MAGNETIC ROTATING SPOTLIGHT 6W COB
LED, 400LM
MODEL NO: LEDSPH01
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. GENERAL
9 Ensure the lamp is fully charged before initial use.
8 DO NOT turn the lamp on when it is being charged.
8 DO NOT shine directly into your, other person’s or an animal’s eyes.
8 DO NOT allow children to use the lamp.
8 DO NOT handle or move the lamp whilst it is being charged.
8 DO NOT use the lamp if you suspect that the battery, the lamp casing or the cable is damaged. Consult your Sealey Stockist.
8 DO NOT leave battery in a discharged state, recharge battery immediately. Before storage, fully recharge the battery,
subsequently recharge the battery at least once every six months of non-use.
1.2. BATTERY SAFETY
WARNING! To reduce the risk of burns or re:
8 DO NOT Attempt to open, dismantle, modify or service the battery pack.
8 DO NOT Crush, puncture, short external contacts or dispose of in re or water.
8 DO NOT Expose to temperatures above 40°C or below -10°C.
8 DO NOT Expose to direct sunlight for long periods of time.
8 DO NOT Expose to moisture.
WARNING! Do not place the lamp face down while in use.
9 Replace only with the battery pack designated for this product.
9 Recycle or dispose of used battery as stipulated by local regulation.
9 If the electrolyte in the cells gets on your skin, wash thoroughly with soap and water. If it gets in your eyes, rinse thoroughly with cool
water and seek immediate medical attention.
2. INTRODUCTION
I Super bright 6W COB LED produces up to 400 lumens with a wide spread of light, illuminating the whole work area. Easy-to-read
charge indicator shows the battery status while charging. Charges via a USB Type-C cable (supplied). Rotating ball is convenient to
position and light can be smoothly positioned to direct light where required. Light can be detached from its magnetic base and used in
your palm as an inspection light. 3.7V 1.8Ah Lithium polymer battery for extended battery life with a long runtime of 2hrs on maximum
brightness.
3. SPECIFICATION
4. OPERATION
4.1. CHARGING THE BATTERY
4.1.1. To charge the battery, plug the charging cable into the
charging port located at the top of the light. See g.1
4.2. TURNING THE LIGHT ON AND ADJUSTING
BRIGHTNESS
4.2.1. To turn the light on, press the power button located below the bulb on the light. (Fig 2) There are two brightness settings to choose
from, keep pressing the power button to cycle through them. Press the button again to turn the light off.
LEDSPH01 Issue 1 02/06/2025
Original Language Version
© Jack Sealey Limited
g.1
Refer to
instructions
Model No: LEDSPH01
LED Type: 6W COB
Lumen Output: High/Low: 400/200lm
Nett Weight: 0.23kg
Operating Time: High/Low: 2/10hr
LEDSPH01
Charging
Port
Magnetic base
5. MAINTENANCE
5.2.1. To maintain optimal performance, always turn off and unplug
the light before cleaning. Wipe the exterior with a soft, dry
cloth, or use a slightly damp cloth for more stubborn dirt, avoid
abrasive cleaners or solvents. Periodically check the charging
port and power button for dust or debris, and clean gently if
needed.
5.2.2. Inspect the light for any signs of damage, such as cracks or
loose components, and discontinue use if any are found.
5.2.3. When not in use, store the light in a cool, dry place, away from
moisture and direct sunlight.
5.1. END OF LIFE
5.1.1. At the end of its useful life, do not dispose of the light with
regular household waste. This product contains electronic
components and a rechargeable battery that must be recycled or disposed of in accordance with local environmental regulations.
Contact your local waste disposal authority or recycling centre for information on proper disposal methods. Responsible disposal helps
protect the environment and ensures that valuable materials can be reused.
LEDSPH01 Issue 1 02/06/2025
Original Language Version
© Jack Sealey Limited
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
BATTERY REMOVAL
Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential purchasers of products
containing batteries (as defined within these regulations), that they are registered with Valpak’s registered compliance scheme. Jack
Sealey Ltd’s Batteries Producer Registration Number (BPRN) is BPRN00705.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
g.2
Charging Indicator Light
Red light – Charging
Green light – Fully charged
Power button and
adjusting brightness
function
