UNATTENDED, especially
when using paper, plastic or other combustible
materials in the cooking process. Paper can
char or burn and some plastics can melt if used
when heating foods.
I
F MATERIAL INSIDE / OUTSIDE THE OVEN SHOULD IGNITE
OR SMOKE IS OBSERVED, keep oven door closed and
turn the oven off. Disconnect the power cord
or shut off power at the fuse or circuit breaker
panel.
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
D
O NOT USE YOUR MICROWAVE oven
for heating anything in airtight
sealed containers. The
pressure increases and may
cause damage when opening or may explode.
EGGS
D
O NOT USE YOUR MICROWAVE oven for cooking
or reheating whole eggs with or
without shell since they may
explode even after microwave
heating has ended.
I
F THE MAINS CORD NEEDS REPLACING it should be
replaced by the original mains cord, which is
available via our service organization.
The mains cord may only be replaced
by a trained service technician.
D
O NOT USE corrosive chemicals or vapors in
this appliance. This type of oven is specifically
designed to heat or cook food. It is not
designed for industrial or laboratory use.
T
HE APPLIANCE AND ITS ACCESSIBLE PARTS MAY BECOME
HOT during use.
CARE SHOULD BE TAKEN to avoid touching heating
elements.
CHILDREN LESS THAN 8 YEARS OF AGE shall be kept
away unless continuosly supervised.
S
ERVICE ONLY TO BE CARRIED OUT BY A TRAINED
SERVICE TECHNICIAN. It is hazardous for
anyone other than a trained person to
carry out any service or repair operation,
which involves the removal of any cover,
which gives protection against exposure to
microwave energy.
DO NOT REMOVE ANY COVER.
WARNING!
THE DOOR SEALS AND THE DOOR SEAL AREAS must
be regularly inspected for damage. If these
areas are damaged the appliance should not
be operated until it has been repaired by a
trained service technician.
T
HIS APPLIANCE CAN BE USED by children aged from
8 years and above and persons with reduced
physical, sensory or mental capabilities or
lack of experience and knowledge if they
have been given supervision or instruction
concerning use of the appliance in a safe way
and understand the hazards involved.
U
SE, CLEANING AND USER MAINTENANCE shall not be
made by children unless they are aged from 8
years and above and supervised.
C
HILDREN SHALL NOT PLAY with the appliance.
4
PUSH - PUSH KNOBS
THE KNOBS OF THIS OVEN are aligned
with the buttons on the pan-
el, at delivery.
The knobs will slide out if pushed
and their various functions can be
accessed. It is not necessary to have
them petruding from the panel
during operation.
Simply push them back into the
panel when you are done with the set-
ting and continue to operate the oven.
THE APPLIANCE SHOULD NOT BE OPERATED without food
in the oven when using microwaves. Operation in
this manner is likely to damage the appliance.
I
F YOU PRACTICE OPERATING the oven, put a glass
of water inside. The water will absorb the mi-
crowave energy and the oven will not be dam-
aged.
REMOVE WIRE TWIST-TIES from paper or
plastic bags before placing bag in
the oven.
DEEP-FRYING
D
O NOT USE YOUR MICROWAVE oven for deep-frying,
because the oil temperature cannot be
controlled.
LIQUIDS
E.
G. BEVERAGES OR WA TER. Overheating the liquid
beyond boiling point can occur
without evidence of bubbling.
This could result in a sudden
boil over of the hot liquid.
To prevent this possibility the
following steps should be taken:
1. Avoid using straight-sided containers with
narrow necks.
2. Stir the liquid before placing the container
in the oven and let the teaspoon remain
in the container.
3. After heating, allow standing for a short
time, stirring again before carefully re-
moving the container from the oven.
CAREFUL
A
LWA YS REFER to a microwave cookbook for de-
tails. Especially, if cooking or reheating food
that contains alcohol.
A
FTER HEATING BABY FOOD or liquids in a
baby bottle or in a baby food
jar, always stir and check the
temperature before serving.
This will ensure that the heat is evenly distributed
and the risk of scalding or burns can be avoided.
Ensure the Lid and the Teat is removed be-
fore heating!
U
SE HOT PADS OR OVEN M ITTS to prevent burns,
when touching containers, oven parts, and
pan after cooking.
D
O NOT USE THE CAVITY for any storage purposes.
LI
LI
LI
LI
QU
QU
QU
QU
ID
ID
ID
ID
S
S
S
S
GENERAL
T
HIS APPLIANCE IS DESIGNED FOR DOMESTIC USE ONLY!
IMPORTANT PRECAUTIONS
THIS APPLIANCE IS INTENDED for heating food and
beverages. Drying of food or clothing and
heating of warming pads, slippers, sponges,
damp cloth and similar may lead to risk of
injury, ignition or fire.
T
HIS APPLIANCE IS INTENDED to be used built-in. Do
not use it freestanding.
5
ACCESSORIES
GENERAL
I
F ACCESSORIES CONTAINING METAL comes in contact
with the oven interior, while the oven is in op-
eration, sparking can occur and the oven could
be damaged.
TURNTABLE SUPPORT
USE THE TURNTABLE SUPPORT under the
Glass turntable. Never put any oth-
er utensils on the turntable sup-
port.
Fit the turntable support in the oven.
GLASS TURNTABLE
U
SE THE GLASS TURNTABLE with all cooking meth-
ods. It collects the dripping juic-
es and food particles that other-
wise would stain and soil the in-
terior of the oven.
Place the Glass turntable on the turntable
support.
E
NSURE THAT THE UTENSILS YOU USE are oven proof
and allow microwaves to
pass through them before
cooking.
W
HEN YOU PUT FOOD AND ACCESSORIES in the micro-
wave oven, ensure that they do not come in
contact with the interior of the oven.
This is especially important with accesso-
ries made of metal or metal parts.
A
LWA YS ENSURE that the turntable is able to turn
freely before starting the oven.
CRISP HANDLE
U
SE THE SUPPLIED SPECIAL CRISP HAN-
DLE to remove the hot Crisp plate
from the oven.
CRISP-PLATE
P
LACE THE FOOD DIRECTLY ON THE CRISP-PLATE.
