HOTO
Compressed Air Capsule
Stay tuned to our social media
(@hoto_official)
Warning!
1
Please read all safety warnings, instructions, illustrations, and rules
provided along with the product and keep all warnings and instructions for
reference.
Read this manual carefully before use, and retain it for future reference.
This product will make noise around 75dB when working. Please be careful.
This product is not a toy, and children are forbidden to use it.
Do not vacuum cleaning without attaching dust cup.
This product is very powerful, please keep distance with your hair while
using.
01 Safety Instructions
2
HOTO Compressed Air Capsule enables vacuum cleaning, inflating, dust
blowing and vacuum deflating after the accessories are installed. For
details, please visit the sales page or contact Hoto customer service.
The images shown are for illustration purposes only and may not be an
exact representation of the product.
02 Product Overview
Charging
port
Inflating
port
Deflating port
Battery
indicator light
ON/OFF
button
Vacuum cleaning accessories
Inflating/deflate valve
Vacuuming connector
Dust cup (including a
HEPA and metal filter)
Short air valve
Vacuum deflating
connector
Long air valve
Swim ring air
valve
Movable brush
vacuum head
3
Battery indicator and charging
Battery indicator
When the product is working, its battery indicator
light is on.
When the power is ≥ 20%, the white indicator
light always stays on.
When the power is ＜ 20%, the red indicator light
always stays on, indicating that the product
needs charging.
Charging
Please fully charge the product before using it for
the first time. Please charge the product using an
adapter that matches the product's charging
power through a charging cable.
Charging status:
When the product is being charged, the red light
presents a breathing lighting style.
When it is 100% charged, the white light always
stays on.
Suggestions:
The product cannot be used when it is being charged.
Please buy a safe and compliant 5 V USB adapter.
03 How to Use
4
5
Turn-on/Turn-off/Gear switch
Turn-on
Press and hold the ON/OFF button for 1.5 seconds to turn on the machine
and make it work.
Turn-off
When the machine is working, press and hold the ON/OFF button for 1.5
seconds to make it stop working and turn it off.
Gear switch
The machine will run in high gear by default after being turned on. You can
press the ON/OFF button to switch to low gear and then press the button to
switch to high gear.
6
Installation and cleaning of the vacuum cleaning accessories
Installation of the dust cup
Please align the dot marking on the dust cup with the unlocking marking on
the machine body, insert the dust cup, and rotate it clockwise to tighten it up.
When the dust cup is installed, the dot marking on the dust cup will be aligned
with the locking marking on the machine body.
You can remove the dust cup by rotating it counterclockwise.
1 2
7
Installation of the movable brush vacuum head
After the dust cup is installed, insert the movable brush vacuum head into
the dust cup according to the arrow as illustrated. When it is fully inserted,
there will be an obvious gear sense, indicating that the vacuum head is fully
installed. The brush component is movable. It can be pulled and pushed
back and forth.
Hold and pull the integrated short brush vacuum head to remove it.
1 2
8
Removal and installation of the HEPA in the dust cup
1. Press the dust cup lid and then rotate to screw it out.
2. Take out the internal filter and remove the dust in the dust cup.
3. If you want to change the HEPA for a new one, please rotate the metal
gauze on the filter to remove it and then rotate and install the new HEPA
and metal gauze.
1 2 3
2
9
Installation of the air valve and connector
Installation of the air valve
Please align the bump on the air valve with the groove on the inflating/suc-
tion port, insert the air valve, and rotate the air valve clockwise to tighten it
up. When the air valve is fully installed, there will be an obvious gear sense.
You can rotate the air valve counterclockwise to remove it.
1
2
10
Installation of the suction connector
Please align the bump on the connector with the groove on the suction
port, insert the connector, and rotate it clockwise to tighten it up. When the
connector is fully installed, there will be an obvious gear sense.
You can remove the connector by rotating it counterclockwise.
1
11
Attention
Please use the product with caution when the pressure allowed by the
balloon is smaller than the max inflating pressure of the product.
Please do not use accessories other than the components of the dust cup
for vacuum cleaning, as the intrusion of fine dust may damage the product.
This product is not a toy, and children are forbidden to use it. The
minimum recommended age for users is 16 years old. During working,
please keep children at a safe distance from the product.
The built-in lithium battery of the product cannot be disassembled. Do not
throw the product into the fire or discard it at will. Overheating and hitting
of the lithium battery and water damage to it may cause fire, autoignition,
and explosion. Please do not place the product in hot environments such
as vehicles for long.
Do not keep the product at a temperature below -10℃ or above 45℃,
because overcooling or overheating will shorten the product's life of
service and damage the built-in battery.
