1. SAFETY
1.1. ELECTRICAL SAFETY
WARNING! It is the user’s responsibility to check the following:
Check all electrical equipment and appliances to ensure that they are safe before using.
Inspect power supply leads, plugs and all electrical connections for wear and damage.
Ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply.
8 DO NOT use worn or damaged cables, plugs or connectors.
9 Ensure that any faulty item is repaired or is replaced immediately by a qualied electrician.
9 If the cable or plug is damaged during use, switch off the electricity supply and remove from use.
9 Sealey recommend that an RCD (Residual Current Device) is used with all electrical products.
IMPORTANT: Ensure that the voltage rating on the appliance suits the power supply to be used and that the plug is tted with the
correct fuse.
8 DO NOT pull or carry the appliance by the power cable.
8 DO NOT pull the plug from the socket by the cable.
1.2. GENERAL SAFETY
9 Save this manual for the safety warnings and precautions, assembly instructions, operating and maintenance procedures, parts list
and diagrams. Keep your invoice with this manual. Keep the manual and invoice in a safe and dry place for future reference.
9 Only to be used by skilled or instructed persons.
9 Familiarise yourself with the application and limitations of the product, as well as the specific hazards.
WARNING! Isolate the product from the electrical supply before servicing or performing any maintenance.
9 Maintain the product in good condition (use an authorised service agent).
9 Replace or repair damaged parts. Use recommended parts only. Unauthorised parts may be dangerous and will invalidate the
warranty.
9 Locate and fix the product in a suitable work area. DO NOT position in direct sunlight, or in areas of extreme heat or cold.
9 Keep children and unauthorised persons away from the work area.
8 DO NOT use the product for any purpose other than that for which it is designed.
8 DO NOT operate the product when you are tired, under the influence of alcohol, drugs or intoxicating medication.
9 When not in use, switch off and unplug from the electrical supply.
WARNING! DO NOT dismantle the product, to do so may result in damage to the product and/or personal injury and will invalidate the
warranty. Internal maintenance, which will require the opening of the casing, must only be undertaken by an authorised service agent.
9 Keep work area clean. Cluttered areas invite injuries.
9 Observe work area conditions. DO NOT use machines or power tools in damp or wet locations. Don’t expose to rain. Keep work area
well lit. DO NOT use electrically powered tools in the presence of flammable gases or liquids.
9 Keep children away. Children must never be allowed in the work area. DO NOT let them handle machines, tools, or extension cords.
9 Store idle equipment. When not in use, tools must be stored in a dry location to inhibit rust. Always lock up tools and keep out of reach
of children.
8 DO NOT force tool. It will do the job better and more safely at the rate for which it was intended. DO NOT use inappropriate
attachments in an attempt to exceed the tool capacity.
9 Use the right tool for the job. DO NOT attempt to force a small tool or attachment to do the work of a larger industrial tool. DO NOT
modify this tool and DO NOT use this tool for a purpose for which it was not intended.
9 Dress properly. DO NOT wear loose clothing or jewellery as they can be caught in moving parts. Protective, electrically non-conductive
clothes and non-skid footwear are recommended when working. Wear restrictive hair covering to contain long hair.
9 Use eye and ear protection. Always wear ANSI approved impact safety goggles. Wear a full face shield if you are producing metal
filings or wood chips. Wear an ANSI approved dust mask or respirator when working around metal, wood, and chemical dusts and
mists.
9 Avoid unintentional starting. Be sure the switch is in the Off position when not in use and before plugging in.
9 Stay alert. Watch what you are doing, use common sense. DO NOT operate any tool when you are tired.
9 Check for damaged parts. Before using any tool, any part that appears damaged should be carefully checked to determine that it will
operate properly and perform its intended function. Check for alignment and binding of moving parts; any broken parts or mounting
fixtures; and any other condition that may affect proper operation.
VIBRATORY TUMBLER PARTS CLEANER
18LB
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to
instruction
manual
SB949 Issue 3 11/11/24
Original Language Version
© Jack Sealey Limited
Wear ear
protection
Wear a face
shield
Wear eye
protection
Wear a mask
MODEL No's: SB949
Any part that is damaged should be properly repaired or replaced by a qualified technician. DO NOT use the tool if any switch does not
turn on and off properly.
9 Guard against electric shock. Prevent body contact with grounded surfaces.
9 Replacement parts and accessories. When servicing, use only identical replacement parts. Use of any other parts will void the
warranty. Only use accessories intended for use with this tool.
8 DO NOT operate tool if under the influence of alcohol or drugs. Read warning labels if taking prescription medicine to determine if your
judgment or reflexes are impaired while taking drugs. If there is any doubt, DO NOT operate the tool.