Always use the Glass turn-
table as support when us-
ing the Crisp-plate.
DO NOT PLACE ANY UTENSILS on the
Crisp-plate since it will quickly be-
come very hot and is likely to cause
damage to the utensil.
THE CRISP-PLATE may be preheated before use
(max. 3 min..). Always use the Crisp function
when preheating the crisp-plate.
T
HERE ARE a number of accessories available on
the market. Before you buy, ensure they are
suitable for microwave use.
WIRE RACK
U
SE THE WIRE RACK when grilling
using the Grill functions.
STEAMER
U
SE THE STEAMER WITH THE
STRAINER in place for foods
such as fish, vegetables and
potatoes.
USE THE STEAMER WITHOUT THE
STRAINER in place for foods such as rice, pasta
and white beans.
ALWA YS place the steamer on the Glass Turnta-
ble.
COVER
THE COVER is used to cover food dur-
ing cooking and reheating with mi-
crowaves only and helps to reduce
spattering, retain food moisture as
well as reducing the time needed.
USE the cover for two level reheat-
ing
6
Safety Lock is activated
close door and press
Key Lock
has been activated
Key Lock
has been deactivated
19:30
START PROTECTION
THE START PROTECTION FUNCTION IS ACTIVATED ONE
MINUTE AFTER the oven has returned to
“stand by mode“.
THE DOOR MUST BE OPENED AND CLOSED e.g. putting
food into it, before the safety lock is released.
KEY LOCK
PRESS THE BACK AND OK buttons simultaneously and keep pressed until two beeps are heard
(3 seconds).
U
SE THIS FUNCTION to hinder children from using the oven
unattended.
WHEN THE LOCK IS ACTIVE, all buttons are non-responsive.
A
CONFIRMATION MESSAGE is displayed for 3 seconds be-
fore returning to the previous view.
THE KEY LOCK ID DEACTIVATED the same way it was acti-
vated.
P
LEASE NOTE: These buttons only work in conjunction
when the oven is turned OFF.
7
DONENESS
WEIGHT
END TIME
COOK TIME
Normal
Steamed Fillets
30:00300g
19:30
DONENESS
WEIGHT
Light
Fruit Pie
400g
DONENESS
Extra
Rolls
AMOUNT
8
Please add milk
Press when done
Cooking nearly finished
Please check on food
Insert food in steamer
Press when done
Please use
high wire rack
Please stir food
Please turn food
Temperature reached
Insert food and press
DONENESS (AUTO FUNCTIONS ONLY)
D
ONENESS IS AVAILABLE in most of the auto func-
tions. You have the possibility to personally
control the end result through the Adjust do-
neness feature. This feature enables you to
achieve higher or lower end temperature com-
pared to the default standard setting.
W
HEN USING one of these functions the oven
chooses the default standard setting. This set-
ting normally gives you the best result. But if
the food you heated became too warm to eat
at once, you can easily adjust this before you
use that function the next time.
W
HEN USING SOME OF THE FUNCTIONS the oven may
stop and prompt you to perform an action or
simply advice on which accsessoire to use.
MESSAGES
THIS IS DONE BY SELECTING A DONENESS LEVEL with the
Adjust knob before pressing the Start button.
W
HEN A MESSAGE APPEAR:
Open the door (if needed).
Perform the action (if needed).
Close the door and restart by pressing the
Start button.
DONENESS
L
EVEL EFFECT
EXTRA YIELDS HIGHEST END TEMPERATURE
NORMAL DEFAULT STA NDARD SETTING
LIGHT YIELDS LOWEST END TEMPERATURE
8
Shortcut
Your most used cooking functions
French Fries
Shortcut
Shortcut
Shortcut
Your most used cooking functions
Pan Pizza
Lasagna
French Fries
Your most used cooking functions
Pan Pizza
Lasagna
French Fries
Your most used cooking functions
COOLING DOWN
WHEN A FUNCTION IS FINISHED, the oven may carry
out a cooling procedure. This is normal.
After this procedure the oven switches off au-
tomatically.
SHORTCUTS
TO FAVOR THE EASE OF USE, the oven automatical-
ly compiles a list of your favorite shortcuts for
you to use.
WHEN YOU BEGIN using your oven, the list con-
sists of 10 empty positions marked “shortcut”.
As you use the oven over time, it will automat-
ically fill in the list with shortcuts to your most
frequently used functions.
WHEN YOU ENTER THE SHORTCUT MENU, the function
you have been using mostly, will be pre-select-
ed and positioned as shortcut #1.
NOTE: the order of functions presented in the
shortcut menu will automatically change ac-
cording to your cooking habits.
TURN THE MULTIFUNCTION KNOB until Shortcut is displayed
.
TURN THE ADJUST KNOB to choose your favorite shortcut. The most frequently used function is
pre-selected.
PRESS THE OK BUTTON to confirm your selection.
TURN THE ADJUST KNOB / OK BUTTON to make the needed adjustments.
PRESS THE START BUTTON.
T
HE COOLING PROCEDURE can be interrupted with-
out any harm to the oven by opening the door.
9
English
Français
Turkçe
Please select language
Language
has been set
Settings
WHEN THE APPLIANCE IS FIRST PLUGGED IN it will ask you to set the Lan-
guage and 24 hour Clock.
AFTER A POWER FAILURE the Clock will flash and needs to be reset.
YOUR OVEN HAS a number of functions which can be adjusted to your
personal taste.
CHANGING SETTINGS
TURN THE MULTIFUNCTION KNOB until Settings is shown.
TURN THE ADJUST KNOB to choose one of the settings to adjust.
PRESS THE BACK BUTTON TO EXIT the settings function when you are done.
LANGUAGE
PRESS THE OK BUTTON .
TURN THE ADJUST KNOB to choose one of the available lan-
guages.
PRESS THE OK BUTTON again to confirm the change.
T
HE APPLIANCE IS TURNED ON OR OFF
using the On/Off button or simply
by turning the Multifunction Knob.
ON/OFF
WHEN THE APPLIANCE IS TURNED OFF , all the buttons
and the Adjust Knob is non-responsive. The 24
hour clock is displayed.