If the product is left idle for long, its battery may be damaged. Please
charge the product at least every three months.
The product is equipped with a built-in direct current machine. Please do
not use it in flammable and explosive environments.
04 Precautions
Please turn off the machine immediately if it makes a strange voice or
overheats when working.
Please do not leave during the inflating. Observe the inflating process to
prevent the inflating pressure from being too high.
Please use the product in a dry and clean environment, as the product is
not waterproof. Do not rinse the product.
Please use a safe and compliant adapter, in combination with a compliant
charging cable, to charge the product. Faults caused by a failure to charge
as stipulated above will not be covered by the warranty.
12
Please do not place the battery in extremely hot environments, such as
sunshine, fire, microwave oven, and oven. Otherwise, explosions or
flammable liquid and gas leakages may be caused.
Please do not disassemble, hit, crush, or cut the battery. Otherwise,
explosions may be caused.
Please do not place the battery under extremely low air pressure.
Otherwise, the battery may explode, or the flammable liquid and gas may
leak.
Please do not use the product if its battery is severely swollen.
05 Battery
13
06 Troubleshooting
Issues
Fail to turn this product on
Slow inflating
Already turned on but
unable to work
Air leaks after the air
valve is connected
Turn on the machine after charing for a while
1. Check whether the power is sufficient.
2. Check whether accessories are fully
installed.
3. Check whether the air outlet is fully
connected to the air valve of the inflated
object.
4. Check whether the inflated object is
subject to any air leakage.
1. Check whether the power is sufficient.
2. Check whether the ambient temperature
is beyond the requested range.
Solutions
1. Check whether the air valve is fully
installed.
2. Check whether the air valve is damaged
or cracked.
Name: HOTO Compressed Air Capsule
Model: QWCXJ001
Item Dimensions:
Approx. 55×56×163.5mm (bare machine，without accessories)
Net Weight: Approx. 356g
Color: Black
Max Suction: 15000 Pa
Storage Temperature: -10℃~45℃
Battery Type: Lithium-ion battery
Battery Capacity: 1900mAh
Operating Noise: Around 75dB
Rated Input: 5V 3A
Rated Power：120W
Rated Voltage：10.8V
Charging Port: USB Type-C
Charging Time: Approx. 2.5 hours
14
07 Specifications
15
08 Regulatory Compliance Information
Europe — EU declaration of conformity
We, Shanghai HOTO Technology Co., Ltd., hereby, declare that this
equipment is in compliance with the applicable Directives and
European Norms, and amendments.
Disposal and recycling information
All products bearing this symbol are waste electrical and electronic
equipment (WEEE as in directive 2012/19/EU) which should not be
mixed with unsorted household waste. Instead, you should protect
human health and the environment by handing over your waste equipment
to a designated collection point for the recycling of waste electrical and
electronic equipment, appointed by the government or local authorities.
Correct disposal and recycling will help prevent potential negative
consequences to the environment and human health. Please contact the
installer or local authorities for more information about the location as well
as terms and conditions of such collection points.
16
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
This supplier’s declaration of conformity is hereby for
We declare that the above mentioned device has been tested and found in
compliance with CFR 47 Part 15 Regulation.
Product: HOTO Air Compressed Machine
Model Number(s): QWCXJ001
Brand/Trade: HOTO
Federal Communications Commission Supplier’s
Declaration of Conformity
Manufacturer: Shanghai HOTO Technology Co., Ltd.
Address: Building 45, No.50 Moganshan Road, Shanghai, China
17
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Representative of Responsible Party for SDoC
Company: Shanghai HOTO Technology Co., Ltd.
Address: Building 45, No.50 Moganshan Road, Shanghai, China
Country: China
Telephone No.: 400-021-8696
Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
18
DECLARATION OF CONFORMITY
EU Declaration of Conformity
We
Shanghai HOTO Technology Co., Ltd.
Declare that the product:
HOTO Compressed Air Capsule / QWCXJ001
Complies with the essential health and safety requirements of the
following directives:
2014/30/EU Electromagnetic Compatibility directive References to the
following harmonized standard were made:
20011/65/EU+ (EU) 2015/863 Restrictions of the Use of Certain Hazardous
Substances in Electrical and Electronic Equipment
Authorised signatory and technical file holder:
Shanghai HOTO Technology Co., Ltd.
Building 45, No.50 Moganshan Road Shanghai, China.
EN55014-1: 2021
EN55014-2: 2021
EN IEC 61000-3-2:2019+A1:2021
EN 61000-3-3:2013+A2:2021