1.2.1. MAINTENANCE. For your safety, service and maintenance should be performed regularly by a qualified technician.
NOTE: Performance of this tool may vary depending on variations in local line voltage.
9 Extension cord usage may also affect tool performance.
WARNING! The warnings, cautions, and instructions discussed in this instruction manual cannot cover all possible conditions and
situations that may occur. It must be understood by the operator that common sense and caution are factors which cannot be built into
this product, but must be supplied by the operator.
8 DO NOT exceed 18lb tank capacity.
8 DO NOT use without top lid in place. Hazardous dust may be created and media and/or work materials may be ejected.
8 DO NOT remove top lid immediately after use. Wait at least 1 hour after tumbling is complete before opening top lid. This will allow
dust to settle.
8 DO NOT place items on the top lid during use.
9 Stay alert, watch what you are doing and use common sense when operating a power tool.
9 Industrial applications must follow OSHA guidelines.
9 Maintain labels and nameplates on the tool. These carry important safety information.
9 Avoid unintentional starting. Prepare to begin work before turning on the tool.
9 People with pacemakers should consult their physician(s) before use. Electromagnetic fields in close proximity to heart pacemaker
could cause pacemaker interference or pacemaker failure.
2. INTRODUCTION
Vibratory tumbler suitable for surface cleaning and polishing, rust removal and deburring, providing quick and effective results. Can be
used wet or dry with polishing media. Allows for efficient cleaning and polishing of various small metal objects and other items with the
assistance of cleaning medias. Features a polymer bowl designed to withstand rigorous use and ensure longevity.
3. SPECIFICATION
4. OPERATION
4.1. PREPARATION
WARNING! Before appliance assembly or adjustment, make sure the appliance’s switch is turned off, the cord is unplugged, and the
unit has cooled completely.
4.2. TO PREVENT SERIOUS INJURY FROM TOOL FAILURE: DO NOT use damaged equipment. If abnormal noise or vibration occurs,
have the problem corrected before further use.
4.2.1. Clean the appliance before use as explained in the Maintenance section.
4.2.2. Ensure that the plastic drain plugs are secure and will not leak if fluid is added to the vibratory bowl.
8 DO NOT plug in the vibratory bowl until ready for operation.
4.2.3. This vibratory tumbler is designed for deburring, cleaning or polishing work materials of various types using either wet or dry polishing
media. NOTE: Very sharp or hard work materials or media may cause excessive wear on the vibratory bowl. DO NOT use very sharp
or hard materials in this appliance.
4.2.4. Various media are available for different jobs. Select the appropriate media and running time for your work material. The chart below
offers suggestions for various situations. Always do a test run on a few pieces of work material to test the media and running time
before committing work material to a specific process.
NOTE: This is a chart of recommended media for this vibratory bowl. Plastic beads are usually used with a powdered abrasive added.
Walnut shells and corn cob may be used alone, or with added abrasive. Polishing materials include rouge, ruby powder and linde A.
Original Language Version
© Jack Sealey Limited
Model No: SB949
Bowl Capacity: 8.15kg
Bowl Opening Size: Ø250mm
Nett Weight: 12.5kg
Supply: 230V/50Hz
Media Type Abrasive Application Weight
Plastic Beads Fine Silicate. Light surface reduction, surface
preparation for polishing.
62 lb. per cubic foot.
Plastic Beads Medium Silicate. Medium surface reduction, deburring. 56lb. per cubic foot.
Plastic Beads Coarse Aluminum Oxide. Heavy surface reduction, deburring. 62lb. per cubic foot.
Walnut Shell Rouge. Polishing Oxide removal. 45lb per cubic foot.
Walnut Shell None Added. Polishing. 45lb. per cubic foot.
Corn Cob None Added. Polishing. 29 lb. per cubic foot.
Red Rouge 1st Step Polisher. Powdered Polishing Additive. May vary, not specied.
Ruby Powder Medium Polisher. Powdered Polishing Additive. May vary, not specied.
Linde A Finish Polisher. Powdered Finishing Additive. May vary, not Specied.
SB949 Issue 3 11/11/24
SB949
4.2.5. ADDITIONAL NOTES
4.2.6. Steel and ceramic media, generally used in tumbling, can also be used however they may cause the bowl to wear out over time due to
them being an aggressive media. There is a wide variety of media to be used in vibratory finishing.
4.3. MEDIA SELECTION
4.3.1. FOR DEGREASING use ground corncob, walnut shell or plastic media. Vibrate for 30 minutes to 1 hour.
4.4. TO REMOVE RUST use commercially available treated plastic media. Depending on the condition materials, you will have to vibrate
for 2 - 6 hours.
4.5. TO DE-BURR OR POLISH, vibrate in walnut hull, plastic beads, or corncob media. You may add a small amount of commercial metal
polish.