W
HEN THE APPLIANCE IS TURNED ON , all
buttons & knobs function normal-
ly and the 24 hour clock is not dis-
played.
N
OTE: The oven behavior may differ from the
above described, depending on the ECO func-
tion being turned ON or OFF (see ECO for more
information).
T
HE DESCRIPTIONS IN THIS IFU assume that the
oven is turned ON .
Language
Time
Eco Mode
Appliance and display settings
10
Press to set time, to confirm
^
^
00 : 00
(HH) (MM)
Time
has been set
Low
High
For normal living conditions
Medium
Volume
has been set
CLOCK SETTING
TURN THE ADJUST KNOB until Time is displayed.
PRESS THE OK BUTTON . (The digits flicker).
TURN THE ADJUST KNOB to set the 24 hour clock.
PRESS THE OK BUTTON again to confirm the change.
T
HE CLOCK IS SET AND IN OPERATION.
CHANGING SETTINGS
SOUND SETTING
TURN THE ADJUST KNOB until Volume is displayed.
PRESS THE OK BUTTON .
TURN THE ADJUST KNOB to set the volume on high, medium, low
or mute.
PRESS THE OK BUTTON again to confirm the change.
Volume
Brightness
Time
Appliance and display settings
Volume
Brightness
Time
Appliance and display settings
11
Medium
Low
High
For normal living conditions
Brightness
has been set
On
Off
Minimal power consumption
e
Eco Mode
has been set
e
e e
BRIGHTNESS
TURN THE ADJUST KNOB until Brightness is displayed.
PRESS THE OK BUTTON .
TURN THE ADJUST KNOB to set the level of brightness suitable to your
preference.
PRESS THE OK BUTTON again to confirm your selection.
CHANGING SETTINGS
ECO
TURN THE ADJUST KNOB until Eco Mode is displayed.
PRESS THE OK BUTTON .
TURN THE ADJUST KNOB to turn the ECO setting ON or OFF.
PRESS THE OK BUTTON again to confirm the change.
W
HEN ECO IS ON, the display will automatically dim down after a
while to save energy. It will automatically light up again when a
button is pressed or the door is opened.
WHEN OFF IS SET, the display will not turn off and the 24 h clock will
always be visible.
Brightness
Eco Mode
Volume
Appliance and display settings
Eco Mode
Language
Brightness
Appliance and display settings
e
12
WEIGHT
200 g
GRILL POWER COOK TIME
High 07:00
DURING COOKING
O
NCE THE COOKING PROCESS HAS BEEN STARTED:
The time can easily be increased in 30-second steps by pressing
the Start button. Each press increases the time with 30 seconds. You
may also Turn the Adjust Knob to increase or decrease the time.
CHANGING SETTINGS
BY TURNING THE ADJUST KNOB, you may toggle be-
tween the parameters to select which you wish
to alter.
P
RESSING THE OK BUTTON selects and enables it to be changed (it
flashes). Turn the Adjust Knob to alter your setting.
PRESS THE OK BUTTON AGAIN to confirm your selection. The oven con-
tinues automatically with the new setting.
B
Y PRESSING THE BACK BUTTON you may return directly to the last pa-
rameter you changed.
13
Timer
00 : 59 : 59
00 : 00 : 00
Press to prolong, to switch off
^
POWER
END TIME
COOK TIME
750 w 00:05
19:00
Microwave
USE THIS FUNCTION when you need a kitchen timer to
measure exact time for various purposes such as cook-
ing eggs or letting the dough rise before baking etc.
THIS FUNCTION IS ONLY AVALIABLE when the oven is switched
off or in standby mode.
KITCHEN TIMER
TURN THE OVEN OFF by turning theMultifunction Knob to the Zero position or pressing the On
/ Off button.
PRESS THE OK BUTTON .
TURN THE ADJUST KNOB to set the desired length of the timer.
PRESS THE OK BUTTON to start the timer countdown
.
A
N ACOUSTIC SIGNAL will be heard when the timer has fin-
ished to count down.
P
RESSING THE ON / OFF BUTTON before the timer has finished will switch
the timer off.
COOK & REHEAT WITH MICROWAVES
TURN THE MULTIFUNCTION KNOB until Microwave is shown.
TURN THE ADJUST KNOB to set the cooking time.
PRESS THE OK BUTTON to confirm your setting.
TURN THE ADJUST KNOB to set the microwave power level.
PRESS THE START BUTTON.
U
SE THIS FUNCTION for normal cooking and reheating, such as vegeta-
bles, fish, potatoes and meat.
00 : 00 : 00
(HH) (MM) (SS)
Press to set Timer, to Start
^
^
Microwave
14
POWER LEVEL
COOK & REHEAT WITH MICROWAVES
MICROWAVES ONLY
POWER SUGGESTED USE:
900 W
R
EHEATING OF BEVERAGES, water, clear soups, coffee, tea or other food with a high water
content. If the food contains egg or cream choose a lower power.
750 W C
OOKING OF VEGETABLES, meat etc.
650 W C
OOKING OF fish.
500 W
M
ORE CAREFUL COOKING e.g. high protein sauces, cheese and egg dishes and to finish cook-
ing casseroles.
350 W S
IMMERING STEWS, melting butter & chocolate.
160 W D
EFROSTING. Softening butter, cheeses.
90 W S
OFTENING Ice cream
0 W W
HEN USING the Timer only.
15
JET START
PRESS THE START BUTTON TO AUTOMATICALLY START with full microwave power level
and the cooking time set to 30 seconds. Each additional press increases the
time with 30 seconds.
T
HIS FUNCTION IS USED for quick reheating of food with a high water
content such as; clear soups, coffee or tea.
THIS FUNCTION IS ONLY AVALIABLE when the oven is switched off or in
standby mode while the Multifunction Knob is in the Microwave
position.
POWER
END TIME
MM:SS
900 w 00:30
19:03
Cooking
16
END TIME
COOK TIME
00:05
19:00
Crisp
TURN THE MULTIFUNCTION KNOB until Crisp is shown.
TURN THE ADJUST KNOB to set the cooking time.
PRESS THE START BUTTON.
CRISP
USE THIS FUNCTION TO reheat and cook pizzas and other dough based
food. It is also good for frying bacon and eggs, sausages, hamburg-
ers etc.
