CA30
Heated Clothes Airer
PLEASE READ ALL THE INSTRUCTIONS BEFORE USE
2
Model
Number
IP
Rating
°C Dimensions Power Voltage
CA30 IPX1 45-55*
Open
147x73.5x70cm
57.9x28.9x27.6in
300W
220-240V
50-60Hz
Folded
147x73.5x15.5cm
/ 57.9x28.9x6.1in
Features and Specications
Components
1
2
3
6
7
8
9
10
4
5
1. Detachable pegs
2. Heated bars
3. Tier shelf 1
4. Tier shelf 2
5. Tier shelf 3
6. Shelf clips
7. Support bars
8. On/Off switch
9. Power cable
10. Feet
* If covered with textiles, the temperature can raise to 60-70°C
3
PLEASE READ THIS MANUAL CAREFULLY AND RETAIN FOR FUTURE
REFERENCE
• This appliance is for indoor/household use only. Do not use outdoors.
• This appliance is not designed for commercial or industrial use; it is for
household use only.
• This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge unless they have been given supervision or instruction concerning
the use of the appliance by a person responsible for their safety.
• Children should be closely supervised at all times to ensure that they do not
play with the appliance.
• Only use the appliance out of the reach of children because it gets hot.
• Do not operate this appliance if the power cable or plug is damaged. If
either is damaged, return it to Duronic for service or repair by a professional
technician.
• Never try to replace the parts and repair the unit by yourself. Do not modify
the appliance in any way that is not described in the instructions for use. The
appliance contains live parts. Repairs may only be carried out by Duronic,
using original spare parts and accessories.
• If an extension lead/cable is needed to reach the appliance to a mains power
socket that is too far away out of reach of the appliance’s accompanying
cable, please ensure that:
- the marked electrical rating of the extension lead is at least as great
as the electrical rating of the appliance.
- the extension lead is of the grounded type.
- no other appliance is plugged into the same extension lead.
- the extension cable is safely positioned to avoid it being pulled on by
children or animals or being tripped over.
Safety Information
4
• Always operate the appliance on a dry, smooth, even, stable and heatproof
surface. Do not put the appliance against any items of furniture or touching
any other objects. The airer should be freestanding and in a space that allows
some clearance space around the heated rails. Do not stand this airer on top
of any furniture.
• Do not cover the airer with down-feather quilts, coats or pillows. Do not cover
with very heavy textile items as this may cause the appliance to overheat.
• Disconnect the mains plug from the power socket if you are going to be
absent for long periods.
• Never disconnect the plug by pulling on the power cable.
• Unplug from the mains plug outlet when not in use and before cleaning.
• This appliance is not intended to be operated using an external timer or
separate remote-control system.
• Do not let the power cable hang over the edge of the table or counter, or
touch hot surfaces.
• When opening and closing the airer, never use force. The mechanisms should
move freely and easily. Be careful to keep ngers away from the folding parts.
• Ensure the airer is opened and folded out securely before loading it with
laundry and before switching it on.
• Do not use the appliance for anything other than drying textiles.
• Do not attempt to move or relocate the appliance whilst it is in use or still hot.
Allow it to cool properly and unplug it before relocating it.
• Do not exceed the maximum load capacity of 30kg (5kg per wing). Ensure
that the load is distributed evenly across the surface to avoid the airer tipping
over.
• Do not attempt to clean or fold and store the appliance whilst it is still hot.
Allow it to cool properly and unplug it before cleaning or storing it away.
Safety Information (continued)
5
Come rain or shine, with the Duronic CA30 extra-large indoor electric heated
clothes dryer you can dry your washing quickly and efciently no matter what the
weather is like.
Both a more energy-efcient option for drying clothes than a tumble dryer and at
the same a kinder option for drying fabrics and textiles, with this heated clothes
airer you can dry your laundry in just 4-8 hours.
This airer has 3 tiers/shelves which all open vertically with 12 wide heated bars on
each tier, giving a total of 36 bars of easily accessible drying space. Clothes can
be hung on individual bars, delicate items can be laid at over the rungs to avoid
any unwanted stretching and, for longer garments such as coats or shirts, they
can be hung from hangers on the higher bars to ensure a crease-free result.