CAUTION: Vibratory finishing often creates dust which may be harmful to your health. Wait for at least 1 hour after vibrating is
complete and the vibratory tumbler has been turned OFF before opening the vibratory tumbler. This will allow the dust to settle.
Never vibrate with the top off, as hazardous dust may be created, and the media or work materials may be ejected from the vibratory
tumblerr.
4.5.1. Fill the vibratory bowl about 2/3 full with polishing media (not included).
4.5.2. Add work material parts to vibratory bowl. DO NOT overfill tumbler bowl, and DO NOT exceed work weight limit of 18lb including
media.
4.5.3. Place the top lid on the vibration bowl. Place the rubber washer and the flat washer on the threaded shaft.
4.5.4. Place the clamp nut on the threaded shaft and tighten in place. Tighten enough to keep the top lid in place. DO NOT overtighten.
4.5.5. Plug in the unit and press the power switch to the ON position. The vibratory tumbler will begin to operate.
4.5.6. When the job is completed, turn the power switch OFF and unplug the unit.
4.5.7. Remove the clamp nut, and pull the top lid off the threaded shaft bringing the flat washer and rubber washer with it. Set the cover
assembly aside.
4.5.8. If a lubricant is used, then the overflow hose must be used to drain any excess lubricant/water into a suitable container, preventing
overflow.
4.5.9. Check the work material to determine if the job is completed to satisfaction. If additional work is required, replace the lid assembly and
repeat the process. If the work is completed, unload the work material and media.
4.5.10. To prevent accidents, turn off the appliance and disconnect its power supply after use. Clean, then store the appliance indoors out of
children’s reach.
5. MAINTENANCE
WARNING! Procedures not specifically explained in this manual must be performed only by a qualified technician.
5.1. CLEANING, MAINTENANCE, AND LUBRICATION
5.1.1. BEFORE EACH USE, inspect the general condition of the tumbler. Check for:
5.1.2. Loose hardware.
5.1.3. Misalignment or binding of moving parts.
5.1.4. Cracked or broken parts.
5.1.5. Damaged electrical wiring, and any other condition that may affect its safe operation.
5.1.6. Check that the rubber washer is in good condition and in place. Replace if damaged.
5.1.7. The rubber feet at the bottom of the base may eventually wear out. Inspect these periodically. If worn, replace.
5.1.8. Protect the motor from water and moisture.
5.1.9. Store vibration tumbler in a dry location and out of the reach of children when not in use.
5.1.10. After use, wipe external surfaces of the tumbler with a clean cloth.
WARNING! If the supply cord of this power tool is damaged, it must be replaced only by a qualified service technician.
Original Language Version
© Jack Sealey Limited
SB949 Issue 3 11/11/24
6. TROUBLESHOOTING
Follow all safety precautions whenever diagnosing or servicing the tool. Disconnect power supply before service.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved
containers and dispose of the product and fluids according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without
prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
REGISTER YOUR
PURCHASE HERE
PROBLEM POSSIBLE CAUSES LIKELY SOLUTIONS
Tool will not start. 1. Cord not connected.
2. No power at outlet.
3.Tool’s thermal reset breaker tripped (if equipped).
4. Internal damage or wear.(Carbon brushes or switch, for
example).
1. Check that cord is plugged in.
2. Check power at outlet. If outlet is unpowered, turn off
tool and check circuit breaker. If breaker is tripped, make
sure circuit is right capacity for tool and circuit has no
other loads.
3. Turn off tool and allow to cool. Press reset button on
tool.
4. Have technician service tool.
Tool operates
slowly.
Extension cord too long or wire size too small. Eliminate use of extension cord. If an extension cord is
needed, use one with the proper diameter for its length
and load.
Performance
decreases over
time.
1. Accessory dull or damaged.
2. Carbon brushes worn or damaged.
1. Keep cutting accessories sharp. Replace as needed.
2. Have qualied technician replace brushes.
Excessive noise
or rattling.
Internal damage or wear. (Carbon brushes or bearings, for
example).
Have technician service tool.
Overheating.
1. Forcing machine to work too fast.
2. Blocked motor housing vents.
3. Motor being strained by long or small diameter
extension cord.
1. Allow machine to work at its own rate.
2. Wear ANSI approved safety goggles and NIOSH-
approved dust mask/respirator while blowing dust out of
motor using compressed air.
3. Eliminate use of extension cord. If an extension cord
is needed, use one with the proper diameter for its length
and load.
Work material
is not nished
properly.
1. Improper media is being used.
2. Material has not been processed long enough.
1. Review media selection and try another option.
2. Unload excess material or extend vibration time cycle.
Original Language Version
© Jack Sealey Limited
SB949 Issue 3 11/11/24