THE OVEN AUTOMATICALLY use Microwaves and Grill in order to heat the
Crisp-plate. This way the Crisp-plate will rapidly reach its working
temperature and begin to brown and crisp the food.
E
NSURE that the Crisp-plate is correctly placed in the
middle of the Glass turntable.
T
HE OVEN AND THE CRISP-PLATE become very hot when using this func-
tion.
D
O NOT PLACE THE HOT CRISP-PLATE on any surface susceptible to heat.
B
E CAREFUL, NOT TO TOUCH the Grill element.
U
SE OVEN MITTENS
or the special Crisp handle supplied when removing the hot
Crisp-plate.
O
NLY USE the supplied Crisp plate with this function. Other available
Crisp plates on the market will not give the
correct result
when using this function.
Crisp
17
GRILL POWER
END TIME
COOK TIME
High 07:00
19:07
Grill
GRILL
TURN THE MULTIFUNCTION KNOB until Grill is shown.
TURN THE ADJUST KNOB to set the cooking time.
PRESS THE OK BUTTON to confirm your setting.
TURN THE ADJUST KNOB set the Grill power level.
PRESS THE START BUTTON.
U
SE THIS FUNCTION TO quickly give a pleasant brown surface to food.
FOR FOOD LIKE CHEESE TOAST, STEAKS AND SAUSAGES, place the food on the
Wire rack.
E
NSURE THAT THE UTENSILS used are heat resistant and ovenproof before
grilling with them.
DO NOT USE PLASTIC utensils when grilling. They will melt. Items of wood or
paper are not suitable either.
P
REHEAT THE GRILL for 3 - 5 minutes on High grill power level.
CHOOSING POWER LEVEL
Grill
GRILL
S
UGGESTED USE:POWER
CHEESE TOAST , Fish Steaks & Ham-
burgers
HIGH
SAUSAGES & Grill Spit MEDIUM
LIGHT BROWNING of food surfaces LOW
18
GRILL POWER
END TIME
COOK TIME
Low
POWER
650 w
07:00
19:07
Grill + MW
Grill + MW
GRILL COMBI
TURN THE MULTIFUNCTION KNOB until Grill + MW is shown.
TURN THE ADJUST KNOB to set the cooking time.
PRESS THE OK BUTTON to confirm your setting.
TURN THE ADJUST KNOB to set the Grill power level.
PRESS THE OK BUTTON to confirm your setting.
TURN THE ADJUST KNOB set the Microwave power level.
PRESS THE START BUTTON.
THE MAX. POSSIBLE microwave power level when using the Grill Combi
is limited to a factory-preset level.
PLACE FOOD on the wire rack or on the glass turntable.
U
SE THIS FUNCTION TO cook such food as Lasagne, Fish and Potato Gra-
tins.
CHOOSING POWER LEVEL
GRILL COMBI
S
UGGESTED USE:GRILL POWER MICROWAVE POWER
LASAGNE MID 350 - 500 W
P
OTATO GRATIN MID 500 - 650 W
F
ISH GRATIN HIGH 350 - 500 W
B
AKED APPLES MID 160 - 350 W
F
ROZEN GRATIN HIGH 160 - 350 W
19
6th Sense Reheat
6th Sense Steam
6th Sense Crisp
For heating frozen, readymade food
6th Sense
CONTROL
Automatic
6th Sense Reheat
6
TH
SENSE REHEAT
TURN THE MULTIFUNCTION KNOB until 6th Sense is shown.
TURN THE ADJUST KNOB until 6th Sense Reheat is shown.
PRESS THE OK BUTTON to confirm your selection.
PRESS THE START BUTTON.
U
SE THIS FUNCTION when reheating ready-made food ei-
ther frozen, chilled or room tempered.
PLACE FOOD onto a microwave-safe heat proof dinner plate or dish.
WHEN YOU ARE SAVING a meal in the refrigerator
or ”plating” a meal for reheating, arrange the
thicker, denser food to the out-
side of the plate and
the thinner or less
dense food in the
middle.
ALWA YS COVER FOOD when using this function.
IF THE FOOD IS PACKAGED in such way that it al-
ready have a cover, the package should be
cut with 2-3 scores to allow for excess
pressure to escape during reheating.
P
LACE THIN SLICES of meat on top of each
other or interlace them.
THICKER SLICES such as meat loaf and sausages
have to be placed close to each other.
P
LASTIC FOIL should be
scored or pricked with a
fork, to relieve the pressure
and to prevent bursting,
as steam builds-up during
cooking.
1-2 MINUTES STANDING TIME ALWAYS
IMPROVES the result, especially
for frozen food.
T
HE PROGRAM SHOULD NOT be interrupted.
THE NET WEIGHT shall be kept within 250 - 600 g when using this func-
tion. If not you should consider using the manual function to obtain
the best result.
ENSURE the oven is at room temperature before using this function
in order to obtain the best result.
20
MANUAL DEFROST
FOLLOW THE PROCEDURE for “Cook & Reheat with
microwaves” and choose power level 160 W
when defrosting manually.
CHECK AND INSPECT THE FOOD REGULARLY. Experi-
ence will give you the times needed for vari-
ous amounts.
T
URN LARGE JOINTS halfway through the defrost-
ing process.
FROZEN FOOD IN PLASTIC BAGS, plastic films or card-
board packages can be placed directly in the
oven as long as the package has no met-
al parts (e.g. metal twist ties).
T
HE SHAPE OF THE PACKAGE alters the de-
frosting time. Shallow packets defrost
more quickly than a deep block.
S
EPARATE PIECES as they begin to defrost.
Individual slices defrost more easily.
S
HIELD AREAS OF FOOD with small
pieces of aluminum foil if
they start to become warm
(e.g. chicken legs and wing
tips).
BOILED FOOD, STEWS AND MEAT SAUCES defrost
better if stirred during defrosting time.
W
HEN DEFROSTING it is better to under-
thaw the food slightly and allow the
process to finish during standing time.
S
TANDING TIME AFTER DEFROSTING ALWAYS IMPROVES
the result since the temperature
will then be evenly distribut-
ed throughout the food.
