IREX STAINLESS STEEL EXHAUST FOR IR13/16/19 Ø100MM:
IREX1: FLUE END PIPE IREX4: STAINLESS STEEL FLUE RAIN CAP
IREX2:FLUE EXTENSION IREX5: STAINLESS STEEL EXHAUST MUFFLER
IREX3: FLUE 90° BEND
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
9 Read instructions carefully prior to installation
9 MUST only be used in conjunction with Sealey IR13, IR16 and IR19 Infrared diesel heaters.
9 Ensurecutsthataremadeintoanystructuralwallsarecarriedoutbyaqualiedperson.
9 Heater MUST be at least 500mm from the wall.
9 Pleaseremovecasterswheninstallingtheexhaustuessothatthemachinecannotmovefreely.
9 SectionsIREX1,IREX2andIREX3requirenoxingsforinstallation.
8 DO NOT place any objects within 2m of the heater.
2. INSTALLATION
.
3. IREX4re
Covers exhaust, preventing water ingress and damage. Can be quickly installed or
removed when required. Manufactured out of 301 stainless steel. Fits to IREX1 and is
compatible with main units IR13/IR16/IR19.
Refer to
instruction
manual
DO NOT cover Hot surfaces
IREX 1,2,3,4,5 Issue:1 30/04/25
Original Language Version
© Jack Sealey Limited
IREX2
IREX1
IREX3
IREX4
Screw
IREX1
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
REGISTER YOUR
PURCHASE HERE
4. IREX5re IREX5
Sound suppressing muffler filled with an anti-vibration padding. Easy to install. Ø100mm. Manufactured out of strong 301 stainless steel.
Compatible with Sealey IR13/IR16/IR19 models.