A set of 6 handy pegs are included that are ideal for hanging smaller items such
as underwear or socks.
The main structure is made of aluminium making it both strong, and at the same
time lightweight so it is easy to move around the home. In addition to this, the
foldable design makes storage easy and convenient when it is not in use.
Introduction
CAUTION:
• When folding the appliance as it is possible for loose clothing or
ngers to become trapped and cause injury to the user.
• When in use the surface of the appliance will be hot, therefore
ensure that it has cooled down properly prior to moving or
cleaning it.
• To avoid a hazard for very young children, this clothes rail should
be installed so that the lowest heated rail is at least 60cm above
oor level.
6
1. Remove all of the packaging materials.
Check that there are no parts missing.
2. Insert a support bar(7) into one of the
feet(10).
3. Insert a screw into the foot as shown,
and use a screwdriver to tighten the
screw in place.
4. Repeat the same process for the 2nd
foot.
Before First Use
How to Use
Set the airer up on a dry
level oor near a plug
socket, ensuring there is
plenty of space around it.
Open all of the support
legs(10)
Unclip the Shelf Clips(6)
1 2 3
7
Lower the shelves(3,4,5)
carefully until they are
fully open in a horizontal
position.
Load your wet laundry
onto the airer.
Plug in the cable to the
wall socket.
Once you’ve loaded your
laundry onto the bars,
switch the airer on
Your airer is now ready
to use.
4
7
5
8
6
8
IMPORTANT:
• Do not immerse the power cable, plug or the airer itself into water
or any liquid. Do not pour water or any liquid over the airer.
• Do not use detergents, abrasive cleaning products or any kind of
polishing material on the body of the airier as this can damage the
nish.
• Do not use alcohol or solvent-based cleaners on the plastic
components, as this will cause the cracking and ageing of these
parts.
Before cleaning, turn off the airer by the switch. Unplug the power cable and allow
the airier to cool down.
To clean the airer use a dry cloth to remove any dust or dirt. If there are stubborn
areas of dirt, use a damp well-wrung cloth to wipe over the airer. Leave to air dry
or use a dry cloth afterwards to dry it.
Cleaning and Maintenance
9
Warranty
1 Year Guarantee from Shine-Mart Ltd, Trademark owners of Duronic Products.
NOTE: THESE STATEMENTS DO NOT AFFECT YOUR STATUTORY RIGHTS AS A
CONSUMER
This product has been manufactured under the strictest or quality control procedures, and
using the highest quality of materials, to ensure excellent performance and reliability. It will
give very good and long lasting service, provided it is properly used and maintained. The
product is guaranteed for 1 years from the date of original purchase. If any defect arises due
to a faulty materials or poor workmanship, the faulty product must be returned to the original
place of purchase. Refund or replacement is at the discretion of that company.
Duronic Products are offered with a 1 year guarantee under the following conditions:
1. The product must be returned to the retailer with original proof of purchase.
2. The product must be installed and used in accordance with the instructions
contained in this operating manual.
3. It must be used only for domestic purposes.
4. It does not cover wear and tear, malicious damage, misuse, neglect,
inexpert repairs or consumable parts.
5. Shine-Mart Ltd has no responsibilities for accidental or consequential loss or damage.
6. Shine-Mart Ltd are not liable to carry out any type of servicing work,
under the guarantee
7. Valid in the UK only
This product is tted with CE:1363 plug and fuse
Imported by Shine-Mart Ltd, RM3 8SB
Information on waste Disposal for Consumers of
Electrical & Electronic Equipment.
This mark on a product and/or accompanying documents indicates that when it
is to be disposed of, it must be treated as Waste
Electrical & Electronic Equipment, (WEEE).
Any WEEE marked products must not be mixed with general household waste,
but kept separate for the treatment, recovery and recycling of the materials used.
For proper treatment, recovery and recycling; please take all WEEE marked
waste to your Local Authority Civic waste site,
where it will be accepted free of charge.
If customers dispose of Waste Electrical & Electronic Equipment correctly, they
will be helping to save valuable resources and preventing any potential negative
effects upon human health and the environment, of any hazardous materials that
the waste may contain.