21
AMOUNT
END TIME
COOK TIME
15:00200g
19:15
Defrosting
Jet Defrost
JET DEFROST
TURN THE MULTIFUNCTION KNOB until Jet Defrost is shown.
TURN THE ADJUST KNOB to select the food.
PRESS THE OK BUTTON to confirm your selection.
TURN THE ADJUST KNOB to set the weight.
PRESS THE START BUTTON.
U
SE THIS FUNCTION for defrosting Meat, Poultry, Fish, Vegetables and
Bread.
Jet Defrost should only be used if the net weight is between 100 g-
3.0 kg.
ALWA YS PLACE THE FOOD on the glass turntable.
22
FROZEN FOODS:
IF THE FOOD IS WARMER than deep-freeze temperature (-18°C),
choose lower weight of the food.
IF THE FOOD IS COLDER than deep-freeze temperature (-18°C),
choose higher weight of the food.
WEIGHT:
T
HIS FUNCTION NEEDS TO KNOW the net weight of the food. The
oven will then automatically calculate the needed time to
finish the procedure.
I
F THE WEIGHT IS LESSER OR GREATER THAN RECOMMENDED WEIGHT: Follow the
procedure for “Cook & Reheat with microwaves” and choose 160 W
when defrosting.
JET DEFROST
FOOD HINTS
M
EAT (100g - 2.0Kg) MINCED MEAT, cutlets, steaks or roasts.
P
OULTRY (100g - 3,0Kg) CHICKEN WHOLE, pieces or fillets.
FISH (100g - 2.0Kg) WHOLE, STEAKS or fillets.
VEGETABLES (100g - 2.0Kg) MIXED VEGETABLES, peas, broccoli etc.
BREAD (100g - 2.0Kg) LOAF, buns or rolls.
F
OR FOOD NOT LISTED IN THIS TABLE and if the weight is lesser or greater than recommended weight,
you should follow the procedure for “Cook and reheat with microwaves” and choose 160 W
when defrosting.
23
6th Sense Crisp
6th Sense Steam
6th Sense Reheat
For heating frozen, readymade food
Forced Air
Thin Pizza
Pan Pizza
French Fries
Please select food
CONTROL
END TIME
COOK TIME
Automatic
WEIGHT
200 g
--:--
--:--
Thin Pizza
6th Sense
6
Th
SENSE CRISP
TURN THE MULTIFUNCTION KNOB until 6th Sense is shown.
TURN THE ADJUST KNOB until 6th Sense Crisp is shown.
PRESS THE OK BUTTON to confirm your selection.
TURN THE ADJUST KNOB to select the food.
PRESS THE OK BUTTON to confirm your selection.
PRESS THE START BUTTON.
U
SE THIS FUNCTION TO quickly reheat your food from frozen to serving
temperature.
AUTO CRISP IS USED ONLY for frozen ready made food.
Only use the supplied Crisp plate with this function. Other available
Crisp plates on the market will not give the correct result when
using this function.
Do not place any containers or wrappings on the Crisp plate!
Only the food is to be placed on the Crisp plate.
24
6
Th
SENSE CRISP
FOOD HINTS
F
RENCH FRIES (300g - 600g)
S
PREAD OUT THE FRIES in an even layer on the
crisp plate. Sprinkle with salt if desired.
S
TIR FOOD when oven prompts.
P
IZZA, thin crust (250g - 500g) FOR PIZZAS with thin crust.
P
AN PIZZA (300g - 800g) FOR PIZZAS with thick crust.
B
UFFALO WINGS (300g - 600g)
FOR CHICKEN NUGGETS, oil the crisp plate and
cook with donness set to Light.
TURN FOOD when oven prompts.
F
OR FOOD NOT LISTED IN THIS TABLE and if the weight is lesser or greater than recommended weight,
you should follow the procedure for manual crisp function.
25
6th Sense Steam
6th Sense Crisp
6th Sense Reheat
For vegetables, fish, rice and pasta
CONTROL
END TIME
COOK TIME
Automatic 00:05
19:00
6th Sense Steam
Please use
steamer bottom and lid
6th Sense
6
TH
SENSE STEAM
THIS FUNCTION WORKS IN 2 STEPS.
The first step quickly brings the food to boiling temperature.
The second step automatically adjusts to simmering tempera-
ture in order to avoid over boiling.
TURN THE MULTIFUNCTION KNOB until 6th Sense is shown.
TURN THE ADJUST KNOB until 6th Sense Steam is shown.
PRESS THE OK BUTTON to confirm your selection.
TURN THE ADJUST KNOB to set the Cook time.
PRESS THE START BUTTON.
T
HE STEAMER IS designed to be used with microwaves only!
NEVER USE IT WITH ANY OTHER FUNCTION AT ALL.
USING THE STEAMER in any other function may cause damage.
ALWA YS ENSURE that the turntable is able to turn freely before starting the
oven.
ALWA YS PLACE the steamer on the Glass Turntable.
U
SE THIS FUNCTION FOR such food as vegetables, fish, rice
and pasta.
26
6
TH
SENSE STEAM
COVER
A
LWA YS COVER THE FOOD WITH A LID. Ensure that the
vessel and lid are microwave proof before us-
ing them. If you don’t have a lid avail-
able to your chosen vessel, you may use
a plate instead. It should be placed
with the underside facing the inside of
the vessel.
DO NOT use plastic or aluminum wrap-
pings when covering the food.
COOKING VEGETABLES
PLACE THE VEGETABLES into the strainer.
Pour 100 ml water into the bottom part.
Cover with the lid and set the time.
S
OFT VEGETABLES such as broccoli and leek
require 2-3 minutes cooking time.
H
ARDER VEGETABLES such as carrots and
potatoes require 4-5 minutes cooking
time.
COOKING RICE
U
SE THE RECOMMENDATIONS ON THE PACKAGE regard-
ing the cooking time, the amount of water &
rice.
PLACE THE INGREDIENTS IN THE BOTTOM PART, cover
with the lid and set the time.
VESSELS
VESSELS USED SHOULD NOT be more than half filled.
If you intend to boil large amounts, you should
choose a larger vessel in order to ensure that
it’s not filled to more than half of its size. This is
to avoid over boiling.
27
Press to view recipes
Bread/Cakes
Snacks
Pizza/Pie
Please select food
Canned Rolls
Scones
DONENESS END TIME
COOK TIME
Normal
Baking
Pieces
09:004
11:18
Recipes
AUTO
RECIPES
TURN THE MULTIFUNCTION KNOB until Recipes is shown.
TURN THE ADJUST KNOB to select one of the recipes.
PRESS THE OK BUTTON to confirm your selection.
USE THE OK / ADJUST KNOB to navigate among and carry out the
needed settings.
PRESS THE START BUTTON.
U
SE THIS FUNCTION TO quickly navigate to your favorite recipe.
28
RECIPES
FOOD AMOUNT ACCESSORIES HINTS
POTATOES
B
OILED 300G - 1KG
STEAMER BOTTOM
+
LID.
P
LACE in steamer bot-
tom and add 100ml
water. Cover with lid.
B
AKED 200G - 1KG
MICROWAVE AND
OVENPROOF DISH
ON TURNTABLE.
WASH and prick. Turn
when oven prompts.
G
RATIN 4 - 10 PORTIONS
MICROWAVE AND
OVENPROOF DISH
ON TURNTABLE.
SLICE raw potatoes
and interlace with on-
ion. Season with salt,
pepper and garlic
and pour over cream.
Sprinkle cheese on
top.
(F
ROZEN)FRENCH FRIES 300G - 600G
CRISP PLATE
SPRINKLE with salt.
W
EDGES 300G - 800G
PEEL and cut in wedg-
es. Season and light-
ly oil the crisp plate +
drizzle oil on top. Stir
when oven prompts
F
OR FOOD NOT LISTED IN THIS TABLE and if the weight is lesser or greater than recommended weight,
you should follow the procedure for “Cook and reheat with microwaves”
29
RECIPES
FOOD AMOUNT ACCESSORIES HINTS
MEAT
RIBS 700G - 1,2KG CRISP PLATE
SEASON and place in
crisp plate.
ENTRECÔTE 2 - 6PCS
HIGH RACK ON
TURNTABLE
ADD MEAT when grill is
preheated. Turn when
oven prompts. Season.
L
AMB CUTLET 2 - 8PCS
BRATWURST 200G - 800G CRISP PLATE
LIGHTLY GREASE the
crisp plate. Add and
turn food when oven
prompts
(B
OIL)HOT DOG 4 - 8PCS
STEAMER BOTTOM
WITHOUT COVER
PLACE in steamer bot-
tom and cover food
with water.
(F
ROZEN)HAMBURGERS 100G - 500G
CRISP PLATE
LIGHTLY GREASE the crisp
plate. Add meat when
crisp plate is preheat-
ed. Turn food when
oven prompts.
B
ACON 50G - 150G
ADD FOOD when crisp
plate is preheated
and turn when oven
prompts
M
EAT LOAF 4 - 8 PORTIONS
MICROWAVE -
AND OVEN PROOF
DISH ON TURN-
TABLE
MAKE your favor-
ite meat loaf mix and
shape it into a loaf
F
OR FOOD NOT LISTED IN THIS TABLE and if the weight is lesser or greater than recommended weight,
you should follow the procedure for “Cook and reheat with microwaves”
30
RECIPES
FOOD AMOUNT ACCESSORIES HINTS
POULTRY C
HICKEN
FILLETS (STEAM) 300G - 800G STEAMER
SEASON and place in
steam grid. Add 100ml
water in bottom and
cover with lid
F
ILLETS (FRY) 300G - 1KG
CRISP PLATE
LIGHTLY GREASE the crisp
plate. Season and
add fillets when crisp
plate is preheated.
Turn food when oven
prompts
P
IECES 400G - 1,2KG
SEASON the pieces and
place on crisp plate
with the skin side up-
wards
F
OR FOOD NOT LISTED IN THIS TABLE and if the weight is lesser or greater than recommended weight,
you should follow the procedure for “Cook and reheat with microwaves”
31
RECIPES
FOOD AMOUNT ACCESSORIES HINTS
FISH
W
HOLE FISH
BAKED 600G - 1,2KG
MICROWAVE -
AND OVEN PROOF
DISH ON TURN-
TABLE
SEASON and brush with
some butter on top
B
OILED 600G - 1,2KG
MICROWAVE SAFE
DISH WITH COV-
ER OR USE PLASTIC
FILM AS COVER
SEASON and add 100ml
fish stock. Cook under
cover
F
ILLETS (STEAM) 300G - 800G STEAMER
SEASON and place in
steam grid. Add 100ml
water in bottom and
cover with lid
C
UTLETS
FRY 300G - 800G CRISP PLATE
LIGHTLY GREASE the crisp
plate. Season and
add food when crisp
plate is preheated.
Turn food when oven
prompts
STEAM 300G - 800G STEAMER
SEASON and place in
steam grid. Add 100ml
water in bottom and
cover with lid
(F
ROZEN)
G
RATIN 600G - 1,2KG
MICROWAVE -
AND OVEN PROOF
DISH ON TURN-
TABLE
COATED FILLETS 200G - 600G CRISP PLATE
LIGHTLY GREASE the crisp
plate. Add food when
crisp plate is preheat-
ed. Turn food when
oven prompts
FOR FOOD NOT LISTED IN THIS TABLE and if the weight is lesser or greater than recommended weight,
you should follow the procedure for “Cook and reheat with microwaves”
32
RECIPES
FOOD AMOUNT ACCESSORIES HINTS
VEGETABLES
(F
ROZEN)VEGETABLES 300G - 800G
STEAMER
PLACE IN STEAM GRID. Add
100ml water in bottom
and cover with lid.
C
ARROTS 200G - 500G
(GREEN)BEANS 2 00G - 500G
STEAMER BOT-
TOM + LID
PLACE in steamer bottom
and add 100ml water.
Cover with lid.
B
ROCCOLI 200G - 500G
STEAMER
PLACE IN STEAM GRID. Add
100ml water in bottom
and cover with lid.
C
AULI FLOWER 200G - 500G
(FROZEN)GRATIN 400G - 800G
MICROWAVE- AND OVEN PROOF DISH ON TURN-
TABLE
PEPPER
STEAM 200G - 500G STEAMER
PLACE IN STEAM GRID. Add
100ml water in bottom
and cover with lid.
FRY 200G - 500G
CRISP PLATE
LIGHTLY OIL the crisp
plate. Add food cut
in pieces when crisp
plate is preheated. Sea-
son and drizzle with oil.
Stir food when oven
prompts.
EGG PLANT 300G - 800G
CUT IN HALVES and sprin-
kle with salt and let
stand for a while. Light-
ly oil the crisp plate and
add food when crisp
plate is preheated. Turn
when oven prompts.
S
QUASH STEAM 200G - 500G
STEAMER
PLACE IN STEAM GRID. Add
100ml water in bottom
and cover with lid.
C
ORN ON COB 300G - 1KG
TOMATOES 300G - 800G
MICROWAVE-
AND OVEN
PROOF DISH ON
WIRE RACK
CUT IN HALVES, season and
sprinkle cheese on top.
F
OR FOOD NOT LISTED IN THIS TABLE and if the weight is lesser or greater than recommended weight,
you should follow the procedure for “Cook and reheat with microwaves”
33
RECIPES
FOOD AMOUNT ACCESSORIES HINTS
PASTA
P
ASTA 1 - 4 PORTIONS
STEAMER BOT-
TOM AND LID
SET RECOMMENDED cook
time for the pasta. Pour
water in steamer bot-
tom. Cover with lid.
Add pasta when oven
prompts and cook cov-
ered.
L
ASAGNA
HOME MADE 4 - 10 PORTIONS
MICROWAVE-
AND OVEN
PROOF DISH ON
TURNTABLE
PREPARE your favorite
recipe or follow the reci-
pe on the lasagne pack-
age.
F
ROZEN 400G - 1KG
MICROWAVE- AND OVEN PROOF DISH ON TURN-
TABLE
RICE
B
OILED RICE
100ML -
400ML
STEAMER BOT-
TOM AND LID
SET RECOMMENDED cook
time for rice. Add water
and rice in bottom part
and cover with lid
P
ORRIDGE
RICE 2 - 4 PORTIONS
PLACE RICE AND WA TER into
the steamer bottom.
Cover with lid. Add milk
when the oven prompts
and continue the cook-
ing
O
AT 1 - 2 PORTIONS
MICROWAVE
SAFE PLATE
WITHOUT COVER
MIX OAT FLAKES, salt and
water
F
OR FOOD NOT LISTED IN THIS TABLE and if the weight is lesser or greater than recommended weight,
you should follow the procedure for “Cook and reheat with microwaves”
34
RECIPES
RECIPES
FOOD AMOUNT ACCESSORIES HINTS
PIZZA / PIE
P
IZZA
HOME MADE 1 BATCH CRISP PLATE
PREPARE YOUR FAVORITE rec-
ipe (dough made with
150ml water) and place
on the crispplate
T
HIN (FROZEN) 250G - 500G
CRISP PLATE
REMOVE package
P
AN (FROZEN) 300G - 800G
CHILLED 200G - 500G
ADD THE PIZZA when crisp
plate is preheated
Q
UICHE
LORRAINE 1 BATCH
PREPARE THE PASTRY (250g
flour, 150 g butter +
2½ tblsp water) and
line the crisp plate with
the pastry. Prick it. Pre
bake the pastry. When
oven prompts to add
the stuffing, place 200g
of ham, 175g of cheese
and pour over a mix of 3
eggs and 300 ml cream.
Place into the oven and
continue the cooking
(F
ROZEN) 200G - 800G REMOVE package
F
OR FOOD NOT LISTED IN THIS TABLE and if the weight is lesser or greater than recommended weight,
you should follow the procedure for “Cook and reheat with microwaves”
FOOD AMOUNT ACCESSORIES HINTS
BREAD / CAKES
R
OLLS CANNED 4 - 6 PCS
CRISP PLATE
REMOVE from package.
Add when oven is pre-
heated
S
CONES 1 BATCH
SHAPE into one scones
or in smaller pieces on
greased crisp plate
F
OR FOOD NOT LISTED IN THIS TABLE and if the weight is lesser or greater than recommended weight,
you should follow the procedure for “Cook and reheat with microwaves”
35
RECIPES
FOOD AMOUNT ACCESSORIES HINTS
SNACKS
P
OPCORN 90 - 100G
PLACE BAG on turntable. Only pop one bag at
a time
R
OASTED NUTS 50G - 200G
CRISP PLATE
ADD NUTS when the crisp plate
is preheated. Stir when oven
prompts
C
HICKEN
BUFFALO
WINGS
300G - 600G
NUGGETS
(FROZEN)
250
G - 600G
ADD NUGGETS when crisp plate
is preheated. Turn when oven
prompts
DESSERT
F
RUIT PIE
HOME MADE 1 BATCH
MAKE A PASTRY of 180g flour,
125g butter and 1 egg. (or use
ready made pastry) Line the
crisp plate with the pastry and
fill with 700-800g sliced ap-
ples mixed with sugar and cin-
namon
F
ROZEN 300G - 800G REMOVE package
BAKED APPLES 4 - 8PCS
MICROWAVE-
AND OVEN
PROOF DISH ON
TURNTABLE
REMOVE THE PIPES and fill with
marzipan or cinnamon, sugar
and butter
C
RÈME CARAMEL 2 - 6 PORTIONS
MICROWAVE-
AND OVEN
PROOF DISH
AND CRISP
PLATE
FOR 4 SERVINGS mix 4 egg yolks,
75ml sugar and 1 tbsp vanil-
la. Heat 200ml cream +150ml
milk for 3-3½ min on Jet pow-
er and add to the eggs. Pour
the mixture into portion dish-
es. Pour 500ml water in the
crispplate and place the dish-
es in the water when the oven
beeps. Sprinkle sugar on top
when cool and melt with a gas
burner.
F
RUIT COMPOTE 300G - 800ML STEAMER
PLACE IN STEAM GRID. Add 100ml
water in the bottom and cov-
er with lid
F
OR FOOD NOT LISTED IN THIS TABLE and if the weight is lesser or greater than recommended weight,
you should follow the procedure for “Cook and reheat with microwaves”
36
MAINTENANCE & CLEANING
CLEANING IS THE ONLY MAINTENANCE normally re-
quired.
F
AILURE TO MAINTAIN THE OVEN in a clean condition
could lead to deterioration of the surface that
could adversely affect the life of the appliance
and possibly result in a hazardous situation.
D
O NOT USE METAL SCOURING PADS,
ABRASIVE CLEANSERS, steel-
wool pads, gritty wash-
cloths, etc. which can
damage the control pan-
el, and the interior and exterior oven sur-
faces. Use a sponge with a mild detergent
or a paper towel with spray glass cleaner.
Apply spray glass cleaner to a paper towel.
DO NOT SPRAY directly on the oven.
A
T REGULAR INTERVALS, especially if spill
overs have occurred, remove the
turntable, the turntable support
and wipe the base of the oven
clean.
T
HIS OVEN IS DESIGNED to operate with the turnta-
ble in place.
DO NOT operate the microwave oven
when the turntable has been removed
for cleaning.
U
SE A MILD DETERGENT, water and a soft cloth to
clean the interior surfaces, front and rear of the
door and the door opening.
DO NOT ALLOW GREASE or food particles to
build up around the door.
D
O NOT USE STEAM CLEANING APPLIANCES when
cleaning your microwave oven.
A
DDING SOME LEMON JUICE to a cup of water, plac-
ing this on the turntable and boiling for a few
minutes can eliminate odors inside the oven.
F
OR STUBBORN STAINS, boil a cup of water in the
oven for 2 or 3 minutes. Steam will soften the
marks.
T
HE GRILL ELEMENT does not need cleaning since
the intense heat will burn off any splashes, but
the ceiling above it may need regular cleaning.
This should be done with warm water, deter-
gent and a sponge. If the Grill is not used reg-
ularly, it should be run for 10 minutes a month
to burn off any splashes.
37
DISHWASHER SAFE:
T
URNTABLE SUPPORT.
G
LASS TURNTABLE.
C
RISP HANDLE.
WIRE RACK.
CAREFUL CLEANING:
T
HE CRISP-PLATE should be cleaned
in mild, detergent water.
Heavily soiled areas can
be cleaned with a scouring
sponge and a mild cleanser.
ALWA YS let the crisp-plate cool off before clean-
ing.
DO NOT immerse or rinse with water while
the crisp-plate is hot. Quick cooling may
damage it.
DO NOT USE STEEL-WOOL PADS. This will
scratch the surface.
S
TEAMER
TROUBLE SHOOTING GUIDE
IF THE OVEN DOES NOT WORK, do not make a service
call until you have made the following checks:
The Turntable and turntable support is in
place.
The Plug is properly inserted in the wall
socket.
The Door is properly closed.
Check your Fuses and ensure that there is
power available.
Check that the oven has ample ventilation.
Wait for 10 minutes, then try to operate the
oven once more.
Open and then close the door before you
try again.
THIS IS TO AVOID unnecessary calls for which you
will be charged.
When calling for Service, please give the serial
number and type number of the oven (see Ser-
vice label). Consult your warranty booklet for
further advice.
IF THE MAINS CORD NEEDS REPLACING it should
be replaced by the original
mains cord, which is available
via our service organiza-
tion. The mains cord may
only be replaced by a trained
service technician.
S
ERVICE ONLY TO BE CARRIED OUT
BY A TRAINED SERVICE TECHNICIAN.
It is hazardous for anyone oth-
er than a trained person to carry
out any service or repair oper-
ation, which involves the re-
moval of any cover, which gives pro-
tection against exposure to microwave
energy.
DO NOT REMOVE ANY COVER.
MAINTENANCE & CLEANING
COVER
38
IN ACCORDANCE WITH IEC 60705.
THE INTERNATIONAL ELECTROTECHNICAL COMMISSION has developed a standard for comparative testing of
heating performance of different microwave ovens. We recommend the following for this oven:
DATA FOR TEST HEATING PERFORMANCE
TECHNICAL SPECIFICATION
Test Amount Approx. time Power level Container
12.3.1 1000 g 12 - 13 min 650 W Pyrex 3.227
12.3.2 475 g 5 ½ min 650 W Pyrex 3.827
12.3.3 900 g 13 - 14 min 750 W Pyrex 3.838
13.3 500 g 10 min 160 W
SUPPLY VOLTAGE 230 V/50 HZ
RATED POWER INPUT 2800 W
F
USE 16 A
MW
OUTPUT POWER 900 W
G
RILL 1600 W
O
UTER DIMENSIONS (HXWXD) 455 X 595 X 560
I
NNER DIMENSIONS (HXWXD) 210 X 450 X 420
39
40
5019-321-01867
GB
Whirlpool is a registered trademark of Whirlpool, USA.
© Whirlpool Sweden AB 2012. All rights reserved. Made in Sweden.
Rev /B
ENVIRONMENTAL HINTS
THE PACKING BOX may be fully re-
cycled as confirmed by the re-
cycling symbol. Follow lo-
cal disposal regulations. Keep
potentially hazardous pack-
aging (plastic bags, polysty-
rene etc.) out of the reach of chil-
dren.
T
HIS APPLIANCE is marked according to the Euro-
pean directive 2002/96/EC on Waste Electrical
and Electronic Equipment (WEEE). By ensuring
this product is disposed of correctly, you will
help prevent potential negative consequences
for the environment and human health, which
could otherwise be caused by inappropriate
waste handling of this product.
T
HE SYMBOL on the product,
or on the documents ac-
companying the product,
indicates that this appliance
may not be treated as house-
hold waste. Instead it shall be
handed over to the applica-
ble collection point for the
recycling of electrical and
electronic equipment.
D
ISPOSAL must be carried
out in accordance with lo-
cal environmental regulations for waste dis-
posal.
FOR MORE DETAILED INFORMATION about treatment,
recovery and recycling of this product, please
contact your local city office, your household
waste disposal service or the shop where you
purchased the product.
BEFORE SCRAPPING, cut off the mains cord so that
the appliance cannot be connected to the
mains.
